Nordpeis Me Ceiling SA-ME000-C14 User manual

Art.no: SA-ME000-C14
Last updated: 22.11.2018
Test Report No: RRF 40 17 4683, NS 17 4683
GB Installation and user manual
Me Ceiling

2
GB IMPORTANT: Included in the installation kit are 4 x Ø8x120 wood screws. These are only intended for
use in solid wood beams. Follow the instructions below on how to insert cross-beams between the origi-
nal beams in order to create a safe construction. If your ceiling construction is made from other material
we strongly suggest to use protruding M8 bolts or threaded bars with appropriate washers on top.
We recommend a maximum chimney weight of 150 kg.
ATTENTION: Always follow the chimney manufacturer’s instructions and safety distances!

3
FIG 1 Me Ceiling = mm / air / chimney
520
339
600
260
1510 max.
246
360
520
339
600
260
1510 max.
246
360
600
246
509
360

4
See separate instruction
Example on how to t the cross-beams (FIG 2): For su󰀩cient strength and stability we strongly
recommend to use minimum 2x6” lumber. As the cross-beams are supporting the entire weight
and stability of the stove and the chimney, it is very important that they are securely xed to
the original beams.
GB
Manual for ME

5
FIG 2
min.50mm
min.150mm
600mm
509mm
509mm

6
Refer to the installation manual for ME and remove the Thermotte liner.
GB
6 mm
x2
FIG 3

7
FIG 4
22-ME000-CA0
O3,6
Insert the drill bush into the two rear holes and drill through the outer body of the stove with the
supplied 3,6mm drill. Attention! Do not press too hard while drilling so that the drill does not
slip o󰀨 the drilling point.
GB
!

8
FIG 5
xx
O3,6
x2
(1)
(2)
(3)
Apply the supplied magnetic (1) drill jig to the top of the stove as illustrated. Make sure the two rear
holes are centered in the two bean-shaped perforations (2) before drilling the two front holes
accordingly to the jig (3).
GB

9
FIG 6
O12
x4
Drill the holes only in the outer body.
GB

10
FIG 7
1.
2a
Remove the ue cover in the outer stove body with an angle grinder.
GB
2b
DV KIT

11
6 mm x2
FIG 8
FIG 9
1. 2.
3. 4.
4 mm
Remove the two screws as indicated and dispose.
GB
3 mm

12
FIG 10
5 mm M6x40
Place the connection bar between the inner and outer stove body using the two supplied
6 x 40mm bolts with washers to fasten it through the now empty holes.
GB
OK
!
UP
1.
2.
2.
3.
3.

13
3 mm
x2
M6x40
Insert the 6 x 40 threaded bars through the front holes of the outer stove body.
GB
FIG 11
FIG 12
Place the support collar as shown.
GB

14
5 mm
x2
FIG 13
M6x40
Fasten the two rear holes of the support collar to the stove through the rear holes with the two
supplied 6 x 40mm bolts from inside the stove.
GB

15
FIG 14
2,5mm
Fix the two threaded bars in front with the four pointed set screws with a force of 4-5 Nm.
GB
90 ⁰

16
x2
FIG 15
4 mm
Manual for DV Kit
See separate instruction
FIG 16
TOP!

17
x5
During assembly and handling please be
careful not to damage the painted surfaces.
GB
3 mm
FIG 16a
FIG 16b

18
FIG 16c
FIG 16d
3 mm
8 mm

19
FIG 17
2.
3.
FIG 17a
1.

20
Make sure the bolts are placed in the middle of the prolonged bean-shaped holes in the ceiling
collar. This will allow you to adjust the angle of the stove with 15 degrees in each direction after the
ceiling collar has been fastend to the ceiling.
GB
FIG 18
4 mm
x4
