WARNINGS
WARNINGS!
LEGAL WARNINGS
► When usng the devce, comply wth all applcable laws and regulatons. Do not use the devce n prvate premses,
hstorc stes and mltary zones. Notfy the authortes of any hstorcal or cultural fndngs.
WARNINGS ABOUT THE DEVICE
► Ths s a hgh-tech electronc devce. Do not assemble or use the devce before readng the user manual.
► Do not expose the devce or the search col to very hot or cold condtons for extended perods of tme.
(Storage Temperature: 0°C (32°F) - 40°C (104°F))
► Do not mmerse the devce or ts accessores (except the search col) n water; do not expose them to extreme humd
condtons.
► Protect the devce from external mpact, especally durng transportaton.
►The devce can only be opened and repared by authorzed servce techncans. The warranty wll be voded f the devce
s opened by you or an unauthorzed person.
3NOKTA DETECTORS

WARNINGS
For Consumers within the European Union: Do not dispose of
this equipment in general household waste. The crossed
wheeled bin symbol on this equipment indicates this unit
should not be disposed of in general household waste, but
recycled in compliance with local government regulations
and environmental requirements.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
IMPORTANTIMPORTANT
Do not use the device indoors. The device will constantly give target
signals inside places like homes where there are many metals present.
Use the device outdoors, in open fields.
Do not let another detector or an electromagnetic device come in close
proximity (10m (33ft.)) to the device.
Do not carry any metal objects while using the device. Keep the device
away from your shoes while walking. The device may detect the metals
on you or inside your shoes as targets.
4

ASSEMBLY
1) System Box
2) Handle and S-Rod
3) Search Col
4) Search Col Cover
5) Upper Shaft
6) Extenson Shaft
7) Wngnut, Fastenng
Screw and Washers
8) 8 AA Batteres
9) Battery Case
10) Battery Case Cover
11) Headphones
Col cover use s optonal. It protects the search
col from scratches. If you want to use the cover,
attach the cover to the col and press frmly on
the edges to secure.
5
123
6
7
4
5
11
89
10
NOKTA DETECTORS

ASSEMBLY
Holdng the metal pn pressed, nsert the S-rod
nto ts place underneath the system box and
secure t by tghtenng the wngnut as shown n
the pcture.
Agan by holdng the metal pn pressed, nsert the
upper shaft nto the S-rod and clck the pn nto ts
hole. Then, secure t by tghtenng the twst lock.
6
Insert the extenson shaft nto the upper shaft
holdng the metal pn pressed and adjust the
heght by clckng the pn nto one of the holes.
Then, secure t by tghtenng the twst lock agan.

ASSEMBLY
Wrap the col cable around the shaft all the way up
as shown n the pcture and after nsertng t n the
col nput socket underneath the system box,
secure t by twstng the connector. Pay attenton
to not wrap the cable too tght durng ths step.
7
Place the washers nto the openngs on both sdes
at the end of the extenson shaft. After placng the
shaft on the col as shown n the pcture, nsert the
fastenng screw through the hole and tghten t
usng the wngnut.
To carry the battery case on your wastband: Insert
the battery case n the leather cover. As shown n the
pcture, attach the clp to the backsde of your belt.
Plug the battery case cable nto the socket
underneath the system box and tghten securely.
NOKTA DETECTORS

ASSEMBLY
8
Assembly s completed.
1 2 3a
3b 4 5
To attach the battery case to the system box: Follow the above steps n the pctures. After step
5, plug the battery case cable nto the socket underneath the system box and tghten securely.

CORRECT WAY OF HOLDING
Shaft heght s wrong.
It s very mportant to adjust the shaft to your heght correctly to be
able to search wthout dscomfort and fatgue.
Shaft heght s correct.
Adjust the heght of the shaft so that you are standng n an uprght
poston, your arm s relaxed and the search col s approxmately 5cm
(~2'') above the ground.
9NOKTA DETECTORS

CORRECT WAY OF SWEEPING
Wrong search col angle
Incorrect way of sweepng
Wrong search col angle Correct search col angle
It s mportant to keep the search col
parallel to the ground n order to get
accurate results.
Correct way of sweepng
The search col must be parallel to the
ground at all tmes.
10

BATTERY
11
The device comes with 8 AA Alkaline batteries and
a battery case. Insert the batteries in the case
paying attention to the + (plus) and – (minus)
poles. When batteries are full, they will provide
approximately 25-30 hours of use. Dierent types
or brand of batteries may have dierent lifetimes.
LOW BATTERY: When the batteries are low, the
device will produce a warning sound
approximately once every minute. The device will
shut down automatically 3-4 hours after the
warning.
Those who prefer rechargeable batteries can
purchase the optional lithium polymer battery and
search over 50 hours.
You may also purchase the
optional car charger with the
lithium polymer battery and
charge your battery on-the-go
as well.
Optional Optional
Optional
NOKTA DETECTORS

DEVICE INTRODUCTION
12
O
On
Mineral 1
Mineral 2
Mineral 3
CoilBattery
SENSITIVITY IRON DISC.
GROUND BALANCE
IRON SIGNAL AUDIO
FS
OFF ON
Speaker Headphone
Input Volume

TURNING ON THE DEVICE
GROUND BALANCE
To turn on the devce, rotate the On/O knob to ON. Turn the same knob to OFF poston
when you want to turn o the devce. When the devce s turned on, a melody wll be heard
and approxmately 10 seconds later you wll hear a long beep ndcatng that the devce s
ready to use.
The devce wll provde more depth at on poston. However, to better dscrmnate ferrous
metals, usng the devce n mneral modes and the ron dscrmnaton at maxmum poston
s recommended.
Especally n mneralzed ground target sgnal s negatvely aected by the ''nose'' caused by
ground mneralzaton. Ths stuaton may prevent the detector from gettng a clean sgnal
from the target necessary for metal detecton and accurate dscrmnaton. Ground balancng
s a process through whch the metal detector s able to cancel out the negatve eects
caused by ground mneralzaton.
To ground balance, holdng the search col 5cm. above the ground, sweep t rght and left,
keepng t parallel to the ground and slowly turn the ground balance knob clockwse untl the
nose s gone and the devce s slent. If you cannot ground balance the detector, gradually
decrease the senstvty and repeat the above steps.
5cm
13
O
On
Mineral 1
Mineral 2
Mineral 3
GROUND BALANCE
CONTROLS
NOKTA DETECTORS

SENSITIVITY
For maxmum depth, do not turn the ground balance knob to the rght more than necessary.
Generally speakng, the md-level (between 4-7) oers the most deal and stable detecton
capablty on derent types of ground wthout sacrfcng depth.
As the ground balance goes nto the rght area, the devce wll start losng depth for some
non-ferrous metals except for gold. When the ground balance settng reaches the maxmum
pont the devce wll detect ron and gold but t wll not detect some non-ferrous metals.
If you are searchng on a ground loaded wth mneralzed stones or dps and holes, t s recommended to ground balance over
one of these stones or the holes.
In areas of very hgh mneralzaton, ground balance may not be sucent. In such a case, you may need to use the mneral
search modes (see page 16).
Senstvty settng s used to elmnate nterferences caused by electromagnetc waves n the
surroundng envronment or ground nose. Electromagnetc waves may result from power
lnes n the surroundng envronment or from the operaton of electrcal devces, radars,
wreless rados, and even TVs.
Senstvty s also the depth settng for the devce. Therefore, especally n hgh
mneralzaton, t s recommended that you lower t only f the devce s stll gettng nose
after you adjust all the other settngs (ground balance, ron dscrmnaton and mneral
modes).
SENSITIVITY
CONTROLS
14
GROUND BALANCE

IRON DISCRIMINATION
IRON SWITCH
In general, when searchng n wet salt water beach sand, the most deal settngs are the maxmum level of the ron dscrmnaton,
ron swtch o and mneral 2 or 3 modes. You can also use these settngs when searchng n wet plowed land wth hgh ron eect.
2) It enables metals contanng ron to produce a low tone and to be dscrmnated more easly. Dscrmnaton starts at about
level 4 - 6. Below ths level, all metals ncludng ron wll produce a non-ferrous (hgh) tone and generally speakng the devce wll
perform at ts maxmum depth. In addton, ron swtch wll not be actve below ths level.
Ths settng s desgned for tough ground condtons and experenced users. For normal
ground condtons or f you do not want to bother wth ths settng t s recommended that
you keep t at the factory settng (FS).
Ths settng has 2 man purposes:
1) Especally n areas of hgh ron mneralzaton and wet beach sand you may not be able to
ground balance the devce. In such a case, you can use ron dscrmnaton. By turnng the ron
dscrmnaton knob to the rght, you can enable the ground eect to be reected as ron and
elmnate t by turnng the ron swtch o.
When you want to avod detectng ferrous metals you can turn the ron swtch o and enable
the devce to elmnate these metals and not produce a warnng tone.
NOTE: Many metals consdered to be trash may not produce a ferrous metal sgnal. For
example, pull tabs may be sensed as a non-ferrous metal by most detectors because ther
sgnal s very smlar to that of gold.
IRON DISC.
IRON
KAPALI AÇIKOFF ON
CONTROLS
15 NOKTA DETECTORS

MINERAL MODES
Mineral Modes: If you are searchng on hgh mneralzed ground (extremely salty sol, wet
beach sand, wet plowed land or hghly magnetc ground condtons) you may not be able to
ground balance the devce. In such a case, frst turn the On/O knob to mneral 1. If the devce
s stll gettng nose, turn t to mneral 2 or mneral 3. Ths wll elmnate the nose and false
sgnals caused by mneralzaton. However, you may experence a decrease or fadng n the
sgnal obtaned from certan metals at maxmum depths.
As mentoned before, especally on grounds wth hgh ron content such as wet salt water
beach sand and wet plowed land, t s recommended that you search n mneral 2 or 3 mode,
brng the ron dscrmnaton to maxmum level and turn the ron swtch o.
SIGNAL AUDIO BOOST
Please note that sgnal audo boost should be used on a temporary or as-needed bass because t wll not only boost the
target sgnal audo but t wll also boost the loudness of ground nose and false sgnals. Therefore, t s recommended to keep
the swtch at poston 1 and turn t to poston 2 or 3 only when you want to verfy a weak metal sgnal and then turn t o
agan.
The sgnal audo boost swtch boosts the sound of weak sgnals receved from small or deep
metals makng t easer for you to detect those uncertan targets.
At poston 1, the booster s o. At 2, the sgnal audo wll be hgher and at 3, t wll be heard
at ts maxmum.
In general, when searchng n wet salt water beach sand, the most deal settngs are the maxmum level of the ron dscrmnaton,
ron swtch o and mneral 2 or 3 modes. You can also use these settngs when searchng n wet plowed land wth hgh ron eect.
2) It enables metals contanng ron to produce a low tone and to be dscrmnated more easly. Dscrmnaton starts at about
level 4 - 6. Below ths level, all metals ncludng ron wll produce a non-ferrous (hgh) tone and generally speakng the devce wll
perform at ts maxmum depth. In addton, ron swtch wll not be actve below ths level.
CONTROLS
16
O
On
Mineral 1
Mineral 2
Mineral 3
SIGNAL AUDIO

SEARCHING AND METAL DETECTION
5cm
After the settngs are adjusted, you can start searchng by lftng the search
col 5cm. above the ground and sweepng t rght and left, keepng t parallel
to the ground.
The devce operates on the prncple of moton. Ths means that you must
move the search col over the target or the target over the search col, n order
for the devce to see t. In other words, metal detecton s not possble
wthout movng the search col.
To avod mssng smaller and deeper targets, sweep the search col both from rght to left and left to rght over each area you
are scannng, slghtly overlappng the sweeps as you move forward.
When the devce detects metal, t wll produce an audble tone.
The devce has 3 tone audo dscrmnaton. The lower tone s for ferrous metals. For non-ferrous metals and gold, the devce
produces 2 very smlar hgh tones. In case of alloy detecton the devce may produce a hgh-low double-tone sound. In order
to get famlar wth the derent tones of your devce, t s recommended that you practce wth derent types of metals and
dentfy the sounds before you use t out n the feld.
NOTE: Dscrmnaton, just lke n any other metal detector, may not always be 100% accurate. There are many derent factors
aectng dscrmnaton accuracy. All metals based on ther conductvty, shape, orentaton underground, depth and ground
mneralzaton are sensed derently by a detector. Oxdzed metals bured under ground for a long tme such as tnplates and
tns may produce gold lke sgnals.
Followng the experenced metal detector users' rule of thumb "when n doubt, dg" s the rght thng to do.
SEARCHING AND METAL DETECTION
17 NOKTA DETECTORS

TECHNICAL SPECIFICATIONS
Operating Principle:
Operating Frequency:
Metal Identification:
Audio Discrimination:
Sensitivity Setting:
Ground Balance:
Search Coil:
Battery:
Headphone Output:
Length:
Weight:
Warranty:
Induction Balance
17.5 KHz
Audio warning
3 tones
Manual
Manual
28cm (11'') waterproof Double-D
8 x AA Alkaline Batteries
6.5mm mono
121-142cm (48''-56'') extendable
1.9kg (4.2lbs) including the search coil
2 years
18

Emek Mah. Sivatyolu Cad. Sakiz Sok. No: 4
34785 Sancaktepe - Istanbul / Turkey
Phone : [phone]
Fax : [phone]
E-mail: [email protected]om
