Numatic TGB 6055/100 User manual

Warning! Read instructions before using the machine
Owner Instructions
TGB 6055/100
TGB 6055/100T
BATTERY SCRUBBER DRYER
www.numatic.co.uk

Machine Overview ................................ Pages 2/3
Control Panel Overview ................................ Page 4
Machine Set up Guide ................................ Page 5
Fitting the Brush / Pad ................................ Page 6
Fitting the Floor Tool ................................ Page 6
Fitting the Hose Guide ................................ Page 7
Filling the Clean Water Tank .......................... Page 7
Fill Level Indicator .............................. Page 8
Lowering the Floor Tool ................................ Page 9
Raise / Lower Brush Deck............................... Page 9
Setting the Cleaning Controls .................... Page 9
Brush Pressure .............................. Page 10
Breakaway Floor Tool ................................ Page 10
Machine in Use ................................ Page 10
Machine Cleaning ................................ Page 11
Waste Water Tank Full ................................ Page 11
Changing Floor tool Blades............................. Page 12
Machine Charging ................................ Page 13
Battery Care ................................ Page 14
Charging Lights Sequence .............................. Page 14
TGB6055/100T Operation ............................ Page 15/16
Specications ................................ Page 17
Trouble Shooting ................................ Page 17/18
Rating Label / Personal Protective
Equipment /Recycling ................................ Page 19
Safety Precautions ................................ Page 20/21
Recommended Spare Parts .......................... Page 22
Schematic Diagram ................................ Page 22
Battery Wiring ................................ Page 23
EU Declaration Document ............................. Page 24
Warranty ................................ Page 25
Company Address ................................ Page 28
BATTERY SCRUBBER DRYER
Index
After the removal of all the packaging,
carefully open and check the contents
● Owner Manual ● 2 x Ignition Keys
● Battery Charging Lead ● 2 x 40 Amp Fuse
(Battery) ● 1 x 30 Amp Fuse (Brush)
● 1 x 20 Amp Fuse (Vac)
● 1 x 2.5 Amp Fuse ● Maxi Fuse-puller
For Charger-less Model, all the above plus:
● 1 x Charger Connector ● 2 x Charger
Connector Terminals ● 4 x Battery Terminal
Connectors ● 1 x Fuse Holder
PLEASE READ
BEFORE COMMENCING
OPERATION
1Operator control panel
2Charging Socket / Point
3Clean Water Fill Point
4Floor Tool Raise / Lower Lever
5Clean Water Tank Emptying Hose & Fill Level
6Vacuum Hose
7Charging Lights
8Brush Deck Lifting Pedal
9Extra Brush Load Pedal
10 Semi Parabolic Floor Tool
11 Brush On/O / Control Handle
12 Safety Fuse 2.5 Amp
13 Batteries
14 40 Amp Battery Fuse (50 Amp in Traction Machine)
15 Brush Motor Fuse 30 Amp
16 Vac Motor Fuse 20 Amp
17 Brush Deck
18 Clean Water Filter
19 Water Flow Tap
20 Waste Water Emptying Hose
21 Separator
22 Top Tank (Waste Water)
23 Bottom Tank (Clean Water)
24 Detent Pin
25 Key Ignition. On/O
TGB 6055/100

6
4
2
1
3
14
15
16
17
9
8
7
11
Machine Overview
5
10
13
12
18
20
19
21
22
23
24
25
For Traction Drive Twintec see pages 15 & 16

TGB 6055/100
BATTERY SCRUBBER DRYER
1Key Ignition Switch
2Hours Meter
3Battery Charge Level Indicator
4Vacuum Pick Up On / O
5Water Flow On / O
6Brush On / O / Control Handle
Control Panel Overview
In the event of a breakdown contact
your Numatic dealer or the
Numatic Technical
help line [phone]
2
1
5
3
6
4

5
T 01460 68600
Insert the Ignition key and
switch the machine on.
(Fig. A)
Use handle grip when
raising or lowering the
top waste-tank.
Fuse Location
Machine Set-up Guide
TGB 6055/100 CONTENTS
● 2xIgnition Keys ● 2 x 40 Amp Fuse
(Battery) ● 1 x 30 Amp Fuse (Brush)
● 1 x 20 Amp Fuse (Vac)
● 1 x 2.5 Amp Fuse ● Maxi Fuse-puller
For Charger-less Model,
all the above plus:
● 1 x Charger Connector ● 2 x Charger
Connector Terminals
● 4 x Battery Terminal Connector
covers ● 1 x Fuse Holder
Lift top tank assembly to reveal battery
compartment, ensuring you use the handle
grip provided.
Fit battery fuse (contained in start-up pack)
into the battery fuse holder as illustrated.
(Fig. 1, 2, 3.)
Insert Key into ignition located on the
control panel (See below (Fig. A)
NOTE: Wear suitable gloves when
inserting fuses.
Using the control handle with both hands,
slowly push the machine o the pallet.
When the machine is removed and in a safe position,
release the control handle.
Note: Do not pull the RED trigger handle while in
transport mode (Fig. B)
During vehicular transportation ensure the product
is secured to avoid unnecessary movement.
PLEASE READ BEFORE COMMENCING ANY OPERATION AFTER THE REMOVAL OF ALL
THE PACKAGING, CAREFULLY OPEN AND CHECK THE CONTENTS. !!
B
A
1
2
3
Ensure that no metal objects come into contact with battery terminals while the batteries
are exposed. When inserting the rst fuse you may notice a spark, this is normal. !!
Less Battery Models - Numatic International Ltd recommends using MK Batteries for 6055 and 6055T in the TGB machines
mentioned in this manual. For full battery spscications see page 22.

6
T 01460 68600
Fit the oor tool and retain using the
detent pin.
Push waste collection pipe onto the
oor tool; ensure a tight t.
Raise the oor tool for transit or
lower for cleaning operation using
the lifting handle tted to the back
of the machine.
For tting the oor tool blades
(See Page 12).
Machine Set-up Guide
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF
BEFORE MAKING ANY ADJUSTMENTS !!
550mm Brush or a 500mm Pad on the TGB 6055/100.
Featuring the Nulock brush system.
The brush is simply pushed and twisted to lock, making tting and removal a simple process.
Slide the brush / pad under the brush deck.
Fit the brush / pad onto the Nulock drive chuck, twist to lock the brush / pad in place.
Safety gloves are recommended for the changing of used brushes.
Turn on the clean water tap.
Fitting the Brush / Pad / Turn on water
Fitting the Floor Tool
The oor tool has been designed for quick tting, allowing easy squeegee blade replacement and a safety knock-o feature if the
oor tool gets snagged, whilst in transit.
NOTE: It is easier to t the oor tool if the weight of the machine is resting on the brush. Ensure the brush is tted rst.

7
T 01460 68600
The vacuum hose has a U-bend clip which creates a U-bend in the hose preventing water spillage when the vacuum is switched
o. If you need to remove the U-bend clip for any reason always ensure it is retted correctly before you resume operation.
Fitting the Hose Guide
NOTE: DO NOT push the vacuum hose
onto the oor tool with the oor tool in
the raised position.
Machine Set-up Guide
Ret vacuum hose to the
Floor tool when nished.
250mm - 300mm
NOTE: Great care must be taken to ensure that contaminants (leaves, hair, dirt, etc.) are not allowed to enter the clean water
tank during the lling process. If using a bucket or similar, ensure it is always clean and free from debris.
The TGB 6055/100 is equipped with a large capacity clean water tank allowing for large areas to be covered in a single ll.
Filling the Clean Water Tank
10
To ll the clean water tank, extend the hose located to the rear of the machine in the centre of the removable ller cap (1). Pull out
hose. Open the stopper and place hose under water tap, or use a hose to commence lling. The tank can also be lled by unscrewing
the ller cap and using a bucket or similar container (2).
1
2

8
T 01460 68600
The water level in the clean-water tank
can be measured using the scale on the
left rear side of the machine. The clean
water bottom tank holds 60 litres.
NOTE: always ensure that the waste
water tank is empty before lifting.
Machine Set-up Guide
Fill Level Indicator
WHEN HANDLING AND MIXING CHEMICALS
Always ensure that chemical manufacturer’s safety guidelines are followed.
Only use chemicals recommended for use in auto scrubber-dryers. !!
The machine is now ready to be moved to
the cleaning site.
Before performing the cleaning operation,
place out appropriate warning signs and
sweep or dust-mop the oor.
IMPORTANT
Do not operate machine unless the Operator Manual has been read and fully understood. !!

9
T 01460 68600
The control for lowering the brush deck can be found to the rear right of the machine.
Lower the brush deck by moving the left hand release lever to the upper position.
After preparing the oor (see previous
section), we are now ready to set the
controls to suit the cleaning conditions.
Before any settings can be applied,
ensure the brush deck is lowered. Move
the oor tool lever to its lower position.
NOTE: Do not pull the machine
backwards with the oor tool in the
lowered position, this could possibly
damage the blades.
Raising/Lowering
the Floor Tool
Machine Operation
Raising/Lowering the Brush Deck
Using the control handle with both hands, push the machine forward.
The battery charge level meter will illuminate for 5 seconds. (Fig. 1)
Switch on the Water Flow Rate (Fig. 2), and vacuum pick up (Fig. 3).
Setting the Cleaning Controls
oo
1
2
3

10
T 01460 68600
Machine Operation
The brush load lever is located to the right hand side of the machine.
This option is for hard to clean patches, adding extra pressure to the brushes.
NOTE: It is recommended this option is NOT used all the time and is for spot cleaning only.
The run-time of the machine may decrease if the load on the brushes is increased.
Brush Pressure / Load Adjustment
To operate, set water ow rate tap, lower brush deck, lower the oor tool, press the vacuum / water switches, pull brush On/O trigger.
The waste water is then retrieved by the suction oor tool.
Overlap each scrubbing path by 10cm to ensure an even clean.
Do not operate the machine on inclines that exceed (2%), (9%) for Traction machines, when full.
On heavily soiled oors use a ‘double scrub’ technique.
First pre-scrub the oor with the oor tool in the raised position, allow the chemical time to work then scrub the area a second time
with the oor tool lowered.
If streaking occurs wipe oor tool blades clean.
NOTE: Care must be taken to reduce speed when cornering or when manoeuvring around obstacles
The oor tool design incorporates a
break-away feature.
Allowing it to safely disengage from its
mounting should it become caught on
an obstruction, during forward machine
movement.
To re-attach the blade to its holder. First
loosen the retaining knobs on the oor tool
body and slide onto the holding bracket.
Tighten retaining knobs to nger tight.
Break-away Floor Tool
Machine In Use
ALWAYS ENSURE THAT THE FLOOR IS PRE-SWEPT
AND RELEVANT SAFETY SIGNS ARE DISPLAYED. !!
(A) Standard Duty
24 Kg Pressure
(B) Heavy Duty
32 Kg Pressure
A
B
