OHAUS Adventurer SL AS64 User manual

Adventurer SL Balances
Instruction Manual
Balances Adventurer SL
Guide de l’utilisateur
Balanzas Adventurer SL
Manual de instrucciones

EN61326: 1997 + A1: 1998
Date: January 1, 2005
Marking Directive Applicable Standards
Marcado Directiva Normas aplicables
Marquage Directive Normes applicables
89/336/EEC
Electromagnetic compatibility
Compatibilidad electromagnética
Compatibilité électromagnétique
AS64, AS214, AS153, AS313, AS312, AS612, AS811, AS1502, AS3101, AS3102, AS6101,
AS8100
Ohaus Corporation, 19A Chapin Road, P.O. Box 2033 Pine Brook, New Jersey, 07058-2033, USA
Declaration of Conformity We, Ohaus Corporation, declare under our sole responsibility that the
balance models listed below marked with “CE” - are in conformity with the directives and standards
mentioned.
Declaración de Conformidad Nosotros, Ohaus Corporation, declaramos bajo responsabilidad
exclusiva que los modelos de balanzas indicados a continuación - con el distintivo ,CE’ - están
conformes con las directivas y normas citadas.
Déclaration de conformité Nous, Ohaus Corporation, déclarons sous notre seule
responsabilité, que les types de balance ci-dessous cité - munis de la mention «CE» - sont
conformes aux directives et aux normes mentionnées ci-après.
Instrument Type/Tipo de instrumento/Type de instrument: Adventurer SL
Ted Xia
President
Ohaus Corporation
Pine Brook, NJ USA
Urs Müller
General Manager
Ohaus Europe
Greifensee, Switzerland
73/23/EEC EN61010-1: 2001
Low Voltage
Baja tensión
Basse tension
Adventurer SL

Adventurer SL
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada
These products also comply with the following standards:
AS/NZS4251.1 Emission; AS/NZS4252.1 Immunity
CAN/CSA-C22.2 No. 1010.1-92; UL Std. No. 3101-1
Mark Standard
ISO 9001 Registration
In 1994, Ohaus Corporation, USA, was awarded a certificate of registration to ISO 9001 by Bureau
Veritus Quality International (BVQI), confirming that the Ohaus quality management system is
compliant with the ISO 9001 standard’s requirements. On May 15, 2003, Ohaus Corporation, USA,
was re-registered to the ISO 9001:2000 standard.
Registro ISO 9001
En 1994, Bureau Veritus Quality International (BVQI) le otorgó a Ohaus Corporation, EE.UU., un
certificado de registro ISO 9001 el cual confirma que el sistema administrativo de calidad de Ohaus
cumple con los requerimientos del estándar ISO 9001. En mayo 15 del 2003, Ohaus Corporation,
EE.UU., fue registrada nuevamente al estándar ISO 9001:2000.
Enregistrement ISO 9001
En 1994, le Bureau Veritus Quality International (BVQI) a octroyé la certification d’enregistrement ISO
9001 à Ohaus Corporation, États-Unis d’Amérique, confirmant que le système de gestion de la
qualité Ohaus était conforme aux conditions normalisées de l’ISO 9001. Le 15 mai 2003, Ohaus
Corporation, États-Unis d’Amérique, a été ré-enregistrée à la norme ISO 9001:2000.
13123

Adventurer SL

Adventurer SL EN-1
TABLE OF CONTENTSTABLE OF CONTENTS
TABLE OF CONTENTSTABLE OF CONTENTS
TABLE OF CONTENTS
1. INTRODUCTION ........................................................................... EN-3
1.1 Description .......................................................................... EN-3
1.2 Features .............................................................................. EN-3
1.3 Safety Precautions ................................................................ EN-3
2. INSTALLATION ............................................................................ EN-4
2.1 Unpacking ........................................................................... EN-4
2.2 Installing Components .......................................................... EN-4
2.2.1 Assembly of Models AS312, AS612, AS811, AS1502,
AS3101, AS3102, AS6101, AS8100 .................................... EN-4
2.2.2 Assembly of Models AS64, AS214, AS313 ........................... EN-5
2.2.3 Assembly of Model AS153 .................................................. EN-8
2.3 Selecting the Location ........................................................... EN-8
2.4 Leveling the Balance ............................................................. EN-8
2.5 Connecting Power ................................................................ EN-9
2.5.1 AC Adapter ........................................................................ EN-9
2.5.2 Battery Installation ............................................................. EN-9
2.6 Initial Claibration .................................................................. EN-9
3. OPERATION ...............................................................................EN-10
3.1 Overview of Controls and Display Functions ..........................EN-10
3.1.1 Models AS153, AS312, AS612, AS811, AS1502, AS3101,
AS6101, AS8100 .............................................................EN-10
3.1.2 Models AS64, AS214, AS313, AS3102 ............................... EN-10
3.2 Button Control Functions ..................................................... EN-12
3.3 Application Modes ...............................................................EN-12
3.3.1 Weigh .............................................................................EN-12
3.3.2 Count ..............................................................................EN-13
3.3.3 Percent ............................................................................EN-14

EN-2 Adventurer SL
TABLE OF CONTENTS (Cont.)
3.4 Menu ..................................................................................EN-15
3.4.1 Menu Structure ................................................................. EN-15
3.4.2 Menu Navigation .............................................................. EN-15
3.4.3 Changing Settings ........................................................... EN-16
3.5 Balance Settings..................................................................EN-16
3.5.1 Calibration Menu .............................................................. EN-16
3.5.1.1 Span Calibration ........................................................... EN-16
3.5.1.2 Linearity Calibration .......................................................EN-17
3.5.2 Set-up Sub-menu ............................................................EN-19
3.5.3 Mode Sub-menu ...............................................................EN-20
3.5.4 Unit Sub-menu ................................................................. EN-21
3.5.5 End Sub-menu ................................................................. EN-24
3.6 Additional Features .............................................................. EN-25
3.6.1 Weigh Below .................................................................... EN-25
3.6.2 Battery Operation .............................................................. EN-25
4. MAINTENANCE .......................................................................... EN-26
4.1 Calibration .......................................................................... EN-26
4.2 Cleaning ............................................................................. EN-26
4.3 Troubleshooting ..................................................................EN-26
4.4 Service Information .............................................................. EN-27
4.5 Parts ..................................................................................EN-27
4.6 Accessories ....................................................................... EN-27
5 .TECHNICAL DATA ....................................................................... EN-28
5.1 Drawings ............................................................................EN-29
5.2 Specifications .................................................................... EN-31
5.3 Capacity x Readability ........................................................ EN-32
5.4 Calibration Masses .............................................................EN-34

Adventurer SL EN-3
1 INTRODUCTION
This manual contains installation, operation and maintenance instructions for
Adventurer SL balances. Please read the manual completely before using the
balance.
1.1 Description
Adventurer SL balances are precision weighing instruments that will provide you
with years of service, if cared for properly. Adventurer SL balances are available
in capacities from 65 grams to 8100 grams.
1.2 Features
Adventurer SL balances are equipped with many standard features. These
include:
• AC Adapter operation (AC Adapter included)
• Battery operation depending on model (batteries not included)
• Weighing, Parts Counting, and Percent application modes.
• In-use cover
• Integral security bracket
• Weigh below hook
1.3 Safety Precautions
Please follow these safety precautions:
• Verify that the input voltage printed on the AC Adapter matches the local AC
power supply.
• Use the balance only in dry locations.
• Do not operate the balance in hostile environments.
• Do not drop loads on the platform.
• Do not place the balance upside down on the platform or platform mounting
cone.
• Service should be performed only by authorized personnel.

EN-4 Adventurer SL
Sub-platform
2. INSTALLATION
2.1 Unpacking
Carefully remove your Adventurer SL balance and each of its components from
the package. Save the packaging to ensure safe stroage and transport.
2.2 Installing Components
Use the illustrations and instructions below to identify and assemble your
Adventurer SL model with its components. All components must be installed
before using the balance.
2.2.1 Assembly of Models AS312, AS612, AS811, AS1502,
AS3101, AS3102, AS6101, AS8100
1. Insert the sub-platform on the cylindrical cone located in the center of
the balance. Align the sub-platform so that it is fully seated on the cone.
2. Place the weighing pan on the sub-platform.
Model AS3102 Models AS312, AS612, AS811, AS1502,
AS3101, AS6101, AS8100
Cylindrical
Cone
Pin
Weighing Pan

Adventurer SL EN-5
2.2.2 Assembly of Models AS64, AS214, AS313
2. Carefully remove each of the five (5) glass draft shield sections from its
packing. You will note that two (2) of these are plain, two (2) contain
handles, and the other is set in a plastic frame. These sections or panels
comprise the front and back, side doors, and top (respectively) of the Draft
Shield. The Draft Shield contains four (4) upright posts and two (2) cross
members which act as a framework for insertion of the panels.
1. Insert the Platform Assembly on the Cylindrical Cone in the center of the
balance.
3. Install the plain glass panels to form the front and back of the draft shield.
• Select a plain glass panel and insert the bottom edge of the glass in the
recessed slot in front of the balance, as shown.
• As you push the top edge of the glass side panel toward the cross-
member, reach inside the top of the framework and depress the small clip
located under the cross-member.
• Release the clip when the glass panel is fully inserted.
• Press the glass panel into the framework until you feel the glass slip into
place.
• Repeat these steps to install the other plain glass panel on the opposite
side of the framework.
Close-up of clip under top of
Draft Shield framework
Models AS64, AS214, AS313
Plain Glass
Front Panel
Platform Assembly
Cylindrical Cone
Recessed Slot
Clip under cross-member
on top of Draft Shield
framework

EN-6 Adventurer SL
2.2.2 Assembly of Models AS64, AS214, AS313 (Cont.)
4. Install the glass doors in the sides of the Draft Shield framework.
Note: The glass doors must be inserted in the Draft Shield framework before
you insert the top door; likewise you must remove the top door before
you remove the side doors.
• Hold and position each door so that the handle is near the front of the
balance and the small notch on the bottom edge of the door is lined up
with the tab that protrudes from the side of the balance housing
(shown below).
• Insert the top edge of the glass door into the recessed area under the top
cross-member of the Draft Shield framework.
• Slide the notch on the bottom edge over the tab and slip the door in
place.
5. The door may now be opened by sliding it toward the back of the balance.
Tab on side of
balance housing
Cross-member
on top of Draft
Shield
Close-up of notch Close-up of tab
Side Door Panel with
handle near front
Notch on bottom
edge of door
Models AS64, AS214, AS313

Adventurer SL EN-7
2.2.2 Assembly of Models AS64, AS214, AS313 (Cont.)
6. Install the top door panel.
• Insert the top door in the Draft Shield by holding the door vertically over the
top of the Draft Shield framework, as shown.
• Position the back edge of the door so that it lines up with two small hinges
located on the rear cross-member.
• Gently press the door onto the hinges until it snaps into place.
• Tilt the door forward to close.
Recessed hinge on
cross-member
Top door in vertical
position over Draft
Shield framework
Close-up view of recessed
hinge on Draft Shield
cross-member
Models AS64, AS214, AS313

EN-8 Adventurer SL
2.3 Selecting the Location
Locate the balance on a firm, steady surface. Avoid locations with excessive air
current, vibrations, heat sources, or rapid temperature changes.
2.4 Leveling the Balance
Before the balance is used, the feet should should be adjusted so that the scale is
level with the surface. This will enable accurate weighing. You will see a level
bubble indicator in a small round window on the front of the balance. Level the
balance by adjusting the leveling feet so the bubble is centered in the circle, as
seen below.
Balance Level
2.2.3 Assembly of Model AS153
1 Insert the sub-platform on the cylindrical cone in the center of the balance.
2. Place the weighing pan on the sub-platform.
3. Attach the Draft Shield by inserting the round bottom edge in the circular
recessed slot, as shown.
4. Place the metal cover on top of the Draft Shield.
Model AS153
Sub-platform
Weighing Pan
Draft Shield
Cover
Circular Recessed Slot
Round Edge
of Draft Shield

Adventurer SL EN-9
2.5 Connecting Power
2.5.1 AC Adapter
Connect the AC Adapter to the wall outlet. Connect the plug to the receptacle on
the rear of the balance.
2.5.2 Battery Installation
Some Adventurer SL models operate with batteries. To install batteries, remove the
pan and its components.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION:
To protect the cone from damage while installing batteries,
do not rest the balance upside down.
Remove the battery compartment cover from the bottom of the balance.
Install 4 AA (LR6) batteries in the compartment, aligning the batteries according
to the + and - symbols.
For use with CSA Certified (or equivalent approved) power source,
which must have a limited circuit output.
2.6 Initial Calibration
When the balance is first installed, it must be calibrated to ensure accurate
weighing. You will need appropriate calibration weights available before
beginning calibration. Refer to Section 4.1 for calibration weight information.
Refer to Sec. 3.5.1 for calibration instructions.

EN-10 Adventurer SL
Rear View
Top Views Bottom View
3
AS153 only
8
1
2
4
7
9
5
12
6
2Top Views Bottom View
AS3102 only
3. OPERATION
3.1 Overview of Controls & Display Functions
3.1.1 Models AS153, AS312, AS612, AS811, AS1502, AS3101,
AS6101, AS8100
Rear View
10
10
312
1
68
13
11
4
5
7
3.1.2 Models AS64, AS214, AS313, AS3102

Adventurer SL EN-11
Digital DisplayDigital Display
Digital DisplayDigital Display
Digital Display
14
17
.oNnoitpircseD.oNnoitpircseD
1nottuBseY/ffO/oreZ/nO21teeFgnileveL
2elbbuBleveL31dleihStfarD
3nottuBoN/stinU/edoM41ro
tacidnIegnaR
4yalpsiD51rotacidnIytilibatS
5gnisuohfoedisnolebalepyT61rotacidnIevitageN
6naP71rotacidnIoreZforetne
C
7lebalataD81)desuton(rotacidnIteN
8gninepOwoleBhgieW91yalpsiDtnemgeSneveS
9tnemtrapmoCyrettaB02sesehtneraP
01rotc
ennoCrewoP12tnemerusaemfostinU
11)ylno2013SAledoM(gniRtfarD22rotacidnIhtgnertSyrettaB
3.1 Overview of Controls and Display Functions (Cont.)
20
19
22
15
18
16
21
21
TABLETABLE
TABLETABLE
TABLE 3.1-1 Controls and Display Functions3.1-1 Controls and Display Functions
3.1-1 Controls and Display Functions3.1-1 Controls and Display Functions
3.1-1 Controls and Display Functions

EN-12 Adventurer SL
3.3 Application Modes
The Adventurer SL balance includes Weigh, Count, and Percent application modes.
To use these application modes, they must be turned on (SET ON) in the Mode Sub-
menu. The default mode, Weigh, has been SET ON at the factory. The other modes
are SET OFF.
3.2 Button Control Functions
The balance is operated using two multi-function buttons located on the front of the
balance. Button labels indicate the functions of each button. Operation of the buttons
is described in these instructions according to the function being performed.
3.3.1 Weigh Mode
Use the Weigh Mode to determine weight using a selected unit of measure. Several
units of measure are available, including grams. The balance will weigh only in
grams until other units of measure are SET ON in the Unit Sub-menu (See Section
3.5.4).
Button
Primary
Function
(Press)
Secondary
Function
(Press & Hold)
Menu
Function
On/Zero
• Turns balance On.
• If balance is On, sets Zero.
Off
• If balance is Off,
enters Menu.
• If balance is On,
turns balance Off.
Yes
• Enter the Menu or Sub-
menu option displayed.
• Accepts the current setting
on the display.
Mode/Unit
• Cycles through the loop of
enabled modes and units.
No
•Cycles through Menu,
Sub-menu, or Setting
options.
• Press and hold to exit
Menu or Sub-menu, or
abort Calibration.
Mode/Unit
•Changes to the next
enabled mode or unit.

Adventurer SL EN-13
If an APW has already been established,
Clear APW (CLR.APW) is displayed.
Press No to use the previously saved APW.
Otherwise, press Yes to establish a new
APW.
This example shows 100 pieces on the pan
with an average weight per piece of 4.99 g.
3.3.1 Weigh Mode (Cont.)
Weigh
To access the Weigh mode, press and hold
Mode until the display shows WEIGH.
Press Zero to zero the balance.
Place objects to be weighed on the pan to
display the weight.
The example displays a 200 gram weight.
3.3.2 Count Mode
Use the Count mode to count parts of uniform
weight. Refer to Section. 3.5.3 to set the
Count mode ON.
When the pieces indicator (PC) is displayed,
place the quantity to be counted on the pan.
The example shows 141 pieces.
To access the Count mode, press Mode until the display shows COUNT.
Establish an Average Piece Weight (APW).
Each time a new type of part is to be counted, the nominal weight of one piece
(Average Piece Weight) must be established using a small quantity of pieces. The
Average Piece Weight (APW) is stored in memory until replaced by a new APW.
Put the specified number of pieces on the pan when the desired sample size is
displayed. To abort the APW, press and hold No. Otherwise press YesYes
YesYes
Yes to establish
and display the new APW.
Count
The display indicates the number of pieces
to be used to establish the new APW.
If a different sample size is preferred, press No until the desired sample size is
displayed. Choices are Put 5, Put 10, Put 25, Put 50 or Put 100.

EN-14 Adventurer SL
3.3.3 Percent Mode
Use this mode to measure the weight of a sample as a percentage of a reference
weight. Refer to Section. 3.5.3 to set Percent Mode On.
3.3.2 Count Mode (Cont.)
APW Optimization
APW Optimization automatically adjusts the Average Piece Weight when a sample
size between one and three times the original sample size is placed on the pan. The
display shows APW.OPT each time the APW is optimized.
Note:Note:
Note:Note:
Note: Count must be SET ON before APW Optimization is SET ON. APW Optimization
settings are found in the Mode Sub-menu. The factory default for APW Optimization
is On.
Since the weight of each piece varies
slightly, APW Optimization may be used
to increase the accuracy of the count.
new Reference Weight.
If a Reference Weight has already been
established, CLEAR REFERENCE (CLR.REF) is
displayed. Press No to use the previously
saved Reference Weight. Otherwise, press Yes
to establish a new Reference Weight.
Establish a Reference Weight
Each time a new sample is used as the 100% reference, a new Reference Weight
must be established. The Reference Weight is stored in memory until replaced by a
To access the Percent Mode, press ModeMode
ModeMode
Mode
until the display shows PERCENT.
To establish the Reference Weight, put a
load on the pan. Press Yes to accept and
display this weight. The Reference Weight is
saved.
To abort the Reference Weight, press and
hold No.
Percent Weighing
Remove the Reference Weight and place the
load(s) to be compared to the reference
weight on the pan. The weight of each new
load is shown as a percentage of the
Reference Weight.

Adventurer SL EN-15
3.4 Menu
3.4.1 Menu Structure
The Adventurer SL Menu Structure consists of three levels.
The first level consists of the CALIBRATION, SETUP, MODE, UNIT and END Sub-
menus. The second level consists of the Menu Items contained in each Sub-menu.
The third level consists of Settings for each Menu Item.
3.4.2 Menu Navigation
The diagram above depicts navigation of the Adventurer SL menu through use of the
Yes and No buttons. Solid arrows point to the content displayed when Yes is pressed.
Dashed lines indicate the display that results when No is pressed.
"
"
!
!#
#
Yes
No
---
The diagram below shows the top two levels of the Menu Structure. For more
information on configuring balance settings, refer to Sections 3.5.1 to 3.5.4.

EN-16 Adventurer SL
3.4.3 Changing Settings
Settings may be changed by performing the following steps:
ENTER THE MENU
With the balance turned off, press and hold Yes until MENU appears on the
display. Release the button to display Calibrate (CAL) on the first level of the Menu
(See Section. 3.4.1 Menu Structure). Each Menu Item on this level represents a
Sub-menu.
SELECT A SUB-MENU
To select the displayed Sub-menu and show the first Menu item, press Yes. To
move to the next Sub-menu item, press No.
SELECT A MENU ITEM
To select the displayed Menu item and show the Setting, press Yes.To move to
the next Menu item, press NoNo
NoNo
No.
SELECT THE SETTING
To select the displayed Setting, press Yes. To move to the next Setting, press NoNo
NoNo
No.
EXITING THE MENU
When END Sub-menu is displayed, press Yes.
Note: Press and hold No at any time to exit quickly.
3.5 Balance Settings
Refer to Section 3.4 (above) for information on navigating the Menu.
3.5.1Calibration Sub-menu
The Calibration Sub-menu is used to calibrate the balance for accurate weighing.
Adventurer SL balances may be calibrated in two ways: Span Calibration or Linearity
Calibration.
3.5.1.1 Span Calibration
Span Calibration is the basic method used to set the balance's weighing range
using two weight values: zero and a weight between 50% and 100% of the capacity
of the balance. Span Calibration is required before the balance is used the first time,
and every time the balance is moved to a new location.
To perform Span Calibration:
With the balance turned off, press and
hold On until MENU is displayed, then
release the button.
CAL is displayed. Press Yes to enter the
Calibration Sub-menu.
