Nokia 500i User manual

Nokia 500i
Installation Guide
Part No. N451656001 Rev A
Published June 2005

2 Nokia 500i Installation Guide
COPYRIGHT
©2005 Nokia. All rights reserved.
Rights reserved under the copyright laws of the United States.
RESTRICTED RIGHTS LEGEND
Use, duplication, or disclosure by the United States Government is subject to restrictions as set
forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013.
Notwithstanding any other license agreement that may pertain to, or accompany the delivery of,
this computer software, the rights of the United States Government regarding its use,
reproduction, and disclosure are as set forth in the Commercial Computer Software-Restricted
Rights clause at FAR 52.227-19.
IMPORTANT NOTE TO USERS
This software and hardware is provided by Nokia Inc. as is and any express or implied
warranties, including, but not limited to, implied warranties of merchantability and fitness for a
particular purpose are disclaimed. In no event shall Nokia, or its affiliates, subsidiaries or
suppliers be liable for any direct, indirect, incidental, special, exemplary, or consequential
damages (including, but not limited to, procurement of substitute goods or services; loss of use,
data, or profits; or business interruption) however caused and on any theory of liability, whether in
contract, strict liability, or tort (including negligence or otherwise) arising in any way out of the use
of this software, even if advised of the possibility of such damage.
Nokia reserves the right to make changes without further notice to any products herein.
TRADEMARKS
Nokia is a registered trademark of Nokia Corporation. Other products mentioned in this
document are trademarks or registered trademarks of their respective holders.
050110

Nokia 500i Installation Guide 3
Nokia Contact Information
Corporate Headquarters
Regional Contact Information
Nokia Customer Support
Web Site http://www.nokia.com
Telephone [phone] or
1-650-625-2000
Fax [phone]
Mail
Address Nokia Inc. 313 Fairchild Drive
Mountain View, California
94043-2215 USA
Americas Nokia Inc.
313 Fairchild Drive
Mountain View, CA 94043-2215
USA
Tel: [phone]
Outside USA and Canada: [phone]
email: info.ipnetworking_america[email protected]
Europe,
Middle East,
and Africa
Nokia House, Summit Avenue
Southwood, Farnborough
Hampshire GU14 ONG UK
Tel: UK: [phone]
Tel: France: [phone]
email: [e-mail]
Asia-Pacific 438B Alexandra Road
#07-00 Alexandra Technopark
Singapore 119968
Tel: [phone]
email: [email protected]
Web Site: https://support.nokia.com/
Email: t[email protected]
Americas Europe
Voice: 1-888-361-5030 or
1-613-271-6721 Voice: [phone]
Fax: [phone] Fax: [phone]
Asia-Pacific
Voice: [phone]
Fax: [phone]
050602

4 Nokia 500i Installation Guide

Nokia 500i Installation Guide 5
Contents
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
In This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Conventions This Guide Uses . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
About the Nokia 500i Gateway. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Nokia 500i Gateway Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preparing the Installation Environment . . . . . . . . . . . . . . . . . . . . . 18
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Humidity and Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Electrical Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Protection Against Lightning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Electrical Power Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Product Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Site Requirements, Warnings, and Cautions . . . . . . . . . . . . . . . . . 22
Installing the Nokia 500i Gateway . . . . . . . . . . . . . . . . . . . . . . . . . 23
Grounding the Nokia 500i Gateway . . . . . . . . . . . . . . . . . . . . . . 23
Rack Mounting the Nokia 500i Gateway. . . . . . . . . . . . . . . . . . . 24
2 Performing the Initial Configuration . . . . . . . . . . . . . . . . . . . . . 31
Performing the Initial Hardware Configuration . . . . . . . . . . . . . . . . 31
Connecting the Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6 Nokia 500i Installation Guide
Console Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Connecting Power and Turning the Power On . . . . . . . . . . . . . . 35
System Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Connecting Network Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Connecting to Ethernet Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Ethernet Cable Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . 39
3 Installing and Replacing Optional Cards . . . . . . . . . . . . . . . . . 43
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Installing Flash Memory PC Cards. . . . . . . . . . . . . . . . . . . . . . . . . 44
Installing an Encryption Accelerator Card . . . . . . . . . . . . . . . . . . . 46
Installing a Network Interface Card . . . . . . . . . . . . . . . . . . . . . . . . 50
Installing a Network Interface Card by Using Nokia VPN Manager 50
Installing a NIC on the Nokia 500i Gateway . . . . . . . . . . . . . . . . 53
Four-port 10/100 Ethernet NIC . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Front Panel Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Fiber Optic or Copper Gigabit Ethernet NIC . . . . . . . . . . . . . . . . 61
Front Panel Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Connectors and Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Fiber Optic Gigabit Ethernet NIC . . . . . . . . . . . . . . . . . . . . . . . 63
Copper Gigabit Ethernet NIC . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Replacing Power Supplies on the Nokia 500i Gateway. . . . . . . . . 64
Replacing an AC Power Supply on the Nokia 500i Gateway . . . 65
4 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
A Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Space Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Nokia 500i Installation Guide 7
B Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Declaration of Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Compliance Statements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
FCC Notice (US) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

8 Nokia 500i Installation Guide

Nokia 500i Installation Guide 9
Figures
Figure 1 Component Locations Front View . . . . . . . . . . . . . . . . . 18
Figure 2 Rack-Mounting Screw Locations . . . . . . . . . . . . . . . . . . 24
Figure 3 Pin Assignments for Console and AUX Connections . . 34
Figure 4 Power Switch Location on the Nokia 500i . . . . . . . . . . . 36
Figure 5 Status LED Location . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 6 Output Connector for the Ethernet Cable . . . . . . . . . . . 40
Figure 7 Ethernet Crossover-Cable Pin Connections . . . . . . . . . 41
Figure 8 PC Card Slots on the Nokia 500i . . . . . . . . . . . . . . . . . 45
Figure 9 PMC Four-port 10/100 Ethernet NIC . . . . . . . . . . . . . . . 61
Figure 10 PMC Dual-Port Fiber Optic Gigabit Ethernet NIC . . . . 62
Figure 11 PMC Dual-Port Copper Gigabit Ethernet NIC . . . . . . . 63

10 Nokia 500i Installation Guide

Nokia 50i Installation Guide 11
Tables
Table 1 Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 2 Pin Assignments for DB9 and DB25 Interface Cables . . 35
Table 3 System Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

12 Nokia 50i Installation Guide

Nokia 500i Installation Guide 13
About this Guide
This manual describes the installation and use of the Nokia 500i gateway.
Installation and maintenance should be performed only by experienced
technicians or Nokia-approved service providers.
This preface provides the following information:
!In This Guide
!Conventions This Guide Uses
!Related Documentation
In This Guide
This guide is organized into the following chapters and appendixes:
!Chapter 1, “Overview,” presents a general overview of the Nokia 500i
gateway and describes how to rack mount the gateway.
!Chapter 2, “Performing the Initial Configuration” describes how to
physically connect it to a network and to a power source and how to make
the Nokia SAS gateway platform available on the network.
!Chapter 3, “Installing and Replacing Optional Cards” describes how to
install, monitor, and replace network interface cards (NICs).
!Chapter 4, “Troubleshooting” discusses problems you might encounter
and proposes solutions to these problems.

About this Guide
14 Nokia 500i Installation Guide
!Appendix A, “Technical Specifications,”provides technical specifications
such as interface characteristics.
!Appendix B, “Compliance Information,”provides compliance and
regulatory information.
Conventions This Guide Uses
The following sections describe the conventions this guide uses, including
notices, text conventions, and command-line conventions.
Notices
Warning
Warnings advise the user that either bodily injury might occur because of
a physical hazard, or that damage to a structure, such as a room or
equipment closet, might occur because of equipment damage.
Caution
Cautions indicate potential equipment damage, equipment
malfunction, loss of performance, loss of data, or interruption of
service.
Note
Notes provide information of special interest or recommendations.

Conventions This Guide Uses
Nokia 500i Installation Guide 15
Text Conventions
Table 1 describes the text conventions this guide uses.
Table 1 Text Conventions
Convention Description
monospace font
Indicates command syntax, or represents computer or screen
output, for example:
Log error 12453
bold monospace font Indicates text you enter or type, for example:
# configure nat
Key names Keys that you press simultaneously are linked by a plus sign (+):
Press Ctrl + Alt + Del.
Menu commands Menu commands are separated by a greater than sign (>):
Choose File > Open.
The words enter and type Enter indicates that you type something and then press the
Return or Enter key.
Do not press the Return or Enter key when an instruction says
type.
Italics •Emphasizes a point or denotes new terms at the place where
they are defined in the text.
•Indicates an external book title reference.
•Indicates a variable in a command:
delete interface if_name

About this Guide
16 Nokia 500i Installation Guide
Related Documentation
In addition to this guide, documentation for this product includes the
following:
!Nokia IP VPN Gateway Configuration Guide v6.3 describes how to
configure and manage Nokia IP VPN Gateways by using the Nokia VPN
Manager software.
!Nokia IP VPN Gateway Command-Line Summary v6.3 is a reference for
the command-line interface (CLI) for Nokia IP VPN gateways.
!Release Notes in an ASCII-text file on the installation CD.

Nokia 500i Installation Guide 17
1Overview
This chapter provides an overview of the Nokia 500i gateway and the
requirements for its use. The following topics are covered:
!About the Nokia 500i Gateway
!Nokia 500i Gateway Overview
!Preparing the Installation Environment
!Site Requirements, Warnings, and Cautions
!Installing the Nokia 500i Gateway
About the Nokia 500i Gateway
The Nokia 500i gateway is a high-end, multiport appliance that is ideally
suited for the enterprise data center. It supports an encryption accelerator card
to further enhance VPN performance.

1Overview
18 Nokia 500i Installation Guide
Nokia 500i Gateway Overview
Figure 1 shows the component locations for the Nokia 500i gateway.
Figure 1 Component Locations Front View
Preparing the Installation Environment
Before you install the gateway, make sure that the installation environment is
clean, dry, and dust free. Take the following precautions to maintain a safe
working environment and to avoid accidents:
!Inspect the area for hazards such as bare wires and standing water.
!Remove scarves and neckties, jewelry, and other loose items before you
install the gateway.
!Do not remove the gateway cover under any circumstances.
00499
500i
Dual 6U PMC carrier
expansion slots 1 and 2
Console port
System status LEDs
PCMCIA slots Ethernet management
ports (slot 3)
Serial (AUX) port

Safety Precautions
Nokia 500i Installation Guide 19
Ventilation
Gateways can generate substantial heat during operation and therefore require
adequate ventilation. You might need to install the gateway in an air-
conditioned room to ensure that its internal cooling system can maintain
acceptable temperatures during operation.
Warning
Do not block any ventilation slots on the appliance. Internal components
might overheat and be damaged.
Humidity and Temperature
During operation, ambient relative humidity should never exceed ninety
percent and ambient air temperature must remain between 32°F and 113° F
(0° C and 45°C).
Safety Precautions
Follow these safety instructions whenever you are working with the gateway.
Caution
Read and follow all of these precautions before you work near any
power source.
!Circuit breakers must be installed in the fixed wiring on all circuits to
which the gateways are connected. Ensure that all of the circuit breakers
are easily accessible.
!For installations in North America, use a 120 VAC, 20A fuse circuit
breaker for the circuit branch.
!For installations outside North America that use 230 VAC, use a
230 VAC, 2A fuse circuit breaker.

1Overview
20 Nokia 500i Installation Guide
!Use the gateway device within the electrical ratings indicated on the back
of the device and in the product documentation.
Follow the requirements of all building and electrical codes before, during,
and after installation of the gateway.
Warning
The gateway requires protection against short-circuits (overcurrent).
Always use overcurrent protection on all conductors of electrical current
to which the gateway is connected.
Electrical Grounding
The gateway must always be connected using a grounding-type plug.
Warning
Make sure that the facility where the gateway is installed has proper
electrical grounding and is connected to that ground at all times during
operation.
Protection Against Lightning
Warning
Do not work on the gateway during an electrical storm. Do not connect or
disconnect any wires, including network or power connections. Whenever
the threat of lightning danger exists, avoid even touching the gateway.
This precaution is sensible for any electrical device during periods of
lightning activity.
