UNPACKING
After unpacking the unit, inspect carefully for any
damage that may have occurred during transit. Check
for loose, missing, or damaged parts. If any damage
is observed, a shipping damage claim must be filed
with the carrier. DO NOT use the OEMTOOLS™ 24991
5 Speed Mini Drill Press if broken, bent, cracked or
damaged parts (including labels) are noted. Any Drill
Press that appears damaged in any way, operates
abnormally or is missing parts should be removed from
service immediately. If you suspect that the Drill Press
was subjected to shock load (a load that was dropped
suddenly, unexpectedly, etc.), immediately discontinue
use until it has been checked by a factory authorized
service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
The following safety information is provided as a guideline to help you operate your 5 Speed Mini Drill Press under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe
handling instructions are not known or not followed. The following safety instructions are to provide the user with the
information necessary for safe use and operation. Please read and retain these instructions for the continued safe use
of your 5 Speed Mini Drill Press. Failure to follow instructions listed below may result in serious injury. In addition, make
sure that anyone who uses the equipment understands and follows these safety instructions as well.
Operating Instructions and Parts Manual 24991
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™ cannot be responsible for issues arising
from modification. We strongly recommend that this product is not modified and/or used for any application other than that for which it was
designed. If you have any questions relative to a particular application, DO NOT use the product until you have first contacted customer service
to determine if it can or should be performed on the product.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES:Provide clarity and helpful information.
5 SPEED MINI DRILL PRESS
1
8/18
2018 OEMTOOLS™
WARNING

2
Operating Instructions and Parts Manual 24991
8/18
2018 OEMTOOLS™
5 SPEED MINI DRILL PRESS
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your product. Read this manual carefully. Learn the product’s
applications and limitations, as well as potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark work areas invite
accidents.
3. Keep children away. All children should be kept away from the
work area. Never let a child handle this product without strict adult
supervision.
4. DO NOT operate this product if under the influence of alcohol or
drugs. Read warning labels on prescriptions to determine if your
judgment or reflexes are impaired while taking drugs. If there is any
doubt, DO NOT attempt to operate.
5. Use safety equipment. Eye protection should be worn at all times
when operating this product. Use ANSI approved safety glasses.
Everyday eyeglasses are NOT safety glasses. Dust mask, non-skid
safety shoes, hard hat or hearing protection should be used in
appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-ties, rings,
bracelets or other jewelry may present a potential hazard when
operating this product. Keep all apparel clear of the product.
7. DO NOT overreach. Keep proper footing and balance at all times when
operating this product.
8. Check for damage. Check your product regularly. If part of the product
is damaged, it should be carefully inspected to make sure that it can
perform its intended function correctly. If in doubt, the part should
be repaired. Refer all servicing to a qualified technician. Consult your
dealer for advice.
9. Keep away from flammables. DO NOT attempt to operate this product
near flammable materials or combustibles. Failure to comply may
cause serious injury or death.
10. Store idle product out of the reach of children and untrained persons.
This product may be dangerous in the hands of untrained users.
11. Maintain product with care.
12. Keep product dry and clean.
13. DO NOT use a damaged product. Tag damaged products “DO NOT
USE” until repaired.
14. Check for misalignment or binding of moving parts, breakage of parts,
and any other condition that may affect the product’s operation.
15. Use only accessories that are recommended by the manufacturer for
your model. Accessories that may be suitable for one product may
become hazardous when used on another product.
16. If damaged, have the product serviced before using. Many accidents
are caused by poorly maintained products.
17. Product service must be performed only by qualified repair personnel.
Service or maintenance performed by unqualified personnel could
result in a risk of injury.
18. When servicing a product, use only identical replacement parts. Use
of unauthorized parts or failure to follow maintenance instructions
may create a risk of injury.
19. Maintain a safe working environment. Keep the work area well lit.
Make sure there is adequate surrounding workspace. Keep the work
area free of obstructions, grease, oil, trash, and other debris. DO NOT
use this product in a damp or wet location.
20. Maintain labels and nameplates on this product. These carry
important information. If unreadable or missing, contact
OEMTOOLS™ for a replacement.
21. Avoid accidental fire and/or explosion. DO NOT smoke near engine
fuel and battery components.
22. We believe the information contained herein to be reliable. However,
general technical information is given by us without charge and
the user shall employ such information at their own discretion and
risk. We assume no responsibility for results or damages incurred
from the use of such information in whole or in part. Always refer to
specific instructions and technical information supplied by the vehicle
manufacturer.
SPECIFIC SAFETY INSTRUCTIONS
AND WARNINGS
WARNING:Read and understand all instructions. Failure to
follow all instructions listed below may result in electric shock, fire
and/or serious injury.
WARNING:For your own safety, DO NOT attempt to operate
your mini drill press until it is completely assembled and installed
according to the manual.
1. DO NOT use your tool where there is a risk of causing a fire or an
explosion; e.g. in the presence of flammable liquids, gases, or dust.
Power tools create sparks, which may ignite the dust or fumes.
2. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control, so visitors should remain
at a safe distance from the work area.
3. Be aware of all power lines, electrical circuits, water pipes and other
mechanical hazards in your work area, particularly those hazards
below the work surface hidden from the operator’s view that may be
unintentionally contacted and may cause personal harm or property
damage.
4. Be alert of your surroundings. Using power tools in confined work
areas may put you dangerously close to cutting tools and rotating
parts.
WARNING:Always check to ensure the power supply
corresponds to the voltage on the rating plate.
5. DO NOT abuse the power cord. Never carry a portable tool by its
power cord, or yank tool or extension cords from the receptacle.
Keep power and extension cords away from heat, oil, sharp edges or
moving parts. Replace damaged cords immediately. Damaged cords
may cause a fire and increase the risk of electric shock.
6. Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove
the grounding prong or modify the plug in any way. DO NOT use any
adapter plugs. Check with a qualified electrician if you are in doubt as
to whether the outlet is properly grounded.
7. Double insulated tools are equipped with a polarized plug (one blade
is wider than the other). This plug will fit in a polarized outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug. If
it still doesn’t fit, contact a qualified electrician to install a polarized
outlet. DO NOT change the plug in any way.
8. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock
if your body is grounded.
9. When operating a power tool outside, use an outdoor extension cord
marked “W-A” or “W.” These cords are rated for outdoor use and
reduce the risk of electric shock.
10. DO NOT expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
11. DO NOT let your fingers touch the terminals of plug when inserting
into or removing from the outlet.
12. Ground fault circuit interrupters. If work area is not equipped with a
permanently installed Ground Fault Circuit Interrupter outlet (GFCI),
use a plug-in GFCI between power tool or extension cord and power
receptacle.
13. Stay alert, watch what you are doing and use common sense when
operating a power tool. DO NOT use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
14. Dress properly. DO NOT wear loose clothing, dangling objects, or
jewelry. Keep your hair, clothing and gloves away from moving parts.
Loose clothes, jewelry or long hair can be caught in moving parts. Air
vents often cover moving parts and should be avoided.
15. Use safety apparel and equipment. Use safety goggles or safety
glasses with side shields which comply with current national

3
Operating Instructions and Parts Manual 24991
8/18
2018 OEMTOOLS™
5 SPEED MINI DRILL PRESS
standards or, when needed, a face shield. Use a dust mask in dusty
work conditions. This applies to all persons in the work area. Also use
non-skid safety shoes, hard hat, gloves, dust collection systems, and
hearing protection when appropriate.
16. Avoid accidental starting. DO NOT carry the power tool with your
finger on the switch. Ensure the switch is in the Off position before
plugging tool into power outlet. In the event of a power failure, while
a tool is being used, turn the switch Off to prevent surprise starting
when power is restored.
17. DO NOT overreach. Keep proper footing and balance at all times.
18. Remove adjusting keys or wrenches before connecting to the power
supply or turning on the tool. A wrench or key that is left attached to a
rotating part of the tool may result in personal injury.
19. Never place your fingers in a position where they could contact the
drill or other cutting tool if the workpiece should unexpectedly shift or
if your hand should slip.
20. Whenever possible, position the workpiece to contact the left side of
the column if it is too short or the table is tilted; clamp solidly to the
table. Use table slots or clamping ledge around the outside edge of
the table.
21. When using a drill press vise, always fasten it to a table.
22. Never climb on or allow others to climb on the drill press table; it
could break or pull the entire drill press down.
23. Turn the motor switch Off and put away the Switch Key when leaving
the drill press.
24. To avoid injury from thrown work or tool contact, DO NOT perform
layout, assembly, or setup work on the table while the cutting tool is
rotating.
25. DO NOT force the tool. Tools do a better and safer job when used in
the manner for which they are designed. Plan your work, and use the
correct tool for the job.
26. Never use a tool with a malfunctioning switch. Any power tool that
cannot be controlled with the switch is dangerous and must be
repaired by an authorized service representative before using.
27. Disconnect power from tool and place the switch in the locked or
Off position before servicing, adjusting, installing accessories or
attachments, or storing. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
28. Secure work with clamps or a vise instead of your hand to hold work
when practical. This safety precaution allows for proper tool operation
using both hands.
29. Store idle tools. When tools are not is use, store them in a dry, secure
place out of the reach of children. Inspect tools for good working
condition prior to storage and before re-use.
30. Use only accessories that are recommended by the manufacturer for
your model. Accessories that may be suitable for one tool may create
a risk of injury when used on another tool.
31. Keep guards in place and in working order.
32. Your mini drill press must be bolted securely to a workbench. If
there is any tendency for your mini drill press to move during certain
operations, bolt the workbench to the floor.
33. This mini drill press is intended for use in dry conditions, indoor use
only.
34. Always keep hands out of the path of a drill bit. Avoid awkward hand
positions where a sudden slip could cause your hand to move into the
drill bit.
35. DO NOT install or use any drill bit that exceeds 175 mm (7”) in length
or extends 150 mm (6”) below the chuck jaws. They can suddenly
bend outward or break.
36. DO NOT use wire wheels, router bits, shaper cutters, circle (fly)
cutters, or rotary planers on this mini drill press.
37. When cutting a large piece of material, make sure it is fully supported
at the table height.
38. DO NOT perform any operation freehand. Always hold the workpiece
firmly against the table so it will not rock or twist. Use clamps or a
vise for unstable workpieces.
39. Make sure there are no nails or foreign objects in the part of the
workpiece to be drilled.
40. DO NOT touch the bit or chips. Drill bits and cuttings are hot
immediately after drilling.
41. Never reach around or under the working head, or grab the chuck key
to stop the drill press.
42. Make sure the drill press speed is appropriate for both the type of
material and bit size you are using.
43. Clamp workpiece or brace against the left side of the column to
prevent rotation. If it is too short or the table is tilted, clamp solidly to
the table and use the fence provided.
44. If the workpiece overhangs the table such that it will fall or tip if not
held, clamp it to the table. Provide auxiliary support.
45. Make sure all clamps and locks are firmly tightened before drilling.
46. Securely lock the head and table support to the column, and the table
to the table support before operating the mini drill press.
47. Never turn your mini drill press on before clearing the table of all
objects (tools, scraps of wood, etc.).
48. Before starting the operation, jog the motor switch to make sure the
drill bit does not wobble or vibrate.
49. Let the spindle reach full speed before starting to drill. If your mini
drill press makes an unfamiliar noise or if it vibrates excessively, stop
immediately, turn the mini drill press off and unplug. DO NOT restart
until the problem is corrected.
50. DO NOT perform layout assembly or set up work on the table while
the mini drill press is in operation.
51. Make sure the spindle has come to a complete stop before touching
the workpiece.
52. To avoid injury from accidental starting, always turn the switch Off
and unplug the mini drill press before installing or removing any
accessory or attachment or making any adjustment.
53. Keep guards in place and in working order.
54. Only use the self-ejecting type chuck key as provided with the mini
drill press.
55. DO NOT try to drill material that is too small to be securely held.
56. Use the mini drill press in a well-lit area and on a level surface clean
and smooth enough to reduce the risk of trips, slips, or falls. Use it
where neither the operator nor a casual observer is forced to stand in
line with a potential kickback.
57. Never leave tool running unattended.
NOTE:The manufacturer declines any and all responsibility for
damage to workshop or components if said damage is the result of
unskillful handling by the operator or of failure to observe the basic
safety rules set forth in the instruction manual.
WARNING:Carefully read Rules for Safe Operation and
Instructions.
IMPORTANT SAFETY INSTRUCTIONS
The warnings, precautions, and instructions discussed in this manual
cannot cover all possible conditions and situations that may occur.
The operator must understand that common sense and caution are
factors which cannot be built into this product but must be supplied
by the operator.
PRODUCT DESCRIPTION
This OEMTOOLS™ 5 Speed Mini Drill Press is an ideal addition to
any workshop. With an overall height of less than two feet, the mini
drill press is easy to store. This unit is great for home craftsmen or
small production operators who need the extra power, accuracy and
trueness that a hand drill can’t provide.

4
Operating Instructions and Parts Manual 24991
8/18
2018 OEMTOOLS™
5 SPEED MINI DRILL PRESS
PRODUCT SPECIFICATIONS
5 SPEED 1/3 HP 1700 RPM MOTOR
DRILLING DEPTH 2"
CHUCK SIZE 1/16" - 1/2"
SPINDLE TO TABLE DISTANCE 9"
SPINDLE TO BASE DISTANCE 11-3/4"
SWING 8"
DIMENSIONS 18 1/2" (L) x 9-1/2" (W) x 14" (H)
WEIGHT 37.5 Lbs.
RANGE OF SPINDLE SPEEDS
UNPACKING
1. Separate all parts from packaging materials and check each of the
following items to make sure all items are accounted for before
discarding any packing material.
Figure Description Quantity
A Head Arm 1
B Column Support Arm 1
C Owner’s Manual 1
D Box of Loose Parts 1
E Bag of Loose Parts 1
F Base 1
G Table/Support Arm 1
2. Remove the protective oil that is applied to the table and column. Use
any ordinary household type grease and spot remover.
3. Apply a coat of paste wax to the table and column to prevent rust.
Wipe all parts thoroughly with a clean dry cloth.
LIST OF LOOSE PARTS IN THE BOX AND BAGS
M8 x 1.25-20 Hex Head
Screw (3)
Support Lock Handle (1)
Feed Handle (3)
Chuck (1)
Chuck Key (1)
M4 Hex “L”
Wrench (1)
M3 Hex “L”
Wrench (1)
Motor Speed Spindle Speeds (min
-1
)
50 Hz 1400 min-1 500 890 1400 1900 2500
60 Hz 1700 min-1 620 1100 1720 2340 3100
A
B
G
F
E
C
D
Figure 2
Figure 3

5
Operating Instructions and Parts Manual 24991
8/18
2018 OEMTOOLS™
5 SPEED MINI DRILL PRESS
ASSEMBLY
1. Install (3) M8 x 20 bolts in each hole through Column Support and
base and tighten with wrench.
2. Slide table/support into column.
3. Install support lock handle from left side into table support and tighten
by hand.
4. Lift head above column and slide it onto the column as far as possible.
Align head with table and base. Using a 4 mm Hex “L” wrench, tighten
the head lock set screws on the head.
5. Screw the feed handles into the threaded holes in the hub and tighten.
6. Clean out the tapered hole in the chuck. Clean the spindle nose with a
clean cloth. Push the chuck up on the spindle nose as far as possible.
Lightly tap the nose of the chuck with a piece of wood to ensure
proper fitting of the chuck on the spindle.
7. Install M5 x 12 pan HD screw in hole located in guard and attach
knob, turning it until it is tight.
8. Choose speed for drilling operation, and install belt to correct position
for desired speed. Loosen belt tension lock handle and turn the motor
counter-clockwise to apply tension to the belt. Tighten belt tension
lock handle.
OPERATION
1. Before using this machine, the operator should carefully read over this
operation manual to acquaint himself with the construction, controls
and driving system of the machine.
2. All of the Ball Bearings are packed with grease at the factory. They
require no further lubrication. Periodically lubricate the grooves in the
spindle and the rack (teeth of the quill).
3. Install drill into chuck far enough to obtain maximum gripping of the
chuck jaws. Make sure that the drill is centered in the chuck. Tighten
the drill sufficiently, so that it does not slip while drilling. Turn the
chuck key clockwise to tighten, counter-clockwise to loosen the drill
bit.
4. The drilling depth may be controlled by the pointer and depth scale or
by the two stop nuts, on the feed stop rod.
5. To position the table, loosen the support lock handle, move the table to
the desired position and retighten the support lock. To tilt table, loosen
the bevel lock, tilt the table to desired position on the bevel scale and
retighten bevel lock.
6. After drilling a hole, release the feed handle to have the spindle sleeve
return to its original position.
7. In case of any trouble or abnormal noise arising during operation, stop
the motor at once and identify the cause.
8. After operation, remove chips and dirt on the machine and cover all
the unpainted surfaces with oil to prevent them from rusting. Turn off
the power supply for safety.
EXTENSION CORD USE
1. Use only ‘Listed’ extension cords. If used outdoors, they must be
marked “For Outdoor Use.” Those cords having 3-prong grounding
type plugs and mating receptacles are to be used with grounded tools.
2. Replace damaged or worn cords immediately.
3. Check the name plate rating of your tool. Use of improper size or
gauge of extension cord may cause unsafe or inefficient operation
of your tool. Be sure your extension cord is rated to allow sufficient
current flow to the motor. For the proper wire gauge for your tool, see
chart.
CHART FOR MINIMUM WIRE SIZE OF
EXTENSION CORDS
If in doubt, use larger cord. Be sure to check voltage requirements of
the tool to your incoming power source.
MAINTENANCE
WARNING:For your own safety, turn switch Off and remove plug
from power source outlet before maintaining or lubricating your mini drill
press.
WARNING:To avoid shock or fire hazard, if the power cord is
worn, cut, or damaged in any way, have it replaced.
WARNING:Make sure this tool is disconnected from its power
source before attempting any maintenance, cleaning, or inspection.
1. Maintain your tools. It is recommended that the general condition of
any tool be examined before it is used. Keep your tools in good repair
by adopting a program of conscientious repair and maintenance
in accordance with the recommended procedures found in this
manual. If any abnormal vibrations or noise occurs, turn the tool off
immediately and have the problem corrected before further use. Have
necessary repairs made by qualified service personnel.
2. All of the ball bearings are packed with grease. They require
no further lubrication. Periodically lubricate the table elevation
mechanism and the grooves in the spindle. See “Getting to know your
mini drill press” section of this manual.
3. Frequently blow out any dust that may accumulate inside the motor. A
coat of automotive type paste wax applied to the table and column will
help keep the surfaces clean.
4. Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to
control. Keep handles dry, clean, and free from oil and grease.
5. Cleaning. Use only soap and a damp cloth to clean your tools. Many
household cleaners are harmful to plastics and other insulation. Never
let liquid get inside a tool.
Nameplate
AMPS Cord Length
25' 50' 100' 150'
0-6 18 AWG 16 AWG 16 AWG 14 AWG
6-10 18 AWG 16 AWG 14 AWG 12 AWG
10-12 16 AWG 16 AWG 14 AWG 12 AWG
12-16 14 AWG 12 AWG (Not Recommended)

6
Operating Instructions and Parts Manual 24991
8/18
2018 OEMTOOLS™
5 SPEED MINI DRILL PRESS
TROUBLE SHOOTING
TROUBLE PROBABLE CAUSE REMEDY
Noisy operation. 1. Incorrect belt tension.
2. Dry spindle.
3. Loose spindle pulley.
4. Loose motor pulley.
1. Adjust tension.
2. Lubricate spindle.
3. Check tightness of retaining nut on
pulley and tighten if necessary.
4. Tighten setscrews in pulleys.
Drill bit burns. 1. Incorrect speed.
2. Chips not coming out of hole.
3. Dull drill bit.
4. Feeding too slow.
5. Not lubricated.
1. Change speed.
2. Retract drill bit frequently to clear
chips.
3. Resharpen drill bit.
4. Increase the speed.
5. Lubricate drill bit.
Drill bit leads off – hole not round. 1. Hard grain in wood or lengths of
cutting lips and/or angles are not
equal.
2. Bent drill bit.
1. Resharpen drill bit correctly.
2. Replace drill bit.
Wood splinters on underside. 1. No “back up material” under
workpiece.
1. Use “back-up material”.
Workpiece turns loose from hand. 1. Not supported or clamped properly. 1. Support workpiece or clamp it.
Drill bit binds in workpiece. 1. Workpiece pinching drill bit or
excessive feed pressure.
2. Improper belt tension.
1. Support workpiece or clamp it.
2. Adjust tension.
Excessive drill bit runout or wobble. 1. Bent drill bit.
2. Worn spindle bearings.
3. Drill bit not properly installed in
chuck.
4. Chuck not properly installed.
1. Use a straight drill bit.
2. Replace bearings.
3. Install drill bit properly.
4. Install chuck properly.
Quill returns too slow or too fast. 1. Spring has improper tension. 1. Adjust spring tension.
Chuck will not stay attached to
spindle or falls off when attempting to
install.
1. Dirt, grease or oil on the tapered
inside surface of chuck or on the
spindle’s tapered surface.
1. Using a household detergent,
clean the tapered surface of the
chuck and spindle to remove all
dirt, grease and oil.
PARTS LIST AND DIAGRAM
1
1
2
3
4
5
6
7
8
8
9
10
11
12
15
14
13
Key No. Description
1 Rubber Bushing
2 Knob
3 Screw-Pan HD M5 x 0.8-1.2
4 V-Belt 5/16 x 26
5 Guard with Labels
6 Screw-Washer HD M6 x 1.0-1.6
7 Retaining Ring
8 Ball Bearing 17 mm
9 Spacer
10 Pulley Insert
11 Spindle Pulley
12 Nut-Pulley
13 Clamp Cord
14 Screw Pan HD M5 x 0.8-16
15 Foam Washer

7
Operating Instructions and Parts Manual 24991
8/18
2018 OEMTOOLS™
5 SPEED MINI DRILL PRESS
Key No. Description
18 Screw-Pan Hd. M5 x 0.8-8
19 Box-Swithch with Depth Scale
20 Screw-Pan Cr. MS x 0.8-12
21 Switch-Locking
22 Screw-Self Tapping Pan HD
M4x16-8
23 Cover-Switch Plate
24 Switch Key
25 Wire Connector
26 Seat Spring
27 Retainer Spring
28 Tension Spring
29 Cap Spring
30 Nut-Hex 3/8-24
31 Nut-Hex M10 x 1.5
32 Pointer
33 Power Cord
NOTE:The manufacturer declines any and all responsibility for damage to vehicles or components if said damage is the result of unskillful
handling by the operator or of failure to observe the basic safety rules set forth in the instruction manual.
OEMTOOLS™ and/or its distributors have provided the parts list and assembly diagram as a reference only. Neither OEMTOOLS™ nor its
distributors make any representation or warranty of any kind to the buyer and/or user of this tool that he or she is qualified to do any repairs
or replace any parts of this product. OEMTOOLS™ and its distributors expressly state that all repairs or parts replacement should be done by
certified or licensed technicians. The buyer assumes all risk and liability arising out of his or her repairs or parts replacement to the original
production.
8
9
10
11 12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
26
27
28
29
30 31
32
33
Key No. Description
1Head with Roll Pin & Trim
2Nut-Lock M8 x 1.25-8
3Washer
4Screw-Hex M8 x 1.25-25
5Motor Pulley
6Screw-Hex Soc. Set M6 x 1.0-10
7Motor
8Stop-Motor
9Spring-Motor Stop
10 Knob-Motor Adjusting
11 Screw-Hex Soc. Set M8 x 1.25-8
12 Knob
13 Rod
14 Shaft-Pinion
15 Nut-Hex M8 x 1.25
16 Screw-Flt. Sit. Set M8 x 1.25
17 Lockwasher-Ext. 5 mm
2
3
4
5
6
7
Figure 5

8
Operating Instructions and Parts Manual 24991
8/18
2018 OEMTOOLS™
5 SPEED MINI DRILL PRESS
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
OEMTOOLS™ 90 DAY LIMITED WARRANTY
For up to 90 days from the original purchase of this OEMTOOLS™product, if you find any defect in material or
workmanship (through normal usage), return it to the place of purchase or to OEMTOOLS™for repair or replacement at
our discretion. In order to obtain this service, send your tool and proof of purchase (transportation pre-paid) to:
OEMTOOLS™Q.A. Dept., 3580 Raines Road #3, Memphis, TN 38118.
We will not be responsible for lost or damaged goods during transportation; please insure your package. If our
inspection verifies the defect, we will either repair or replace the product, or we may elect to refund the purchase price
if we cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but if
we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty, then you
must bear the cost of returning the product.
OEMTOOLS™does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™will
not provide any warranty for products subjected to abnormal use. Abnormal use includes (but is not limited to) abuse,
accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover bits,
blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits,
files, and batteries as necessary. OEMTOOLS™reserves the right to make any changes in construction or design at
any time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS™makes every effort to ensure that its products meet high quality and durability standards, and warrants
to the original purchaser that this product is free from defects in materials and workmanship for the period of 90
days from the date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear
and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY
IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Don’t forget to register your new OEMTOOLS™product at www.oem-tools.com.
