Nokia RM-632 User manual

Service Manual
RM-632; RM-634; RM-699 (Nokia E5-00; L3&4)
Part No: (Issue 3)
Nokia Customer Care
COMPANY CONFIDENTIAL
Copyright © 2010 Nokia. All rights reserved.

Amendment Record Sheet
Amendment No Date Inserted By Comments
Issue 1 4/2010 NS
Issue 2 8/2010 NS RM-634 added.
Issue 3 11/2010 KF RM–699 added.
RM-632; RM-634; RM-699
Amendment Record Sheet
Page ii COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

Copyright
Copyright © 2010 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form
without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of Nokia
Corporation. Other product and company names mentioned herein may be trademarks or tradenames of
their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of
any kind, either express or implied, including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this
document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.
RM-632; RM-634; RM-699
Copyright
Issue 3 COMPANY CONFIDENTIAL Page iii
Copyright © 2010 Nokia. All rights reserved.

Warnings and cautions
Warnings
•IF THE DEVICE CAN BE INSTALLED IN A VEHICLE, CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED
WITH ELECTRONIC ENGINE MANAGEMENT SYSTEMS AND ANTI-SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT
CONDITIONS, EMITTED RF ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/
MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC SYSTEMS TO RF ENERGY.
•THE PRODUCT MUST NOT BE OPERATED IN AREAS LIKELY TO CONTAIN POTENTIALLY EXPLOSIVE ATMOSPHERES,
FOR EXAMPLE, PETROL STATIONS (SERVICE STATIONS), BLASTING AREAS ETC.
•OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR TELEPHONES, MAY INTERFERE
WITH THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE
MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY
ALSO BE SUBJECT TO INTERFERENCE.
•BEFORE MAKING ANY TEST CONNECTIONS, MAKE SURE YOU HAVE SWITCHED OFF ALL EQUIPMENT.
Cautions
•Servicing and alignment must be undertaken by qualified personnel only.
•Ensure all work is carried out at an anti-static workstation and that an anti-static wrist strap is worn.
•Ensure solder, wire, or foreign matter does not enter the telephone as damage may result.
•Use only approved components as specified in the parts list.
•Ensure all components, modules, screws and insulators are correctly re-fitted after servicing and
alignment.
•Ensure all cables and wires are repositioned correctly.
•Never test a mobile phone WCDMA transmitter with full Tx power, if there is no possibility to perform the
measurements in a good performance RF-shielded room. Even low power WCDMA transmitters may disturb
nearby WCDMA networks and cause problems to 3G cellular phone communication in a wide area.
•During testing never activate the GSM or WCDMA transmitter without a proper antenna load, otherwise
GSM or WCDMA PA may be damaged.
RM-632; RM-634; RM-699
Warnings and cautions
Page iv COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

For your safety
QUALIFIED SERVICE
Only qualified personnel may install or repair phone equipment.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible products.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user’s guide for detailed safety instructions. Do not connect
incompatible products.
RM-632; RM-634; RM-699
For your safety
Issue 3 COMPANY CONFIDENTIAL Page v
Copyright © 2010 Nokia. All rights reserved.

Care and maintenance
This product is of superior design and craftsmanship and should be treated with care. The suggestions below
will help you to fulfil any warranty obligations and to enjoy this product for many years.
•Keep the phone and all its parts and accessories out of the reach of small children.
•Keep the phone dry. Precipitation, humidity and all types of liquids or moisture can contain minerals that
will corrode electronic circuits.
•Do not use or store the phone in dusty, dirty areas. Its moving parts can be damaged.
•Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
•Do not store the phone in cold areas. When it warms up (to its normal temperature), moisture can form
inside, which may damage electronic circuit boards.
•Do not drop, knock or shake the phone. Rough handling can break internal circuit boards.
•Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone.
•Do not paint the phone. Paint can clog the moving parts and prevent proper operation.
•Use only the supplied or an approved replacement antenna. Unauthorised antennas, modifications or
attachments could damage the phone and may violate regulations governing radio devices.
All of the above suggestions apply equally to the product, battery, charger or any accessory.
RM-632; RM-634; RM-699
Care and maintenance
Page vi COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

ESD protection
Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing
the phone.
Any product of which the covers are removed must be handled with ESD protection. The SIM card can be
replaced without ESD protection if the product is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be damaged by static electricity
discharge.
All ESD sensitive parts must be packed in metallized protective bags during shipping and handling outside
any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product components must be done under
ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD Protected Area.
For more information and local requirements about ESD protection and ESD Protected Area, contact your local
Nokia After Market Services representative.
RM-632; RM-634; RM-699
ESD protection
Issue 3 COMPANY CONFIDENTIAL Page vii
Copyright © 2010 Nokia. All rights reserved.

Battery information
Note: A new battery's full performance is achieved only after two or three complete charge and
discharge cycles!
The battery can be charged and discharged hundreds of times but it will eventually wear out. When the
operating time (talk-time and standby time) is noticeably shorter than normal, it is time to buy a new battery.
Use only batteries approved by the phone manufacturer and recharge the battery only with the chargers
approved by the manufacturer. Unplug the charger when not in use. Do not leave the battery connected to
a charger for longer than a week, since overcharging may shorten its lifetime. If left unused a fully charged
battery will discharge itself over time.
Temperature extremes can affect the ability of your battery to charge.
For good operation times with Li-Ion batteries, discharge the battery from time to time by leaving the product
switched on until it turns itself off (or by using the battery discharge facility of any approved accessory
available for the product). Do not attempt to discharge the battery by any other means.
Use the battery only for its intended purpose.
Never use any charger or battery which is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object (coin, clip or
pen) causes direct connection of the + and - terminals of the battery (metal strips on the battery) for example
when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the battery
or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions, will reduce
the capacity and lifetime of the battery. Always try to keep the battery between 15°C and 25°C (59°F and 77°
F). A phone with a hot or cold battery may temporarily not work, even when the battery is fully charged.
Batteries' performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire!
Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as household waste.
RM-632; RM-634; RM-699
Battery information
Page viii COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

Company policy
Our policy is of continuous development; details of all technical modifications will be included with service
bulletins.
While every endeavour has been made to ensure the accuracy of this document, some errors may exist. If
any errors are found by the reader, NOKIA MOBILE PHONES Business Group should be notified in writing/e-
mail.
Please state:
•Title of the Document + Issue Number/Date of publication
•Latest Amendment Number (if applicable)
•Page(s) and/or Figure(s) in error
Please send to:
NOKIA CORPORATION
Nokia Mobile Phones Business Group
Nokia Customer Care
PO Box 86
FIN-24101 SALO
Finland
E-mail: [email protected]
RM-632; RM-634; RM-699
Company policy
Issue 3 COMPANY CONFIDENTIAL Page ix
Copyright © 2010 Nokia. All rights reserved.

RM-632; RM-634; RM-699
Company policy
(This page left intentionally blank.)
Page x COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

Nokia E5-00; L3&4 Service Manual Structure
1 General information
2 Service Devices and Service Concepts
3 BB Troubleshooting and Manual Tuning Guide
4 RF troubleshooting
5 System Module
6 Service information differences between RM-632 and RM-634
7 Service information differences between RM-632 and RM-699
Glossary
RM-632; RM-634; RM-699
Nokia E5-00; L3&4 Service Manual Structure
Issue 3 COMPANY CONFIDENTIAL Page xi
Copyright © 2010 Nokia. All rights reserved.

RM-632; RM-634; RM-699
Nokia E5-00; L3&4 Service Manual Structure
(This page left intentionally blank.)
Page xii COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

1 — General information
Nokia Customer Care
Issue 3 COMPANY CONFIDENTIAL Page 1 – 1
Copyright © 2010 Nokia. All rights reserved.

RM-632; RM-634; RM-699
General information
(This page left intentionally blank.)
Page 1 – 2 COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

Table of Contents
Product selection................................................................................................................................................... 1–5
Phone features ...................................................................................................................................................... 1–5
Software and user interface features.................................................................................................................. 1–6
Accessories............................................................................................................................................................. 1–6
Technical specifications........................................................................................................................................ 1–7
General specifications...................................................................................................................................... 1–7
Main RF characteristics for GSM850/900/1800/1900 and WCDMA band I, II and VIII phones .................. 1–8
Battery endurance............................................................................................................................................ 1–9
Environmental conditions ............................................................................................................................... 1–9
List of Tables
Table 1 Battery and chargers ............................................................................................................................... 1–7
Table 2 Car accessories ......................................................................................................................................... 1–7
Table 3 Headsets ................................................................................................................................................... 1–7
Table 4 Cables ........................................................................................................................................................ 1–7
List of Figures
Figure 1 RM-632 (Nokia E5-00) product picture................................................................................................. 1–5
RM-632; RM-634; RM-699
General information
Issue 3 COMPANY CONFIDENTIAL Page 1 – 3
Copyright © 2010 Nokia. All rights reserved.

RM-632; RM-634; RM-699
General information
(This page left intentionally blank.)
Page 1 – 4 COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

Product selection
RM-632 (Nokia E5-00) is a GSM/WCDMA dual mode phone, supporting EGSM850/900/1800/1900 and WCDMA
bands I, II and VIII.
Figure 1 RM-632 (Nokia E5-00) product picture
Phone features
Display and keypad features
•Horizontal 2.36" QVGA display with 256K colors
•Full QWERTY, Home key + Messaging, Call and End keys, 4 way + select, Volume keys
Hardware features
•Main camera: 5 megapixel EDOF camera with integrated flash
•MicroUSB connector/charger plug for data transfer (USB 2.0) and charging
•High speed USB (FS/HS)
•2 mm charger plug interface
•Bluetooth version 2.0
•microSD memory card connector
•Stereo Music Player
•Integrated handsfree speaker
•Internal vibra
•Plug-in SIM 1.8V and 3.0V, more than 1000 entries
•Nokia 3.5mm AV connector
•FM-radio with headset as antenna
RM-632; RM-634; RM-699
General information
Issue 3 COMPANY CONFIDENTIAL Page 1 – 5
Copyright © 2010 Nokia. All rights reserved.

RF features
•Ïnternal antennas
•GSM/EDGE 850/900/1800/1900
•WCDMA band I, II and VIII
•High speed upload - HSUPA cat 5 (2.0 Mbps)
•High speed download - HSDPA cat 9 (10.2 Mbps)
•EDGE: MSC 32
•GPRS: MSC 32
•CSD for browsing and as data modem
Software and user interface features
Selection of software application and features
•Operating System: Symbian v. 9.3
•User Interface: S60 3rd Edition, Feature Pack 2
•PIM: Contacts, Calendar, To-do, Notes & Active Notes, Recorder, Calculator, Clock, Converter
•Call management: call logs, speed dial, enhanced voice dialing, talking ring tone
•People centric home screen
•3D stereo ringing tones, Up to 64 Polyphonic Midi, MP3 tones, video ringing tones
•OMA DRM 2.0, OMA DRM2 video, Windows DRM, WMV
•Offline mode, and SIM-less operation
•Flashlite 3.0, Java TM MIDP 2.0
•FM radio
•Audio messaging
•Java &Api's MIDP2.0, JSR75 (file connection and PIM), JSR82 (BT), JSR135, JSR139 (CLDC1.1), JSR184 (3D),
JSR185 (JTWI R1)
•3GPP H.263 playback+streaming, H.264 and MPEG4
•Video, MP3, AAC and 64 polyphonic ringing tones
•Music Player for MP3, AAC, AAC+, eAAC+, WMA
•WAP 2.0, XHTML browser over HTTP/TCP/IP stack
•OMA SyncML 1.1.2 (local)
Accessories
Sales package contents
•Nokia E5-00 phone
•Nokia Battery BL-4D
•Travel Charger AC-8E
•Nokia Stereo Headset WH-102
•Nokia Micro USB Cable CA-101D
•Nokia MU-37, 2 GB micro SD
RM-632; RM-634; RM-699
General information
Page 1 – 6 COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.

Table 1 Battery and chargers
Type Name
Note: This phone is charged through the smaller Nokia standard charger interface (2.0 mm plug). A 3.5
mm compatible Nokia standard charger can be used together with the CA-44 charger adapter.
BL-4D Battery 1200 mAh Li-Ion
AC-8 Travel Charger
AC-6 USB charger
Table 2 Car accessories
Type Name
CK-100 Bluetooth car kit
DC-9 Mobile charger
HK-510 Plug-In car kit with display and DSP
Table 3 Headsets
Type Name
Wired
WH-102 Stereo headset
Wireless
BH-105 Bluetooth headset
BH-214 Bluetooth stereo headset
Table 4 Cables
Type Name
CA-101D Micro USB cable
Technical specifications
General specifications
Unit Dimension (mm) Weight (g) Volume (cc)
RM-632 transceiver with
BL-4D 1200 mAh Li-Ion
battery pack
115*58.9*12.8 128 75
RM-632; RM-634; RM-699
General information
Issue 3 COMPANY CONFIDENTIAL Page 1 – 7
Copyright © 2010 Nokia. All rights reserved.

Main RF characteristics for GSM850/900/1800/1900 and WCDMA band I, II and VIII phones
Parameter Unit
Cellular system GSM850, EGSM900, GSM1800/1900, WCDMA I (2100), WCDMA II (1900)
and WCDMA VIII (900)
Rx frequency band GSM850: 869 - 894 MHz
EGSM900: 925 - 960 MHz
GSM1800: 1805 - 1880 MHz
GSM1900: 1930 - 1990 MHz
WCDMA I (2100): 2110 - 2170 MHz
WCDMA II (1900): 1930 - 1990
WCDMA VIII (900): 925- 960 MHz
Tx frequency band GSM850: 824 - 849 MHz
EGSM900: 880 - 915 MHz
GSM1800: 1710 - 1785 MHz
GSM1900: 1850 - 1910 MHz
WCDMA I (2100): 1920 - 1980 MHz
WCDMA II (1900): 1850 - 1910
WCDMA VIII (900): 880 - 915 MHz
Output power GSM850: +5 ...+33dBm/3.2mW ... 2W
GSM900: +5 … +33dBm/3.2mW … 2W
GSM1800: +0 … +30dBm/1.0mW … 1W
GSM1900: +0 … +30dBm/1.0mW … 1W
WCDMA I (2100): -50 ... +24 dBm/0.01μW ... 251.2mW
WCDMA II (1900): -50 ... +24 dBm/0.01μW ... 251.2mW
WCDMA VIII (900): -50 ... +24 dBm/0.01μW ... 251.2mW
Number of RF channels GSM850: 124
GSM900: 174
GSM1800: 374
GSM1900: 299
WCDMA I (2100): 277
WCDMA II (1900): 289
WCDMA VIII (900): 152
Channel spacing 200 kHz
RM-632; RM-634; RM-699
General information
Page 1 – 8 COMPANY CONFIDENTIAL Issue 3
Copyright © 2010 Nokia. All rights reserved.
