OHAUS 1400 Series Manual

@
en FOUR-IN-ONE
SCALE
Directions for Use
and Maintenance
Please read this manual
before you use your Ohaus
Scale
Models 14-00
14-50, 14M &14L
-: ~.:::~ .
©Ohaus Scale Corporation 1984 all rights reserved

UNPACKING AND SETUP
Each scale is individually packed in a carton
specially desiiPted to protect the scale and all its
vital working parts. Upon unpacking the scale,
care should be taken not to grasp it by the beam,
but rather lift it by the base beneath the center post.
Save the rubber washer used in packing and in-
sert between parallel loop and base when scale is
not in use.
A reasonably flat and level surface should be
selected on which to use the scale. On such a
surface a very near balance should be attained when
all of the poise are set to their respective zero marks.
In the event that the scale does not balance ex-
actly at zero when set up on its working surface,
there are two knurled balance adjustment nuts pro-
vided in the beam to make the necessary balance
correction. These nuts are locked against each other
to prevent any movement in shipping or in use.
When adjustments are made, unlock the nuts by
turning them apart about a quarter turn; they can
then be easily moved. When the correct balance
has been restored, be sure to lock the balance nuts
against each other so that there will be no chance
for their movement and hence a change in the
zero balance.
It is also advisable to check the zero balance
periodically since foreign material may accumulate
on the scoop or beams and cause a slight change in
the balance position. Whenever the scale is moved,
the zero balance must be rechecked, since it will be
affected by an appreciable change in the inclination
of the working surface on which the scale rests.
WEIGHING
Please see other side.

WEIGHING
Before proceeding with weighing make sure the
scale is set up as described above.
The determination of a weight on the 4·in·1
Scale is a very simple and rapid operation. The
material to be weighed is placed in the scoop with
both Doises at the zero marks. Next, manipulate the
poise until a balance position is again obtained. The
weight of the specimen can then be read directly
from the beams through the indicator panels.
You will note that the lower beam is notched at
50 gram to 500 gram intervals and the lower poise
is equipped with a unique device enabling it to be
used as either a straight sliding poise, or as a poise
with a notch that will fall into definite locations.
Various type weighings should be made as follows:
1. LBS/Bushel on 1 pint sample or kg/hi on 0.5
litre sample. Use poise in slide position, read
lower indicator panel. To insure accurate re-
sults, fill bucket with No. 151 Filling Hopper.
2. Percentage Readings-The scale is equipped to
read dockage or moisture percentage directly on
a 500 gram sample. The large poise, set ir'
"Notch" position, is set at 450 gram and the
small poise is set at 50 gram. A 500 gram sam-
ple is then weighed out. After weight loss, the
sample is reweighed by moving the large poise
to the left to tl->~ tirst notch position which
causes the beam to rise and then moving it back
to the right one notch causing the beam to go
back down: the small poise is then moved to the
left until the beam balances. The percentage can
then be read to the nearest .1 %by combining
the readings of the two poises. If percentage
readings to only the nearest 1%are desired,
the large poise can be used alone, in "Slide"
position, keeping the small poise at initial 50
gram position.
3. Weight in Grams-(Lower Poise in "Notch"
Position) Read values in upper indicator panel.
Set lower poise to nearest 50 gram notch. Add
intermediate values with upper poise.
4. Weight in Ounces-Lower beam only. Poise in
"Slide" position, read value in lower indicator
panel. (Except Model 14M).
FOUR-IN-ONE SCALES
Model 14·00 - Complete with Winchester Pint Bucket
Model 14·80 for American use.
Model 14M -Complete with 0ne-half litre Bucket.
(Beam graduated kg/hi)
Model 14L -Without Bucket.

_--------- _ 4083-00
__r----·--~~~I ___1__ - 4073-00
__-------- 4080-00
1101-20
~ 1215-20
/~ /1231-00
\(1/ /
1035-03
1
PARTS LIST TABULATION A
Part Part
Used on
No. DESCRIPTION
Reqd No.
Model No.DESCRIPTION
Reqd
1008-23 Agate Bearing 4
4011-20
14-00
500 Gram Gradu-
1023-00 Balance Cup 1 14-LS
ated Beam
1231-00 Dial Bracket Assembly
114-LO
(lb/bu)
I4-S0
1034-00 Friction Plate wlo Tab34090-20
14-MO500 Gram Gradu-
1247-00 Friction Plate with Tab
114-MS
ated Beam
L 14-MS (kg/hI)
103~03 Bearing Cover 314-ML
1044-00 Balance Cup Cover Plate
1
4184-02
14-S0
Winchester Pint
14-00 Bucket
1077-03 Scoop, Stainless Steel
1
4184-01
14-MO
0.5 litre
1101-20 Scoop, Polypropylene
114-MS Bucket
121~2O
Pointer 1
4069-10 Fork 1
4080-00 500 Gram Poise Assem.
1
4073-00 50 Gram Graduated Beam 1
4083-00 50 Gram Poise Assembly
1

DIIAIIS Balances
Olal-O-Gram 310/Cent-O-Gram
311 Balance: versatile 10 mg read-
ability with fast, easy dial balancing
for economy. The Cent-O-Gram
Balance uses no dial.
Triple Beam Balance Series 700/
Olal-O-Gram Series 1600 Bal-
ance. Top loading convenience in
the most popular combination of
capacity and sensitivity, plus fast
weighing with the dial models.
The classic even-arm, two-pan balance:
the Harvard Trip Balance with sliding
poise. The ahaus Olal-O-Gram 2000
Balance uses a dial.
For quick moisture determination on
most material: the ahaus Model MB 301
For heavy-duty weighing under
abusive conditions: the ahaus
Heavy Duty Solution Balance.
Manual checkweighing. Specifically
designed for rugged performance
in harsh environments. Mechanical
simplicity and durability. The ahaus
Check-O-Gram Balance. USDA
approved.
Fast. direct reading digital convenience
with high reliability at economical prices.
Available in grams only, gram/ounce,
gram/carat/pennyweight and parts
counting models. EaSily interfaced with
computers, printers and calculators
ahaus Galaxy Electronic Balances.
The newest most economical electronic
of them all. The aha us Port-O-Gram
Electronic Balances. Battery powered for
portability. Available in ounce, gram,
pennyweight and parts counting models.
Lowest cost electronic balances,
featuring battery operation and
ABS plastic construction. ahaus
Lume-O-Gram Balances.
