NSA DF15-R31-AC User manual

Compact Cool
Table Top
Air Circulator
DF15-R31-AC
User manual
www.nsauk.com

Welcome
www.nsauk.com
With a clear focus on new technologies, innovation and design, NSAUK has
played a leading role in the Air Improvement industry for over 20 years.
NSAUK uses the latest technologies to maximise consumer benets with
energy saving DC motors and cordless rechargeability at the forefront.
Boasting 8 Quiet Mark accreditations across the range, NSAUK are the
leading brand for build quality & exceptionally quiet performance.

3
4
5
6
7
10
11
13
14
15
16
Box Contents
Parts Description
Controls
Operation Guide
Circulating Air
Remote Operation
Cleaning & Care
Recycling & Disposal
Safety
Technical Data
Keep safe for future reference.
Contents
Thank you for purchasing this Table Top / Personal Air Circulator with Remote Control.
Please read this instruction manual before using your Table Top Fan for the rst time.

4
1
2
3
1. Table Top Air Circulator
2. Remote Control
3. CR2032 cell battery (for remote control)
4. User guide
What’s included
Included in the box you will nd:
4
Fig.1

5
Parts Description
1. Front Grille (Air Outow)
2. Centre Disk
3. Fan Blades (Internal)
4. Control Panel w. LED Lights
5. Remote Control Receiver
6. Oscillation Base
7. Base Plate
8. Fan Casing
9. Back Grille (Air Intake)
10.Tilt Point
Fig.2
1
2
3
4
5
6
7
8
9
10

6
1. Oscillation
2. 1, 2, 4hr timer (Totalling 7hrs)
3. 3 Speeds (Low / Med / High)
4. On / Off
Manual controls
Remote control
5. On / Off
6. Oscillation
7. Speed
8. Timer
Fig.4
56
7 8
4
31 2
NB: before disposal of packaging check thoroughly for the remote control.
Controls
Fig.3

7
Operation guide
On/Off
Press ON/OFF button on the manual controls or the remote control to turn on the fan.
Press again to stop the fan from operating.
Press SPEED button on the manual controls or the remote control to select the desired
speed level. Each time the SPEED button is pressed the LED light on the control panel
indicates the speed selected.
Speed
Speed / Airow Cycle

8
You can set the run time for 1 to 7 hours duration. Press the Timer button to move
through the timer options. The LED light will indicate the time selected. If there is no
LED light showing then the timer is off and operation will be continuous until the fan is
manually powered off.
Timer
1h 2h 3h 4h 5h 6h 7h
Continuous
Press OSC once to activate the oscillation feature, for wide distribution of air. Press OSC
button again to stop oscillation function.
NOTE: Maximum benet from oscillation function between 0° to 45°. Little to no benet
when fan head tilted into horizontal position.
Oscillation (OSC)

9
TIlt Adjustment 0-90°
Fig.5
• Gently tilt the fan head up or down to the desired angle.
• NB: Only adjust tilt when the fan is turned off. Adjusting tilt when the fan is
operating may damage the tilt mechanism.

10
a. Distributing Air Conditioned & cooled air throughout the room
b. Distributing Heated air throughout the room
c. Circulating air upstairs & around the house
d. Evenly distribute Air Conditioned & cooled air between rooms
e. Circulate warm air from inside to outside
a b c
d e
Circulating Air
Suitable uses for circulating air around the home include:
Fig.6

11
Remote Operation
• Be sure to direct the remote control toward the
receiver on the control panel.
• Use the remote control within 5 metres from the
receiver. If the remote control is not directed
towards the receiver, the effectiveness will be
reduced.
• Do not place any obstacle between the receiver
and remote control.
• Please treat your remote control with care. Knocking
or dropping it will reduce its reliability.
• Please store the remote control safely when not in
use or in the special recess in the carry handle.
The fan can be operated either manually by the control panel on the fan unit itself or
by the remote control supplied with the product.
Fig.7
IMPORTANT: This remote control contains a button battery. If swallowed, it
could cause severe injury or death in just 2 hours. Seek medical attention
immediately.

12
Replacing the Remote Control Battery
(1pc x Lithium 3V CR2032)
Turn over the remote
control. Open the cover
of battery compartment
~ squeeze lock towards
centre to release
Install the battery into the
battery compartment.
Take care of the polarity
of the battery, which
is indicated inside the
battery compartment.
Close the battery cover.
Ensure it clicks closed.
NB Please dispose of used
batteries responsibly.
WARNING:
Keep Batteries Out of Reach of Children
1. Swallowing may lead to serious injury in as little as 2 hours or death, due to
chemical burns and potential perforation of the oesophagus.
2. If you suspect your child has swallowed or inserted a button battery, immediately
seek urgent medical assistance.
3. Examine the devices and make sure the battery compartment is correctly
secured – eg: that the screw or other mechanical fastener is tightened or locked.
Do not use if the compartment is not secure.
4. Dispose of button batteries immediately and safely. Flat/dead batteries can still
be dangerous.
Fig.8
Lock

13
• Unplug the appliance before cleaning.
• Do not use any chemical-based solutions for cleaning surfaces.
• Slightly moisten a cloth and then wipe off the surfaces of the fan.
• In order to remove the dust from the protective fan grille use a vacuum cleaner
upholstery attachment.
• Ensure fan is completely dry before storage or reconnecting to the electrical
supply.
• Never immerse the fan or fan motor in water or other liquid.
• If the fan is not used for long periods, protect with a suitable cover after cleaning,
then store in a dry place.
Cleaning & Care

14
Recycling & Disposal
The packaging of your new fan has a recycle mark on it.
Please dispose of it as recycled paper or by using the “Dual System”.
The symbol on the product or on its packaging indicates that this product may
not be treated as general household waste. Instead it should be handed over to the
applicable collection point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about the recycling of this product, please contact your
local council ofce, your household waste disposal service or the store where you
purchased the product.
UK Guarantee
24 months warranty valid only in respect of defects found to be due to faulty
workmanship or material. Proof of purchase is required to validate the guarantee.
This guarantee is no longer valid if the damage has been caused by a fall, alteration
or repair by any unauthorised persons or if the product has been resold.
This guarantee in no way affects your statutory rights.
Please recycle
Compliance
For your safety, this appliance complies with the applicable standards and
regulations (Low Voltage Directive, Electromagnetic Compatibility, Environmental
directives). We reserve the right to make technical changes without prior notice.

15
1. Check the household voltage to ensure it matches
the fan’s rated specication before using.
2. Always use this device in accordance with the
instructions.
3. Close supervision is necessary when this fan is used
near children and pets.
4. Do not allow children to play with the product or
product packaging, such as plastic bags.
5. Repairs may only be carried out by a recognised
repair centre, incorrect handling and faulty repairs
may lead to danger and invalidate warranty.
6. This fan is not intended for use in wet or damp
locations.
7. Never position the fan in an area where it may fall
into a bath or other water container.
8. Do not use this fan if it has any damaged parts
or it has fallen into water. Return the product to
a recognised repair centre for examination and
repair.
9. Do not insert any object into the grille whilst the
fan is operating. It may cause damage to persons
or property.
10. Always turn off the power supply before
unplugging the product to move, store or clean it.
11. Always use both hands to carry this product. Do
not lift by the carry handle alone – please support
the fan base.
12. Do not operate the fan near an open ame,
cooking or heating appliance or hot surface
13. Always place your fan on a rm, dry, level surface,
away from curtains & blinds.
14. This fan is intended for indoor, domestic & light
commercial use only and is not to be operated
outside.
15. Do not hang anything from the fan grille.
16. Disconnect the unit from the electrical outlet
before cleaning.
17. To disconnect from the power supply, grip the plug
and pull from the power socket. Never pull by the
cord.
18. Arrange the power cord away from an area
where it may be tripped over.
19. Never place the power cord under a carpet or
rug.
20. Do not direct the fan towards babies or the elderly
for extended periods.
21. If the power cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
22. Do not operate if the fan grille is removed or
damaged.
23. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Safety Keep safe for future reference.

© 2021 Newton Stovold Assocs Ltd GU8 6AA
www.nsauk.com
Technical Data
Model No: DF15-R31-AC
EAN No: 5 060301 911455
Rated Power: 35W
Voltage: 220-240V ~ 50Hz
Ref: IM/DF15R31AC/2102/GU86AA
Product Dims: 295 x 245 x 205 mm (H*W*D)
Carton Dims: 325 x 265 x 225 mm
N.W. 1.50kg
G.W. 2.00kg
