Introduction
3
Copyright © 2006 Nokia. All rights reserved.
Introduction
This document is a support guide for the configuration of
Internet settings needed to use the Nokia E62 for data
connections.
To access the Internet (in order to use WWW or mail), the
following conditions must exist:
• The cellular network (GSM 850/900/1800/1900) you
use must support data calls.
• The data service (also the high-speed HSCSD service if
used) must be activated for your SIM card.
• You must have obtained an Internet access point (IAP)
from an Internet service provider.
• Proper Internet settings must have been configured in
your device.
For information about the correct settings, contact your
Internet service provider or system administrator. The
service provider may be able to configure the access point
for you using a special SMS message or WWW page, which
sets up all the necessary Internet access settings. Please
contact your Internet service provider (ISP) for details.
The necessary settings for Internet configuration are
provided by your Internet Service Provider. If your Internet
settings are incomplete or incorrect, please contact your
service provider. Depending on your ISP or network
operator, you may not need to fill in all of the settings.
When you insert a SIM card, the device will read the
necessary GPRS, MMS, and SMSC settings from the SIM
card if they are available, and no manual configuration is
necessary. Note that this may not work with all operators
and SIM cards.

Creating Internet connections
4Copyright © 2006 Nokia. All rights reserved.
Creating Internet connections
Creating an Internet access point
for data calls
1Select Menu→ Tools→ Settings→ Connection→
Access points.
2The list of existing access points is shown. Press
Options→New access point to create a new Internet
access point.
To use an existing access point as a basis for the new
one, select Use existing settings. To start with an empty
access point, select Use default settings.
3Define the following settings:
•Connection name — Type a descriptive name for the
Internet access point, such as My Data Call
Internet.
•Data bearer — Select Data call or High speed data
(GSM only).
•Dial-up number — Enter the modem telephone
number of the acess point. Remember to type +
before international numbers.
•User name — Enter your user name if required by the
service provider. User names are often case-sensitive
and provided by your service provider.
•Prompt password — Select Yes to enter your password
each time you log into a server or No to save the
password in your device memory and automate the
login.
•Password — Enter your password if required by the
service provider. The password is often case-
sensitive and provided by the service provider.
•Authentication — Select Secure to always send your
password encrypted or Normal to send your password
encrypted when possible.
•Homepage — Enter the Web address of the page you
want to display as a home page when you use this
access point.
•Data call type — Select Analogue or ISDN. This setting
depends on both your GSM network operator and
Internet service provider, because some GSM
networks do not support certain types of ISDN
connections. For details, contact your Internet
service provider. If ISDN connections are available,
they establish connections more quickly than analog
methods.

Creating Internet connections
5
Copyright © 2006 Nokia. All rights reserved.
•Max. data speed — Select the limit to apply to the
transfer speed. The speed represents the maximum
speed at which your connection will operate. During
the connection, the operating speed may be less,
depending on network conditions. If you select
Automatic, the data transfer rate is determined by
the network and may be affected by network traffic.
Some service providers may charge more for higher
data rates.
4After setting up a basic Internet access point for Data
call or High speed data (GSM only), select Back to save the
settings and exit, or Options→Advanced settings to
define the following advanced settings:
•IPv4 settings — Enter the device IP and name server
addresses for IPv4 Internet protocol.
•IPv6 settings — Enter the device IP and name server
addresses for IPv6 Internet protocol.
•Proxy serv. address — Enter the IP address or the
domain name of the proxy server. For example,
domain names are company.com and
organisation.org
•Proxy port number — Enter the proxy server port
number. The port number is related to the protocol.
Common values are 8000 and 8080, but vary with
every proxy server.
Proxy servers are intermediate servers between a
browsing service and its users, which are used by
some service providers. These servers may provide
additional security and speed up access to the
service.
•Use callback — Select Yes if you have a service that
dials back to your device when you establish an
Internet connection.
•Callback type — Select Use server no. or Use other no.,
according to instructions from your service
provider.
•Callback number — Enter your data call phone
number of your device, which the callback server
uses.
•Use PPP compress. — Select Yes to speed up the data
transfer, if it is supported by the remote PPP server.
•Use login script — Select Yes, if your Internet service
provider requires a login script, or if you want to
automate your login. A login script is a sequence of
instructions that the system follows during the
login process.
•Login script — Enter the login script. This setting is
available only if you have selected Use login script→
Yes.
•Modem initialisation — Enter a command string for
the connection setup, if required by your service
provider.

Creating Internet connections
6Copyright © 2006 Nokia. All rights reserved.
Creating an Internet access point
for packet data (GPRS)
1Select Menu→ Tools→ Settings→ Connection→
Access points.
2The list of existing access points is shown. Press
Options→New access point to create a new Internet
access point.
To use an existing access point as a basis for the new
one, select Use existing settings. To start with an empty
access point, select Use default settings.
3Define the following settings:
•Connection name — Type a descriptive name for the
Internet access point, such as My GPRS Internet.
•Data bearer — Select Packet data.
•Access point name — Enter the name for the access
point. The name is usually provided by your service
provider or network operator.
•User name — Enter your user name if required by the
service provider. User names are often case-
sensitive and provided by your service provider.
•Prompt password — Select Yes to enter your password
each time you log into a server or No to save the
password in your device memory and automate the
login.
•Password — Enter your password if required by the
service provider. The password is often case-
sensitive and provided by the service provider.
•Authentication — Select Secure to always send your
password encrypted or Normal to send your
password encrypted when possible.
•Homepage — Enter the Web address of the page you
want to display as a home page when you use this
access point.
4After setting up a basic Internet access point for Packet
data (GPRS), select Back to save the settings and exit,
or Options→Advanced settings to define the following
advanced settings:
•Network type — Select IPv4 or IPv6 as the Internet
protocol type. The Internet protocol defines how
data is transferred to and from your device.
•Phone IP address — Enter the IP address of your
device. Select Automatic to have the network
provide the device IP address. This setting is
available only if you have selected Network type→
IPv4.
•DNS address — Enter the IP addresses of the Primary
DNS address and Secondary DNS addr. if required by

Creating Internet connections
7
Copyright © 2006 Nokia. All rights reserved.
your service provider or network operator.
Otherwise, the name server addresses are provided
automatically.
•Proxy serv. address — Enter the address of the proxy
server. Proxy servers are intermediate servers
between a browsing service and its users, which are
used by some service providers. These servers may
provide additional security and speed up access to
the service.
Creating an Internet access point
for IP passthrough
1Select Menu→ Tools→ Settings→ Connection→ Access
points.
2The list of existing access points is shown. Select
Options→New access point→ Use default settings to
create a new access point.
3Define the following settings:
•Connection name — Type a descriptive name for the
Internet access point, such as My IP Passthrough.
•Data bearer — Select IP passthrough.
4After configuring the basic settings for IP passthrough,
select Back to save the settings and exit, or Options→
Advanced settings to define the following advanced
settings:
•IPv4 settings — Enter the Phone IP address and DNS
address for the IPv4 Internet protocol.
•IPv6 settings — Enter the DNS address for the IPv6
Internet protocol.
•Proxy serv. address — Enter the address of the proxy
server. Proxy servers are intermediate servers
between a browsing service and its users, which are
used by some service providers. These servers may
provide additional security and speed up access to
the service.
•Proxy port number — Enter the proxy server port
number.
Note: DNS is an Internet service that
translates domain names such as
www.nokia.com into IPv4 addresses such
as 192.100.124.195, or IPv6 addresses like
3ffe:2650:a640:1c2:341:c39:14.
Activating IP passthrough
Note: Use the USB data cable driver to
establish a cable connection between your
device and a compatible Windows-based PC.
For Windows 2000 and Windows XP users:
the drivers for the Nokia DKU-2 and CA-53
cables are integrated into Nokia PC Suite
version 6.7 and onwards. Instead of
downloading the cable driver separately, it is
recommended that you download the
Nokia PC Suite.

Creating Internet connections
8Copyright © 2006 Nokia. All rights reserved.
Select Menu→ Connect.→ Data cable→ Options→ IP
passthrough to use the data cable for the IP passthrough
Internet access point.
Nokia Network Bridge (which can be downloaded from
forum.nokia.com) is the IP passthrough application that
allows you to obtain a network connection on your device
from a compatible PC through a USB data cable. Connect
the USB data cable to the bottom of the device. Connect
the other end of the data cable to a compatible PC, and
wait for the PC to recognize your device.
Use IP passthrough as you use any Internet access point
to browse or synchronize remotely. If a wireless network
connection is unavailable, use IP passthrough to access
the Internet or a LAN. You cannot use IP passthrough at
the same time as Nokia PC Suite. You cannot activate the
modem if you select IP passthrough in cable connection
settings.
Selecting an Internet access
point
When you establish an Internet connection, you are asked
to select the Internet access point you want to use for
that connection. Select an Internet access point from the
list of available access points, and press Select.
Tip: The Select access point dialog opens only if
you have selected Always ask in the Access point
field in the Web settings. Otherwise, the
selected default Internet access point is used.
To check the status of the setting, select
Menu→ Web→ Options→ Settings.
Access point groups
Select Menu→ Tools→ Settings→ Connection→ Access
point groups.
An access point group is used for grouping and prioritizing
access points. An application can use a group as a
connection method instead of a single access point. In
that case the best available access point inside a group is
used for making connection and in case of email, also for
roaming.
To create an access point group, select Access point
groups→ Options→ New groups. In the Group name field,
enter a name for the group. Define in the Conn. switching
field whether to show the connection switching process
on the display of your device. Choose and edit the access
points that belong to this group in the Access points
section.
To remove an access point in an access point group, select
the access point and Options→ Remove.

Configuring text messages (SMS)
9
Copyright © 2006 Nokia. All rights reserved.
Configuring text messages (SMS)
Note: Before you can send and receive text
messages, the following conditions must exist:
•The phone must be turned on.
•The network you are using must support the
text message service.
•The text message service must be activated
for your SIM card.
•The text message settings must be defined.
Configuring text message center
settings
Select Menu→ Messag.→ Options→ Settings→ Text
message→ Message centres to access the message center
settings.
To edit message centers, select the message center, and
Options→ Edit.
To add new message centers, select Options→ New msg.
centre.
To delete message centers, select the message center, and
Options→ Delete.
Configuring text message settings
Select Menu→ Messag.→ Options→ Settings→ Text
message to access the following text message settings.
•Msg. centre in use — Select the message center you
want to deliver your text messages.
•Character encoding — Select Reduced support to use
automatic character conversion to another encoding
system when available.
•Receive report — Select Yes if you want to receive
delivery reports on your messages (network service).
•Message validity — Select how long the message center
resends your message if the first attempt fails
(network service). If the recipient cannot be reached
within the validity period, the message is deleted from
the message center.
•Message sent as — Convert the message to another
format, such as Text, Fax, Paging or E-mail. Change this
option only if you are sure that your message center is
able to convert text messages into these other formats.
Contact your network operator.
•Preferred conn. — Select the preferred method of
connection when sending text messages from your
device.
•Reply via same ctr. — Select whether you want the reply
message to be sent using the same text message
center number (network service).

Configuring multimedia messages (MMS)
10 Copyright © 2006 Nokia. All rights reserved.
Configuring multimedia messages (MMS)
Note: Only devices that have compatible
features can receive and display multimedia
messages. The appearance of a message may
vary depending on the receiving device.
Before you can send or receive multimedia
messages on your device, you must define the
multimedia message settings. Your device may
have recognized the SIM card provider and
automatically configured the multimedia
message settings. If not, contact your service
provider.
Select Menu→ Messag.→ Options→ Settings→
Multimedia message to access the multimedia message
settings.
•Image size — Select Small or Large to scale images in
multimedia messages. Select Original to maintain the
original image size of multimedia messages.
•MMS creation mode — Select Restricted to have your
device prevent you from including content in
multimedia messages that may not be supported by
the network or the receiving device. To receive
warnings about including such content, select Guided.
To create a multimedia message with no restrictions
on attachment type, select Free. If you select Restricted,
creating multimedia presentations is not possible.
•Access point in use — Select the default access point to
connect to the multimedia message center. You may
not be able to change the default access point if it is
preset in your device by your service provider.
•Multimedia retrieval — Select Always automatic to always
receive multimedia messages automatically, Aut. in
home network to receive notification of a new multi-
media message that you can retrieve from the message
center (for example, when you are traveling abroad and
are outside your home network), Manual to retrieve
multimedia messages from the message center manual-
ly, or Off to prevent receipt of any multimedia messages.
•Allow anon. msgs. — Select whether you want to receive
messages from unknown senders.
•Receive adverts — Select whether you want to receive
messages defined as advertisements.
•Receive report — Select Yes to have the status of the sent
message to be shown in the log (network service).
Receiving a delivery report of a multimedia message
that has been sent to an e-mail address may not be
possible.
•Deny report sending — Select Yes to not send delivery
reports from your device for received multimedia
messages.
•Message validity — Select how long the message center
resends your message if the first attempt fails (network
service). If the recipient cannot be reached within the
validity period, the message is deleted from the
message center. Maximum time is the maximum
amount of time allowed by the network.

Configuring voice mailbox (network service)
11
Copyright © 2006 Nokia. All rights reserved.
Configuring voice mailbox (network service)
To configure your voice mailbox settings, select Menu→
Organiser→ Voic.mail.
When you open the voice mailbox application for the first
time, you are asked to enter the number of your voice
mailbox. To change the number, select Options→
Change number. To call the number, select Options→
Call voice mailbox.
Tip: To call your voice mailbox (network
service) in standby mode, press and hold 1, or
press 1then the call key.
