Nordson Fulfill User manual
Fulfill)Retrofit Kit −
DuraBlue/VersaBlue 25L and 50L
Melters
Customer Product Manual
Part 1105309A
Issued 2/11
NORDSON CORPORATION DULUTH, GEORGIA USA
www.nordson.com
This document contains important safety information
Be sure to read and follow all safety information in this
document and any other related documentation.
Part 1105309A E2010 Nordson Corporation
All rights reserved
For CE Declaration, refer to melter manual.
Nordson Corporation welcomes requests for information, comments, and inquiries about its products. General information
about Nordson can be found on the Internet using the following address: http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
11475 Lakefield Drive
Duluth, GA 30097
Notice
This is a Nordson Corporation publication which is protected by copyright. Original copyright date 2011.
No part of this document may be photocopied, reproduced, or translated to another language without the prior written
consent of Nordson Corporation. The information contained in this publication is subject to change without notice.
Trademarks
AccuJet, AeroCharge, Apogee, AquaGuard, Asymtek, Automove, Baitgun, Blue Box, Bowtie, CanWorks, Century, CF, CleanSleeve, CleanSpray, ColorMax,
Color-on-Demand, Control Coat, Coolwave, Cross-Cut, cScan+, Dispensejet, DispenseMate, DuraBlue, DuraDrum, Durafiber, DuraPail, Dura-Screen,
Durasystem, Easy Coat, Easymove Plus, Ecodry, Econo-Coat, e.DOT, EFD, Emerald, Encore, ESP, e stylized, ETI - stylized, Excel 2000, Fillmaster,
FlexiCoat, Flex-O-Coat, Flow Sentry, Fluidmove, FoamMelt, FoamMix, Fulfill, GreenUV, HDLV, Heli-flow, Horizon, Hot Shot, iControl, iDry, iFlow, Isocoil,
Isocore, Iso-Flo, iTRAX, Kinetix, LEAN CELL, Little Squirt, LogiComm, Magnastatic, March, Maverick, MEG, Meltex, Microcoat, Micromark, MicroSet,
Millennium, Mini Squirt, Mountaingate, Nordson, OptiMix, Package of Values, Pattern View, PermaFlo, PicoDot, Porous Coat, PowderGrid, Powderware,
Precisecoat, PRIMARC, Printplus, Prism, ProBlue, Prodigy, Pro-Flo, ProLink, Pro-Meter, Pro-Stream, RBX, Rhino, Saturn, Saturn with rings, Scoreguard,
Seal Sentry, Select Charge, Select Coat, Select Cure, Signature, Slautterback, Smart-Coat, Solder Plus, Spectrum, Speed-Coat, SureBead, Sure Coat,
Sure-Max, Sure Wrap, Tracking Plus, TRAK, Trends, Tribomatic, TrueBlue, TrueCoat, Ultra, UpTime, u-TAH, Vantage, VersaBlue, Versa-Coat, VersaDrum,
VersaPail, Versa-Screen, Versa-Spray, Watermark, and When you expect more. are registered trademarks of Nordson Corporation.
Accubar, Advanced Plasma Systems, AeroDeck, AeroWash, AltaBlue, AltaSlot, Alta Spray, Artiste, ATS, Auto-Flo, AutoScan, Axiom, Best Choice,
Blue Series, Bravura, CanPro, Champion, Check Mate, ClassicBlue, Classic IX, Clean Coat, Cobalt, Controlled Fiberization, Control Weave, ContourCoat,
CPX, cSelect, Cyclo-Kinetic, DispensLink, Dry Cure, DuraBraid, DuraCoat, DuraPUR, Easy Clean, EasyOn, EasyPW, Eclipse, e.dot+, E-Nordson,
Equalizer, EquiBead, FillEasy, Fill Sentry, Flow Coat, Fluxplus, Get Green With Blue, G-Net, G-Site, iON, Iso-Flex, iTrend, Lacquer Cure, Maxima, Mesa,
MicroFin, MicroMax, Mikros, MiniBlue, MiniEdge, Minimeter, Multifill, MultiScan, Myritex, Nano, OmniScan, OptiStroke, Partnership+Plus, PatternJet,
PatternPro, PCI, Pinnacle, Plasmod, Powder Pilot, Powder Port, Powercure, Process Sentry, Pulse Spray, Ready Coat, RediCoat, Royal Blue,
Select Series, Sensomatic, Shaftshield, SheetAire, Smart, SolidBlue, Spectral, SpeedKing, Spray Works, Summit, SureFoam, Sure Mix, SureSeal,
Swirl Coat, TAH, ThruWave, Trade Plus, Trilogy, Ultra FoamMix, UltraMax, Ultrasaver, Ultrasmart, Universal, ValueMate, Versa, Vista, Web Cure, and
2 Rings (Design) are trademarks of Nordson Corporation.
Designations and trademarks stated in this document may be brands that, when used by third parties for their own purposes,
could lead to violation of the owners’ rights.
Table of Contents i
Part 1105309A
E2010 Nordson Corporation
Table of Contents
Safety 1........................................................
Safety Alert Symbols 1...........................................
Responsibilities of the Equipment Owner 2..........................
Safety Information 2...........................................
Instructions, Requirements, and Standards 2......................
User Qualifications 3...........................................
Applicable Industry Safety Practices 3..............................
Intended Use of the Equipment 3................................
Instructions and Safety Messages 4..............................
Installation Practices 4.........................................
Operating Practices 4..........................................
Maintenance and Repair Practices 5.............................
Equipment Safety Information 5....................................
Equipment Shutdown 6.........................................
General Safety Warnings and Cautions 7.........................
Other Safety Precautions 10.....................................
First Aid 10.....................................................
Safety Labels and Tags 11.........................................
Description 12...................................................
Theory of Operation 13...........................................
Overview 13......................................................
Pneumatic & Mechanical Components 14............................
(1). Adhesive Storage Bin 14....................................
(2). Air Pressure Regulator/Solenoid Assembly 15..................
(3). Suction Lance 15...........................................
(4). Adhesive Transfer Hose 15..................................
(5). Lid Assembly 15............................................
Electrical Components 16..........................................
(6). Control Box 16.............................................
(7). Sensor 18.................................................
Installation 19...................................................
Prepare the Melter 19.............................................
Install the Tank Lid Components 20..................................
Install the Control Box/Regulator Assembly 25........................
Assemble the Transfer Hose, Air Line, and Suction Lance 26...........
Level Sensor Adjustment and Calibration 28..........................
Baseline Setting 29.............................................
Final Setting 29.................................................
Operation 30....................................................
Time Settings 30..................................................
Monitoring Refill Operation 32......................................
Table of Contents
ii
Part 1105309A E2010 Nordson Corporation
Maintenance 32..................................................
Troubleshooting 33..............................................
Refill PCA Troubleshooting Diagnostic Instructions 34..................
Parts 36.........................................................
Using the Illustrated Parts Lists 36..................................
DuraBlue/VersaBlue 25L and 50L Retrofit Kit Assemblies 37...........
Ship With Fastener Kit 37........................................
DuraBlue/VersaBlue 25L Lid Assembly Parts 38....................
DuraBlue/VersaBlue 50L Lid Assembly Parts 42....................
Lid Switch Assembly for 25L Melters 45...........................
Lid Switch Assembly for 50L Melters 46...........................
25L Clamp Assembly With Actuator 47............................
50L Clamp Assembly With Actuator 48............................
Level Probe Holder Assembly 49.................................
Pneumatic Control Assembly 50..................................
Control Box Assembly 51........................................
Container/Wand Kit 52..........................................
Service Kits 52...................................................
Accessories 52...................................................
Service Parts 52..................................................
Specifications 53................................................
Wiring Diagram 54................................................
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 1
Part 1105309A
E2010 Nordson Corporation
Fulfill)Retrofit Kit −DuraBlue/VersaBlue
25L and 50L Melters
Safety
Read this section before using the equipment. This section contains
recommendations and practices applicable to the safe installation, operation,
and maintenance (hereafter referred to as “use”) of the product described in
this document (hereafter referred to as “equipment”). Additional safety
information, in the form of task‐specific safety alert messages, appears as
appropriate throughout this document.
WARNING! Failure to follow the safety messages, recommendations, and
hazard avoidance procedures provided in this document can result in
personal injury, including death, or damage to equipment or property.
Safety Alert Symbols
The following safety alert symbol and signal words are used throughout this
document to alert the reader to personal safety hazards or to identify
conditions that may result in damage to equipment or property. Comply with
all safety information that follows the signal word.
WARNING! Indicates a potentially hazardous situation that, if not avoided,
can result in serious personal injury, including death.
CAUTION! Indicates a potentially hazardous situation that, if not avoided,
can result in minor or moderate personal injury.
CAUTION! (Used without the safety alert symbol) Indicates a potentially
hazardous situation that, if not avoided, can result in damage to equipment
or property.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
2
Part 1105309A E2010 Nordson Corporation
Responsibilities of the Equipment Owner
Equipment owners are responsible for managing safety information, ensuring
that all instructions and regulatory requirements for use of the equipment are
met, and for qualifying all potential users.
Safety Information
SResearch and evaluate safety information from all applicable sources,
including the owner‐specific safety policy, best industry practices,
governing regulations, material manufacturer's product information, and
this document.
SMake safety information available to equipment users in accordance with
governing regulations. Contact the authority having jurisdiction for
information.
SMaintain safety information, including the safety labels affixed to the
equipment, in readable condition.
Instructions, Requirements, and Standards
SEnsure that the equipment is used in accordance with the information
provided in this document, governing codes and regulations, and best
industry practices.
SIf applicable, receive approval from your facility's engineering or safety
department, or other similar function within your organization, before
installing or operating the equipment for the first time.
SProvide appropriate emergency and first aid equipment.
SConduct safety inspections to ensure required practices are being
followed.
SRe‐evaluate safety practices and procedures whenever changes are
made to the process or equipment.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 3
Part 1105309A
E2010 Nordson Corporation
User Qualifications
Equipment owners are responsible for ensuring that users:
Sreceive safety training appropriate to their job function as directed by
governing regulations and best industry practices
Sare familiar with the equipment owner's safety and accident
prevention policies and procedures
Sreceive, equipment‐ and task‐specific training from another qualified
individual
NOTE: Nordson can provide equipment‐specific installation,
operation, and maintenance training. Contact your Nordson
representative for information
Spossess industry‐ and trade‐specific skills and a level of experience
appropriate to their job function
Sare physically capable of performing their job function and are not
under the influence of any substance that degrades their mental
capacity or physical capabilities
Applicable Industry Safety Practices
The following safety practices apply to the use of the equipment in the
manner described in this document. The information provided here is not
meant to include all possible safety practices, but represents the best safety
practices for equipment of similar hazard potential used in similar industries.
Intended Use of the Equipment
SUse the equipment only for the purposes described and within the limits
specified in this document.
SDo not modify the equipment.
SDo not use incompatible materials or unapproved auxiliary devices.
Contact your Nordson representative if you have any questions on
material compatibility or the use of non‐standard auxiliary devices.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
4
Part 1105309A E2010 Nordson Corporation
Instructions and Safety Messages
SRead and follow the instructions provided in this document and other
referenced documents.
SFamiliarize yourself with the location and meaning of the safety warning
labels and tags affixed to the equipment. Refer to Safety Labels and Tags
at the end of this section.
SIf you are unsure of how to use the equipment, contact your Nordson
representative for assistance.
Installation Practices
SInstall the equipment in accordance with the instructions provided in this
document and in the documentation provided with auxiliary devices.
SEnsure that the equipment is rated for the environment in which it will be
used and that the processing characteristics of the material will not create
a hazardous environment. Refer to the Material Safety Data Sheet
(MSDS) for the material.
SIf the required installation configuration does not match the installation
instructions, contact your Nordson representative for assistance.
SPosition the equipment for safe operation. Observe the requirements for
clearance between the equipment and other objects.
SInstall lockable power disconnects to isolate the equipment and all
independently powered auxiliary devices from their power sources.
SProperly ground all equipment. Contact your local building code
enforcement agency for specific requirements.
SEnsure that fuses of the correct type and rating are installed in fused
equipment.
SContact the authority having jurisdiction to determine the requirement for
installation permits or inspections.
Operating Practices
SFamiliarize yourself with the location and operation of all safety devices
and indicators.
SConfirm that the equipment, including all safety devices (guards,
interlocks, etc.), is in good working order and that the required
environmental conditions exist.
SUse the personal protective equipment (PPE) specified for each task.
Refer to Equipment Safety Information or the material manufacturer's
instructions and MSDS for PPE requirements.
SDo not use equipment that is malfunctioning or shows signs of a potential
malfunction.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 5
Part 1105309A
E2010 Nordson Corporation
Maintenance and Repair Practices
SPerform scheduled maintenance activities at the intervals described in
this document.
SRelieve system hydraulic and pneumatic pressure before servicing the
equipment.
SDe‐energize the equipment and all auxiliary devices before servicing the
equipment.
SUse only new Nordson‐authorized refurbished or replacement parts.
SRead and comply with the manufacturer's instructions and the MSDS
supplied with equipment cleaning compounds.
NOTE: MSDSs for cleaning compounds that are sold by Nordson are
available at www.nordson.com or by calling your Nordson representative.
SConfirm the correct operation of all safety devices before placing the
equipment back into operation.
SDispose of waste cleaning compounds and residual process materials
according to governing regulations. Refer to the applicable MSDS or
contact the authority having jurisdiction for information.
SKeep equipment safety warning labels clean. Replace worn or damaged
labels.
Equipment Safety Information
This equipment safety information is applicable to the following types of
Nordson equipment:
Shot melt and cold adhesive application equipment and all related
accessories
Spattern controllers, timers, detection and verification systems, and all
other optional process control devices
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
6
Part 1105309A E2010 Nordson Corporation
Equipment Shutdown
To safely complete many of the procedures described in this document, the
equipment must first be shut down. The level of shut down required varies by
the type of equipment in use and the procedure being completed.
If required, shut down instructions are specified at the start of the procedure.
The levels of shut down are:
Relieving System Hydraulic Pressure
Completely relieve system hydraulic pressure before breaking any hydraulic
connection or seal. Refer to the melter‐specific product manual for
instructions on relieving system hydraulic pressure.
De‐energizing the System
Isolate the system (melter, hoses, applicators, and optional devices) from all
power sources before accessing any unprotected high‐voltage wiring or
connection point.
1. Turn off the equipment and all auxiliary devices connected to the
equipment (system).
2. To prevent the equipment from being accidentally energized, lock and tag
the disconnect switch(es) or circuit breaker(s) that provide input electrical
power to the equipment and optional devices.
NOTE: Government regulations and industry standards dictate specific
requirements for the isolation of hazardous energy sources. Refer to the
appropriate regulation or standard.
Disabling the Applicators
NOTE: Adhesive dispensing applicators are referred to as “guns” in some
previous publications.
All electrical or mechanical devices that provide an activation signal to the
applicators, applicator solenoid valve(s), or the melter pump must be
disabled before work can be performed on or around an applicator that is
connected to a pressurized system.
1. Turn off or disconnect the applicator triggering device (pattern controller,
timer, PLC, etc.).
2. Disconnect the input signal wiring to the applicator solenoid valve(s).
3. Reduce the air pressure to the applicator solenoid valve(s) to zero; then
relieve the residual air pressure between the regulator and the applicator.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 7
Part 1105309A
E2010 Nordson Corporation
General Safety Warnings and Cautions
Table 1 contains the general safety warnings and cautions that apply to
Nordson hot melt and cold adhesive equipment. Review the table and
carefully read all of the warnings or cautions that apply to the type of
equipment described in this manual.
Equipment types are designated in Table 1 as follows:
HM = Hot melt (melters, hoses, applicators, etc.)
PC = Process control
CA = Cold adhesive (dispensing pumps, pressurized container, and
applicators)
Table 1 General Safety Warnings and Cautions
Equipment
Type Warning or Caution
HM
WARNING! Hazardous vapors! Before processing any polyurethane
reactive (PUR) hot melt or solvent‐based material through a compatible
Nordson melter, read and comply with the material's MSDS. Ensure
that the material's processing temperature and flashpoints will not be
exceeded and that all requirements for safe handling, ventilation, first
aid, and personal protective equipment are met. Failure to comply with
MSDS requirements can cause personal injury, including death.
HM
WARNING! Reactive material! Never clean any aluminum component
or flush Nordson equipment with halogenated hydrocarbon fluids.
Nordson melters and applicators contain aluminum components that
may react violently with halogenated hydrocarbons. The use of
halogenated hydrocarbon compounds in Nordson equipment can
cause personal injury, including death.
HM, CA WARNING! System pressurized! Relieve system hydraulic pressure
before breaking any hydraulic connection or seal. Failure to relieve the
system hydraulic pressure can result in the uncontrolled release of hot
melt or cold adhesive, causing personal injury.
Continued...
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
8
Part 1105309A E2010 Nordson Corporation
General Safety Warnings and Cautions (contd)
Table 1 General Safety Warnings and Cautions (contd)
Equipment
Type Warning or Caution
HM
WARNING! Molten material! Wear eye or face protection, clothing that
protects exposed skin, and heat‐protective gloves when servicing
equipment that contains molten hot melt. Even when solidified, hot melt
can still cause burns. Failure to wear appropriate personal protective
equipment can result in personal injury.
HM, PC
WARNING! Equipment starts automatically! Remote triggering devices
are used to control automatic hot melt applicators. Before working on
or near an operating applicator, disable the applicator's triggering
device and remove the air supply to the applicator's solenoid valve(s).
Failure to disable the applicator's triggering device and remove the
supply of air to the solenoid valve(s) can result in personal injury.
HM, CA, PC
WARNING! Risk of electrocution! Even when switched off and
electrically isolated at the disconnect switch or circuit breaker, the
equipment may still be connected to energized auxiliary devices.
De‐energize and electrically isolate all auxiliary devices before
servicing the equipment. Failure to properly isolate electrical power to
auxiliary equipment before servicing the equipment can result in
personal injury, including death.
HM, CA, PC
WARNING! Risk of fire or explosion! Nordson adhesive equipment is
not rated for use in explosive environments and should not be used
with solvent‐based adhesives that can create an explosive atmosphere
when processed. Refer to the MSDS for the adhesive to determine its
processing characteristics and limitations. The use of incompatible
solvent‐based adhesives or the improper processing of solvent‐based
adhesives can result in personal injury, including death.
HM, CA, PC
WARNING! Allow only personnel with appropriate training and
experience to operate or service the equipment. The use of untrained
or inexperienced personnel to operate or service the equipment can
result in injury, including death, to themselves and others and can
damage to the equipment.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 9
Part 1105309A
E2010 Nordson Corporation
Warning or Caution
Equipment
Type
HM
CAUTION! Hot surfaces! Avoid contact with the hot metal surfaces of
applicators, hoses, and certain components of the melter. If contact
can not be avoided, wear heat‐protective gloves and clothing when
working around heated equipment. Failure to avoid contact with hot
metal surfaces can result in personal injury.
HM
CAUTION! Some Nordson melters are specifically designed to
process polyurethane reactive (PUR) hot melt. Attempting to process
PUR in equipment not specifically designed for this purpose can
damage the equipment and cause premature reaction of the hot melt. If
you are unsure of the equipment's ability to process PUR, contact your
Nordson representative for assistance.
HM, CA
CAUTION! Before using any cleaning or flushing compound on or in
the equipment, read and comply with the manufacturer's instructions
and the MSDS supplied with the compound. Some cleaning
compounds can react unpredictably with hot melt or cold adhesive,
resulting in damage to the equipment.
HM
CAUTION! Nordson hot melt equipment is factory tested with Nordson
Type R fluid that contains polyester adipate plasticizer. Certain hot melt
materials can react with Type R fluid and form a solid gum that can clog
the equipment. Before using the equipment, confirm that the hot melt is
compatible with Type R fluid.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
10
Part 1105309A E2010 Nordson Corporation
Other Safety Precautions
SDo not use an open flame to heat hot melt system components.
SCheck high pressure hoses daily for signs of excessive wear, damage, or
leaks.
SNever point a dispensing handgun at yourself or others.
SSuspend dispensing handguns by their proper suspension point.
First Aid
If molten hot melt comes in contact with your skin:
1. Do NOT attempt to remove the molten hot melt from your skin.
2. Immediately soak the affected area in clean, cold water until the hot melt
has cooled.
3. Do NOT attempt to remove the solidified hot melt from your skin.
4. In case of severe burns, treat for shock.
5. Seek expert medical attention immediately. Give the MSDS for the hot
melt to the medical personnel providing treatment.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 11
Part 1105309A
E2010 Nordson Corporation
Safety Labels and Tags
Figure 1 illustrates the location of the product safety labels and tags affixed to
the equipment. Table 2 provides an illustration of the hazard identification
symbols that appear on each safety label and tag, the meaning of the
symbol, or the exact wording of any safety message.
1
Figure 1 Safety labels and tags
Table 2 Safety Labels and Tags
Item Part Description
1. 1021984
WARNING! Hazardous voltage. Disconnect all power supply
connections before servicing.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
12
Part 1105309A E2010 Nordson Corporation
Description
The DuraBlue/VersaBlue 25L and 50L Fulfill Retrofit Kit converts a
DuraBlue/VersaBlue 25L and 50L melter into an automatic fill system that
maintains adhesive in the melter , improving productivity and reducing
maintenance. The retrofit kit adds adhesive to the sealed tank, reducing the
possibility of char, contaminants, thermal shock and incorrect adhesive
temperatures that result in poor adhesive bonding.
The Fulfill system is shipped with the components illustrated in Figure 2.
23
1
6
7
5
4
Figure 2 Fulfill system components
1. Adhesive storage bin
2. Transfer hose
3. Suction lance
4. Lid assembly with control box and
mounting bracket with level sensor,
filter-regulator w/ gauge, and
solenoid
5. Hose clamp (2)
6. Air line (4m)
7. Wire tie (5)
Optional accessories available for the Fulfill Retrofit include:
Sa vibrator kit for the adhesive storage bin
Sa light tower kit for audio/visual fill/fault indication of the Fulfill processes.
Contact your Nordson representative for more information on these kits.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 13
Part 1105309A
E2010 Nordson Corporation
Theory of Operation
Overview
The system adds small quantities of adhesive to the sealed tank at regular
intervals, reducing the possibility of adhesive char, contaminants, thermal
shock and incorrect adhesive temperatures that result in poor bonding.
A capacitance sensor located in the melter detects low adhesive level, and
then sends a signal to the Fulfill system control box. A delay timer prevents
the fill system from frequently cycling on and off.
At the end of the delay, the control box activates the vacuum via a solenoid
valve. Air pressure flows to a suction lance that is placed in the supplied bulk
adhesive container. Using vacuum, the system conveys adhesive from the
bulk container to the adhesive melter tank. When the adhesive in the melter
tank reaches the desired level, the control box shuts off the solenoid valve to
stop the flow of adhesive.
The control box activates the suction lance for a limited amount of time to
prevent over‐fill conditions. If the maximum fill time is exceeded, the
controller activates a fault that stops the system from filling.
A safety interlock switch detects whether the melter tank lid is in place. If the
tank lid is not in place, the fill system will not operate.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
14
Part 1105309A E2010 Nordson Corporation
Pneumatic & Mechanical Components
Refer to Figure 3 as you learn about the components of the
DuraBlue/VersaBlue 25L and 50LL and 50L Fulfill retrofit assembly.
1
3
5
4
2
67
Figure 3 Assembled DuraBlue/VersaBlue 25L and 50LL and 50L Fulfill retrofit assembly.
(1). Adhesive Storage Bin
Place adhesive in the adhesive storage bin. The bin contains a gasket that
prevents debris from entering the bin. For best results, break up the
adhesive as much as possible when emptying into the bin. Do not get the
adhesive wet.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters 15
Part 1105309A
E2010 Nordson Corporation
(2). Air Pressure Regulator/Solenoid Assembly
The supplied air pressure regulator is permanently set at 65 psig, the optimal
setting for most adhesives.
The solenoid valve turns on after the sensor indicates level state and the time
delay has been reached. The solenoid directs compressed air to flow to the
suction lance.
(3). Suction Lance
The suction lance draws adhesive from the adhesive storage bin. The
suction lance includes:
SA venturi pump to draw in and transport the adhesive.
SA vibrator to keep the adhesive in loose condition. The vibrator is active
as long as compressed air is supplied to the suction lance.
Air line tubing and the adhesive transfer hose are connected to the suction
lance. The lance is placed in the PVC pipe located in the adhesive storage
bin.
(4). Adhesive Transfer Hose
The adhesive transfer hose connects the suction lance to the lid assembly.
The transfer hose conveys adhesive from the adhesive storage bin to the
melter tank.
(5). Lid Assembly
The lid assembly includes the filter stack, lid, fill tube, baffle and deflector:
SThe filter stack contains a replaceable filter sock to prevent adhesive
fines and talc/powder in the adhesive from being emitted into the ambient
air.
SThe fill tube attaches to the adhesive transfer hose.
SThe baffle prevents adhesive from entering the filter sock.
SThe deflector distributes adhesive evenly in the tank.
A safety interlock switch detects whether the melter tank lid is in place. If the
tank lid is not in place, the fill system will not operate.
FulfillRetrofit Kit −DuraBlue/VersaBlue 25L and 50L Melters
16
Part 1105309A E2010 Nordson Corporation
Electrical Components
(6). Control Box
The control box contains the membrane panel and PCA.
Membrane Panel
The front panel of the electrical control box shown in Figure 4 contains three
LEDs that have different colored lights to indicate the unit condition:
SEnable On/Off LED (green light) - Indicates that the system is
enabled. Pressing the Enable On/Off key will toggle the indicator. If
the melter tank lid is open, this LED will flash, indicating that the fill
system is disabled.
SEnable button - Press the enable button to turn the fill system on or
off.
SAdhesive transfer LED (blue light) - Indicates adhesive delivery is
active. When a low level is detected, the indicator notes that
adhesive is being transferred from the adhesive storage bin into the
melter tank through the transfer hose.
SFault LED (red light) - activates if the system exceeds the user
defined fill time limit. The system will not resume operation until the
fault is cleared with the clear fault button.
SClear fault button - Press the clear fault button to reset fault and
resume normal activity.
123
4
Figure 4 Fill system controls and indicators
1. Enable On/Off
2. Filling activated symbol and blue LED
3. Fault symbol and red LED
4. Clear fault
