OHAUS Pioneer PXP Series User manual

P
Pioneer
PXP Series
Balances
Instruction Manual
Pioneer
Balanzas
Serie PXP
Manual de Instrucciones
Pionnier
Balance de
Séries PXP
Manuel d’instruction
Pioneer
PXP-Serie
Waagen
Bedienungsanleitung
Bilance
Pioneer Serie PXP
Manuale di Istruzioni

PXP Series Balance EN-1
Table of Contents
1. INTRODUCTION .............................................................................................................. EN-3
1.1 Description ............................................................................................................................................. EN-3
1.2 Features ................................................................................................................................................. EN-3
1.3 Definition of Signal Warnings and Symbols ........................................................................................... EN-3
1.4 Safety Precautions ................................................................................................................................. EN-3
2. INSTALLATION ............................................................................................................... EN-4
2.1 Unpacking .............................................................................................................................................. EN-4
2.2 Select the Location ................................................................................................................................ EN-4
2.3 Leveling .................................................................................................................................................. EN-4
2.4 Connecting Power and Acclimating the Balance ................................................................................... EN-5
2.5 Connecting the Interface ........................................................................................................................ EN-5
2.6 Initial Calibration .................................................................................................................................... EN-5
3. OPERATION .................................................................................................................... EN-6
3.1 Overview of Display, Home Screen ....................................................................................................... EN-6
3.2 Principal Functions and Main Menu ....................................................................................................... EN-7
3.3 Overview of Parts and Features – Draft Shield Models ......................................................................... EN-7
3.4 Overview of Parts and Features – Non-Draft Shield Models ................................................................. EN-7
4. APPLICATIONS ............................................................................................................... EN-8
4.1 Weighing ................................................................................................................................................ EN-8
4.2 Parts Counting ....................................................................................................................................... EN-8
4.3 Percent Weighing ................................................................................................................................. EN-10
4.4 Formulation .......................................................................................................................................... EN-11
4.5 Additional Features .............................................................................................................................. EN-13
5. MENU SETTINGS .......................................................................................................... EN-14
5.1 Menu Navigation .................................................................................................................................. EN-14
5.1.1 Changing Settings ............................................................................................................................ EN-14
5.2 Calibration ............................................................................................................................................ EN-15
5.2.1 Calibration Sub-menu (InCal models) .............................................................................................. EN-15
5.2.2 Internal Calibration (not applicable to ExCal models) ...................................................................... EN-15
5.2.3 InCal Adjust (not applicable to ExCal models) ................................................................................. EN-15
5.2.4 Span Calibration............................................................................................................................... EN-15
5.2.5 Linearity Calibration ......................................................................................................................... EN-17
5.3 Balance Setup ...................................................................................................................................... EN-18
5.3.1 Password ......................................................................................................................................... EN-18
5.3.2 Language ......................................................................................................................................... EN-19
5.3.3 Filter Level ........................................................................................................................................ EN-19
5.3.4 AZT (Auto Zero Tracking) ................................................................................................................ EN-19
5.3.5 Auto Tare ......................................................................................................................................... EN-19
5.3.6 Graduations ...................................................................................................................................... EN-20
5.3.7 Date Format ..................................................................................................................................... EN-20
5.3.8 Date Setup ....................................................................................................................................... EN-20
5.3.9 Time Format ..................................................................................................................................... EN-20
5.3.10 Time Setup ....................................................................................................................................... EN-20
5.3.11 Brightness ........................................................................................................................................ EN-20
5.3.12 Auto Dim .......................................................................................................................................... EN-20
5.3.13 Capacity Bar ..................................................................................................................................... EN-20
5.3.14 Approved Mode ................................................................................................................................ EN-21
5.4 Weighing Units ..................................................................................................................................... EN-21
5.5 RS232 Interface Setup ......................................................................................................................... EN-23
5.5.1 Baud Rate ........................................................................................................................................ EN-23
5.5.2 Transmission .................................................................................................................................... EN-23
5.5.3 Handshake ....................................................................................................................................... EN-24
5.6 Print Settings ........................................................................................................................................ EN-24
5.6.1 Stable Only ....................................................................................................................................... EN-24
5.6.2 Numeric Only ................................................................................................................................... EN-24
5.6.3 Single Header .................................................................................................................................. EN-24

EN-2 PXP Series Balance
5.6.4 Print To ............................................................................................................................................. EN-24
5.6.5 Auto Print ......................................................................................................................................... EN-24
5.6.6 Header ............................................................................................................................................. EN-24
5.6.7 Date and Time................................................................................................................................. EN-24
5.6.8 Balance ID ........................................................................................................................................ EN-25
5.6.9 Balance Name.................................................................................................................................. EN-25
5.6.10 User Name ....................................................................................................................................... EN-25
5.6.11 Project Name ................................................................................................................................... EN-25
5.6.12 Application Name ............................................................................................................................. EN-25
5.6.13 Result ............................................................................................................................................... EN-25
5.6.14 Gross ................................................................................................................................................ EN-25
5.6.15 Net..... ............................................................................................................................................... EN-25
5.6.16 Tare... ............................................................................................................................................... EN-25
5.6.17 Line Feed ......................................................................................................................................... EN-25
5.7 GLP ...................................................................................................................................................... EN-26
5.7.1 Header ............................................................................................................................................. EN-26
5.7.2 Balance Name ................................................................................................................................. EN-26
5.7.3 User Name ....................................................................................................................................... EN-26
5.7.4 Project Name ................................................................................................................................... EN-26
5.8 Factory Reset ....................................................................................................................................... EN-26
5.9 Lockout................................................................................................................................................. EN-26
6. LEGAL FOR TRADEδ
δ
LFT
ε
........................................................................................ EN-27
6.1 Settings ................................................................................................................................................ EN-27
6.2 Verification ........................................................................................................................................... EN-27
6.3 Securing the Menu ............................................................................................................................... EN-27
6.4 Sealing Access to the Balance Settings .............................................................................................. EN-27
7. Printing .......................................................................................................................... EN-28
7.1 Connecting, Configuring and Testing the Printer / Computer Interface ............................................... EN-28
7.2 Output Format ...................................................................................................................................... EN-29
7.3 Printout Examples ................................................................................................................................ EN-29
8. MAINTENANCE ............................................................................................................. EN-31
8.1 Calibration ............................................................................................................................................ EN-31
8.2 Cleaning ............................................................................................................................................... EN-31
8.3 Troubleshooting ................................................................................................................................... EN-31
8.4 Service Information .............................................................................................................................. EN-32
9. TECHNICAL DATA ........................................................................................................ EN-32
9.1 Specifications ....................................................................................................................................... EN-32
9.2 Drawings and Dimensions ................................................................................................................... EN-36
9.3 Accessories .......................................................................................................................................... EN-36
9.4 Communication .................................................................................................................................... EN-37
9.4.1 Interface Commands ........................................................................................................................ EN-37
9.4.2 RS232 (DB9) Pin Connections ........................................................................................................ EN-38
9.4.3 USB Connection............................................................................................................................... EN-39
10. SOFTWARE UPDATES ................................................................................................. EN-39
11. COMPLIANCE ............................................................................................................... EN-40

PXP Series Balance EN-3
1. INTRODUCTION
1.1 Description
The PXP balance is a precision weighing instrument that will provide you with years of service if properly cared for.
PXP balances are available in capacities from 52 grams to 4200 grams.
1.2 Features
Operation Controls: 2-line backlit display, with 3
weighing applications and
many other features.
1.3 Definition of Signal Warnings and Symbols
Safety notes are marked with signal words and warning symbols. These show safety issues and warnings. Ignoring
the safety notes may lead to personal injury, damage to the instrument, malfunctions and false results.
WARNING
For a hazardous situation with medium risk, possibly resulting in injuries or
death if not avoided.
CAUTION
For a hazardous situation with low risk, resulting in damage to the device or
the property or in loss of data, or injuries if not avoided.
Attention
For important information about the product
Note
For useful information about the product
Warning Symbols
General Hazard Electrical Shock Hazard
1.4 Safety Precautions
CAUTION: Read all safety warnings before installing, making connections, or servicing this equipment.
Failure to comply with these warnings could result in personal
injury and/or property damage.
Retain all
instructions for future reference.
x Verify that the AC adapter’s input voltage range and plug type are compatible with the local AC main power
supply.
x Make sure that the power cord does not pose a potential obstacle or tripping hazard.
x Do not position the balance such that it is difficult to reach the power connection.
x The balance is for indoor use only. Do not operate the equipment in hazardous or unstable environments.
x Operate the equipment only under ambient conditions specified in these instructions.
x Do not drop loads on the pan.
x Use the balance only in dry locations.
x Disconnect the equipment from the power supply when cleaning.
x Use only approved accessories and peripherals.
x Service should only be performed by authorized personnel.
Direct Current

Alternating Current


EN-4 PXP Series Balance
2. INSTALLATION
2.1 Unpacking
Carefully remove your PXP balance and each of its components from the package. The included components vary
depending on the balance model (see the list below). Save the packaging to ensure safe storage and transport.
Please read the manual completely before installing and using the Adventurer balance to avoid incorrect operation.
Components included:
x Balance
x Power adapter + Attaching plug
x Stainless steel pan
x Pan support (for 0.1 g / 0.01 g / 0.00001 g model only)
x Warrenty card
2.2 Select the Location
Avoid heat sources, rapid temperature changes, air current or excessive vibrations. Allow sufficient space.
2.3 Leveling
Be sure the balance is level before it is used or after
its location is changed.
The PXP balance has a level bubble in a small round
window beside the display.
To level the balance, adjust the 4 Leveling Feet until
the bubble is centered in the circle.
Please refer to Figure 2-1 for leveling.
Figure 2-1. Leveling

PXP Series Balance EN-5
2.4 Connecting Power and Acclimatising the Balance
Connect the DC output connector to the power receptacle on the rear of the balance. Then connect the AC adapter
plug to a suitable electrical outlet.
Acclimatising
It is suggested that the balance should not be used until it has been connected to power and acclimatised to the
environment for a certain period of time. In the case of a balance with the precision above 0.1 mg, the
acclimatisation time should be 1.5 hours; in the case of balance with the precision of 0.01 mg, the acclimatisation
time should be more than 4 hours.
2.5 Connecting the Interface
The PXP balance has two data interfaces, RS232 and USB.
Use the RS
-232 port to connect either to a computer or a printer with a standard (straight-
through) serial cable.
Use the USB port to connect to a computer
with a USB 2.0 Type A to Type B cable.

Interface connections on the rear of the balance
USB
φUsed to connect to PC only
RS232
φUsed to connect to PC or Printer
Note:
For Connecting, Configuring and Testing the Printer / Computer Interface, see the Printing section.
2.6 Initial Calibration
When the PXP balance is first installed, or when it is moved to another location, it must be calibrated to ensure
accurate weighing results. PXP balances are classified into two categories, InCal models and ExCal models. InCal
models have a built-in calibration mechanism which can calibrate the balance automatically and does not require
the use of external calibration masses. If preferred, InCal models can also be manually calibrated with external
masses. ExCal models are calibrated with external masses. Make sure to have the appropriate calibration masses
available before beginning calibration.
USB
RS232

EN-6 PXP Series Balance
3. OPERATION
3.1 Overview of Display, Home Screen
The PXP balance has a 2-line backlit display.
CONTROLS
CONTROL FUNCTIONS
Button
Primary
Function
(Short
Press)

On / Zero
x
If the Indicato
r is
Off, turns on the
Indicator.
x
If Indicator is On,
sets zero.
Print
x
Sends the current
displayed value to
the serial interface.
Function
x
Operation is
dependent on the
application mode.
Tare
x
Performs tare
operation.
Secondary
Function
(Long
Press)

Off
x
Zeroing current
value.
Unit
x
Changes weighing
units.
Mode
x
Changes
application mode.
Menu-Cal
x
Enters the main
menu.
Calibration is
the first sub-
menu.
x
Views the preset
Tare value.
Menu
Function
(Short
Press)

Yes
x
Accepts the current
(blinking) sett
ing on
the display.
No
x
Rejects the current
(blinking) setting
on the display.
x
Increments a value
being entered.
Back
x
Reverts back to
previous menu
item.
x
Decrements a
value being
entered.
Exit
x Immediately
exits the sub
-
menu.
x
Aborts a
calibration in
progress.

PXP Series Balance EN-7
MAIN APPLICATION SCREEN
3.2 Principal Functions and Main Menu
Weighing:
First press Zero to set the display to zero. Place an object on the pan. The display indicates
the gross weight.
Taring:
With no load on the pan, press Zero to set the display to zero. Place an empty container on
the pan and press
Tare
. Add material to the container and its net weight is displayed. After
the container and the objects are removed, the load will be displayed as a negative number.
Press Tare to clear.
Zero:
Press Zero to zero the balance.
Dot-matrix Display:
The relevant data in the specific application mode are shown in the dot-matrix display area.
3.3 Overview of Parts and Features – Draft Shield Models
3.4 Overview of Parts and Features – Non-Draft Shield Models
Result Field:
Information varies
by application
Unit
Instructional Messages
Net (NET)
Stability (*)
Negative (-)
Centre of Zero (>0<)
Pre-tare (PT)
Pan
Level Indicator
Adjustable
Foot
Adjustable
Foot
USB
Device
Security Switch
RS232
Power Input
Pan
Adjustable Foot
Adjustable Foot
USB
Device
Security Switch
RS232
Power Input

EN-8 PXP Series Balance
4. APPLICATIONS
The PXP balance can be operated in 4 application modes by long pressing the Function / Mode button.
4.1 Weighing
Note: Before using any application, be sure the balance has been leveled and calibrated.
Use this application to determine the weight of objects in the selected unit of measure.
Weighing
1. Press Tare or Zero if necessary to begin.
2. Press and hold the Function / Mode button to select
Weighing (this application is the default).
3. Place objects on the pan to display the weight. Once
the reading is stable, the * will appear.
4. The resulting value is displayed in the active unit of
measure.
Item Settings
To view or adjust the current settings.
• Capacity Bar: When set to On, the capacity bar is displayed in the reference field. The capacity will not
display when the balance is set to zero.
• Weighing Units: Change the displayed unit. See Section 5.4 for more information.
• Filter Level: Change Filtering level. See Section 5.3.4 for more information.
• GLP Data: See Section 5.7 for more information.
• Print Settings: Change printing settings. See Section 7 for more information.
4.2 Parts Counting
Note: Before using any application, be sure the balance has been leveled and calibrated. The minimum piece
weight should be no less than 0.1d.
Use this application to count samples of uniform weight.
Parts Counting
1. Press Tare or Zero if necessary to begin.
2. Press and hold the Function / Mode button u
ntil
Parts Counting appears.


PXP Series Balance EN-9
3. After confirmation by pressing Yes, the message
"Clear APW?" will appear on the screen.
4.
If the APW of the last Parts Counting operation needs
to be kept, press No
when the message "Clear
APW?" displays.


5. Press Yes, and the message "Sample size 10" will
display with the numeral "10" (default) flashing.
6. Confirm the sample size by pressing Yes,
and place
10 samples
on the pan to display the weight. When
the reading is stable, the * will appear.
7. Press the Function / Mode
button so that the weight
of the
10 samples is used to establish the average
piece weight (APW). The display will show 10 pieces.
8.
To view the piece weight or the total weight, press the
Function / Mode button.

9. Place additional objects on the pan, and the
corresponding number of pieces will display.
Item Settings
To view or adjust the current settings.
Sample: The sample size ranges from 1 to 1000. The default
value is 10.
Note:
To ensure accurate counting
, the minimum piece
weight should be n
o less than 0.1d.

EN-10 PXP Series Balance
APW Optimization:
Improving counting accuracy by re-calculating the piece weight
automatically as parts are added.
APW Optimization occurs only when the number of pieces
added to the pan is between one and three times the number
already on the pan.
Print Settings:
Changing printing setup. See Section 7 for more information.
4.3 Percent Weighing
Note: Before using any application, be sure the balance has been leveled and calibrated.
Use Percent Weighing to display the weight of a test object as a percentage of a pre-established reference
sample.
The default (or last) reference weight is displayed.
Percent Weighing
1. Press and hold the Function / Mode button until
Percent Weighing appears.

2. After confirmation by pressing Yes, the message
"Clear reference?" will appear on the screen.
3. Press Yes
, and then the message "Place sample" will
display.

4. Place the reference sample on the pan to display the
weight. When the reading is stable, the * will appear.
5. Press the Function / Mode
button so that the weight
of the reference
sample is stored in memory. The
display will show 100%.

PXP Series Balance EN-11
6. Remove the reference sample and place the test
object on the pan. The ratio of the test object to the
reference sample weight is displayed as a
percentage.
7. To view the reference sample weight or the test
object weight, press the Function / Mode button.
Item Settings
4.4 Formulation
Note: Before using any application, be sure the balance has been leveled and calibrated.
Use this application for compounding and recipe making. The maximum number of components is 50.
Formulation
1. Press and hold the Function / Mode button until
Formulation appears.
2. After confirmation by pressing Yes, the message
"Place component 1" will appear on the screen.
3.
Place the first ingredient on the pan (or in a tared
container) and press the Function / Mode
button to
store the first weight.
Note: If the previously established reference sample weight
needs to be kept, press
No when the
message "Clear
reference?" displays.
Printing Setup:
Changing printing setup. See Section 7 for more information.

EN-12 PXP Series Balance
4. Then, the message "Place component 2" will display.
5. Remove the first ingredient, add the second
ingredient to the pan, and press the Function / Mode
button to store the second weight.
6. Continue adding components, and press the
Function / Mode button to store the weights.
7. Press No if no more ingredients need to be added.
8. The instructional message will appear and ask to
add
a filler material.
9.
If a filler material needs to be added, place it on the
pan, and press the Function / Mode
button when the
* appears; if no filler material needs
to be added,
press No.

10. The total weight will display.
11. Pressing the Function / Mode
button switches
between the total weight, the weight of component 1,
component 2 and so forth (as well as the weight of
the filler if added).
Print Settings:
Changing printing setup. See Section 7 for more information.

PXP Series Balance EN-13
4.5 Additional Features
Weigh Below
Note: Ensure the balance has been leveled and calibrated.
The PXP balance is equipped with a weigh below hook for weighing below the balance (as shown in the figure
below).
Before turning the balance over, remove the pan and draft shield elements (if present) to prevent damage. Do not
place the balance on the pan support cone or load cell pins.
To use this feature, remove power from the balance, then remove the protective cover for the weigh below
opening.
Power on the balance, and then use a string or wire to attach items to be weighed.
Weigh Below
protective cover
Weigh Below hook

EN-14 PXP Series Balance
5. MENU SETTINGS
5.1 Menu Navigation
Table 5-1 User Menu Structure
Calibration
Setup Units RS232 Print
GLP
Factory
Reset
Lockout
Internal Cal
Language
Gram
Baud Rate
Stable Only
Header 1
Reset All
Calibration
InCal Adjust
Filter Level
Kilogram
Transmission
Numeric Only
Header 2
Setup
Span Cal
AZT
Milligram
Handshake
Single Header
Header 3
Units
Linearity Cal
Auto Tare
Carat
Print To
Header 4
RS232
Graduations
Newton
Auto Print
Header 5
Print
Date format
Pound Header
Balance
Name
GLP
Date Ounce
Date and
Time
User
Name
Factory
Reset
Time Format
Ounce Troy
Balance ID
Project
Name
Time Grain
Balance
Name
Brightness
Pennyweight
User Name
Auto Dim
Momme
Project Name
Capacity Bar
Mesghal
Application
Name
Approved
Mode
Hong Kong
Tael
Result
Singapore Tael
Gross
Tanwan Tael
Net
Tical
Tare
Tola
Line Feed
Note: PXP balances are classified into InCal models and ExCal models.
5.1.1 Changing Settings
To change a menu setting, navigate to that setting using the following steps:
Enter the Menu
Long press the Menu button to enter the Menu.
Select the Sub-Menu
Press No to step between the sub-menus, and press Yes to enter the sub-menu.
Select the Menu Item
Press No to step through the Menu Items, and press Yes to enter the displayed Menu Item.

PXP Series Balance EN-15
5.2 Calibration
PXP balances offer a choice of three calibration methods: Internal Calibration (for InCal models only), Span
calibration and Linearity Calibration.
Attention: Do not disturb the balance during any calibration.
5.2.1 Calibration Sub-menu (InCal models)
Note: ExCal models only have Span Calibration and Linearity Calibration.
5.2.2 Internal Calibration (not applicable to ExCal models)
Calibration is accomplished with the internal calibration mass. Internal Calibration can be performed at any time,
provided the balance has warmed up to operating temperature and is level.
With the Balance turned ON and no load on the pan, the internal calibration can be performed.
Alternatively, press the Tare / Menu-Cal button and select Internal Cal to initiate the internal calibration.
The screen shows the status, and then press any button to return to the current application after calibration.
5.2.3 InCal Adjust (not applicable to ExCal models)
Use this calibration method to fine tune the effect of the Internal Calibration.
Calibration Adjust may be used to adjust the result of the Internal Calibration by +100 divisions.
Note: Before making a calibration adjustment, perform an Internal Calibration. To verify whether an adjustment is
needed, place a test mass equal to the span calibration value on the pan and note the difference (in divisions)
between the nominal mass value and the actual balance reading. If the difference is within +/- division, calibration
adjustment is not required. If the difference exceeds +/-1 division, calibration adjustment is recommended.
Example: Expected weight reading: 200.000 (Test mass value)
Actual weight reading: 200.014
Difference in gram: – 0.014
Difference in division: – 14 (InCal Adjust value)
To perform a Calibration Adjustment, select InCal Adjust from the list of Calibration Menu; enter the value (positive
or negative divisions) to match the difference noted earlier in the procedure.
Recalibrate using Internal Calibration. After calibration, place the test mass on the pan and verify that the mass
value now matches the displayed value. If not, repeat the procedure until Internal Calibration reading agrees with
the test mass.
Once completed, the balance stores the Adjustment value and the display returns to the current application.
5.2.4 Span Calibration
Span calibration uses two calibration points, one at zero load and the other at specified full load (span). For
detailed calibration mass information, please see the specification tables in section 9.1.
With the balance turned On and no load on the pan, Span Calibration can be performed. The best accuracy is
achieved using the mass closest to the full span value.

EN-16 PXP Series Balance
Steps for span calibration
1. Press and hold the Tare / Menu-Cal button, and the
Calibration Menu will display.
2. Press Yes to enter the Calibration Menu. To change
the calibration mode, press No
until Span Cal (span
calibration) is displayed.
3. Press Yes to begin the span calibration.
4. Calibration masses value will be shown in the screen.
5.
After the display shows "Place weights" and "100.0000
g", place weight(s
) of 100 g on the pan for calibration.
To change to the calibration point of half full capacity
(e.g. 50 g), press the Function / Mode button.
6.
After the screen shows "Place weights" and "50.0000
g", place weight(s) of 50 g on the pan for calibration.
7. Remove the weight(s) from the pan.

PXP Series Balance EN-17
8. Once the span calibration is completed successfully,
"Calibration done" will display.
Press any button to return to the previous screen.
5.2.5 Linearity Calibration
Linearity calibration uses three calibration points, one at zero load and the others at specified loads.
For detailed calibration mass information, please see the specification tables in section 9.1.
With no load on the scale, press Linearity Calibration to begin the process.
The balance captures the zero point, and then prompts for the next weight.
Continue to follow the instructions on the display until the calibration is completed.
Steps for linearity calibration
1. Press and hold the Tare / Menu-Cal button, and the
Calibration Menu will display.
2. Press Yes to enter the Calibration Menu. To change
the calibration mode, press No
until Linearity Cal
(linearity calibration) is displayed.
3. Press Yes to begin the linearity calibration.

EN-18 PXP Series Balance
4. Calibration masses value will be shown in the screen.
After the di
splay shows "Place weights" and "50.0000
g", place weight(s)
of 50 g on the pan for calibration.
5. Remove the weight(s) of 50 g from the pan. After a
while, "100.0000 g" will display. Place weight(s) of
100
g on the pan for calibration.
6. Once the linearity calibration is completed successfully,
"Linearity done" will display.
Press any button to return to the previous screen.
5.3 Balance Setup
Enter this sub-menu to customize balance functionality.
Note: The factory default settings are shown below in bold.
5.3.1 Password
Set or clear the password.
Off = disabled
On = enabled
When the Password is set On and the password is not correctly entered, the menu settings are affected as
follows:
z Calibration Menu:
Auto Calibration, InCal Adjustment, Span Calibration and Linearity Calibration are locked at the current settings.
z Setup Menu:
Language, Filter level, Auto Zero Tracking, Auto Tare, Graduations, Date Format, Date Setting, Time Format and
Time Setting are locked at the current settings.
z Units Menu:
All settings are locked.
z Print Menu:
All settings are locked.
z GLP Menu:
All settings are locked.
