Nokia Speakerphone HF-300
User Guide
9206561
Issue 1 EN

DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this HF-34W product is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
The product is in conformity with the limits defined in Directive 2004/104/EC
(amending Directive 72/245/EEC), Annex I, paragraph 6.5, 6.6, 6.8 and 6.9.
A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation.
Other product and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of ongoing development. Nokia reserves the right to make
changes and improvements to any of the products described in this document
without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or
any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable
law, no warranties of any kind, either express or implied, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose, are

made in relation to the accuracy, reliability or contents of this document. Nokia
reserves the right to revise this document or withdraw it at any time without prior
notice.
The availability of particular products may vary by region. Please check with the
Nokia dealer nearest to you.
Unauthorized changes or modifications to this device may void the user's authority
to operate the equipment.
Export Controls
This device may contain commodities, technology or software subject to export laws
and regulations from the US and other countries. Diversion contrary to law is
prohibited.
9206561 / Issue 1 EN

4
Contents
For your safety.................................5
1. Introduction................................5
Bluetooth wireless technology ..........6
2. Get started..................................7
Chargers and batteries .......................8
Insert and charge the battery ............8
Switch on or off .................................9
Pair the speakerphone..................... 10
Disconnect the speakerphone ........... 11
Reconnect the speakerphone ............ 11
3. Call handling.............................11
Adjust speaker volume.................... 11
Call handling ................................... 12
Mount in a car .................................12
General safety instructions ................13
Attach the clip to the sunvisor ..........13
Fix the speakerphone to the clip.......14
Clear settings or reset......................15
4. Battery information................. 15
Charging and discharging ...............15
Care and maintenance.................. 16
Additional safety
information................................... 18

5
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which
could affect performance.
1. Introduction
With the Nokia Speakerphone HF-300 you can make and receive hands-free
calls. You can connect the speakerphone to a compatible mobile device that
supports Bluetooth wireless technology.
Read this user guide carefully before using the speakerphone. Also read the
user guide for the device that you connect to the speakerphone, which provides
important safety and maintenance information. Keep all accessories and
enhancements out of reach of small children.

6
■Bluetooth wireless technology
Bluetooth wireless technology allows you to connect compatible devices without
cables. In a Bluetooth connection, the mobile device and the speakerphone
should be within 10 meters (33 feet) of each other. Connections can be subject to
interference from obstructions, such as other electronic devices.
The speakerphone is compliant with the Bluetooth Specification 2.0 supporting
the Hands-Free Profile 1.5. Check with the manufacturers of other devices to
determine their compatibility with this device.
There may be restrictions on using Bluetooth technology in some locations.
Check with your local authorities or service provider.

7
2. Get started
The speakerphone contains the following parts:
• Charger connector (1)
• Speaker (2)
• Power key (3)
• Volume up key (4)
• Answer/end key (5)
• Volume down key (6)
• Microphone (7)
Before using the speakerphone, you must charge the battery and pair the
speakerphone with a compatible device.
Parts of the speakerphone are magnetic. Metallic materials may be attracted to
the speakerphone. Do not place credit cards or other magnetic storage media
near the speakerphone, because information stored on them may be erased.
46
5
3
7

8
■Chargers and batteries
Check the model number of any charger before using it with this speakerphone.
The speakerphone is intended for use with the AC-4, AC-5, and DC-4 chargers.
Warning: Use only batteries and chargers approved by Nokia for use with
this particular enhancement. The use of any other types may invalidate
any approval or warranty and may be dangerous.
When you disconnect the power cord of any enhancement, grasp and pull the
plug, not the cord.
■Insert and charge the battery
To insert the battery, do the following:
1. To remove the back cover, slide it toward the side of the speakerphone.
2. Align the contact area of the battery with the connectors on the
speakerphone, and push the battery into place.
3. To replace the back cover, insert the catches on the cover into the
corresponding slots in the speakerphone, and slide the back cover into
the speakerphone until it snaps into place.
(To remove the battery, detach the back cover, and lift the battery from the
end opposite to the contact area.)
To recharge the battery, do the following:
1. Connect the charger cable to the charger connector on the speakerphone.
2. Connect the charger to the power source. For example, connect the DC-4
charger to the cigarette lighter socket of your car or the AC-5 charger to a
wall outlet.

9
If you use a charger that is connected to the cigarette lighter socket, power
must be supplied by a 12-volt car battery. Ensure that the charger is properly
inserted in the cigarette lighter socket and does not interfere with the
normal operation of the car. In some car models, the cigarette lighter socket
is powered by the car battery even when you remove the ignition key. In
those cases, the car battery might be discharged even if the speakerphone
is not used. Contact the vehicle manufacturer for more information.
The red indicator light is continuously on while charging. It may take a
while before charging starts. If charging does not start, disconnect the
charger, plug it in again, and retry. Charging the battery fully may take
up to 2 hours and 30 minutes.
3. When the battery is fully charged, the red indicator light turns green.
Disconnect the charger from the speakerphone and the power source.
The fully charged battery has power for up to 20 hours of talk time or up to
240 hours of standby time. However, the times may vary when used with different
compatible Bluetooth devices, usage settings, usage styles, and environments.
When battery power is low, the red indicator light flashes slowly.
■Switch on or off
To switch on, press and hold the power key until the speakerphone beeps
and the green indicator light turns on. The indicator light flashes when the
speakerphone tries to connect to a paired device. When the speakerphone is
connected to a paired device and is ready for use, the blue indicator lights are
displayed.

10
To switch off, press and hold the power key until all the indicator lights turn off.
If the speakerphone is not connected to a paired device within about 5 minutes,
it switches off automatically to save power.
■Pair the speakerphone
1. Ensure that your mobile device is switched on, and switch on the
speakerphone. The green indicator light flashes slowly.
2. Activate the Bluetooth feature on the mobile device, and set the device
to search for Bluetooth devices. See the user guide of your device for
instructions.
3. Select the speakerphone from the list of found devices.
4. Enter the Bluetooth passcode 0000 to pair and connect the speakerphone
to your device. In some devices you may need to make the connection
separately after pairing.
If pairing is successful, the speakerphone sounds a beep and appears in the
menu of the mobile device where you can view the currently paired Bluetooth
devices. When the speakerphone is connected with your mobile device, the
blue indicator lights are displayed.
To pair and connect the speakerphone with a new device, disconnect the
speakerphone from the current device, then pair and connect the new device.

11
Disconnect the speakerphone
To disconnect the speakerphone from your mobile device, do one of the
following:
• Switch off the speakerphone.
• Disconnect the speakerphone in the Bluetooth menu of your device.
• Move the speakerphone more than 10 meters (33 feet) away from the device.
You do not need to delete pairing with the speakerphone to disconnect it.
Reconnect the speakerphone
To connect the speakerphone to your paired device, switch on the
speakerphone, and press and hold the answer/end key; or make the connection
in the Bluetooth menu of your device.
In your device, you may be able to allow the speakerphone to connect to it
automatically when the speakerphone is switched on. To do this in Nokia
devices, change your paired device settings in the Bluetooth menu.
3. Call handling
■Adjust speaker volume
To adjust the speakerphone volume, use the volume keys on the speakerphone.
Warning: Do not hold the device near your ear when the
loudspeaker is in use, because the volume may be extremely loud.

12
■Call handling
To make a call, use your mobile device in the normal way when the
speakerphone is connected to it. Speak toward the speakerphone microphone.
For optimal performance, check that there are no objects in front of the
microphone and that the microphone is in front of the user, not beneath or
behind. The green indicator light is displayed during a call.
If your device supports last number redial with the speakerphone, press the
answer/end key twice when no call is in progress.
If your device supports voice dialing with the speakerphone, press and hold the
answer/end key when no call is in progress, and proceed as described in the
user guide of your device.
When you receive a call, you hear a ringing tone through the speaker on the
speakerphone, and the green indicator light flashes. To answer the call, press
the answer/end key, or use the device keys. To reject an incoming call, press the
answer/end key twice.
To end a call, press the answer/end key, or use the device keys.
To switch the active call between the speakerphone and your device, press and
hold the answer/end key.
To mute or unmute the microphone during a call, briefly press the power key.
■Mount in a car
You can attach the speakerphone to the sunvisor of your car using the
supplied clip.

13
General safety instructions
When you install the speakerphone in a car, ensure
that it does not interfere with or hinder the systems
used in the operation of the vehicle (for example,
airbags) or disturb your field of vision while driving.
Check that the deployment of the airbags is not
blocked or impaired in any way. Only operate the
speakerphone if it is safe to do so under all driving
conditions.
To use the speakerphone when it is attached to the
sunvisor, ensure that the sunvisor is up at the car roof.
Attach the clip to the sunvisor
Slide the clip around the sunvisor
from the driver’s or passenger’s
side so that the "OPEN" text is on
the top of the sunvisor, and wrap
the strap attached to the clip
around the sunvisor from the
back (1).
1

14
Thread the strap through the slot
on the clip. Tighten the strap to
keep the speakerphone securely
in place, and firmly press the hook
and loop end of the strap against
the felt on the strap (2).
Fix the speakerphone to the clip
Align the speakerphone sidewise
with the clip so that the hole
located at the back of the
speakerphone is facing the catch
on the clip. Insert the catch into
the hole, and turn the
speakerphone clockwise until it
locks into place (3). (To detach
the speakerphone, turn it
counterclockwise.)
Fold the sunvisor up against the car roof.
2
3

15
■Clear settings or reset
To clear the pairing settings from the speakerphone, press and hold the answer/
end key and the volume up key at the same time for about 10 seconds. When
the settings have been cleared, the indicator light alternates red and green.
To reset the speakerphone if it stops functioning, although it is charged, press
the answer/end key and the power key at the same time. The speakerphone
switches off. To use the speakerphone, reconnect it to your mobile device.
The reset does not clear the pairing settings.
4. Battery information
■Charging and discharging
Your device is powered by a rechargeable battery. The battery can be charged and discharged
hundreds of times, but it will eventually wear out. When the talk and standby times are
noticeably shorter than normal, replace the battery. Use only Nokia approved batteries,
and recharge your battery only with Nokia approved chargers designated for this device.
If a replacement battery is being used for the first time or if the battery has not been used
for a prolonged period, it may be necessary to connect the charger, then disconnect and
reconnect it to begin charging the battery.
Unplug the charger from the electrical plug and the device when not in use. Do not leave
a fully charged battery connected to a charger, since overcharging may shorten its lifetime.
If left unused, a fully charged battery will lose its charge over time.
Use the battery only for its intended purpose. Never use any charger or battery that is damaged.

16
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic
object such as a coin, clip, or pen causes direct connection of the positive (+) and negative (-)
terminals of the battery. (These look like metal strips on the battery.) This might happen,
for example, when you carry a spare battery in your pocket or purse. Short-circuiting the
terminals may damage the battery or the connecting object.
Leaving the device in hot or cold places, such as in a closed car in summer or winter
conditions, will reduce the capacity and lifetime of the battery. Always try to keep the
battery between 15°C and 25°C (59°F and 77°F). A device with a hot or cold battery may not
work temporarily, even when the battery is fully charged. Battery performance is particularly
limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also explode if damaged.
Do not dismantle or shred cells or batteries. In the event of a battery leak, do not allow the
liquid to come in contact with the skin or eyes. In the event of such a leak, flush your skin or
eyes immediately with water, or seek medical help.
Care and maintenance
Your device is a product of superior design and craftsmanship and should be treated with
care. The following suggestions will help you protect your warranty coverage.
• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can
contain minerals that will corrode electronic circuits. If your device does get wet, remove
the battery, and allow the device to dry completely before replacing it.
• Do not use or store the device in dusty, dirty areas. Its moving parts and electronic
components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.

17
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic circuit boards.
• Do not attempt to open the device other than as instructed in this guide.
• Do not drop, knock, or shake the device. Rough handling can break internal circuit
boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device.
• Do not paint the device. Paint can clog the moving parts, microphone, or speaker and
prevent proper operation.
These suggestions apply equally to your device, battery, charger, or any enhancement. If any
device is not working properly, take it to the nearest authorized service facility for service.
Disposal
The crossed-out wheeled-bin symbol on your product, literature, or packaging
reminds you that in the European Union all electrical and electronic products,
batteries, and accumulators must be taken to separate collection at the end of
their working life. Do not dispose of these products as unsorted municipal waste.
Return the products to collection to prevent possible harm to the environment or human
health from uncontrolled waste disposal and to promote the sustainable reuse of material
resources. Collection information is available from the product retailer, local waste
authorities, national producer responsibility organizations, or your local Nokia
representative. For more information, see product Eco-Declaration or country-specific
information at www.nokia.com.

18
Additional safety information
■Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems
in motor vehicles such as electronic fuel injection systems, electronic antiskid (antilock)
braking systems, electronic speed control systems, and air bag systems. For more
information, check with the manufacturer or its representative of your vehicle or any
equipment that has been added.
Faulty installation or service may be dangerous and may invalidate any warranty that may
apply to the device. Check regularly that all wireless device equipment in your vehicle is
mounted and operating properly. Do not store or carry flammable liquids, gases, or explosive
materials in the same compartment as the device, its parts, or enhancements. For vehicles
equipped with an air bag, remember that air bags inflate with great force. Do not place
objects, including installed or portable wireless equipment in the area over the air bag or in
the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the
air bag inflates, serious injury could result.
FCC/Industry Canada notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: 1. This device may not cause harmful interference; and 2. This device must
accept any interference received, including interference that may cause undesired
operation. NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC
radiation exposure limits set forth for an uncontrolled environment. This transmitter must
not be co-located or operating in conjunction with any other antenna or transmitter.
NOTE: Changes or modifications not expressly approved by Nokia could void the user's
authority to operate the equipment.

Telefone com Viva-Voz Nokia HF-300
Manual do Usuário
9206561
Edição nº 1 PT-BR

DECLARAÇÃO DE CONFORMIDADE
A NOKIA CORPORATION declara, neste instrumento, que o produto HF-34W está em
conformidade com as exigências básicas e outras disposições relevantes da Diretiva
1999/5/EC. Este produto está em conformidade com os limites definidos na Diretiva
2004/104/EC (emenda da Diretiva 72/245/EEC), Anexo I, parágrafos 6.5, 6.6, 6.8 e 6.9.
Para obter uma cópia da Declaração de Conformidade, acesse o site, em inglês,
http://www.nokia.com/phones/declaration_of_conformity/.
© 2007 Nokia. Todos os direitos reservados.
É proibida a reprodução, transferência, distribuição ou armazenamento, no todo
ou em parte, do conteúdo deste documento, de qualquer forma, sem a prévia
autorização por escrito da Nokia.
Nokia e Nokia Connecting People são marcas registradas da Nokia Corporation.
Outros nomes de produto e empresa, mencionados neste manual, podem ser marcas
comerciais ou nomes comerciais de seus respectivos proprietários.
Bluetooth é uma marca registrada da Bluetooth SIG, Inc.
A Nokia adota uma política de desenvolvimento contínuo. A Nokia reserva-se
o direito de fazer alterações e melhorias em qualquer dos produtos descritos neste
documento sem aviso prévio.
NO LIMITE PERMITIDO PELA LEI APLICÁVEL, NEM A NOKIA NEM QUALQUER DE SEUS
LICENCIANTES PODERÃO SER, EM HIPÓTESE ALGUMA, RESPONSABILIZADOS POR
QUAISQUER PERDAS DE DADOS, LUCROS OU LUCROS CESSANTES, NEM POR DANOS
EXTRAORDINÁRIOS, INCIDENTAIS, CONSEQÜENTES OU INDIRETOS, SEJA QUAL FOR
A CAUSA.
