U ser’s ma nua l (sh o r t)
NDR-BA2208-II
NDR-BB2208
NDR-BA2416
NDR-BA4104-II
NDR-BB4104
NDR-BA4208
NDR-BA4416

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
2
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of following directives and national
regulations implementing the directives:
 Electromagnetic compatibility EMC 2004/108/EC.
 Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well
as 75VDC and 1500VDC.
WEEE Directive 2002/96/EC
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European Directive on Waste Electrical and Electronic
Equipment (2002/96/EC) and further amendments. By ensuring this product is disposed of correctly,
you will help to prevent potential negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance
may not be treated as household waste. It shall be handed over to the applicable collection point for the
waste electrical and electronic equipment for recycling purpose. For more information about recycling
of this product, please contact your local authorities, your household waste disposal service or the shop
where you purchased the product.
RoHS Directive 2002/95/EC
Concerning for human health protection and friendly environment, we assure that our products falling
under RoHS Directive regulations, regarding the restriction of the use of hazardous substances in
electrical and electronic equipment, were designed and manufactured in compliance with mentioned
regulation. Simultaneously, we claim that our products were tested and do not contain hazardous
substances exceeding limits which could have negative impact on human health or natural
environment.
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed
for self installation in households by individuals without technical knowledge.
The manufacturer is not responsible for defects and damages resulted from improper or inconsistent
with user’s manual installation of the device in the system.
IMPORTANT SAFEGUARDS AND WARNINGS

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
3
ATTENTION!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT PROVISIONED FOR THE GIVEN
PRODUCT IN ITS USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE
PRODUCT, OR THAT ARISES FROM THE NORMAL APPLICATION OF THE PRODUCT, ITS
MANUFACTURER MUST BE CONTACTED OR THE RESPONSIBILITY OF THE
MANUFACTURER FOR THE RESULTS OF SUCH AN ACTION SHELL BE EXCLUDED.
1. The installation of this device should be made by a qualified service person or a professional safety
system installer.
2. Device mustn’t be placed in places where ventilating holes are partially or fully covered.
3. User’s interference inside the device is not allowed and is unnecessary as it does not have any
systems which require adjusting or which are suitable for self-repair. You mustn’t dismantle the
recorder or remove any single fastening screws. If any repairs are necessary contact the service.
The device must be take care of and protected against any mechanical damage.
4. The device has to be protected against humidity and dust. In case the recorder had a contact with
water react immediately: switch off the power supply and contact the authorised Novus service. If
the device gets dirty it might get damaged or electrocute someone.
5. The device can only be cleaned with a damp cloth after the power supply has been switched off.
Avoid strong detergents (liquids and sprays). Mild detergents can be used if the recorder becomes
very dirty.
6. Power supply unit cords and signal cords should be laid in a way that eliminates the risk of
mechanical damage; special attention should be paid to the plug. Be careful not to overload sockets
and extension cords so that there is no fire.
7. To avoid devices’s damage vision and control signals should be equipped with systems protecting
against disturbances, over voltage and atmospheric discharge that are in compliance with Polish
regulations. It is also advised to use ground loop isolators.
8. The device mustn’t be used in conditions which do not fulfil operating requirements as far as power
supply, relative humidity or air temperature are concerned.
9. You cannot allow any metal objects get inside the recorder. It might cause serious damage. If a
metal object gets inside the device contact the authorised Novus service immediately.
10. The manufacturer does not bear responsibility for damage or loss of data stored on HDDs or other
media occurred during the usage of the product.
Attention!
Technical changes reserved without prior notice and printing errors possible.
IMPORTANT SAFEGUARDS AND WARNINGS

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
4
TABLE OF CONTENT
TABLE OF CONTENT................................................................................................................ 4
1. FOREWORD INFORMATION ............................................................................................ ..5
1.1. Main characteristics............................................................................................................ 5
1.2. NDR-BA2208-II, and NDR-BA4104-II recorder’s technical data ................................. ...6
1.3 NDR-BB2208, and NDR-BB4104 recorder’s technical data ........................................... ...7
1.4. NDR-BA2416 and NDR-BA4416 recorder’s technical data.......................................... ...8
1.5. NDR-BA4208 recorder’s technical data.......................................................................... ...9
1.6. Package contents ........................................................................................................... ...10
2. STARTING THE DEVICE.................................................................................................... 11
2.1. Electrical connection and other rear panel elements of NDR-BA-2208-II DVR........... 11
2.2. Electrical connection and other rear panel elements of NDR-BB-2208 DVR ............... 12
2.3. Electrical connection and other rear panel elements of NDR-BA2416 DVR ................ 13
2.4. Electrical connection and other rear panel elements of NDR-BA4104-II DVR ............ 14
2.5. Electrical connection and other rear panel elements of NDR-BA4104 DVR ................ 15
2.6. Electrical connection and other rear panel elements of NDR-BA4208 DVR ................ 16
2.7. Electrical connection and other rear panel elements of NDR-BA4416 DVR ................ 17
2.8. HDD mounting .............................................................................................................. 18
2.9. Turning on the power..................................................................................................... 20
3. RECORDER’S OPERATION ............................................................................................... 21
3.1. Front panel description..................................................................................................... 21
3.2. Controlling via USB mouse .......................................................................................... ...22
3.3. Controlling via IR remote controller ............................................................................. ...22
4. RECORDER’S MENU ........................................................................................................... 24
4.1. Startup wizard .................................................................................................................. 24
4.2. Menu operating ............................................................................................................. ...26
4.3. Setting English language ............................................................................................... ...27

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
5
1. FOREWORD INFORMATION
1.1. Main characteristics
 Quadruplex: simultaneous recording, live monitoring, playback or backup and networking
 Linux-based operating system
 Real-time display
 1080p HDMI socket
 Recording speed up to 25 FPS per channel
 H.264 compression
 Recording resolution: 720 x 576, 720 x 288, 360 x 288
 Advanced schedule recording & motion detection functions
 Pre-alarm & post-alarm functions
 Audio recording
 PTZ control directly from the device or via the network
 Control protocols: N-Control, Pelco-D, Pelco-P and other
 Supports remote control by NV-KBD70 and NV-KBD30 keyboards
 Supports up to 2 SATA HDDs (for NDR-BA4416 and NDR-BA4208 ) or 1 SATA HDD (for
NDR-BA2208-II,NDR-BB2208 ,NDR-BA2416, NDR-BA4104-II,NDR-BB4104)
 S.M.A.R.T function
 Backup onto USB Flash Memory through USB port & via the network
 Backup as *.AVI files
 Advanced search of recorded images (by time or event)
 Networking (live monitoring, playback, archiving & alarm event e-mail notification, changing
DVR’s settings via the IE web browser)
 Dual stream; two independent network streams (SUBSTREAM and MASTERSTREAM) for
each channel
 Software: CMS application for remote administration, live monitoring and recorded data search
 User friendly, multi-lingual graphical user interface
 Mobile platforms supported
 Mask function
 Event log
 Snapshot function exporting current frame to the .jpg file
 Supports settings import/export
 IP addresses filtering function
 PC mouse control (in-set included)
 12 VDC (100 ~ 240 VAC/12 VDC PSU in-set included)
FOREWORD INFORMATION

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
6
1.2. NDR-BA2208-II and NDR-BA4104-II recorder’s technical data
FOREWORD INFORMATION
Model NDR-BA2208-II NDR-BA4104-II
Operation Mode Quadrupleks
Operating System Linux
Video Input 8 x BNC 4 x BNC
Video Output Main (split screen, full screen, sequence):
1 x BNC, 1 x VGA ,1 x HDMI
Alarm Input -
Alarm Output -
Audio Input 2
Audio output 1
Recording speed Up to 100 fps(720x576) + 100 fps(360x288) Up to 100 fps (720 x 576)
Compression H.264
Recording Resolution 352 x 288,720x288 ,720 x 576
Recording Mode Time-lapse, Event Alarm, Motion detection, Schedule
Display Speed Up to 200 fps (real time) Up to 100 fps (real time)
Display Screen 1, 4, 6, 8, 1+5, 1+7, sequence, digital zoom
of a selected screen area: 4x
1,4,sequence, digital zoom of a selected
screen area: 4x
Motion Detection 22 x 15 grid, with sensitivity defined individually for each channel
Video Loss Detection Yes
Schedule Recording individual settings for: each day, each camera, possibility of combining individual
recording modes
Recorded Data Search By date/time, events ( Motion detection) , schedule
Event History Log Yes
Time Synchronization Automatic time synchronization with NTP server
HDD Supports 1 HDD SATA
Backup HDD or USB Flash Memory through USB port, through the network
External Ports
1 x Ethernet - RJ-45 interface,
10/100 Mbit/s, 2 x USB 2.0 - for Flash Memory and PC mouse,
1 x RS-485 - for PTZ cameras or PTZ keyboard
PTZ Control Directly from the device or via the network
Protocol N-Control, Pelco-D, Pelco-P and others
Control Front panel, NV-KBD70 and NV-KBD30 keyboards, Network ,IR remote control ,
USB PC mouse (included)
Menu Multi-lingual On Screen Display (OSD)
Software CMS, Internet Explorer, Super Live Pro (iPhone, Android, BlackBerry),
Pocket Camera (Windows Mobile, Symbian)
User Authorization Creation of user accounts with varying privileges, password protection
Power Supply 12 VDC (100~240 VAC/12 VDC PSU in-set included)
Power Consumption max. 25 W with HDD
Operating Temperature 0°C ~ 50°C
Relative Humidity 10% ~ 90% (non-condensing)
Dimensions (mm) 255 (W) x 42 (H) x 210 (D)
Weight 2 kg (without HDD)

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
7
1.3. NDR-BB2208 and NDR-BB4104 recorder’s technical data
FOREWORD INFORMATION
Model NDR-BB2208 NDR-BB4104
Operation Mode Quadrupleks
Operating System Linux
Video Input 8 x BNC 4 x BNC
Video Output
Main (split screen, full screen, sequence):
1 x BNC, 1 x VGA, 1 x HDMI
Spot (full screen, sequence): 1 x BNC
Alarm Input 8 4
Alarm Output 1
Audio Input 4
Audio output 1
Recording speed Up to 125 fps(720x576) /
100 fps(720x576) + 100 fps(360x288) Up to 100 fps (720 x 576)
Compression H.264
Recording Resolution 352 x 288,720x288 ,720 x 576
Recording Mode Time-lapse, Event Alarm, Motion detection, Schedule
Display Speed Up to 200 fps (real time) Up to 100 fps (real time)
Display Screen 1, 4, 6, 8, 1+5, 1+7, sequence, digital zoom
of a selected screen area: 4x
1,4,sequence, digital zoom of a selected
screen area: 4x
Motion Detection 22 x 15 grid, with sensitivity defined individually for each channel
Video Loss Detection Yes
Schedule Recording individual settings for: each day, each camera, possibility of combining individual
recording modes
Recorded Data Search By date/time, events (Alarm, Motion detection) , schedule
Event History Log Yes
Time Synchronization Automatic time synchronization with NTP server
HDD Supports 1 HDD SATA
Backup HDD or USB Flash Memory through USB port, through the network
External Ports
1 x Ethernet - RJ-45 interface,
10/100 Mbit/s, 2 x USB 2.0 - for Flash Memory and PC mouse,
1 x RS-485 - for PTZ cameras or PTZ keyboard
PTZ Control Directly from the device or via the network
Protocol N-Control, Pelco-D, Pelco-P and others
Control Front panel, NV-KBD70 and NV-KBD30 keyboards, Network ,
IR remote control (included), USB PC mouse (included)
Menu Multi-lingual On Screen Display (OSD)
Software CMS, Internet Explorer, Super Live Pro (iPhone, Android, BlackBerry),
Pocket Camera (Windows Mobile, Symbian)
User Authorization Creation of user accounts with varying privileges, password protection
Power Supply 12 VDC (100~240 VAC/12 VDC PSU in-set included)
Power Consumption max. 25 W with HDD
Operating Temperature 0°C ~ 50°C
Relative Humidity 10% ~ 90% (non-condensing)
Dimensions (mm) 300 (W) x 65 (H) x 280 (D)
Weight 2 kg (without HDD)

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
8
1.4. NDR-BA2416 and NDR-BA4416 recorder’s technical data
FOREWORD INFORMATION
Model NDR-BA2416 NDR-BA4416
Operation Mode Quadrupleks
Operating System Linux
Video Input 16 x BNC 16 x BNC
Video Output
Main (split screen, full screen, sequence):
1 x BNC, 1 x VGA, 1 x HDMI
Spot (full screen, sequence): 1 x BNC
Alarm Input 16
Alarm Output 1 relay
Audio Input 4
Audio output 1
Recording speed Up to 400 fps (360 x 288) Up to 400 fps (720 x 576)
Compression H.264
Recording Resolution 360 x 288, 720 x 288, 720 x 576
Recording Mode Time-lapse, Event Alarm, Motion detection, Schedule
Display Speed Up to 400 fps (real time) Up to 400 fps (real time)
Display Screen 1, 4, 6, 8, 16, 1+5, 1+7, 1+12, sequence,
digital zoom of a selected screen area: 4x
1, 4, 6, 8, 16, 1+5, 1+7, 1+12, sequence,
digital zoom of a selected screen area: 4x
Motion Detection 22 x 15 grid, with sensitivity defined individually for each channel
Video Loss Detection Yes
Schedule Recording individual settings for: each day, each camera, possibility of combining individual
recording modes
Recorded Data
Search By date/time, events (Alarm, Motion detection)
Event History Log Yes
Time Synchronization Automatic time synchronization with NTP server
HDD Supports 1 HDD SATA Supports up to 2 HDD SATA
Backup HDD or USB Flash Memory through USB port, through the network
External Ports
1 x Ethernet - RJ-45 interface,
10/100/1000 Mbit/s, 2 x USB 2.0 - for Flash Memory and PC mouse,
2 x RS-485 - for PTZ cameras and PTZ keyboard
PTZ Control Directly from the device or via the network
Protocol N-Control, Pelco-D, Pelco-P and others
Control Front panel, NV-KBD70 and NV-KBD30 keyboards, IR remote control (included),
Network , USB PC mouse (included)
Menu Multi-lingual On Screen Display (OSD)
Software CMS, Internet Explorer, Super Live Pro (iPhone, Android, BlackBerry),
Pocket Camera (Windows Mobile, Symbian)
User Authorization Creation of user accounts with varying privileges, password protection
Power Supply 12 VDC (100~240 VAC/12 VDC PSU in-set included)
Power Consumption max. 30 W with HDD max. 40 W with 2 HDDs
Operating
Temperature 0°C ~ 50°C
Relative Humidity 10% ~ 90% (non-condensing)
Dimensions (mm) 300 (W) x 65 (H) x 280 (D) 430 (W) x 65 (H) x 300 (D)
Weight 2 kg (without HDD) 4 kg (without HDD)

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
9
1.5. NDR-BA4208 recorder technical data
FOREWORD INFORMATION
Model NDR-BA4208
Operation Mode Quadrupleks
Operating System Linux
Video Input 8x BNC
Video Output
Main (split screen, full screen, sequence):
1 x BNC, 1 x VGA, 1 x HDMI
Spot (full screen, sequence): 1 x BNC
Alarm Input 8
Alarm Output 1 relay
Audio Input 4
Audio output 1
Recording speed Up to 200 fps (720 x 576)
Compression H.264
Recording Resolution 360 x 288 , 720 x 288 ,720 x 576
Recording Mode Time-lapse, Event Alarm, Motion detection, Schedule
Display Speed Up to 200 fps (real time)
Display Screen 1, 4, 6, 8, 1+5, 1+7, sequence, digital zoom of a selected screen area: 4x
Motion Detection 22 x 15 grid, with sensitivity defined individually for each channel
Video Loss Detection Yes
Schedule Recording individual settings for: each day, each camera, possibility of combining individual re-
cording modes
Recorded Data
Search By date/time, events (Alarm, Motion detection)
Event History Log Yes
Time Synchronization Automatic time synchronization with NTP server
HDD Supports up to 2 HDD SATA
Backup DVD (optional),HDD or USB Flash Memory through USB port, through the network
External Ports
1 x Ethernet - RJ-45 interface,
10/100 Mbit/s, 2 x USB 2.0 - for Flash Memory and PC mouse,
2 x RS-485 - for PTZ cameras and PTZ keyboard
PTZ Control Directly from the device or via the network
Protocol N-Control, Pelco-D, Pelco-P and others
Control Front panel, NV-KBD70 and NV-KBD30 keyboards, IR remote control (included), Net-
work , USB PC mouse (included)
Menu Multi-lingual On Screen Display (OSD)
Software CMS, Internet Explorer, Super Live Pro (iPhone, Android, BlackBerry),
Pocket Camera (Windows Mobile, Symbian)
User Authorization Creation of user accounts with varying privileges, password protection
Power Supply 12 VDC (100~240 VAC/12 VDC PSU in-set included)
Power Consumption max. 40 W with 2 HDDs
Operating Tempera-
ture 0°C ~ 50°C
Relative Humidity 10% ~ 90% (non-condensing)
Dimensions (mm) 430 (W) x 65 (H) x 300 (D)
Weight 4 kg (without HDD)

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
10
1.6. Package contents
Unpack the device carefully. After unpacking, please ensure that package contains the following items:
If any of the elements has been damaged during transport, pack all the elements back into the original
packaging and contact your supplier.
WARNING!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning on the device immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
CD with a full version of user’s
manual and software tools
NDR-BAxxxx DVR
Mouse
Short user’s
manual
Power supply
12VDC
Power cord
Screws
FOREWORD INFORMATION
IR remote control
(NDR-BA4416 , NDR-BA2416
NDR-BA4208,
NDR-BB4104,NDR-BB2208))
HDD SATA
cables

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
11
2. STARTING THE DEVICE
2.1. Electrical connection and other rear panel elements of NDR-BA2208-II DVR
1. RS-485: one RS-485 bus port for connecting external keyboard or PTZ cameras
(RS485: A+, B-)
Note:
Only one of the devices may be connected at a time.
2 LAN: RJ-45 connector port for connecting to the local network and internet.
3. USB: USB 2.0 port for external Flash memory and mouse connection.
4. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
5. VIDEO OUT: Main monitor connectors,
6. VIDEO IN: 8 video inputs for connecting video signal sources to the DVR.
7. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
8. AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
9. DC12V: 12V DC power socket for connecting included power adaptor.
10. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
BNC, please press and hold the ESC button for 5sec.
STARTING THE DEVICE
12 345
67 8 910

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
12
2.2. Electrical connection and other rear panel elements of NDR-BB2208 DVR
1. RS-485: one RS-485 bus port for connecting external keyboard or PTZ cameras
(RS485: A+, B-)
Note:
Only one of the devices may be connected at a time.
2. DC12V: 12V DC power socket for connecting included power adaptor.
3. USB: USB 2.0 port for external Flash memory and mouse connection.
4 LAN: RJ-45 connector port for connecting to the local network and internet.
5. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
6. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
7. VIDEO OUT: Main monitor connectors,
8. AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
9. VIDEO IN: 8 video inputs for connecting video signal sources to the DVR.
10. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
11.ALARM IN: 8 alarm inputs, which may be set either as normally open (N.O.) or normally
closed (N.C.). In order to detect the alarm, signal should last for minimum
0.5sec .
12. ALARM OUT : Alarm relay output, max. load capacity of the outputs is 0,5A/125VAC and
1A/30VDC. (NO, COM)
13. SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
14. POWER SWITCH: DVR power switch.
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
BNC, please press and hold the ESC button for 5sec.
STARTING THE DEVICE
1 2345 6789 10 1112 13 14

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
13
2.3. Electrical connection and other rear panel elements of NDR-BA2416 DVR
1. I/O Terminal block: Input, output and RS-485 port .
 RS-485: two RS-485 bus ports for connecting external keyboard (K/D:
A+, B-) and PTZ cameras (P/Z: Y+, Z-)
 ALARM IN: 16 alarm inputs, which may be set either as normally open
(N.O.) or normally closed (N.C.). In order to detect the alarm, signal
should last for minimum 0.5sec .
 ALARM OUT(NO, COM): Alarm relay output, max. load capacity of
the outputs is 0,5A/125VAC and 1A/30VDC.
 +5V, GND: Alarm indicator power supply, feeding +5V
2 LAN: RJ-45 connector port for connecting to the local network and internet.
3. USB: USB 2.0 port for external Flash memory and mouse connection.
4. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
5. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
6. VIDEO OUT: Main monitor connectors,
7. SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
8. VIDEO IN: 16 video inputs for connecting video signal sources to the DVR.
9. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
10. AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
11. POWER SWITCH: DVR power switch.
12. DC12V: 12V DC power socket for connecting included power adaptor.
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
HDMI or BNC, please press and hold the ESC button for 5sec.
STARTING THE DEVICE
2 8 3 1 4 5 6
7 10
9
12
11

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
14
2.4. Electrical connection and other rear panel elements of NDR-BA4104-II DVR.
1. RS-485: one RS-485 bus port for connecting external keyboard or PTZ cameras
(RS485: A+, B-)
Note:
Only one of the devices may be connected at a time.
2 LAN: RJ-45 connector port for connecting to the local network and internet.
3. USB: USB 2.0 port for external Flash memory and mouse connection.
4 VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
5. VIDEO OUT: Main monitor connectors,
6. VIDEO IN: 16 video inputs for connecting video signal sources to the DVR.
7. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
8. AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
9. DC12V: 12V DC power socket for connecting included power adaptor.
10. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
BNC, please press and hold the ESC button for 5 sec.
STARTING THE DEVICE
12 345
67 8 910

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
15
2.5. Electrical connection and other rear panel elements of NDR-BB4104 DVR.
1. RS-485: one RS-485 bus port for connecting external keyboard or PTZ cameras
(RS485: A+, B-)
Note:
Only one of the devices may be connected at a time.
2. DC12V: 12V DC power socket for connecting included power adaptor.
3. USB: USB 2.0 port for external Flash memory and mouse connection.
4 LAN: RJ-45 connector port for connecting to the local network and internet.
5. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
6. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
7. VIDEO OUT: Main monitor connectors,
8. AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
9. VIDEO IN: 8 video inputs for connecting video signal sources to the DVR.
10. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
11.ALARM IN: 8 alarm inputs, which may be set either as normally open (N.O.) or normally
closed (N.C.). In order to detect the alarm, signal should last for minimum
0.5sec .
12. ALARM OUT : Alarm relay output, max. load capacity of the outputs is 0,5A/125VAC and
1A/30VDC. (NO, COM)
13. SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
14. POWER SWITCH: DVR power switch.
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
BNC, please press and hold the ESC button for 5 sec.
STARTING THE DEVICE
1 2345 678910 1112 13 14

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
16
2.6. Electrical connection and other rear panel elements of NDR-BA4208 DVR.
1. VIDEO IN: 8 video inputs for connecting video signal sources to the DVR.
2. VIDEO OUT: Main monitor connectors,
3 LAN: RJ-45 connector port for connecting to the local network and internet.
4. SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
5. USB: USB 2.0 port for external Flash memory and mouse connection.
6.AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
7. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
8. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
9. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
10. I/O Terminal block: Input, output and RS-485 port .
 RS-485: two RS-485 bus ports for connecting external keyboard (K/D:
A+, B-) and PTZ cameras (P/Z: Y+, Z-)
 ALARM IN: 16 alarm inputs, which may be set either as normally open
(N.O.) or normally closed (N.C.). In order to detect the alarm, signal
should last for minimum 0.5sec .
 ALARM OUT(NO, COM): Alarm relay output, max. load capacity of
the outputs is 0,5A/125VAC and 1A/30VDC.
 GND: Grounding
11.DC12V: 12V DC power socket for connecting included power adaptor.
12.POWER SWITCH: DVR power switch.
13.FAN: Cooling fan, do not cover!
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
HDMI or BNC, please press and hold the ESC button for 5sec.
STARTING THE DEVICE
1
2
3
4 2
37 5
6 4
8
9
101112 1 13

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
17
2.7. Electrical connection and other rear panel elements of NDR-BA4416 DVR.
1. I/O Terminal block: Input, output and RS-485 port .
 RS-485: two RS-485 bus ports for connecting external keyboard (K/D:
A+, B-) and PTZ cameras (P/Z: Y+, Z-)
 ALARM IN: 16 alarm inputs, which may be set either as normally open
(N.O.) or normally closed (N.C.). In order to detect the alarm, signal
should last for minimum 0.5sec .
 ALARM OUT(NO, COM): Alarm relay output, max. load capacity of
the outputs is 0,5A/125VAC and 1A/30VDC.
 +5V, GND: Alarm indicator power supply, feeding +5V
2 LAN: RJ-45 connector port for connecting to the local network and internet.
3. USB: USB 2.0 port for external Flash memory and mouse connection.
4. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
5. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
6. VIDEO OUT: Main monitor connectors,
7. SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
8. VIDEO IN: 16 video inputs for connecting video signal sources to the DVR.
9. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
10. AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
11. POWER SWITCH: DVR power switch.
12. DC12V: 12V DC power socket for connecting included power adaptor.
13. FAN: Cooling fan, do not cover!
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
HDMI or BNC, please press and hold the ESC button for 5sec.
STARTING THE DEVICE
1
2 3
6
4
7
5 8
10
9
11
12
13

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
18
2.8. HDD mounting
NDR-BA2208-II, NDR-BA2416, NDR-BA4104-II DVRs support up to 1 internal SATA HDD.
NDR-BA4416 and NDR-BA4208 DVR supports up to 2 internal SATA HDDs.
WARNING!
In order to find information regarding the compatible models of HDDs and their maximum
capacities, please contact Novus distributor or check the information presented at
www.novuscctv.com. AAT HOLDING Company is not responsible for any problems resulting
from using not recommended hard drives.
The list of compatible HDDs contains all the HDDs that can be used with a given DVR including
HDDs designed for office use - so called desktop disks. However, due to the fact that reliability of
the recording process and data safety are paramount factors of any CCTV system, we strongly
advise to use HDDs designed for continuous (24/7) operation.
In order to mount HDD, please unscrew the screws as depicted below, then please remove the DVR's
cover first by sliding into the rear-end and then lifting it.
NDR-BA2208-II,NDR-BB2208, NDR-BA2416, NDR-BA4104-II,NDR-BB4104 :
NDR-BA4416,NDR-BA4208:
WARNING!
Prior to removing cover of the NVR please unplug the power cord first! If the NVR is powered
up, please shutdown the NVR's system using LOGOUT & SHUTDOWN menu, prior to
unplugging the power.
STARTING THE DEVICE

NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
19
After removing top cover of the DVR, please mount the HDD to the DVR bottom using included
screws (4 pieces for each HDD), and connect power and signal cables.
NDR-BA2208-II, NDR-BB2208, NDR-BA2416, NDR-BA4104-II ,NDR-BB4104:
NDR-BA4416 and NDR-BA4208:
After connecting an HDD(s), please put the top cover onto the DVR and turn the device on in order to
check the operation of particular components and to format the HDDs.
WARNING!
You need to format disks if they were used in a different device. All data saved on HDD prior to
format will be lost. Mounted HDDs should be the same model.
STARTING THE DEVICE

NDR-BA2208-II, NDR-BB2208,NDR-BA2416, NDR-BA4104-II, NDR-BB4104, NDR-BA4208
and NDR-BA4416
User’s manual (short) ver.1.3
All rights reserved © AAT Holding sp. z o.o.
20
Recording capacity calculate table:
“Total Recording capacity” = “Used space per hour (MB/h)” × “recording time” × “channel numbers”
For instance: computing space for 16 x cameras that are to record in D1 with Lowest video quality, 25
fps framerate and 30-day recording capacity requires the calculation below:
Total Recoding capacity =112 (mb/h) X 24(hours/day) X30(days) X16(channels)= 1290240MB~1,3TB
2.9. Turning on the power
Connect power cord to the DVR to start the unit. Initialization lasts for approximately 60 seconds.
During this time executing any device functions and pressing any buttons is prohibited. To shut the
device down please use its menu.
Note:
OSD menu will be displayed on the VGA monitor default. To switch the OSD display from BNC to
VGA, please press and hold the ESC button.
STARTING THE DEVICE
DVR Resolution Frame Rate
Totally(FPS) Video Quality Bit Rate (kbps)
Used
Space
(MB/h)
NDR-BA2416
CIF 25
Highest 2M 910
Higher 1.5M 712
Medium 1M 468
Low 768K 297
Lower 512K 241
Lowest 256K 112
NDR-BA2208-II
NDR-BA4104-II
NDR-BA2408
NDR-BA4416
NDR-BB2208
NDR-BB4104
D1 25
Highest 2M 910
Higher 1.5M 712
Medium 1M 468
Low 768K 297
Lower 512K 241
Lowest 256K 112
