OM13489 16-bit GPIO Daughter Card User Manual
Rev. 2.0 — 09 January 2014
User manual
Document information
Info
Content
Keywords
Fm+ Development Kit, OM13320, GPIO, OM13303
Abstract
Installation guide and User Manual for the OM13489 16-bit GPIO
Daughter Card that connects to OM13320 Fm+ Development Kit. This
board permits easy and simple evaluation of most of NXP’s 16-bit I2C
GPIO portfolio of products.
Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
2 of 16
Contact information
For more information, please visit:
http://www.nxp.com
For sales office addresses, please send an email to: [e-mail]
Revision history
Rev
Date
Description
2.0
20140109
Added A0 jumper hardware fix and CN5 schematic – changed from 14-pin to 18-pin with 4
pins not connected for correct connector seating on the Fm+ board. Active pins remain the
same. Labels for JP7 and JP8 (A1 and A2 address jumpers) are incorrect; 1 connects to
ground and 0 connects to VDDP
1.0
20131011
Initial Release
Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
3 of 16
1. Introduction
The OM13489 16-bit I2C GPIO Daughter Card connects to the OM13320 Fm+ Development
kit and permits easy evaluation of most of NXP’s 16-bit I2C GPIO portfolio of products.
Table_1 lists the supported devices.
The OM13489 16-bit I2C GPIO Daughter Card is shipped with no GPIO device soldered to
the board. The user must purchase the device he is interested in evaluating in a TSSOP24
package (the ordering part number suffix should be “PW” and the package designation
should be SOT355-1). These leaded packages should be relatively easy to solder to the
board with a low wattage, fine tipped soldering iron.
NOTE pin 1 orientation pointing toward C1.
Please note that a fix is needed for correct operation of the A0 jumper JP1. A wire must
be soldered between pin 2 of JP1 and the via directly below to make connection to pin 21 on
the device under test IC1. See Section 3.2 for additional details.
Table 1. Devices Supported by OM13489 16-bit I2C GPIO Daughter Card
Device
Description
Orderable Part Number
PCA6416A
Low-voltage translating 16-bit I²C-bus/SMBus I/O
expander with interrupt output, reset, and
configuration registers
PCA6416APW
PCA8575
Remote 16-bit I/O expander for I2C-bus with
interrupt
PCA8575PW
PCA9535A
Low-voltage 16-bit I²C-bus I/O port with interrupt
PCA9535APW
PCA9535C
16-bit I2C-bus and SMBus, low power I/O port with
interrupt
PCA9535CPW
PCA9535
16-bit I2C-bus and SMBus, low power I/O port with
interrupt
PCA9535PW
PCA9539A
Low voltage 16-bit I²C-bus I/O port with interrupt
and reset
PCA9539APW
PCA9539
16-bit I²C-bus and SMBus low power I/O port with
interrupt and reset
PCA9539PW
PCA9539R
16-bit I²C-bus and SMBus low power I/O port with
interrupt and reset
PCA9539RPW
PCA9555A
Low-voltage 16-bit I²C-bus I/O port with interrupt
and weak pull-up
PCA9555APW
PCA9555
16-bit I2C-bus and SMBus I/O port with interrupt
PCA9555PW
PCA9671
Remote 16-bit I/O expander for Fm+ I2C-bus with
reset
PCA9671PW
PCA9673
Remote 16-bit I/O expander for Fm+ I2C-bus with
interrupt and reset
PCA9673PW
PCA9675
Remote 16-bit I/O expander for Fm+ I2C-bus with
interrupt
PCA9675PW
PCAL6416A
Low-voltage translating 16-bit I²C-bus/SMBus I/O
expander with interrupt output, reset, and
configuration registers
PCAL6416APW
PCAL9535A
Low-voltage 16-bit I²C-bus I/O port with interrupt
and Agile I/O
PCAL9535APW
PCAL9539A
Low-voltage 16-bit I²C-bus and SMBus low power
I/O port with interrupt and reset
PCAL9539APW
PCAL9555A
Low-voltage 16-bit I²C-bus GPIO with Agile I/O,
interrupt and weak pull-up
PCAL9555APW
PCF8575
Remote 16-bit I/O expander for I2C-bus
PCF8575PW
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
4 of 16
The pin configuration of these devices varies only a bit and the different pin selections are
made via jumpers.
2. Features of the OM13489 16-bit GPIO Daughter Card
Direct connection to OM13320 Fm+ Development kit
Footprint for a TSSOP24 package, user solderable
Jumper configuration accommodates most NXP 16-bit GPIO
Flexible power supply configuration: 3.3V, 5V or external supply
Direct connection to OM13303 GPIO Target board for I/O visualization
Jumper configuration of device I2C address
LED indicators for power and INT
Scope ground connection loop
3. Pin Configuration of 16-bit GPIO Devices
The different 16-bit GPIO devices pin configurations differ only slightly between devices. See
Fig 1 for a description of the different pinouts.
Fig 1. Pin Configuration 16-bit GPIO Devices
PCA9671
PCA(L)9535/55 PCA8575 PCA9675 PCF8575
PCA(L)9539 PCA9673
PCA(L)6416
PCA(L)6416
PCA(L)9539 PCA9673
PCA(L)9535/55 PCA8575 PCA9675 PCF8575
PCA9671
O
RESET 124
VCC(I 2C- b us )
223
322
421
520
619
718
817
916
10 15
11 14
12 13
P0_2
P0_1
P0_0
INT
VSS
P0_7
P0_6
P0_5
P0_4
P0_3
P1_0
A1
RESET
A2
P1_5
P1_3
P1_4
P1_2
P1_1
VCC(P)
SDA
SCL
ADDR
P1_7
P1_6
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
5 of 16
3.1 Power Supply Setup
Power supply voltages may be selected from the tester connector CN4 or the Fm+ board
CN5. If one selects Fm+ CN5, either 3.3V or 5V can be chosen. Additionally, the
PCA(L)6416 device implements two power supplies which are separately chosen, i.e. one
can be 3.3V and the other 5V for voltage level translation evaluation. Both of these power
supplies can be supplied externally by using TP1 and TP2 near the tester connector CN4.
See the schematic section at the end of this document for more details.
The jumpers for power supply selection are CN3, JP3, and JP4
3.2 Reset, Interrupt, and Address pins selection
The Reset, Interrupt and Address pins are used in combinations on various devices. The
selection matrix on the 16-bit GPIO board sends pins 1, 2, and 3 to determine if the pins are
address or function on JP9, JP10, and JP11. Then, if they are determined address pins, JP1,
JP7 and JP8 tie them to logic high or low. If they are determined to be function pins, the
other position of JP9, JP10 and JP11 tie them to the correct connector function pins. See the
schematic section at the end of this document for more details.
The logic high level for the address pins is VDDP .
Please note that a fix is needed for correct operation of the A0 jumper JP1. A wire must
be soldered between pin 2 of JP1 and the via directly below to make connection to pin 21 on
the device under test IC1. Use 30 AWG wire wrap wire for the easiest connection. The solder
mask on the board will prevent any short circuits.
Please note that A1 and A2 jumpers are incorrectly labeled. JP7 and JP8 program I2C
addresses when selected. The labels show that A1 and A2 pins will be connected to ground
when the jumper shorts pin 1 and 2 (toward the bottom edge of the board). In fact, this is a
connection to VDDP or high. The schematic is correct, only the labels are incorrect.
Fig 2. Fix needed for correct operation of A0 jumper JP1
4. Board Jumper Set Up
4.1 Power Supply Jumpers
The power supply selections for the OM13489 is very flexible and allows for detailed analysis
and evaluation of all the NXP 16-bit GPIO devices. JP3 labeled PWR selects between 5V
supplied from the tester connector CN4 (jumper between pin 2 and 3 labeled TSTR) and the
Fm+ board connector CN5 (jumper between pin 1 and 2). If 3.3V or external power operation
is desired, no jumper is required.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
6 of 16
CN3 selects between 5V and 3.3V for a second power supply needed for PCA(L)6408A. If
the device under test is not PCA(L)6408A, leave this jumper open.
JP4 selects between 5V and 3.3V for the main power supply on pin 16 of the device under
test. Add a jumper between pins 2 & 3 for 3.3V or 1 & 2 for 5V.
For external power supply operation, do not jumper CN3, JP3 and JP4 and connect a voltage
source to TP2 for the main power supply connected to pin 16 of the device under test.
Connect another external voltage source to TP1 if the device under test is PCA(L)6408A.
See the schematic section at the end of this document for more details.
Fig 3. Power Jumpers and External Power Test Points
4.2 SCL and SDA Jumpers
The I2C-bus signals SDA and SCL supplied to the device under test can be sourced from
either the Fm+ board via CN5 or the tester via CN4. Jumpers JP5 and JP6 select the source.
Shorting pins 1 to 2 source from the Fm+ board while shorting pins 2 to 3 source from the
tester connector CN4.
See the schematic section at the end of this document for more details.
Fig 4. SDA and SCL Jumpers
4.3 PCA8575, PCA9535A, PCA9535C, PCA9535, PCA9555A, PCA9555,
PCA9675, PCAL9535A, PCAL9555A, PCF8575
The PCA8575, PCA9535/A/C, PCA9555/A, PCA9675 and PCF8575 series implement three
address pins and INT . This configuration ignores the power supply setup, but normally,
only JP4 with a jumper between pins 2 & 3 need be applied to power the device at 3.3V.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
7 of 16
To configure the function pins, apply jumpers between pins 1 & 2 on JP10 and JP11 to
configure device pin 2 and pin 3 as addresses. Apply a jumper between pins 2 & 3 on JP9 to
configure device pin 1 as INT .
Then, apply jumpers to JP1, JP7 and JP8 to configure the desired I2C address. Logic high or
logic low is labeled on the board, but is incorrect for JP7 and JP8. Using the labels, a 0 is
actually a 1 and a labeled 1 is actually a 0. The schematic is correct and note the square
solder pad is pin 1.
Fig 5. Jumper Configuration for PCA8575, PCA9535A, PCA9535C, PCA9535,
PCA9555A, PCA9555, PCA9675, PCAL9535A, PCAL9555A, PCF8575
4.4 PCA9671
The PCA9671 implements three address pins and RST . This configuration ignores the
power supply setup, but normally, only JP4 with a jumper between pins 2 & 3 need be
applied to power the device at 3.3V.
To configure the function pins, apply jumpers between pins 1 & 2 on JP9, JP10 and JP11 to
configure pin 2 and pin 3 as addresses and pin 1 as RST .
Then, apply jumpers to JP1, JP7 and JP8 to configure the desired I2C address. Logic high or
logic low is labeled on the board, but is incorrect for JP7 and JP8. Using the labels, a 0 is
actually a 1 and a labeled 1 is actually a 0. The schematic is correct and note the square
solder pad is pin 1.
Fig 6. Jumper Configuration for PCA9671
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
8 of 16
4.5 PCA9673, PCAL9539A, PCA9539A, PCA9539R, PCA9539
The PCA9673 and PCA9539 series implement two address pins, RST and INT . This
configuration ignores the power supply setup, but normally, only JP4 with a jumper between
pins 2 & 3 need be applied to power the device at 3.3V.
To configure the function pins, apply jumpers between pins 2 & 3 on JP9 and JP11 to
configure device pin 3 as RST and device pin 1 as INT . Apply a jumper between pins 1 &
2 on JP10 to configure device pin 2 as an address.
Then, apply jumpers to JP1 and JP7 to configure the desired I2C address. Logic high or logic
low are labeled on the board. Leave JP8 open. The labels are incorrect for JP7 and JP8.
Using the labels, a 0 is actually a 1 and a labeled 1 is actually a 0. The schematic is correct
and note the square solder pad is pin 1.
Fig 7. Jumper Configuration for PCA9673, PCAL9539A, PCA9539A, PCA9539R,
PCA9539
4.6 PCAL6416A, PCA6416A
The PCA(L)6416A devices are level translating, Agile I/0 Expanders with two power supplies,
one address pin, RST and INT . The two power supplies may operate at different voltages
to translate from the I2C-bus voltage domain to a higher or lower I/O voltage. CN3 and JP4
may be set to the same or different voltages, or left open and external voltage sources
connected to TP1 and TP2. See the datasheet for more details on voltage level translation.
Note that the 10K pull up resistors SDA and SCL, R5 and R6, are connected to VDDP which
may cause incorrect current readings if two different supplies are used.
To configure the function pins, apply jumpers between pins 2 & 3 on JP9, J10 and JP11 to
configure device pin 2 as a power supply, device pin 3 as RST and device pin 1 as INT .
Then, apply a jumper to JP1 to configure the desired I2C address. Logic high or logic low are
labeled on the board. Leave JP7 and JP8 open.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
9 of 16
Fig 8. Jumper Configuration for PCA(L)6416
5. Connector Pinouts
5.1 CN1 GPIO Target Board Connector
The OM13303 GPIO Target Board consists of eight LEDs and eight switches and connects
directly to the 16-bit GPIO board through CN1. The switches and LEDs permit easy exercise
of the I/O functionality of the device under test. The LEDs light red when the voltage on that
channel is below VCC x 0.3V and lights green when the voltage is above VCC x 0.7V. The
LEDs remain off when the voltage is between those two levels.
Table 2. CN1 GPIO Target Board Connector Pinout
CN1 Pin Number
Function
Board Connection
1
VDD
VDDP
2
Ground
GND
3
IO0
U1 pin 4
4
IO1
U1 pin 5
5
IO2
U1 pin 6
6
IO3
U1 pin 7
7
IO4
U1 pin 9
8
IO5
U1 pin 10
9
IO6
U1 pin 11
10
IO7
U1 pin 12
5.2 CN5 Fm+ Development Board Connector
The OM13489 can connect directly to the OM13320 Fm+ Development kit via CN5. This
connector provides power, I2C signals and other ancillary signals.
Note: The connector on the Fm+ board is a male, shrouded 14 pin type, while the connector
on the GPIO board is female, 18 pin.. The reason lies with the shroud around the 14 pin
connector. To ensure correct mating of the female with the male, two pin positions on both of
the female sides are unused.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NXP Semiconductors
UM10752
OM13489 16-bit GPIO User Manual
UM10752
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2014. All rights reserved.
User manual
Rev. 2.0 — 09 January 2014
10 of 16
Table 3. CN5 Fm+ Board Connector
CN5 Pin Number
Function
Board Connection
1
—
No connect
2
—
No connect
3
SCL
SCL Bus 1 to U1 pin 14
4
SDA2
SDA Bus 2 not used
5
INT
Interrupt to INT LED and JP9 pin 3
6
RESET
JP9 pin 1, JP11 pin 3
7
+5V
JP3 pin 1
8
+3.3V
CN3 pin 3 and JP4 pin 3
9
GND
10
GND
11
+3.3V
CN3 pin 3 and JP4 pin 3
12
+5V
JP3 pin 1
13
RESET
JP9 pin 1, JP11 pin 3
14
INT
Interrupt to INT LED and JP9 pin 3
15
SDA
SDA Bus 1 to U1 pin 15
16
SCL2
SCL Bus 2 not used
17
—
No connect
18
—
No connect
5.3 CN4 Tester Connector
Generation, inspection and logging of I2C-Bus data is easily achieved with third party
development tools from Total Phase (www.totalphase.com) There are two tools called
Aardvark and Beagle that direct connect to this board through CN4.
Note: Since SDA and SCL are both connected to the device under test, the Aardvark and the
Fm+ Development board cannot be used simultaneously. The Beagle, a bus sniffer, does not
have any issues.
Table 4. CN4 Tester Connector
CN4 Pin Number
Function
Board Connection
1
SCL
U1 pin 14
2
Ground
3
SDA
U1 pin 15
4
+5V
JP3 pin 3
5
+5V
JP3 pin 3
6
+5V
JP3 pin 3
7
—
8
—
9
—
10
Ground
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
