Nokia RM-313 User manual

Service Manual
RM-313 (Nokia N82; L3&4)
Part No: (Issue 1)
Nokia Customer Care
COMPANY CONFIDENTIAL
Copyright © 2007 Nokia. All rights reserved.

Amendment Record Sheet
Amendment No Date Inserted By Comments
Issue 1 11/2007 ATu
RM-313
Amendment Record Sheet
Page ii COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Copyright
Copyright © 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form
without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of Nokia
Corporation. Other product and company names mentioned herein may be trademarks or tradenames of
their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of
any kind, either express or implied, including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this
document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.
RM-313
Copyright
Issue 1 COMPANY CONFIDENTIAL Page iii
Copyright © 2007 Nokia. All rights reserved.

Warnings and cautions
Warnings
• IF THE DEVICE CAN BE INSTALLED IN A VEHICLE, CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED
WITH ELECTRONIC ENGINE MANAGEMENT SYSTEMS AND ANTI-SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT
CONDITIONS, EMITTED RF ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/
MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC SYSTEMS TO RF ENERGY.
•THE PRODUCT MUST NOT BE OPERATED IN AREAS LIKELY TO CONTAIN POTENTIALLY EXPLOSIVE ATMOSPHERES,
FOR EXAMPLE, PETROL STATIONS (SERVICE STATIONS), BLASTING AREAS ETC.
• OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR TELEPHONES, MAY INTERFERE
WITH THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE
MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY
ALSO BE SUBJECT TO INTERFERENCE.
• BEFORE MAKING ANY TEST CONNECTIONS, MAKE SURE YOU HAVE SWITCHED OFF ALL EQUIPMENT.
Cautions
• Servicing and alignment must be undertaken by qualified personnel only.
• Ensure all work is carried out at an anti-static workstation and that an anti-static wrist strap is worn.
• Ensure solder, wire, or foreign matter does not enter the telephone as damage may result.
• Use only approved components as specified in the parts list.
• Ensure all components, modules, screws and insulators are correctly re-fitted after servicing and
alignment.
• Ensure all cables and wires are repositioned correctly.
•Never test a mobile phone WCDMA transmitter with full Tx power, if there is no possibility to perform the
measurements in a good performance RF-shielded room. Even low power WCDMA transmitters may disturb
nearby WCDMA networks and cause problems to 3G cellular phone communication in a wide area.
• During testing never activate the GSM or WCDMA transmitter without a proper antenna load, otherwise
GSM or WCDMA PA may be damaged.
RM-313
Warnings and cautions
Page iv COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

ESD protection
Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing
the phone.
Any product of which the covers are removed must be handled with ESD protection. The SIM card can be
replaced without ESD protection if the product is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be damaged by static electricity
discharge.
All ESD sensitive parts must be packed in metallized protective bags during shipping and handling outside
any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product components must be done under
ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD Protected Area.
For more information and local requirements about ESD protection and ESD Protected Area, contact your local
Nokia After Market Services representative.
RM-313
ESD protection
Issue 1 COMPANY CONFIDENTIAL Page v
Copyright © 2007 Nokia. All rights reserved.

Care and maintenance
This product is of superior design and craftsmanship and should be treated with care. The suggestions below
will help you to fulfil any warranty obligations and to enjoy this product for many years.
• Keep the phone and all its parts and accessories out of the reach of small children.
•Keep the phone dry. Precipitation, humidity and all types of liquids or moisture can contain minerals that
will corrode electronic circuits.
• Do not use or store the phone in dusty, dirty areas. Its moving parts can be damaged.
•Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
• Do not store the phone in cold areas. When it warms up (to its normal temperature), moisture can form
inside, which may damage electronic circuit boards.
• Do not drop, knock or shake the phone. Rough handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone.
• Do not paint the phone. Paint can clog the moving parts and prevent proper operation.
• Use only the supplied or an approved replacement antenna. Unauthorised antennas, modifications or
attachments could damage the phone and may violate regulations governing radio devices.
All of the above suggestions apply equally to the product, battery, charger or any accessory.
RM-313
Care and maintenance
Page vi COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Company Policy
Our policy is of continuous development; details of all technical modifications will be included with service
bulletins.
While every endeavour has been made to ensure the accuracy of this document, some errors may exist. If
any errors are found by the reader, NOKIA MOBILE PHONES Business Group should be notified in writing/e-
mail.
Please state:
• Title of the Document + Issue Number/Date of publication
• Latest Amendment Number (if applicable)
• Page(s) and/or Figure(s) in error
Please send to:
NOKIA CORPORATION
Nokia Mobile Phones Business Group
Nokia Customer Care
PO Box 86
FIN-24101 SALO
Finland
E-mail: [email protected]
RM-313
Company Policy
Issue 1 COMPANY CONFIDENTIAL Page vii
Copyright © 2007 Nokia. All rights reserved.

Battery information
Note: A new battery's full performance is achieved only after two or three complete charge and
discharge cycles!
The battery can be charged and discharged hundreds of times but it will eventually wear out. When the
operating time (talk-time and standby time) is noticeably shorter than normal, it is time to buy a new battery.
Use only batteries approved by the phone manufacturer and recharge the battery only with the chargers
approved by the manufacturer. Unplug the charger when not in use. Do not leave the battery connected to
a charger for longer than a week, since overcharging may shorten its lifetime. If left unused a fully charged
battery will discharge itself over time.
Temperature extremes can affect the ability of your battery to charge.
For good operation times with Li-Ion batteries, discharge the battery from time to time by leaving the product
switched on until it turns itself off (or by using the battery discharge facility of any approved accessory
available for the product). Do not attempt to discharge the battery by any other means.
Use the battery only for its intended purpose.
Never use any charger or battery which is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object (coin, clip or
pen) causes direct connection of the + and - terminals of the battery (metal strips on the battery) for example
when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the battery
or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions, will reduce
the capacity and lifetime of the battery. Always try to keep the battery between 15°C and 25°C (59°F and 77°
F). A phone with a hot or cold battery may temporarily not work, even when the battery is fully charged.
Batteries' performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire!
Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as household waste.
RM-313
Battery information
Page viii COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Nokia N82; L3&4 Service Manual Structure
1 General Information
2 Service Tools and Service Concepts
3 BB Troubleshooting and Tuning Guide
4 RF troubleshooting
5 Camera Module Troubleshooting
6 System Module
Glossary
RM-313
Nokia N82; L3&4 Service Manual Structure
Issue 1 COMPANY CONFIDENTIAL Page ix
Copyright © 2007 Nokia. All rights reserved.

RM-313
Nokia N82; L3&4 Service Manual Structure
(This page left intentionally blank.)
Page x COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

1 — General Information
Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 1 –1
Copyright © 2007 Nokia. All rights reserved.

RM-313
General Information
(This page left intentionally blank.)
Page 1 –2 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Table of Contents
Product selection....................................................................................................................................................1–5
Product features and sales package.....................................................................................................................1–5
Mobile enhancements............................................................................................................................................1–8
Technical specifications...................................................................................................................................... 1–10
Transceiver general specifications ............................................................................................................... 1–10
Main RF characteristics for GSM850/900/1800/1900 and WCDMA 2100 phones ..................................... 1–11
Battery endurance.......................................................................................................................................... 1–11
Environmental conditions ............................................................................................................................. 1–12
List of Tables
Table 1 Audio..........................................................................................................................................................1–8
Table 2 Car...............................................................................................................................................................1–9
Table 3 Data ............................................................................................................................................................1–9
Table 4 GPS........................................................................................................................................................... 1–10
Table 5 Messaging............................................................................................................................................... 1–10
Table 6 Power...................................................................................................................................................... 1–10
Table 7 Carrying................................................................................................................................................... 1–10
List of Figures
Figure 1 View of RM-313........................................................................................................................................1–5
RM-313
General Information
Issue 1 COMPANY CONFIDENTIAL Page 1 –3
Copyright © 2007 Nokia. All rights reserved.

RM-313
General Information
(This page left intentionally blank.)
Page 1 –4 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Product selection
RM-313 is a WCDMA/GSM dual mode handportable phone, supporting EGSM850/900/1800/1900 and
WCDMA2100.
RM-313 is a 3GPP Release 5 terminal supporting WCDMA/HSDPA, EGPRS and GPRS data bearers. For WCDMA
HSDPA the maximum bit rate is up to 3.6 Mbps for downlink and 384 kbps for uplink with simultaneous CS
speech or CS video (max. 64 kbps).
For 2G and 2.5G networks the RM-313 is a Class A EGPRS DTM MSC 11 which means maximum download speed
of up to 236.8 kbps simultaneously with speech or Class B EGPRS MSC 32 which means a in maximum download
speed of up to 296kbit/s with EGPRS, and up to 107kbit/s with GPRS.
According to GSM standard 05.05 it responds to class 4 (max. 2W) in GSM 850 and EGSM 900 class 1 (1W) in
DCS 1800 and class 1 in PCS 1900. RM-313 supports EGPRS (EDGE) class B as well as Bluetooth 2.0 EDR standard.
RM-313 supports two way video calls with two integrated cameras, one on the front and one on the back.
RM-313 is an MMS (Multimedia Messaging Service) enabled multimedia computer with a 2.4’’ QVGA (240 x
320 pixels) TFT colour display and an integrated 5 Megapixel auto focus camera. The MMS implementation
follows the OMA MMS standard release 1.2. The Browser is a highly advanced internet browser also capable
of viewing operator domain XHTML Mobile Profile (MP) content.
RM-313 uses Symbian 9.2 operating system and supports also MIDP Java 2.0 & CLDC1.1, providing a good
platform for compelling 3rd party applications.
Figure 1 View of RM-313
Product features and sales package
Imaging
Main camera:
RM-313
General Information
Issue 1 COMPANY CONFIDENTIAL Page 1 –5
Copyright © 2007 Nokia. All rights reserved.

• Sensor: CMOS, 5 megapixel
• Carl Zeiss Optics: Tessar™ lens
• F number/Aperture: F2.8
• Focal length: 5.6 mm
35 mm (35 mm equiv.)
• Focus range: 10 cm ~ infinity
• Macro focus distance: 10-50 cm
• Shutter speed: Mechanical shutter 1/1000~1/4 s
• Lens protection: Sliding cover with activation
Video:
• Video resolution: up to VGA at 30 fps
• Audio recording: AAC (AMR for MMS)
• Video stabilization
• Video clip length: 59 min 59 sec
• Video file format: .mp4 (default) , .3gp (for MMS)
• White balance: automatic, sunny, cloudy, incandescent, fluorescent
• Scene: Auto, Night
• Colour tone: normal, sepia, B&W, vivid, negative
• Zoom (optical/digital): 1x / up to 10x (VGA 4X)
Photo:
• Still image resolutions: up to 5 megapixel: 2592 x 1944
• Still image file format: JPEG/EXIF
• Auto focus
• Auto exposure: center weighted AE
• Image orientation: automatic
• Exposure compensation: +2 ~ -2EV at 0.5 step
• White balance: automatic, sunny, cloudy, incandescent, fluorescent
• Scene: auto, sports, portrait, close-up, landscape, night, user defined
• Colour tone: normal, sepia, B&W, vivid, negative
• Zoom (digital): up to 20x (5Mpix 6X)
Other camera features:
• Xenon flash and recording indicator
• Front camera, CIF (352 x 288) sensor
Edit
• On device Photo editor and Video editor (manual & automatic)
View
• 2.4” QVGA (240 x 320 pixels) TFT colour display, ambient light detector - used to optimize display and
keypad backlight brightness and power consumption
• Slideshow from Gallery
RM-313
General Information
Page 1 –6 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Share
• Nokia XpressShare - share effortlessly from Gallery or after capture via Email, Bluetooth or MMS
• Direct connection to TV via cable or WLAN (UPnP)
• Video call and video sharing support. (WCDMA services)
• Online Album : Image/Video uploading from Gallery
Print
•Nokia XpressPrint – direct printing via USB (PictBridge), Bluetooth (BPP), and WLAN (UPnP), from memory
card or via online printing
Store
• Nokia XpressTransfer – easy to transfer and organize photos and video between your device and a
compatible PC
• Photoshop Album 3.0 Starter Edition (PC)
• Nokia Lifeblog (mobile & PC)
Music
• Digital music player: supports MP3/AAC/M4A/WMA with playlists
• Dedicated music keys
• OMA DRM 2.0 & WMDRM support for music
• Stereo FM radio (87.5-108MHz)
• Integrated stereo handsfree speakers
• Music headset HS-44 & music remote AD-43
Media
• Mobile TV experience with video streaming
• Full web browser support (HTML)
• Visual Radio™ support
Productivity
Messaging:
• E-mail (SMTP, IMAP4, POP3), MMS, SMS
Office applications:
• Viewing of email attachments – .doc, .xls, .ppt, . pdf
PIM:
• Contacts, calendar, to-do, notes, recorder, calculator, clock, converter
Synchronization:
• Local/Remote (using SyncML)
• Data: Calendar, Contacts, To-do, Notes, E-mail
• PC Applications: Microsoft Outlook (98, 2000, 2002, 2003), Outlook Express, Lotus Organizer (5.0, 6.0),
Lotus Notes (5.0, 6.0)
Call management:
• Call logs, speed dial, voice dialling (with SIND) and voice commands
RM-313
General Information
Issue 1 COMPANY CONFIDENTIAL Page 1 –7
Copyright © 2007 Nokia. All rights reserved.

• Nokia Push to Talk (PoC)
Connectivity
• WLAN - IEEE802.11 g/b with UPnP support
• Micro USB type B interface with USB 2.0 full speed
• 3.5mm stereo headphone plug and TV out support (PAL/NTSC)
• Bluetooth wireless technology 2.0 with A2DP stereo audio
Add-on software framework
• Symbian 9.2 OS
• Nokia Series 60, 3rd edition, feature pack 3.1
• Java: MIDP2.0
• C++ and Java SDKs
Additional technical specifications
• Vibrating alert
• 3GPP Rel 5 compliant
• Speech codecs supported in WCDMA: AMR
• Speech codecs supported in GSM: FR AMR/HR AMR/EFR/FR/HR
• WCDMA HSDPA 2100 MHz with simultaneous voice and packet data (PS max speed DL/UL= 3.6Mbps/
384kbps, CS max speed 64kbps)
• Dual Transfer Mode (DTM) support for simultaneous voice and packet data connection in GSM/EDGE
networks. Simple class A, multi slot class 11, max speed DL/UL: 118.4/118.4kbits/s
• EGPRS class B, multi slot class 32, (5 Rx + 3 Tx / Max Sum 6), max speed DL/UL= 296 / 177.6 kbits/s
• GPRS class B, multi slot class 32 (5 Rx + 3 Tx / Max Sum 6), max speed DL/UL= 107 / 64.2 kbits/s
• GPS
Sales package
• Transceiver RM-313
• Charger (AC-5)
• Battery (BP-6MT)
• Music headset (HS-43)
• Connectivity cable (CA-101)
• Video out cable (CA-75U)
• MicroSD card (MU-37)
Mobile enhancements
Table 1 Audio
Enhancement Type
Music headset HS-44 with AD-43 3.5mm stereo plug, HS-45 with
AD-54 3.5mm stereo plug
Basic headset HS-41
Stereo headset HS-48, HS-16, HS-43
RM-313
General Information
Page 1 –8 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Enhancement Type
Bluetooth headset BH-900, BH-902 & BH-903
BH-800
STEREO BH-501
BH-601
MONO BH-200, BH-201
BH-202
BH-303
BH-300
BH-702
BH-500
BH-600, BH-602 & BH-604
BH-101
BH-803
Wireless stereo gateway AD-42W
Music headphone HS-61
Advanced headphone HS-62
Music speaker MD-3
Mini speaker MD-4, MD-6
Audio Adapter AD-53, AD-63
BT speakers MD-5W, MD-7W
FM transmitters CA-300
Table 2 Car
Enhancement Type
Mobile charger DC-4
Wireless plug-in car handsfree HF-500
HF-33W
HF-300
Car kit Nokia 616, 810
Multimedia car kit CK-20W, CK-7W & CK-15W
Table 3 Data
Enhancement Type
Connectivity cable CA-101
RM-313
General Information
Issue 1 COMPANY CONFIDENTIAL Page 1 –9
Copyright © 2007 Nokia. All rights reserved.

Enhancement Type
Video connectivity cable CA-75U
MicroSD card 128MB - 2GB
Table 4 GPS
Enhancement Type
Wireless GPS module LD-3W
Navigation pack LD-2
Table 5 Messaging
Enhancement Type
Digital pen SU-27W
Wireless keyboard SU-8W
Table 6 Power
Enhancement Type
Battery 1050mAh Li-ion BP-6MT
Travel charger AC-5
AC-6, CA-100
Charger adapter CA-44
Table 7 Carrying
Enhancement Type
Carrying case
Technical specifications
Transceiver general specifications
Unit Dimensions (L x W x T)
(mm) Weight (g) Volume (cm3)
Transceiver with
BP-6MT 1050mAh li-ion
battery back
112 x 50.2 x 17.3 ~ 120
RM-313
General Information
Page 1 –10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
