OHAUS Navigator User manual

1
INSTRUCTION MANUAL
Balances
Ohaus CorporationOhaus Corporation
Ohaus CorporationOhaus Corporation
Ohaus Corporation
29 Hanover Road
Florham Park, NJ
07932-0900

2
IEC1010-1 & EN60950:1992 Safety Regulations
IEC1010-1 & EN60950:1992 Sicherheitsbestimmungen
IEC1010-1 & EN60950:1992 Consignes de sécurité
IEC1010-1 & EN60950:1992 Disposiciones sobre seguridad
IEC1010-1 & EN60950:1992 Prescrizioni . di sicurezza
EN55022:1987 Emissions
EN50082-1:1992 Immunity
NOTE: The displayed value may be adversely affected under
extreme electromagnetic influences, eg. when using a radio unit in the
immediate vicinity of the device. Once the interference has been
rectified, the product can once again be used for its intended purpose.
EN55022:1987 Funkstörungen
EN50082-1:1992 Immunität
Hinweis: Unter extremen elektromagnetischen Einflüssen z.B. bei
Betreiben eines Funkgerätes in unmittelbarer Nähe des Gerätes kann
eine Beeinflussung des Anzeigewertes verusacht werden. Nach Ende
des Störeinflusses ist das Produkt wieder bestimmungsgemäss
benutzbar.
EN55022:Emissions parasites
EN50082-1:1992 Immunité
Remarque: Dans des conditions d'influences électromagnètiques
extrêmes, par exemple en cas d'exploitation d'un appareil radio à
proximité immédiate de l'appareil la valeur d'affichage risque d'être
influencée. Une fois que l'influence parasite est terminée, le produit
peut être de nouveau utilisé de manière conforme aux prescriptions.
EN55022:1987 Radiointerferencias
EN50082-1:1992 Inmunidad
Nota: Bajo influencias electromagnèticas extremas, p.ej. cuando
funciona una radio en las inmediaciones del aparato, se pueden
alterar los valores del display. Cuando concluye el efecto perturbador,
el producto puede ser utilizado de nuevo, de acuerdo con lo
estipulado.
EN55022:1987 Radiointerferenze
EN50082-1:1992 Immunità
Nota: ll valore visualizzato può essere influenzato negativamente dalla
presenza di forti interferenze elettromagnetiche, per esempio quando
viene usata una radio in prossimità della bilancia. Eliminata la fonte
dell'interferenza, il prodotto può essere nuovamente utilizzato per le
funzioni cui è preposto.
EU 73/23 Low Voltage
EU 73/23 Niederspannung
EU 73/23 Basse tension
EU 73/23 Baja tensión
EU 73/23 Bassa tensione
EU 89/336, 92/31, 93/68
Electromagnetic compatibility
EU 89/336, 92/31, 93/68
Elektromagnetische Verträglichkeit
EU 89/336, 92/31, 93/68
Compatibilité électromagnétique
EU 89/336, 92/31, 93/68
Compatibilidad electromagnética
EU 89/336, 92/31, 93/68
Compatibilità elettromagnetica
James Ohaus
President
Ohaus Corporation,29 Hanover Road,Florham Park,New Jersey,07932,USA
Declaration of Conformity We, Ohaus Corporation, declare under our sole responsibility that the balance models listed below marked with
“CE” - are in conformity with the directives and standards mentioned.
Konformitätserkärung Wir, die Ohaus Corporation, erklären in alleiniger Verantwortung, dass die untenstehenden Waagentypen,
gekennzeichnet mit “CE” - mit den genannten Richtlinien und Normen übereinstimmen.
Déclaration de conformité Nous, Ohaus Corporation, déclarons sous notre seule responsabilité, que les types de balance ci-dessous cité -
munis de la mention «CE» - sont conformes aux directives et aux normes mentionnées ci-après.
Declaración de Conformidad Nosotros, Ohaus Corporation, declaramos bajo responsabilidad exclusiva que los modelos de balanzas
indicados a continuación - con el distintivo ,CE’ - están conformes con las directivas y normas citadas.
Dichiarazione di conformità Noi, Ohaus Corporation, U.S.A, dichiariamo sotto nostra unica responsabilità, che i tipi di bilance specificati di
seguito - contrassegnati con la marcatura “CE” - sono conformi alle direttive e norme citate.
Balance Type/Waagentyp/Type de balance/Modelo de balanza/Tipo di biliancia Navigator
Marked with: Directive Standard
Gekennzeichnet mit: Richtlinie Norm
Munis de la mention: Directive Norme
Con el distintivo: Directiva Norma
Contrassegnati con la Direttiva Norma
Marcatura:

3
ISO9001CertificateforOhausCorporation. OhausCorporation,USA,wasexaminedandevaluatedin1994bytheBureauVeritasQualityInternational,
BVQI,andwasawardedtheISO9001certificate. ThiscertifiesthatOhausCorporation,USA,hasaqualitysystemthatconformswiththeinternationalstandardsfor
qualitymanagementandqualityassurance(ISO9000series). RepeatauditsarecarriedoutbyBVQIatintervalstocheckthatthequalitysystemisoperatedintheproper
manner.
ISO9001-ZertifikatfürOhausCorporation. DieFirmaOhausCorporation,USA,wurde1994durchdasBureauVeritasQualityInternationalBVQIgeprüft,
underhieltdasISO9001Zertifikat. Diesesbescheinigt,dassOhausCorporation,USAübereinQualitätssystemverfügt,welchesdeninternationalenNormenfür
QualitätsmanagementundQualitätssicherung(ISO9000er-Reihe)entspricht. AnlässlichvonWiederhol-AuditsdurchdasBVQIwirdperiodischüberprüft,obdas
Qualitätssystemzweckmässiggehandhabtwird.
CertificatISO9000pourOhausCorporation. LasociétéOhausCorporation,USA,aétécontrôléeen1994parBureauVeritasQualityInternationalBVQI
etaobtenulecertificat,degréISO9001. Celui-ciattestequeOhausCorporation,USA,disposed’unsystèmequalitécorrespondantauxnormesinternationalespour
lagestiondelaqualitéetpourI’assurancequalité(degréISO9000). DesauditsrégulierseffectuésparlaBVQIvérifientsilesystèmequalitéestappliquédefacon
appropriée.
CertificadoISO9001paraOhausCorporation. LafirmaOhausCorporation,USA,hasidoinspeccionadaporlaBureauVeritasQualityInternational
(BVQI)yhaobtenidoelcertificadoISO9001. EstoacreditaqueOhausCorporation,USA,disponedeunsistemadecalidadquecumplelasnormasinternacionalespara
gestiónygarantfadecalidad(ISOserie9000). ConocasióndelasinspeccionesderepetibilidadporpartedelaBVQI,secompruebaperiódicamentesielsistemade
calidadsemanipuladeformacorrecta.
CertificatoISO9001perlaOhausCorporation. llsistemadigaranziadellaqualitàdellaSocietàOhausCorporation,USAècertificatoISO9001sindal
1994dallBureauVeritasQualityInternationalBVQI,ecosìfomiceladimostrazionecheilsuosistemadieGaranziaQualitàsoddisfaimassimirequisite.llsistemadella
garanziadellaqualitàOhausCorporationvieneverificatoperiodicamentedallBVQI,dandocosievidenzadi.
NOTE: THIS EQUIPMENT HAS BEENTESTED AND FOUNDTO COMPLYWITHTHE LIMITS FOR A CLASS B
DIGITAL DEVICE, PURSUANTTO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNEDTO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE
WHENTHE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES,
USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN ACCORDANCE
WITHTHE INSTRUCTIONMANUAL, MAYCAUSEHARMFULINTERFERENCETORADIO COMMUNICATIONS.
OPERATION OFTHIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELYTO CAUSE HARMFUL INTERFERENCE
INWHICH CASETHE USER WILL BE REQUIRED TO CORRECTTHE INTERFERENCE AT HIS OWN EXPENSE.
THIS DIGITAL APPARATUS DOES NOT EXCEEDTHE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM
DIGITAL APPARATUS AS SET OUTINTHE INTERFERENCE-CAUSING EQUIPMENTSTANDARD ENTITLED
“DIGITAL APPARATUS”, ICES-003OFTHE DEPARTMENTOF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR :
“APPAREILS NUMERIQUES”,NMB-003 EDICTEEPAR LEMINISTRE DES COMMUNICATIONS.
Unauthorized changes or modifications to this equipment are not permitted.

4
TABLE OF CONTENTS
OVERVIEW OF CONTROLS ........................................................................................................................ 6
OVERVIEW OF DISPLAYINDICATORS ...................................................................................................... 7
1. GETTINGTO KNOWYOUR BALANCE .............................................................................................................. 8
1.1 Introduction ....................................................................................................................................................... 8
2. INSTALLATION ................................................................................................................................................... 8
2.1 Unpacking and Checking theStandardEquipment ............................................................................................. 8
2.2 Selecting the Location ........................................................................................................................................ 9
2.3 InstallingWindShield.......................................................................................................................................... 9
2.4 Installing Subplatform and Pan ........................................................................................................................... 9
2.5 Connecting Power andCommunications ........................................................................................................... 10
2.6 Levelingthe Balance ........................................................................................................................................ 10
3. OPERATINGYOURBALANCE ......................................................................................................................... 11
3.1 The Menu (Basic Settings of the Instrument) ................................................................................................... 11
3.2 TurningOnthe Balance..................................................................................................................................... 12
3.3 Calibration ..................................................................................................................................................... 12
3.3.1 InternalCalibration (InCalTM) ................................................................................................................... 14
3.3.2 Calibration message ............................................................................................................................... 15
3.3.3 Calibration Adjust ................................................................................................................................... 16
3.3.4 SpanCalibration ..................................................................................................................................... 17
3.3.5 UserCalibration ...................................................................................................................................... 18
3.3.6 LinearityCalibration ................................................................................................................................ 19
3.3.7 CalibrationTest ....................................................................................................................................... 20
3.3.8 Calibration GLP Printout ......................................................................................................................... 21
3.4 Weighing ..................................................................................................................................................... 22
3.5 PercentWeighing .............................................................................................................................................. 23
3.6 Parts Counting.................................................................................................................................................. 24
3.7 AnimalWeighing ............................................................................................................................................... 25
3.8 Checkweighing.................................................................................................................................................. 26
3.9 PrintingData..................................................................................................................................................... 27
4. SETTING UPYOUR BALANCE........................................................................................................................ 28
4.1 Setting Date andTime ...................................................................................................................................... 28
4.2 Readout ..................................................................................................................................................... 29

5
TABLE OF CONTENTS (Cont.)
4.3 Good Laboratory Practices (GLP)Data............................................................................................................. 30
4.4 Good LaboratoryPractices (GLP) Set .............................................................................................................. 30
4.5 Print ..................................................................................................................................................... 31
4.6 RS232 ..................................................................................................................................................... 33
4.7 Mode ..................................................................................................................................................... 34
4.8 Units ..................................................................................................................................................... 35
4.9 Global ..................................................................................................................................................... 35
4.10 Custom Unit ............................................................................................................................................... 37
4.11 Auto Shut-Off ............................................................................................................................................. 39
4.12 Menu Lock-OutProtection .......................................................................................................................... 40
4.13 Weigh Below............................................................................................................................................... 40
5. CARE AND MAINTENANCE ............................................................................................................................ 41
5.1 Troubleshooting................................................................................................................................................. 41
5.2 RS232 Interface................................................................................................................................................ 42
5.3 Error CodesList................................................................................................................................................ 45
5.4 Information Messages ...................................................................................................................................... 45
5.5 Service Information........................................................................................................................................... 46
5.6 Replacement Parts ........................................................................................................................................... 46
5.7 Accessories41
5.8 Specifications ................................................................................................................................................... 47

6
OVERVIEW OF CONTROLS
1
3
4
2
5
6
8
9
10
7
No. Designation Function
1I On/Off button Power on/off button.
2Mode button Selects standard weighing,percent, parts counting, animalweighingandcheckweighing
modes.
3 Units button Selects weighing units.
4Setup button Selects various menus: calibration, date, time, readout, GLP data, GLP set, print,
RS232, mode, units, global, custom and auto shut-off.
5->O/T<- button When pressed,performs tareorrezero function.
6 button Whenpressed, travels upthroughmenus.
7 button When pressed, travels to the left through menus.
8 button When pressed, travels to the right through menus.
9button When pressed, travels downthrough menus.
10 Enter/Printbutton When in menus, selects item on display, otherwise prints data.
11 Levelingindicator Indicates leveling position of the balance.
1
11

OVERVIEW OF DISPLAY INDICATORS
No. Function
1
2
3
5678910
12
13
4
14
No. Function
1 Use (PointerGroup) key to change - used to
promptthe user whilenavigating through the menu
system.
2Standard (7) segment numeric characters. Six
characters are available and are used for display-
ing weight values.
3Center of Zero - Not used
4 Stable - Indicates that the measured value has
becomestable.
5Change - Is displayed together with Mode,Units
or Setup signifying that a change to balance
settings is being performed.
6Mode - Is displayed when the Mode button is
pressed. Allows the user to know what area of
thebalance menu isbeing addressed.
(14) segment alpha numeric characters. Six
characters are used to present features and
functions.
Units - Is displayed when the Units button is
pressed. Allows the user to know what area of the
balancemenu is beingaddressed.
B/G & NET - Not used
10 Setup - Is displayed when the Setup button is
pressed. Allows the user to know what area of the
balancemenu is being addressed.
7
8
9
11 Custom -The user can input a factor to meet
uniqueunit measuring applications.
12 Symbols for weighing units and modes, include:
mg - Milligrams
g- Grams
kg - Kilograms
dwt - Pennyweight
ct - Carats
oz - Ounces
oz t - Ounces troy
GN - Grain
t-Taels. Taels are available in three types;
HongKong, Singapore,andTaiwan
m- Mommes
lb - Pounds
N- Newton
ti -Tical
%- Percent weighing
PC - Parts counting
tola - tola (appears on 14 segment display)
13 - Not used
14 press Enter - Used as a prompt to the user to
press the Enter button. The menu item displayed
is accepted/selected.
18
10
11

8
••
••
•Pan 3" Diameter •
••
••
•Pan Support, round 3" •
••
••
•Pan 4.75 Diameter • •
••
••
•Pan Support, round 4.75" • •
••
••
•Pan 6"x5.5" • • • •
••
••
•Pan Support, rectangular • • • •
••
••
•AC Power Adapter • • • • • • •
••
••
•Scoop •
••
••
•Windshield • • • •
••
••
•30g Calibration mass •
••
••
•Glass Draft shield •
••
••
•Draft shield cover •
••
••
•Instruction Manual • • • • • • •
••
••
•Warranty Card • • • • • • •
1. GETTING TO KNOW YOUR BALANCE
Please read through this section carefully, as it contains important information for safe and economical operation of
yourNavigatorTM balance.
1.1Introduction
Thank you for deciding to purchase a NavigatorTM balance from Ohaus. This versatile, portable balance offers a high
level of operating convenience and useful functions to make accurate measurements usually obtained from higher
priced laboratory instruments. A custom LCD panel has a large 6 digit, 7 segment display which indicates the weight
value of an item being measured and a 6 character 14 segment display which spells out items selected in the menus.
In addition, the display contains text which indicates the active operating mode of the balance. Arrow indicators in
the display prompt the user as to what panel keys are to be pressed to initiate a change. Built-in RS232 communica-
tion is standard on all models and allows communication with printers or computers.
Panel controls are clearly marked as to their function with large zero/tare buttons on either side of the front panel.
Operation and setup of the balance is straightforward and easy. Setup is simple with 4 cursor keys, straightforward
menus, and prompts that easily guide you through the process.
NavigatorTM is designed with contours for easy cleaning and has a sealed front panel and spill gutter to direct liquids
off the balance. For leveling purposes, all models are equipped with adjustable feet and a level indicator.
Behindyourinstrument standsOHAUS Corporation, aleadingmanufacturerof precision weighingequipment. An
Aftermarket Department with trained instrument technicians is dedicated to provide you with the fastest service
possible in the event your instrument requires servicing. OHAUS Corporation also has a Customer Service Depart-
mentto answer anyinquiries regarding applications andaccessories.
To ensure you make full use of the possibilities offered by your NavigatorTM balance, we advise you to read through
these operating instructions very carefully.
Equipment Capacities
32g 210 410g 810g 2100g 4100g 8100g
2. INSTALLATION
2.1Unpacking and Checking the Standard Equipment
Open the package and remove the instrument and the accessories. Check the completeness of the delivery. The
following accessories are part of the standard equipment of your new NavigatorTM balance.
• Remove packing material from the instrument.
• Check the instrument for transport damage. Immediately inform your Ohaus dealer if you have complaints or
parts are missing.
• Store all parts of the packaging. This packaging guarantees the best possible protection for the transport of your
instrument.

9
DO NOT install the balance:
•Next to open windows or doors causing drafts or
rapid temperature changes.
•Near air conditioning or heat vents.
•Near vibrating, rotating or reciprocating equipment.
•Near magnetic fields or equipment that generates
magnetic fields.
•On an unlevel work surface.
•Allow sufficient space around the instrument for
ease of operation and keep away from radiating heat
sources.
2.2 Selecting the Location
The balance should always be used in an environment which is free from excessive air currents, corrosives, vibration,
and temperature or humidity extremes.These factors will affect displayed weight readings.
Wind Shield
On 810g to 8100g balances, a wind shield is provided to
reduce the possibility of air currents from disturbing the
pan. When the wind shield is in place, air currents are
deflected up over the pan. Place the wind shield on top
of the balance making sure the small alignment tab is
locatedproperly on the balance.
2.3 Installing Wind Shield
2.4 Installing Subplatform and Pan All balances are supplied with a subplatform and pan.
The subplatform fits through the hole on top of the
balance and rests on a cone assembly which is part of
themeasuring load cell.
The bottom of the subplatform contains a slotted keyway
for installation purposes. Place the subplatform in place
aligning the slot with the pin on the cone assembly.
Install the pan on the subplatform. The illustration shows
therectangularpan.
Pan
Subplatform
Windshield

10
2.5 Connecting Power and
Communications
AC Power Operation
Connect the cord from the AC Adapter supplied to the
connector located at the rear of the balance. Connect the
ACAdapter to an appropriatepower source.
Battery Operation
The balance can be operated using 8 AA alkaline batter-
ies (not included). The battery compartment is located on
the bottom of the balance. To install batteries, proceed as
follows:
• Remove the pan, subplatform, and wind shield.
• Turn the balance over. Do not rest the balance on
the cone.
• Press the tab on the battery cover inward and lift the
cover off.
• Remove thebattery holder.
• Install the 8 AA alkaline batteries in the battery holder,
orienting the plus (+) and minus (-) ends as indicated
onthe holder.
• Replace the battery holder in the compartment. Make
sure the snap connector is connected.
• Replace the battery cover.
• Turn the balance over and replace the wind shield,
subplatformand pan.
Communication Connections
When an optional printer or computer is going to be used
with the balance, connect an Ohaus RS232 Interface
Cable to the connector at the rear of the balance and the
external device. Refer to paragraph 5.7 Accessories for
cable information and part numbers.
NOTE: A standard RS232 cable cannot be used as the
pinconnections are different.
Thebalance is nowready for operation.
Security Bracket
A security bracket (molded in base) is provided at the
rear of the balance which allows the balance to be
secured by the optional cable and lock accessory.
Rear of Balance
AC Adapter Connection
RS232 Connector
Security Bracket
BottomView of Balance
2.6Leveling the Balance
Exact horizontal positioning and stable installation are
prerequisites for repeatable results. To compensate small
irregularities or inclinations at the location, the instrument
can be leveled.
For exact horizontal positioning, the balance is equipped
with a level indicator located at rear.
Position the balance in the intended
operating location. Adjust the leveling
feet until the air bubble in the indicator
is centered.
NOTE:The instrument should be leveled each time its
location is changed.

11
RS232
Power ON/OFF(Batterymodeonly)
Baud 300,1200,2400,4800,9600
Parity None,-E-,-Odd-,-0-,-1-
Data 7,8
Stop 1, 2
Lock ON/OFF
Exit
MODE
Weigh ON/OFF
Percent ON/OFF
Count ON/OFF
Animal ON/OFF
Checkweigh ON/OFF
Lock ON/OFF
Exit
PRINT
AutoPrint OFF,Cont,Inter,OnStb
Interval Enter 1seconds
Stable ON/OFF
Numeric ON/OFF
GLP Con ON/OFF
GLP Tar ON/OFF
Reference ON/OFF
Lock ON/OFF
Exit
START
DATE
Type m/d/y, dMy, yMd, Myd,ydM,
or dyM
Set
Exit
TIME
Type 12 Hour/24 Hour
Set Time
Adjust Enter xx seconds
Exit
GLP DATA
User Number Enter 6 digits
Project Number Enter 6 digits
Lock ON/OFF
Exit
GLP SET
Time ON/OFF
Balance ID ON/OFF
User Number ON/OFF
Project Number ON/OFF
Difference ON/OFF
Name ON/OFF
Lock ON/OFF
Exit
SETUP SUBMENUS
3 OPERATINGYOUR BALANCE
3.1 The Menu (Basic Settings of the Instrument)
The balance has three basic menus; each is selected by front panel buttons marked Mode, Units and Setup.
Mode Button
The Mode button, when pressed, permits the selection of five weighing modes which are: weigh, percent, count, animal
weighing and checkweigh. These modes are controlled by an on or off selection made in the Setup menu under the
Modemenu.
Units Button
The Units button, when pressed, allows you to select or change units.
Setup Button
The Setup button, when pressed, allows entry into menus which allow you to set the balance for specific operating
parameters. Each of the menus contain settings which are user selectable. The tables below illustrates the various
menus and the functions which are selectable. The items shown on the menu, which are bolded, are the factory default
settings. If the Setup menu is not entered, the balance would function in the basic manner shown by the various
settings which are bolded. The setup menus shown below are arranged in the order as displayed in the balance.
UNITS
Units (grams only) ON/OFF
Lock ON/OFF
Exit
GLOBAL
List NO/YES
Reset NO/YES
Version Software No.
Lock ON/OFF
Exit
CUSTOM
Factor Enter 6 digits
Exponent 3 , 2, 1, 0, -1, -2, -3
LSD .5, 1, 2, 5, 10, 100
Lock ON/OFF
Exit
READOUT
Stable .5d, 1d, 2d, 5d
Auto 0 OFF, .5d, 1d, 3d
Filter -0-, -1-, -2-, -3-
Lock ON/OFF
Exit
CAL (CALIBRATION)
InCalTM Calibration (No Lock)*
Span Calibration
User Calibration
Linearity Calibration
Calibration Test (No Lock)
Calibration Now ON/OFF
Calibration Adj ± 100 (0)
Lock ON/OFF
Exit
*(If option is installed)
AUTO SHUT OFF
Timer 0- 60 minutes
Lock ON/OFF
Exit

12
3.2 Turning On the Balance
The balance is ready to operate after the installation procedures are performed. When the balance is first turned on
and it completes its checks, it can be used to weigh or tare materials without setting the menus.
It is recommended that you read this manual carefully and set the balance to operate for your specific applications
using the procedures in Chapter 4 Setting upYour Balance and calibrate the balance before using.
In this section, you will enter the menu for the first time. Do not worry if you are unfamiliar with the function of the
buttons on the panel, the display provides the necessary coaching as you go along.
Power On/Off
To turn the balance ON, press the ON/OFF button (circled
button with an I inside) located at the upper left-hand
corner of the panel once. To turn OFF, press button
again.
NOTE: If the balance has been battery operated for a
long period of time, and the batteries are low, the balance
displaysLOWBAT. Turn the balance OFF. Remove the
batteriesandreplace.
Stabilization
Before initially using the balance, allow time for it to
adjust to its new environment. Recommended warm up
period is 5 minutes.
Calibration
Referto paragraph 3.3 andcalibrate the balance before
proceeding.
3.3 Calibration
Navigator balances offer a choice of five calibration methods: Internal Calibration (InCALTM), Span Calibration, User
Calibration,Linearity Calibration, and CalTestTM.
• InCal
TM Internal calibration (InCALTM) of the balance is accomplished by an internal mass (If option
is installed). When CAL NOW is selected and set ON, CAL NOW is displayed when the
balance requires calibration. When CAL NOW is set OFF, the message CAL NOW is not
displayed.
• Span - Span calibration ensures that the balance reads correctly within specifications using two
weight values: zero and a weight value at 50% of full capacity and or 100% of the balance’s
full capacity.
• User - User calibration is a method where the balance can be calibrated using a mass of known
value and entering that numeric value into the balance.
• Linearity - Linearity calibration minimizes deviation between actual and displayed weights within the
balance’s weighing range. Three weight values are used:zero, a weight value at midpoint of
the balance's weighing range, and a weight value at or near the balance’s specified capacity.
• CalTest - Calibration test allows the stored calibration data to be tested against the current mass being
used for the test.
• Lock - Can be set on or off. When set on, Span, User and Linearity calibration are locked out and
cannot be used.

13
CALIBRATION MASSES
LINEARITY SPAN ONLY
CAPACITY MASSES MASSES
32g 10g and 30g 30g
210g 100g and 200g 100g or 200g
410g 200g and 400g 200g or 400g
810g 400g and 800g 400g or 800g
2100g 1000g and 2000g 1000g or 2000g
4100g 2000g and 400g 2000g or 4000g
8100g 4000g and 8000g 4000g or 8000g
It is recommended that masses meet or exceed ASTM
Class 4Tolerance. Models 410g and 4100g use Class
2. Calibrationmasses are available as accessories.
3.3 Calibration (Cont.)
Calibration Menu Protection
NOTES:
• Calibration may be locked out to prevent unauthorized
personnelfrom changing calibration.Ifcalibration has been
locked out, you can only access Cal Test.
•To lock out calibration menu, after calibration, refer to the
sectiontitled Menu Lock-OutProtection, paragraph 4.12.
Calibration Masses
Beforebeginning calibration, makesure masses are
available. If you begin calibration and realize calibration
masses are not available, exit the menu. The balance will
retainpreviously stored calibrationdata. Calibrationshould
beperformed as necessary toensure accurate weighing.
Masses required to perform the procedures are listed in
the adjacent table and are available as accessories.
NOTE:
Any of the calibration modes can be terminated at any
time by pressing either the Mode, Units or Setup buttons.

14
3.3.1Internal Calibration (InCALTM)
On NavigatorTM balances equipped with the InCalTM feature, calibration can be accomplished using the internal calibra-
tion mass. InCalTM requires use of the AC adapter supplied with the balance. When the balance requires calibration, a
screen prompt of CAL NOW appears. This display can be turned off as described under Calibration Message. Also, a
software feature is incorporated which permits the internal calibration mass to be adjusted by +100 divisions. The
adjust feature is described under Calibration Adjust. Internal calibration can be performed at any time providing the
balancehas warmed up to operatingtemperature.
• Press the Setup button, CAL is displayed.
• Press Enter button, CAL TYP is displayed.
• Press Enter button, CALTYP InCAL is displayed.
• Press Enter button, INCAL is displayed.
Procedure
NOTE: If a weight is left on the pan, the balance will
display CLR PAN (remove the weight from the pan).
Thebalance automatically resumescalibration.
The internal mass is positioned several times during
calibration and then removed, then after a few seconds,
CAL SET is displayed indicating a successful calibra-
tion. The display returns toWEIGH mode.
IMPORTANT !
DO NOT DISTURB THE BALANCE DURING
CALIBRATION. IF THE MESSAGE UNSTBL
IS DISPLAYED,THE BALANCEWAS UNABLE
TO ACQUIRE STABLE DATA DURING INTER-
NAL CALIBRATION. THE BALANCE WILL
CONTINUE TO PERFORM INTERNAL CALI-
BRATION UNTIL READINGS STABILIZE. THE
BALANCE WILL THEN COMPLETE THE IN-
TERNAL CALIBRATION FUNCTION.
TO EXIT INTERNAL CALIBRATION MODE
BEFORE COMPLETION, PRESS ENTER OR
SETUP BUTTONS.
STABILITY CAN BE AFFECTED BY TEM-
PERATURE CHANGES, AIR CURRENTS, VI-
BRATION, ETC...

15
3.3.2Calibration Message
On NavigatorTM balances equipped with the InCalTM feature, a screen prompt of CAL NOW appears when the balance
requires calibration. This display can be turned off if it is desired not to have the balance indicate that calibration is
required. Turning the display off has no effect on the basic balance operation.
Procedure
• Press the Setup button, CAL is displayed.
• Press Enter button, CALTYP is displayed.
• Press button, CAL NOW is displayed.
• Press Enter button, CAL NOW ON or OFF is dis-
played.
• Press or button and select either ON or
OFF. When OFF is selected, the CAL NOW message
will not appear in the display.
• Press Enter button, SAVED is momentarily displayed,
then the display indicates CAL ADJ.
NOTE: At this point you may continue with the calibra-
tion adjust procedure on the next page or exit.
The calibration adjust procedure is only used when it is
desired to calibrate the internal calibration mass to a
known external mass if a difference exits between the
known mass and the InCal
TM
value.
• Press Enter button, LOCK is displayed.
• Press or button and select either ON or OFF.
• Press Enter button, SAVED is momentarily displayed,
then the display indicates EXIT.
• Press Enter button, display returns toWEIGH mode.

16
3.3.3Calibration Adjust
Balances with InCalTM contain software which allows the
internal calibration value to be adjusted by + 100 divisions
at full scale capacity using an external mass which is
traceable to a certified standard.
Procedure
• Perform theinternal calibrationprocedure.
• Press >O/T< button to zero the balance.
• Place a mass equal to the span calibration value of
the balance on the pan. Note the reading on the bal-
ance and see if the balance indicates the exact
weight or indicates a higher or lower reading. If the
readingis higher or lower, proceed.
• Press the Setup button, CAL is displayed.
• Press Enter button, CALTYP is displayed.
• Press button until , CAL ADJ is displayed.
• Press Enter button, CAL ADJ 0 should be dis-
played (0 is factory setting).
NOTE: Balance will retain last CAL ADJ setting.
• Press or button until desired number is
displayed.
• Press Enter button, SAVED is momentarily displayed,
then display indicates LOCK.
• Press Enter button, LOCK ON or LOCK OFF is
displayed.
• Press or button and select either LOCK ON
or LOCK OFF.
• Press Enter button, SAVED is momentarily displayed,
then EXIT is displayed.
• Press Enter button, display returns to WEIGH
mode.Note weight readingandremove mass from
pan.
• Performthe internal calibration procedure. The value
entered as an adjustment is now stored. Place the
calibration mass on the pan and check. Repeat pro-
cedure if further correction is required.
• To return to factory setting, follow procedure above
and set CAL ADJ to 0.

17
3.3.4Span Calibration
Span calibration utilizes two calibration points, one at zero and a choice of either half capacity or full capacity. All
balances will prompt for a particular weight which is shown in the table.If the prompt calls for a half capacity mass,
you can use a full capacity mass, the balance will accept it. If the prompt calls for a full capacity mass, you can use
a half capacity mass.This versatility allows calibration at other than full capacity. Sample display below illustrates a
210gbalance.
Procedure
• Clearthe pan.
• Press the Setup button, CAL is displayed.
• Press Enter button, CALTYP is displayed.
• Press Enter button to select SPAN calibration, CAL
TYP SPAN is displayed.
• Press Enter button, BUSY is displayed.
NOTE: If a weight is left on the pan, the balance will
display CLR PAN (remove the weight from the pan).
The balance automatically resumes calibration.
• Place the calibration mass on pan.
NOTE:The PUTWEIGHT message indicates the
calibration mass that is on the pan.
• Press Enter button, BUSY is displayed. After a
few seconds CAL SET is displayed, the display then
returns toWEIGH mode.
• Span calibration is completed.
• Remove calibration mass from the pan.
SPAN CALIBRATION MASSES
MODEL 32g 210g 410g
MASS 30g 100g, 200g 200g, 400g
MODEL 810g 2100g 4100g 8100g
MASS 400g, 800g 1kg, 2kg 2kg, 4kg 4kg, 8kg
• Display changes to PUTWT 200g. The displayed
weight is the value of the mass to be used. See the
following table for masses that may be used with the
different model balances. Values shown in bold are
displayed.

18
3.3.5User Calibration
User calibration is used when it is desired to calibrate the balance using a mass of known value. User calibration limits
are no less than the 1/2 nominal capacity point and no more than the display over limit. For example, on a 210g
balance, it's no less than 100.00g and no more than 210.09g. To use this calibration feature, proceed as follows:
(FLASHING)
• Clearthe pan.
• Press the Setup button, CAL is displayed.
• Press Enter button, CALTYP is displayed.
• PressEnter button.
• Press and scroll to select USER calibration,
CAL TYP USEr is displayed.
• Press Enter button, the display indicates the last
calibration mass value which was entered with the
first digit flashing. (Sampleillustrates 200g).
• Press to change value of digit and
button to advance to next digit. Enter the desired
mass value for your balance. This number must be
at least 50% of the full span value.
• After entering value, press Enter button, BUSY is
displayed.
NOTE: If a weight is left on the pan, the balance will
display CLR PAN (remove the weight from the pan).
Thebalance automatically resumescalibration.
• Display changes to PUT WT 200 g.
• Place specified calibration mass on pan.
• Press Enter button, BUSY is displayed. After a
few seconds CAL SET is displayed, the display then
returns toWEIGH mode.
• User calibration is completed.
• Remove calibration mass from the pan.
Procedure

19
Procedure
• Clearthe pan.
• Press the Setup button, CAL is displayed.
• Press Enter button, CAL TYP is displayed.
• PressEnter button.
• Press button and scroll to select Linearity
calibration, CALTYP Lin is displayed.
• Press Enter button, BUSY is displayed.
NOTE: If a weight is left on the pan, the balance will
display CLR PAN (remove the weight from the pan).
Thebalance automatically resumescalibration.
• Display changes to PUT WT 100 g. The displayed
weight is half the capacity of the balance.
• Place specified calibration mass on pan.
• Press Enter button, BUSY is displayed. After a
few seconds display changes to PUT WT 200 g.
The displayed weight is the full capacity of the
balance.
• Place specified calibration mass on pan.
• Press Enter button, BUSY is displayed. After a
few seconds CAL SET is displayed, the display then
returns to WEIGH mode.
• Linearity calibration is completed.
• Remove calibration mass from the pan.
3.3.6Linearity Calibration
Linearity calibration utilizes three calibration points, one at zero, center span and full span. This method minimizes
deviation between actual and displayed weights within the balance's weighing range. Sample display illustrates a 210g
balance.

20
3.3.7Calibration Test
Calibration test feature allows a check of a known calibration mass against the last stored calibration information in the
balance. Sample display illustrates a 210g balance.
Procedure
• Clearthe pan.
• Press the Setup button, CAL is displayed.
• Press Enter button, CALTYP is displayed.
• PressEnter button.
• Press button and scroll to select CALtSt
calibration, CAL TYP CALtSt is displayed.
• Press Enter button, BUSY is displayed.
NOTE: If a weight is left on the pan, the balance will
display CLR PAN (remove the weight from the pan).
The balance automatically resumes calibration.
• Display changes to PUTWT 200 g. The displayed
weight is the full capacity of the balance.
• Place specified calibration mass on pan.
• Press Enter button, BUSY is displayed. After a
few seconds, DIFF is displayed. The display now
indicates the actual difference in weight between
what value was just placed on the pan and the previ-
ous weight value which was stored in the balance.
After approximately 8 seconds, the display returns to
theWEIGH mode.
• Remove calibration test mass from the pan.
