OBSOLETE
21-37
Issued 7/96 1
Nordson Corporation
OPERATOR’S CARD
P/N 108 885B
Model WM-1 Manual Waterborne Air Spray Gun
Safety
The following symbols warn against dangers or
possible sources of danger. Become familiar with
them! Failure to heed a warning symbol could lead to
personal injury and/or damage to the unit or other
equipment.
Heed all warning symbols that appear in this
document, the operator’s manual, or on the
equipment.
WARNING: Allow only qualified personnel to
perform the following tasks. Observe and
follow the safety instructions in this document
and all other related documentation.
WARNING: Risk of electrical shock. Spray
gun operation requires the use of a grounding
air hose and a high-dielectric strength fluid
tube. Failure to observe this warning may
result in personal injury, death, or equipment
damage.
WARNING: System or material pressurized.
Relieve pressure. Failure to observe may
result in serious burns.
WARNING: Ignition hazard. Do not use this
handgun to spray coating materials having a
fire point below 60 _C (140 _F). Failure to
observe this warning may result in serious
injury and equipment damage.
CAUTION: Use only clean dry air. Failure to
observe this caution may reduce electrostatic
efficiency and cause equipment damage.
WARNING: Wear protective clothing, safety
goggles, and approved respiratory protection.
Failure to observe may result in serious injury.
CAUTION: Do not over tighten parts. Failure
to observe this caution may result in equipment
damage.
SAlways follow instructions in the material supplier’s
Material Safety Data Sheet (MSDS) or material
information sheet.
Introduction
This operator’s card contains only the information
necessary for installation, daily operation and
maintenance. For other information, refer to the
manual.
The WM-1 spray gun operates with an Iso-Flo HD
Voltage Block unit (Iso-Flo). Each installation must
meet the following requirements:
SThe system, including the electrostatic power
supply, must be installed properly and in good
working condition.

OBSOLETE
21-37 Issued 7/96
2
Introduction (contd.)
The WM-1 spray gun air line must be attached to
earth ground. NOTE: Numbers in parenthesis throughout this
operator’s card correspond to the numbers on
Figure 1.
2137001B
1
25
3 4
6
7
8
10
9
11
12
13
15
14
16
17
18
19 20
Fig. 1 WM-1 spray gun installation
1. Retaining ring
2. Cap
3. Nozzle
4. Valve seat
5. Extension
6. Captive screw
7. Thumb wheel (air adjustment)
8. Rear slide
9. Dielectric grease application
10. Fluid hose
11. Grounding air hose
12. Grounding air hose connector
13. Fitting
14. Trigger lock
15. Trigger
16. Screw
17. Captive screw
18. Fluid tip
19. Air cap
20. Hose strain relief lug

OBSOLETE
21-37
Issued 7/96 3
Daily Operation
Delivery System Start-Up
1. Perform the necessary tasks to start-up the Iso-Flo
HD unit.
2. Check all fluid and air lines for leaks.
Setting Flow Rate
WARNING: Risk of electrical shock. Make
sure that the electrostatic power unit is turned
off and the fluid supply is properly grounded.
Failure to observe this warning may result in
personal injury, death, or equipment damage.
1. Turn off air supply.
2. Slide the trigger lock (14) all the way down.
3. Perform the tasks necessary to set fluid pressure
in the fluid delivery system. Use the lowest fluid
pressure possible to obtain a satisfactory flow rate
of your coating material.
4. Fully trigger the WM-1 spray gun into a graduated
container. Use a stop watch to establish the time
needed to collect the desired amount of fluid.
5. Repeat steps 3 and 4 until the desired flow rate
per minute is obtained.
Preparing to Spray
1. Turn on air supply.
2. Perform the tasks necessary to set the supply air
pressure to the WM-1 spray gun. Use the lowest
air pressure possible to obtain satisfactory
atomization of your coating material.
3. Fully trigger the WM-1 spray gun.
4. Turn the thumb wheel (7) to achieve your desired
spray pattern.
5. Repeat steps 2, 3, and 4 until the desired spray
pattern and atomization is obtained. If necessary,
adjust the Iso-Flo HD unit fluid and air pressure.
6. Cover the exterior of the WM-1 spray gun with a
Nordson spray gun cover.
7. Turn on the electrostatic power supply.
8. The system is now operational.

OBSOLETE
21-37 Issued 7/96
4
Maintenance
2137003A
1. Relieve the air and fluid pressure. Turn the
electrostatic unit off. 2. Trigger the WM-1 spray gun into a grounded metal container to drain the fluid tube.
2137005A
3. Point the WM-1 spray gun downward and
remove the retaining ring, air cap, and fluid
tip.
2137006A
4. Adjust the solvent supply to the lowest
possible pressure.
2137005A
5. Flush the WM-1 spray gun into a grounded
metal container until clean. 6. Turn off the solvent supply and relieve pressure.
2137008A
2137004A

OBSOLETE
21-37
Issued 7/96 5
Maintenance (contd.)
2137009A
7. Point the gun downward and clean the
front with a soft brush dampened with a
compatible cleaning solvent.
2137010A
8. Dampen a soft cloth with a compatible
cleaning solvent. Point the gun downward
and wipe off the outer surfaces.
2137011A
9. Clean the retaining ring, air cap, and fluid
tip with a soft brush, then dry.
2137012A
10. Trigger the WM-1 spray gun. Insert the
fluid tip into the gun. Place the air cap on
the fluid tip. Install the retaining ring and
tighten securely.
2137013A
11. Hang up the WM-1 spray gun.
2137014A
Do not point the gun
upward while cleaning. Do not submerge the gun in solvent.
Do not use excessive
solvent on cleaning cloth. Do not use metal tools to clean the air cap.

OBSOLETE
21-37 Issued 7/96
6
Connections and Controls
Table 1 describes each input and control of the WM-1 spray gun. Numbers in the Connections and Controls
column correspond to the numbers on Figure 1.
Table 1 Connections and Controls
Connections and Controls Functions
7. Thumb wheel (pattern/horn) Varies the pattern/horn air flow of the spray gun
NOTE: Turning the thumb wheel downward increases the flatness of the spray
pattern on a standard nozzle or narrows the cone pattern on a conical nozzle. Both
increase atomization.
13.Fitting Attaches a grounding air hose to the WM-1 spray gun
14.Trigger lock Prevents trigger movement
NOTE: Sliding the trigger stop all the way up prevents trigger movement. Sliding the
trigger stop all the way down enables trigger movement.
15.Trigger Controls coating material flow from the WM-1 spray gun
NOTE: Always draw the trigger fully during WM-1 spray gun operation.
Installation
Standard Nozzle Installation
1.Trigger the WM-1 spray gun. Thread the fluid tip
into the extension(5). Use the Nordson supplied
wrench to secure the fluid tip.
2.Place the air cap (19) on the fluid tip (18) and the
retaining ring (1) over the air cap. Position the air
cap and hand-tighten the retaining ring onto the
extension (5).
Conical Nozzle Installation
1.Trigger the WM-1 spray gun. Thread the valve
seat (4) into the extension (5). Use an open-end
wrench to secure the valve seat.
2.Set the nozzle (3) on the valve seat. Place the
cap (2) over the nozzle. Hand-tighten the retaining
ring (1) onto the extension (5).
Hose Connections
Perform these steps if you ordered the WM-1 spray
gun with hoses, part 176 526:
1.Route and connect the fluid hose (10) to your
Iso-Flo HD unit.
2.Route and connect the grounding air hose (11) to
the air supply regulator.

OBSOLETE
21-37
Issued 7/96 7
Installation (contd.)
Hose Connections (contd.)
Perform these steps if you ordered the WM-1 spray
gun without hoses, part 176 501:
1. Loosen the captive screw (6) securing the rear
slide (8). Remove the rear slide.
2. Remove the screws (16) securing the trigger (15).
3. Loosen the captive screws (17) securing the
extension (5).
4. Carefully insert the fluid hose (10) through the gun
body. Apply a thin film of dielectric grease (9) onto
the fluid hose (10) as illustrated.
5. Insert the fluid hose (10) into the extension (5).
6. Tighten the captive screws (17) to secure the
extension (5).
7. Install the trigger (15) and secure using the
screw (16).
8. Insert the fluid hose strain relief lug (20) into the
pocket in the gun handle.
9. Install the rear slide (8) and tighten the captive
screw (6).
10. Connect the grounding air hose (11) to the
fitting (13).
Service Kits and Accessories
Service kits and accessories available from Nordson
are listed here.
Table 2 Service Kits and Accessories
Part Service Kits and Accessories
176 538 Packing cartridge assembly service kit
176 542 Air valve service kit
176 541 Fluid needle service kit
176 550 Air seal service kit
176 545 Fluid seal service kit
176 546 Air hose
176 539 Fluid hose
227 583 Bag, cover, qty 1
227 584 Bag, cover, qty 12
Specifications
Weight
400 grams (14 oz)
NOTE: Weight includes fluid tip, air cap, and retaining
ring.
Air Operating Capacity (at the spray gun)
Maximum working pressure: 7 bar (100 psi)
Average operating pressure
range: 1.70–2.8 bar
(25–40 psi)
Quality of the Air: Particulate free, 5
microns maximum
Fluid Operating Capacity (at the spray gun)
Maximum working pressure: 5.17 bar (75 psi)
Average operating pressure
range: .68–1.70 bar
(10–25 psi)
Maximum temperature: (49 C) 120 F
Flow rate (Zahn 2 cup): up to 20 oz./min. at
20 sec.
Nordson Technical Service Help
For technical assistance within the United States,
contact your local Nordson distributor or call Nordson
Technical Service at 1-800-275-6357. For assistance
outside the United States, call your local Nordson
representative.

OBSOLETE
21-37 Issued 7/96
8
Troubleshooting
Figure 2 shows some common spray pattern faults.
Troubleshooting procedures for these and other
common film-build faults are listed in Table 3. If you
cannot solve your problem with the information given
here, contact your local Nordson representative or
distributor for help.
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎÎ
ÎÎÎÎ
ÎÎÎÎ
ÎÎÎÎ
ÎÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
ÎÎ
12345 76
2137002A
Fig. 2 Common spray pattern fault
1. Blown pattern
2. Heavy bottom pattern
3. Heavy top pattern
4. Heavy left side pattern
5. Heavy right side pattern 6. Heavy center pattern 7. Spitting pattern
Table 3 Troubleshooting Procedures
Spray Pattern/
Film Faults Corrective Action
Blown pattern Reduce pattern/horn air; increase coating material pressure.
Heavy top or
Heavy bottom Rotate air cap and trigger spray gun; if problem exists, clean air cap; if problem does not exist, clean fluid tip or replace air cap; change coating material mixture, if necessary.
Heavy left side or
Heavy right side Rotate air cap and trigger spray gun; if problem exists, clean air cap; if problem does not exist, clean fluid tip or replace air cap; change coating material mixture, if necessary.
Heavy center Increase atomizing air, increase pattern/horn air, or reduce coating material viscosity.
Spitting Purge air bubbles in fluid line; adjust puller; raise atomizing air and reduce fluid pressure;
increase pattern/horn air; raise coating material temperature.
Runs and sags Purge air bubbles in fluid line; adjust puller; raise atomizing air and reduce fluid pressure;
move farther from substrate, increase pattern/horn air; raise coating material temperature.
Dry spray Reduce atomizing air; reduce pattern air; change coating material mixture.
Poor or no wrap Check electrostatic power supply; clean spray gun; remove water from supply air; check
substrate ground; check spray gun for internal leakage.
Poor coverage in
recesses Raise atomizing air and coating material pressure; reduce electrostatic power supply voltage; move closer to substrate.
1996 Nordson Corporation
Nordson, the Nordson logo and Iso-Flo are registered trademarks of Nordson Corporation.
