Nokia BH-200 User manual

Nokia Bluetooth Headset BH-200
User Guide
9247798
Issue 2
1

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product
HS-58W is in conformity with the provisions of the following Council Directive:
1999/5/EC. A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
© 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other
product and company names mentioned herein may be trademarks or tradenames of their
respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
Unauthorized changes or modifications to this device may void the user's authority to
operate the equipment.
Export Controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
9247798
Issue 2 EN

3
English
Contents
1. Introduction ......................... 4
Bluetooth wireless technology .......... 4
2. Get started............................ 5
Overview .................................................. 5
Chargers and batteries......................... 5
Charge the battery ................................ 6
Switch the headset on or off ............. 6
Pair the headset with a compatible
phone ........................................................ 6
Disconnect the headset from the
phone..................................................... 7
Reconnect the paired headset to
your phone........................................... 7
Troubleshooting ..................................... 7
3. Basic use ............................... 9
Place the headset on the ear ............. 9
Call handling........................................... 9
Adjust the earphone volume.............. 9
Mute or unmute the microphone..... 9
Switch the call between phone
and headset........................................... 10
Use the headset with several
phones .................................................... 10
Clear the settings ................................ 10
4. Battery information ........... 11
Care and maintenance ........... 12

Introduction
4
1. Introduction
The Nokia Bluetooth Headset BH-200 allows you freedom to make and
receive calls while on the move or in the office. You can connect the
headset to a compatible phone that supports Bluetooth wireless
technology.
Read this user guide carefully before using the headset. Read also the
user guide for your phone, which provides important safety and
maintenance information. Keep the headset out of reach of small
children.
■Bluetooth wireless technology
Bluetooth wireless technology
allows you to connect compatible
devices without cables. A Bluetooth
connection does not require that the
phone and the headset be in line of
sight, but the maximum distance
between the devices is 10 meters (30
feet). The closer the phone and the
headset are to each other, the better
is the performance. The optimal
operating range is shown in dark
grey in the picture. The connection is
subject to interference from distance and obstructions (shown in light
grey) or other electronic devices.
The headset is compliant with Bluetooth Specification 2.0 + EDR
supporting the following profiles: Headset Profile 1.1 and Hands-Free
Profile 1.0. Check with the manufacturers of other devices to determine
their compatibility with this device.
There may be restrictions on using Bluetooth technology in some
locations. Check with your local authorities or service provider.
<10m

Get started
5
English
2. Get started
■Overview
The headset contains the
following parts as shown in
the figure:
• Volume key (1)
• Answer/end key (2)
• Indicator light (3)
• Charger connector (4)
• Power key (5)
• Earphone (6)
• Microphone (7)
Before you can start using the headset, you must charge the battery and
pair the headset with a compatible phone.
Parts of the headset are magnetic. Metallic materials may be attracted
to the headset. Do not place credit cards or other magnetic storage
media near the headset, because information stored on them may be
erased.
■Chargers and batteries
Check the model number of any charger before using it with this
headset. The headset is intended for use with the AC-3, AC-4, and DC-4
chargers.
Warning: Use only batteries and chargers approved by Nokia for
use with this particular enhancement. The use of any other
types may invalidate any approval or warranty, and may be
dangerous.
For availability of approved enhancements, please check with your
dealer. When you disconnect the power cord of any enhancement, grasp
and pull the plug, not the cord.
12
3
4
7
6
5

Get started
6
■Charge the battery
This device has an internal, nonremovable, rechargeable battery. Do not
attempt to remove the battery from the device as you may damage the
device.
1. Connect the charger cable to the headset.
2. Connect the charger to a wall outlet. The red
indicator light is displayed during charging. It
may take a while before charging starts. If
charging does not start, disconnect the
charger, plug it in again, and retry. Charging the battery fully may
take up to 2 hours.
3. When the battery is fully charged, the red indicator light turns off.
Disconnect the charger from the wall outlet and the headset.
The fully charged battery has power for up to 5 hours and 30 minutes of
talk-time or up to 150 hours of standby time. However, the talk and
standby times may vary when used with different mobile phones,
products that use a Bluetooth connection, usage settings, usage styles,
and environments.
When the battery is running out of power, the headset beeps, and the
red indicator light starts to flash.
■Switch the headset on or off
To switch on, press and hold the power key. The headset beeps, and the
green indicator light starts to flash quickly. When the headset is
connected to a paired phone and is ready for use, the green indicator
light flashes slowly.
To switch off, press and hold the power key. The headset beeps, and the
red indicator light is displayed briefly.
■Pair the headset with a compatible phone
1. Switch on your phone and the headset.

Get started
7
English
2. Activate the Bluetooth feature on the phone, and set the phone to
search for Bluetooth devices. See the user guide of your phone for
instructions.
3. Select the headset (Nokia BH-200) from the list of found devices.
4. Enter the passcode 0000 to pair and connect the headset to your
phone. In some phones you may need to make the connection
separately after pairing. See the user guide of your phone for details.
You only need to pair the headset with your phone once.
5. If the pairing is successful, the headset beeps and appears in the
phone menu where you can view the currently paired Bluetooth
devices.
Disconnect the headset from the phone
To disconnect the headset from your phone (for example, to connect the
phone to another Bluetooth device), do one of the following:
• Switch off the headset.
• Disconnect the headset in the Bluetooth menu of your phone.
• Move the headset more than 10 meters (30 feet) away from the
phone.
You do not need to delete the pairing with the headset to disconnect it.
Reconnect the paired headset to your phone
To connect the headset to your phone, switch on the headset, make the
connection in the Bluetooth menu of your phone, or press and hold the
answer/end key.
You can set your phone to connect with the headset automatically
when the headset is switched on. To do this in Nokia phones, change
your paired device settings in the Bluetooth menu.
■Troubleshooting
If you cannot connect the headset to your phone, do as follows:

Get started
8
• Ensure that the headset is charged, switched on, paired with and
connected to your phone.
• Ensure that the Bluetooth feature is activated on your phone.
• Check that the headset is within 10 meters (30 feet) of your phone
and that there are no obstructions between the headset and the
phone, such as walls or other electronic devices.
• To reset the headset if it stops functioning, although it is charged,
briefly press the power key and the middle of the volume key while it
is plugged into a charger. This reset does not clear your settings (for
example, pairing settings).

Basic use
9
English
3. Basic use
■Place the headset on the ear
Place the headset over your ear and slide it
downwards as shown in the figure. Adjust
the headset into a comfortable position on
your ear so that it points toward your mouth.
■Call handling
To make a call, use your phone in the normal way when the headset is
connected to your phone.
If your phone supports redialing with this device, press the answer/end
key twice briefly while no call is in progress.
If your phone supports voice dialing with this device, press and hold the
answer/end key when no call is in progress, and proceed as described in
the user guide of your phone.
To answer a call, press the answer/end key, or use the phone keys. If the
automatic answer function is set on, the phone automatically answers
the incoming call after one ring.
To reject an incoming call, briefly press the answer/end key twice.
To end a call, press the answer/end key, or use the phone keys.
■Adjust the earphone volume
Press the volume key up to increase or down to decrease the volume. To
adjust the volume quickly, press and hold the key in the desired
direction.
■Mute or unmute the microphone
To mute or unmute the microphone during a call, briefly press the
middle of the volume key. A long tone is played, and the headset beeps
at regular intervals until you unmute the microphone.

Basic use
10
■Switch the call between phone and headset
To switch the call between the headset and a compatible phone, press
and hold the answer/end key, or use the respective function in your
phone.
■Use the headset with several phones
You can pair the headset with up to eight phones but connect it to only
one phone at a time.
The phone that was first paired with the headset is the default phone. If
the headset is switched on within 10 meters (30 feet) of several paired
phones, the headset tries to connect to the default phone.
If the headset cannot connect to the default phone, the headset tries to
connect to the last used phone. If the headset cannot connect to this
phone either, one of the other six paired phones can be connected to the
headset. To make the connection, see the user guide of your phone.
■Clear the settings
If you want to clear all the settings from the headset (for example, the
list of paired devices), press and hold the power key and the volume key
up for 10 seconds. After the settings are cleared, the headset beeps
twice, and the indicator lights alternate for several seconds.

Battery information
11
English
4. Battery information
Your device is powered by a rechargeable battery. The full performance of a new
battery is achieved only after two or three complete charge and discharge cycles.
The battery can be charged and discharged hundreds of times, but it will
eventually wear out. Recharge your battery only with Nokia approved chargers
designated for this device.
Unplug the charger from the electrical plug and the device when not in use. Do
not leave a fully charged battery connected to a charger, since overcharging may
shorten its lifetime. If left unused, a fully charged battery will lose its charge over
time.
Never use any charger that is damaged.
Leaving the device in hot or cold places, such as in a closed car in summer or
winter conditions, will reduce the capacity and lifetime of the battery. Always try
to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot
or cold battery may not work temporarily, even when the battery is fully charged.
Battery performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.

Care and maintenance
12
Care and maintenance
Your device is a product of superior design and craftsmanship and should be
treated with care. The suggestions below will help you protect your warranty
coverage.
• Keep all accessories and enhancements out of the reach of small children.
• Keep the device dry. Precipitation, humidity, and all types of liquids or
moisture can contain minerals that will corrode electronic circuits. If your
device does get wet, allow it to dry completely.
• Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
All of the above suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility.
