Nokia 2630
User's Guide

Copyright © 2007 Nokia. All rights reserved. 1
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-298 product is
in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. A copy of the Declaration of
Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution, or storage of part or all of the
contents in this document in any form without the prior written
permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Xpress-on, Navi, and Visual Radio
are trademarks or registered trademarks of Nokia Corporation. Nokia
tune is a sound mark of Nokia Corporation. Other product and
company names mentioned herein may be trademarks or
tradenames of their respective owners.
US Patent No 5818437 and other pending patents. T9 text input
software Copyright (C) 1997-2007. Tegic Communications, Inc. All
rights reserved.
Includes RSA BSAFE cryptographic or security protocol
software from RSA Security.
0434

2 Copyright © 2007 Nokia. All rights reserved.
Java and all Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio
License (i) for personal and noncommercial use in connection with
information which has been encoded in compliance with the
MPEG-4 Visual Standard by a consumer engaged in a personal and
noncommercial activity and (ii) for use in connection with MPEG-4
video provided by a licensed video provider. No license is granted or
shall be implied for any other use. Additional information, including
that related to promotional, internal, and commercial uses, may be
obtained from MPEG LA, LLC. See <http://www.mpegla.com>.
Nokia operates a policy of ongoing development. Nokia reserves the
right to make changes and improvements to any of the products
described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER
NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE
RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT
AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND,

Copyright © 2007 Nokia. All rights reserved. 3
EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,
RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES
THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY
TIME WITHOUT PRIOR NOTICE. For the most current product
information, please refer to www.nokia.com.hk.
The availability of particular products and applications and services
for these products may vary by region. Please check with your Nokia
dealer for details, and availability of language options.
This device may contain commodities, technology or software
subject to export laws and regulations from the US and other
countries. Diversion contrary to law is prohibited.
The third-party applications provided with your device may have
been created and may be owned by persons or entities not affiliated
with or related to Nokia. Nokia does not own the copyrights or
intellectual property rights to the third-party applications. As such,
Nokia does not take any responsibility for end-user support,
functionality of the applications, or the information in the
applications or these materials. Nokia does not provide any warranty
for the third-party applications.BY USING THE APPLICATIONS YOU
ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS
WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER
ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE
ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED,

4 Copyright © 2007 Nokia. All rights reserved.
INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR
THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY
PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.

Copyright © 2007 Nokia. All rights reserved. 5
Contents
For your safety .............. 6
General information .. 12
Access codes............................ 12
Nokia Support and Contact
Information.............................. 13
1.Get started .............. 14
Install the SIM card and
battery....................................... 14
Remove the SIM card............ 16
Charge the battery................. 18
Normal operating position .. 19
2.Your phone .............. 20
Keys and parts......................... 20
Switch the phone on or
off ............................................... 22
Standby mode ......................... 22
Keypad lock.............................. 23
3.Call functions.......... 24
Make and answer a call ....... 24
Loudspeaker............................. 24
4.Write text................ 25
5.Menu functions ...... 26
Messaging................................ 26
Text and multimedia
message settings ............... 27
Text messages..................... 28
Multimedia messages....... 29
Create text or multimedia
message................................ 30
Flash messages................... 31
Instant messages ............... 31
Audio message ................... 32
Voice messages .................. 33
E-mail application............. 33
Contacts ................................... 35
Log ............................................. 37
Settings .................................... 38
Profiles.................................. 38
Tone settings....................... 39
My shortcuts....................... 39
Call and phone settings... 40
Display settings.................. 40
Time and date settings..... 41
Connectivity ........................ 41
Data transfer....................... 45
Contents

6 Copyright © 2007 Nokia. All rights reserved.
Enhancement settings ...... 47
Configuration settings...... 47
Operator menu........................ 48
Gallery ....................................... 49
Media......................................... 50
Camera and video .............. 50
Voice recorder ..................... 51
Radio...................................... 52
Organiser .................................. 53
Alarm clock .......................... 53
Calendar................................ 54
To-do list .............................. 55
Applications............................. 55
Web............................................ 56
Service connection ............ 57
Browser appearance
settings.................................. 58
Service inbox ....................... 59
Browser security................. 60
SIM services............................. 60
6.Battery information 61
Charging and discharging.... 61
Nokia battery authentication
guidelines ................................. 64
7.Nokia original
enhancements ............. 67
BATTERY ................................... 68
Care and
maintenance................ 69
Additional safety
information ................. 71
Index ............................ 78
Contents

For your safety
Copyright © 2007 Nokia. All rights reserved.
7
For your safety
Read these simple guidelines. Not following them may be dangerous
or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use
is prohibited or when it may cause interference or
danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to
operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference,
which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off near
medical equipment.

For your safety
8 Copyright © 2007 Nokia. All rights reserved.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the device at a refueling point. Do not use
near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the device where
blasting is in progress.
USE SENSIBLY
Use only in the positions as explained in the product
documentation. Do not touch the antenna areas
unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this
product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do
not connect incompatible products.

For your safety
Copyright © 2007 Nokia. All rights reserved.
9
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written
record of all important information stored in your
device.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user
guide for detailed safety instructions. Do not connect
incompatible products.
EMERGENCY CALLS
Ensure the phone function of the device is switched on
and in service. Press the end key as many times as
needed to clear the display and return to the standby
mode. Enter the emergency number, then press the call
key. Give your location. Do not end the call until given
permission to do so.

For your safety
10 Copyright © 2007 Nokia. All rights reserved.
■About your device
The wireless device described in this guide is approved for use on
GSM 900 and 1800 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect
local customs, privacy and legitimate rights of others, including
copyrights.
Copyright protections may prevent some images, music (including
ringing tones), and other content from being copied, modified,
transferred, or forwarded.
Warning: To use any features in this device, other than
the alarm clock, the device must be switched on. Do not
switch the device on when wireless device use may cause
interference or danger.
■Network services
To use the phone you must have service from a wireless service
provider. Many of the features require special network features.
These features are not available on all networks; other networks may
require that you make specific arrangements with your service
provider before you can use the network services. Your service

For your safety
Copyright © 2007 Nokia. All rights reserved.
11
provider can give you instructions and explain what charges will
apply. Some networks may have limitations that affect how you can
use network services. For instance, some networks may not support
all language-dependent characters and services.
Your service provider may have requested that certain features be
disabled or not activated in your device. If so, these features will not
appear on your device menu. Your device may also have a special
configuration such as changes in menu names, menu order, and
icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on
TCP/IP protocols. Some features of this device, such as multimedia
messaging service (MMS), remote synchronization, and accessing
internet with the browser, require network support for these
technologies.

General information
12 Copyright © 2007 Nokia. All rights reserved.
General information
■Access codes
The security code helps to protect your phone against
unauthorized use. You can create and change a code, and
set the phone to request the code.
The PIN code supplied with the SIM card, protects the card
against unauthorized use. The PIN2 code supplied with
some SIM cards, is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in
succession, you are asked for the PUK or PUK2 code. If you
do not have them, contact your local service provider.
The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.
Select Menu > Settings > Security to set how your phone
uses the access codes and security settings.
Nokia_2630_UG_2_hk_en.fm Page 12 Monday, September 24, 2007 2:33 PM

General information
Copyright © 2007 Nokia. All rights reserved.
13
■Nokia Support and Contact
Information
For the latest version of this guide, downloads, services and
additional information related to your Nokia product,
please visit www.nokia.com.hk/support or your local Nokia
web site. You may also download free configuration
settings such as MMS, GPRS, e-mail, and other services for
your phone model at www.nokia.com.hk/settings.
Should you still require assistance, please refer to
www.nokia.com.hk/contactus.

Get started
14 Copyright © 2007 Nokia. All rights reserved.
1. Get started
■Install the SIM card and battery
For availability and information on using SIM card services,
contact your SIM card vendor. This may be the service
provider or other vendor.
Note: Always switch off the power and
disconnect the charger and any other device
before removing the cover. Avoid touching
electronic components while changing the cover.
Always store and use the device with the cover
attached.
1. Push the side release buttons (one on each side of the
cover) (1) to release the back cover (2), and lift it from
the phone.

Get started
Copyright © 2007 Nokia. All rights reserved.
15
2. Insert the SIM card (3). Ensure that the gold-colored
contact area faces down and the beveled corner of the
SIM card is slided in first.
3. Insert the battery into the battery slot (4). Ensure that
the contacts on the top of the battery are facing the
connectors in the phone.

Get started
16 Copyright © 2007 Nokia. All rights reserved.
4. To replace the back cover, position the bottom first,
then press the top of the cover down (5) until it clicks
into place.
■Remove the SIM card
1. Follow step 1 of 'Install the SIM card and battery' to
remove the back cover.
2. Lift the battery out by the groove at the top (1).

Get started
Copyright © 2007 Nokia. All rights reserved.
17
3. With the finger grip, carefully slide the SIM card holder
out (2).
4. Carefully slide out the SIM card from the holder (3).
5. Slide the SIM card holder closed (4).
6. Follow step 3 and 4 of 'Install the SIM card and battery'
to replace the battery and the back cover.

Get started
18 Copyright © 2007 Nokia. All rights reserved.
■Charge the battery
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with
this particular model. The use of any other types
may invalidate any approval or warranty, and may
be dangerous.
Check the model number of any charger before use with
this device1. This device is intended for use when supplied
with power from the AC-3 charger.
This device is intended to use the BL-4B battery.
For availability of approved enhancements, please check
with your dealer. When you disconnect the power cord of
any enhancement, grasp and pull the plug, not the cord.
1. The exact model number of charger may vary depending
on the type of plug. For example, the model numbers for
AC-3 charger can be AC-3C, AC-3U, AC-3X, etc.

Get started
Copyright © 2007 Nokia. All rights reserved.
19
1. Connect the charger to a wall outlet.
2. Connect the charger to the phone as
shown.
■Normal operating
position
Your device has an internal antenna.
Note: As with any radio
transmitting device, avoid
touching an antenna
unnecessarily when the
antenna is in use. For example,
avoid touching the cellular antenna during a
phone call. Contact with a transmitting or
receiving antenna affects the quality of the radio
communication, may cause the device to operate
at a higher power level than otherwise needed,
and may reduce the battery life.
