IBASE Technology Signature Book SI-102-424 Series User manual

www.ibase.com.tw
IBASE Technology Inc.
SI-102-424 Series
User Manual

Copyright © 2013 IBASE Technology Inc. All Rights Reserved. 2
2
SI-102-424 User Manual
Revision
Release Date
V1.0
2015/05/14

1
SI-102-424 User Manual
Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
No part of thismanual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE”).
Products and corporate namesmentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, themanufacturermakes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

2
SI-102-424 User Manual
Table of Contents
Setting up your system ........................................................................................................3
Care during use ....................................................................................................................4
Acknowledgments ...............................................................................................................5
CHAPTER 1 INTRODUCTION.................................................................................................6
1.1 General Description .......................................................................................................6
1.2 System Specifications.....................................................................................................7
1.2.1 Hardware Specifications……………………………………………………………………………………….7
1.2.2 Dimensions .................................................................................................................8
1.2.3 I/O View......................................................................................................................9
1.3 Exploded View of the SI-102-424 Assembly................................................................10
1.3.1 Parts Description.......................................................................................................10
1.4 Packing List...................................................................................................................10
1.4.1 Optional Items ..........................................................................................................11
1.5 HARDWARE INSTALLATION..........................................................................................12
1.5.1 Installing the Wireless Module.................................................................................12
1.5.2 Installing the mSATA Module....................................................................................14
1.5.3 Installing the HDMI cable holder…………………………………………………………………………16
CHAPTER 2 MOTHERBOARD INTRODUCTION....................................................................17
2.1 Installing the Memory .................................................................................................17
2.2 Setting the Jumpers .....................................................................................................18
2.3 Connectors on IB923....................................................................................................19
CHAPTER 3 BIOS SETUP......................................................................................................21
3.1 BIOS Introduction.........................................................................................................21
3.2 BIOS Setup....................................................................................................................21
CHAPTER 4 DRIVERS INSTALLATION ..................................................................................38
4.1 VGA Drivers Installation...............................................................................................38
4.2 Realtek HD Audio Driver Installation...........................................................................42
4.3 LAN Drivers Installation ...............................................................................................43
Appendix............................................................................................................................46
Mounting SI-102-424 to the Wall ......................................................................................46
Wall Mounting Requirements............................................................................................47
Selecting the Location........................................................................................................47
SI-102-424 Mounting Bracket Solution..............................................................................48

3
SI-102-424 User Manual
Safety Information
Your SI-102-424 is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions
Setting up your system
Read and follow all instructions in the documentation before you operate your
system.
Do not use this product near water.
Set up the system on a stable surface. Do not secure the system on any unstable
plane.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
This system should be operated from the type ofpower indicated on themarking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
Use this product in environments with ambient temperatures between 0˚C and
45˚C.
If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENTWHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20°C (-4°F) OR ABOVE 80°C
(176°F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.

4
SI-102-424 User Manual
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.
The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by themanufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
5
IBASE Technology Inc.
Acknowledgments
AMI is a registered trademark of AMI Software International, Inc.
AMD and ATI are registered trademarks of AMD Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
FINTEK is a registered trademark of FINTEK Electronics Corporation.
REALTEK is a registered trademark of REALTEK Electronics Corporation.
All other product names or trademarks are properties of their respective
owners.

6
SI-102-424 User Manual
CHAPTER 1 INTRODUCTION
1.1 General Description
The “Signature Book™” SI-102-424 is a professional fanless digital signage
system powered by the new AMD Embedded new generation G-Series quad-core
APU with DASH compliance for remote control, and compact & slim design. It
supports 2x HDMI, 1x RJ45 for LAN, 1x RJ45 for RS232, 1x USB2.0 and 2x USB3.0
ports to give a wide selection for data communication in display applications.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
7
IBASE Technology Inc.
1.2 System Specifications
1.2.1 Hardware Specifications
Model Name
SI-102-424
System Mainboard
IB923-424
CPU
AMD Embedded G-Series SoC; 4 Cores @ 2.4GHz APU
FT3b BGApackage
Chipset
SoC Integrated
Memory
1x DDR3 1866 MHz SO-DIMM, Max. 8GB (Non-ECC)
I/O Interface
2x HDMI 1.4a
2x USB 3.0 ports, 1x USB 2.0 port
1x RJ45 for LAN, 1x RJ45 for RS232
2x Microjack audio connectors for Line-in / Line-out
Power LED, 1x power on/off button
1x DC jack
Storage
1 x mSATA
Expansion Slots
1x mPCIe(x1) for WiFi + Bluetooth, 3G, and TV tuner
options
1x UIM/SIM card slot (for 3G/LTE adapter in mPCIe slot)
Power Supply
+12V DC-in with 60W power adaptor
Construction
Aluminum + SGCC
Chassis Color
Black & White
Mounting
STD system bracket
Dimensions
220mm(W) x 147mm(D) x 25mm(H)
8.66”(W) x 5.79”(D) x 0.98”(H)
Operating Temperature
0°C~ 45°C (32°F~113°F)
Storage Temperature
-20°~ 80°C (-4°F~176°F)
Relative Humidity
5~90% @45°C (non-condensing)
Vibration
mSATA: 5 Grms/5~500Hz random operation
RoHS
Available
Certification
CE/FCC, VCCI class B, UL & CCC
‧ This specification is subject to change without prior notice.

8
SI-102-424 User Manual
1.2.2 Dimensions

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
9
IBASE Technology Inc.
1.2.3 I/O View
Item
Connector
Item
Connector
1
Line-in
6
2x USB 3.0
2
Line-out
7
1x USB 2.0
3
2x HDMI 1.4a
8
12V DC jack
4
1x RJ45 for RS232
9
Power LED
5
1x RJ45 for LAN
10
Power on/off button

10
SI-102-424 User Manual
1.3 Exploded View of the SI-102-424 Assembly
1.3.1 Parts Description
Part No.
Description
Part No.
Description
1
IB923-424 motherboard
2
SI-102-424 Base
3
SI-102-424 Cover
4
SI-102-424 heat sink
5
Screw-B30
1.4 Packing List
Item No.
Description
Qty
1
Driver CD
1
2
Power adaptor
1
3
Power Cord
1

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
11
IBASE Technology Inc.
1.4.1 Optional Items
WiFi Solution
Description
QCOM WiFi
module
Wireless; PCI-E Mini Card 802.11B/G/N
[AW-NE238H] (A008WLAWNE238H000P)
External Antenna
(2pcs)
WiFi Antenna (A055RFA02C2M20800P)
Internal cable
(2pcs)
Internal Antenna 100mm [BTC130-1-70B-100]RoHS
(A055RFA0000021000P)
Bracket
MPCIE-EXT V-B2 Bracket RoHS
(SC2MPCIEEXT0B2100P)
3G Solution
Description
ZU 202
Wireless; 3.75G UMTS/HSPA [ZU202] RoHS
(A008WIRELESS00520P)
ZU 200
Wireless; 3.75G UMTS/HSPA & GPS Module
[ZU200] RoHS (A008WIRELESS00510P)
WW-350U
Wireless; 3.75G UMTS/HSPA [NAVISYS WW-350U]
RoHS (A008WIRELESS00530P)
Cable
Cable; Antenna-2 30CM P 2pcs
(C501ANT0200300000P)
Antenna
Antenna; 3G, P, 2pcs (A055ANT0921Q2P000P)
COM Port Cable
Description
EXT-481
Cable; EXT-481 2-HD 8C 90CM; RJ45
Jack-8M=>DSU-9M RoHS (C501EXT4810902000P)
EXT-424
Cable; EXT-424 2-HD 8C 90CM; RJ45
Jack-8M=>DSU-9F RoHS (C501EXT4240902000P)
EDID Dongle
Description
H8246JT021-001
EDID Emulator Dongle (HDMI), Adapter;
HDMI 19P A/M TO A/F (A025HDMI001010000P)

12
SI-102-424 User Manual
1.5 HARDWARE INSTALLATION
1.5.1 Installing the optional Wireless Module
1. Remove the six screws on the sides that are used to secure the white cover to the
chassis. Once all the screws are removed, from the side, push the cover forward to
remove it.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
13
IBASE Technology Inc.
2. Push the WIFI module into the slot. Screw two screws to secure the module in the
slot.
** The picture is only for reference only. Please make the object as the standard.

14
SI-102-424 User Manual
1.5.2 Installing the mSATA Module
1. Remove the six screws on the sides that are used to secure the white cover to the
chassis. Once all the screws are removed, from the side, push the cover forward to
remove it.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
15
IBASE Technology Inc.
2. Push the mSATA module into the slot. Screw two screws to secure the module in
the slot.
** The picture is only for reference, please make the object as the standard.

16
SI-102-424 User Manual
1.5.3 Installing the Optional HDMI cable holder
Install the HDMI cable holder and screw two M3 screws as shown.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
17
IBASE Technology Inc.
CHAPTER 2 MOTHERBOARD INTRODUCTION
2.1 Installing the Memory
The IB923 board supports one DDR3 memory socket J6 for a maximum total memory
of 8GB DDR3 memory type.
Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and perform the
following steps:
1. Hold the DDR3 module so that the key of the DDR3 module aligned with that on
the memory slot.
2. Gently push the DDR3 module in an upright position until the clips of the slot close
to hold the DDR3 module in place when the DDR3 module touches the bottom of
the slot.
3. To remove the DDR3 module, press the clips with both hands.

18
SI-102-424 User Manual
2.2 Setting the Jumpers
Jumpers are used on IB923 to select various settings and features according to
your needs and applications. Contact your supplier if you have doubts about the best
configuration for your needs. The following lists the connectors on IB923 and their
respective functions.
Jumper Locations on IB923
SW1: Power On Button
LED6 : Power On LED
JBAT1: Clear CMOS Contents
JBAT1
Setting
Function
Pin 1-2
Short/Closed
Normal
Pin 2-3
Short/Closed
Clear CMOS
