Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
1
Change History
Document Version
Release Date
Description
V1.1.2
2022-03-15
Updated the legends on the appearance pictures.
V1.1.1
2021-12-17
Updated the descriptions of the USB (Type B) port and Gigabit
Ethernet port.
Added a note for the dimension drawings.
Added the gross weight of the product.
V1.1.0
2021-11-03
Updated the product appearance pictures.
V1.0.1
2021-09-30
Added certification information.
Updated the description of the playback performance.
Updated the product pictures.
Added net weight.
V1.0.0
2021-08-31
First release
Introduction
The T30 is a new generation of multimedia player created by NovaStar for full-color LED displays. This multimedia
player integrates playback and sending capabilities, allowing users to publish content and control LED displays with a
computer, mobile phone, or tablet. Working with our superior cloud-based publishing and monitoring platforms, the
T30 enables users to manage LED displays from an Internet-connected device anywhere, anytime.
Thanks to its reliability, ease of use, and intelligent control, the T30 becomes a winning choice for commercial LED
displays and smart city applications such as fixed displays, lamp-post displays, chain store displays, advertisement
players, mirror displays, retail store displays, door head displays, shelf displays, and much more.
Certifications
CE, RoHS, FCC, IC, FCC ID, IC ID, UKCA
If the product does not have the relevant certifications required by the countries or regions where it is to be
sold, please contact NovaStar to confirm or address the problem. Otherwise, the customer shall be responsible
for the legal risks caused or NovaStar has the right to claim compensation.
Features
Output
Loading capacity up to 650,000 pixels
Maximum width: 4096 pixels
Maximum height: 4096 pixels
2x Gigabit Ethernet ports
One serves as primary and the other as backup.
1x Stereo audio connector
The audio sample rate of the internal source is
fixed at 48 KHz. The audio sample rate of the
external source supports 32 KHz, 44.1 KHz, or
48 KHz. If NovaStar’s multifunction card is used
for audio output, audio with a sample rate of 48
KHz is required.
Input
2x Sensor connectors
Connect to brightness sensors or temperature
and humidity sensors.
Control
1x USB 3.0 (Type A) port
Allows for playback of content imported from a
USB drive and firmware upgrade over USB.
1x USB (Type B) port
Connects to the control computer for content
publishing and screen control.
1x Gigabit Ethernet port
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
2
Connects to the control computer, a LAN or
public network for content publishing and screen
control.
Performance
Powerful processing capacity
−Quad-core ARM A55 processor @1.8 GHz
−Support for H.264/H.265 4K@60Hz video
decoding
−1 GB of onboard RAM
−16 GB of internal storage
Flawless playback
2x 4K, 6x 1080p, 10x 720p, or 20x 360p video
playback
Functionality
All-round control plans
−Enables users to publish content and
control screens from a computer, mobile
phone, or tablet.
−Allows users to publish content and control
screens from anywhere, anytime.
−Allows users to monitor screens from
anywhere, anytime.
Switching between Wi-Fi AP and Wi-Fi STA
−In Wi-Fi AP mode, the user terminal
connects to the built-in Wi-Fi hotspot of the
T30. The default SSID is “AP+Last 8 digits
of SN” and the default password is
“12345678”.
−In Wi-Fi STAmode, the user terminal and
the T30 are connected to the Wi-Fi hotspot
of a router.
Synchronous playback across multiple screens
−NTP time synchronization
−GPS time synchronization (The specified
4G module must be installed.)
−RF time synchronization (The specified RF
module must be installed.)
Support for 4G modules
The T30 ships without a 4G module. Users have
to purchase 4G modules separately if needed.
Network connection priority: Wired network > Wi-
Fi network > 4G network When multiple types of
networks are available, the T30 will choose a
signal automatically according to the priority.
Appearance
All product pictures shown in this document are for illustration purpose only. Actual product may vary.
Name
Description
USB 2
A reserved USB port
SIM CARD
SIM card slot
Capable of preventing users from inserting a SIM card in the wrong orientation
RESET 2
Reset connector used to reset the product to its factory settings
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
3
Name
Description
RESET 1
Reset button
Press and hold this button for 5 seconds to reset the product to its factory settings.
RS232
External expansion connector
USB 1
USB (Type B) port
Connects to the control computer for content publishing and screen control.
LED OUT
Gigabit Ethernet outputs
RS485
Sensor connectors
Connect to brightness sensors or temperature and humidity sensors.
RF
RF module connector
WiFi
Wi-Fi antenna connector
Support for switching between Wi-Fi AP and Wi-Fi Sta
ETHERNET
Gigabit Ethernet port
Connects to the control computer, a LAN or public network for content publishing and screen
control.
COM 2
GPS antenna connector
USB 3.0
USB 3.0 (Type A) port
Allows for playback of content imported from a USB drive and firmware upgrade over USB.
The Ext4 and FAT32 file systems are supported. The exFAT and FAT16 file systems are not
supported.
COM 1
4G antenna connector
AUDIO OUT
Audio output connector
POWER
Power input connector
RELAY
3-pin relay control switch
DC: Maximum voltage and current: 30 V, 3 A
AC: Maximum voltage and current: 250 V, 3 A
Two connection methods:
Common switch: The connection method of pins 2 and 3 is not fixed. Pin 1 is not connected
to the wire. On the power control page of ViPlex Express, turn on the circuit to connect pin
2 to pin 3, and turn off the circuit to disconnect pin 2 from pin 3.
Single pole double throw switch: The connection method is fixed. Connect pin 2 to the pole.
Connect pin 1 to the turn-off wire and pin 3 to turn-on wire. On the power control page of
ViPlex Express, turn on the circuit to connect pin 2 to pin 3 and disconnect pin 1 form pin
2, or turn off the circuit to disconnect pin 3 from pin 2 and connect pin 2 to pin 1.
Note: The T30 uses DC power supply. Using the relay to directly control AC is not
recommended. If it is required to control AC, the following connection method is
recommended.
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
4
Name
Description
4G
4G module slot
Indicators
Name
Color
Status
Description
PWR
Red
Staying on
The power supply is working properly.
SYS
Green
Flashing once every 2s
The T30 is functioning normally.
Flashing once every second
The T30 is installing the upgrade package.
Flashing once every 0.5s
The T30 is downloading data from the Internet or copying
the upgrade package.
Staying on/off
The T30 is abnormal.
CLOUD
Green
Staying on
The T30 is connected to the Internet and the connection
is available.
Flashing once every 2s
The T30 is connected to VNNOX and the connection is
available.
RUN
Green
Flashing once every second
No video signal
Flashing once every 0.5s
The T30 is functioning normally.
Staying on/off
FPGA loading is abnormal.
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
5
Dimensions
Tolerance: ±0.3 Unit: mm
If you want to make molds or trepan mounting holes, please contact NovaStar for structural drawings with higher
precision.
Specifications
Electrical Parameters
Input voltage
DC 5 V~12 V
Maximum power consumption
18 W
Storage Capacity
RAM
1 GB
Internal storage
16 GB
Operating Environment
Temperature
–20ºC to +60ºC
Humidity
0% RH to 80% RH, non-condensing
Storage Environment
Temperature
–40°C to +80°C
Humidity
0% RH to 80% RH, non-condensing
Physical Specifications
Dimensions
165.0 mm ×146.4 mm ×21.2 mm
Net weight
179.7 g
Gross weight
369.2 g
Note: It is the total weight of the product, printed
materials and packing materials packed according
to the packing specifications.
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
6
Packing Information
Dimensions
278.0 mm ×63.0 mm ×221.0 mm
List
1x T30
1x Wi-Fi omnidirectional antenna
1x Power connector
2x IPex cables
1x Quick Start Guide
System Software
Android 11.0 operating system software
Android terminal application software
FPGA program
Note: Third-party applications are not supported.
The power consumption may vary according to the setup, environment and use of the product as well as many other
factors.
Media Decoding Specifications
Category
Codec
Supported Image Size
Container
Remarks
JPEG
JFIF file
format 1.02
96×32 pixels to 817×8176 pixels
JPG, JPEG
No support for non-interlaced scan
Support for SRGB JPEG
Support for Adobe RGB JPEG
BMP
BMP
No Restriction
BMP
N/A
GIF
GIF
No Restriction
GIF
N/A
PNG
PNG
No Restriction
PNG
N/A
WEBP
WEBP
No Restriction
WEBP
N/A
Video
Category
Codec
Resolution
Maximum
Frame Rate
Maximum
Bit Rate
(Ideal Case)
File Format
Remarks
MPEG-1/2
MPEG-
1/2
48×48 pixels to
1920×1088 pixels
30fps
80Mbps
DAT, MPG,
VOB, TS
Support for field
coding
MPEG-4
MPEG4
48×48 pixels to
1920×1088 pixels
30fps
38.4Mbps
AVI, MKV,
MP4, MOV,
3GP
No support for
MS MPEG4
v1/v2/v3, GMC
H.264/AVC
H.264
48×48 pixels to
4096×2304 pixels
2304p@60fps
80Mbps
AVI, MKV,
MP4, MOV,
3GP, TS, FLV
Support for field
coding and
MBAFF
MVC
H.264
MVC
48×48 pixels to
4096×2304 pixels
2304p@60fps
100Mbps
MKV, TS
Support for
Stereo High
Profile only
H.265/HEVC
H.265/
HEVC
64×64 pixels to
4096×2304 pixels
2304p@60fps
100Mbps
MKV, MP4,
MOV, TS
Support for
Main Profile,
Tile & Slice
GOOGLE
VP8
48×48 pixels to
30fps
38.4Mbps
WEBM, MKV
N/A
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
7
Category
Codec
Resolution
Maximum
Frame Rate
Maximum
Bit Rate
(Ideal Case)
File Format
Remarks
VP8
1920×1088 pixels
GOOGLE
VP9
VP9
64×64 pixels to
4096×2304 pixels
60fps
80Mbps
WEBM, MKV
N/A
H.263
H.263
SQCIF (128×96)
QCIF (176×144)
CIF (352×288)
4CIF (704×576)
30fps
38.4Mbps
3GP, MOV,
MP4
No support for
H.263+
VC-1
VC-1
48×48 pixels to
1920×1088 pixels
30fps
45Mbps
WMV, ASF,
TS, MKV, AVI
N/A
MOTION
JPEG
MJPEG
48×48 pixels to
1920×1088 pixels
60fps
60Mbps
AVI
N/A
FCC Caution
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient of relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Important Note:
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Country Code selection feature to be disabled for products marketed to the US/Canada.
The antenna must be installed such that 20 cm is maintained between the antenna and users, and
The transmitter module may not be co-located with any other transmitter or antenna.
As long as the three conditions above are met, further transmitter testing will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required with
this module installed.
Important Note:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another
transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
8
product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including
the transmitter) and obtaining a separate FCC authorization.
End Product Labeling:
The final end product must be labeled in a visible area with the following “Contains FCC ID:2AG8JT60”
If the FCC identification number is not visible when the module is installed inside another device, then the outside of
the device into which the module is installed must also display a label referring to the enclosed module. This exterior
label can use wording such as the following; Contains Transmitter Module FCC ID: 2AG8JT60.
Manual Information to the End User:
The OEM integrator has to be aware not provide information to the end user regarding how to install or remove this
RF module in the user's manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
When the module is installed inside another device, the user manual of this device must contain below warning
statements;
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
−This device may not cause harmful interference,
−This device must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment. The devices must be installed and used in strict accordance with the
manufacturer’s instructions as described in the user documentation that comes with the product.
ISED Statement
English: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) This device may not cause interference, and (2) This device must accept any
interference, including interference that may cause undesired operation of the device. The digital apparatus complies
with Canadian CAN ICES-3 (B)/NMB-3(B).
French: Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire
de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest
susceptible d'encompromettre le fonctionnement.
This radio transmitter (ISED certification number: 23873-T60) has been approved by Industry Canada to operate with
the antenna types listed with the maximum permissible gain indicated. Antenna types not included in this list, having
a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Le présent émetteur radio (ISED certification number: 23873-T60) a étéapprouvépar Industrie Canada pour
fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne
non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
Radiation Exposure Statement
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Déclaration d'exposition aux radiations
Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement non contrôlé. Cet
équipement doit être installéet utiliséàdistance minimum de 20cm entre le radiateur et votre corps.
This device is intended only for OEM integrators under the following condition:
The transmitter module may not be co-located with any other transmitter or antenna.
As long as the condition above is met, further transmitter test will not be required. However, the OEM integrator is still
responsible for testing their end-product for any additional compliance requirements required with this module
installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes:
Le module émetteur peut ne pas être coïmplantéavec un autre émetteur ou antenne.
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
9
Tant que les 1 condition ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas
nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes
exigences de conformitésupplémentaires requis pour ce module installé.
Important Note:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another
transmitter), then the Canada authorization is no longer considered valid and the IC cannot be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including
the transmitter) and obtaining a separate Canada authorization.
Note Importante:
Dans le cas oùces conditions ne peuvent être satisfaites (par exemple pour certaines configurations d'ordinateur
portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est plus considéré
comme valide et l' IC ne peut pas être utilisésur le produit final. Dans ces circonstances, l'intégrateur OEM sera
chargéde réévaluer le produit final (y compris l'émetteur) et l'obtention d'une autorisation distincte au Canada.
End Product Labeling
The final end product must be labeled in a visible area with the following: Contains IC: 23873-T60.
Plaque signalétique du produit final
Le produit final doit être étiquetédans un endroit visible avec l'inscription suivante: Contient des IC: 23873-T60
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this
RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Manuel d'information àl'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations àl'utilisateur final quant àla façon d'installer
ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme
indiquédans ce manuel.
Radiation Exposure Statement
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Cetéquipementestconforme Canada limitesd'exposition aux radiations dans un environnement non contrôlé.
Cetéquipementdoitêtreinstalléet utiliséàdistance minimum de 20cm entre le radiateur et votre corps.
Integration Instructions for Host Product Manufacturers
According to KDB 996369 D03 OEM Manual v01
List of applicable FCC rules
FCC Part 15 Subpart C 15.247 & 15.209
Specific operational use conditions
The module is a 2.4G WiFi module.
Operation Frequency: 2412-2462 MHz
Number of Channel: 11
Modulation: DSSS, OFDM
Type: Helix Antenna
Gain: 5.03 dBi Max.
The module can be used for mobile or portable applications with a maximum 5.03dBi antenna. The host
manufacturer installing this module into their product must ensure that the final composite product complies with
the FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter
operation. The host manufacturer has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user's manual of the end product which integrates this module. The end
user manual shall include all required regulatory information/warning as show in this manual.
Limited module procedures
XI'AN NOVASTAR TECH CO., LTD.

Taurus Series Multimedia Player T30 Specifications
www.novastar.tech
10
Not applicable. The module is a Single module and complies with the requirement of FCC Part 15.212.
Trace antenna designs
Not applicable. The module has its own antenna, and doesn’t need a host’s printed board micro strip trace
antenna etc.
RF exposure considerations
The module must be installed in the host equipment such that at least 20cm is maintained between the antenna
and users’ body; and if RF exposure statement or module layout is changed, then the host product manufacturer
required to take responsibility of the module through a change in FCC ID or new application. The FCC ID of the
module cannot be used on the final product. In these circumstances, the host manufacturer will be responsible
for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization.
Antennas
Antenna Specification are as follows:
Type: Helix Antenna
Gain: 5.03 dBi
This device is intended only for host manufacturers under the following conditions: The transmitter module may
not be co-located with any other transmitter or antenna; the module shall be only used with the internal
antenna(s) that has been originally tested and certified with this module. The antenna must be either
permanently attached or employ a ‘unique’ antenna coupler.
As long as the conditions above are met, further transmitter test will not be required. However, the host
manufacturer is still responsible for testing their end-product for any additional compliance requirements
required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
Label and compliance information
Host product manufacturers need to provide a physical or e-label stating “Contains FCC ID: 2AG8JT60” with
their finished product.
Information on test modes and additional testing requirements
Operation Frequency: 2412-2462 MHz
Number of Channel: 11
Modulation: DSSS, OFDM
Host manufacturer must perform test of radiated & conducted emission and spurious emission, etc. according to
the actual test modes for a stand-alone modular transmitter in a host, as well as for multiple simultaneously
transmitting modules or other transmitters in a host product. Only when all the test results of test modes comply
with FCC requirements, then the end product can be sold legally. 2.10 Additional testing, Part 15 Subpart B
disclaimer. The modular transmitter is only FCC authorized for FCC Part 15 Subpart C 15.247 & 15.209 and that
the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not
covered by the modular transmitter grant of certification. If the grantee markets their product as being Part 15
Subpart B compliant (when it also contains unintentional-radiator digital circuity), then the grantee shall provide
a notice stating that the final host product still requires Part 15 Subpart B compliance testing with the modular
transmitter installed.
XI'AN NOVASTAR TECH CO., LTD.

XI'AN NOVASTAR TECH CO., LTD.
