OHAUS Emerald User manual

1
Ohaus Corporation
19A Chapin Road
P.O. Box 2033
Pine Brook, NJ 070 8, USA
Ohaus Emerald Hand-Held Jewelry Scales
-OPERATING MANUAL-
 Emerald scales only differ in weighing units and capacity. Unless
otherwise specified, the content of this manual applies to all models.
 For best results, use the scale in the specified optimum operating
temperature.
 For best accuracy, perform your mass measurements in clean
environments, free of electrostatic and magnetic fields, dust and dirt,
moisture, vibration and air currents.
 Use your scale with care, gently loading items to be weighed onto the
center of the pan. Avoiding rough treatment will aid in the life of your
hand-held scale.
 Calibration weights are not provided with the scale.
Emerald 7 language manual 71152284.p65 11/21/2002, 11:43 AM1

2
Battery Installation
Two AAA size alkaline batteries are provided.
CAUTION: eep the protective cover in place while installing batteries.
 Remove the battery cover on the bottom of the scale and place the two
AAA size alkaline batteries into the compartment as indicated.
 Do not use excessive force or press the weighing pan.
 Re-insert the battery cover.
General Produ t Features
Power Up Test: When the scale is turned on, all display segments will
appear for approximately 3 seconds before resetting to zero.
Unit Indi ation: On the right side of the display, a right facing arrow will
appear indicating the weighing mode in which the scale is operating.
Stable Reading Indi ation: On the display, a star indicator will appear in
the lower left corner of the display when a stable reading has been
reached.
Overload: If the applied load exceeds the capacity of the scale, an E
will appear on the display and the load should be removed immediately.
The scale will return to normal operation.
Zero Fun tion: Values can progressively be added to a sample. By
pressing the Zero button, the scale display returns to zero. After
adding additional mass, press Zero to zero the scale again.
Additional mass may be added up to the capacity of the scale.
Negative Value: When a load is removed from the scale, any zeroed
value will be displayed as a negative number. To return to normal
operation, the tared value can be cancelled by pressing Zero.
Auto Shut-Off: To extend battery life, the scale will automatically turn off
after approximately 2 to 4 minutes if no active weighing is occurring.
EL Ba k Light: The display has an Electronic Luminescence (EL) back
light source, which is activated by pressing the Light Bulb button. The
back light will automatically turn off after 10 seconds.
Lo Battery: The display will show Lo when the batteries are weak and
need replacement.
g
+
ozt
dwt
oz
Emerald 7 language manual 71152284.p65 11/21/2002, 11:43 AM2

3
Four Button Keypad
On/Off : Pressing this button turns on the scale. Pressing and holding
this button turns the scale off.
Zero: Pressing this button operates the zero feature when the scale is
on.
Unit/Cal: Press this button briefly to change the weighing unit. The
following weight units may be selected: grams (g), ounces (oz),
pennyweight (dwt), or troy ounces (oz t). Press and holding this button
begins the calibration process.
 Light Button: Pressing this button turns on the EL ba k light on for
10 se onds.
Calibration
For best results, calibrate the scale at regular intervals. This is especially
important if the scale is in use for prolonged periods.
 Pressing and holding the Unit/Cal button starts the
calibration process. The display should show CAL.
 The calibration process can be aborted by turning the
scale off.
 Press the On/Off button to capture 0. The display
shows -C- while the scale stores the the zero load
signal.
 The display will show C xxx where xxx is the
calibration weight in grams.
 Place the appropriate calibration weight on the
platform.
 Press the On/Off button.
 The display shows -C- while the scale stores the
calibration point signal.
 After span capture, the display returns to the
normal weighing mode.
 The message AL E then E will appear if the
calibration steps are not followed or the wrong weight
was used.
g
+
Emerald 7 language manual 71152284.p65 11/21/2002, 11:43 AM3

4
A essories Supplied
 Two AAA size alkakine batteries.
 Plastic molded protective cover.
Optional A essories
Calibration Mass:
100g for JE 120 51015-16
200g for JE 250 51025-16
300g for JE 500 51035-16
Spe ifi ations
JE1 0 JE 50 JE500
Capacity x Readability 120.0 X 0.1g 2 0 X 0.1g 00 X 0.1g
4.232 x .002oz 8.81 x .00 oz 17.63 x .01oz
3.8 8 x 002ozt 8.03 x .00 ozt 16.07 x 0.01oz t
77.1 x 0.0 dwt 160.7 x 0.1 dwt 321 x .1 dwt
Linearity ±0.1g ±0.2g
Weighing units g, oz, dwt, oz t
Zero range to capacity by subtraction
Calibration User calibration
Stabilization time 3 seconds
Maximum overload 1 0% of capacity
Overload indication [ E ]
Underload indication Negative value
Auto shut-off 2 - 4 minutes no activity
Optimum operating temperature 64° to 77° F / 18° to 2 ° C
Weigh pan size L x W (in/cm) 3.2 x 3/8.3 x 7.6
Power requirements 2-AAA alkaline batteries
Dimensions L x W x H (in/cm) .3 x 3.2 x 0.8 / 13.6 x 8.3 x 2.0
Net Weight (lb/kg) 0.34/0.16
Emerald 7 language manual 71152284.p65 11/21/2002, 11:43 AM4

Declaration of Conformity We, Ohaus Corporation, declare under our sole responsibility that
the balance models listed below marked with "CE" are in conformity with the directives and
standards mentioned.
Marked with: EC Directive (Including applicable amendments) Standard
89/336/EC EN613 6:1997 + A1:1998
Electromagnetic compatibility Electrical Equipment for Measurement,
Control and Laboratory Use
- EMC requirements
Immunity - Performance Criterion B
Emissions - Class B
ISO 9001 Registration for Ohaus Corporation. Ohaus Corporation, USA, was examined and
evaluated in 1994 by the Bureau Veritas Quality International (BVQI) and was awarded ISO 9001
registration. This certifies that Ohaus Corporation, USA, has a quality system that conforms with the
international standards for quality management and quality assurance (ISO 9000 series). Repeat
audits are carried out by BVQI at intervals to check that the quality system is operated in the proper
manner.
Last two digits of the year which the CE marking was affixed: 02
Ohaus Corporation, 19A Chapin Road, P.O. Box 2033, Pine Brook, NJ, 070 8, USA
Scale model (s) Emerald Hand-Held Jewelry Scales
Ted Xia
Ohaus Corporation, Pine Brook, NJ USAn
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Emerald 7 language manual 71152284.p65 11/21/2002, 11:43 AM5

6
LIMITED WARRANTY
Ohaus compact scales are warranted against defects in materials and
workmanship for a period of 12 months from the date of delivery. During
the warranty period, Ohaus will repair, or, at its option, replace any
component(s) that prove to be defective at no charge, provided that the
product is returned, freight prepaid, to Ohaus.
This warranty does not apply if the product has been damaged by accident
or misuse, exposed to radioactive or corrosive materials, has foreign
material penetrating to the inside of the product, or as a result of service
or modification by other than Ohaus. In lieu of a properly returned warranty
registration card, the warranty period shall begin on the date of shipment
to the authorized dealer. No other express or implied warranty is given by
Ohaus Corporation. Ohaus Corporation shall not be liable for any
consequential damages.
Ohaus Corporation
19A Chapin Road
P.O. Box 2033
Pine Brook, NJ 070 8, USA
Tel: [phone]
Fax: [phone]
With offices worldwide.
Ohaus Corporation 2002, all rights reserved. Printed in China P/N 711 2284
