Nuu A5X User manual

Getting Started
With Your
Model: N5501LAT, A5X

3
Front/Back
A5X OverviewIndex
A5X Overview 3
Setting up Your Device 4
Safety information 6
Certificate 11
Customer Support 14
Top
Bottom
Wake/Sleep
button
Speaker
Volume
control
microUSB
connector
AUX-In/
Headset jack

4 5
Setting Up Your Device
Follow these step-by-step instructions to set up your A5X.
Remove Back Cover
• Remove the back cover by prying the lower left corner
of your device.
Insert the Battery
• Align the battery contacts, then insert the battery
contact-first.
Replace Back Cover
• After installing the battery, align the cover and snap it
closed. Be sure to press all around the edges to ensure
a secure fit.
Charge
• Plug in the microUSB connector to charge the device.
1
1
3
3
2
2
4
4
# SIM slots functions are disabled. The device does not support telephony function.
Battery

6 7
Safety Information
This section contains important information about the operation of your device, it also contains
information about how to use the device safely. Read this information carefully before using
your device.
Electronic device
Do not use your device if using the device is prohibited.
Do not use the device if doing so causes danger or interference with other electronic devices.
Interference with medical equipment
• Follow rules and regulations set forth by hospitals and health care facilities. Do not use your
device where prohibited.
• Some wireless devices may affect the performance of hearing aids or pacemakers. Consult
your service provider for more information.
• Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained
between a device and a pacemaker to prevent potential interference with the pacemaker. If
using a pacemaker, hold the device on the side opposite the pacemaker and do not carry
the device in your front pocket.
Areas with flammables and explosives
•
Do not use the device where flammables or explosives are stored (in a gas station, oil
depot, or chemical plant, for example). Using your device in these environments increases
the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols.
• Do not store or transport the device in containers with flammable liquids, gases, or explosives.
Traffic security
• Observe local laws and regulations while using the device. To reduce the risk of accidents, do
not use your wireless device while driving.
• Concentrate on driving. Your first responsibility is to drive safely.
• Do not hold the device while driving. Use hands-free accessories.
• RF signals may affect the electronic systems of motor vehicles. For more information, consult
the vehicle manufacturer.
• Do not place the device over the air bag or in the air bag deployment area in a motor vehicle.
Doing so may hurt you because of the strong force when the air bag inflates.
• Wireless devices may interfere with the airplane’s flight system. Do not use your device where
wireless devices are not allowed according to the airplane company’s regulations.
Operating environment
• Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these
environments may result in circuit malfunctions. Do not use your device during thunderstorms
to protect your device against any danger caused by lightning.
• Ideal operating temperatures are 0 °C to 35 °C. Ideal storage temperatures are -20 °C to
45 °C. Extreme heat or cold may damage your device or accessories.
• Do not expose your device to direct sunlight (such as on a car dashboard) for prolonged
periods.
• To protect your device or accessories from fire or electrical shock hazards, avoid rain and
moisture.
• Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove,
water heater, radiator, or candle.
• Do not place sharp metal objects, such as pins, near the earpiece or speaker. The earpiece
may attract these objects and result in injury.
• Stop using your device or applications for a while if the device is overheated. If skin is exposed
to an overheated device for an extended period, low temperature burn symptoms, such as
red spots and darker pigmentation, may occur.
• Do not touch the device’s antenna. Otherwise, communication quality may be reduced.
• Do not allow children or pets to bite or suck the device or accessories. Doing so may result
in damage or explosion.
• Observe local laws and regulations, and respect the privacy and legal rights of others.
Child safety
• Comply with all precautions with regard to child’s safety. Letting children play with the device
or its accessories may be dangerous. The device includes detachable parts that may present
a choking hazard. Keep away from children.
• The device and its accessories are not intended for use by children. Children should only use
the device with adult supervision.
Accessories
• Using an unapproved or incompatible power adaptor, charger or battery may cause fire,
explosion or other hazards.
• If the power cable is damaged (for example, the cord is exposed or broken), or the plug
loosens, stop using it at once. Continued use may lead to electric shocks, short circuits,
or fire.
• Do not touch the power cord with wet hands or pull the power cord to disconnect the
charger.
• Do not touch the device or the charger with wet hands. Doing so may lead to short circuits,
malfunctions, or electric shocks.
• If your charger has been exposed to water, other liquids, or excessive moisture, only an
authorized service center has the right to inspect.
Battery safety
• Do not connect battery poles with conductors, such as keys, jewelry, or other metal materials.
Doing so may short-circuit the battery and cause injuries or burns.
• Keep the battery away from excessive heat and direct sunlight. Do not place it on or in heating
devices, such as microwave ovens, stoves, or radiators. Batteries may explode if overheated.
• Do not attempt to modify or remanufacture the battery, insert foreign objects into it, or
immerse or expose it to water or other liquids. Doing so may lead to fire, explosion, or other
hazards.
• If the battery leaks, ensure that the electrolyte does not make direct contact with your skins or
eyes. If the electrolyte touches your skins or splashes into your eyes, immediately flush with
clean water and consult a doctor.
• In case of battery deformation, color change, or overheating while charging or storing,
immediately stop using the device and remove the battery. Continued use may lead to battery
leakage, fire, or explosion.

8 9
• Do not put batteries in fire as they may explode. Damaged batteries may also explode.
• Dispose of used batteries in accordance with local regulations. Improper battery use may lead
to fire, explosion, or other hazards.
• Do not allow children or pets to bite or suck the battery. Doing so may result in damage
or explosion.
• Do not smash or pierce the battery, or expose it to high external pressure. Doing so may lead
to a short circuit or overheating.
• Do not drop the device or battery. If the device or battery is dropped, especially on a hard
surface, it may be damaged.
• If the device standby time shortens significantly, replace the battery.
Cleaning and maintenance
• Keep the device and accessories dry. Do not attempt to dry it with an external heat source,
such as a microwave oven or hair dryer.
• Do not expose your device or accessories to extreme heat or cold. These environments may
interfere with proper function and may lead to fire or explosion.
• Avoid collision, which may lead to device malfunctions, overheating, fire, or explosion.
• Before you clean or maintain the device, stop using it, stop all applications, and disconnect
all cables connected to it.
• Do not use any chemical detergent, powder, or other chemical agents (such as alcohol and
benzene) to clean the device oraccessories. These substances may cause damage to parts
or present a fire hazard. Use a clean, soft, and dry cloth to clean the device and accessories.
• Do not place magnetic stripe cards, such as credit cards and phone cards, near the device for
extended periods of time. Otherwise the magnetic stripe cards may be damaged.
• Do not dismantle or remanufacture the device and its accessories. This voids the warranty
and releases the manufacturer from liability for damage. In case of damage, contact an
authorized service center for assistance or repair.
• If the device screen is broken in a collision, immediately stop using the device. Do not touch or
attempt to remove the broken parts. Promptly contact an authorized service center.
Environmental protection
• The device and its accessories (if included), such as the power adaptor and battery should
not be disposed of with household garbage.
• Disposal of the device and its accessories is subject to local regulations. Support proper
collection and recycling.
Safety precautions
People having active medical implants should preferably keep the device at least 15 cm away
from the implant.
Disposal and recycling information
When the end-user wishes to discard this product, it must be sent to
separate collection facilities for recovery and recycling. By separating this
product from other household-type waste, the volume of waste sent to
incinerators or land-fills will be reduced and natural resources will thus
be conserved.

10 11
Battery Caution
1. Use only NUU-approved batteries and cables to charge your device. Unapproved
chargers or cables can cause the battery to explode or damage the device.
2. Use only NUU-approved batteries and cables. Use unapproved batteries and cables
may cause safety issue and the warranty will be lost.
3. You can recharge your battery many times, but all batteries have a limited lifespan.
If you notice a significant deterioration in your device’s battery life, you will need to
purchase a replacement battery for replacement. If the battery is built-in in the device,
do not attempt to remove built-in batteries and contact an authorized NUU service
center for a replacement.
4. Your device may become warm after prolonged use or when exposed to high ambient
temperatures. If your device becomes hot to the touch, unplug the USB cable, disable
non-essential features, and avoid prolonged skin contact. Place your device in a cool
location and allow it to cool down to room temperature.
5. Charging times may vary depending on the ambient temperature and the remaining
battery level.
6. Avoid using your device when it is charging. Do not cover your device when it is
charging.
7. Do not disassemble this battery.
8. Do not short-circuit this battery.
9. Do not expose battery to open flames.
10. Dispose of the battery appropriately.
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

12 13
Your wireless device is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency (RF)
energy set by the Federal Communications Commission of the U.S. Government.
These limits are part of comprehensive guidelines and establish permitted levels of RF
energy for the general population.
The guidelines are based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health. The exposure standard for wireless mobile
devices employs a unit of measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted with the
device transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR
level of the device while operating can be well below the maximum value. This is
because the device is designed to operate at multiple power levels so as to use only
the power required to reach the network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
Before a device model is available for sale to the public, it must be tested and certified
to the FCC that it does not exceed the limit established by the government adopted
requirement for safe exposure. The tests are performed in positions and locations
(e.g., at the ear and worn on the body) as required by the FCC for each model. The
highest SAR value for this model device when worn on the body, as described in this
user guide, is 0.347W/Kg (Body-worn measurements differ among device models,
depending upon available accessories and FCC requirements). While there may be
differences between the SAR levels of various devices and at various positions, they
all meet the government requirement for safe exposure. The FCC has granted an
Equipment Authorization for this model device with all reported SAR levels evaluated
as in compliance with the FCC RF exposure guidelines.
SAR information on this model device is on file with the FCC and can be found under
the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID:
2ADINN5501LAT
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular
Telecommunications Industry Association (CTIA) website at http://www.ctia.org
* In the United States and Canada, the SAR limit for mobile devices used by the public
is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates
a substantial margin of safety to give additional protection for the public and to
account for any variations in measurements.
Body-wornOperation
This device was tested for typical body-worn operations. To comply with RF exposure
requirements, a minimum separation distance of 5mm must be maintained between
the user’s body and the handset, including the antenna. Third-party belt-clips,
holsters and similar accessories used by this device should not contain any metallic
components. Body-worn accessories that do not meet these requirements may not
comply with RF exposure requirements and should be avoided. Use only the supplied
or an approved antenna.
SAR Information Statement
Made in China

14 15
Battery
Don’t directly put the battery into the re.
Re-chargeable Li-ion battery and it can be used repeatedly.
The device with battery are tested and passed CE
Don’t put into rubbish bin directly.
US Charger
The charger is tested and passed FCC.
The charger is tested and passed UL.
Energy efciency “VI” grade
Indoor use only
Double insulation
Customer Support
Questions? Let us help. We’re here to support you.
US and Canada:
Phone: Toll Free: 844-NUU-3365
Hours: 9am-6pm ET
Email: [email protected]
UK and Europe:
Email: [email protected]
