NSA SFC-200B User manual

Warning
1. Check the voltage indicated on the rating label is suitable before connecting to the mains.
2. If the power cord is damaged it must be replaced immediately by a qualified electrician or
returned to the store where you purchased the product to avoid a hazard.
. Do not operate the fan if it malfunctions, has been dropped or damaged in any way.
4. Do not operate if the fan grille has been removed or damaged.
5. Close supervision is necessary when this fan is used near children, the elderly & pets.
6. This appliance can be used by children aged from 8 yrs and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved.
7. Always turn off the fan after use, before cleaning, or moving location.
8. Do not insert fingers or other objects into the fan grille.
9. Never place the power cord under a carpet or rug.
10. Never operate the fan where it may fall into a bath or other water container.
11. Do not use outdoors. This product is designed for domestic household use only.
12. Disconnect from the mains by gripping the plug. Do not pull by the power cord
Disposal
The packaging of your new fan has a recycle mark on it.
Please dispose of it as recycled paper or by using the “Dual System”.
The symbol on the product or on its packaging indicates that this product may not be
treated as general household waste. Instead it should be handed over to the applicable collection
point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of this product. For more
detailed information about the recycling of this product, please contact your local council office, your
household waste disposal service, the store where you purchased the product or visit www.recycle-
more.co.uk.
Technical Data
Ref: IM/SFC8/12/16/1702/GU86AA
Model No:
Power:
Voltage:
Product Dims (W*D*H):
Giftbox Dims (W*D*H):
NW:
GW:
SFC-200B (8” / 20cm)
6W
220-240V ~ 50Hz
280 x 140 x 260 mm
290 x 150 x 275 mm
1.75 kg
2.10 kg
SFC- 00BP (12” / 0cm)
48W
220-240V ~ 50Hz
90 x 145 x 70 mm
400 x 150 x 80 mm
.16kg
.70kg
SFC-400BP1 (16” / 40cm)
88W
220-240V ~ 50Hz
510 x 180 x 490 mm
520 x 195 x 510 mm
4.4kg
5.2kg
UK guarantee
For 24 months warranty in respect of defects found to be due to
faulty workmanship or material. Proof of purchase is required for
validity of the guarantee. This guarantee is no longer valid if the
damage has been caused by fall, alteration or repair by any
unauthorised persons. This guarantee in no way affects your
statutory rights.
Air Circulator
8 inch / 20 cm
Model ： SFC-200B
12 inch / 0 cm
Model ： SFC- 00BP
16 inch / 40 cm
Model ： SFC-400BP1
Instruction manual
 fan blades
 speeds
Rotary controls
Tilt
Carry Handle
Rubber Feet
Please keep safe for future reference
Please Recycle
4
© 2017 Newton Stovold Associates Ltd
GU8 6AA / www.nsauk.com
All manuals and user guides at all-guides.com

Air Circulator
Thank you for purchasing this air circulator. Please read the instructions and
warnings carefully before use to ensure safe and satisfactory operation of this
product. Please retain this information for future reference.
Appliance components
A. Fan grille
B. Rotary controls (not visible)
C. Motor
D. Tilt pivot (120º rotation)
E. Fan blade
F. Stand
G. Fan grille securing screws (8pc)
H. Non-slip feet
Operation
1. Position your fan on a dry, level surface & plug into an electrical socket.
2. Select 1=Low; 2=Med or =Hi on the rotary speed control switch (“B” above
not visible – located on the back of the fan). Select 0 to turn OFF the fan.
. Airflow direction can be adjusted upwards or downwards by simply tilting
the fan head to the desired angle. Up to 120º rotation.
Cleaning & Care
♦Unplug the appliance before cleaning.
♦Do not use any chemical-based solutions for cleaning metal surfaces.
♦Slightly moisten a cloth and then wipe the surfaces of the fan.
♦In order to remove the dust from the protective fan grille use a vacuum
cleaner or undo the securing 8pc screws on grille edge and wipe fan blades
with a damp cloth.
♦Ensure fan is completely dry and the fan grille securely refitted before
storage or reconnecting to electrical supply.
♦Never immerse the fan or fan motor in water or other liquid.
♦If the fan is not used for long periods, protect with a suitable cover after
cleaning, then store in a dry place.
♦The motor bearings are permanently sealed and do not require additional
lubrication.
This appliance complies with both the low voltage and electromagnetic
compatibility directives. Its construction complies with current safety standards.
We reserve the right to make technical changes without prior notice.
BS plug wiring
1. Wiring instructions: Should it be necessary to change the plug please note
the wires in the mains lead are coloured in accordance with the following
code:
BLUE – NEUTRAL * BROWN – LIVE * GREEN AND YELLOW - EARTH
2. As the colours of the wires in the mains
lead of this appliance may not
correspond with the coloured
markings identifying the terminals in
your plug, proceed as follows:
. The BLUE wire is the NEUTRAL and must
be connected to the terminal that is
marked with the letter N or coloured
BLACK.
4. The BROWN wire is the LIVE and must
be connected to the terminal that is
marked with the letter L or coloured
RED.
5. The GREEN/YELLOW is the EARTH and
must be connected to the terminal
which is marked with or the letter
E or coloured GREEN OR GREEN/YELLOW.
6. Always ensure that the cord grip is positioned and fastened correctly.
If a 1 A (BS 1 6 fused plug is used it must be fitted with a 5A fuse. If in doubt
consult a qualified electrician.
3
