nubeca RT-1116 User manual

Owner’s Manual
311-1116100-009
Virsion 3.0 April, 2009
Ear and Forehead Thermometer
RT-1116

IMPORTANT SAFETY INSTRUCTIONS
READ THIS BEFORE USING
The following basic safety precautions should
always be taken.
1. Close supervision is necessary when the device is
used by, on, or near children, handicapped persons
or invalids.
2. Use the device only for the intended use described in
this manual.
3. Do not use the device if it is not working properly, or if
it has suffered any damage.
KEEP THESE INSTRUCTIONS

Cautions and Warnings 02
Restrictions of Use 03
Introduction 04
Highlighted Features 05
Package Contents 06
Thermometer Parts 07
LCD Screen 08
Setting the Thermometer 09
Replacing the Battery 10
About Normal Body Temperature & Fever 11
Using the Device 12
As an Ear Thermometer 12
As a Forehead Thermometer 14
As a Clock and Room Thermometer 15
Turning Off the Device 16
Recalling the Memory 17
Care & Cleaning 18
Result Indicator 19
Specifications 20
Warranty 21

2
As with any thermometer, proper technique is crucial
to getting accurate temperature readings. Please
read this manual thoroughly and carefully before
using.
Always store the thermometer in a cool and dry
place: temperatures between -25°C(-13°F) and
55°C(131°F); relative humidity less than 95%. Avoid
direct sunlight.
Avoid dropping the thermometer.
Do not touch the lens.
Do not disassemble the thermometer.
Basic safety precautions should always be observed,
especially when the thermometer is used on or near
children and disabled persons.
This thermometer is not intended to substitute for
consultation with your physician.
The forehead temperature serves as a reference
only. It cannot be a judgment on fever.
CAUTIONS & WARNINGS

3
This thermometer is clinically proven to produce
accurate temperature measurements; however,
please be advised of the following situations:
The accuracy cannot be ensured for a person who
has deformity in the ear such that the thermometer
probe cannot be properly inserted into the ear
canal.
The accuracy cannot be ensured when blood or
drainage is found in the ear canal.
If ear drops or medications have been placed in
one ear take temperature from the other ear.
If wear ear plug or hearing aid, remove the
thermometer and wait for 15 minutes before taking
temperature.
RESTRICTIONS OF USE
Never try to clean inside the ears. You may accidentally
damage the eardrum or its surrounding tissues. Remove
excess ear wax only when you can reach it with a clean
cloth. Consult a physician if you suspect the presence
of excess earwax.
NOTE

4
Thank you for choosing nu-beca RT-1116 &
Forehead
Thermometer.
This innovative medical device leverages on advanced
infrared (IR) technology to measure temperature
instantly and accurately in two convenient ways: in the
ear or on the forehead. An additional function is while
resting on a table, an elegant clock displaying room
temperature will be presented. nu-beca is an elegantly
designed infrared thermometer meant for your family.
INTENDED USE
nu-beca RT-1116 Ear & Forehead Thermometer
is intended for the intermittent measurement and
monitoring of human body temperature from ear canal
or forehead. The device is indicated for use by people
of all ages in the home.
HOW DOES IT WORK
The thermometer measures the infrared heat generated
by the eardrum and its surrounding tissue, or the
forehead skin surface over the temporal artery. The
thermometer then converts it into a temperature value
shown on LCD.
The thermometer does not send out any infrared signal.
INTRODUCTION
NOTE

5
HIGHLIGHTED FEATURES
Provide two body temperatures: ear or forehead.
Fast and accurate: meet the accuracy requirement
specified in ASTM E1965-98 and EN 12470-5.
Non-contact measurement that does not require lens
filter, there by saving cost of replacement.
Clock and room temperature inter-display.
A waterproof probe that can be wiped using a clean
cloth slightly damped with alcohol or water.
Automatically power down or back to the CLOCK/RT
mode if left unused over 30 seconds.
Big button improves handling and activation.
Memory function allows you to recall previous results
up to 10 measurements.

6
nu-beca RT-1116 Ear &
Forehead Thermometer
DC 3V type CR2032 Lithium
Battery
User’s Manual
Warranty Card
PACKAGE CONTENTS

7
Set button
Battery compartment
Battery cover
THERMOMETER PARTS
On/Scan button
LCD screen
Probe cover
Lens
Probe
Detector
ear/forehead
thermometer

8
LCD SCREEN
DISPLAY MODE
Two modes can be selected.
1. OFF mode
The thermometer is off.
2. CLOCK/RT mode
This mode allows t h e
thermometer to detect room
temperature (RT).
It also provides clock.
The screen inter-displays clock
and room temperature.
High Temperature
Indicator
Forehead Temperature
Indicator
Ear Temperature
Indicator
Temperature
Scanning in Progress
Temperature Reading
or Clock
Temperature Unit
Temperature Unit
Historical Reading Indicator
Order of Historical Reading
from 0 to 9
Clock Mode Indicator
Low Battery Indicator
