nubeca RT-1241 User manual

OWNER’S MANUALR
RT-1241
Infrared Forehead
non-contact Thermometer

IMPORTANT SAFETY INSTRUCTIONS
READ THIS BEFORE USING
The following basic safety precautions should always be taken.
1. Close supervision is necessary when the thermometer is used by,
on, or near children, handicapped persons or invalids.
2. Use the thermometer only for the intended use described in this
manual.
3. Do not use the thermometer if it is not working properly, or if it has
suffered any damage..
KEEP THESE INSTRUCTIONS
Version 1.0 MAR. 2012
311-1240100-001

TABLE OF CONTENTS
CAUTIONS AND WARNINGS 05
RESTRICTIONS OF USE 05
INTRODUCTION 06
HIGHLIGHTED FEATURES 07
PACKAGE CONTENTS 07
THERMOMETER PARTS 08
DISPLAY SCREEN 08
DISPLAY MODE 09
SETTING THE THERMOMETER 10
REPLACING THE BATTERY 11
ABOUT NORMAL BODY TEMPERATURE & FEVER 12
USING THE DEVICE 14
As a Body Scan Thermometer 14
As a Surface Scan Thermometer 15
As a Room Scan Thermometer 16
RECALLING THE MEMORY 18
CARE & CLEANING 19
TROUBLESHOOTING 20
SPECIFICATIONS 21
SYMBOL INFORMATION 22

5
As with any thermometer, proper technique is crucial to obtaining
accurate temperature readings. Please read this manual thor-
oughly and carefully before using.
Always operate the thermometer in an operating temperature
range 10°C to 40°C (50°F to 104°F), and relative humidity less
than 95%.
Always store the thermometer in a cool and dry place -20°C to
60°C (-4°F to 140°F) and relative humidity less than 95%
Avoid direct sunlight.
Avoid dropping the thermometer, if it happens and you think the
thermometer may be damaged, please contact customer services
immediately.
Do not touch the lens.
Do not disassemble the thermometer.
Basic safety precautions should always be observed, especially
when the thermometer is used on or near children and disabled
persons.
This thermometer is not intended to substitute for a consultation
with your physician.
The forehead scan temperature serves as a reference only. It
cannot be a judgment on fever.
CAUTIONS AND WARNINGS
RESTRICTIONS OF USE
This thermometer is clinically proven to produce accurate tempera-
ture measurements. However, please be advised if you have the
following situations: The accuracy cannot be ensured when the
thermometer is not clean. Check that the probe is clean before tak-
ing a measurement.

6
INTRODUCTION
Thank you for choosing RT-1241 Thermometer. Please read this
and correctly. Please keep this instruction manual for future refer-
ence. This innovative medical device uses advanced infrared (IR)
technology to measure temperature instantly and accurately on the
forehead/surface.
Intended Use
RT-1241 Thermometer is intended for the intermittent measurement
and monitoring of human body temperature from forehead measure-
ment at home. The device is intended for use by people of all ages
in the home.
How does it work
The thermometer measures the infrared heat generated by the
surface of the skin over the vessel and its surrounding tissue. The
thermometer then converts it into a temperature value.
The thermometer does not emit any infrared signal.
NOTE

7
ASTM E1965-98 and the EC directive 93/42/EEC.
Non-contact measurement that does not require probe cover,
thereby saving cost of replacement.
Automatically power off if left idle for 30 seconds.
Memory function allows you to recall previous results up to 10
previous results.
Easy to read LCD with backlight in a dark environment.
Able to measure temperature of other objects without contact and
room temperature.
HIGHLIGHTED FEATURES
PACKAGE CONTENTS
RT-1241 Thermometer
Two 1.5V AA batteries
User’s Manual
Warranty Card

8
THERMOMETER PARTS
1°C / °F Button
2SET Button
3Probe
4Display Screen
5On/Scan Button
6MODE Button
7MEM Button
8Battery Cover
1Low battery indicator
2Date indicator
3Date/Time
4Temperature reading
5Body temperature indicator
6Object surface temperature
indicator
7Room temperature indicator
8Memory mode
9Temperature unit
10 Error warning
DISPLAY SCREEN
1
1
2
2
3
3
4
4
6
7
7
8
9
10
8
5
5
6

9
Three modes can be selected.
DISPLAY MODE
1. Body mode
This mode is used to measure
the forehead temperature.
It also provides clock.
2. Surface mode
This mode is used to measure
the object surface tempera-
ture.
It also provides clock.
3. Room mode
This mode is used to measure
the room temperature.
It also provides clock.

10
-
tery.
SETTING THE THERMOMETER
Step 1
Press the for 5
seconds to enter the setting mode.
Step 2 Set the date and time
Press the Mode or °C / °F button to select the correct month.
Press the to move on the next step.
Press the Mode or °C / °F button to select the correct day/year/
hour/minute.
Setting is all completed. The thermometer will automatically turn it off.

11
If the meter is idle for 30 seconds during the setting mode, it will
switch off automatically.
NOTE
1. Although the thermometer works when “ ” appears, we
still recommend that you change the batteries to obtain an
accurate result.
2. Remove the batteries if stored for a long period of time.
3. The batteries should be kept away out of child’s reach. If they
are swallowed, promptly see a doctor for help.
NOTE
The thermometer comes with two 1.5 V AA alkaline batteries. The
meter will display “ ” to alert you when the meter power is getting
low. If “ ” and appear both, please follow the steps below to
replace new batteries immediately.
REPLACING THE BATTERY
Step 1
Remove the battery cover as
the arrow direction accordingly.
(Figure 1)
Step 2
Remove the old batteries and
replace with two 1.5V AA size
alkaline batteries. (Figure 2)
Step 3
Close the battery cover. If the batteries are inserted correctly, you
will hear a “ beep ” afterwards.
(Figure 1) (Figure 2)

12
Body temperature can vary from one individual/person to next. It
also varies by location on the body and time of day. Below shows
the statistical normal ranges from different sites. Please keep in
mind that temperatures measured from different sites, even at the
same time, should not be directly compared. Fever indicates that
the body temperature is higher than normal. This symptom may be
caused by infection, overdressing or immunization. Some people
may not experience fever even when they are ill. These include, but
are not limited to, infants younger than 3 months old, persons with
compromised immune systems, persons taking antibiotics, steroids
or antipyretics (aspirin, ibuprofen, acetaminophen), or persons with
certain chronic illnesses. Please consult your physician when you
feel ill even if you do not have fever.
Table 1*1Body Site Normal Temperature Range
*1. Body Temperature at WebMD;
Oral 0.6°C (1°F) or more above or below 37°C
(98.6°F)
Rectal/ear 0.3°C to 0.6°C (0.5°F to 1°F) higher than oral
temperature
Axillary (armpit) 0.3°C to 0.6°C (0.5°F to 1°F) lower than oral
temperature
ABOUT NORMAL BODY
TEMPERATURE & FEVER

13
This meter provides two measurement units used for indicating the
body / surface / room temperature, °C or °F, for your preferred selec-
tion.
SELECT THE TEMPERATURE UNIT
Step 1
Press the
Step 2
Press the °C / °F button to select. Press the to begin the mea-
surement or keep the meter in idle for 30 seconds to automatically
turn it off.

14
USING THE DEVICE
As a Body Measurement Thermometer
Step 1 Remove the front protec-
tive cap if present. Press to
turn on the thermometer.
Step 2 Press the Mode button
for 5 seconds to enter the dis-
play mode to select Body mode.
The Body temperature indicator “ ”
Step 3 Move the probe close to
the forehead.
Press and hold the . Make sure the
at an angle. Perform a forehead measure-
ment with a distance within 5 cm.
Step 4 Read the result.
Release the button and read the result. “ ”
is shown together with a temperature value
and two short beeps.

15
As the forehead measurement temperature is likely to be af-
fected by sweat, oil and the surroundings, the reading shall be
taken as a reference only.
If the probe is placed at an angle close to the forehead
measurement, the reading will be affected by surrounding
temperature.
The thermometer will automatically turn off if left idle for 30
seconds.
NOTE
As a Surface Measurement Thermometer
Step 1 Remove the protective
cap if present. Press to turn
on the thermometer.
Step 2 Press the Mode button
for 5 seconds to enter the dis-
play mode to select Body mode.
The Surface temperature indicator “

16
Step 4 Read the result.
Release the button and read the result. “
” is shown together with a tempera-
ture value and two short beeps.
Step 3 Move the probe close to
the object surface.
Press and hold the . Make sure the
not at an angle. Perform an object mea-
surement with a distance within 5 cm.
As a Room Measurement Thermometer
Step 1 Remove the protective
cap if present. Press On/Scan
button to turn on the thermom-
eter.

17
Step 2 Press the Mode button
for 5 seconds to enter the dis-
play mode to select Room mode.
The Room temperature indicator “ ”
Step 4 Read the result.
Release the button and read the result. “
” is shown together with a temperature
value and two short beeps.
Step 3 Press and hold the On/Scan button.
The built-in sensor inside the thermometer will capture the ambient
temperature automatically.

18
RECALLING THE MEMORY
Your thermometer stores 10 most recent readings
Step 1
Be sure the thermometer is OFF before recalling this memory.
Step 2
Press the to turn on the thermometer.
Step 3
Press the MEM button to enter
the memory mode.
Each time you press the
MEM button, a result will be
displayed in the order of dates
-
gether with “ ” and number
( from 1 to 10 ).
When the memory is full, the
oldest result is deleted as the
new one added. When the
last record is displayed, press
MEM button again to return

19
Step 4 Exit the memory.
Press ON/SCAN button to return to the measurement mode or keep
the meter in idle for 30 seconds in the memory mode, it will switch
off automatically.
The probe is not waterproof. Please wipe with a clean and dry cot-
ton swab to clean the probe on the inside.
The body of the thermometer is not water-resistant. Never put the
thermometer under a running tap or submerge it into water. Use a
soft and dry cloth to clean it. Do not use abrasive cleaners.
Store the thermometer in a cool and dry location. Free from dust
and away from direct sunlight.
CARE & CLEANING

20
The table below shows problems you may encounter. All error
messages below would be shown together with backlight. Please
follow “what to do” to resolve problems. If the problem still exists,
please call your local dealer for help.
Message What it means What to do
Appear when envi-
ronmental tempera-
ture is below system
operation range.
Put the thermometer
under operating tem-
perature range of 10°C to
40°C (50°F to 104°F).
Appear when envi-
ronmental tempera-
ture is above system
operation range.
Put the thermometer
under operating tem-
perature range of 10°C to
40°C (50°F to 104°F).
Battery is low and “
” appears on LCD.
Please replace batteries
as soon as possible.
Problem with the
thermometer.
Please put the thermom-
eter under operating
temperature range of
10°C to 40°C (50°F to
104°F). If the problem is
unsolved, please contact
the customer service line.
Battery is very low. Please replace batteries
prior to further use.
Body mode tem-
perature is below
22°C (71.6°F)
Please follow this manual
to take a reading again.
Body mode tem-
perature is above
44°C (111.2°F)
TROUBLESHOOTING

21
SPECIFICATIONS
Model no. RT-1241
Dimensions 150mm(L) x 48.48mm(W) x
55.16mm(H)
Weight 128.8 g
(include 2 x1.5V AA batteries)
Battery 2 x 1.5 V AA alkaline batteries
Displayed temperature range 22°C to 44°C (71.6°F to 111.2°F)
Display resolution 0.1°C / 0.1°F
Accuracy
±0.2°C (±0.4°F) for the range
of 36.0°C to 39.0°C (96.8°F to
102.2°F)
±0.3°C (±0.5°F) for less than
36.0°C (96.8°F) and greater
than 39.0°C (102.2°F)
Temperature unit °C or °F
Operating temperature range 10°C to 40°C (50°F to 104°F)
Operating humidity 95% RH or less
Storage temperature range -20°C to 60°C (-4°F to 140°F)
Storage humidity 95% RH or less
Memory capacity 10 measurements
