1. INTRODUCTION
This manual contains installation, operation and maintenance instructions for the Scout SPX
Series Balances. Please read the manual completely before using the balance.
1.1 Definition of Signal Warnings and Symbols
Safety notes are marked with signal words and warning symbols. These show safety issues and
warnings. Ignoring the safety notes may lead to personal injury, damage to the instrument,
malfunctions and false results.
Signal Words
WARNING For a hazardous situation with medium risk, possibly resulting in injuries or
death if not avoided.
CAUTION For a hazardous situation with low risk, resulting in damage to the device or
the property or in loss of data, or injuries if not avoided.
Attention For important information about the product.
Note For useful information about the product
Warning Symbols
Attention Symbol Electric Shock Hazard
1.2 Safety Precautions
CAUTION: Read all safety warnings before installing, making connections, or
servicing this equipment. Failure to comply with these warnings could result in
personal injury and/or property damage. Retain all instructions for future
reference.
Verify that the local AC power supply is within the input voltage range printed on the AC
label.
Only connect the AC adapter to a compatible grounded electrical outlet.
Do not position the scale such that it is difficult to disconnect the AC adapter from the
power receptacle.
Make sure that the power cord does not pose a potential obstacle or tripping hazard.
This equipment is intended for indoor use and should only be operated in dry locations.
Operate the equipment only under ambient conditions specified in the user instructions.
Do not operate the equipment in hazardous or unstable environments.
Do not drop loads on the pan.
Only use approved accessories and peripherals.
Disconnect power from the equipment before cleaning or servicing.
Service should only be performed by authorized personnel.
2. INSTALLATION
2.1 Installing Components
Refer to the illustrations and instructions below to identify and assemble your Scout balance
with its components. All components must be assembled before using the balance.
www. .com [e-mail]1.800.561.8187

EN-2 SCOUTTM SERIES BALANCES - SPX
2.1.1 Releasing the transportation Lock
Release the red Transportation Lock on
subplatform of the balance by turning
the
red pointer 90 counter-clockwise.
Figure 2-1. Transportation Lock
2.1.2 Installing the Weighing Pan
Balances with a rectangular pan are placed into the sub-platform as shown and rotated
counter-clockwise until it locks. Round pans are placed straight down on sub-platform.
Figure 2-2. Pan Installation
2.1.3 Security Slot
A security slot is provided at the rear of the balance allowing the balance to be secured by an
optional cable and lock accessory.
2.2 Selecting the Location
For best performance, the Scout SPX balance should be used in a clean, stable environment.
Do not use the balance in environments with excessive drafts, with rapid temperature changes,
near magnetic fields or near equipment that generates magnetic fields, or vibrations.
2.3 Leveling the Balance
The Scout has an illuminated level indicator as a reminder that the balance should be leveled
for accurate weighing. There is a level bubble in a small round window on the front of the
balance. To level the balance, adjust the feet at each corner until the bubble is centered in the
circle. Be sure the equipment is level each time its location is changed.
Figure 2-3. Level indicator
Subplatform Transportation
Lock Pointer
Unlocked
Position
Locked
Position
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-3
2.4 Connecting Power
AC Adapter Installation
AC power is used to power the scale when battery power is not needed. First, connect the AC
Adapter (supplied) to the AC Adapter Input Jack at the rear of the balance then connect the AC
plug to an electrical outlet.
Figure 2-4. Rear and bottom view of balance
Battery Installation
Note:
After power on, it is recommended to warm up the balance for at least 5 minutes before using it.
2.5 Initial Calibration
When the Balance is first installed, and when it is moved to another location, it must be
calibrated to ensure accurate weighing results. Have the appropriate calibration masses
available before beginning calibration. Refer to the Calibration Section for masses and
calibration procedure.
AC Adapter Input Jack
Battery Compartment Cover
Interface Connection
Security Switch
Weigh Below Hole
Security slot (Anti-theft lock slot)
www. .com [e-mail]1.800.561.8187

EN-4 SCOUTTM SERIES BALANCES - SPX
3. OPERATION
3.1 Controls
Figure 3-1. Scout Control Panel
TABLE 3-1. Button Functions
Button
Primary Function
(Short Press)
Zero/On
Turns the balance
on
If balance is On,
sets Zero
Print
Sends the current
value to the selected
COM ports if
AUTOPRINT is set
to Off.
Function
Initiates an
application
mode.
Tare
Enter/clear a
tare value.
Secondary Function
(Long Press)
Zero/Off
Turns the balance
Off.
Units
Changes the
weighing unit.
Mode
Allows changing
the application
mode.
Menu
Enter the
User menu.
Menu Function
(Short Press)
Yes
Accepts the current
setting on the
display.
No
Advances to the next
menu or menu item.
Rejects the current
setting on the
display and
advances to the next
available setting.
Back
Moves Back to
previous menu
item.
Exit
Exits the
User menu.
Aborts the
calibration in
progress.
Notes: 1 Short Press: Press less than 1 second.
2 Long Press: Press and hold for more than 2 seconds.
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-5
Figure 3-1. Scout Display
TABLE 3-2. Display Symbols*
Item Description Item Description
1 Battery charge symbol 8 Kilogram, grain symbols
2 Stable weight symbol 9 Check Weighing symbols
3 Negative symbol 10 Pound, Ounce, Pound:Ounce symbols
4 Center of Zero symbol 11 Percent, dwt, g/mol symbols
5 NET symbol 12 Gravity, Pieces, t hk, t sg, t tw, Hold
symbols
6 Preset Tare symbol 13 Newton, Totalization, Dynamic, Bluetooth
symbols
7 Pointer symbols
Note: * Some symbols might not be available depending on different models.
3.2 Turning Balance On/Off
To turn the balance on, press and hold the On/Zero Off button for 1 second. The balance
performs a display test, momentarily displays the software version, and then enters the active
weighing mode.
To turn the balance off, press and hold the On/Zero Off button until OFF is displayed.
3.3 Calibration Operation
When the balance is operated for the first time, a span calibration is recommended to ensure
accurate weighing results. Before performing the calibration, be sure to have the appropriate
calibration weights. Ensure that the Security switch is set to unlocked position.
Press and hold Menu until [ ] (Menu) is displayed. When the button is released, the display
will show [ ]. Press Yes to accept. [ ] will then be shown. Press Yes to begin the span
calibration.
[ ] will be displayed while zero reading is stored. Next, the display shows the calibration
weight value (press No to toggle value). Place the specified calibration mass on the pan. [ ]
will be displayed while the reading is stored. The display will show [ ] if the calibration was
successful. The balance returns to the previous application mode and is ready for use.
2
3
4
1
5
6
8
9
10
11
12
13
7
www. .com [e-mail]1.800.561.8187

EN-6 SCOUTTM SERIES BALANCES - SPX
3.4 Weighing Mode
This mode is the factory default setting.
1. If needed, press and hold Mode until [ ] (Weigh) is displayed.
2. If required, place an empty container on the pan and press Tare.
3. Add sample to the pan or container. The display shows the weight of the sample.
3.5 Counting Mode
This mode counts large numbers of items based on the weight of a reference count.
1. Place an empty container on the pan and press Tare.
2. Press and hold Mode until [ ] (Count) is displayed. [ ] (Clear Average Piece
Weight, APW) will then display.
If no APW exists, the balance will display [ ], proceed to step 5.
3. Press No to use the stored APW. Proceed to step 7.
4. Press Yes to establish an APW.
5. The balance will then display the stored sample size, i.e. [ ]. Press No or Back to
toggle the choices (5, 10, 20, 50 or 100).
6. Put the indicated number of pieces on the pan then press Yes to calculate the APW. The
display shows the piece count.
7. Add additional pieces until the desired count is reached.
8. To clear the stored APW press and hold Mode until [ ] is displayed. Press Yes when
[ ] is displayed.
Note: Press Function to view the current APW.
3.6 Percent Mode
This mode measures the weight of a sample as a percentage of a reference weight.
1. If required place an empty container on the pan and press Tare.
2. Press and hold Mode until [ ] is displayed. [ ] (clear reference) will then
display. If no reference weight exists, the balance will display [ ], proceed to step 5.
3. Press No to use the stored reference weight and proceed to step 6.
4. Press Yes to establish a new reference. Balance will now display [ ].
5. Add the desired reference material to the pan or container. Press Yes to store the
reference weight. The display shows 100%.
6. Replace the reference material with the sample material. The display shows the
percentage of the sample compared to reference weight.
7. To clear the stored reference press and hold Mode until [ ] is displayed. Press Yes
when [ ] is displayed.
Note: Press Function to view the current reference weight.
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-7
3.7 Check Mode
Use this mode to compare the Weight to a target weight range. The balance supports positive,
negative and zero check weighing.
3.7.1 Check Weighing
Use this mode to compare the weight of items to a target weight range.
1. Press and hold Mode until [ ] (Check) is displayed. [ ] (clear check limits) will
then display.
2. Press No to use the stored check limits and proceed to step 5.
3. Press Yes to establish new check limits. The balance will then display [ ]. Press Yes
Yes to accept or No
stored value then displays with the first digit highlighted [ kg]. Repeatedly press No
until the desired number appears. Press Yes to accept and highlight the next digit. Repeat
until all the digits are correct. Press Yes ] will be
displayed.
4. Repeat the same procedure to
5. If required, place an empty container on the pan and press Tare.
6. Place sample material on the pan or in the container. If the sample weight is under the
target weight range, the under icon will light.
If the sample is within the target weight range, the accept symbol will light. If the sample
is over the target weight range, over icon will light.
Note: Press Function to view the low and high check limits.
Positive Check
Positive check is used to determine when the material added to the balance is within the target
range. In this case the UNDER and OVER limits must be positive values. (The OVER limit must
be greater than the UNDER limit.)
Add material to the balance until it is within the ACCEPT ( ) range.
Negative Check
Negative check is used to determine when the material removed from the balance is within the
target range. In this case the UNDER and OVER limits are both negative values.
(The UNDER limit must be greater than the OVER limit.)
Place the item to be weighed on the balance and press TARE.
Remove a portion of the item until it is within the ACCEPT range.
Zero Check
Zero check is used when comparing subsequent samples to an initial reference sample. In this
case, the UNDER limit must be a negative value and the OVER limit must be a positive value.
Place the reference item on the balance and press TARE. Remove the reference sample and
place the item to be compared on the balance to determine if it is within the ACCEPT range.
www. .com [e-mail]1.800.561.8187

EN-8 SCOUTTM SERIES BALANCES - SPX
3.8 Totalization Mode
This mode allows the user to store a series of weight measurements. Totalize mode has been
initiated when the symbol is displayed and the current unit is displayed.
Notes: Only positive numbers are totalized.
1. Press and hold Mode until [ ] (Totalization) is displayed. [ ] will then
be displayed.
2. Press Yes or No key to clear the current totalized data or not. When a weight is added to
the scale the value is displayed.
3. If required, place an empty container on the pan and press Tare. Add the first item, its
weight is displayed. Press Function symbol will flash and
the display will show the total weight.
4. Press Tare (or remove the weight in previous operation) and add the next item. The
scale will display its weight. Press Function to store its weight. The symbol will
flash and the new total weight will be displayed.
5. Repeat step 4 for all of the items to be accumulated.
6. To clear the stored total press and hold Mode until [ ] is displayed. When [ ]
is displayed, press Yes.
3.9 Hold Mode
There are two modes for the display hold:
- Peak Hold: allows the user to capture and store the highest stable weight value (>=5d).
- Display Hold (default): allows the user to capture and store the first stable weight value (>=5d).
Start
If no weight value is held on the display, press Function key to begin. The [ ] (Ready) will
be displayed until a weight is added on the pan.
When the stable value is being held on the display, the Hold icon (H) will blink and the displayed
weight will not change.
Reset
If the pan is empty and a weight value was held on the display, a single short press of the
Function key will clear the held value and show the new weight on the pan.
1. Press and hold Mode until [ ] is displayed.
2. If required, place an empty container on the pan and press Tare. Zero value will then
display.
3. Press Function key to begin. The [ ] (Ready) will be displayed.
4. Place samples to be weighed on the pan.
5. The stable value will be held on the display, the Hold icon (H) will blink.
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-9
4. MENU SETTINGS
The User Menu allows the customizing of balance settings.
Note: Additional Sub-Menus may be available if Interface Options are installed. See Interface
User Manual for the additional setting information.
4.1 Menu Navigation
User Menu:
Sub-Menus C.a.l S.e.t.u.p M.o.d.e U.n.i.t E.n.d
User Menu
Items:
Span
Lin
Reset
Yes/No
Filter
Low/Med/High
AZT
0.5/1/3/Off
StableRange
0.5/1/2//5
Backlight
Off/On/Auto
Auto Tare
Off/On/On-acc
Auto Off
Off/1/5/10
Reset
Yes/No
Weighing
On/Off
Counting
On/Off
Percent
On/Off
Check
On/Off
Totalize
On/Off
Hold
Disp/Peak/Off
Reset
g
kg
ct
N
oz
ozt
dwt
lb
lb:oz
grn
hkt*
sgt*
twt*
t*
tola/tical
C
End End End End
Notes:
* Only available in certain regions.
When the Security Switch is in locked position, the Calibration function is hidden, Units are
locked to the current setting.
Security switch:
4.2 Calibration Menu
Enter this menu to perform calibrations.
Span [ ]
Initiates a span calibration procedure (zero and span)
Lin [ ]
Initiates a linearity calibration procedure (zero, mid-point and span).
End Cal [ ]
Advance to the next menu or return to the top of the current menu.
Span: Perform
Linearity: Perform
End Calibration: Exit menu
No/Back
Long press
-
Enter menu
Short press -
Accept
Short press
Go to
Next/Prev.
menu
Yes
Exit
Short press
Exit menu
www. .com [e-mail]1.800.561.8187

EN-10 SCOUTTM SERIES BALANCES - SPX
4.3 Setup Menu
Enter this menu to set balance parameters.
Note: Bold always represents factory default value
Reset [ ]
Reset the Setup menu to factory defaults.
NO = not reset
YES = reset
Filter [ ]
Set the amount of signal filtering.
LOW = less stability, faster stabilization time
MED = normal stability, stabilization time
HI = greater stability, slower stabilization time
AZT [ ]
Set the automatic zero tracking functionality.
OFF = disabled
0.5d = the display will maintain zero until a change of 0.5 divisions per second has
been exceeded.
1d = the display will maintain zero until a change of 1 divisions per second has been
exceeded.
3d = the display will maintain zero until a change of 3 divisions per second has been
exceeded.
Stable Range [ ]
Set the amount the reading can vary while the stability symbol remains on.
0.5d = 0.5 balance division
1d = 1 balance division
2d = 2 balance division
5d = 5 balance division
Back Light [ ]
Sets backlight functionality.
OFF = always off
ON = always on
AUTO = turns on when a button is pressed or the displayed weight changes.
Note: When connected with power pack, the backlight is always on.
Auto Tare [ ]
Set the automatic tare functionality.
OFF = Automatic Tare is disabled
ON = the first stable gross weight is tared
ON-ACC = stable gross loads within the accept limits are tared (in Check weighing mode)
Reset: no, yes
Filter: Low, Med, High
Auto Zero Tracking: off, 0.5d, 1d, 3d
Stable: 0.5d, 1d, 2d, 5d
Backlight: off, on, auto
Auto Tare: off, on, on-acc
Auto Off: off, 1, 5, 10
End Setup: Exit menu
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-11
Auto off [ ]
Set the automatic shut off functionality.
OFF = disabled
1 = powers off after 1 minute of no activity
5 = powers off after 5 minutes of no activity
10 = powers off after 10 minutes of no activity
End Setup [ ]
Advance to the next menu or return to the top of the current menu.
4.4 Mode Menu
This menu activates modes so they will be available for use with the Mode button.
Reset [ ]
Reset the Mode menu to factory defaults.
NO = not reset
YES = reset
Weigh [ ]
Set the status.
OFF = disabled
ON = enabled
Count [ ]
Set the status.
OFF = disabled
ON = enabled
Percent [ ]
Set the status.
OFF = disabled
ON = enabled
Check [ ]
Set the sub-mode
OFF = disabled
ON = enabled
Totalize [ ]
Set the sub-mode
OFF = disabled
ON = enabled
Reset:
no
, yes
Weigh: off, on
Count: off, on
Percent: off, on
Check: off, on
Totalize: off, on
Hold: Disp, Peak, Off
End Mode: Exit menu
www. .com [e-mail]1.800.561.8187

EN-12 SCOUTTM SERIES BALANCES - SPX
Hold [ ]
Set the sub-mode.
OFF = disabled
Peak Hold = allows the user to capture and store the highest stable weight value
(>=5d).
Display Hold = allows the user to capture and store the first stable weight value (>=5d).
weight will not change.
Advance to the next menu or return to the top of the current menu.
End Mode [ ]
4.5 Unit Menu
This menu activates units so they will be accessible with the Units button. The units in the menu
m .
Note: Available units vary by model and local regulations.
Custom Unit (C)
Use the Custom Unit to display weight in an alternative unit of measure. The custom unit is
defined using a conversion factor based on gram unit, where the conversion factor is the
number of custom units per gram expressed in scientific notation (Factor x 10^Exponent).
Factor
Set the conversion factor (0.1 to 1.99) using the numeric keypad.
The default setting is 1.0.
g: off,
on
kg: off, on
ct: off, on
N: off, on
oz: off, on
ozt: off, on
dwt: off, on
lb: off, on
lb:oz: off, on
grn: off, on
hkt: off, on
sgt: off, on
twt: off, on
t: off, tola, tical
C: off, on
End Unit: Exit menu
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-13
Exponent
Set the factor multiplier.
-3 = divide the Factor by 1000 (1x10-3)
-2 = divide the Factor by 100 (1x10-2)
-1 = divide the Factor by 10 (1x10-1)
0 = multiply the Factor by 1 (1x100)
1 = multiply the Factor by 10 (1x101)
2 = multiply the Factor by 100 (1x102)
3 = multiply the Factor by 1000 (1x103)
Least Significant Digit
Set the graduation.
Settings of 0.5, 1, 2, 5, 10, 100 are available.
Note: Custom Unit is locked at Off position when the Security Switch is set to the locked position.
Follow below instructions below to enter the unit menu to set the Custom Unit.
Press and hold Menu until [ ] is displayed. When the button is released, the display will
show [ ]. Press No through the succeeding menu items: [ ], [ ], [ ] until [ ] is
displayed.
1. When [ ] is displayed, press Yes.
2. [ ] will be displayed. Press No, [ g] will be displayed.
3. Press No to toggle through active units until [ c] is displayed.
4. Press Yes, [ c] will be displayed, then press Yes.
5. [ ] is displayed. Press Yes to view the default Factor. Press Yes to accept or No to edit
factor multiplier
[ ]. Repeatedly press No until the desired number appears. Press Yes to accept and
highlight the next digit. Repeat until all the digits are correct. Press Yes Factor
value.
6. [ ] is displayed. Repeat the same procedure as in step 5 to accept or edit the Exponent
value. Press Yes to accept the Exponent value.
7. [ ] is displayed. Repeat the same procedure as in step 5 to accept or edit the Least
Significant Digit value. Press the Yes key to accept the graduation value, [ ] is displayed.
8. When [ ] is displayed, press Exit to exit to weighing mode.
www. .com [e-mail]1.800.561.8187

EN-14 SCOUTTM SERIES BALANCES - SPX
4.6 Additional Features
Weigh Below Hook
The Scout Balance is equipped with a weigh below hook for weighing below the balance.
The weigh below hook is located at the reverse side of the battery cover as shown below.
To use this feature, remove the red protective cover underneath for the weigh below opening.
Attention: Before turning the balance over, remove the Pan and Pan
Support to
prevent damage.
Figure 4-2. Weigh below
The balance can be supported using lab jacks or any other convenient method. Ensure the
balance is level and secure and that the transportation lock has been released. Power on the
balance, then use a string or wire to attach items to be weighed.
Figure 4-3. Weigh below application
Connecting the Interface
Use an optional interface connectivity kit to
connect the balance either to a computer or a
printer.
Below Interface kit accessories are available:
RS232, USB Host, USB Device, Ethernet,
Bluetooth®*.
Figure 4-4. Rear of the balance
* Interface kits may vary according to local regulations
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by OHAUS is under license.
Interface connection AC Adapter jack Security slot
Weigh Below Hook Weigh Below Hook installed
Weigh below opening
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-15
5. MAINTENANCE
5.1 Cleaning
WARNING:
Electric Shock Hazard. Disconnect the equipment from the power
supply before cleaning. Electric Shock Hazard.
The housing may be cleaned with a cloth dampened with a mild detergent if necessary.
Attention: Do not use solvents, chemicals, alcohol, ammonia or abrasives to clean the housing
or control panel.
5.2 Troubleshooting
The following table lists common problems and possible causes and remedies.
If the problem persists, contact OHAUS or your authorized dealer.
TABLE 5-1
Symptom Possible Cause
Cannot turn on No power to balance
Poor accuracy Improper calibration; Unstable environment
Cannot calibrate Security switch in locked position
Weight exceeds power on zero range.
Weight below power on zero range.
Over load (weight exceeds rated capacity)
Under load (pan removed)
Tare out of range
Displayed value exceeds 999999 (possible in Totalization mode)
Parts counting or percentage error sample weight <1d. Balance shows
error then exits parts counting or goes to [ ].
Percent Reference weight or APW is too low for accurate results
Fail to do calibration.
Cannot find menu or app file in U-disk.
5.3 Service Information
If the troubleshooting section does not resolve or describe your problem, contact your
authorized OHAUS service agent. For service assistance or technical support in the United
States call toll- - - - between 8:00 AM and 5:00 PM EST. An OHAUS
product service specialist will be available to provide assistance. Outside the USA, please visit
our web site, to locate the OHAUS office nearest you.
www. .com [e-mail]1.800.561.8187

EN-16 SCOUTTM SERIES BALANCES - SPX
6. TECHNICAL DATA
The technical data is valid under the following ambient conditions:
Indoor use only
Operating temperature range: +10°C to +40°C
Relative humidity: 10% to 80% at 31°C, decreasing linearly to 50% at 40°C, non-condensing
Altitude: Up to 2000 m
Power: AC power adaptor input 100-240V 50/60 Hz and output 5 V DC 1 A, or 4 AA batteries
Pollution degree: 2
Installation category: II
Main supply voltage fluctuations: up to ± 10% of the nominal voltage
6.1 Specifications
TABLE 6-1. SPECIFICATIONS
Model SPX123 SPX223 SPX222 SPX422 SPX622 SPX1202 SPX2202
Capacity (g) 120 220 220 420 620 1200 2200
Readability (g) 0.001 0.001 0.01 0.01 0.01 0.01 0.01
Repeatability (Std. Dev.)
(g)
0.002
0.002
0.01
0.01
0.01
0.02
0.02
Linearity (g)
0.003
0.003
0.01
0.01
0.02
0.03
0.03
Span Calibration Mass*
100 g
200 g
200 g
200 g
300 g
1 kg
2 kg
Linearity Calibration Mass 50, 100 g 100, 200 g 100, 200 g 200, 400 g 300, 600 g
500 g,
1 kg 1 kg, 2 kg
Stabilization Time (s) 1.5 1 1.5
Construction ABS plastic housing with 304 stainless steel (SST) pan
Draftshield Yes No
Calibration User-selectable external span or linearity calibration / Digital with external weight
Tare Range
Full Capacity
by subtraction
Weighing Units** g, kg, ct, N, oz, ozt, dwt, lb, lb:oz, grn,Tael (HongKong),Tael (Singapore),Tael (Taiwan), tical,
tola, C (Custom unit)
Application Modes Weighing, Parts Counting, Percent Weighing, Check Weighing, Totalization, Display Hold
Typical Battery Life 80 hours 120 hours 80 hours
Specified Temperature
Range 10°C (50°F) to 40°C (104°F) at 10% to 80% relative humidity, non-condensing
Storage Conditions -20°C (-4°F) to 55°C (131°F) at 10% to 90% relative humidity, non-condensing
Communication RS232, USB Host, USB Device, Ethernet or Bluetooth*** (all available as accessory)
Display Type Backlit LCD: 6-digit 7-segment with white LED backlight
Display Size 0.78 in / 20 mm digits
Pan Size (W x D) Ø93 mm / 3.7 in Ø120 mm / 4.7 in 170 x 140 mm /
6.7 x 5.5 in
Balance Dimensions
(W x D x H)
202 x 222 x 103 mm /
8 x 8.7 x 4.1 in 202 x 224 x 54 mm / 8 x 8.8 x 2.1 in
Shipping Dimensions
(W x D x H)
300 x 250 x 129mm /
11.8 x 9.8 x 5.1 in 300 x 250 x 86 mm / 11.8 x 9.8 x 3.4 in
Net Weight 1 kg / 2.2 lb
Shipping Weight
1.5 kg / 3.3 lb
Notes:
* Calibration weights are included with models up to 620g capacity.
** Availability is dependent on model and region.
*** Bluetooth kit is only available in certain regions according to the local regulations
www. .com [e-mail]1.800.561.8187

SCOUTTM SERIES BALANCES - SPX EN-17
TABLE 6-2. SPECIFICATIONS cont.
Capacity x Readability:
Model SPX123 SPX223 SPX222 SPX422 SPX622 SPX1202 SPX2202
Gram (g) 120 x 0.001 220 x 0.001 220 x 0.01 420 x 0.01 620 x 0.01 1200 x 0.01 2200 x 0.01
Kilogram (kg) / / / / / 1.2 x 0.00001 2.2 x 0.00001
Carat (ct) 600 x 0.005 1100 x 0.005 1100 x 0.05 2100 x 0.05 3100 x 0.05 6000 x 0.05 11000 x 0.05
Newton (N) 1.17679 x
0.00001
2.15744 x
0.00001
2.1574 x
0.0001
4.1188 x
0.0001
6.0801 x
0.0001
11.7679 x
0.0001
21.5744 x
0.0001
Ounce (oz) 4.23290 x
0.00005
7.76030 x
0.00005
7.7600 x
0.0005
14.8150 x
0.0005
21.8700 x
0.0005
42.3290 x
0.0005
77.6030 x
0.0005
Ounce Troy (ozt) 3.85810 x
0.00005
7.07320 x
0.00005
7.0730 x
0.0005
13.5030 x
0.0005
19.9335 x
0.0005
38.5810 x
0.0005
70.7320 x
0.0005
Pennyweight (dwt) 77.162 x
0.001
141.463 x
0.001 141.46 x 0.01
270.07 x 0.01 398.67 x 0.01 771.62 x 0.01 1414.63 x
0.01
Pound (lb) / / / / 1.36690 x
0.00005
2.64555 x
0.00005
4.85020 x
0.00005
Pound:Ounce
(lb:oz) / / / / 1lb:5.8700oz x 0.0005oz
2lb:10.3290oz
x 0.0005oz
4lb:13.6030oz
x 0.0005oz
Grain (grn) 1851.88 x
0.02
3395.12 x
0.02
3395.0 x
0.2
6481.6 x
0.2
9568.0 x
0.2 18518.8 x 0.2 33951.2 x 0.2
TABLE 6-3. SPECIFICATIONS cont.
Model SPX421 SPX621 SPX2201 SPX6201 SPX8200
Capacity (g) 420 620 2200 6200 8200
Readability (g) 0.1 0.1 0.1 0.1 1
Repeatability (Std. Dev.) (g) 0.1 0.1 0.1 0.1 1
Linearity (g) 0.1 0.1 0.1 0.2 1
Span Calibration Mass*
200 g
300 g
2 kg
5 kg
8 kg
Linearity Calibration Mass 200, 400 g 300, 600 g 1 kg, 2 kg 3 kg, 6 kg 4 kg, 8 kg
Stabilization Time (s) 1
Construction ABS plastic housing with 304 stainless steel (SST) pan
Draftshield No
Calibration User-selectable external span or linearity calibration / Digital with external weight
Tare Range Full Capacity by subtraction
Weighing Units** g, kg, ct, N, oz, ozt, dwt, lb, lb:oz, grn,Tael (HongKong),Tael (Singapore),Tael (Taiwan),
tical, tola, C (Custom unit)
Application Modes Weighing, Parts Counting, Percent Weighing, Check Weighing, Totalization, Display Hold
Typical Battery Life 120 hours 80 hours 120 hours
Specified Temperature Range 10°C (50°F) to 40°C (104°F) at 10% to 80% relative humidity, non-condensing
Storage Conditions -20°C (-4°F) to 55°C (131°F) at 10% to 90% relative humidity, non-condensing
Communication RS232, USB Host, USB Device, Ethernet or Bluetooth*** (all available as accessory)
Display Type Backlit LCD: 6-digit 7-segment with white LED backlight
Display Size
0.78 in / 20 mm digits
Pan Size (W x D)
Ø120 mm /
4.7 in 170 x 140 mm / 6.7 x 5.5 in
Balance Dimensions
(W x D x H)
202 x 222 x 103 mm /
8 x 8.7 x 4.1 in 202 x 224 x 54 mm / 8 x 8.8 x 2.1 in
Shipping Dimensions
(W x D x H)
300 x 250 x 129mm /
11.8 x 9.8 x 5.1 in 300 x 250 x 86 mm / 11.8 x 9.8 x 3.4 in
Net Weight 1 kg / 2.2 lb
Shipping Weight 1.5 kg / 3.3 lb
Notes: * Calibration weights are included with models up to 620g capacity.
** Availability is dependent on model and region.
*** Bluetooth kit is only available in certain regions according to the local regulations
www. .com [e-mail]1.800.561.8187

EN-18 SCOUTTM SERIES BALANCES - SPX
TABLE 6-4. SPECIFICATIONS cont.
Capacity x Readability:
Model
SPX421
SPX621
SPX2201
SPX6201
SPX8200
Gram (g)
420 x 0.1
620 x 0.1
2200 x 0.1
6200 x 0.1
8200 x 1
Kilogram (kg)
/
/
2.2 x 0.0001
6.2 x 0.0001
8.2 x 0.001
Carat (ct) 2100 x 0.5 3100 x 0.5 11000 x 0.5 31000 x 0.5 41000 x 5
Newton (N) 4.119 x 0.001 6.080 x 0.001 21.574 x 0.001 60.801 x 0.001 80.41 x 0.01
Ounce (oz) 14.815 x 0.005 21.870 x 0.005 77.600 x 0.005 218.700 x 0.005 289.25 x 0.05
Ounce Troy (ozt) 13.500 x 0.005 19.930 x 0.005 70.730 x 0.005 199.335 x 0.005 263.60 x 0.05
Pennyweight (dwt) 270.1 x 0.1 398.7 x 0.1 1414.6 x 0.1 3986.7 x 0.1 5270 x 1
Pound (lb) / 1.3670 x 0.0005 4.8500 x 0.0005 13.6685 x
0.0005 18.080 x 0.005
Pound:Ounce (lb:oz) / 1lb:5.870oz x
0.005oz
4lb:13.600oz x
0.005oz
13lb:10.700oz x
0.005oz
18lb:1.25oz x
0.05oz
Grain (grn) 6480 x 2 9570 x 2 33950 x 2 95680 x 2 126540 x 20
6.2 Drawings
Figure 6.1 Dimensions
Model
A B C
with draftshield 202 mm / 8.0 in. 222 mm / 8.7 in. 103 mm / 4.1 in.
w/o draftshield 202 mm / 8.0 in. 224 mm / 8.8 in. 54 mm / 2.1 in.
6.3 Compliance
Compliance to the following standards is indicated by the corresponding mark on the product.
Mark Standard
This product complies with the applicable harmonized standards of EU
Directives 2011/65/EU (RoHS), 2014/30/EU (EMC), 2014/35/EU (LVD) and
2014/31/EU (NAWI). The EU Declaration of Conformity is available online at
EN 61326-1
CAN/CSA-C22.2 No. 61010-1
UL Std. No. 61010-1
www. .com [e-mail]1.800.561.8187
