Nussbaum JUMBO HFK 7000 Quick start guide

OWNERS / INSTALLATION
MANUAL
JUMBO HFK 7000 SCISSOR LIFT
ISSUE 4 USA
6/5/20
Lift Manufacturer:
Nussbaum Automotive Solutions, LP
1932 Jordache Court
Gastonia, North Carolina 28052

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
2
This Lift and Guide belongs to the owner(s):

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
3
TABLE OF CONTENTS
1. LIFT PURPOSE............................................................................................................................................................................................... 4
2. LIABILITY...................................................................................................................................................................................................... 4
3. OWNER/EMPLOYER RESPONSIBILITIES...................................................................................................................................................... 4-5
3.1. ADDITIONAL OWNER/EMPLOYER RESPONSIBILITIES ....................................................................................................................................................6
4. LIFT OPERATOR RESPONSIBILITIES................................................................................................................................................................ 6
5. SAFETY REGULATIONS............................................................................................................................................................................... 6-7
OPERATING INSTRUCTIONS................................................................................................................................................................................... 9
5.1. TO LOAD VEHICLE...............................................................................................................................................................................................9
5.2. TO LIFT VEHICLE............................................................................................................................................................................................9-10
5.3. TO LOWER AND UNLOAD VEHICLE.........................................................................................................................................................................10
6. INSPECTION AND MAINTENANCE PLAN.......................................................................................................................................................11
6.1. HOW OFTEN MUST THE LIFT BE CLEANED? ..............................................................................................................................................................11
6.1.1. DAILY MAINTENANCE ...................................................................................................................................................................................11
6.1.2. YEARLY MAINTENANCE..................................................................................................................................................................................12
6.2. LIFT MAINTENANCE...........................................................................................................................................................................................13
7. TECHNICAL INFORMATION..........................................................................................................................................................................14
8. TROUBLESHOOTING....................................................................................................................................................................................15
9. FILL AND VENT THE HYDRAULIC SYSTEMS ...................................................................................................................................................16
10. INSTALLATION AND INITIATION..............................................................................................................................................................16
10.1. SAFETY CHECKS ..............................................................................................................................................................................................166
10.2. PREPARE LIFT ASSEMBLY LOCATION ......................................................................................................................................................................17
10.3. INSTALLATION WITH DRIVE THROUGH DOOR .............................................................................................................................................17
10.4. INSTALLATION ON AN INTERIOR BAY WITH EXISTING LIFTS.........................................................................................................................17
10.5. ESTABLISHING FRONT OR REAR PLATFORM GUIDELINES ............................................................................................................................18
11. LIFT INSTALLATION .................................................................................................................................................................................19
11.1. UNPACK CONTAINER AND LOCATE ALL PIECES (FIGURES 7&8)....................................................................................................................................19
11.2. POSITION CONTROL STATION &PLATFORMS.........................................................................................................................................20-21
11.3. MOUNTING THE PLATFORM, CONTROL STATION AND HOSE COVERS.........................................................................................................22
11.4. ATTACHING PLATFORM EXTENSIONS..........................................................................................................................................................23
11.6. BLEEDING AND EQUALIZATION OF THE LIFT..................................................................................................................................................24
12. FINAL INSTALLATION CHECKOUT INSTRUCTIONS ...............................................................................................................................24-25
13. REGULAR INSTALLATION CHECKOUT INSTRUCTIONS ..............................................................................................................................26
APPENDIX 1: FLOOR PLAN ....................................................................................................................................................................................27
1.1. 1. CONCRETE REQUIREMENTS:............................................................................................................................................................................27
APPENDIX 2: LIFT DIMENSIONS ............................................................................................................................................................................28
APPENDIX 3: CONCRETE ANCHOR SPECIFICATIONS...............................................................................................................................................29
APPENDIX4: HYDRAULIC DIAGRAM ......................................................................................................................................................................30
1. HYDRAULIC PARTS LIST ..................................................................................................................................................................................31
APPENDIX5: ELECTRICAL DIAGRAM-400-230 V 3-PHASE .......................................................................................................................................32
APPENDIX6: FLUSHMOUNT CONCRETE PIT DRAWING ..........................................................................................................................................33
APPENDIX6: FLUSHMOUNT INSTALLATION DRAWING……………………………………………………………………………………………………………………………………34-35

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
4
1. Lift Purpose
Nussbaum lifting systems are the result of over 35 years experience in the automotive lifting industry. The high quality
and superior concept ensures reliability, a long lift lifetime, and a strong economic business solution for your automotive
lifting needs. The JUMBO is a scissor lift with a lifting capacity of 7,000 pounds. The Lift features a powerful 4.0hp
motor and hard-chromed cylinder sets.
2. Liability
To avoid unnecessary damage, injury or death, read all operating instructions carefully. Nussbaum Automotive
Solutions, LP is not liable for any damages, injuries, or deaths resulting from misuse of the Lift. The user carries the
risk alone.
There will be no guarantee or liability for incidents involving injuries, death, or damage to equipment if these incidents
are the result of one or more of the following:
•Inappropriate use of the Lift to include: Inappropriate installation, operation, and maintenance of the Lift.
•Use of the Lift while security devices are inoperative, not working properly, or are installed incorrectly.
•Failure to follow the operating instructions regarding transport, storage, installation, initiation, operation, and
maintenance of the Lift.
•Unauthorized changes to the design and operation of the Lift.
•Wrong or incorrect maintenance practice.
•Catastrophes, acts of God, or external reasons.
•Nussbaum Lifts are warrantied with the use of Nussbaum original or replacement parts. Use of unauthorized
parts may void the warranty. For parts, call Nussbaum Automotive Solutions at 1-704-864-2470.
•It should be recognized that any piece of equipment can be dangerous when operated improperly.
3. Owner/Employer Responsibilities
AUTOMOTIVE LIFT INSTITUTE SAFETY REQUIREMENTS FOR OPERATION, INSPECTION AND MAINTENANCE (ANSI/ALI
ALOIM)
The Owner/Employer Must insure that lift operators are qualified and that they are trained in the safe use and operation
of the lift: ALI/SM 93-1, ALI Lifting it Right safety manual; ALI/ST-90 ALI Safety Tips card; ANSI/ALI ALOIM-2000, American
National Standard for Automotive Lifts-Safety Requirement for Operation, Inspection and Maintenance; ALI/WL Series,
ALI Uniform Warning Label Decals/Placards; and in case of frame engaging lifts, ALI/LP-GUIDE, Vehicle Lifting
Points/Quick Reference Guide for Frame Engaging Lifts and SAE J2184, Vehicle Lifting Points for Service Garage Lifting.
The Owner/Employer Must establish procedures to periodically inspect the lift in accordance with the lift manufacturer’s
instructions or ANSI/ALI ALOIM-2000, American National Standard for Automotive Lifts-Safety Requirements for
Operation, Inspection and Maintenance; and the employer Must insure that the lift inspectors are qualified and that
they are adequately trained in the inspection of the lift.
The Owner/Employer Must establish procedures to periodically maintain the lift in accordance with the lift
manufacturer’s instructions or ANSI/ALI ALOIM-2000, American National Standard for Automotive Lifts-Safety

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
5
Requirements for Operation, Inspection and Maintenance; and the employer Must insure that the lift maintenance
personnel are qualified and that they are adequately trained in the maintenance of the lift.
The Owner/Employer Must maintain the periodic inspection and maintenance records recommended by the
manufacturer or ANSI/ALI ALOIM-2000, American National Standard for Automotive Lifts-Safety Requirements for
Operation, Inspection and Maintenance.
The Owner/Employer Must display the lift manufacturer’s operating instructions; ALI/SM 93-1, ALI Lifting it Right safety
manual; ALI/ST-90 ALI Safety Tips card; ANSI/ALI ALOIM-2000, American National Standard for Automotive Lifts-Safety
Requirement for Operation, Inspection and Maintenance; ALI/WL Series, ALI Uniform Warning Label Decals/Placards;
and in case of frame engaging lifts, ALI/LP-GUIDE, Vehicle Lifting Points/Quick Reference Guide for Frame Engaging Lifts;
in a conspicuous location in the lift area convenient to the operator.
3.1. Additional Owner/Employer Responsibilities
•Must require that Personal Protective Equipment (PPE) be used according to the appropriate regulations.
•Must display the “Safety Regulations” and adhere to them closely.
•Must ensure that all safety and danger signs on and around the Lift are observed and followed!
•Must follow the specified time intervals between the recommended inspection and maintenance procedures
and tests.
•Must use only spare parts that comply with the technical requirements specified by the manufacturer.
•Must ensure that loose screws, nuts, and bolts are firmly tightened after maintenance.
•Must not modify the Lift without written consent of Nussbaum Automotive Solutions, LP.
•Must ensure that these instructions are maintained and available to all personnel that install, use, or maintain
the lift. This document contains important information about installation, operation, and maintenance of the
automotive Lift.
•Any changes to the installation and or location of the automotive Lift must be documented.

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
6
4. Lift Operator Responsibilities
•Must read and understand all safety and warning instructions in the manual or affixed to the lift.
•Must be trained to operate and use the Jumbo HFK Lift for its designed use.
•Must be familiar with accident prevention and basic labor safety regulations.
•Must not allow unauthorized personnel to operate the Lift.
Pay close attention to the danger and important information symbols shown below.
Carefully read all marked passages throughout this manual.
Danger! This sign indicates danger to life. Improper handling of
the described operation may cause serious injury or death.
Caution! This sign warns against possible damage to the
automotive Lift or other material defects in case of improper
handling.
Attention! This sign indicates an important function or note.
5. Safety Regulations
Danger! The Safety Regulations must be observed and strictly
adhered to while working with the automotive Lift. Read the
safety regulations and the ANSI/ALI ALOIM manual included with
the lift documentation carefully before working with the Lift!
1. IMPORTANT SAFETY INSTRUCTIONS –READ ALL INSTRUCTIONS
•The total weight of the lifted vehicle must not exceed 7,000 pounds.
•The Lift must not be installed in a hazardous location or in washing bays.
•The Lift must be checked by a service technician after initial installation and after repairs or changes have been
made to the Lift.
•The operating and maintenance instructions must be followed while working with the Lift.
•High density blocks must be positioned correctly.
•Pre-check low clearance or specially equipped vehicles for ample clearance to avoid damage to the vehicle
and/or Lift.
•Only trained personnel are to operate the Lift.
•No one is to stand within the working area (danger area) during vehicle lifting and lowering operations.
•No one is to occupy a vehicle during any phase of Lift operation.
•No one is to climb onto the automotive Lift when in a raised position.

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
7
•The main electrical switch (when applicable) must be switched off and locked out/tagged out according to OSHA
Regulations before maintenance or repair work is performed on the Lift.
•The operator must continue to observe the vehicle and Lift throughout the lifting or lowering operation.
•Check the center of gravity of the vehicle if heavy parts, such as the engine are removed.
•If heavy parts such as the engine must be removed, the center of gravity will change. Secure the vehicle before
removing parts to avoid the possibility of the vehicle becoming insecure.
•Read all instructions before operating lift.
•Care must be taken as burns may occur from touching hot parts.
•Do not operate the equipment with a damaged cord or if the equipment has been damaged –until it has been
examined by a qualified service person.
•To reduce the risk of fire, do not operate equipment near open containers of flammable liquids (gasoline).
•Adequate ventilation should be provided when working on operating internal combustion engines.
•Keep hair, loose clothing, fingers, and all parts of body away from moving parts.
•Use only as described in this manual. Use only manufacturer’s recommended attachments.
•ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses only have impact resistant lenses, they are not safety
glasses.
SAVE THESE INSTRUCTIONS
2. SAFETY DEVICES
Nussbaum has designed several safety features into each Lift to ensure safe and efficient operations under a variety of
conditions. Warranties will be voided, and dangerous working conditions exist if any of the listed devices are altered
or disabled.
Pressure relief valve
Safety device to prevent over pressuring of the hydraulic system.
Two independent master-slave systems
Safety device that protects against unintentional lowering.
Safety Ratchets
Safety device against unintentional lowering.
Hydraulic Flow Restrictors
Safety device to prevent excessive lowering speed.
Check Valve
Secures the vehicle against unauthorized lowering.
Hold-to-run controls
Safety device that protects against unsupervised operation

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
8
SAFETY LABELS AFFIXED TO LIFT
[NK1]
READ ALL LABELS AND VERIFY THAT ALL AUTHORIZED USERS FULLY UNDERSTAND THE
MEANING OF EACH CAUTION / WARNING / SAFETY INSTRUCTION. DO NOT REMOVE OR
DEFACE SAFETY LABELS FROM THE LIFT.

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
9
Operating Instructions
DANGER! READ ALL OWNER’S MANUAL INSTRUCTIONS AND
ANSI/ALI ALOIM BEFORE USING THE LIFT
5.1. To Load Vehicle
Clear persons and objects from Lift working area.
Ensure the lifting platforms are in the lowest position.
Ensure ramps are released and in the down position, suitable for driving.
Drive the vehicle over the platforms and park in the center of the lifting area.
Secure the vehicle from rolling, put into gear, and apply the parking brake.
Check all the danger points of the Lift to ensure that loose objects or people are clear from Lift and
working area.
The manufacturer’s service garage Lift points may be marked on the
undercarriage of the vehicle with triangle shaped markings. If the Lift
points are not marked on the vehicle, refer to the vehicle manufacturer
for the approved Lift points.
The Center of Gravity must be located slightly towards the front of the
lifting platforms. (Hose Side)
Determine the center of gravity. Place the High Density Blocks in a position which assures equal contact with the
Lift Platforms and the vehicle lifting points.
Check all the danger points of the Lift to ensure that loose objects or people are clear from Lift and working area.
Modified or specialty vehicles: Contact vehicle manufacturer to
determine if vehicle can be lifted on a hinged-pad frame engaging
Lift.
5.2. To Lift Vehicle
•Drive the vehicle over the lifting platforms (long axis) of the lift stopping after the front tires clear the front
extensions. Make certain the vehicle is centered on the lift from side to side.
•The vehicle must be prevented from rolling by blocking, setting brakes or engaging the transmission.
•If the main platforms are not capable of reaching the vehicle pick-up points, the platform extensions should be
raised even with the platforms and their supports extended from beneath the platforms.
Danger! The operating instructions must be followed when
operating the lift.
Danger! If the vehicles wheelbase is too short and the wheels
remain on the platform extensions, you must remove the ramps
before lifting the vehicle.

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
10
•Verify the vehicle is properly centered on the Lift and all pads are properly positioned on the manufacturer
approved lift points of the vehicle.
•Position the “High Density Blocks” under the pick-up points of the vehicle as described
by the vehicle manufacturer.
•Be certain that no bystanders are in or around the vehicle before lifting.
•Lift up and Push the handle FORWARD (Fig. 1) until the blocks engage the frame.
•Once the wheels clear the ground, ensure the vehicle is safely positioned by a
generous shaking. If the vehicle appears unstable, lower the vehicle, and reposition.
•Lift up and Push the handle FORWARD (Fig. 1) to raise the vehicle to the desired
working height making certain that no bystanders are in or around vehicle during the
entire process.
5.3. To Lower and unload Vehicle
•Lift up and Pull the handle DOWNWARD to lower the vehicle. The further down the handle is pulled, the faster
the vehicle will descend.
•Release the handle (Fig. 1) when the vehicle has reached the appropriate working height or has reached its
lowest possible position.
•Observe the entire lowering process and control the area to ensure bystanders or objects to not enter the area of
the lowering vehicle.
•When the lift is in its lowest position remove the “High Density Blocks”.
•If platform extensions have been used for support, lift them and slide all support devices back into their original
positions under the platforms.
•Drive the vehicle off the lift.
Danger! The platform extensions support must be completely
engaged or the vehicle could suddenly fall.
Danger! The blocks must be positioned in a safe and secure
manner or the vehicle could slip and fall from the lift. Always
place blocks flat, not on the narrow edges.
Danger! When lowering the lift absolute care must be taken to
ensure that there are no objects or bystanders in the area in
which the lift and vehicle are to be lowered.
Figure 1

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
11
SAVE THESE INSTRUCTIONS
6. Inspection and Maintenance Plan
Attention! Before conducting maintenance work, safety
precautions must be in place to eliminate harm to people working
with or around the Lift.
Danger! To avoid personal injury, allow only qualified technicians
to perform maintenance on the Lift.
To guarantee the utmost availability and to ensure that the Lift remains functional,
maintenance work contracts are organized between our clients and their local retailers.
Service must be performed at regular intervals of 3 months in accordance with service
manual. Proof of maintenance records may be a prerequisite for warranty claims. The
maintenance rate must be increased if the Lift is in continuous operation, in a dirty
environment, or in contact with de-icing salts, sand, pebble stones, natural soil, and
industrial dust of all manner, water, or constant humidity caused by insufficient ventilation.
During daily operation, the Lift must be closely observed to ensure that it is functioning
correctly. In the case of malfunction or fluid leak, Technical Service must be informed.
6.1. How often must the Lift be cleaned?
The schedule depends on the cleanness of the workshop and location of the Lift. The degree may vary dependent on
the season, weather conditions, and the ventilation of the workshop. The best protection for the Lift is a regular
cleaning every month. Under bad conditions, it may be necessary to clean the Lift every week.
6.1.1. Daily Maintenance
•Clean the Lift and the floor with a mild, non-abrasive detergent.
•Remove dirt with a sponge, or if necessary, a soft brush.
•Rinse away detergent with sponge.
•Do not leave any kind of liquid on machine.
•Check for proper operation after any power failure, or flooding of the lift of any type.
•Perform equalization procedure if platforms become unlevel. (See Sec 12.7)
•Check for leaking fluid from pump, hoses, tubes, or cylinders.
•Prevent corrosion by oiling metallic surfaces and retouching paint.
•Lubricate all fittings with high pressure grease.
•Check condition of “High Density Blocks” and replace if worn.

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
12
•During winter months in “snow belt” areas great care should be taken to keep the lift as free from corrosive
ice/snow melting agents as possible.
•Examine locking mechanism, checking for any stress cracks and proper function of pneumatic cylinders.
6.1.2. Yearly Maintenance
•Safety Related
•Check for proper function of all mechanical and hydraulic locking functions.
•Check for proper anchoring to the floor.
•Check for floor stability. (no cracking)
•Check for potential structural failure particularly in welded areas.
•Check for bending or distortion of mechanical parts.
•Replace safety related parts if there is any doubt about the ability to perform their function
•Replace hydraulic fluid with AW light 150 ISO32 or equivalent.
•Maintenance Related
•Check for any hydraulic leaks and condition of tubes and hoses.
•Check electrical connections, switches and fuses.
•Check for wear on bearings, hinge points and shafts.
•Check for condition of all lifting pads.
•Check for corrosion.
•Replace any worn or improperly functioning part before breakdown occurs to save future service charges and
down time.
•Replace hydraulic hoses every 6 years.
Danger! Before beginning any maintenance work: Locate the
power supply main switch and turn off. Lockout and tag out to
prevent re-energizing system during maintenance. Secure the
danger area around the Lift and secure the Lift with safety stands to
guards against unintentional lowering.
Inspection, repair and maintenance must be performed by a certified Nussbaum technician who has been trained on the
lift they are servicing. They must be able to make proper judgment as to the repair or maintenance that needs
performed to ensure full safety, operational reliability and structural integrity during the lifetime of the lift. Proper
maintenance records should be kept to back up possible warranty claims.
Danger! Never use any type of pressure or steam cleaning
devices on the lift. Damage to the seals and hoses could occur
causing failure of the hydraulic system.

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
13
6.2. Lift Maintenance
PART
ACTION/PRODUCT
Clean the Piston-Rod.
Use compressed air.
Check Oil Level.
Fill the tank with a clean, high quality AW32 oil.
Change the hydraulic oil at least once every 6 years.
To change the oil, lower the Lift to its lowest position.
Empty tank and refill with clean oil. Approximately 2 Gallons
(If ambient temperature is under 40 degrees Fahrenheit, use lower
than 32 viscosity).
Dispose of used oil according to the appropriate regulations.
Check all welded joints for cracks.
If any cracks are found on the Lift, stop use immediately. Switch-off
and secure the power supply and call service provider.
Check all external surfaces for damage.
If damaged, repair immediately. If repairs are not made
immediately, permanent damage to the powder-coated surface may
result.
Repair and clean damaged areas with an abrasive paper (120 grit).
Coat repaired area with a suitable paint (observe the RAL Number).
Check Zinc Surface. White rust can result from
moisture laying in certain areas for long periods of
time or poor ventilation. Poor ventilation can also
result in rust formation. Rust may result from
mechanical damage, wear, aggressive sediments (de-
icing salt, liquids), or insufficient cleaning.
Repair and clean these areas with abrasive paper (240 grit). Coat
repaired area with a suitable paint (observe the RAL Number).
Check all safety devices.
All safety devices must be in good working condition. If not, contact
Technical Service.
REPLACEMENT PARTS
ONLY USE NUSSBAUM ORIGINAL EQUIPMENT PARTS TO REPAIR THE LIFT
CALL NUSSBAUM PARTS DEPARTMENT AT 1-704-864-2470

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
14
7. Technical Information
TECHNICAL RATINGS
TECHNICAL INFORMATION
Lifting Capacity
7,000 lbs
Load Distribution
3,500 lbs per [NK2]platform
Lifting Time
approximately 40 seconds
Lowering Time
approximately 30 seconds
Line Voltage
208-240 volt, 60 Hz, 30 amp, single phase
Lifting Height
78.5” (standard height model)
Power Rating
4 HP (2.98 Kw)
Circuit Breaker Requirement
30 Amp min.
Motor Speed
3450 rpm[TR3]
Hydraulic Pressure
Approximately 3000 PSI (207 bar)
Pressure Relief Valve
Approximately 4250 PSI (293 bar)
Oil Tank Capacity
2 gallons (7.5 Liters)
Sound level
≤75 dBA

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
15
8. Troubleshooting
If the Lift does not work properly, refer to the following troubleshooting guide. If the
problem cannot be resolved, call Technical Service at 704.864.2470.
PROBLEM
POTENTIAL CAUSE
REPAIR OPTIONS
Motor does not start
No power supply, or feed line is cut
Check the power supply at the facility
breaker box and the power supply box.
Thermal protector in the motor is
activated[TR4]
Let the motor cool for 10 minutes and
switch it on
Internal contactor is defective
Call technical service.
Motor is defective
Call technical service.
Motor starts, Lift does not move
Vehicle is too heavy
Check vehicle for empty weight. Unload
unnecessary weight from vehicle.The lift
can raise a weight up to 7000lbs.
Oil level is too low
Lower Lift and fill oil reservoir. Check
for leakage. Call Technical Service if
leakage is observed.
Refill the oil if necessary with AW light
150 ISO32 hydraullic fluid or equivalent.
Hydraulic pump is defective
Call Technical Service.
Coupling between motor and pump is
defective
Call Technical Service.
Pressure line leaking
Call Technical Service.
Pressure relief valve is defective
Call Technical Service.
Cylinder is defective
Call Technical Service.
The Lift will not lower
An obstacle is restricting the Lift from
being lowered
Press the Raise Button until the obstacle
is freed. Remove the obstacle.
Operating lever is defective
Call Technical Service.
Lowering valve is defective
Call Technical Service.
The Lift lowers unexpectedly
Lowering valve is defective
Call Technical Service.
REPLACEMENT PARTS
ONLY USE NUSSBAUM ORIGINAL EQUIPMENT PARTS TO REPAIR THE LIFT
CALL NUSSBAUM PARTS DEPARTMENT AT 1-704-864-2470

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
16
9. Fill and Vent the Hydraulic Systems
The lift is preinstalled at the factory and is delivered with the hoses connected to the unit. After unpacking the power
unit, loosen the allen head screws to remove the back cover and fill the power unit with a high-quality hydraulic oil with
a viscosity of AW32. The required oil volume is approximately 2 gallons. After filling, the oil must be near the top of the
oil dipstick or to the “fill” line.
•Make certain the lift area is free of all bystanders.
•Check all hose connections for tightness, most leaks occur at connection points
[TR5]
Danger! The lift is pre-tested at the factory, so the hoses and
cylinders are already full of oil. Over-filling the system before
bleeding and lowering can cause the tank to overflow due to the
excess fluid.
This procedure must always be completely carried out, meaning
first fill and then vent. This is the only method of balancing a lift
with HyperFlow
10. Installation and Initiation
10.1. Safety Checks
The safety check is necessary to guarantee safe operation of the Lift during use.
Safety checks should occur as follows: after installation, before initial startup, after initial startup, at least once a year,
and any time modifications have been made to the Lift.
A. TOOLS NEEDED FOR THE INSTALLATION
•Chalk line
•Marking Pen
•Tape Measure
•4’ Level
•Hacksaw
•Hammer Drill
•½” & ¼” Masonry Bits
•Metric Hex Key Set
•Hammer
•SAE Wrench Set
•Transmission funnel
Danger! Before the installation of the Lift, secure the installation
area to prevent access by unauthorized persons.
Attention! Before beginning installation, familiarize yourself with
the entire installation process and with the “Foundation Plan”
(Appendix 1).

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
17
B. SUPPLIES NEEDED FOR INSTALLATION
•12 ½” x 6-½” concrete anchors
•10 ¼” x 3” concrete anchors
•2 gallons AW32 light hydraulic fluid or equivalent.
10.2. Prepare Lift Assembly Location
Attention! These locations are merely guidelines. The shop owner
should always be consulted to determine work habits, vehicles
serviced and preferences of the shop technicians.
The installation of the Lift is performed by manufacturer trained technicians or by the manufacturer’s distribution
partner. The Lift owner may use their trained mechanics to install the Lift. The installation must be performed
according to the following regulations:
•Use architectural plans, if available, to determine Lift location.
•Lift is intended for indoor installation only. Installation in an outdoor application is prohibited and will void the
warranties of the product.
•Always consult a qualified person regarding local regulations for seismic requirements.
•Do not install Lift in hazardous locations, depression areas, or washing stalls.
•Concrete must have compression strength of at least 3,500PSI and be a minimum of 4 inches thick.
•Mount on a level foundation.
•Mount on a foundation deeper than the local external frost line.
•Be sure to read the ANSI/ALI ALIS prior to installation.
10.3. INSTALLATION WITH DRIVE THROUGH DOOR
•Determine door or bay width. (measurement W) (Fig.2)
•Determine center of door and mark. (measurement W2)
•Multiply the door width by 1.5 (W x 1.5) and draw arcs with a tape measure from the door towards the center of
the bay as shown. (Fig. 2)
•Be sure to use the same location from each side of the door!
•Place a mark at the intersection of the two arcs.
•Snap a chalk line from the intersection of the arcs to the center point of the door. This is the “Bay Center Line”.
10.4. INSTALLATION ON AN INTERIOR BAY WITH EXISTING LIFTS
•Determine the distance between lifts in the opposing bays. (measurement W) (Fig. 3)
•Determine the center of those lifts and mark. (measurement W2)
•Multiply the width between existing lifts by 1.5 (W x 1.5) and using tape measure draw arcs from each opposing
lift towards the center of the bay as shown in figure 3. Be sure to use the same location from each of the
opposing lifts!

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
18
•Place a mark at the intersection of the two arcs.
•Snap a chalk line from the intersection of the arcs to the center point of the existing lifts. This is the “Bay Center
Line”
10.5. ESTABLISHING FRONT OR REAR PLATFORM GUIDELINES
Establishing location from the Lift Front. Allow 2’ (600mm) for a workbench, 3’ (920mm) for working area and
an additional 6’(1830mm) for the front of the car. This is a total of 11’ (3350mm) from the wall to the front of
the lift platform (excluding ramps). (Fig. 4)
Establishing location from the Lift Rear. Allow 10’ (3050mm) from the inside of the door to the rear of the
platform (excluding ramps) (Fig. 4)
•Determine the best method above for your application a place a mark on the “Bay Center Line” at the
appropriate location.
•Measure 4’ (1200mm) down the “Bay Center Line” and place a mark at that point. (Fig. 4)
•From that mark (established in 5.3.12) draw two, 5’ (1500mm) arcs with the tape measure approximately 3’
(900mm) on both sides of the “Bay Center Line” (Fig. 4)
Figure 3
Figure 2
Figure 5
Figure 4
Figure 2
Figure 3

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
19
•From the mark establishing either the rear or front location of the platforms (whichever method used) draw
two, 3’ (900mm) arcs with the tape measure that intersect the 5’ (1500mm) arcs (created in 5.3.13). (Fig. 4)
•Make marks at each of the intersections created by the arcs.
•Snap a line connecting each of the marks (created in 5.3.15) This becomes the rear or front guideline for the
platforms. (Fig. 5)
•Measure 15 ¾” on both sides of the “Bay Center Line” in two locations,
mark and snap two additional lines. These lines should run parallel with
each other and be exactly 31.5 inches apart. (Fig. 6) These lines become
the inner platform base guidelines.
•For express lube and pickup lifting purposes, the platforms may be
distanced by 23”-31.5”
This procedure establishes the location for the exact
placement of the lift.
11. LIFT INSTALLATION
11.1. Unpack container and locate all pieces
(Figures 7 & 8)
Part
Quantity
Owner/Installation Manual
1
Hose Covers (left, right, control)
3
Main Control Station
1
Lifting Platforms
2
High density blocks
8(4 Large, 4 Small)
Hydraulic Hoses
1(Connected)
Platform Extensions
4
Platform Extension Bolts
8
[TR6]
Attention! Report any shortages immediately
Figure 6Figure 6

JUMBO 7000 HFK SCISSOR
Nussbaum Automotive Solutions, LP | 1932 Jordache Court, Gastonia, NC 28052 | 704.864.2470 | Email: [e-mail] | www.nussbaum-usa.com
20
11.2. POSITION CONTROL STATION &
PLATFORMS
•Front of the lift is the end with the hydraulic hoses
•Control station can be mounted of either the driver or passenger
side of the lift.
[TR7]
•Figure 7 shows the packing of the lift. The passenger side platform is
on the bottom beneath the driver side platform. The control station
is on top.
•Set the control station on the appropriate side of the lift for
application. (Fig. 9)
•Remove top of control panel
•At this point, a qualified electrician should connect the electrical
power to the control station (Appendix 5)
•Turn “Main Power Switch” on control station (if applicable) to the
ON position.
•Operate the “Lifting” handle (Fig. 1) and raise the lift approximately
48” (1220mm) Raising the lift makes it easier to position.
Attention! Position the pour spout at the top of
the container when pouring. This will eliminate
the “glugging” effect.
Figure 10
Figure 9
Figure 7
Figure 8
