Nova 4205 User manual

9
12
34
56
1.Unfoldthewalkerbypullingthefrontandrearframeapartand
 placeonaatsurface.Lifttheseatandpushdownwardonthe
foldingsupportpiecesothesidefoldinghingesarefullyextended.
(see image 5)
2.Insertthebackrestintotheplasticbackresthinges.Pressdownon
thepushbuttonsandslidethebackrestcompletelyintothehinge
untilthebuttonsengageintothehingeholes(pull on the backrest
to make sure it is secure).(see image 6)
3.Turnthewalkersothatitrestsontherearoftheframe.(see image 7)
4. Insertthefrontwheelsintotheframeforyourdesiredseatheight.
 (See recommended seat height below)
Recommended Seat Height
 Theuser’sfeetshouldbeatonthegroundwhentheyareproperly 
 seatedonthewalker.Werecommendthelowerseatheighttot
mostindividualsfrom4’9”–5’4”&thehigherseatheightfor
individualsfrom5’4”-6’0”.
For Heights 5’4” - 6’0” (upper push button)
 Pushdownonthetopbuttonandslidethestemintotheframe.You
 willneedtopressdownonthesecondbuttontoallowthetopbutton
 toinsertintotheholeontheframe.(see image 8)
For Heights 4’9” - 5’4” (lower push button)
 Alignthebuttonjustoffcenterfromtheholeintheframeandslide
thestemintotheframe.Pressdownagainonthelowerbuttonand
 continuetoslidethestemintotheframewhilealigningthelower
 buttonwiththeholeontheframeuntilthelowerbuttonisinserted
 intothehole.(see image 9)(Be sure that both wheels are set at the
same height and pull on the legs to make sure they are secure.)
5. Turnwalkeroversothatitrestsonthefrontoftheframe.(see image 10)
6. Insertthewheellegmarked(L)intotheleftrearframesothatthewheel
isontheoutsideoftheframeandthepushbuttonsarelinedupwiththe
holdintheframe.(see image 11)
7. Insertthewheellegmarked(R)intotherightrearframesothatthe
wheelisontheoutsideoftheframeandthepushbuttonsarelinedup
withtheholeintheframe. (see image 12)
(See recommended seat height above)
8.Turnthewalkeroversothatitisrestingonthewheels.Besurethat
 allthefourwheelsareatandthattheseatislevel.(see image 13)
9.Insertthehandlesintotheframebeingsurethatthecablesareonthe
outsideoftheframe.(see image 14)
78
To Unfold
To Remove
ASSEMBLY INSTRUCTIONS
1.Carefullyremovethewalkerframeandcomponentsfrom
theshippingbox.
2.Examineallpartsfordamagefromshipping.Ifanyparts
aremissingordamaged,pleasecall1-800-557-6682and
promptCustomerService. DO NOTusewalkeruntilall
partsarereceived.
Components
-WalkerFramewithBagandSeat,Backrest(see image 1)
-(2)FrontWheels(see image 2)
-(2)RearWheelswithCableHandleandHandBrake(see image 3)
-(6)LegandHandleAdjustmentScrews(see image 4)
10
11 12
13 14

10.Insertthefourlegattachmentscrewsintotheholeslocatedonthe
outsideoftheframe.Handtightenuntilthescrewissecureandthe
plasticknobisushwiththeframe. (Adjustment handle should be tight
and not move from side to side.)Besureallfourscrewlegsscrews
aresecurebeforeusingthewalker.(see image 15)
Determining the Correct Handle Height
Standuprightbehindthewalkerwithyourarmshangingatyoursideand
bothfeetinlinewiththerearwheels.Adjusttheheightofthewalker
handlessothattheyareevenwiththewristoftheuser.Thisshouldcreate
a20to30degreebendintheelbowwhenusingthewalker.
1. Aligntheholeinthehandlewiththeholeintheframetoyourselected
handleheightandhandtightenuntilthescrewissecureandtheplastic
knobisushwiththeframe. (Adjustment handle should be tight and not
move from side to side.)(see image 16)
2. Attachtheplasticcableguidetotheframeofthewalker.(see image 17)
15 16
17
OPERATING INSTRUCTIONS
1. Placethewalkerintheuprightpositionrestingontherearwheels.Hold
bothhandlesandsqueezethehandbrakeswhilepushingforwardonthe
walkeruntilitrestsonallfourwheels.(see image 18)
2. Liftuponthepaddedseatandpressdownonthebottomofthebag.
Youwillfeelthecentersupportbarlocatedunderthecarrybag.Push
downuntilitlocksintoplace.(see image 19)
To Open
To Close
Liftuptheseatandpullonthenyloncarryhandleuntilthewalkercloses.(see image 20)
18 19
20
To Check the Hand Brakes
Youshouldchecktomakesurethehandbrakesareworkingproperlybeforeeachuse.
Squeezethebrakehandlestomakesurethatthebrakepadcontactsthewheelandcan
stopthewalker.Pushdownonthehandbrakesuntiltheylockintopositionandmake
surethatthebrakepadcontactsthewheelandcanstopthewalker.
Adjusting the Brakes
To Tighten the Brakes
To Loosen the Brakes
Thebrakesshouldbepresettoworkproperly.Tomaintainthepresetcondition
ortoadjustthebraketension,placethewalkeronaatsurfaceandloosenthe
nutfromthetopofthebrakeshoenearthewheel.(see image 21) 
Turnthetensionadjustmentscrewcounterclockwiseuntilyoureachthedesired
tension.(see image 22)
Turnthetensionadjustmentscrewclockwiseuntilyoureachthedesiredtension.
Tightenthenutbackdownsothatitistightagainstthetopofthebrakepad
afteryouhaveachievedthedesiredtension.(see image 23) 
21
22
23
