nubeca RT1112 User manual

USER’S MANUAL
RT1112
ear and forehead thermometer

Ver. 1.0
2011/03
311-1112100-xxx
RT-1112 ear and forehead thermometer
User＇s Manual

Screen
Using
Turning
Recalling
Replacing
Setting the Thermometer
Device
Device
Symbol Information 22
23
20
21

2
As with any t hermometer, proper technique is crucial
to getting accurate temperature readings. Please read
this manual thoroughly and carefully before using.
Always store the thermometer in a cool and dry place:
temperatures between
relative humidity less than 95%. Avoid direct sunlight.
Avoid dropping t he thermometer.
Do not touch the lens.
Do not disassemble the thermometer.
Basic safety precautions should always be observed ,
especially when the thermometer is used on or near
children and disabled persons.
The forehead temperatur s a reference
only. It cannot be a judgment on fever.
CAUTIONS & WARNINGS
This thermometer is not i ntended t o substitute f or
consultation with your physician.
serves a
-20°C to 50°C (-4°F to 122°F)

3
This t hermometer is clinically proven to produce accu-
rate temperaturemeasurement
The accuracy can not beensured for a person who has
deformity in t he ear such that t he thermometer probe
The be ensured when blood or drai-
nage is found in the ear canal.
Never try toclean inside the ears. You may accidentally
damagethe eardrumorits surrounding tissues.
Remove excessearwax only when youcan reachit
with a clean cloth.Consult aphysician i fyou suspect
the presence of excess earwax.
RESTRICTIONS OF USE
NOTE
advised of following situations:
accuracy cannet
s ; however, please be
cannot be properly inserted into the ear canal.
If ear drops or medications have been placed in one
ear take temperature from the other ear.
If wear ear plug or hearing aid, remove the
thermometer and wait for 15 minutes before taking
temperature.

4
INTRODUCTION
HOW DOES IT WORK
The thermometer measures the infrared heat generated
by the eardrum and its surrounding tissue, or t he
forehead skin surface over t he temporal artery. T he
thermometer then c onverts i t into a temperature value
shown on LCD.
NOTE
The thermometer does not emit any infrared signal.
Thank you for choosing nu-beca RT-1112 Ear/Forehead
Infrared Thermometer. This innovative medical
thermometer relies on advanced infrared (IR)
technology to measure temperature instantly and
accurately through two convenient sites, the ear
canal and the surface of the skin over the temple. An
additional function is while resting on a table, an elegant
clock displaying room temperature will be presented.
Setup with a backlight LCD, nu-beca is an elegantly
designed infrared thermometer meant for your family.

5
HIGHLIGHTED FEATURES
Provide two body temperatures: ear or forehead.
Fast and accurate:meetthe accuracy requirement
specified in ASTM E1965-98 and the EC directive 93/42
Non-contact measurement that
Clock and room temperature inter-display.
A splash-proof probe that can bew
iped using a clean
cloth slightly damped with alcohol or water.
Automatically power down or back to t he C LOCK/RT
mode if left unused over 30 seconds.
Big button improves handling and activation.
LCDbacklight improves visibility especially ina dark
environment.
Memory function allows you to recall previous
results up to 20 measurements.
/EEC.
does not require
lens lter, there by saving cost of replacement.

6
M
nu-beca RT-1112

7
Lens

8
SCREEN

9
You willneed t o set time and unit for first-time use or
after replacing the battery.
Step1 Press the Set Button.
" " and the flashing hour appear first.
Step2 Set hour&minute
Press the On/Scan button to select the
correct hour.
Press the Set button and t he f lashing
minute then appears.
Press the On/Scan button to select the correct minute.
Step3 Select°C or °F
Press the Set button and °C/°F is
displayed next.
Press the On/Scan button to select.
“
“
“
“
Setting is all completed. Select either of the following
two modes to exit setting.
OFF mode: Just leave the meter without pressing. It
will be automatically off after 30 seconds.
CLOCK/RT mode: Press the Set button after Step3.
Without pressing any buttons over 30 seconds, the
meter will automatically turn off.
NOTE
Set button
Step4 Select Beeping sound
Press the On/Scan button to select on/
off the Beeping sound.
Step5 Select LCD backlight
Press the On/Scan button to select on/
off the LCD backlight.
SETTING THE THERMOMETER

10
NOTE
REPLACING
Reattach

11
Body temperature can vary from one person to next.
It also varies by location on the body and time of day.
Below shows the statistical normal ranges from different
sites. Please keep in mind that temperatures measured
from different sites, even at the same time, should not be
directly compared.
Fever indicates that the body temperature is higher
than normal. This symptom may be caused by infection,
overdressing or immunization. Some people may not
experience fever even when they are ill. These include,
but are not limited to, infants younger than 3 months old,
persons with compromised immune systems, persons
taking antibiotics, steroids or antipyretics (aspirin,
ibuprofen, acetaminophen), or persons with certain
chronic illnesses. Please consult your physician when
you feel ill even if you do not have a fever.
Body Site Normal Temperature Range
35.5°C - 37.5°C (95.9°F - 99.5°F)
Auxiliary(underarm)
Oral
Rectal
Ear
34.7°C - 37.3°C (94.5°F - 99.1°F)
36.6°C - 38.0°C (97.9°F - 100.4°F)
35.8°C - 38.0°C (97.9°F - 100.4°F)
*1
*1
96.4

12
NOTE
M
M
M

13
1.As with any type of thermometer, you may observe
slight variations in consecutive measurements. It
is recommended that you take 3 temperature
readings and use the highest one for the following
situations:
When you are learning to use the thermometer.
2.Please free from the following situations at least for 15
minutes before taking a reading.
When you have your ear covered.
After exercising, swimming, or taking a bath. When
expose to extreme temperature
During eating and talking.
3.To take accurate readings, the ear must be free from
excess ear wax buildup.
Hints on Taking Ear Temperature
Infants younger than 3 months old.
Children younger than 3yearsold and havea
compromised immune systemand t he presence/
absence of fever is critical.

14
NOTE
As the forehead temperature is likely to be affected by
sweat, oil and the surroundings, the reading shall be
taken as a reference only.
If the probe is placed at an angle on the forehead, the
reading will be affected by surrounding temperature.
You can scan at 3 cm distance from the forehead.
Flat
M
Step2 Press and hold the
On/Scan button. Put
the probe on the
temple. Make sure the
probe is at on the
temple, not at an
angle.

15

16
Aftermeasurements, t he meterwill back to itsinitial
mode after unused over 30 seconds. That is, if the meter
is started fromthe OFFmode, it willbeautomatically
offaftermeasurements. Likewise, ifthe meterisstarted
fromthe CLOCK/RTmode, itwill be back to that mode
after measurements.
To exit the CLOCK/RTmode, youhave t oturn offthe
thermometer.
To turn the thermometer off, press t he Set button until
the hour or minute isblinking. Leave for 30 seconds
without pressing any button. The t hermometer will
then automatically off.
TURNING OFF THE DEVICE

17
THE MEMORY
Your thermometer stores 20 recent readings in the
memory. Be sure the thermometer is in either "OFF" or
"CLOCK/RT" mode before recall.
Step1 Press the M button to enter
the memory.
Each time you press the M
button, a result will be displayed
in the order of dates (latest result
shown first together with and
number ( from 0 to 19).
When the memory is full, the
oldest result is deleted as the
new one added.
Step3
Step2
Press the On/Scan button to exit the memory.
Press the M button to review
the result.
When using t he t hermometer at f irst t ime,number o f
memory will f lash. I t indicates that t here are no test
results in memory.
NOTE
RECALLING
