nubeca RT-1261B User manual

311-1261000-010 Version 1.0 April, 2009
RT-1261B Ear Thermometer
Owner’s Manual

IMPORTANT SAFETY
INSTRUCTIONS
READ THIS BEFORE USING
The following basic safety precautions
should always be taken.
1. Close supervision is necessary when the thermometer
is used by, on, or near children, handicapped persons or
invalids.
2. Use the thermometer only for the intended use described in
this manual.
3. Do not use the thermometer if it is not working properly, or if it
has suffered any damage.
4. Do not use accessories which are not supplied or
recommended by the manufacturer.
KEEP THESE INSTRUIONS

TABLE OF CONTENT
06 Cautions and Warnings
07 Restrictions of Use
08 Introduction
10 Package Contents
11 Thermometer Parts
12 LCD Screen
14 Replacing the Battery
16 About Normal Body Temperature & Fever

17 Using the Device
17 Replacing Lens Filter
18 Taking Ear Thermometer
20 Hints on Taking Ear Temperature
21 Recalling the Memory
23 Viewing Results on a Personal Computer
26 Care & Cleaning
26 Fever Indicator
27 Troubleshooting
28 Specifications
29 Symbol Information
30 Warranty

Cautions and Warnings
As with any thermometer, proper technique is crucial to
getting accurate temperature readings. Please read this
manual thoroughly and carefullybefore using.
Always store the thermometer in a cool and dry place:
temperatures between -20℃to 60℃relative humidity less
than 95%. Avoid direct sunlight.
Avoid droppingthe thermometer from a height or strongly
hitting it with a hard object.
Only use the lens filter for infrared nu-beca RT-1261 ear
thermometer.
For proper hygiene, do not share lens filter. Damaged lens
filter may result in error display.
Do not disassemble the thermometer.
Basic safety precautions should always be observed,
especially when the thermometer is used on or near children
and disabled persons.
This thermometer is not intended to be a substitution for
consultation with your physician.
Keep lens filters out of reach of children.
Temperature of left and right ear may differ. Always measure
using same ear.

Restrictions of Use
This thermometer is clinically proven to produce accurate
temperature measurements. However, please be advised if you
have the following situations:
The accuracy cannot be ensured for a person who has
deformity in the ear such that the thermometer probe can not
be properly inserted into the ear canal.
The accuracy cannot be ensured when blood or drainage is
found in the ear canal.
Take temperature from the other ear if ear drops or
medications have been placed in an ear.
For a person who wears ear plug or hearing aid, remove the
device and wait for 15 minutes before taking temperature.
NOTE
Never try to clean inside the ears. You may accidentally damage the
eardrum or its surrounding tissues. Remove excess earwax only when
you can reach it with a clean cloth. Consult a physician if you suspect the
presence of excess earwax.

Introduction
Thank you for choosing nu-beca RT-1261 ear thermometer.
This innovative medical device relies on on advanced infrared
(IR) technology to measure temperature instantly nu-beca
RT-1261 ear thermometer is an elegantly designed infrared
thermometer meant for your family.
Intended use
nu-beca RT-1261 ear thermometer is intended for the
intermittent measurement and monitoring of human body
temperature from ear canal. The device is intended for use by
people of all ages in the home.

How does itwork
The thermometer measures the infrared heat generated by
the eardrum and its surrounding tissue. The thermometer then
converts it into a temperature value shown on LCD.
NOTE
The thermometer does not emit any infrared signal.

Package Contents
Lens Filter
Ear Thermometer
Two 1.5V AAA
Batteries
User’s Manual
Warranty Card
nu-beca RT-1261
Storage Case

Thermometer Parts
1
1
2
3
4
6
7
8
9
10
5
Lens filter
Lens filter ejection button
On/Memory button
Sticker
Battery cover
Data port
Probe lens
Probe
Lens filter detector
Scan button
2
3
4
6
7
8
5
29
10

LCD Screen
19
7
210
6
3
5
4
8

1
2
3
4
6
7
8
9
10
5
Ear temperature indicator
Non-lens filter warning
Temperature scanning in progress
Temperature display
Memory mode
Record numbers
Low bettery indicator
Temperature unit
Temperature indicator for
memory mode
Communication symbol

Step 1
Remove the battery cover.
Step 2
Place the new battery in the
battery compartment and press
it in until the battery is firmly secured.
Replacing the Battery
The thermometer comes with two 1.5V AAA alkaline batteries.
Replace it when “ ” appears. Please follow the steps to
replace new batteries.

Step 3
Reattach the battery cover.
NOTE
Although the thermometer works when “ ” appears, we still
recommend that you change the battery to obtain an accurate result.
Remove the battery if stored for a long period of time.
The battery should be kept out of reach of children. If they are
swallowed, promptly see a doctor for help.

About Normal Body
Temperature & Fever
Body temperature can vary from one individual/person to next.
It also varies by location on the body and different time of the
day. Below shows the statistical normal ranges from different
sites. Please keep in mind that temperatures measured from
different sites, even at the same time, should not be directly
compared.
Fever indicates that the body temperature is higher than
normal. This symptom may be potentially caused by infection,
overdressing or immunization. Some people may not
experience fever even when they are ill. These include, but
are not limited to, infants younger than 3 months old, persons
with compromised immune systems, persons taking antibiotics,
steroids or antipyretics (aspirin, ibuprofen, acetaminophen), or
persons with certain chronic illnesses. Please consult your
physician when you feel ill even if you do nothave fever.
Body Site Normal Temperature Range
35.5℃- 37.5 (95.9℉- 99.5
34.7℃- 37.3 (94.5℉- 99.1
36.6℃- 38.0 (97.9℉- 100.4
35.8℃- 38.0 (96.4℉- 100.4
Oral
Rectal
Ear
Axillary
(underarm)
Table 1*1
*1. Chamberlain, J. M. Terndrup, T. E., New Light on Thermometer
Readings,Contemporary Pediatrics, March 1994.

Using the Device
Replacing Lens Filter
Step 1
Check the lens filter is clean and new.
Step 2
Attach new lens filter into the probe.
Now, you can start to test your ear
temperature.
NOTE
If a lens filter is not attached on the probe, LCD will show “ ” until a
new lens filter is firmly attached tothe probe.
The used lens filter should be removed after each measurement by a
clean and new lens filter to ensure accuracy reading.
For hygiene use, attach a new lens filter each time and do not touch its
tip.

Taking Ear Temperature
Step 2
Press and release the On / Memory
button to turn on the thermometer.
When ready, the thermometer displays
the last measurement.
Step 1
Make sure lens filter is firmly attached
to the probe.
Step 3
Gently fit the probe into the ear canal.

Step 5
Read the result.
“ ” is shown together with a
temperature value.
Step 4
Press and release the Scan button.
Do not remove the thermometer until it
beeps.
Step 6
Discard used lens filter into trash by
pressing lens filter ejection button.
NOTE
Turn off the thermometer by pressing On/ Memory button twice. It will
automatically turn off if left idle for 3 minutes.

Hints on Taking Ear
Temperture
1. As with other of thermometer, you may observe slight
variations in consecutive measurements. It is recommended
that you take 3 temperature readings and use the highest
one for the following situations:
Infants younger than 3 months old.
Children younger than 3 years old and who have a
compromised immune system and the presence / absence of
fever is critical.
When you are learning to use the thermometer.
2. Do not take a reading while eating and /or talking. Wait 30
minutes after any of the following situations before taking a
measurement:
When you have your ear covered.
After exercising, swimming, or taking a bath. When expose to
extreme temperature.
3. To take accurate readings, the ear must be free from excess
earwax build-up.

▲
Recalling the Memory
Your thermometer stores 10 recent readings in the memory.
Step 1
Be sure the thermometer is OFF
before recalling this memory.
Step 2
Press the On / Memory button to
turn on the thermometer.
Step 3
Press the On / Memory button for 3
seconds to enter memory mode.
Each time you press the On / Memory
button, a result will be displayed in
the order of dates (latest result shown
first), together with “ ” and number
( from 1 to 10 ).
When the memory is full, the oldest
result is deleted as the new one
added. When the last record is
displayed in the LCD, press On /
Memory button again to return the first
record.
