NOVAK BRUSHLESS CONVERSION - KIT User manual
STEP 5 - INSTALL ESC & RECEIvER BRUSHLESS CONvERSION KIT INSTRUCTIONS
CONvERSION KITS AvAILABLE
The following Novak Brushless Conversion Kits are available (Refer to
www.teamnovak.com for additional and/or updated kit compatibility information)
#5010 Associated®RC8TM for Team Associated RC-8 Buggy
#5011 CEN®MatrixTM for CEN Matrix C-1 Buggy
#5012 Hot Bodies®LightningTM for Hot Bodies Lightning2 Evo Pro Buggy
#5013 Kyosho®InfernoTM for Kyosho Inferno 777, 777 SP-1, SP-2,
SP-2WC, and Sport ST-R Buggies
#5014 Mugen®MBX5TM for Mugen MBX5 and MBX5R Buggies
#5015 OFNA®9.5TM/UltraTM
for
OFNA 9.5 Series Buggies (ViolatorTM,
RavengerTM and Jammin X1TM) and the OFNA Ultra Series Buggies (MBXTM,
CompTM and LX1TM)
#5016 OFNA®Hyper 8TM for OFNA Hyper 8 and Hyper 8.5 Buggies
#5017 OFNA
®
Hyper 7
TM
for
OFNA Hyper 7 Buggies
#5018 XRAY®XB8TM for X-Ray XB8 TQ and XB8 EC Buggies
#5019 Losi
®
8ight
TM
for Team Losi 8ight Buggy
Car models listed are the registered trademarks of their respective company.
The Ultimate Conversion Kit to Convert Nitro Buggies to Electric Power!
include all of the necessary conversion components.
A Novak High-Voltage Brushless ESC and HV Brushless Motor are not included but required for completion.
#55-5010-1 • 4/2008
GEARING SETUP
1.
INSTALL NOVAK HV BRUSHLESS ESC
a. Select mounting position for ESC — refer to Figure 14
(on
For OFNA & Kyosho Dual Battery Setups: refer to Figure 15
For Losi 8ight: refer to Figures 20 & 21
Note: Be sure there is adequate
ventilation over ESC’s heat sink!
b.
Using the included double-sided tape, mount ESC to chassis.
Phillips FH self-tapping screws (see Figure 13) — chassis
and/or stone guard will need to be drilled and holes
countersunk to do this.
c.
Refer to the ESC instructions for further installation instructions.
2.
INSTALL RECEIVER AND ANTENNA MOUNT
a. Select mounting position for receiver and antenna — refer to
Figure 14
For OFNA & Kyosho Dual Battery Setups: refer to Figure 15
For Losi 8ight: refer to Figure 14
b. Install Receiver:
refer to receiver instructions.
c. (in
Add’l Hardware Bag — refer to Figure 13), using the M3x8 FH
tube that came with nitro vehicle.
Quality Racing Electronics since 1978
NOvAK ELECTRONICS, INC.
3.
INSTALL MOTOR PINION GEAR
Install a Mod 1 pinion gear to the output shaft. A hardened steel,
high-strength pinion gear is recommended with a 5mm bore. Novak
. Refer to
Figure 14
4.
INSTALL BRUSHLESS MOTOR ASSEMBLY
Each kit has a unique motor adapter plate.
Slotted Plates
Nylon insert lock nuts — see Figure 12.
Non-Slotted Plates: require the four screws (and cupped washers
depending on model) that were originally used to mount the nitro engine
to the chassis. Use thread-locking agent on these screws.
Mount motor assembly to chassis with the proper screws and
adjust gear mesh before tightening, being sure that the two
clamping screw holes in the heat sink face the outside of the
buggy. The motor’s solder tabs should face in the direction that
will provide the shortest wire length from the ESC to the motor.
•
For Losi 8ight Vehicle: refer to Figures 17-19 .
FIGURE 12:
Motor Adapter Plate Installation
Note: Motor and Heat Sink removed to show screw detail
5. INSTALL MOTOR FAN ON HEAT SINK
(refer to label on fan for direction).
•
screws (in Add’l Hardware Bag) through fan into heat sink — see
Figure 11 & Figure 14
.
•
Use included Y-harness (see Figure 1) to plug the motor fan and
ESC fan into the Novak HV High-Voltage Brushless ESC.
4-40x1/2” Socket Cap Screw (4)
#6x1” Phillips FH Self-Tapping
Screw (2)
M3x8 FH Screw (1)
Antenna Mount (1)
Servo Stand-Offs (4)
FIGURE 13:
Additional Hardware Bag Contents (#65-5010-3)
Note: For non-slotted plates, use the hardware that was included with
your Nitro engine. Do not use M4x10 FH screws of M4 lock nuts.
P1
P4
FIGURE 11:
Motor Heat Sink
Installed on
Motor Adapter
Plate
same side as engraved
Refer to Vehicle Specics Sheet for Novak’s
recommended Gearing Starting Points.
Motor operating temperature is the
ONLY
way to set vehicle gearing
BE SURE TO CREATE
SUFFICIENT VENTILATION
The Motor and Speed Control should not exceed
160-170°F MAX at end of the run!
Change the gearing to avoid overheating!
DO NOT FREE-REV MOTOR!
Free-running your brushless motor in a no-load condition can cause rotor
failure & ESC transistor damage and will void the product’s warranty.
WITH CUT-OFF WHEEL AND
SANDING DRUM
mm
mm
mm HEX WRENCH
mm HEX WRENCH
mm HEX WRENCH
OCOUNTER SINK TOOL
PLEASE READ ALL INSTRUCTIONS BEFORE STARTING
