NTI VOPEX Series User manual

MAN363 Rev 1/2/20
VOPEX-4K18GB-4
HDMI 2.0 4K 60Hz 1 IN 4 OUT HDMI Splitter
V
VO OP P
E
E
X
X®
®
S
Se er ri ie es s

1
Introduction
VOPEX-4K18GB-4 is an HDMI 2.0/HDCP 2.2 compliant splitter supporting resolutions up to UHD 4K2K
@60Hz. It equalizes the signal and distributes it to four identical outputs.
Features
Connects up to 4 HDMI displays at the same time from an HDMI source.
Supports 4K@60Hz 4:4:4 18Gbps (6Gbps per color),1080p@60Hz 16bit,3D,High Dynamic Range
Built-in EDID learning/integration function.
Supports LPCM 7.1, Dolby TrueHD, DTS-HD Master Audio.
HDMI 2.0 compliant.
HDCP 1.4/2.2 compliant.
DVI 1.0 compliant.
Materials Supplied
VOPEX-4K18GB-4 4K HDMI Splitter
100-240VAC, 50/60Hz ; 5VDC 2A AC Adapter
Mounting hardware
Installation
1. Connect the video source to "HDMI IN".
2. Connect up to 4 displays to the "HDMI OUT" ports. If displays are different models, use the DIP switches (page 3) to
determine what resolutions will be supported.
Note: For available cable lengths, see chart on page 4.
3. Connect the power supply and power up the VOPEX, video source and displays (in any order).

2
Mounting
Screws and wall anchors are included to secure the VOPEX to a surface. Slots (.155 In. wide) are found on the bottom of
the unit. Install the screws and attach the VOPEX.
Panel View
VOPEX-4K18GB-4
LED Indications
Label Meaning
ON Green ON = Power ON
IN Blue ON= HDMI Input connected
OUT1 Blue ON= HDMI Out 1 is connected
OUT2 Blue ON= HDMI Out 2 is connected
OUT3 Blue ON= HDMI Out 3 is connected
OUT4 Blue ON= HDMI Out 4 is connected
3.938"
1.880" 1.327"

3
DIP Switch Function
The default position is with DIP Switch 1~4 OFF(switches are all up) meaning EDID is set at
1080P.
Position Effect
Switch 1 ON Use Output 1 as EDID source
Switch 2 ON Use Output 2 as EDID source
Switch 3 ON Use Output 3 as EDID source
Switch 4 ON Use Output 4 as EDID source
More than 1 DIP
switch ON The VOPEX will analyze the EDID from each monitor associated with the DIP switches in the ON
position and generate a set of EDID common to each monitor.
Example: Outputs 1 and 2 have different displays attached. Set the DIP switches 1 and 2 to the
ON position and press “EDID COPY”button. A new a set of EDID supporting both monitor's
screen resolutions will be created.
Note：If more than one DIP switch is ON, the VOPEX will only support stereo (2-Channel) audio.
EDID COPY Button
When the “EDID COPY”button is pressed, the VOPEX will learn and generate EDID according to the DIP switch
settings.
Console Port
Connect a serial cable for R232 interface between the "Console" port and a PC for firmware updates.
Serial Cable Pinout:
D
DB B9 9M M( (M Ma al le e) ) D DB B9 9F F( (F Fe em ma al le e) )
R
RS S2 23 32 2 R RS S2 23 32 2
P
Pi in n S Si ig gn na al l P Pi in n S Si ig gn na al l
P
Pi in n 2 2 T TX X I In n P Pi in n 2 2 T TX X O Ou ut t
P
Pi in n 3 3 R RX X O Ou ut t P Pi in n 3 3 R RX X I In n
P
Pi in n 5 5 G GN ND D P Pi in n 5 5 G GN ND D
DIP Switch for EDID
Firmware update feature not supported as of this publishing.

4
Specifications
Resolution 480i/p, 576i/p, 720p, 1080i/p@60Hz, 4K@30Hz, 4K@60Hz(YCbCr 4:4:4)
HDMI Connector HDMI Type A x 5
Audio Support LPCM 7.1, Dolby TrueHD, DTS-HD Master Audio
Console RS-232 x 1
DIP Switch 4 Pin Dip Switch x 1
Function button Button x 1
Power Supply 100-240VAC, 50/60Hz ; 5VDC 2A AC Adapter
Power Consumption 1000mA (Max)
Environmental Operation: 32 to 140˚F (0 to 60˚C)
Storage: -4 to 185˚F (-20 to 85˚C)
Humidity: up to 95%
Dimensions WxDxH (In.) 6.57 x 3.96 x 1.57 (167 x 100.5 x 40mm)
Weight 455g (1 lb.)
Agency Approvals RoHS, CE
Use NTI HDMI Cables for Input and Output cables
Available Cables Supported Resolution
1080p@60Hz 4096x2160 and
3840x2160
HD-xx-MM
Where x=3,6,10,15,20, 30 and 50 ft Yes Max. 20 ft (@ 30/60Hz)
HD-ACT-xx-MM
Where xx= 20,25,30,40 and 50 ft Yes Yes (@ 30/60Hz)
HD-ACT-xx-MM
Where xx= 60,75 and 100 ft Yes No
HD4K18GB-FO-xxM-MM
Where xx= 10,15,20,25,30,50,70 and
100 meters
Yes Yes
DVI-HD-xM-MM
Where x= 1,2,3 and 5 meters Yes No
Warranty Information
The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact
Network Technologies Inc at [phone] (800-RGB-TECH) or [phone] or visit our website at
http://www.networktechinc.com for information regarding repairs and/or returns. A return authorization number is
required for all repairs/returns.
MAN363 Rev 1/2/20
