Nordson Tribomatic II Reference guide

TribomaticrII Extended Automatic
Powder Spray Gun
Customer Product Manual
Part 334691B03
Issued 7/06
NORDSON CORPORATION AMHERST, OHIO USA
For parts and technical support, call the Industrial Coating
Systems Customer Support Center at [phone] or
contact your local Nordson representative.
This document is subject to change without notice.
Check http://emanuals.nordson.com for the latest version.

Part 334691B03 E2006 Nordson Corporation
Table of Contents
Safety 1-1....................................
Introduction 1-1...............................
Qualified Personnel 1-1........................
Intended Use 1-1..............................
Regulations and Approvals 1-1..................
Personal Safety 1-2...........................
Fire Safety 1-2................................
Grounding 1-3................................
Action in the Event of a Malfunction 1-3..........
Disposal 1-3..................................
Description 2-1...............................
Introduction 2-1...............................
Operation 2-2.................................
Options 2-2...................................
Material Descriptions 2-2.......................
Installation 3-1................................
Mounting 3-1.................................
Feed Hose, Air Tubing, and
Ground Wire Connections 3-2...................
Installing Nozzles on Sprayheads 3-4.............
Operation 4-1.................................
Introduction 4-1................................
Operation 4-1.................................
Daily Maintenance 4-2..........................
Troubleshooting 5-1..........................
Repair 6-1....................................
Service Kits 6-1................................
Charge Module Cutaway Drawing 6-2............
Prepare for Disassembly 6-3....................
Charge Module Service Kit Installation 6-4........
Inner/Outer Wear Sleeve Service Kit Installation 6-7
Parts 7-1.....................................
Introduction 7-1...............................
Using the Illustrated Parts List 7-1............
Spray Gun 7-2................................
Diffuser Parts List 7-4..........................
Inner/Outer Wear Sleeve Service Kit 7-5..........
Positioning and Spacing Ring Service Kit 7-5......
Charge Module Service Kit 7-6..................
Gun Holder Kits 7-8...........................
Options 7-9...................................
Powder Feed Hose and Air Tubing 7-9.........
Lance Extensions 7-10.......................
Gun Holder Adapter Conversion Kit 7-11........
Miscellaneous Options 7-11...................
Versa-Spray Nozzles 7-11.....................
Contact Us
Nordson Corporation welcomes requests for information, comments, and
inquiries about its products. General information about Nordson can be
found on the Internet using the following address:
http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
555 Jackson Street
Amherst, OH 44001
Notice
This is a Nordson Corporation publication which is protected by copyright.
Original copyright date 2000. No part of this document may be
photocopied, reproduced, or translated to another language without the
prior written consent of Nordson Corporation. The information contained
in this publication is subject to change without notice.
Trademarks
Nordson, the Nordson logo, and Tribomatic are registered trademarks of
Nordson Corporation.
Tivar is a registered trademark of Poly-Hi Corporation.

Safety 1-1
Part 334691B03
E2006 Nordson Corporation
Section 1
Safety
Introduction
Read and follow these safety instructions. Task- and equipment-specific
warnings, cautions, and instructions are included in equipment
documentation where appropriate.
Make sure all equipment documentation, including these instructions, is
accessible to all persons operating or servicing equipment.
Qualified Personnel
Equipment owners are responsible for making sure that Nordson equipment
is installed, operated, and serviced by qualified personnel. Qualified
personnel are those employees or contractors who are trained to safely
perform their assigned tasks. They are familiar with all relevant safety rules
and regulations and are physically capable of performing their assigned
tasks.
Intended Use
Use of Nordson equipment in ways other than those described in the
documentation supplied with the equipment may result in injury to persons
or damage to property.
Some examples of unintended use of equipment include
Susing incompatible materials
Smaking unauthorized modifications
Sremoving or bypassing safety guards or interlocks
Susing incompatible or damaged parts
Susing unapproved auxiliary equipment
Soperating equipment in excess of maximum ratings
Regulations and Approvals
Make sure all equipment is rated and approved for the environment in which
it is used. Any approvals obtained for Nordson equipment will be voided if
instructions for installation, operation, and service are not followed.
All phases of equipment installation must comply with all federal, state, and
local codes.

Safety
1-2
Part 334691B03 E2006 Nordson Corporation
Personal Safety
To prevent injury follow these instructions.
SDo not operate or service equipment unless you are qualified.
SDo not operate equipment unless safety guards, doors, or covers are
intact and automatic interlocks are operating properly. Do not bypass or
disarm any safety devices.
SKeep clear of moving equipment. Before adjusting or servicing any
moving equipment, shut off the power supply and wait until the
equipment comes to a complete stop. Lock out power and secure the
equipment to prevent unexpected movement.
SRelieve (bleed off) hydraulic and pneumatic pressure before adjusting or
servicing pressurized systems or components. Disconnect, lock out,
and tag switches before servicing electrical equipment.
SObtain and read Material Safety Data Sheets (MSDS) for all materials
used. Follow the manufacturer’s instructions for safe handling and use
of materials, and use recommended personal protection devices.
STo prevent injury, be aware of less-obvious dangers in the workplace
that often cannot be completely eliminated, such as hot surfaces, sharp
edges, energized electrical circuits, and moving parts that cannot be
enclosed or otherwise guarded for practical reasons.
Fire Safety
To avoid a fire or explosion, follow these instructions.
SDo not smoke, weld, grind, or use open flames where flammable
materials are being used or stored.
SProvide adequate ventilation to prevent dangerous concentrations of
volatile materials or vapors. Refer to local codes or your material MSDS
for guidance.
SDo not disconnect live electrical circuits while working with flammable
materials. Shut off power at a disconnect switch first to prevent
sparking.
SKnow where emergency stop buttons, shutoff valves, and fire
extinguishers are located. If a fire starts in a spray booth, immediately
shut off the spray system and exhaust fans.
SClean, maintain, test, and repair equipment according to the instructions
in your equipment documentation.
SUse only replacement parts that are designed for use with original
equipment. Contact your Nordson representative for parts information
and advice.

Safety 1-3
Part 334691B03
E2006 Nordson Corporation
Grounding
WARNING: Operating faulty electrostatic equipment is hazardous and can
cause electrocution, fire, or explosion. Make resistance checks part of your
periodic maintenance program. If you receive even a slight electrical shock
or notice static sparking or arcing, shut down all electrical or electrostatic
equipment immediately. Do not restart the equipment until the problem has
been identified and corrected.
All work conducted inside the spray booth or within 1 m (3 ft) of booth
openings is considered within a Class 2, Division 1 or 2 Hazardous location
and must comply with NFPA 33, NFPA 70 (NEC articles 500, 502, and 516),
and NFPA 77, latest conditions.
SAll electrically conductive objects in the spray areas shall be electrically
connected to ground with a resistance of not more than 1 megohm as
measured with an instrument that applies at least 500 volts to the circuit
being evaluated.
SEquipment to be grounded includes, but is not limited to, the floor of the
spray area, operator platforms, hoppers, photoeye supports, and
blow-off nozzles. Personnel working in the spray area must be
grounded.
SThere is a possible ignition potential from the charged human body.
Personnel standing on a painted surface, such as an operator platform,
or wearing non-conductive shoes, are not grounded. Personnel must
wear shoes with conductive soles or use a ground strap to maintain a
connection to ground when working with or around electrostatic
equipment.
SOperators must maintain skin-to-handle contact between their hand and
the gun handle to prevent shocks while operating manual electrostatic
spray guns. If gloves must be worn, cut away the palm or fingers, wear
electrically conductive gloves, or wear a grounding strap connected to
the gun handle or other true earth ground.
SShut off electrostatic power supplies and ground gun electrodes before
making adjustments or cleaning powder spray guns.
SConnect all disconnected equipment, ground cables, and wires after
servicing equipment.
Action in the Event of a Malfunction
If a system or any equipment in a system malfunctions, shut off the system
immediately and perform the following steps:
SDisconnect and lock out electrical power. Close pneumatic shutoff
valves and relieve pressures.
SIdentify the reason for the malfunction and correct it before restarting the
equipment.
Disposal
Dispose of equipment and materials used in operation and servicing
according to local codes.

Safety
1-4
Part 334691B03 E2006 Nordson Corporation

Description 2-1
Part 334691B03
E2006 Nordson Corporation
Section 2
Description
Introduction
The Nordson extended Tribomatic II automatic powder spray gun uses
friction (the tribo effect) to electrostatically charge powder coating particles
as compressed air forces them through the spray gun. The spray gun is
used with a Tribomatic II controller and powder pump.
See Figure 2-1. The spray gun consists of a diffuser (1), extension (2),
charge module (3), and various optional sprayheads (4). The standard
spray gun has a PTFE charge module for use with organic powder coatings.
The spray gun mounts to a reciprocator or oscillator, or to a fixed gun stand.
An optional gun holder adapter allows existing Tribomatic gun holders to be
used with gun mounting bars.
The spray gun uses the same wide variety of optional nozzles and
sprayheads available for use with the original Tribomatic automatic powder
spray gun. Options are listed in Table 2-1.
Table 2-2 lists the characteristics of the PTFE and Tivar materials used in
the Tribomatic II powder spray guns. Use this table to identify the materials
used in your spray gun.
1400342A
1
3
4
2
Figure 2-1 Extended Tribomatic II Automatic Gun
1. Diffuser
2. Extension
3. Charge module 4. Sprayhead

Description
2-2
Part 334691B03 E2006 Nordson Corporation
Operation
Flow rate air pumps powder out of the feed hopper and forces it through the
feed hose to the diffuser. Diffuser air mixes with the powder and increases
its speed. The powder and air mixture then passes between the inner and
outer wear sleeves inside the charge module. The collision of the powder
particles with the walls of the wear sleeves electrostatically charges both the
powder particles and the wear sleeves.
The wear sleeves are grounded through the gun body, ground wire, and
control unit. The charge picked up by the sleeves is displayed in
microamperes at the control unit. The display indicates how well the
powder is charging. The higher the number, the stronger the charge the
powder is receiving. The strength of the charge the powder receives will
vary depending on many factors, including the powder type and its speed
through the spray gun.
Options
Table 2-1 lists the options are available for the extended Tribomatic II
automatic powder spray gun. Unless otherwise noted, refer to Options on
page 7-9 in the Parts section for part numbers and ordering information.
Table 2-1 Options
Option Description
Tribomatic sprayheads and nozzles Available in PTFE. Connect directly to the charge module. Refer
to the Tribomatic Optional Sprayheads and Nozzles instruction
sheet for more information.
Gun mounting bar Use to mount an automatic gun on a 25.4-mm (1-in.) round or
square fixed gun stand or gun mover arm.
Gun holder adapter Allows old-style Tribomatic gun holders to be used with gun
mounting bars and the Tribomatic II automatic gun.
Lance extensions Use to spray powder into recesses. Available in 100-, 150-, or
300-mm lengths.
Deflectors for lance extensions Available in Tivar, with and without holes.
Versa-Spray nozzles Must be used with one of the optional lance extensions
described above. Refer the Optional Nozzles for Versa-Spray
and Versa-Spray II Guns instruction sheet for more information.
Powder feed hose, air tubing,
spiral-cut tubing, and hose clamps
Available in both metric and English ID and OD sizes and in bulk
lengths.
Material Descriptions
Table 2-2 describes the two types of plastics used in the Tribomatic II
powder spray guns and the powder compatible with each type. Use this
table to determine which type of plastic is used in your spray gun.
Table 2-2 Material Description and Usage
Material Appearance Usage
PTFE Opaque white Standard material for inlet and outlet distributors and wear
sleeves in automatic spray guns. Shorter wear-life than Tivar,
but reduces or eliminates impact-fusion.
Tivar Grayish, translucent
white
Longer wear-life than PTFE, but some powders may
impact-fuse to Tivar. Switch to PTFE if impact-fusion is a
problem.

Installation 3-1
Part 334691B03
E2006 Nordson Corporation
Section 3
Installation
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
Mounting
1. See Figure 3-1. Install the gun mount (2) on a fixed gun stand or gun
mover arm (1).
2. Tighten the gun mount adjuster (3).
3. Loosen the gun holder adjuster (5) and slide the spray gun through the
gun holder (4). Tighten the adjuster.
4. Loosen the gun mount adjuster and position the spray gun. Tighten the
adjuster.
5. Rotate the spray gun to the desired position, then tighten the gun mount
adjuster (6).
1400343A
3
2
1
45
6
Figure 3-1 Mounting the Tribomatic II Extended Automatic Powder Spray Gun
1. Fixed gun stand or gun mover arm
2. Gun mount
3. Gun mount adjuster
4. Gun holder
5. Gun holder adjuster
6. Gun mount adjuster

Installation
3-2
Part 334691B03 E2006 Nordson Corporation
Feed Hose, Air Tubing, and Ground Wire Connections
CAUTION: Do not overtighten threaded parts. Overtightening threaded
parts will strip the threads.
1. See Figure 3-2. Install the diffuser (1) onto the threaded connector at
the end of the extension (3). Hand tighten the diffuser lock nut.
2. Install 6-mm blue air tubing (8) between the diffuser and the control unit
and install 6-mm black flow rate air tubing between the control unit and
the powder pump.
3. Connect powder feed hose (7) to the barbed diffuser fitting, route the
hose to the powder pump, and connect it to the pump outlet connector.
Use snap clamps to secure the hose to the diffuser and pump adapters.
Wrap spiral-cut tubing around the hose where necessary to prevent it
from kinking and cutting off the flow of powder.
4. Connect a ground wire (6) to the ground stud (2). Tighten the knurled
knob to secure the wire.
5. Route the ground wire to the control unit and connect it to the gun
ground terminal in the rear panel.
1400344
A
5
8
7
6
2
4
1
3
Figure 3-2 Connecting Feed Hose, Air Tubing, and Ground Wire
1. Diffuser
2. Ground Stud
3. Extension
4. Charge module body
5. Sprayhead
6. Ground wire
7. Powder feed hose
8. 6-mm Blue air tubing

Installation 3-3
Part 334691B03
E2006 Nordson Corporation
NOTE: The cone is only used with the original Tribomatic gun.
6. See Figure 3-3. Before installing a sprayhead on the gun, remove the
nozzle cone (1) from the interior of the sprayhead base (2) with a pair of
pliers.
7. See Figure 3-2. Install the sprayhead (5) on the end of the charge
module body (4) with a twisting motion. Tighten the set screws around
the circumference of the charge module body to secure the sprayhead.
8. Adjust the spray gun-to-workpiece distance and position.
1400406A
1
2
Figure 3-3 Removing the Nozzle Cone
1. Nozzle cone 2. Sprayhead base

Installation
3-4
Part 334691B03 E2006 Nordson Corporation
Installing Nozzles on Sprayheads
Figure 3-4 illustrates the various ways in which the nozzles can be installed.
Item Nozzle Installation
1 Cylindrical Install on sprayhead tubing ends or on threaded or angled
nozzles. The eight-orifice nozzle must be installed on a
cylindrical nozzle. Cylindrical nozzles are also used as
connectors.
2 Flat
3 Pinpoint
4 Eight-Orifice
5 Threaded Use to modify standard sprayheads. They are threaded on one
end to screw into the sprayhead base.
6 Angled Install on existing sprayhead nozzles, using cylindrical nozzles
as connectors. These nozzles are not threaded.
1400407A
1
2
3
5
61
2
3
4
1
3
2
4
1
1
To sprayhead base
1
To existing sprayhead tube ends
or threaded or angled nozzles
6
6
1
To existing sprayhead tube ends
or threaded or angled nozzles
Figure 3-4 Installing Nozzles on Sprayheads
1. Cylindrical nozzles
2. Flat nozzles
3. Pinpoint nozzles
4. Eight-orifice nozzles
5. Threaded nozzles
6. Angled nozzles without
threads

Operation 4-1
Part 334691B03
E2006 Nordson Corporation
Section 4
Operation
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
WARNING: All electrically conductive equipment in the spray area must be
grounded. Ungrounded or poorly grounded equipment can store an
electrostatic charge which can give personnel a severe shock or arc and
cause a fire or explosion.
WARNING: Make sure the spray gun is grounded before spraying powder
or cleaning the spray gun with compressed air. Without a ground
connection the spray gun will become electrostatically charged. Personnel
touching the spray gun could receive a shock.
Introduction
Each automatic powder spray gun is controlled by one gun control unit
which houses electrical controls, a digital display, and regulators and
gauges for flow rate and diffuser air. Refer to the control unit manual for
operation instructions.
Operation
Powder volume, velocity, and atomization are controlled by the flow rate and
diffuser air pressure settings. As a starting point, set air pressures to
Flow rate (ejector) air pressure 1.8 bar (26 psi)
Diffuser (atomizing) air pressure 2.5 bar (36 psi)
Keep the flow rate air pressure as low as possible. Maintain the same ratio
of diffuser air-to-flow rate air without reducing the charging level. Reduce
the diffuser air pressure if powder is being blown out of recesses. Build
coating thicknesses slowly. Reduce air pressures to keep overspray to a
minimum.
Experiment with the part hanger configuration and part density. Reduce the
space between parts to keep overspray to a minimum. Keep the air velocity
through the booth as close to the minimum required by law as practical
without violating safety.

Operation
4-2
Part 334691B03 E2006 Nordson Corporation
Operation (contd)
Use different sprayheads for different part shapes. Select the appropriate
nozzle for the parts being coated:
SPinpoint nozzles for penetration
SEight-orifice nozzles for flat surfaces
SCylindrical nozzles for general purpose coating
Angle the nozzles to meet and follow the parts as they move through the
booth. Typical nozzle-to-part distance is 20−25 cm (8−10 in.). Coat the
inside surfaces and recessed areas first, then coat the outside surfaces and
open areas.
Daily Maintenance
WARNING: Make sure the spray gun is grounded before spraying powder
or cleaning the spray gun with compressed air. Without a ground
connection the spray gun will become electrostatically charged. Personnel
touching the spray gun could receive a shock.
1. Remove the powder feed hose from the pump and the air tubing from
the pump and diffuser. Use an OSHA-approved air gun to clean the
hose, diffuser, and charge module with compressed air.
NOTE: Never blow powder through the feed hose back into the pump.
Turn on the booth exhaust fan, disconnect the hose from the pump, and
blow out the hose from the pump end into the booth.
2. Remove the diffuser from the extension. Disassemble the diffuser and
clean the parts with compressed air and a clean, soft cloth. Check the
powder contact parts for wear and replace worn parts.
3. Remove the rear connector and blow out the gun body.
4. Blow out the extension, charge module, and sprayhead.
5. Disassemble and clean the charge module. Check the powder contact
parts for wear and replace worn parts.
NOTE: Never use a knife or other sharp object to clean plastic parts.
Powder will build up on scratches on the powder contact surfaces. The
powder particles can fuse on impact and clog the spray gun.
WARNING: All electrically conductive equipment in the spray area must be
grounded. Ungrounded or poorly grounded equipment can store an
electrostatic charge which can give personnel a severe shock or arc and
cause a fire or explosion.
6. Make sure all conductive equipment in the spray area, including the
spray guns, are connected to a true earth ground. The resistance from
part to ground, through the hangers and conveyor, must not exceed
one megohm. For best results, the resistance should be less than
500 ohms.

Troubleshooting 5-1
Part 334691B03
E2006 Nordson Corporation
Section 5
Troubleshooting
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
This section contains troubleshooting procedures. These procedures cover
only the most common problems that you may encounter. If you cannot
solve the problem with the information given here, contact your local
Nordson representative for help.
Problem Possible Cause Corrective Action
1. Powder does not flow
when control unit
turned on
No supply air or pressure set too
low
Make sure the control unit is getting
air. Check the supply air pressure.
Blockage in system Shut down and clean the system
starting with the pump. Check the air
dryer for proper operation. Drain the
air filters and inspect the filter
elements. Make sure the powder
supply in the feed hopper is dry.
Powder is not fluidized in hopper Increase the air pressure to the
hopper.
Control unit malfunction; solenoid
valve is not opening
Repair or replace the control unit.
Flow rate (ejector) air pressure too
low
Increase the flow rate air pressure.
2. Powder puffing from
spray gun
Blockage in system Shut down the system. Clean the
system starting with the pump.
Pump venturi throat worn out Change the venturi throat.
Diffuser (atomizing) air pressure
too high or incorrect ratio of
diffuser to flow rate air pressure
Decrease the diffuser air pressure or
increase the flow rate air pressure.
Powder feed hose ID too large or
hose too short
Change to a smaller ID hose or
change the hose length. Best results
are obtained when a hose is 4−6 m
(13−20 ft) long.
Continued...

Troubleshooting
5-2
Part 334691B03 E2006 Nordson Corporation
Problem Possible Cause Corrective Action
3. Poor powder
charging—no
electrostatic wrap or
adhesion
Flow rate air pressure too high or
diffuser air pressure too low
Decrease the flow rate air pressure or
increase the diffuser air pressure.
Parts not properly grounded Check the conveyor and hangers with
a standard ohmmeter for coating
buildup that could affect the ground.
Resistance between the parts and the
ground must not exceed
one megohm. For best results,
resistance should not exceed
500 ohms.
Too much moisture in compressed
air supply
Check the air dryer for proper
operation. Use a refrigerated or
regenerative desiccant air dryer that
can produce a 3.4 _C (38 _F) or
lower dew point at 7 bar (100 psi).
Drain the air filter and check the filter
element.
Inner and outer wear sleeves worn Disassemble the spray gun. Reverse
the inner and outer wear sleeves
(turn end-for-end). Replace the
sleeves if necessary.
Too many fine particles in powder
supply
Replace the powder supply with virgin
powder. Consult with the powder
manufacturer.
Powder not suitable for
tribo-charging
Consult with the powder
manufacturer.
4. Inadequate powder
flow
Flow rate air pressure too low Increase the flow rate air pressure.
Wet powder clogging system Check the air filters, dryer, and
powder supply. Service the filters
and/or the dryer and change the
powder supply.

Repair 6-1
Part 334691B03
E2006 Nordson Corporation
Section 6
Repair
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
Service Kits
See Figure 6-1. Two main service kits are available for the extended
Tribomatic II automatic powder spray gun:
Item Service Kit Kit Contents
ACharge module Parts included in the wear sleeve replacement kit, plus the
inlet and outlet wear sleeves and distributors. Refer to
page 7-6 in the Parts section.
BWear sleeve Parts subject to the most wear: inner and outer wear sleeves,
spacing ring, and positioning ring. Refer to page 7-5 in the
Parts section.
1400347A
AB
Figure 6-1 Service Kits
A. Charge module service kit B. Wear sleeve service kit

Repair
6-2
Part 334691B03 E2006 Nordson Corporation
Charge Module Cutaway Drawing
The cutaway drawing below shows how the parts of the charge module fit
together. Refer to this drawing when assembling the charge module.
NOTE: The numeric callouts in this section match the item numbers in the
spray gun’s main parts list. Refer to the Parts section for a complete parts
list and ordering information.
1400348A
3
9
19
11
1
514
20
12
6
1317
15
21
Figure 6-2 Charge Module Cutaway Drawing
1. Outlet wear sleeve assembly1
3. Spring
5. Spacing ring1,2
6. Outer wear sleeve1,2
9. Outlet distributor plug
11. Outlet distributor1
12. Inner wear sleeve1,2
13. Positioning ring1,2
14. Stud1
15. Inlet distributor1
17. Inlet wear sleeve1
19. Set screws
20. Extension tube
21. Body
Note: 1—Provided with charge module service kit.
Note: 2—Provided with wear sleeve service kit.

Repair 6-3
Part 334691B03
E2006 Nordson Corporation
Prepare for Disassembly
WARNING: Use ground straps to avoid shock during cleaning.
1. Shut off the flow rate and diffuser air.
2. Disconnect the powder feed hose from the pump and the diffuser air
tubing from the diffuser.
3. Leave the ground wire attached to the spray gun. Make sure the booth
exhaust fan is operating.
NOTE: The charge module remains assembled during step 4.
4. Blow through the feed tubing into the diffuser, extension, and charge
module.
5. Remove the diffuser from the gun extension and blow out the extension.
6. Remove the charge module and blow out the wear sleeves and
extension tube.
7. Remove the sprayhead.

Repair
6-4
Part 334691B03 E2006 Nordson Corporation
Charge Module Service Kit Installation
1. See Figure 6-3. Unscrew the extension tube (20) from the gun
extension (25). Pull the extension tube out of the gun extension, and
slide it off the inner/outer wear sleeve assembly (A). The outlet wear
sleeve assembly (1) will remain inside the extension tube.
2. Pull the inner/outer wear sleeve assembly from the gun extension. The
inlet wear sleeve assembly will stay in the gun extension.
1400349A
25
A
20
32
1
Figure 6-3 Installing the Charge Module Service Kit—Steps 1 and 2
1. Outlet wear sleeve assembly
20. Extension tube
25. Gun extension
32. Rear connector
A. Inner/outer wear sleeve
assembly
