Nordson Ultimus II User manual

Ultimus™I–II High Precision Fluid Dispensers
Operating Manual
Electronic pdf les of Nordson EFD
manuals are also available at
www.nordsonefd.com
™

You have selected a reliable, high-quality dispensing system from Nordson EFD, the world leader in uid
dispensing. The Ultimus high precision uid dispenser was designed specically for industrial dispensing
and will provide you with years of trouble-free, productive service.
This manual will help you maximize the usefulness of your Ultimus dispenser.
Please spend a few minutes to become familiar with the controls and features. Follow our recommended
testing procedures. Review the helpful information we have included, which is based on more than
50years of industrial dispensing experience.
Most questions you will have are answered in this manual. However, if you need assistance, please do
not hesitate to contact EFD or your authorized EFD distributor. Detailed contact information is provided
on the last page of this document.
The Nordson EFD Pledge
Thank You!
You have just purchased the world’s nest precision dispensing equipment.
I want you to know that all of us at Nordson EFD value your business and will do everything in our power
to make you a satised customer.
If at any time you are not fully satised with our equipment or the support provided by your Nordson
EFD Product Application Specialist, please contact me personally at 800.556.3484 (US), 401.431.7000
(outside US), or [email protected].
I guarantee that we will resolve any problems to your satisfaction.
Thanks again for choosing Nordson EFD.
Srini Subramanian, General Manager
Srini Subramanian
Ultimus I–II High Precision Fluid Dispensers
2www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Contents
Contents..........................................................................................................................................................................3
Nordson EFD Product Safety Statement ........................................................................................................................4
Halogenated Hydrocarbon Solvent Hazards ...............................................................................................................5
High Pressure Fluids....................................................................................................................................................5
Qualied Personnel......................................................................................................................................................5
Intended Use ...............................................................................................................................................................6
Regulations and Approvals..........................................................................................................................................6
Personal Safety............................................................................................................................................................6
Fire Safety....................................................................................................................................................................7
Preventive Maintenance ..............................................................................................................................................7
Important Disposable Component Safety Information ................................................................................................8
Action in the Event of a Malfunction............................................................................................................................8
Disposal .......................................................................................................................................................................8
Getting Started................................................................................................................................................................9
Specications................................................................................................................................................................10
Features & Controls: Front Panel ..................................................................................................................................12
Features & Controls: Back Panel...................................................................................................................................15
Initial Test Procedures ..................................................................................................................................................17
Setup for Testing........................................................................................................................................................17
Testing in Steady Mode .............................................................................................................................................17
Testing in Timed Mode ..............................................................................................................................................18
Testing in Teach Mode ...............................................................................................................................................18
Helpful Hints ..............................................................................................................................................................19
Advanced Features (Memory) .......................................................................................................................................20
To Save a Job Program .............................................................................................................................................20
To Work in a Saved Job Program ..............................................................................................................................20
To Edit or Clear a Saved Job .....................................................................................................................................21
Menu Functions.............................................................................................................................................................22
Units of Pressure / Units of Vacuum..........................................................................................................................22
Language ...................................................................................................................................................................22
Info.............................................................................................................................................................................22
Security Code ............................................................................................................................................................23
Input / Output Connection ............................................................................................................................................24
Voltage Initiate Circuit ...............................................................................................................................................24
Mechanical Contact Initiate .......................................................................................................................................24
End-of-Cycle Feedback Circuit .................................................................................................................................24
Pin Function...............................................................................................................................................................25
Pressure and Time Calibration...................................................................................................................................25
Filling the Syringe Barrel................................................................................................................................................26
Filling Procedure for Pourable Low and Medium Viscosity Fluids ............................................................................26
Filling Procedure for Thick Fluids .............................................................................................................................26
Filling Procedure for Watery Fluids and Vacuum Control ..........................................................................................27
Syringe Barrel Loading Alternatives ..............................................................................................................................28
Part Numbers ................................................................................................................................................................29
Replacement Parts........................................................................................................................................................29
Accessories ...................................................................................................................................................................29
Troubleshooting.............................................................................................................................................................30
Ultimus I–II High Precision Fluid Dispensers
3www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement
The safety messages that follow have a CAUTION level hazard.
Failure to comply may result in minor or moderate injury.
CAUTION
READ MANUAL
Read manual for proper use of this equipment. Follow all safety instructions. Task- and equipment-
specic warnings, cautions, and instructions are included in equipment documentation where
appropriate. Make sure these instructions and all other equipment documents are accessible to
persons operating or servicing equipment.
The safety message that follows has a WARNING level hazard.
Failure to comply could result in death or serious injury.
WARNING
ELECTRIC SHOCK
Risk of electric shock. Disconnect power before removing covers and / or disconnect, lock out, and
tag switches before servicing electrical equipment. If you receive even a slight electrical shock, shut
down all equipment immediately. Do not restart the equipment until the problem has been identied
and corrected.
MAXIMUM AIR PRESSURE
Unless otherwise noted in the product manual, the maximum air input pressure is 7.0 bar (100 psi).
Excessive air input pressure may damage the equipment. Air input pressure is intended to be applied
through an external air pressure regulator rated for 0 to 7.0 bar (0 to 100 psi).
RELEASE PRESSURE
Release hydraulic and pneumatic pressure before opening, adjusting, or servicing pressurized
systems or components.
BURNS
Hot surfaces! Avoid contact with the hot metal surfaces of heated components. If contact can not be
avoided, wear heat-protective gloves and clothing when working around heated equipment. Failure
to avoid contact with hot metal surfaces can result in personal injury.
Ultimus I–II High Precision Fluid Dispensers
4www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement (continued)
Halogenated Hydrocarbon Solvent Hazards
Do not use halogenated hydrocarbon solvents in a pressurized system that contains aluminum components.
Under pressure, these solvents can react with aluminum and explode, causing injury, death, or property damage.
Halogenated hydrocarbon solvents contain one or more of the following elements.
Element Symbol Prefix
Fluorine F “Fluoro-”
Chlorine Cl “Chloro-”
Bromine Br “Bromo-”
Iodine I “Iodo-”
Check the Safety Data Sheet (SDS) or contact your material supplier for more information. If you must use
halogenated hydrocarbon solvents, contact your EFD representative for compatible EFD components.
High Pressure Fluids
High pressure uids, unless they are safely contained, are extremely hazardous. Always release uid pressure before
adjusting or servicing high pressure equipment. A jet of high pressure uid can cut like a knife and cause serious
bodily injury, amputation, or death. Fluids penetrating the skin can also cause toxic poisoning.
Any injury caused by high pressure liquid can be serious. If you are injured or even suspect an injury:
• Go to an emergency room immediately.
• Tell the doctor that you suspect an injection injury.
• Show the doctor the following note.
• Tell the doctor what kind of material you were dispensing.
WARNING
Medical Alert — Airless Spray Wounds: Note to Physician
Injection in the skin is a serious traumatic injury. It is important to treat the injury surgically as soon as possible. Do
not delay treatment to research toxicity. Toxicity is a concern with some exotic coatings injected directly into the
bloodstream.
Qualified Personnel
Equipment owners are responsible for making sure that EFD equipment is installed, operated, and serviced by
qualied personnel. Qualied personnel are those employees or contractors who are trained to safely perform
their assigned tasks. They are familiar with all relevant safety rules and regulations and are physically capable of
performing their assigned tasks.
Ultimus I–II High Precision Fluid Dispensers
5www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement (continued)
Intended Use
Use of EFD equipment in ways other than those described in the documentation supplied with the equipment may
result in injury to persons or damage to property. Some examples of unintended use of equipment include:
• Using incompatible materials.
• Making unauthorized modications.
• Removing or bypassing safety guards or interlocks.
• Using incompatible or damaged parts.
• Using unapproved auxiliary equipment.
• Operating equipment in excess of maximum ratings.
• Operating equipment in an explosive atmosphere.
Regulations and Approvals
Make sure all equipment is rated and approved for the environment in which it is used. Any approvals obtained for
Nordson EFD equipment will be voided if instructions for installation, operation, and service are not followed. If the
equipment is used in a manner not specied by Nordson EFD, the protection provided by the equipment may be
impaired.
Personal Safety
To prevent injury, follow these instructions:
• Do not operate or service equipment unless you are qualied.
• Do not operate equipment unless safety guards, doors, and covers are intact and automatic interlocks are
operating properly. Do not bypass or disarm any safety devices.
• Keep clear of moving equipment. Before adjusting or servicing moving equipment, shut off the power supply
and wait until the equipment comes to a complete stop. Lock out power and secure the equipment to prevent
unexpected movement.
• Make sure spray areas and other work areas are adequately ventilated.
• When using a syringe barrel, always keep the dispensing end of the tip pointing towards the work and away
from the body or face. Store syringe barrels with the tip pointing down when they are not in use.
• Obtain and read the Safety Data Sheet (SDS) for all materials used. Follow the manufacturer’s instructions for
safe handling and use of materials and use recommended personal protection devices.
• Be aware of less-obvious dangers in the workplace that often cannot be completely eliminated, such as hot
surfaces, sharp edges, energized electrical circuits, and moving parts that cannot be enclosed or otherwise
guarded for practical reasons.
• Know where emergency stop buttons, shutoff valves, and re extinguishers are located.
• Wear hearing protection to protect against hearing loss that can be caused by exposure to vacuum exhaust port
noise over long periods of time.
Ultimus I–II High Precision Fluid Dispensers
6www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement (continued)
Fire Safety
To prevent a re or explosion, follow these instructions:
• Shut down all equipment immediately if you notice static sparking or arcing. Do not restart the equipment until
the cause has been identied and corrected.
• Do not smoke, weld, grind, or use open ames where ammable materials are being used or stored.
• Do not heat materials to temperatures above those recommended by the manufacturer. Make sure heat
monitoring and limiting devices are working properly.
• Provide adequate ventilation to prevent dangerous concentrations of volatile particles or vapors. Refer to local
codes or the SDS for guidance.
• Do not disconnect live electrical circuits when working with ammable materials. Shut off power at a disconnect
switch rst to prevent sparking.
• Know where emergency stop buttons, shutoff valves, and re extinguishers are located.
Preventive Maintenance
As part of maintaining continuous trouble-free use of this product, Nordson EFD recommends the following simple
preventive maintenance checks:
• Periodically inspect tube-to-tting connections for proper t. Secure as necessary.
• Check tubing for cracks and contamination. Replace tubing as necessary.
• Check all wiring connections for looseness. Tighten as necessary.
• Clean: If a front panel requires cleaning, use a clean, soft, damp rag with a mild detergent cleaner. DO NOT USE
strong solvents (MEK, acetone, THF, etc.) as they will damage the front panel material.
• Maintain: Use only a clean, dry air supply to the unit. The equipment does not require any other regular
maintenance.
• Test: Verify the operation of features and the performance of equipment using the appropriate sections of this
manual. Return faulty or defective units to Nordson EFD for replacement.
• Use only replacement parts that are designed for use with the original equipment. Contact your Nordson EFD
representative for information and advice.
Ultimus I–II High Precision Fluid Dispensers
7www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Important Disposable Component Safety Information
All Nordson EFD disposable components, including syringe barrels, cartridges, pistons, tip caps, end caps,
and dispense tips, are precision engineered for one-time use. Attempting to clean and re-use components will
compromise dispensing accuracy and may increase the risk of personal injury.
Always wear appropriate protective equipment and clothing suitable for your dispensing application and adhere to
the following guidelines:
• Do not heat syringe barrels or cartridges to a temperature greater than 38° C (100° F).
• Dispose of components according to local regulations after one-time use.
• Do not clean components with strong solvents (MEK, acetone, THF, etc.).
• Clean cartridge retainer systems and barrel loaders with mild detergents only.
• To prevent uid waste, use Nordson EFD SmoothFlow™pistons.
Action in the Event of a Malfunction
If a system or any equipment in a system malfunctions, shut off the system immediately and perform the following
steps:
1. Disconnect and lock out system electrical power. If using hydraulic and pneumatic shutoff valves, close and
relieve pressure.
2. For Nordson EFD air-powered dispensers, remove the syringe barrel from the adapter assembly. For Nordson
EFD electro-mechanical dispensers, slowly unscrew the barrel retainer and remove the barrel from the actuator.
3. Identify the reason for the malfunction and correct it before restarting the system.
Disposal
Dispose of equipment and materials used in operation and servicing according to local codes.
Nordson EFD Product Safety Statement (continued)
Ultimus I–II High Precision Fluid Dispensers
8www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

The Ultimus high precision uid dispenser is designed to provide complete process control for precise,
repeatable uid dispensing.
Key features include:
• All-digital, multi-function display with simultaneous readout of air pressure, vacuum, dispense time, and deposit
shot count.
• Unique air management reservoir and high-speed solenoid system for consistent, repeatable deposits.
• Time increment adjustments as small as 0.0001 seconds for precise deposit control.
• Workstation panel to hold a variety of useful accessories, such as a syringe barrel holder.
First Steps
First: Place the dispenser in your work area. The Ultimus is equipped with “stay put” rubber pads. It can be placed
on the benchtop or any at surface.
Second: Connect to power and air supplies and program the unit. For step-by-step setup instructions, see the
Ultimus Quick Start Guide.
Third: Now is a good time to activate your Ten Year Warranty. Please register your warranty online at www.
nordsonefd.com/warranty/dispensers/ten/. Or if you prefer, follow the instructions in the enclosed “Welcome” letter
to contact your area Nordson EFD representative.
Getting Started
Ultimus I–II High Precision Fluid Dispensers
9www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Ultimus I
Air input: 5.5–7.0 bar (80–100 psi)
Air output: 0–7.0 bar (0–100 psi)
Ultimus II
Air input: 5.5–7.0 bar (80–100 psi)
Air output: 0–1.0 bar (0–15 psi)
Specifications
NOTE: Specications and technical details are subject to engineering change without prior notication.
Item Specification
Cabinet size 14.3Wx 18.1Hx 17.3Dcm (5.63Wx 7.12Hx 6.82D")
Weight 2.3 kg (5.0 lb)
Power adapter AC input: 100–240 VAC (+/-10%), ~50/60Hz, 0.6 Amp
DC output: 24 VDC @ 1.04 Amp
End-of-cycle feedback circuits 5–24 VDC; 100 mA maximum
Initiate circuits Foot pedal, nger switch, or 5–24 VDC signal
Cycle rate Exceeds 600 cycles per minute
Time Range: Programmable from 0.0001–999.9999 seconds
Accuracy: Within ±0.05% of the selected time setting
Repeatability: Less than 16 μsec at any time setting
Pressure readout accuracy Ultimus I: ±2.0 psi, 0–7.0 bar (0–100 psi)
Ultimus II: ±0.3 psi, 0–1.0 bar (0–15 psi)
Vacuum readout accuracy ±2.0 inH2O, 0–18 inH2O
Ambient operating conditions Temperature: 5–45° C (41–113° F)
Humidity: 85% RH at 30° C non-condensing
Height above sea level: 2000 m maximum (6,562 ft)
Approvals CE, RoHS, WEEE, UL, and China RoHS compliant
Meets or exceeds CE and CSA requirements
120.7 mm
4.75"
180.8 mm
7.12"
143 mm
5.63"
173.2 mm
5.63"
159.5 mm
6.28"
Ultimus I–II High Precision Fluid Dispensers
10 www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

RoHS标准相关声明 (China RoHS Hazardous Material Declaration)
产品名称
Part Name
有害物质及元素
Toxic or Hazardous Substances and Elements
铅 
Lead
(Pb)
汞 
Mercury
(Hg)
镉 
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr6)
多溴联苯
Polybrominated
Biphenyls
(PBB)
多溴联苯醚
Polybrominated
Diphenyl Ethers
(PBDE)
外部接口
External Electrical
Connectors
X00000
O:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准低于SJ/T11363-2006限定要求。
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is below
the limit requirement in SJ/T11363-2006.
X:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准高于SJ/T11363-2006限定要求.
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is above
the limit requirement in SJ/T11363-2006.
WEEE Directive
This equipment is regulated by the European Union under WEEE Directive (2012/19/EU). Refer to
www.nordsonefd.com/WEEE for information about how to properly dispose of this equipment.
Specifications (continued)
Ultimus I–II High Precision Fluid Dispensers
11www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Dispense Mode
When powered on for the rst time, the Ultimus Home screen displays in TIMED mode.
Otherwise, it displays in the mode last used.
You can verify the mode by checking the top left corner of the display screen. It will be TIMED,
TEACH, STEADY, or MEMORY.
• You can return to TIMED mode from TEACH or STEADY by pressing TIMED in the bottom right
corner of the display.
• You can return to TIMED mode from MEMORY by pressing MENU, then selecting TIMED.
See the appropriate section below for details on each dispense mode.
Dispense Time
Dispense time, shown with an hourglass icon, displays from 000.0001 to 999.9999 seconds.
Follow these steps to set the dispense time.
1. Begin in TIMED mode.
2. Press the left / right arrows to highlight the rst number you want to change.
3. Press the up / down arrows to set the dispense time.
4. Repeat as needed to adjust the other numbers in the dispense time row.
Timed Mode
Dispense time
Display navigation
Multi-function controls
Pressure regulator Vacuum regulator
Power
Output air
Dispense pressure
Serial number
Cycle counter
Mode indicator
Vacuum pullback
Menu
See the Ultimus Icon Guide, included with your dispensing system, if you are working in
Chinese, Japanese, or Korean. Sample icons:
(Timed) (Steady) (Teach) (Menu) (Select) (Home)
Features & Controls: Front Panel
Ultimus I–II High Precision Fluid Dispensers
12 www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Air Pressure
Air pressure is displayed in psi. See page 22 to change the display of pressure from psi to
bar or kPa. It is shown with the icon of an arrow pushing into a syringe barrel. Follow these
steps to set air pressure.
1. Pull the air pressure regulator knob out to unlock it (bottom left knob).
2. Turn the knob clockwise to increase the pressure or counterclockwise to decrease the
pressure.
3. Push the knob in to lock the pressure setting.
A pressure regulator of 0–7.0 bar (0–100 psi) is intended to be provided before connecting the unit to the air supply.
CAUTION
4. Set the plant air supply to within 5.5–7.0 bar (80–100 psi).
Vacuum
Vacuum is displayed in inH2O (inches of water). See page 22 to change the display of
vacuum from inH2O to inHg, kPa, mmHg, or Torr. It is shown with the icon of an arrow pulling
out of a syringe barrel. Follow these steps to set vacuum pressure.
1. Pull the vacuum regulator knob out to unlock it (bottom right knob).
2. Turn the knob clockwise to the desired setting. You can adjust the vacuum in increments
of 0.1 inH2O.
3. Push the knob in to lock the vacuum setting.
Use EFD lter / mufer P/N 7016875 or wear adequate ear protection when operating the vacuum in close proximity
for a prolonged period of time.
CAUTION
Power
Press the power button to turn the unit on. A Nordson EFD logo will briey appear before the Home screen displays.
The Ultimus will go into sleep mode when it is inactive for more than 90 minutes. Simply press any button or the foot
pedal to reactivate the screen.
Features & Controls: Front Panel (continued)
Ultimus I–II High Precision Fluid Dispensers
13www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Menu
You can access the menu screen by pressing MENU. From here press the up / down and left / right arrows to select
from a variety of screens, including:
TIMED TEACH MEMORY
CLEAR COUNT UNITS OF PRESSURE UNITS OF VACUUM
SECURITY LANGUAGE SAVE JOB
INFO
Refer to “Menu Functions” on page 22 for more information on Menu functions.
Shot Count
The shot count is displayed in the top center section of the display screen. It displays the number of deposits that
have been dispensed. Follow these steps to reset the shot count.
1. Press MENU.
2. Press the down arrows to scroll to CLEAR COUNT.
3. Press SELECT. This resets the shot count to 0 and automatically returns you to the Home screen.
Timed Mode
In TIMED mode, the Ultimus will dispense a single deposit each time you press the foot pedal or nger switch.
Deposit size is based on dispense time and pressure settings shown on the display.
Steady Mode
In STEADY mode you can dispense for as long as you press the foot pedal or nger switch. From TIMED mode,
press STEADY. This toggles the display so that the top left corner is now shows the STEADY mode. Refer to “Initial
Test Procedures” on page 17 for more details on STEADY mode.
Teach Mode
In TEACH mode you can “teach” the deposit based on physical size. Begin at the Home screen for TIMED mode.
Press TEACH. This toggles the display so that the top left corner is now shows the TEACH mode. Refer to “Initial
Test Procedures” on page 17 for more details on TEACH mode.
Output Air Port
The Ultimus features one air port on front panel to provide regulated air pressure to the syringe barrel. You can
connect the Optimum™adapter assembly to the port on the front panel.
• Push the black quick-connect from the EFD adapter assembly into the air output port and twist to lock.
NOTE: Air does not ow through the port until a quick-connect is installed.
Features & Controls: Front Panel (continued)
Ultimus I–II High Precision Fluid Dispensers
14 www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Power Input Port
The power input port is located at the top left corner of the Ultimus. The Ultimus power pack automatically adjusts
for 100 to 240 VAC.
Use only the universal power pack provided with the Ultimus workstation. The unit is shipped with four power plugs
(one USA and three international plugs) and an 1800 mm (5.9 ft) length power cord.
• Connect the DC plug from the cord to the Ultimus power input port.
• Connect the power cord to your local power source.
Communication Port
The Ultimus communication port, located on the top row of ports, is for EFD use only.
Input / Output 8-Pin Interface Connector
Input / output features are used when the Ultimus is interfaced with external control circuits. The 8-pin connector is
located on the top row of ports. Refer to “Input / Output Connection” on page 24 for details.
• An End-of-Cycle signal, in the form of an electronic switch, closes upon completion of the dispense cycle.
Chassis connection
This symbol identies the
chassis connection terminal.
Used for grounding the chassis
to shunt leakage current and
/ or enhancing system EFD
protection.
Foot pedal /
nger switch
Power
input port
Exhaust Input air
Communication
port
Input / output
(I/O) port
Features & Controls: Back Panel
Ultimus I–II High Precision Fluid Dispensers
15www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Features & Controls: Back Panel (continued)
Foot Pedal / Finger Switch Port
The switch port, a 6-pin mini DIN connection, is located on the top right corner of the Ultimus. It is used to connect
the foot pedal or nger switch that activates the dispense cycle. Be sure to align the foot pedal or nger switch cord
connector so that arrow on the connector is on top.
Exhaust Port
The exhaust port is the larger 8 mm pneumatic tting located at the bottom left corner of the Ultimus workstation.
• If needed, you can connect a cleanroom lter mufer to lter output air to meet Fed 209-B (0.5 micron
particulates). For dispenser accressories, refer to “Accessories” on page 29.
Use EFD lter / mufer P/N 7016875 or wear adequate ear protection when operating the vacuum in close proximity
for a prolonged period of time.
CAUTION
Air Input Port
The air input port is the smaller pneumatic tting (6 mm) located at the bottom right corner of the Ultimus
workstation.
1. Push one end of the 6 mm air input tubing into the air input tting on the back of the Ultimus. A 2.4 mm (8 ft)
length of air tubing is provided.
2. Connect the other end of the air input tubing to your plant air supply. A standard 1/4 NPT tting is included with
your unit.
NOTE: Clean, dry ltered factory air is required to meet warranty. If your air supply is not ltered, order the 5-micron
lter regulator. For dispenser accressories, refer to “Accessories” on page 29.
Bottled nitrogen can be used. If high pressure bottled air or nitrogen is used, a high pressure regulator must be
installed on the bottle and set at 7.0 bar (100 psi) maximum. In this instance, the 5-micron lter regulator is not
required.
WARNING
A pressure regulator of 0–7.0 bar (0–100 psi) is intended to be provided before connecting the unit to the air supply.
CAUTION
Ultimus I–II High Precision Fluid Dispensers
16 www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Deposit size is controlled by dispense time, pressure, and tip size.
Follow these instructions to test each function. Use the convenient Dot Standards sheet included in your dispensing
system kit.
NOTE: Tips and helpful suggestions for setup are provided under “Helpful Hints” on page 19. Refer to this
information as needed during initial setup and testing.
Setup for Testing
1. Attach an EFD syringe barrel lled with your assembly uid to the adapter
assembly as shown.
2. Keep the vacuum set at 0.0 during initial testing. (If you are dispensing
a watery uid, refer to “Filling Procedure for Watery Fluids and Vacuum
Control” on page 27.)
3. Replace the blue tip cap with an EFD precision dispense tip.
4. Slide the syringe barrel into the hand grip. Snap in place.
5. Run through the following tests to demonstrate the ease at which deposit
sizes can be established using the various dispense modes.
Testing in Steady Mode
1. Select STEADY mode.
2. Pull the air pressure regulator knob out until it clicks into the unlocked position. Start with pressure set to
0.0bar (0 psi).
3. Press and hold the foot pedal or nger switch.
4. Slowly, turn the pressure knob clockwise until your uid begins to dispense out of the tip in a controlled ow
(not too fast, not too slow).
5. Push the air pressure knob in to lock the setting.
Correct angle for consistent deposits.
Remember - always bring the tip in contact
with the work surface at the illustrated angle.
After the tip is in position, press the foot
pedal. Release the pedal and remove the tip
by lifting straight up.
Initial Test Procedures
Ultimus I–II High Precision Fluid Dispensers
17www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Testing in Timed Mode
1. Refer to “Testing in Steady Mode” on page 17 to purge your dispensing tip with uid.
2. Change to TIMED mode.
3. Set the time to 000.0250 seconds.
4. Rest the dispense tip on the Dot Standards sheet.
5. Press the foot pedal (or nger switch) to activate the dispense cycle.
NOTE: The pedal only needs to be pressed for a moment. The complete time will run once you activate the
dispense cycle.
6. Changing the time changes the deposit size. If your dot is too small, increase the dispense time to increase
the deposit size. If your dot is too large, decrease the dispense time to decrease the deposit size.
Testing in Teach Mode
1. Refer to “Testing in Steady Mode” on page 17 to purge the dispensing tip with uid.
2. Change to TEACH mode by going to the menu and scrolling to TEACH.
3. Rest the dispense tip on the Dot Standards sheet.
4. Press the foot pedal to establish your dot size. Depressing the foot pedal repeatedly will have a cumulative
effect on the dot size and dispense time.
5. Continue to press the foot pedal until you achieve the correct deposit size.
6. If needed, press CLEAR to start over.
7. Save the dispense time setting you just created by pressing SAVE. This automatically exits TEACH mode and
returns you to TIMED mode.
Initial Test Procedures (continued)
Ultimus I–II High Precision Fluid Dispensers
18 www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Helpful Hints
• There are three core variables for setting up the Ultimus high precision uid dispenser: dispense time, pressure,
and vacuum. Adjust just one of these at a time, in small increments, to achieve the correct deposit.
• Another important variable is tip size. Choose the right tip for the deposit type. Remember, smaller tips require
more pressure and more time. Try different tips without changing the time or pressure settings and observe the
results.
• Tapered tips reduce the amount of air pressure needed to dispense thick materials. They also help prevent
drooling at the end of a dispense cycle.
• To ensure smooth uid ow and to make consistent deposits, keep the dispense tip at a 45° angle to the work
surface.
• Use EFD SmoothFlow pistons to make barrel loading, dispensing, and uid handling cleaner, safer, and more
accurate.
If you dispense watery uids and choose not to use EFD pistons, do not increase vacuum pressure rapidly and do
not tip the barrel. Vacuum may pull uid into the adapter hose, or, if the syringe barrel is tipped, uid may ow back
into the dispenser.
CAUTION
• Always use new EFD syringe barrels and tips. Carefully dispose of after use. This procedure ensures maximum
cleanliness, prevents contamination, and provides proper safety.
• Do not completely ll the syringe barrel. For most uids, optimum ll is a maximum 2/3 of the barrel capacity. For
cyanoacrylates or watery uids, optimum ll is 1/2 of the barrel capacity.
Suggestions on Settings
• Avoid high pressure settings with very short time settings (example: 5.5 bar / 80 psi at less than
000.0100seconds). The ideal setup matches air pressure and tip size to produce a “workable” ow rate – no
splashing, but not too slow either – with a time setting that is not extremely low.
• With any uid, always give the air pressure time to do its job. Moderate time and pressure provides the best
results since dispensing pressure remains at its peak for a longer period of time.
• Longer dispense time settings generally provide the highest accuracy. However, in the interest of cost-effective
production, do not use excessively long dispense time settings. Experiment to nd what works best for your
application.
Initial Test Procedures (continued)
Ultimus I–II High Precision Fluid Dispensers
19www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.

Advanced Features (Memory)
The Ultimus high precision dispenser allows you to store the dispense time, pressure, and vacuum settings for up to
16 different job programs. Programs are saved even with power removed and will remain in storage unless changed
or erased intentionally.
Job programs are identied as Memory 1 through Memory 16.
NOTE: Dispense time is automatically adjusted when you select an individual job program. Settings for pressure and
vacuum are stored and can be displayed but you need to manually adjust the pressure and vacuum regulator knobs
to match the stored settings for these values.
To Save a Job Program
1. From TIMED or TEACH mode, set the dispense time, air pressure, and vacuum settings to create a correct
deposit size. When you are in TEACH mode, press SAVE after you create your settings, then return to TIMED
mode.
2. Press MENU. Use the up / down arrows to scroll to SAVE JOB. Press SELECT.
3. Use the up / down arrows to select the correct job program in which to save these settings (example, Memory1
or Memory 2).
Remember: to prevent accidental data loss, review the contents of each job program before selecting and
storing a new job into memory.
4. Press SAVE. This automatically saves the settings in the job program.
To Work in a Saved Job Program
1. Press MENU. Use the up / down arrows to highlight MEMORY. Press SELECT.
2. Use the up / down arrows to scroll through the individual jobs until you reach the correct Memory number.
3. Press and hold SETTINGS to see the stored pressure and vacuum settings for the job.
Remember: Dispense time automatically adjusts when you select a job program. Releasing the SETTINGS
button displays the current values for pressure and vacuum, not the stored values. To retrieve the stored values,
manually adjust air pressure and vacuum based on the pressure and vacuum shown when you press Settings.
4. Press the foot pedal or nger switch to activate the dispense cycle. The Ultimus will automatically make the
deposit based on the settings in the selected job program.
5. To escape from Memory, press MENU. Then press TIMED to return to the Home screen. At this point, you are
still in the current memory setting for the previous job program, but you are free to change time, pressure, and
vacuum without impacting the stored settings in memory.
Ultimus I–II High Precision Fluid Dispensers
20 www.nordsonefd.com [email protected] 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
