REBL plus Instructions REBL plus Instructions
EN EN
Contents
Product information
Product Registration 3
Warranty 3
Contact 3
Child Usage Requirements 4
For Use with Base 5
Parts List 7
Warnings 8
Product Use 13
Cleaning and Maintenance 21
French (FR) 23
Dutch (NL) 53
German (DE) 75
Italian (IT) 97
Spanish (ES) 119
Türkiye (TR) 141
한국어 (KR) 164
Polish (PL) 173
IMPORTANT!
KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE:
READ CAREFULLY

43
REBL plus Instructions REBL plus Instructions
EN EN
Product Information
Model Number:______________________________________________________________________________________________________________________
Manufactured in (date):_______________________________________________________________________________________________
Product Registration
Please fill in the above information. The model number
and the manufactured in date are located on the bottom
of the REBL plus.
To register your product please visit:
www.nuna.eu/register-gear
Warranty
We have purposely designed our high-quality products
so that they can grow with both your child and your
family. Because we stand by our product, our gear is
covered by a custom warranty per product, starting
from the day it was purchased. Please have the proof
of purchase, model number and manufactured in date
available when you contact us.
For warranty information please visit:
www.nuna.eu/warranty
Contact
For replacement parts, service, or additional warranty
questions, please contact our customer service
department.
[email protected]
www.nuna.eu
Child Usage Requirements
This product is suitable for use with children who meet
the following requirements:
Rearward Facing:
Child height 40cm-105cm / Child weight<=18.5kg
Forward Facing:
Child height 80cm-105cm / Child weight<=18.5kg
NOT allowed to use forward facing before the age of 15
month.
In the United Kingdom:
[email protected]
www.nuna.eu
Installation
Mode InstallationRecline Position
1-7
1-7
Baby
mode
Toddler
mode
Child height 40cm–105cm/
Child weight≤18.5kg
Child height 80cm–105cm/
Child weight≤18.5kg
Age ≥ 15 months

65
REBL plus Instructions REBL plus Instructions
EN EN
For use with base
1 According to the ECE R129/00 Regulation, the child
restraint with base is a Universal ISOFIX Class B1, D
Child Restraint and should be fitted using the ISOFIX
connections.
2 This is an "i-Size" Child Restraint System. It is
approved to Regulation ECE R129/00, for use in,
"i-Size compatible" vehicle seating positions as
indicated by vehicle manufacturers in the vehicle
users’ manual.
3 If in doubt, please consult the child restraint
manufacturer or the retailer.
ECE. R129/00
i-Size UNIVERSAL
ISOFIX
Rearward facing
40cm-105cm
≤18.5kg
Forward facing
80cm-105cm
≤18.5kg
000005
This is an i-Size ISOFIX Child Restraint SYSTEM. It
is approved to ECE R129/00 series of amendments,
not all vehicle manufacture's handbooks list i-Size
compatibility yet. This child restraint and base is also
approved for use in ISOFIX compatible vehicles. Please
refer to the vehicle manufacturer's website or consult
your dealer.
It will fit vehicles with positions approved as i-Size
ISOFIX positions (as detailed in the vehicle handbook),
depending on the category of the child restraint and of
the fixture. If in doubt, consult either the child restraint
manufacturer or vehicle manufacturer.

87
REBL plus Instructions REBL plus Instructions
EN EN
1 Head Support
2 Infant Insert
3 Seat Pad
4 Adjustment Webbing
5 Recline Adjustment
Button
6 Load Leg Adjustment
Button
7 Load Leg
8 Load Leg Indicator
9 Load Leg Adjustment
Button
10 ISOFIX Adjustment
Button
11 Rotating Button
12 Buckle
13 Shoulder Strap
14 Head Support
Adjustment Lever
15 Rebound Bar
16 ISOFIX Connector
17 ISOFIX Guides
18 ISOFIX Release
Button
Parts List
1
2
4
5
6
7
89
10
11
12 14
15
16
3
17
18
13
Warning
NO child restraint can guarantee full
protection from injury in an accident. However,
proper use of this child restraint will reduce
the risk of serious injury or death to your child.
To use this child restraint with the ISOFIX
connections according to the ECE R129/00
Regulation, your child must meet the following
requirements.
Rearward Facing: Child height 40cm–105cm/
Child weight≤18.5kg;
Forward Facing: Child height 80cm–105cm/
Child weight≤18.5kg;
Any straps of child restraint should be
tightened and not twisted.
DO NOT use forward facing before the
child’s age exceeds 15 months. Keep your
child rearward facing as long as possible as
rearward facing is the safest position.
DO NOT install this child restraint without
following the instructions in this manual or you
may put your child at serious risk of injury or
death.
NEVER leave your child unattended with this
child restraint.

109
REBL plus Instructions REBL plus Instructions
EN EN
DO NOT make any modification to this child
restraint or use it along with component parts
from other manufacturers.
DO NOT use this child restraint if it has
damaged or missing parts.
DO NOT have your child in large/oversized
clothes because this may prevent your child
from being properly and securely fastened by
the shoulder harness straps and the crotch
strap between the legs.
DO NOT leave this child restraint or other
items unbelted or unsecured in your vehicle
because an unsecured child restraint can be
thrown around and may injure occupants in a
sharp turn, sudden stop, or collision.
DO NOT place rear-facing child restraint on
frontal seat with air bag. Death or serious
injury may occur. Please reference vehicle
owner’s manual for more information.
NEVER use a second-hand child restraint
or an child restraint whose history you do
not know because they may have structural
damage that endangers your child’s safety.
NEVER use ropes or any other substitutes to
secure child restraint in vehicle or to secure
child into child restraint.
DO NOT use this child restraint without the
soft goods.
The soft goods should not be replaced with
any besides the ones recommended by the
manufacturer. The soft goods constitute an
integral part of the child restraint performance.
DO NOT put anything other than the
recommended inner cushions in this child
restraint.
Be sure that the child restraint is installed in
such a way that no part of it interferes with
movable seats or in the operation of vehicle
doors.
DO NOT continue to use this child restraint
after it has suffered any type of crash, even a
minor one. Replace immediately as there may
be invisible, structural damage from the crash.
Remove this child restraint from the vehicle
seat when it is not in regular use.
Consult the distributor for issues concerning
maintenance, repair and part replacement.
To avoid the risk of falling out, always secure
the child using the safety harness when the
child is placed in child restraint, even when
the child restraint is not in the vehicle.

1211
REBL plus Instructions REBL plus Instructions
EN EN
Before carrying the child restraint by hand,
ensure that the child is fastened with the
safety harness, and that the handle is correctly
locked in a vertical position.
To avoid serious injury or death, NEVER place
child restraint on elevated surface seat with
child in it.
The parts of this child restraint should not be
lubricated in any way.
Always secure child in child restraint, even
on short trips, as this is when most accidents
occur.
Please keep this child restraint away from
sunlight, otherwise it may be too hot for child’s
skin. Always touch the child restraint before
placing child in it.
Frequently check the ISOFIX guides for dirt
and clean them if necessary. Reliability can be
effected by ingress of dirt, dust, food particles
etc.
DO NOT place any objects in the load leg area
in front of your child restraint.
Correct Installation is only permitted by use of
the ISOFIX connectors.
After your child is placed in this child restraint,
the child harness must be used correctly, and
ensure that any lap strap is worn low down, so
that the pelvis is firmly engaged.
DO NOT use any load bearing contact points
other than those described in the instructions
and marked on the child restraint.
Must use the rebound bar.

1413
REBL plus Instructions REBL plus Instructions
EN EN
Product Use
DO NOT install this child restraint on vehicle seats that
face sideways (1) or rearward (1) with respect to the
moving direction of the vehicle.
DO NOT place rear-facing child restraint on front
seat with air bag. Death or serious injury may occur.
(1) Please reference vehicle owner’s manual for more
information.
It is recommended to install this child restraint on the
rear vehicle seat. (1)
This child restraint is suitable for vehicle seats with
i-Size ISOFIX anchor points. (2)
DO NOT install this child restraint on vehicle seats
unstable during installation.
Installation
1 - Unfold the load leg from the storage compartment.
(3)
2 - Fit the ISOFIX guides into the ISOFIX anchor points.
(4) The ISOFIX guides can protect the surface of the
vehicle seat from being torn. They will also guide
the ISOFIX connectors.
3 - Press the ISOFIX release button on either side of
the base, then pull out the ISOFIX connectors. (5)
4 - Line up the ISOFIX connectors with the ISOFIX
guides, and then click both ISOFIX connectors into
the ISOFIX anchor points. (6)
Make sure that both ISOFIX connectors are securely
attached to their ISOFIX anchor points. There should
be two audible clicks and the colors of the indicators
on the both ISOFIX connectors should be completely
green. (6)-1
Check to make sure the child restraint is securely
installed by pulling on the both ISOFIX connectors.
5 - There are 9 adjustable positions for ISOFIX. Press
the ISOFIX release button and push the base back
against the vehicle seat until tight.
6 - After placing the child restraint on the vehicle
seat, extend the load leg to floor. (7), The load leg
indicator will show green when installed correctly,
red means it is installed incorrectly. (7)
The load leg has 24 positions. When the load leg
indicator shows red this means the load leg is in the
wrong position.
Make sure the load leg is secure by pressing down
on the front of the child restraint.
To shorten the load leg, squeeze the load leg
release button and pull the load leg upwards.
7 - To remove the child restraint, press the ISOFIX
release button (5)-1 and pull the base away from
the seat, then while squeezing the button and
secondary lock on the ISOFIX connectors remove
from the vehicle. (8)
8 - Press the ISOFIX release button to store the ISOFIX.
(9)

1615
REBL plus Instructions REBL plus Instructions
EN EN
The completely assembled child restraint is shown as
(10)
Recline Adjustment
Squeeze the recline adjustment button (11)-1, to adjust
the child restraint to the proper position. The recline
angles are shown as (11).
Please recheck the load leg position after reclining.
There are 7 recline angles for baby mode and 7
positions for toddler mode.
Baby Mode (Rearward Facing Mode)
Rearward Facing Child height 40cm-105cm/Child
weight≤18.5kg
Recline position Position 1-7
1 - Press the rotating button to rotate the seat facing
the rear of the vehicle. (12)(13)
Please recline the seat to be in positions 3 through
7 for ease of rotation.
2 - Rearward facing mode assembled as (13)
The ISOFIX connectors must be attached and
locked onto the ISOFIX anchor points. (13)-1
The load leg must be installed correctly with green
indicator. (13)-2
Height Adjustment
for Head Support and Shoulder Harnesses
Check that Shoulder Harness Straps are set at the
proper height.
Shoulder Harness Straps must be at a height nearest to
your childs shoulders (14), but not above the shoulder
line. (15)
If the Shoulder Harness Straps are not at the proper
height, the child might be ejected the child restraint if
there is a crash.
Squeeze the head support adjustment lever (16), while
pulling up or down on the head support until it snaps
into one of the 7 positions. The head support positions
are shown as (17).
Securing Child
After the child is placed into the seat, check whether
the Shoulder Harness Straps are at proper height.
1 - While pressing the adjustment button located at
the front of the child restraint, pull the two Shoulder
Harness Straps of the child restraint. (18)
2 - Unlock the buckle of the harnesses by pressing the
red button. (19)
3 - Fix the buckles on the both sides of seat to make
placing the baby more convenient. (20)

1817
REBL plus Instructions REBL plus Instructions
EN EN
4 - Use Infant Insert
Infant insert is for children’s protection. (21)
5 - Place the child into the child restraint and lock the
buckle. Please refer to. (22)
6 - Tighten the shoulder harness straps by pulling the
adjustment webbing. (23)
Make sure the space between the child and the
Shoulder Harness Straps is about the thickness of one
hand.
1
2
Detach the snaps on
the head support to
remove the head
portion of the insert.
We recommend
using the full infant
insert while the baby
is under 60 cm or
until they outgrow
the insert. The infant
insert increases side
impact protection.
Remove the head
support portion of
the infant insert
when the child’s
head no longer fits
comfortably.
Remove the body
portion of the infant
insert when the
infant’s shoulders no
longer fit comfortably.
The cushion can
be used separately
without being
attached to the
insert to bolster
the infant's back
for more comfort.
Remove the infant
insert cushion by
detaching the snaps
to allow more space
when the infant does
not fit comfortably.
Toddler Mode
(Forward Facing Mode)
Forward Facing
Child height 80cm-105cm/Child weight≤18.5kg
Recline position Position 1-7
NOT allowed to use forward facing before the age
of 15 month.
1 - Press the rotating button to rotate the seat facing
the vehicle's moving direction. (24)(25)
Please recline the seat to be in positions 3 through
7 for ease of rotation.
2 - Forward facing mode assembled as (25)
The ISOFIX connectors must be attached and
locked onto the ISOFIX anchor points. (25)-1
The load leg must be installed correctly with green
indicator. (25)-2
Securing Child
After the child is placed into the seat, check whether
the Shoulder Harness Straps are at the proper height.
(26)
1 - While pressing the adjustment button located at
the front of the child restraint, pull the two Shoulder
Harness Straps of the child restraint. (18)
2 - Unlock the buckle of the harnesses by pressing the
red button. (19)

2019
REBL plus Instructions REBL plus Instructions
EN EN
3 - When installing the child restraint in the toddler
mode, do not use the infant insert.
4 - Fix the buckles on the both sides of seat to make
placing the baby more convenient. (20)
5 - Place the child into the child restraint and lock the
buckle. Please refer to. (22)
6 - Tighten the shoulder harness straps by pulling the
adjustment webbing. (27)
Make sure the space between the child and the
Shoulder Harness Straps is about the thickness of
one hand.
Detach Soft Goods
1 - Open the buckle, then remove the infant insert.
2 - Open the snaps. (28)
3 - Push the crotch strap through the crotch strap
opening. (29)
4 - Open the snaps on the main seat pad behind
shoulder harnesses. (30) Move the shoulder
harnesses behind the flap below the headrest. (31)
5 - Detach the hook and loop fasteners to remove the
shoulder belt cover. (32)
6 - Unfasten the elastic on the bottom of headrest to
remove the head support soft goods. (33)
7 - Remove the soft goods. (34)
To assemble winter and summer soft goods according
to reversed steps above.
Please keep the instruction manual in the storage
compartment at the bottom of the child restraint (35).

2221
REBL plus Instructions REBL plus Instructions
EN EN
Cleaning and Maintenance
After removing the wedge from the insert, please store
it somewhere that the child cannot access it.
Please wash the bottom seat pad and the top seat cover
with cold water under 30°C.
Do not iron the soft goods.
Do not bleach or dry clean the soft goods.
Do not use undiluted detergents, gasoline or other
organic solvents to wash the child restraint. It may
cause damage to the product.
Use only mild detergent, water and a soft cloth to clean
the child restraint shell, handle and harness straps.
Do not twist the soft goods to dry with great force. It
may leave the soft goods with wrinkles.
Please hang dry the soft goods in the shade.
Please remove the child restraint from the vehicle seat
if not in use for a long period of time. Put the child
restraint in a cool, dry place and somewhere your child
can not access it.
©2018 Nuna International B.V. Nuna and all associated logos are trademarks.

2423
Instructions REBL plus Instructions REBL plus
FR FR
Sommaire
Informations sur le produit
Enregistrement du produit 25
Garantie 25
Contact 25
Exigences d’utilisation par les enfants 26
Utilisation avec la base 27
Liste des pièces 29
Avertissements 30
Utilisation du produit 35
Nettoyage et maintenance 43
IMPORTANT !
CONSERVEZ CES
INSTRUCTIONS POUR UNE
UTILISATION FUTURE !
LIRE ATTENTIVEMENT

2625
Instructions REBL plus Instructions REBL plus
FR FR
[email protected]
www.nuna.eu
Exigences d’utilisation
par les enfants
Ce produit convient aux enfants qui rencontrent les Les
exigences suivantes:
Orientation vers l’arrière :
Taille entre 40 cm-105 cm / Poids ≤ 18.5 kg
Orientation vers l’avant :
Taille entre 80 cm-105 cm / Poids ≤ 18.5kg
NON autorisé à utiliser vers l’avant avant l’âge de 15
mois.
Informations sur le produit
Numéro de modèle :_________________________________________________________________________________________________________
Fabriqué le (date) :______________________________________________________________________________________________________________
Enregistrement du produit
Veuillez remplir les informations ci-dessus. Le numéro
de modèle et la date de fabrication se situent sur une
étiquette sur la REBL plus.
Pour enregistrer votre produit, veuillez vous rendre sur
le site suivant : https://www.nuna.eu/register-gear
Garantie
Nous avons conçu spécialement nos produits de
haute qualité afin qu’ils puissent accompagner le
développement de votre enfant et de votre famille.
Nous soutenons notre produit en couvrant notre
matériel par une garantie personnalisée, commençant
le jour de son achat. Ayez la preuve d’achat, le numéro
de modèle et la date de fabrication à votre disposition
lorsque vous nous contactez.
Pour des informations sur la garantie, veuillez vous
rendre sur le site suivant :
http://www.nuna.eu/warranty
Contact
Pour des informations sur les pièces de rechange,
le service ou des questions supplémentaires sur la
garantie, veuillez contacter notre service client.
Au Royaume-Uni:
[email protected]
www.nuna.eu
Mode
d'installation Installation Position inclinée
1-7
1-7
Mode
bébé
Mode
bambin
Taille de l'enfant entre 40 cm
et 105 cm/
Poids de l'enfant≤18,5 kg
Taille de l'enfant entre 80 cm
et 105 cm/
Poids de l'enfant≤18,5 kg
NON autorisé à utiliser vers
l'avant avant l'âge de 15 mois

2827
Instructions REBL plus Instructions REBL plus
FR FR
Utilisation avec la base
1 Conformément à la réglementation ECE R129/00, ce
siège enfant avec base est un siège enfant ISOFIX
universel de classe B1, D et doit être installé avec des
connexions ISOFIX.
2 Il s’agit d’un système de sécurité pour enfants
« i-Size ». Son utilisation est approuvée par la
réglementation ECE R129/00 pour des sièges de
véhicule «compatibles i-Size » comme indiqué dans
le manuel de l’utilisateur du véhicule fourni par votre
constructeur.
3 En cas de doute, veuillez consulter le fabricant ou
revendeur du siège enfant.
ECE. R129/00
i-Size UNIVERSAL
ISOFIX
Rearward facing
40cm-105cm
≤18.5kg
Forward facing
80cm-105cm
≤18.5kg
000005
Il s'agit d'un SYSTÈME DE SÉCURITÉ pour enfants
ISOFIX « i-Size ». Il a été approuvé pour la série
d'amendements ECE R129/00, tous les manuels des
constructeurs de véhicule ne mentionnant pas encore
une compatibilité i-Size. Ce siège et cette base sont
aussi approuvés pour une utilisation dans des véhicules
compatibles ISOFIX. Veuillez vous reporter au site Web
du constructeur de votre voiture ou consulter votre
revendeur.
Il conviendra aux véhicules avec des positions
approuvées en tant que positions ISOFIX i-Size (comme
détaillé dans le manuel du véhicule), selon la catégorie
de siège enfant et de la fixation. En cas de doute,
veuillez consulter le fabricant du siège enfant ou le
constructeur du véhicule.
