Nordica ROSA XXL UL-C User manual

MADE IN ITALY
design & production
INSTALLATION
AND OPERATING
INSTRUCTIONS
INSTALLER: LEAVE THIS
MANUAL WITH THE
APPLIANCE.
CONSUMER: SAVE THESE
INSTRUCTIONS.
NEVER LEAVE CHILDREN
OR OTHER AT RISK
INDIVIDUALS ALONE WITH
THE APPLIANCE.
SAFETY INFORMATION
WARNING
PLEASE READ ENTIRE MANUAL BEFORE YOU INSTALL AND USE
YOUR NEW APPLIANCE.
If this appliance is not properly installed, a house re may result. To
reduce the risk of re, follow the installation instructions. Failure to
follow instructions may result in property damage, bodily injury, or
even death.
- AUTHORITIES HAVING JURISDICTION (SUCH
AS MUNICIPAL BUILDING DEPARTMENT,
FIRE DEPARTMENT, FIRE PREVENTION
BUREAU, ETC.) SHOULD BE CONSULTED
BEFORE INSTALLATION TO DETERMINE THE
NEED TO OBTAIN A PERMIT.
- HOT WHILE IN OPERATION. KEEP
CHILDREN, CLOTHING AND FURNITURE
AWAY. CONTACT MAY CAUSE SKIN BURNS.
- Do not use an elevated grate or otherwise raise the re.
- Do not use chemicals or uids to start the re - do not burn
garbage or ammable uids
- Do not connect to any air distribution duct or system
- Do not burn lawn clippings / waste, rubber, waste petroleum
products, paints or paint thinners / solvents, plastic, materials
containing asbestos, construction debris, railroad ties, manure
or animal remains, salt water driftwood or salted materials,
unseasoned wood, coloured paper, cardboard, plywood or
particleboard. Burning these materials may result in release of
toxic fumes or render the appliance ineective and cause smoke.
WARNING
HOT GLASS
WILL CAUSE
BURNS.
DO NOT TOUCH
GLASS UNTIL
COOLED.
NEVER ALLOW
CHILDREN TO
TOUCH GLASS.
LISTED: UL 1482 - 2011, UL 737 - 2011, ULC-S627 - 2000, SOLID FUEL TYPE ROOM HEATERS
ROSA XXL UL-C
ROSA L UL-C
MILLY UL-C
007098005 - Rev.001

007098005-0012

007098005-001
1.0 INSTALLATION OVERVIEW......................................................................................................................................................................4
1.1 ROSA XXL UL-C - ROSA L UL-C......................................................................................................................................................................................................................................... 4
1.2 MILLY UL-C .............................................................................................................................................................................................................................................................................. 5
2.0 INTRODUCTION........................................................................................................................................................................................6
2.1 DIMENSIONS........................................................................................................................................................................................................................................................................... 7
2.2 SPECIFICATIONS ..................................................................................................................................................................................................................................................................10
2.2.1 HEATING SPECIFICATIONS...................................................................................................................................................................................................................................10
2.2.2 CALCULATION OF THE THERMAL POWER .....................................................................................................................................................................................................10
2.3 GENERAL INSTRUCTIONS ................................................................................................................................................................................................................................................11
2.4 GENERAL INFORMATION..................................................................................................................................................................................................................................................12
2.4.1 ALLOWED FUELS SPECIFICATIONS..................................................................................................................................................................................................................12
2.4.2 DISPOSAL OF ASHES..............................................................................................................................................................................................................................................13
2.5 FIRE SAFETY.........................................................................................................................................................................................................................................................................13
2.5.1 NOTES FOR PROPER OPERATION......................................................................................................................................................................................................................13
2.5.2 IN A EMERGENCY....................................................................................................................................................................................................................................................13
3.0 INSTALLATION PLANNING .................................................................................................................................................................. 14
3.1 APPLIANCE MINIMUM CLEARANCE TO COMbUSTIbLES ...................................................................................................................................................................................14
3.1.1 STRAIGHT INSTALLATION....................................................................................................................................................................................................................................15
3.1.2 FLOOR PROTECTION INSTALLATION REQUIREMENTS ............................................................................................................................................................................15
3.2 THE CHIMNEY .......................................................................................................................................................................................................................................................................16
3.2.1 CHIMNEY CONNECTOR.........................................................................................................................................................................................................................................16
3.2.2 CHIMNEY AND CHIMNEY CONNECTOR MAINTENANCE.........................................................................................................................................................................16
3.2.3 MINIMUM INSIDE vERTICAL CLEARANCES..................................................................................................................................................................................................17
3.2.4 CLASS A CHIMNEY RETROFIT ............................................................................................................................................................................................................................17
3.2.5 MINIMUM INSIDE vERTICAL CLEARANCES..................................................................................................................................................................................................18
3.2.6 CLASS A CHIMNEY RETROFIT ............................................................................................................................................................................................................................18
3.2.7 CHIMNEY CONNECTOR SYSTEM AND CLEARANCE FROM COMbUSTIbLE WALLS RESIDENTIAL HEATHING APPLIANCES.........................................19
3.3 vENTILATION AND AERATION OF THE INSTALLATION PREMISES...................................................................................................................................................................20
4.0 - ROSA XXL UL-C / ROSA L UL-C ......................................................................................................................................................... 21
4.1 TECHNICAL DESCRIPTION ...............................................................................................................................................................................................................................................21
4.2 ACCESSORIES........................................................................................................................................................................................................................................................................21
4.3 COOKER CONTROLS...........................................................................................................................................................................................................................................................22
4.3.1 TO IGNITE THE FLAME............................................................................................................................................................................................................................................22
4.3.2 HOW TO SET THE MACHINE TO bOIL WATER................................................................................................................................................................................................22
4.3.3 HOW TO SET THE MACHINE TO COOK bISCUITS.........................................................................................................................................................................................22
5.0 MILLY UL-C ............................................................................................................................................................................................ 23
5.1 TECHNICAL DESCRIPTION ...............................................................................................................................................................................................................................................23
5.2 ACCESSORIES........................................................................................................................................................................................................................................................................23
5.3 COOKER CONTROLS...........................................................................................................................................................................................................................................................24
5.3.1 TO IGNITE THE FLAME............................................................................................................................................................................................................................................24
5.3.2 HOW TO SET THE MACHINE TO bOIL WATER................................................................................................................................................................................................24
5.3.3 HOW TO SET THE MACHINE TO COOK bISCUITS.........................................................................................................................................................................................24
6.0 IGNITION ................................................................................................................................................................................................ 25
6.1 FIRST IGNITION ....................................................................................................................................................................................................................................................................25
6.1.1 LOW EMISSION FIRE LIGHTING..........................................................................................................................................................................................................................26
6.1.2 FIRE STARTER MODULE.........................................................................................................................................................................................................................................26
6.2 NORMAL OPERATION........................................................................................................................................................................................................................................................27
6.2.1 USE OF THE OvEN....................................................................................................................................................................................................................................................27
6.2.2 OPERATION IN TRANSITION PERIODS.............................................................................................................................................................................................................27
7.0 MAINTENANCE AND CARE................................................................................................................................................................... 28
7.1 PERIODIC MAINTENANCE UNDER USER’S RESPONSIbILITY..............................................................................................................................................................................28
7.1.1 GLASS CLEANING ....................................................................................................................................................................................................................................................28
7.1.2 bROKEN GLASS REPLACEMENT.........................................................................................................................................................................................................................29
7.1.3 DIMENSIONS OF THE CERAMIC-bASED GLASSES......................................................................................................................................................................................29
7.1.4 CLEANING OUT THE ASHES.................................................................................................................................................................................................................................30
7.1.5 CLEANING OF THE HEARTH GRATE..................................................................................................................................................................................................................30
7.1.6 MAINTENANCE OF THE OvEN ............................................................................................................................................................................................................................31
7.1.7 CLEANING THE SMOKES COLLECTION CASING THROUGH THE DOOR UNDER THE OvEN.......................................................................................................31
7.1.8 CAST IRON COOKING PLATE AND RINGS.......................................................................................................................................................................................................32
7.1.9 vARNISHED PRODUCTS........................................................................................................................................................................................................................................32
7.1.10 ENAMELLED PRODUCTS....................................................................................................................................................................................................................................32
7.1.11 CHROMIUM-COMPONENTS..............................................................................................................................................................................................................................32
7.1.12 LATERAL HANDRAIL.............................................................................................................................................................................................................................................32
7.1.13 MAJOLICAS (IF PRESENT) ..................................................................................................................................................................................................................................32
7.1.14 PRODUCTS MADE OF NATURAL STONE (IF PRESENT)...........................................................................................................................................................................32
7.2 SUMMER STOP......................................................................................................................................................................................................................................................................33
7.3 ROUTINE MAINTENANCE PERFORMED bY QUALIFIED TECHNICIANS ..........................................................................................................................................................33
7.3.1 GASKETS......................................................................................................................................................................................................................................................................33
7.3.2 CONNECTION TO THE FLUE.................................................................................................................................................................................................................................33
8.0 WARRANTY TERMS............................................................................................................................................................................... 34
9.0 INSTALLATION MILLY UL-C TOP FOOD WARMER - OPTIONAL......................................................................................................... 35
3

007098005-001
1.0 INSTALLATION OVERVIEW
1.1 ROSA XXL UL-C - ROSA L UL-C
CAST IRON RINGS
HANDRAIL CLOSING CAP
JOINT FOR HANDRAIL
HANDRAIL
HANDRAIL SUPPORT SELF-TAPPING SCREW
HANDRAIL SUPPORT
Multi-Purpose
OPERATING TOOL
SUPPORT
EXHAUST COLLAR
CAST IRON PLATE
CAST IRON PLATE
THREADED NUT
THREADED SCREW
HEARTH
OVEN
THERMOMETER
DRAWER
COLLECTION
ASHES
Multi-Purpose
OPERATING TOOL
HANDRAIL
4

007098005-001
1.2 MILLY UL-C
WARNING
THE COOK STOVES MUST BE INSTALLED WITH THE LEGS PROVIDED (IF APPLICABLE), ATTACHED AS SHOWN WITHIN
THESE INSTALLATION AND OPERATING INSTRUCTIONS.
DO NOT OBSTRUCT THE SPACE BENEATH THE APPLIANCE.
CAST IRON RINGS
HANDRAIL
HEARTH
OVEN
EXHAUST COLLAR
CAST IRON PLATE
THREADED SCREW
THREADED SCREW
THERMOMETER
DRAWER
COLLECTION
ASHES
Multi-Purpose
OPERATING TOOL
Multi-Purpose
OPERATING TOOL
SUPPORT
5

007098005-001
WARNING
2.0 INTRODUCTION
THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
Do not operate this appliance before reading and understanding the operating instructions. Failure to operate appliance
according to operating instructions could cause re or injury. Consult the authorities that have jurisdiction (e.g. municipal building
department, re department, re prevention bureau, etc.) and follow their guidelines. Notify your insurance company of this
appliance as well.
Never try to repair or replace any part of the appliance unless instructions are given in this manual. All other work should be
done by a trained technician.
Risk of burns. The appliance should be turned o and cooled before servicing.
Do not operate without fully assembling all components.
Do not install damaged, incomplete or substitute components.
Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges may be sharp.
Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns or clothing
ignition. Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is recommended if
there are at risk individuals in the house.To restrict access to an appliance or stove, install an adjustable safety gate to keep toddlers,
young children and other at risk individuals out of the room and away from hot surfaces.
Clothing or other ammable material should not be placed on or near the appliance.
Due to high temperatures, the appliance should be located out of trac and away from furniture and draperies.
Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
Even after the appliance is switched o, the glass and/or screen will remain hot for an extended period of time.
Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These
screens and guards must be fastened to the oor.
Any safety screen or guard removed for servicing must be replaced prior to operating the appliance. It is imperative that the
control compartments, burners and circulating blower and its passageway in the appliance and venting system are kept clean. The
appliance and its venting system should be inspected before use and at least annually by a qualied service person. More frequent
cleaning may be required due to excessive lint from carpeting, bedding material, etc.The appliance area must be kept clear and free
from combustible materials, gasoline and other ammable vapors and liquids.
This appliance shall not be modied or sabotaged.
Do not use this appliance if any part has been underwater. Immediately call a qualied service technician to inspect the appliance
and to replace any part of the control system and any gas control which has been underwater.
Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or qualied service person. The viewing door and ash pan must be closed and latched during operation.
Do not strike or slam shut the appliance glass door.
Only doors / optional fronts certied with the unit are to be installed on the appliance.
Keep the packaging material out of reach for children and dispose of the material in a safe manner. As with all plastic bags, these
are not toys and should be kept away from children and infants.
If the appliance is not properly installed, a house re may result. Do not expose the appliance to the elements (ex. rain, etc.) and
keep the appliance dry at all times. Wet insulation will produce an odour when the appliance is used.
The chimney must be sound and free of cracks. Clean your chimney a minimum of twice a year and as required.
The appliance is designed and approved for dry logs wood fuel only. Any other type of fuel burned in this appliance will void
the warranty and safety listing.
Do not start a re with chemicals or uids such as gasoline, engine oil, etc.
Ashes must be disposed in a metal container with a tight lid and placed on a non-combustible surface well away from the home
or structure.
Your appliance requires periodic maintenance and cleaning. Failure to maintain your appliance may lead to smoke spillage in
your home.
Ensureclearancesto combustibles aremaintained when building a mantelor shelves abovethe appliance.Elevatedtemperatures
on the wall or in the air above the appliance can cause melting, discolouration or damage to decorations, a T.V. or other electronic
components.
SAVE THESE INSTRUCTIONS. This manual has important operating and maintenance instructions that you will need at a later
time. Always follow the instructions in this manual.
THE EXHAUST SYSTEM SHOULD BE CHECKED AND CLEANED ONCE A YEAR MINIMUM FOR ANY BUILDUP OF SOOT OR
CREOSOTE.
THIS APPLIANCE BECOMES VERY HOT, YOU MUST WEAR HEAT RESISTANT GLOVES WHEN CLEANING OR HANDLING THIS
APPLIANCE.
6

1067
954
861
154
658
652
669
435 514
98
215
743
475 475
153
668
1068
6 inch female
S000013126 - 270521
ROSA XXL UL-C MAJOLICA
ROSA XXL UL-C steel
S000012536-260521
669
1074
934
658
652
154
153 861
435
743
514
1068
475
668
475
205
98
120
6 inch female
ROSA XXL UL-C Steel - 202 kg
ROSA XXL UL-C Majolica - 235 kg
007098005-001
Ø4,72-in OPTIONAL
External Air inlet
Rear Flue Gas outlet
Ø4,72-in OPTIONAL
External Air inlet
Rear Flue Gas outlet
2.1 DIMENSIONS
7

154
658
S000013127 - 270521
ROSA XXL UL-C stone
861
652
153
475 475
964
1074
669
1068
668
435 514
743
220
98
6 inch female
743
143
7015304-270521
ROSA L UL-C
861
382 593
834 608
975
143
425 425
670
658
200
98
120
6 inch female
ROSA XXL UL-C Stone - 275 kg
ROSA L UL-C Steel - 192 kg
007098005-001
Ø4,72-in OPTIONAL
External Air inlet
Ø4,72-in OPTIONAL
External Air inlet
Rear Flue Gas outlet
Rear Flue Gas outlet
8

7018005-270521
MILLY UL-C
670
648 410 539
748
153
865
857
970 592
475 475
100
970
250
119
19
33
100
6 inch female
1050
MILLY UL-C Steel with Majolica - 217 kg
007098005-001
52 kg
MILLY UL-C TOP FOOD WARMER
- OPTIONAL -
WARNING
NEVER INTRODUCE FLAMMABLE OBJECTS OR
MATERIALS IN TO THE FOOD WARMER HOLDER
Ø 3,94-in
External Air inlet
Rear Flue Gas outlet
WARNING
THE COOK STOVES MUST BE INSTALLED WITH THE LEGS
PROVIDED (IF APPLICABLE), ATTACHED AS SHOWN WITHIN THESE
INSTALLATION AND OPERATING INSTRUCTIONS.
DO NOT OBSTRUCT THE SPACE BENEATH THE APPLIANCE.
9

007098005-001
2.2 SPECIFICATIONS
Flue Gas outlet diameter in mm
Hearth opening size in mm (W x H)
Hearth size in mm (W x H x D)
Oven size in mm (W x H x D)
Type of grill
Height in mm
Width in mm
Depth in mm
Weight in kg Chapter 2.1 DIMENSIONS
2.2.1 HEATING SPECIFICATIONS
Nominal power in kW
Eciency in %
Chimney height ≥ (m) - dimension (mm)
Chimney draught in Pa (mm H2O)
Chimney draught MAX in Pa (mm H2O)
Hourly wood consumption in kg / h
CO measured at 13% oxygen in %
Flue Gas emission in g/s – wood
Flue Gas temperature in °C - wood
Heatable volume in m3(30 kcal/h x m3)
(*) The proposed value are indicative. This appliance must be connected to (1) a listed Type HT (2100°F) chimney per UL 103 or ULC S629, or
(2) a code-approved masonry chimney with a ue liner. The chimney size should not be less than or more than three times greater than
the cross-sectional area of the ue collar.
(**) For those buildings in which the thermal insulation does not correspond to the instructions on heat protection, the heating volume of
the product is: favourable type of building (30 kcal/h x m3); less favourable type of building (40 kcal/h x m3); unfavourable type of building
(50 kcal/h x m3).
(***) When the depression exceeds 15 Pa (=1.5 mm of column of water), it is necessary to reduce the same by installing an an
appropriate device on the exhaust pipe or in the chimney, according to the regulations in force.
With thermal insulation in accordance with the regulations regarding energy saving, the heated volume is greater. With temporary
heating, in the event of interruptions which last more than 8 hours, the heating capacity is reduced by about 25%.
The declared technical data have been achieved by burning beech wood class “A1” according to the requirement UNI EN ISO 17225-5 and
wood moisture content less than 20%. By burning a dierent kind of wood the eciency of the product itself could change and some specic
adjustments on the appliance could be needed.
2.2.2 CALCULATION OF THE THERMAL POWER
There is not an absolute rule for calculating the correct necessary power. This power is given according to the space to be heated, but it
depends also largely on the insulation. On an average, the caloric value necessary for a properly insulated room is 30 kcal/h per m3(for an
external temperature of 0°C).
Given that 1 kW corresponds to 860 kcal/h, it is possible to adopt a value of 35 W/m3.
Let’s suppose one wishes to heat a room of 150 m3(10 x 6 x 2.5 m) in an insulated apartment. In this case, it is necessary to have 150 m3x 35
W/m3= 5250 W or 5,25 kW. As main heating, a 8 kW device is therefore sucient.
Approximate combustion value Required quantity in relation to
1 kg of dry wood
Fuel Unit kcal/h kW
Dry wood (15% humidity) kg 3600 4.2 1,00
Wet wood (50% humidity) kg 1850 2.2 1,95
Wood briquettes kg 4000 5.0 0,84
Brown coal briquettes kg 4800 5.6 0,75
Normal anthracite kg 7700 8.9 0,47
Coke kg 6780 7.9 0,53
Natural gas m37800 9.1 0,46
Naphtha L 8500 9.9 0,42
Electricity kW/h 860 1.0 4,19
ROSA XXL ULC ROSA L UL-C MILLY UL-C
150 150 150
225 x 210 225 x 210 240 x 185
296 x 306 x 460 296 x 306 x 460 270 x 287 x 455
436 x 418 x 430 307 x 418 x 430 436 x 418 x 430
Movable - at Movable - at Movable - at
861 861 865
1074 975 1050
669 670 670
ROSA XXL ULC ROSA L UL-C MILLY UL-C
8,5 8,1 8,7
85 84 89
(*) 4 - 200x200 Ø200 (*) 4 - 200x200 Ø200 (*) 4 - 200x200 Ø200
12 (1,2 mm H2O) 12 (1,2 mm H2O) 12 (1,2 mm H2O)
(***)15 (1,5 mm H2O) (***)15 (1,5 mm H2O) (***)15 (1,5 mm H2O)
2,3 2,3 2,3
0,08 - (1000 mg/Nm3) 0,1 - (1212 mg/Nm3) 0,07 - (900mg/Nm3)
6,2 7 5,8
232 202 180
244 (**) 232 (**) 249 (**)
10

007098005-001
2.3 GENERAL INSTRUCTIONS
WARNING
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. DO NOT CONNECT TO ANY AIR
DISTRIBUTION DUCT OR SYSTEM.
PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE.
PROVIDE ADEQUATE VENTILATION.
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT AT A MINIMUM OF 48” (1200mm) FROM THE FRONT FACE
OF THE APPLIANCE.
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology
with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a ame gives, in
complete safety.
La NORDICA S.p.A. responsibility is limited to the supply of the appliance.
The installation must be carried out scrupulously according to the instructions provided in this manual and the rules of the profession.
Installation must only be carried out by a qualied technician who works on behalf of companies suitable to assume the entire
responsibility of the system as a whole.
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology
with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a ame gives, in
complete safety.
This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to
another owner or user, or if transferred to another place. If it is damaged or lost, request another copy from the area technician.
This product is intended for the use for which it has been expressly designed.The manufacturer is exempt from any liability, contractual
and extracontractual, for injury/damage caused to persons/animals and objects, due to installation, adjustment and maintenance
errors and improper use
Installation must be performed by qualied sta, which assumes complete responsibility for the denitive installation and consequent
good functioning of the product installed. One must also bear in mind all laws and national, regional, provincial and town council
Standards present in the country in which the appliance has been installed, as well as the instructions contained in this manual. The
Manufacturer cannot be held responsible for the failure to comply with such precautions.
After removing the packaging, ensure that the content is intact and complete. Otherwise, contact the dealer where the appliance was
purchased.
All components that make up the product must be replaced with original spare parts exclusively by an authorised after-sales centre,
thus guaranteeing correct functioning.
La NORDICA S.p.A. declines any responsibility for the product that has been modied without written authorisation as well as for the
use of non-original spare parts.
11

007098005-001
The wood used as fuel must have a humidity content lower than the 20% and must be stored in a dry place.
Humid wood tends to burn less easily, since it is necessary a greater quantity of energy to dry the wood out. Moreover, humid content
has the disadvantage that, when temperature decreases, the water condensates earlier in the hearth and therefore in the chimney
causing a remarkable deposit of soot that could catch re.
Fresh wood contains about 60% of H2O, therefore it is not suitable to be burnt.
It is necessary to place this wood in a dry and ventilated place (for example under a roong) for at least two years before using it.
Variety kg/mc kWh/kg moistness 20%
Beech 750 4,0
Oak 900 4,2
Elm 640 4,1
Poplar 470 4,1
Larch* 660 4,4
Spruce* 450 4,5
Scots pine * 550 4,4
*RESINOUS WOOD LESS SUITABLE FOR THE BURNING
WARNING
THE CONTINUOUS AND PROTRACTED USE OF AROMATIC WOOD (E.G. EUCALYPTUS, MYRTLE ETC.) QUICKLY DAMAGES
THE CAST IRON PARTS (CLEAVAGE) OF THE PRODUCT.
WOOD STANDARDS
The declared technical data have been achieved by burning beech wood class “A1” according to the requirement UNI EN ISO 17225-5
and wood moisture content less than 20%. By burning a dierent kind of wood the eciency of the product itself could change and
some specic adjustments on the appliance could be needed.
2.4 GENERAL INFORMATION
WARNING
ALLOWED FUELS ARE LOGS. USE EXCLUSIVELY DRY LOGS (MAX. CONTENT OF WATER 20%).
MAXIMUM 3 LOGS SHOULD BE LOADED.
THE PIECES OF WOOD SHOULD HAVE A LENGTH OF CA. 20-30 CM AND A MAXIMUM CIRCUMFERENCE OF 30-35 CM.
NOT WORKED-OUT WOOD BRIQUETTES MUST BE USED CAREFULLY TO AVOID OVERHEATING THAT MAY DAMAGE THE
DEVICE, SINCE THESE HAVE A VERY HIGH CALORIFIC VALUE.
IT IS NOT POSSIBLE TO BURN: COAL, CUTTINGS, WASTE OF BARK AND PANELS, HUMID WOOD OR WOOD TREATED WITH
PAINTS, PLASTIC MATERIALS; IN THIS CASE, THE WARRANTY ON THE DEVICE BECOMES VOID.
THE COMBUSTION OF WASTE IS FORBIDDEN AND WOULD EVEN DAMAGE THE APPLIANCE AND THE FLUE, CAUSING
HEALTH DAMAGES AND CLAIMS BY THE NEIGHBORHOOD OWING TO THE BAD SMELL.
WHEN USING THE WRONG FUEL OR ONE WHICH IS TOO DAMP, DUE TO DEPOSITS PRESENT IN THE FLUE, A SOOT FIRE IS
POSSIBLE.
PAPER AND CARDBOARD MUST BE USED ONLY TO LIGHT THE FIRE.
THE WOOD IS NOT A FUEL WHICH ALLOWS A CONTINUOUS OPERATION OF THE APPLIANCE, AS CONSEQUENCE THE
HEATING ALL OVER THE NIGHT IS NOT POSSIBLE.
NEVER USE GASOLINE, GASOLINE-TYPE LANTERN FUEL, KEROSENE, CHARCOAL LIGHTER FLUID, OR SIMILAR LIQUIDS TO
START OR ‘FRESHEN UP’ A FIRE IN THIS HEATER.
KEEP ALL SUCH LIQUIDS WELL AWAY FROM THE HEATER WHILE IT IS IN USE.
2.4.1 ALLOWED FUELS SPECIFICATIONS
12

007098005-001
WARNING
DURING COMBUSTION, THERMAL ENERGY IS RELEASED WHICH LEADS TO CONSIDERABLE HEATING OF THE SURFACES,
DOORS, HANDLES, CONTROLS, GLASS PARTS, THE FLUE GAS PIPE AND POSSIBLY THE FRONT PART OF THE APPLIANCE..
AVOID CONTACT WITH THESE ELEMENTS UNLESS USING SUITABLE PROTECTIVE CLOTHING OR ACCESSORIES.
ENSURE CHILDREN ARE AWARE OF THESE DANGERS AND KEEP THEM AWAY FROM THE FURNACE WHEN IT IS ON.
2.5 FIRE SAFETY
This appliance shall be operated exclusively with the ash drawer inserted. The fueling and ash removal door(s) must remain closed
when in operation.
The solid combustion residues (ash) must be collected in a sealed, re resistant container.
The Product must never be on in the presence of gaseous emissions or vapours (for example glue for linoleum, petrol etc.).
Never deposit ammable materials near the Product.
WARNING
DO NOT PUT OUT THE FIRE WITH WATER.
WHEN THE CHIMNEY FLUE STOPS BURNING, HAVE IT CHECKED BY A SPECIALIST TO IDENTIFY ANY CRACKS OR
PERMEABLE POINTS.
In case of re in the ue connection :
a) Close the loading door and the ash drawer door
b) Close the comburent air registers
c) Use carbon dioxide ( CO2powder ) extinguishers to put out the re
d) Request the immediate intervention of the Fire Brigade
2.5.1 NOTES FOR PROPER OPERATION
2.5.2 IN A EMERGENCY
Ashes should be placed in a metal container with a tight-tting lid. The closed container of ashes should be placed on a noncombustible
oor or on the ground, well away from all combustible materials, pending nal disposal. If the ashes are disposed of by burial in soil or
otherwise locally dispersed, they should be retained in the closed container until all cinders have thoroughly cooled.
2.4.2 DISPOSAL OF ASHES
13

007098005-001
WARNING
READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE THIS APPLIANCE. FAILURE TO FOLLOW THE
INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
USE ONLY APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE. USING NON-LISTED
ACCESSORIES AND REPLACEMENT PARTS (BLOWERS, DOORS, GASKETS, VENT COMPONENTS, ETC.) COULD RESULT IN A
SAFETY HAZARD AND WILL VOID THE WARRANTY.
THE COATING USED MUST BE NON-COMBUSTIBLE AND APPROVED ACCORDING TO STANDARD UL1618 FOR USA OR
APPROVED TO THE LOCALS CODES.
Installation of the Product and auxiliary equipment in relation to the heating system must comply with all current Standards and
Regulations and to those envisioned by the law.
The installation and the relating to the connections of the system, the commissioning and the check of the correct functioning must
be carried out in compliance with the regulations in force by authorised professional personnel with the requisites required by the
law, being national, regional, provincial or town council present in the country within which the appliance is installed, besides these
present instructions.
Installation must be carried out by authorised personnel who must provide the buyer with a system declaration of conformity and will
assume full responsibility for nal installation and as a consequence the correct functioning of the installed product.
The Product, assembled and ready for the installation, must be connected with a junction to the existing ue of the house.The junction
must be possibly short, straight, horizontal or positioned a little uphill. The connections must be tight.
3.0 INSTALLATION PLANNING
WARNING
THE COOK STOVES MUST BE INSTALLED WITH THE LEGS PROVIDED (IF APPLICABLE), ATTACHED AS SHOWN WITHIN
THESE INSTALLATION AND OPERATING INSTRUCTIONS.
DO NOT OBSTRUCT THE SPACE BENEATH THE APPLIANCE.
LA NORDICA S.P.A. DECLINES ALL RESPONSIBILITY FOR DAMAGE TO THINGS AND/OR PERSONS CAUSED BY THE SYSTEM.
IN ADDITION, IT IS NOT RESPONSIBLE FOR ANY PRODUCT MODIFIED
WITHOUT AUTHORISATION AND EVEN LESS FOR THE USE OF NON ORIGINAL SPARE PARTS.
3.1 APPLIANCE MINIMUM CLEARANCE TO COMBUSTIBLES
When installing the product, the following safety measures must be observed:
a) In order to ensure sucient thermal insulation, respect the minimum safety distance from objects or furnishing components
ammable and sensitive to heat (furniture, wood sheathings, fabrics. etc.) and from materials with ammable structure (see
Picture 1 - distances A1, A2, and A3). All the minimum safety distances are shown on the product data plate and lower values
must not be used (see DECLARATION OF PERFORMANCE ).
b) In front of the furnace door, in the radiation area there must be non-ammable nor heat-sensitive objects or material closer than
Picture 1 - distance A1.
Before installing this appliance, carry out the following checks:
• check where the ue gas connection is located on the appliance, i.e. UPPER - REAR - LATERAL
• verify if your structure can support the weight of the appliance. In case of insucient carrying capacity it is necessary to adopt
appropriate measures, La NORDICA responsibility is limited to the supply of the appliance (See chapterTECHNICAL DESCRIPTION).
• Make sure that the oor can support the weight of the appliance (for ex. distributing weight plate), and if it is made of ammable
material, provide suitable UL 1618 listed oor protector.
• Make sure that there is adequate ventilation in the room where the appliance is to be installed, with particular attention to
windows and doors with tight closing (seal ropes).
• Do not install the appliance in rooms containing collective ventilation ducts, hoods with or without extractor, type B gas appliances,
heat pumps, or other appliances that, operating at the same time, can put the room in depression.
• Make sure that the ue and the pipes to which the appliance will be connected are suitable for its operation. It is NOT allowed the
connection of several appliances to the same chimney.
• The diameter of the opening for connection to the chimney must at least correspond to the diameter of the ue gas pipe. The
opening must be equipped with a wall connection for the insertion of the exhaust pipe and a rosette.
• The unused ue gas exhaust connection must be covered with its respective cap (see chapter DIMENSIONS).
• The installation must be appropriate and has to allow the cleaning and maintenance of the product and the ue.
• It is recommended to install smoke detectors.
Your authorized local chimney sweeper must be informed about the installation of the appliance so that he can check the correct
connection to the chimney.
14

inches (mm) A1 A2 A3 B1 B2 B3
ROSA XXL UL-C 40 in (1016 mm) 10 in (254 mm) 15 in (381 mm) 16 in (406 mm) 8 in (203 mm) 2 in (50.8 mm)
ROSA L UL-C 40 in (1016 mm) 10 in (254 mm) 15 in (381 mm) 16 in (406 mm) 8 in (203 mm) 2 in (50.8 mm)
MILLY UL-C 40 in (1016 mm) 10 in (254 mm) 15 in (381 mm) 16 in (406 mm) 8 in (203 mm) 2 in (50.8 mm)
007098005-001
c) If the product is installed on a ammable oor, a oor protection must be installed. The oors made of ammable material,
such as moquette, parquet or cork etc., must be covered by a oor protector. SUCH FLOOR PROTECTOR SHALL BE A LISTED UL
1618 MATERIAL.
The oor protector shall be placed under the appliance and it must extend at least 16-in (419 mm) beyond the front and at least
8-in (203 mm) beyond each side of the fuel loading and ash removal opening (see Picture 2 - distance B).
Interior Vertical Vents Through the wall installation
A1
A2
A3
B3
A2
B2 B2
B1
A1
A2
A3
B3
A2
B2 B2
B1
Interior Vertical Vents Through the wall installation
A1
A2
A3
B3
A2
B2 B2
B1
A1
A2
A3
B3
A2
B2 B2
B1
3.1.1 STRAIGHT INSTALLATION
3.1.2 FLOOR PROTECTION INSTALLATION REQUIREMENTS
Picture 1
Picture 2
Floor ProtectionFloor Protection
15

007098005-001
3.2 THE CHIMNEY
Essential requirements for correct appliance operation:
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
THIS APPLIANCE MUST BE CONNECTED TO 1 A LISTED TYPE HT 2100 °F CHIMNEY PER UL 103 OR ULC S629 OR 2
A CODEAPPROVED MASONRY CHIMNEY WITH A FLUE LINER.
THECHIMNEY SIZE SHOULD NOTBELESSTHAN OR MORETHANTHREETIMES GREATERTHANTHE CROSSSECTIONAL
AREA OF THE FLUE COLLAR.

FOR A CORRECT INSTALLATION PLEASE RESPECT THE SECTIONS/LENGTHS OF THE FLUE SHOWN IN THE TECHNICAL
DATATABLE. BYINSTALLATIONSWITHDIFFERENT DIMENSIONSTHEFLUEMUST BESUITABLYSIZEDINACCORDANCE
WITH CAN/ULC S629 M87 IN CANADA AND TO UL 103 (TYPE HT 2100°F) IN USA.
WARNING
THE CHIMNEYS USED MUST BE IN ACCORD TO
CAN/ULC S629 M87 IN CANADA AND TO UL 103 (TYPE HT 2100°F) IN USA.
THE FLUE MUST BE AT A SUITABLY DISTANCE FROM FLAMMABLE OR COMBUSTIBLE MATERIAL USING SUITABLE
INSULATION OR AN AIR SPACE.
IT IS FORBIDDEN TO CREATE MOVEABLE OR FIXED OPENINGS ON THE FLUE ITSELF, FOR THE CONNECTION OF FURTHER
DIFFERENT APPLIANCES (SEE CHAPTER CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE).
3.2.1 CHIMNEY CONNECTOR
The chimney connector must be as short as possible, straight horizontal and positioned slightly in ascent, and watertight.
Connection to the chimney shall be performed attaching and securing the connections with a minimum of three screws to the product
and to each adjoining section.
Connection must be carried out with stable and robust pipes, comply with all current Standards and Regulations and to those
envisioned by the law, and be hermetically secured to the ue. Chimney Connector size to be used: 24 ga black or blued-steel, 6–
inch diameter. The chimney pressure (DRAUGHT) must be at least (see chap. TECHNICAL DATA SHEET) Pascal. The measurement
has always to be carried out with hot device (rated thermal performance).

WHEN THE DEPRESSION EXCEEDS 15 PA =1.5 MM OF COLUMN OF WATER, IT IS NECESSARY TO REDUCE THE
SAME BY INSTALLING AN AN APPROPRIATE DEVICE ON THE EXHAUST PIPE OR INTHE CHIMNEY, ACCORDING TO
THE REGULATIONS IN FORCE.
WARNING
THE CHIMNEYS USED MUST BE TESTED ACCORDING TO
CAN/ULC S629 M87 IN CANADA AND TO UL 103 (TYPE HT 2100°F) IN USA.
THE FLUE MUST BE PROPERLY SPACED FROM ANY FLAMMABLE MATERIALS OR FUELS THROUGH A PROPER INSULATION
OR AN AIR CAVITY. MINIMUM DISTANCE SAFETY 25 CM.
THE UNUSED FLUE GAS EXHAUST HOLE MUST BE COVERED WITH ITS RESPECTIVE CAP (See Chapter: Dimensions).
FOR CORRECT APPLIANCE OPERATION, IT IS ESSENTIAL THAT SUFFICIENT AIR FOR COMBUSTION IS INTRODUCED INTO
THE PLACE OF INSTALLATION (see paragraph VENTILATION AND AERATION OF THE INSTALLATION PREMISES).
FOR CANADA: A CHIMNEY CONNECTOR SHALL NOT PASS THROUGH AN ATTIC, ROOF SPACE, CLOSET, FLOOR, CEILING,
OR SIMILAR CONCEALED SPACE. WHERE PASSAGETHROUGH A WALL OR PARTITION OF COMBUSTIBLE CONSTRUCTION IS
DESIRED, THE INSTALLATION SHALL CONFORM WITH CAN/CSA-B365.
3.2.2 CHIMNEY AND CHIMNEY CONNECTOR MAINTENANCE
Inspection, maintenance, and cleaning of the chimney and chimney connector shall be guaranteed to handle the potential formation of
Creosote.
When wood is burned slowly, it produces tar and other organic vapors, which combine with expelled moisture to form creosote. The creosote
vapors condense in the relatively cool chimney ue of a slow-burning re. As a result, creosote residue accumulates on the ue lining. When
ignited this creosote makes an extremely hot re. When burning wood, the chimney connector and chimney should be inspected at least
once every two months during the heating season to determine if a creosote buildup has occurred.
16

007098005-001
3.2.3 MINIMUM INSIDE VERTICAL CLEARANCES
3.2.4 CLASS A CHIMNEY RETROFIT
Ceiling Support
Ceiling Support
Floor Protection
Floor Protection
Vertical Cap
Vertical Cap
Storm Collar
Storm Collar
Roof Flashing
Roof Flashing
NOTE:
FOLLOW CHIMNEY
MANUFACTURER'S
SPECIFICATIONS
INSTALLATION TYPE 1
NOTE:
FOLLOW CHIMNEY
MANUFACTURER'S
SPECIFICATIONS
INSTALLATION TYPE 1
SEE CHIMNEY MANUFACTURER'S
INSTRUCTIONS
SEE CHIMNEY MANUFACTURER'S
INSTRUCTIONS
17

007098005-001
3.2.5 MINIMUM INSIDE VERTICAL CLEARANCES
3.2.6 CLASS A CHIMNEY RETROFIT
Ceiling Support
Ceiling Support
Floor Protection
Floor Protection
Vertical Cap
Vertical Cap
Storm Collar
Storm Collar
Roof Flashing
Roof Flashing
NOTE:
FOLLOW CHIMNEY
MANUFACTURER'S
SPECIFICATIONS
INSTALLATION TYPE 1
NOTE:
FOLLOW CHIMNEY
MANUFACTURER'S
SPECIFICATIONS
INSTALLATION TYPE 1
SEE CHIMNEY MANUFACTURER'S
INSTRUCTIONS
SEE CHIMNEY MANUFACTURER'S
INSTRUCTIONS
18

Chimney ue
Chimney ue
Chimney ue
007098005-001
3.2.7 CHIMNEY CONNECTOR SYSTEM AND CLEARANCE FROM COMBUSTIBLE WALLS
RESIDENTIAL HEATHING APPLIANCES
Minimum chimney clearance from
masonry to sheet steel support and
combustibles 2 in. (51 mm)
Minimum chimney clearance from
masonry to sheet steel support and
combustibles 2 in. (51 mm)
Minimum chimney clearance from
masonry to sheet steel support and
combustibles 2 in. (51 mm)
Minimum chimney
clearance 2 in. (51 mm)
Factory built
chimney lenght
Sheet steel
supports
Sheet steel
supports
Sheet steel
supports
Sheet steel
support
Minimum
clearance 9 in.
(229 mm)
Minimum 6 in.
(152 mm) glass
ber insulation
Two ventilated
air channels each
1-in (25.4 mm).
Construction of
sheet steel
Two air channels each
1-in (25.4 mm)
1-in (25.4 mm)
air space to
chimney lenght
Air space 9 in.
(229 mm) min.
Air space 2 in.
(51 mm) min.
Chimney
connector
Adapter
Chimney
connector
Chimney
connector
Chimney
connector
Chimney
section
Chimney
lenght
Chimney lengh
ush with
inside of ue
Solid insulated listed
factory-built chimney
lenght
Non-soluble
refractory
cement
Masonry chimney
constructed to
NFPA 211
Masonry chimney
constructed to
NFPA 211
Masonry chimney
constructed to
NFPA 211
Minimum chimney clearance
to brick and combustibles 2 in.
(51 mm)
Minimum clearance
12 in. (305 mm)
of brick
Minimum 12in.
(305 mm)
to combustibles
Masonry chimney
constructed to
NFPA 211
A
Minimum 3.5-in thick brick masonry all framed into
combustible wall with a minimum of 12-in brick
separation from clay liner to combustibles.
the reclay liner shall run from outer surface of brick
wall to, but not beyond, the inner surface of chimney
ue liner and shall be rmly connected in place.
B
Solid-insulated, listed factory-built chimney
length of the same inside diameter as the chimney
connector and having 1-in or more of insulation with
a minimum 9-in air space between the outr wall of
the chimney length and combustibles.
C
Sheet steel chimney connector, minimum 24 gauge
in thickness, with a ventilated thimble, minimum
24 gauge in thickness, having two 1-in air channels,
separated from combustibles by a minimum of 6-in
of glass ber insulation. Opening shall be covered,
and thimble supported with a sheet steel support,
minimum 24 gauge in thickness.
D
Solid insulated, listed factory-built chimney length
with an inside diameter 2-in larger than tha chimney
connector and having 1-in or more of insulation,
serving as a pass-through for a single wall sheet steel
chimney connector of minimum 24 gauge thickness,
with a minimum 2-in air space between the outer
wall of chimney section abd combustibles.
Minimum length of chimney section shall be 12-in
chimney section spaced 1-in away from connector
using sheet steel support plates on both ends of
chimney section supported on both sides with sheet
steel supports securely fastened to wall surfaces of
minimum 24 gauge thickness.
Fastners used to secure chimney section shall not
penetrate cheminey ue liner.
19

3.3 VENTILATION AND AERATION OF THE INSTALLATION PREMISES
ASTHE PRODUCT MIGHT DRAW COMBUSTION AIR FROM THE PLACE OF INSTALLATION, IT IS MANDATORYTHAT IN THE PLACE ITSELF, A
SUFFICIENT QUANTITY OF AIR IS INTRODUCED. IF THE HOUSE IS EQUIPPED WITH A WELL-SEALED VAPOR BARRIER AND TIGHT-FITTING
WINDOWS AND/OR HAS ANY POWERED DEVICES THAT EXHAUST HOUSE AIR IT IS POSSIBLETHAT THE FRESH AIR INTAKE IS NO LONGER
GUARANTEED AND THIS JEOPARDISES THE DRAUGHT OF THE APPLIANCE AND YOUR HEALTH AND SAFETY.
Provision for outside combustion air may be necessary to ensure that the product do not discharge products of combustion into
the house. Guidelines to determine the need for additional combustion air may not be adequate for every situation. If in doubt, it is
advisable to provide additional air.
Outside combustion air may be required if:
1. The solid-fuel-red appliance does not draw steadily, smoke rollout occurs, fuel burns poorly, or back-drafts occur whether or not
there is combustion present.
2. Existing fuel-red equipment in the house, such as replaces or other heating appliances, smell, do not operate properly, suer
smoke roll-out when opened, or back-draft whether or not there is combustion present.
3. Opening a window slightly on a calm (windless) day alleviates any of the above symptoms.
4. The house is equipped with a well-sealed vapor barrier and tight tting windows and/or has any powered devices that exhaust
house air.
5. There is excessive condensation on windows in the winter.
6. A ventilation system is installed in the house.
If these or other indications suggest that inltration air is inadequate, additional combustion air should be provided from the outdoors.
Outside combustion air can be provided to the appliance by the following means:
1. Indirect method: the outside air is ducted to a point no closer than (12 in.) 300 mm from the appliance, to avoid aecting the
performance of the appliance.
2. A mechanical ventilation system: if the house has a ventilation system (air change or heat recovery):
- The ventilation system may be able to provide sucient combustion make-up air for the solid-fuel-red appliance.
- The householder should be informed that the ventilation system might need to be re-balanced by a ventilation technician after
installation of the appliance.
IMPORTANT: For a better comfort and corresponding oxygenation of the place of installation, the combustion air can be withdrawn from the
outside of the building through a pipe (not furnished) that which shall have a minimum according the OPTIONAL RING Air Fitting described
in Chapt. ACCESSORIES. This pipe must have a maximum length of 118-in (3 m) and no more than 3 bends.
The air inlets must meet the following requirements:
• they must be protected with grids, metal mesh, etc., but without reducing the net useful section;
• maintenance of the inlet shall be easy and feasible;
• positioned so that they cannot be obstructed;
007098005-001
WARNING
INSTALLATION IN PREMISES WITH FIRE HAZARDS IS FORBIDDEN.
ALL NATIONAL, AND LOCAL STANDARDS IN FORCE IN THE COUNTRY WHERE THE APPLIANCE IS INSTALLED MUST BE
COMPLIED WITH.
20
