UltimusPlus Series Dispensers
Operating Manual
Electronic pdf files of Nordson EFD
manuals are also available at
www.nordsonefd.com
™

You have selected a reliable, high-quality dispensing system from Nordson EFD, the world leader in fluid
dispensing. UltimusPlus™Series fluid dispensers are designed specifically for industrial dispensing and
will provide you with years of trouble-free, productive service.
This manual will help you maximize the usefulness of your UltimusPlus dispenser.
Please spend a few minutes to become familiar with the controls and features. Follow our recommended
testing procedures. Review the helpful information we have included, which is based on more than
50years of industrial dispensing experience.
Most questions you will have are answered in this manual. However, if you need assistance, please do
not hesitate to contact EFD or your authorized EFD distributor. Detailed contact information is provided
on the last page of this document.
The Nordson EFD Pledge
Thank You!
You have just purchased the world’s finest precision dispensing equipment.
I want you to know that all of us at Nordson EFD value your business and will do everything in our power
to make you a satisfied customer.
If at any time you are not fully satisfied with our equipment or the support provided by your Nordson
EFD Product Application Specialist, please contact me personally at 800.556.3484 (US), 401.431.7000
(outside US), or [email protected].
I guarantee that we will resolve any problems to your satisfaction.
Thanks again for choosing Nordson EFD.
Srini Subramanian, General Manager
Srini Subramanian
UltimusPlus Series Dispensers
2www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Contents
Contents..........................................................................................................................................................................3
Introduction .....................................................................................................................................................................5
UltimusPlus Dispenser Models....................................................................................................................................5
Overview of Features...................................................................................................................................................5
Nordson EFD Product Safety Statement ........................................................................................................................6
Halogenated Hydrocarbon Solvent Hazards ...............................................................................................................7
High Pressure Fluids....................................................................................................................................................7
Qualified Personnel......................................................................................................................................................7
Intended Use ...............................................................................................................................................................8
Regulations and Approvals..........................................................................................................................................8
Personal Safety............................................................................................................................................................8
Fire Safety....................................................................................................................................................................9
Preventive Maintenance ..............................................................................................................................................9
Important Disposable Component Safety Information ..............................................................................................10
Action in the Event of a Malfunction..........................................................................................................................10
Disposal .....................................................................................................................................................................10
Specifications................................................................................................................................................................11
Operating Features........................................................................................................................................................12
Overview of the UltimusPlus User Interface..................................................................................................................14
Navigation..................................................................................................................................................................14
Flowchart of Dispenser Screens................................................................................................................................15
About Programs.........................................................................................................................................................16
How the System Names Programs ...........................................................................................................................16
Entering Values..........................................................................................................................................................17
Dispense Modes........................................................................................................................................................17
Ranges for All Editable Settings ................................................................................................................................18
Installation .....................................................................................................................................................................19
Unpack the Unit / Warranty .......................................................................................................................................19
Connect Power ..........................................................................................................................................................19
Connect the Foot Pedal.............................................................................................................................................19
(Optional) Connect a Mouse ......................................................................................................................................20
Connect the Air Input.................................................................................................................................................20
Connect the Air Output..............................................................................................................................................21
Connect the Syringe Barrel / Dispense Tip ...............................................................................................................21
Switch the Power On .................................................................................................................................................22
Set the Dispense Time...............................................................................................................................................22
Set the Air Pressure ...................................................................................................................................................22
Set the Vacuum .........................................................................................................................................................23
Purge the Tip .............................................................................................................................................................23
Connect to Ancillary Components.............................................................................................................................23
Initial Startup and Testing .............................................................................................................................................24
Decision Tree for Setting Up Dispenser Operation ...................................................................................................24
Setting Up the Dispenser for Steady Mode Operation..............................................................................................25
Setting Up the Dispenser for Timed Mode Operation ...............................................................................................25
Using the Teach Mode to Set Up the Dispenser for Timed Operation ..................................................................26
Manually Setting Up the Dispenser for Timed Mode Operation ............................................................................27
Helpful Hints ..............................................................................................................................................................28
Continued on next page
UltimusPlus Series Dispensers
3www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Contents (continued)
Operation.......................................................................................................................................................................29
Routine Startup..........................................................................................................................................................29
Setting the Dispense Time, Pressure, or Vacuum .....................................................................................................29
Activating a Program .................................................................................................................................................30
Editing a Program ......................................................................................................................................................31
Locking or Unlocking the System..............................................................................................................................32
Exporting Programs to a USB Drive ..........................................................................................................................33
Importing Programs from a USB Drive to a Dispenser..............................................................................................33
Using the Barcode Scanner.......................................................................................................................................34
Using the MultiShot Feature ......................................................................................................................................36
Using the Sleep Mode (UltimusPlus I Only) ...............................................................................................................37
Clearing Alarms .........................................................................................................................................................37
Viewing or Exporting the Dispense Log.....................................................................................................................38
Connecting an Ethernet Cable for Factory Integration..............................................................................................39
System Settings ............................................................................................................................................................40
Setting the Language.................................................................................................................................................40
Setting the Units of Measure .....................................................................................................................................40
Setting the System Date or Time...............................................................................................................................40
Changing the System Password ...............................................................................................................................41
Setting a Run Limit, Viewing the Shot Count or System Count, and Resetting the Shot Count...............................42
Viewing System Information ......................................................................................................................................43
Viewing the Software Version or Updating the Software ..........................................................................................43
Syringe Barrel Filling......................................................................................................................................................44
Selecting an Adapter Assembly.................................................................................................................................44
Selecting a Piston ......................................................................................................................................................44
Filling the Syringe Barrel............................................................................................................................................45
Top Filling of Pourable Materials............................................................................................................................45
Top Filling of Medium- to High-Viscosity Materials ...............................................................................................45
Bottom Filling of All Materials ................................................................................................................................46
Syringe Barrel Filling Alternatives ..............................................................................................................................47
Service...........................................................................................................................................................................48
Part Numbers ................................................................................................................................................................48
Dispensers .................................................................................................................................................................48
Quicksilver Adapter Assembly...................................................................................................................................48
Accessories ...................................................................................................................................................................49
Replacement Parts........................................................................................................................................................49
Troubleshooting ............................................................................................................................................................50
Dispenser Warnings...................................................................................................................................................50
Electrical or Software Problems ................................................................................................................................51
Mechanical or Material Output Problems ..................................................................................................................52
Technical Data...............................................................................................................................................................53
I/O Port Pin Assignments...........................................................................................................................................53
Input / Output Connections .......................................................................................................................................54
Voltage Initiate Circuit ............................................................................................................................................54
Program Selector Circuit........................................................................................................................................54
Emergency Stop (E-Stop) Circuit ...........................................................................................................................55
Clear Alarm Circuit .................................................................................................................................................55
Alarm Out Circuit....................................................................................................................................................56
End-of-Cycle Feedback Circuit..............................................................................................................................56
Contact Closure Circuit..........................................................................................................................................57
Appendix A, Changing the IP Address of a Computer..................................................................................................58
UltimusPlus Series Dispensers
4www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Introduction
This manual provides specifications, operating features, installation, setup, operation, troubleshooting, and parts
information for UltimusPlus Series pneumatic benchtop fluid dispensers. The UltimusPlus dispenser is designed
to provide precise dispensing control for advanced applications of glue, oil, grease, epoxy, silicone, sealants,
cyanoacrylates, solder paste, and other assembly fluids dispensed with syringe barrels.
UltimusPlus Dispenser Models
• The UltimusPlus I features 0.7–7.0 bar (10–100 psi) constant-bleed air pressure regulation and provides greater
control when dispensing any type of fluid.
• The UltimusPlus II features 0–1.0 bar (0.3–15 psi) constant-bleed air pressure regulation and provides greater
control when dispensing low-viscosity or thin fluids.
Overview of Features
• Intuitive, easy-to-use touchscreen interface that provides simultaneous readout of dispense time, pressure,
vacuum, and deposit count
• Storage of 16 dispensing programs in a Program Library
• USB connectivity for exporting or importing dispense programs and for exporting log data
• Ethernet connectivity for triggering the dispenser and switching between active programs
• Time increment adjustments as small as 0.0001 seconds
• MultiShot™capability, allowing the operator to dispense multiple deposits with only one cycle initiate (such as
one press of the foot pedal)
• Dispense log data collection, including the collection of dispensing parameter data (dispense time, pressure,
vacuum) and the date, day, and hour / time of each dispense cycle
• Full operator lockout of time, pressure, and vacuum settings
• Optional barcode scanner accessory available for quick program recognition and change
• Easy integration into an automated dispensing system via a single plug-and-play cable
• Input / output connectivity for initiating a dispense cycle (via voltage initiate or contact closure), program
selection, emergency stop, clearing alarms, an alarm out signal, and end-of-cycle feedback.
• On UltimusPlus I dispensers, sleep mode for reduced power and air consumption during downtimes
• Quicksilver™adapter assembly allows maximum air flow to the syringe barrel for faster cycle speeds and pulsing
UltimusPlus Series Dispensers
5www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement
The safety messages that follow have a CAUTION level hazard.
Failure to comply may result in minor or moderate injury.
CAUTION
READ MANUAL
Read manual for proper use of this equipment. Follow all safety instructions. Task- and equipment-
specific warnings, cautions, and instructions are included in equipment documentation where
appropriate. Make sure these instructions and all other equipment documents are accessible to
persons operating or servicing equipment.
The safety message that follows has a WARNING level hazard.
Failure to comply could result in death or serious injury.
WARNING
ELECTRIC SHOCK
Risk of electric shock. Disconnect power before removing covers and / or disconnect, lock out, and
tag switches before servicing electrical equipment. If you receive even a slight electrical shock, shut
down all equipment immediately. Do not restart the equipment until the problem has been identified
and corrected.
MAXIMUM AIR PRESSURE
Unless otherwise noted in the product manual, the maximum air input pressure is 7.0 bar (100
psi). Excessive air input pressure may damage the equipment. Air input pressure is intended to be
applied through an external air pressure regulator rated for 0 to 7.0 bar (0 to 100 psi).
RELEASE PRESSURE
Release hydraulic and pneumatic pressure before opening, adjusting, or servicing pressurized
systems or components.
BURNS
Hot surfaces! Avoid contact with the hot metal surfaces of heated components. If contact can not be
avoided, wear heat-protective gloves and clothing when working around heated equipment. Failure
to avoid contact with hot metal surfaces can result in personal injury.
UltimusPlus Series Dispensers
6www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement (continued)
Halogenated Hydrocarbon Solvent Hazards
Do not use halogenated hydrocarbon solvents in a pressurized system that contains aluminum components.
Under pressure, these solvents can react with aluminum and explode, causing injury, death, or property damage.
Halogenated hydrocarbon solvents contain one or more of the following elements.
Element Symbol Prefix
Fluorine F “Fluoro-”
Chlorine Cl “Chloro-”
Bromine Br “Bromo-”
Iodine I “Iodo-”
Check the Safety Data Sheet (SDS) or contact your material supplier for more information. If you must use
halogenated hydrocarbon solvents, contact your EFD representative for compatible EFD components.
High Pressure Fluids
High pressure fluids, unless they are safely contained, are extremely hazardous. Always release fluid pressure before
adjusting or servicing high pressure equipment. A jet of high pressure fluid can cut like a knife and cause serious
bodily injury, amputation, or death. Fluids penetrating the skin can also cause toxic poisoning.
Any injury caused by high pressure liquid can be serious. If you are injured or even suspect an injury:
• Go to an emergency room immediately.
• Tell the doctor that you suspect an injection injury.
• Show the doctor the following note.
• Tell the doctor what kind of material you were dispensing.
WARNING
Medical Alert — Airless Spray Wounds: Note to Physician
Injection in the skin is a serious traumatic injury. It is important to treat the injury surgically as soon as possible. Do
not delay treatment to research toxicity. Toxicity is a concern with some exotic coatings injected directly into the
bloodstream.
Qualified Personnel
Equipment owners are responsible for making sure that EFD equipment is installed, operated, and serviced by
qualified personnel. Qualified personnel are those employees or contractors who are trained to safely perform
their assigned tasks. They are familiar with all relevant safety rules and regulations and are physically capable of
performing their assigned tasks.
UltimusPlus Series Dispensers
7www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement (continued)
Intended Use
Use of EFD equipment in ways other than those described in the documentation supplied with the equipment may
result in injury to persons or damage to property. Some examples of unintended use of equipment include:
• Using incompatible materials.
• Making unauthorized modifications.
• Removing or bypassing safety guards or interlocks.
• Using incompatible or damaged parts.
• Using unapproved auxiliary equipment.
• Operating equipment in excess of maximum ratings.
• Operating equipment in an explosive atmosphere.
Regulations and Approvals
Make sure all equipment is rated and approved for the environment in which it is used. Any approvals obtained for
Nordson EFD equipment will be voided if instructions for installation, operation, and service are not followed. If the
equipment is used in a manner not specified by Nordson EFD, the protection provided by the equipment may be
impaired.
Personal Safety
To prevent injury, follow these instructions:
• Do not operate or service equipment unless you are qualified.
• Do not operate equipment unless safety guards, doors, and covers are intact and automatic interlocks are
operating properly. Do not bypass or disarm any safety devices.
• Keep clear of moving equipment. Before adjusting or servicing moving equipment, shut off the power supply
and wait until the equipment comes to a complete stop. Lock out power and secure the equipment to prevent
unexpected movement.
• Make sure spray areas and other work areas are adequately ventilated.
• When using a syringe barrel, always keep the dispensing end of the tip pointing towards the work and away
from the body or face. Store syringe barrels with the tip pointing down when they are not in use.
• Obtain and read the Safety Data Sheet (SDS) for all materials used. Follow the manufacturer’s instructions for
safe handling and use of materials and use recommended personal protection devices.
• Be aware of less-obvious dangers in the workplace that often cannot be completely eliminated, such as hot
surfaces, sharp edges, energized electrical circuits, and moving parts that cannot be enclosed or otherwise
guarded for practical reasons.
• Know where emergency stop buttons, shutoff valves, and fire extinguishers are located.
• Wear hearing protection to protect against hearing loss that can be caused by exposure to vacuum exhaust
port noise over long periods of time.
UltimusPlus Series Dispensers
8www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Nordson EFD Product Safety Statement (continued)
Fire Safety
To prevent a fire or explosion, follow these instructions:
• Shut down all equipment immediately if you notice static sparking or arcing. Do not restart the equipment until
the cause has been identified and corrected.
• Do not smoke, weld, grind, or use open flames where flammable materials are being used or stored.
• Do not heat materials to temperatures above those recommended by the manufacturer. Make sure heat
monitoring and limiting devices are working properly.
• Provide adequate ventilation to prevent dangerous concentrations of volatile particles or vapors. Refer to local
codes or the SDS for guidance.
• Do not disconnect live electrical circuits when working with flammable materials. Shut off power at a disconnect
switch first to prevent sparking.
• Know where emergency stop buttons, shutoff valves, and fire extinguishers are located.
Preventive Maintenance
As part of maintaining continuous trouble-free use of this product, Nordson EFD recommends the following simple
preventive maintenance checks:
• Periodically inspect tube-to-fitting connections for proper fit. Secure as necessary.
• Check tubing for cracks and contamination. Replace tubing as necessary.
• Check all wiring connections for looseness. Tighten as necessary.
• Clean: If a front panel requires cleaning, use a clean, soft, damp rag with a mild detergent cleaner. DO NOT
USE strong solvents (MEK, acetone, THF, etc.) as they will damage the front panel material.
• Maintain: Use only a clean, dry air supply to the unit. The equipment does not require any other regular
maintenance.
• Test: Verify the operation of features and the performance of equipment using the appropriate sections of this
manual. Return faulty or defective units to Nordson EFD for replacement.
• Use only replacement parts that are designed for use with the original equipment. Contact your Nordson EFD
representative for information and advice.
UltimusPlus Series Dispensers
9www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Important Disposable Component Safety Information
All Nordson EFD disposable components, including syringe barrels, cartridges, pistons, tip caps, end caps,
and dispense tips, are precision engineered for one-time use. Attempting to clean and re-use components will
compromise dispensing accuracy and may increase the risk of personal injury.
Always wear appropriate protective equipment and clothing suitable for your dispensing application and adhere to
the following guidelines:
• Do not heat syringe barrels or cartridges to a temperature greater than 38° C (100° F).
• Dispose of components according to local regulations after one-time use.
• Do not clean components with strong solvents (MEK, acetone, THF, etc.).
• Clean cartridge retainer systems and barrel loaders with mild detergents only.
• To prevent fluid waste, use Nordson EFD SmoothFlow™pistons.
Action in the Event of a Malfunction
If a system or any equipment in a system malfunctions, shut off the system immediately and perform the following
steps:
1. Disconnect and lock out system electrical power. If using hydraulic and pneumatic shutoff valves, close and
relieve pressure.
2. For Nordson EFD air-powered dispensers, remove the syringe barrel from the adapter assembly. For Nordson
EFD electro-mechanical dispensers, slowly unscrew the barrel retainer and remove the barrel from the actuator.
3. Identify the reason for the malfunction and correct it before restarting the system.
Disposal
Dispose of equipment and materials used in operation and servicing according to local codes.
Nordson EFD Product Safety Statement (continued)
UltimusPlus Series Dispensers
10 www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Specifications
NOTE: Specifications and technical details are subject to change without prior notification.
Item Specification
Cabinet size 21.2Wx 10.8Hx 19.2Dcm (8.33Wx 4.27Hx 7.55D")
Weight 1.8 kg (4.0 lb)
Power adapter AC input: 100–240 VAC (+/-10%), ~50/60 Hz, 0.6 Amp
DC Output: 24 VDC @ 3.75 Amp
Internal voltage 24 VDC
Cycle rate Exceeds 600 cycles per minute
Time range 0.0001–9999 s
Accuracy: Within ±0.05% of the selected time setting
Repeatability: Less than 16 μs at any time setting
Foot pedal Voltage: 24 VDC
Current: 20 mA
End-of-cycle feedback circuits 24 VDC, 100 mA maximum
Cycle initiate Foot pedal, finger switch, 24 VDC signal, or mechanical contact closure
Input air pressure UltimusPlus I: 5.5–7.0 bar (80–100 psi)
UltimusPlus II: 1.7–2.4 bar (25–35 psi)
Air output UltimusPlus I: 0.7–7.0 bar (10–100 psi)
UltimusPlus II: 0–1.0 bar (0.3–15 psi)
Pressure readout accuracy UltimusPlus I: ±0.1 bar (2.0 psi)
UltimusPlus II: ±0.2 bar (0.3 psi)
Vacuum 0–1.3 inHG (0–18inH2O)
Vacuum readout accuracy ±0.15 inHG (±2.0 inH2O)
NOTE: The dispenser vacuum readout accuracy is calibrated from
0–0.88inHG (0–12inH2O).
Ambient operating conditions Temperature: 5–45° C (41–113° F)
Relative humidity (RH): 85% at 30° C (86° F), non-condensing
Height above sea level: 2,000 m maximum (6,562 ft)
Approvals CE, TUV, RoHS, WEEE, China RoHS
UltimusPlus Series Dispensers
11www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Operating Features
Air Out port
Item Description
Touchscreen
User interface for the UltimusPlus dispenser. Refer to “Overview of the UltimusPlus User
Interface” on page14 for details.
NOTE: No protective screen is available for the touchscreen. To prevent operators from
using the touchscreen with dirty hands or gloves, a mouse can connected to the USB port
on the back panel.
Air Out port
Air output tubing connection to provide regulated air pressure to the syringe barrel (an
additional Air Out port is provided on the back of the dispenser)
NOTE: Air does not flow through the port until tubing is connected.
Touchscreen
RoHS标准相关声明 (China RoHS Hazardous Material Declaration)
产品名称
Part Name
有害物质及元素
Toxic or Hazardous Substances and Elements
铅 
Lead
(Pb)
汞 
mercury
(Hg)
镉 
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr6)
多溴联苯
Polybrominated
Biphenyls
(PBB)
多溴联苯醚
Polybrominated
Diphenyl Ethers
(PBDE)
外部接口
External Electrical
Connectors
X00000
O:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准低于SJ/T11363-2006限定要求。
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is below
the limit requirement in SJ/T11363-2006.
X:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C
的标准高于SJ/T11363-2006限定要求.
Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is above
the limit requirement in SJ/T11363-2006.
WEEE Directive
This equipment is regulated by the European Union under WEEE Directive (2012/19/EU). Refer to
www.nordsonefd.com/WEEE for information about how to properly dispose of this equipment.
Specifications (continued)
UltimusPlus Series Dispensers
12 www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Power connection
Input / output
port
Power
switch
Foot pedal
port
Ethernet
port
Ground
connection
USB port
Air In port
(6 mm OD)
Air Out port
(6 mm OD)
Exhaust port
Operating Features (continued)
Item Description
USB port
USB port for (1) exporting or importing programs or (2) for exporting the dispense log. You
can also connect a mouse to this USB port to provide an alternative method for interacting
with the touchscreen.
Foot pedal port Connection for a foot pedal or optional finger switch to initiate the dispense cycle
Power switch Main power switch for the dispenser
Power input port
24 VDC power supply cord input connection. The UltimusPlus power pack automatically
adjusts for 100–240 VAC. Use only the supplied universal power pack. The unit is shipped
with four power plugs (one USA and three international plugs) and a 1.8 m (5.9 ft) power
cord.
Air In port
6 mm OD air input tubing connection from the factory air supply. Clean, dry, filtered factory
air is required to meet warranty. If your air supply is not filtered, order the 5-micron filter
regulator (P/N 7002002).
Air Out port
6 mm OD air output tubing connection to provide regulated air pressure to the syringe barrel
(an additional Air Out port is provided on the front of the dispenser)
NOTE: Air does not flow through the port until tubing is connected.
Exhaust (EXH) port
Pneumatic port for an optional exhaust connection. If needed, you can connect a
cleanroom filter muffler (P/N 7017049) to filter the output air to meet Fed 209-B (0.5 micron
particulates).
Ground Ground wire connection
I/O port Input / output port to allow the dispenser to interface with external control circuits. Refer to
“Input / Output Connections” on page54 for details.
Ethernet port
Ethernet port for a standard Ethernet cable. You can use an Ethernet cable to integrate the
dispenser into an automated dispensing system. Refer to “Connecting an Ethernet Cable for
Factory Integration” on page39 for details.
UltimusPlus Series Dispensers
13www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Overview of the UltimusPlus User Interface
When the dispenser is powered on, the Welcome screen appears
after about 45 seconds. Select the Home button to go to the Home
screen.
From the Home screen, you can access all dispenser functions.
Refer to “Operation” on page29 for programming and dispensing
procedures.
Navigation
Navigation icons
(present on all
screens)
Dispense time, pressure, and
vacuum settings for the currently
running program
Operating
information
Toggles to
enable or disable
MultiShot
operation, Steady
Mode, and and
Sleep Mode (Sleep
Mode is present
on UltimusPlus I
only)
Home screen
Dynamic action
bar
Home
Back
Program Library
(active program
number shown)
Settings
A yellow carrot indicates an associated
screen; refer to the flowchart on the next
page for the screen structure.
Back Export Program
Library Settings Unlocked
Backspace Home Reset Count Teach
Error Locked Saved Test
Icons
UltimusPlus Series Dispensers
14 www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Flowchart of Dispenser Screens
Overview of the UltimusPlus User Interface
(continued)
Home
Time Pressure Vacuum
Back Shot Count MultiShot On / Off
Home Run Limit Steady Mode On / Off
Programs System Count Sleep Mode On / Off
Settings Lock Reset Count Log Teach
Import / Export
Library
Export Library
Import Library
MultiShot
Pause Time
Count
Dispense Log
Export and Delete Log
Export and Keep Log
Locked / Unlocked
Enter Password
Settings
Company Info Software Update
Sleep Mode Ethernet
Language System Clock
Units of Measure Password
Program Edit
Time Pressure Vacuum
Barcode Run Limit
MultiShot Steady Mode
Program Library
Import / Export Library
Password
Enter Current
Password
Password
Enter New Password
Password
Re-Enter New
Password
Run Limit
Time VacuumPressure
Barcode
Assign Barcode
Delete Barcode
Time VacuumPressure Run Limit
Teach
Teach
Test Teach Time
Language
English German French
Spanish Chinese
Japanese Korean
Ethernet
Activate & Reboot
Software Update
Update
Units of Measure
psi bar kPa
inH2O inHG kPa
Company Info
System Clock
Year Month Day Time
AM PM 24 HR
Sleep Mode
(UltimusPlus I only)
5 10 60
MultiShot
Pause Time
Count
UltimusPlus Series Dispensers
15www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Overview of the UltimusPlus User Interface
(continued)
You can adjust any program by editing its settings, accomplished by pressing the name of the program in the
Program Library. The dispenser automatically renames an edited program based on the new settings, as shown
under “How the System Names Programs” below.
• For details on how to activate (or switch) programs, refer to “Activating a Program” on page30.
• For details on how to edit a program, refer to “Editing a Program” on page31.
How the System Names Programs
Barcode (present only if a
program is associated with a
barcode)
Dispense
Time setting
Pressure
setting
Vacuum
setting
Currently active
program number on
all screens
Home screen
Currently active program number
and program name on the
Program Details screen when the
currently active program is being
edited or viewed
Program Details screen (currently
active program being edited)
Program number and program
name on the Program Details screen
when the program being edited is
different from the currently active
program (press the gray P3 box to
make P3 the active program)
Program Details screen (program
being edited different from currently
active program)
About Programs
The dispenser includes 16 preprogrammed dispense programs in the Program Library.
On all screens, the active program number (P1 to P16) is displayed in a yellow box.
You can change the currently active program by pressing the program number in the
Program Library or by pressing the dark gray (inactive) program box on any screen.
UltimusPlus Series Dispensers
16 www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Overview of the UltimusPlus User Interface
(continued)
Dispense Modes
When powered on, the UltimusPlus dispenser opens to the last used program and dispense mode.
Dispense
Mode Typical Application Description or Comment
Steady
When you want to
dispense different
volume amounts for
each deposit
In STEADY mode, the system dispenses for as long as the dispense cycle
is initiated (either by foot pedal, finger switch, voltage initiate, or contact
closure). You can place the system in Steady mode on the Home screen.
Refer to “Setting Up the Dispenser for Steady Mode Operation” on page25
for details.
Timed
When you want
to dispense a set
amount of time for
each deposit
In TIMED mode, the system dispenses a single deposit for each dispense
cycle initiate (either by foot pedal, finger switch, voltage initiate, or contact
closure). Deposit size is based on the dispense time, pressure, and vacuum
settings shown on the touchscreen. Refer to “Setting Up the Dispenser for
Timed Mode Operation” on page25 for details.
Teach
When you want to
teach the system
the desired deposit
size
In TEACH mode, you can “teach” the system the desired deposit size
to determine the correct amount of time needed to achieve the deposit
size. Refer to “Using the Teach Mode to Set Up the Dispenser for Timed
Operation” on page26 for details.
Entering Values
For editable settings, the touchscreen functions as follows:
• If applicable, a numeric entry keypad opens.
• As you enter a value, the value-entry field turns yellow.
• If a value is outside of the acceptable range, a red box appears to identify the error.
• After a few seconds of no interaction, the entered value turns white and a check mark appears briefly, indicating
that the value is saved.
Set Time screen opened Set Time screen, value being entered Set Time screen, value saved (the
check mark appears briefly, then
disappears)
UltimusPlus Series Dispensers
17www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Ranges for All Editable Settings
For your reference, the following table lists all user-editable settings and their corresponding range of values.
Variable Range of Values Description or Comment
Time 0.0001–9999 (s) Sets the open time of the dispense cycle in
seconds
Pressure UltimusPlus I: 0.7–7.0 bar (10–100 psi)
UltimusPlus II: 0–1.0 bar (0.3–15 psi)
Sets the air pressure to the syringe barrel in psi
or bar
Vacuum 0.0–18.0 inH2O Sets the vacuum pressure in inches of water or
inches of mercury
MultiShot Pause Time: 0.0001–999.9 (s)
Count: 0–9999
For each cycle initiate (for example, one press of
the foot pedal), sets how many deposits (Count)
the system dispenses and how many seconds
elapse between deposits (Pause Time).
Run Limit None (0)–9999
Sets the maximum number of shots (cycle
initiates) for a program; when the Run Limit is
reached, the system stops responding to a cycle
initiate. Use Reset Count to reset the Shot Count
for a program to 0.
NOTE: In the MultiShot mode, each dispense
cycle is counted in the Run Limit.
Sleep Mode Enabled or disabled (toggle)
Time: 5, 10, 60 (min)
If Sleep Mode is enabled, sets the Time (in
minutes) to elapse after the last dispense before
the system enters the Sleep Mode
Language English, Chinese, French, German,
Japanese, Korean, Spanish Sets the language
Pressure Units psi, bar, kPa Sets how the system displays pressure units
Vacuum Units inH2O, inHG, kPa Sets how the system displays vacuum units
System Clock 12 hour, 24 hour Sets how the system displays time
Password 4 digit password Changes the password that locks and unlocks
the system
Overview of the UltimusPlus User Interface
(continued)
UltimusPlus Series Dispensers
18 www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Unpack the Unit / Warranty
Unpack the contents of the package and lay them out on a
clean work bench. The following items are included with your
UltimusPlus dispensing system:
a. Dispenser
b. Syringe barrel adapter with safety
clip
c. Syringe barrel stand
d. 2.4 m (8 ft) of 6 mm air supply
tubing and 1/4NPT fitting (not
shown)
e. Foot pedal assembly
f. Power supply and power cord
(Not shown)
• Dot standards sheet
1
Now is a good time to activate your
EFD UltimusPlus dispensing system
warranty. Register online at www.nordsonefd.com/
warranty/dispensers/five-limited.
Installation
2Connect Power
a. Connect the power plug to the power pack. The unit
is shipped with a USA-compatible plug and three
international plugs. Attach the correct plug to match
local power outlets.
b. Connect the power cord to the back of the UltimusPlus.
c. Connect the power cord to your local power source.
d. Connect a suitable ground wire to the ground
connection.
3Connect the Foot Pedal
• Plug the foot pedal into the back of the UltimusPlus.
NOTE: The UltimusPlus is normally operated using the supplied
foot pedal. You can also operate the UltimusPlus with an
optional finger switch, or, you can initiate dispense cycles
through the initiate terminals available on the I/Oport. Refer to
the following to connect dispense cycle initiate signals as an
alternative to a foot pedal or finger switch:
- “Voltage Initiate Circuit” on page54
- “Contact Closure Circuit” on page57
• (Optional) Connect other inputs / outputs as applicable for your
operation. Refer to “Input / Output Connections” on page54
for details and wiring diagrams.
a
b
c
e
d
f
2b
2d
UltimusPlus Series Dispensers
19www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.

Connect the Air Input
a. Install a pressure regulator that is capable of providing the air
supply recommended for the dispenser.
NOTE: Clean, dry filtered factory air is required to meet
warranty. If your air supply is not filtered, order the 5-micron
filter / regulator (P/N 7002002).
Bottled nitrogen can be used. If high pressure bottled air or
nitrogen is used, a high pressure regulator must be installed on
the bottle and set at 7 bar (100 psi) maximum. In this instance, the
5-micron filter regulator is not required.
WARNING
b. Push one end of the 6 mm air input hose into the AIR IN port
on the back of the UltimusPlus.
c. Connect the other end of the hose to the factory air supply.
d. Set the factory air supply as follows:
• UltimusPlus I: 5.5–7.0 bar (80–100 psi)
• UltimusPlus II: 1.7–2.4 bar (25–35 psi)
5
Installation (continued)
6 mm
(Optional) Connect a Mouse
Risk of equipment damage. Do not use the
touchscreen with dirty hands or gloves.
CAUTION
• If there is a risk of screen contamination, connect
a mouse to the USB port. The touchscreen can be
operated with the mouse.
4
PX
P
X
UltimusPlus Series Dispensers
20 www.nordsonefd.com [email protected] [phone] Sales and service of Nordson EFD dispensing systems are available worldwide.
