Oki MC770 series User manual

MC770 / MC770+ / MC780 / MC780+
MPS3537mc / MPS3537mc+
MPS4242mc / MPS4242mc+
Maintenance Manual
(2 of 2) Controller Unit
051515B

Copyright © 2013 by Oki Data. All Rights Reserved
Oki Data America's, Inc. ("Oki Data"), authorizes you to view, copy, and print
documents published by Oki Data for noncommercial use within your organization only.
In consideration of this authorization, you agree and acknowledge that any copy of these
documents shall retain all copyright and proprietary rights contained herein. Each
document published by Oki Data may contain additional copyright information and
proprietary notification relating to that individual document.
Nothing contained herein shall be construed as conferring by estoppel, implication or
otherwise any license or right under any patent or trademark of Oki Data, Oki Electric
Industry Co., Ltd. ("Oki Electric"), or any third party. Except as provided above nothing
contained herein shall be construed as conferring any license or right under any Oki
Data copyright.
Oki Data has taken care to insure that the information which follows is complete,
accurate and up-to-date. However, Oki Data assumes no responsibility for errors or
omissions which may occur. All the information provided is subject to change from time
to time at the sole discretion of Oki Data.
All publications may include technical inaccuracies or typographical errors. We reserve
the right to make periodic changes, additions, and deletions to publications without
notice.
The most up-to-date drivers and manuals are available from the web site:
http://www.okiprintingsolutions.com
Oki Data CONFIDENTIAL

45584901TH Rev.1 ii /
Oki Data CONFIDENTIAL
Document Revision History
Rev.No. Date Corrected items Person in
charge
No. Page Description of change
1 2013-04-10 ISSUE P2E1 T. Asaba

45584901TH Rev.1 iii /
Oki Data CONFIDENTIAL
TRADEMARKS
• TheofcialnameofWindows8isMicrosoftWindows8OperatingSystem.
• TheofcialnameofWindows7isMicrosoftWindows7OperatingSystem.
• TheofcialnameofWindowsVistaisMicrosoftWindowsVistaOperatingSystem.
• TheofcialnameofWindowsXPisMicrosoftWindowsXPOperatingSystem.
• Microsoft,Windows,WindowsNT,WindowsVistaandthebrandnamesandproductnamesof
other Microsoft products are trademarks or registered trademarks of Microsoft Corporation in
the U.S. and/or other countries.
• Apple, AppleTalk, Macintosh, and Mac are trademarks of Apple Inc. in the U.S. and other
countries.
• PostScriptisatrademarkofAdobeSystemsIncorporated.
• NOVELL,NetWare,andNDSaretrademarksorregisteredtrademarksofNovell,Inc.
• FLOILisaregisteredtrademarkofKantoKaseiLtd.CORPORATION.
• MolykoteisaregisteredtrademarkofDowCorningCorporation.
• WebPageisatrademarkofOKIDATACorporation.
• Othercompanynames andproductnamesinthismanualarethetrademarksoftheir
respective companies.
©2013OKIDATACORPORATIONAllrightsreserved
Underthecopyrightlaws,thismanualcannotbereproducedinanyformwithoutpriorwritten
permissionofOKIDATACORPORATION.

45584901TH Rev.1 iv /
Oki Data CONFIDENTIAL
GENERAL PRECAUTIONS REGARDING THE SERVICE FOR THIS EQUIPMENT
The installation and service shall be done by a qualified service technician.
1. Transportation/Installation
- When transporting/installing the equipment, employ two or more persons and be sure
to hold the positions as shown in the figure.The equipment is quite heavy and weighs
approximately60 kg(132.27 lb.)(includingthenisher),thereforepayfullattention when
handling it.
- Besurenottoholdthemovablepartsorunits(e.g.thecontrolpanel,ADUorRADF)when
transportingtheequipment.
- BesuretouseadedicatedoutletwithAC110V/15A,120V/12A,220-240V/8Aforitspower
source.
- Theequipmentmustbegroundedforsafety.
- Selectasuitableplaceforinstallation.Avoidexcessiveheat,highhumidity,dust,vibration
and direct sunlight.
- Toinsureadequateworkingspaceforthecopyingoperation,keepaminimumclearanceof
20cm(8”)ontheleft,20cm(8”)ontherightand60cm(24”)ontherear.
- Theequipmentshallbeinstallednearthesocketoutletandshallbeaccessible.
- Be sure to fix and plug in the power cable securely after the installation so that no one trips
over it.
- If the unpacking place and where the equipment is to be installed differ, perform image
qualityadjustment(automaticgammaadjustment)accordingtothetemperatureand
humidity of the place of installation and the paper to be used.
- Iftheequipmenthascasters,lockthemaftertheinstallation.

45584901TH Rev.1 v /
Oki Data CONFIDENTIAL
2. General Precautions at Service
- Be sure to turn the power OFF and unplug the power cable during service (except for the
service should be done with the power turned ON).
- Unplug the power cable and clean the area around the prongs of the plug and socket outlet
once a year or more. A fire may occur when dust lies on this area.
- Whenthepartsaredisassembled, reassemblyisthereverseofdisassemblyunless
otherwise noted in this manual or other related documents. Be careful not to install small
partssuchasscrews,washers,pins,E-rings,starwashers,harnessesinthewrongplaces.
- Basically,theequipmentshouldnotbeoperatedwithanypartsremovedordisassembled.
- The PC board must be stored in an anti-electrostatic bag and handled carefully using a
antistatic wrist strap since the ICs on it may be damaged due to static electricity.
Caution: Beforeusingtheantistaticwriststrap,unplugthepowercableoftheequipment
and make sure that there are no charged objects which are not insulated in the
vicinity.
- Be sure not to touch high-temperature sections such as the fuser unit and areas around
them.
- Besurenottotouchhigh-voltagesectionssuchasthechargers,transferbelt,developer,
high-voltagetransformer,andpowersupplyunit.Especially,theboardofthesecomponents
shouldnotbetouchedsincetheelectricchargemayremaininthecapacitors,etc.onthem
even after the power is turned OFF.
- Makesurethattheequipmentwillnotoperatebeforetouchingpotentiallydangerousplaces
(e.g.rotating/operatingsectionssuchasgears,beltspulleys,andfans).
- Be careful when removing the covers since there might be the parts with very sharp edges
underneath.
- WhenservicingtheequipmentwiththepowerturnedON,besurenottotouchlivesections
and rotating/operating sections.
- Use designated jigs and tools.
- Userecommendedmeasuringinstrumentsorequivalents.
- Return the equipment to the original state and check the operation when the service is
finished.
- Be very careful to treat the touch panel gently and never hit it. Breaking the surface could
cause malfunctions.
3. Important Service Parts for Safety
- Thedoorswitch,fuse,thermostat,thermistor,batteries,IC-RAMsincludinglithium
batteries,etc.areparticularlyimportantforsafety.Besuretohandle/installthemproperly.
If these parts are short-circuited and their functions become ineffective, they may result
in fatal accidents such as a burnout. Avoid short-circuiting and do not use parts not
recommendedbyOKIDATACorporation.

45584901TH Rev.1 vi /
Oki Data CONFIDENTIAL
4.CautionaryLabels
- Duringservicing,besuretochecktheratingplateandcautionarylabelstoseeifthereis
anydirtontheirsurfaceandiftheyareproperlystucktotheequipment.
[1]
[1] Identification label
5.DisposaloftheEquipment,Supplies,PackingMaterials,UsedBatteriesandIC-RAMs
- Regardingtherecoveryanddisposaloftheequipment,supplies,packingmaterials,used
batteries and IC-RAMs including lithium batteries, follow the relevant local regulations or
rules.
- Never attempt to incinerate a used transfer belt unit. This could cause an explosion and
burn you since the toner inside would be scattered.
Caution:
Dispose of used batteries and IC-RAMs including lithium batteries according to this
manual.
Attention:
Se débarrasser de batteries et IC-RAMs usés y compris les batteries en lithium selon ce
manuel.
Vorsicht:
EntsorgungdergebrauchtenBatterienundIC-RAMs(inclusivederLithium-Batterie)nach
diesem Handbuch.

45584901TH Rev.1 vii /
Oki Data CONFIDENTIAL
ALLEGEMEINE SICHERHEITSMASSNAHMEN IN BEZUG AUF DIE WARTUNG
Die Installation und die Wartung sind von einem qualifizierten Service-
Techniker durchzuführen.
1. Transport/Installation
- Das Tragen oder Installieren des Gerätes braucht wenigstens zwei Menschen. Die
angezeigten Stellen sind wie in der Abbildung festzuhalten. Das Gerät ist ziemlich schwer
undwiegtungefähr60kg(mitdemFinisher);deshalbwennSieeshochhebenodertragen,
passen Sie besonders auf.
- Beim Transportieren des Geräts nicht an den beweglichen Teilen oder Einheiten (z.B. das
Bedienungsfeld,dieDuplexeinheitoderdieautomatischeDokumentenzuführung)halten.
- EinespezielleSteckdosemitStromversorgungvonAC110V/15A,120V/12A,220-240V/8A
alsStromquelleverwenden.
- DasGerätistausSicherheitsgründenzuerden.
- Einen geeigneten Standort für die Installation wählen. Standorte mit zuviel Hitze, hoher
Luftfeuchtigkeit,Staub,VibrierenunddirekterSonneneinstrahlungsindzuvermeiden.
- UmeinenoptimalenKopierbetriebzugewährleisten,musseinAbstandvonmindestens20
cmlinks,20cmrechtsund60cmdahintereingehaltenwerden.
- Das Gerät ist in der Nähe der Steckdose zu installieren; diese muss leicht zu erreichen
sein.
- Nach der Installation muss das Netzkabel richtig hineingesteckt und befestigt werden,
damitniemanddarüberstolpernkann.
- Falls der Auspackungsstandort und der Installationsstandort des Geräts verschieden
sind,die Bildqualitätsjustierung (automatische Gammajustierung)je nach derTemperatur
und Luftfeuchtigkeit des Installationsstandorts und der Papiersorte, die verwendet wird,
durchführen.
- WenndasGerätRollenhat,sindsienachderInstallationzuverriegeln.

45584901TH Rev.1 viii /
Oki Data CONFIDENTIAL
2.AllgemeineSicherheitsmassnahmeninbezugaufdieWartung
- Während derWartung das Gerät ausschalten und das Netzkabel herausziehen (ausser
Wartung,diebeieinemeingeschaltetenGerät,durchgeführtwerdenmuss).
- Das Netzkabel herausziehen und den Bereich um die Steckerpole und die Steckdose die
Umgebung in der Nähe von den Steckerzacken und der Steckdose wenigstens einmal
im Jahr reinigen. Wenn Staub sich in dieser Gegend ansammelt, kann dies ein Feuer
verursachen.
- Wenn dieTeile auseinandergenommen werden, wenn nicht anders in diesem Handbuch
uswerklärt,istdasZusammenbaueninumgekehrterReihenfolgedurchzuführen.
Aufpassen,dasskleineTeilewie Schrauben,Dichtungsringe,Bolzen,E-Ringe,Stern-
Dichtungsringe,KabelbäumenichtandenverkehrtenStelleneingebautwerden.
- Grundsätzlich darf das Gerät mit enfernten oder auseinandergenommenen Teilen nicht in
Betrieb genommen werden.
- Das PC-Board muss in einer Anti-elektrostatischen Hülle gelagert werden. Nur Mit einer
Manschette bei Betätigung eines Armbandes anfassen, sonst könnte es sein, dass die
integrierten Schaltkreise durch statische Elektrizität beschädigt werden.
Vorsicht:VorBenutzungderManschettederBetätigungdesArmbandes,dasNetzkabel
des Gerätes herausziehen und prüfen, dass es in der Nähe keine geladenen
Gegenstände,dienichtisoliertsind,gibt.
- Auf keinenFallHochtemperaturbereiche,wiedieFixiereinheitunddieumliegenden
Bereiche,berühren.
- AufkeinenFallHochspannungsbereiche,wiedieLadeeinheiten,dasTransferband,
die Entwicklereinheit, den Hochspannungstransformator und das Netzgerät, berühren.
InsbesonderesolltendiePlatinendieserKomponentennichtberührtwerden,dadie
Kondensatorenusw.auchnachdemAusschaltendesGerätsnochelektrischgeladensein
können.
- Vordem Berühren potenziellgefährlicherBereiche(z.B.drehbareoderbetriebsrelevante
Bereiche, wie Zahnräder, Riemen, Riemenscheiben und Lüfter) sicherstellen, dass das
Gerät sich nicht bedienen lässt.
- Beim Entfernen von Abdeckungen vorsichtig vorgehen, da sich darunter scharfkantige
Komponentenbendenkönnen.
- BeiWartungsarbeitenameingeschalteten GerätdürfenkeineunterStrom stehenden,
drehbarenoderbetriebsrelevantenBereicheberührtwerden.
- AusschließlichvorgeseheneWerkzeugeundHilfsmittelverwenden.
- Empfohlene oder gleichwertige Messgeräte verwenden.
- Nach Abschluss derWartungsarbeiten das Gerät in den ursprünglichen Zustand zurück
versetzenunddeneinwandfreienBetriebüberprüfen.
- DasberührungsempfindlicheBedienungsfeldstetsvorsichtighandhabenundkeinen
Stößenaussetzen.WenndieOberächebeschädigtwird,kanndieszuFunktionsstörungen
führen.
3.SicherheitsrelevanteWartungsteile
- DerTürschalter,dieSicherung,derThermostat,derThermistor,dieIC-RAMseinschließlich
der Lithiumakkus usw. sind besonders sicherheitsrelevant. Sie müssen unbedingt korrekt
gehandhabtundinstalliertwerden.WenndieseTeilekurzgeschlossenundfunktionsunfähig
werden,kanndieszuschwerwiegendenSchäden,wieeinemAbbrand,führen.
Kurzschlüssesindzuvermeiden,und essind ausschließlichTeile zuverwenden,dievon
derOKIDATACorporationempfohlensind.

45584901TH Rev.1 ix /
Oki Data CONFIDENTIAL
4.Warnetiketten
- ImRahmenderWartungunbedingtdasLeistungsschildunddieEtikettenmit
Warnhinweisen überprüfen [z. B. „Unplug the power cable during service“ („Netzkabel
vor Beginn derWartungsarbeiten abziehen“), „CAUTION. HOT“ („VORSICHT, HEISS“),
„CAUTION.HIGHVOLTAGE“(„VORSICHT, HOCHSPANNUNG“),„CAUTION. LASER
BEAM“(„VORSICHT,LASER“)usw.],umsicherzustellen,dasssienichtverschmutztsind
und korrekt am Gerät angebracht sind.
5.EntsorgungdesGeräts,derVerbrauchs-undVerpackungsmaterialien,alterAkkusundIC-
RAMs
- In Bezug auf die Entsorgung undWiederverwertung des Geräts, derVerbrauchs- und
Verpackungsmaterialien, alter Akkus und IC-RAMs, einschließlich Lithiumakkus, sind die
einschlägigennationalenoderregionalenVorschriftenzubefolgen.
- Eine benutzteTransportriemeneinheit darf niemals verbrannt werden. Dies könnte eine
Explosionverursachenundsiebrennen,daderTonerinnerhalbderEinheitverstreutwird.
Caution:
Dispose of used batteries and IC-RAMs including lithium batteries according to this
manual.
Attention:
Se débarrasser de batteries et IC-RAMs usés y compris les batteries en lithium selon ce
manuel.
Vorsicht:
EntsorgungdergebrauchtenBatterienundIC-RAMs(inclusivederLithium-Batterie)nach
diesem Handbuch.

45584901TH Rev.1 x /
Oki Data CONFIDENTIAL
CONTENTS
1. SPECIFICATIONS/SYSTEM LIST.................................................................. 1-1
1.1 Specifications........................................................................................ 1-1
1.1.1 General ........................................................................................................... 1-1
1.1.2 HDD Memory Map.......................................................................................... 1-2
1.2 SystemList ........................................................................................... 1-3
2. DISASSEMBLY AND REPLACEMENT ......................................................... 2-1
2.1 Removal and Installation of Options ..................................................... 2-1
2.1.1 Inner Finisher (MJ-1038) ................................................................................ 2-1
2.1.2 Fax Unit (GD-1340)......................................................................................... 2-3
2.1.3 Option-Tray ..................................................................................................... 2-3
2.1.4 Caster Stand................................................................................................... 2-4
2.1.5 Spacer ............................................................................................................ 2-5
2.1.6 OfineStapler ................................................................................................. 2-6
3. SELF-DIAGNOSTIC MODE ........................................................................... 3-1
3.1 Overview............................................................................................... 3-1
3.2 Service UI ............................................................................................. 3-5
3.2.1 Overview......................................................................................................... 3-5
3.2.2 Loginprocedure.............................................................................................. 3-5
3.2.3 [SERVICEMODE]Screen .............................................................................. 3-6
3.2.4 Setting/Changing password............................................................................ 3-6
3.3 Input check (Test mode 03)................................................................... 3-7
3.4 Output check (test mode 03)................................................................. 3-8
3.5 Test print mode (test mode 04) ............................................................. 3-9
3.6 Operation Procedure in Adjustment Mode (05) .................................. 3-10
3.7 Test print pattern in Adjustment Mode (05)......................................... 3-12
3.8 Operation Procedure in Setting Mode (08) ......................................... 3-16
3.9 Assist Mode (3C) ................................................................................ 3-18
3.9.1 General description....................................................................................... 3-18
3.9.2 Operating Procedure..................................................................................... 3-18
3.9.3 Functions ...................................................................................................... 3-18
3.10 HDD Assist Mode (4C) ....................................................................... 3-21
3.10.1 General description....................................................................................... 3-21
3.10.2 Operation procedure..................................................................................... 3-21
3.10.3 Functions ...................................................................................................... 3-23
3.11 File System Recovery Mode (5C)....................................................... 3-25
3.11.1 Overview....................................................................................................... 3-25
3.11.2 Operation procedure..................................................................................... 3-25
3.11.3 Functions ...................................................................................................... 3-26
3.12 SRAM Clear Mode (6C)...................................................................... 3-30
3.12.1 General description....................................................................................... 3-30
3.12.2 Operation procedure..................................................................................... 3-30
3.12.3 Functions ...................................................................................................... 3-31

45584901TH Rev.1 xi /
Oki Data CONFIDENTIAL
3.13 Listprintmode(9S) ............................................................................ 3-32
3.13.1 Operation procedure..................................................................................... 3-32
3.13.2 ListPrinting ................................................................................................... 3-33
4. SETTING / ADJUSTMENT............................................................................. 4-1
4.1 Image Related Adjustment ................................................................... 4-1
4.1.1 Adjustment Order............................................................................................ 4-1
4.1.2 Performing density correction ......................................................................... 4-2
4.1.3 Image Dimensional Adjustment ...................................................................... 4-3
4.1.4 Image dimensional adjustment in the copy/printer/fax function ...................... 4-4
4.2 Image Quality Adjustment (Copying Function) ..................................... 4-5
4.2.1 Automatic gamma adjustment ........................................................................ 4-5
4.3 Image Quality Adjustment (Printing Function) ...................................... 4-7
4.3.1 Automatic gamma adjustment ........................................................................ 4-7
4.3.2 Gamma balance adjustment (Black Mode)..................................................... 4-9
4.3.3 Color balance adjustment ............................................................................. 4-11
4.3.4 Adjustment of faint text ................................................................................. 4-13
4.3.5 Upper limit value in the Toner Saving Mode.................................................. 4-13
4.3.6 Maximum toner density adjustment (Special Paper 3) ................................. 4-14
4.3.7 Fine line enhancement switchover................................................................ 4-14
4.3.8 “PureBlack/PureGray”thresholdadjustment(PCL) ...................................... 4-14
4.3.9 “PureBlack/PureGray”thresholdadjustment(Twincolormode) ................... 4-15
4.3.10 “PureBlack/PureGray”thresholdadjustment(PS) ........................................ 4-15
4.3.11 “PureBlack/PureGray”thresholdadjustment(XPS) ...................................... 4-15
4.3.12 Toner limit threshold adjustment ................................................................... 4-16
4.3.13 Sharpness adjustment.................................................................................. 4-17
4.3.14 Thin line width lower limit adjustment ........................................................... 4-18
4.3.15 Offsetting adjustment for background processing......................................... 4-18
4.3.16 Color/black judgment setting for twin color printing images.......................... 4-18
4.3.17 LEDemissionleveladjustment..................................................................... 4-19
4.3.18 Density adjustment of graphic lines (1200 dpi)............................................. 4-20
4.3.19 Auto Trapping width/density adjustment (PS) ............................................... 4-21
4.4 Image Quality Adjustment (Scanning Function) ................................. 4-22
4.4.1 Gamma balance adjustment......................................................................... 4-22
4.4.2 Density adjustment ....................................................................................... 4-23
4.4.3 Background adjustment (Color Mode) .......................................................... 4-24
4.4.4 Background adjustment (Black/Grayscale)................................................... 4-25
4.4.5 Judgment threshold for ACS (common for copy and network scan)............. 4-25
4.4.6 Sharpness adjustment.................................................................................. 4-26
4.4.7 Fine adjustment of black density................................................................... 4-26
4.4.8 RGB conversion method selection................................................................ 4-27
4.4.9 Adjustment of saturation ............................................................................... 4-27
4.4.10 Background offsetting adjustment for RADF
(commonforcopy,scanandfax) .................................................................. 4-28
4.4.11 AdjustmentofthecapacityandimagequalityofSlimPDF ........................... 4-28
4.4.12 Surrounding void amount adjustment ........................................................... 4-29
4.4.13 Judgment threshold adjustment for blank originals
(common for copy and scan) ........................................................................ 4-29

45584901TH Rev.1 xii /
Oki Data CONFIDENTIAL
4.4.14 JPEG compression level adjustment ............................................................ 4-30
4.4.15 Color conversion table selection ................................................................... 4-30
5. ERROR CODE AND TROUBLESHOOTING .................................................. 5-1
5.1 General Descriptions ............................................................................ 5-1
5.1.1 If a problem continues even after performing all troubleshooting.................... 5-1
5.1.2 Collection of debug logs with a USB device ................................................... 5-2
5.2 ErrorCodeList...................................................................................... 5-4
5.2.1 Jam ................................................................................................................. 5-4
5.2.2 Service call ..................................................................................................... 5-5
5.2.3 ErrorinInternetFAX/ScanningFunction ...................................................... 5-8
5.2.4 Printer function error ..................................................................................... 5-17
5.2.5 WebPagerelatederror/Communicationerrorwithexternalapplication....... 5-19
5.2.6 MFP access error ......................................................................................... 5-20
5.2.7 Maintenance error......................................................................................... 5-21
5.2.8 Network error ................................................................................................ 5-22
5.2.9 Error history .................................................................................................. 5-25
5.3 Diagnosis and Prescription for Each Error Code ................................ 5-27
5.3.1 Check item.................................................................................................... 5-27
5.3.2 Paper jam in finisher section......................................................................... 5-28
5.3.3 Finisher related service call .......................................................................... 5-32
5.3.4 Communication related service call .............................................................. 5-40
5.3.5 Circuit related service call............................................................................. 5-43
5.3.6 Other service call.......................................................................................... 5-45
5.3.7 ErrorinInternetFAX/ScanningFunction .................................................... 5-63
5.3.8 Printer function error ..................................................................................... 5-75
5.3.9 WebPagerelatederror/Communicationerrorwithexternalapplication....... 5-77
5.3.10 MFP access error ......................................................................................... 5-81
5.3.11 Maintenance error......................................................................................... 5-83
5.3.12 Network error ................................................................................................ 5-88
5.4 Other errors ........................................................................................ 5-98
5.4.1 Equipmentoperationdisabledaftertheinstallationofoption(s) ................... 5-98
5.4.2 WirelessLANconnectiondisabled ............................................................... 5-98
5.4.3 “InvalidDepartmentCode”isdisplayed ........................................................ 5-98
5.4.4 Ethernet disabled in half-duplex communication .......................................... 5-98
6. REPLACEMENT OF PC BOARDS/HDD........................................................ 6-1
6.1 Removal and Installation of PC Boards/HDD ....................................... 6-1
6.1.1 Right side cover .............................................................................................. 6-1
6.1.2 CU board cover............................................................................................... 6-3
6.1.3 CU board ........................................................................................................ 6-3
6.1.4 Hard disk (HDD) ............................................................................................. 6-5
6.1.5 SRAM board <for CU board>.......................................................................... 6-6
6.1.6 FAXunit .......................................................................................................... 6-7
6.2 Precautions,ProceduresandSettingsforReplacingPCBoardsand
HDD ...................................................................................................... 6-8
6.2.1 Precautions when replacing PC boards.......................................................... 6-8
6.2.2 HDD fault diagnosis ........................................................................................ 6-9

45584901TH Rev.1 xiii /
Oki Data CONFIDENTIAL
6.2.3 Precautions and procedures when replacing the HDD................................. 6-11
6.2.4 Precautions and Procedures when replacing the CU board......................... 6-16
6.2.5 Precautions and procedure when replacing the SRAM board
(for the CU board)......................................................................................... 6-20
6.2.6 Precautions and Procedures when replacing the PU board ......................... 6-26
6.2.7 Precautions and Procedures when replacing the SU board ......................... 6-26
6.2.8 Firmware confirmation after the PC board/HDD replacement ...................... 6-26
6.2.9 Licensere-registrationusingtheone-timedongle........................................ 6-27
6.3 Precautions for Installation of GP-1070 and Disposal of HDD/ Board 6-29
6.3.1 Precautions for Installation of GP-1070 ........................................................ 6-29
6.3.2 Precautions when disposing of HDD ............................................................ 6-29
6.3.3 Precautions when disposing of the CU board............................................... 6-29
6.3.4 Precautions when disposing of the SRAM board (for CU board).................. 6-29
7. REMOTE SERVICE ........................................................................................ 7-1
7.1 Auto Supply Order ................................................................................ 7-1
7.1.1 Outline ............................................................................................................ 7-1
7.1.2 Setting Item..................................................................................................... 7-1
7.1.3 Setting procedure ........................................................................................... 7-4
7.1.4 Order Sheet Format...................................................................................... 7-14
7.2 Service Notification............................................................................. 7-18
7.2.1 Outline .......................................................................................................... 7-18
7.2.2 Setting........................................................................................................... 7-18
7.2.3 Items to be notified ....................................................................................... 7-24
8. FIRMWARE UPDATING ................................................................................. 8-1
8.1 Overview............................................................................................... 8-1
8.2 Firmware Updating with USB Device.................................................... 8-3
8.2.1 Firmware type and data file name for updating............................................... 8-3
8.2.2 Update procedure ........................................................................................... 8-5
8.3 Patch Updating with USB Device........................................................ 8-13
8.3.1 Firmware type and data file name for patch updating................................... 8-13
8.3.2 Update procedure ......................................................................................... 8-15
8.4 FirmwareUpdatingwithPWA-DWNLD-JIG2 ...................................... 8-20
8.4.1 Writingthedatatothedownloadjig(PWA-DWNLD-JIG2) ........................... 8-21
8.4.2 System firmware........................................................................................... 8-23
8.5 FirmwareUpdatingwithK-PWA-DLM-320 ......................................... 8-25
8.5.1 FAXunitrmware(GD-1340)........................................................................ 8-26
8.6 Confirmation of the updated data ....................................................... 8-28
8.7 WhenFirmwareUpdatingFails........................................................... 8-29
8.7.1 Procedure ........................................................................................... 8-29
8.7.2 Flow chart for correcting USB update failure ................................................ 8-30
9. BACKUP FUNCTION ..................................................................................... 9-1
9.1 Data Cloning ......................................................................................... 9-1
9.1.1 General description......................................................................................... 9-1
9.1.2 Precautions..................................................................................................... 9-1

45584901TH Rev.1 xiv /
Oki Data CONFIDENTIAL
9.1.3 Backup files..................................................................................................... 9-2
9.1.4 Cloning procedure .......................................................................................... 9-2
9.2 AES Data Encryption Function Setting ................................................. 9-5
9.2.1 General description........................................................................................ 9-5
9.2.2 Precautions .................................................................................................... 9-5
9.2.3 Setting procedure ........................................................................................... 9-6
9.2.4 Procedure for disabling data encryption function.......................................... 9-10
9.2.5 Procedure for discarding HDD when data encryption function is enabled.... 9-10
9.3 High Security Mode ............................................................................ 9-11
9.3.1 General description....................................................................................... 9-11
9.3.2 Prior confirmation.......................................................................................... 9-11
9.3.3 Procedure for entering the High Security Mode............................................ 9-11
9.3.4 Precautions................................................................................................... 9-12
10. EXTERNAL COUNTERS ............................................................................. 10-1
10.1 Outline ................................................................................................ 10-1
10.2 Signal.................................................................................................. 10-1
10.2.1 PinLayout ..................................................................................................... 10-1
10.2.2 Details of the signals..................................................................................... 10-3
10.3 Notices................................................................................................ 10-5
10.3.1 Setting code.................................................................................................. 10-5
10.3.2 Setting value change and restrictions when using the coin controller .......... 10-5
11. SELF-DIAGNOSIS CODE (03/04/05/08 CODE) .......................................... 11-1
Test mode (03)/Test Print mode (04)............................................................. 11-1
Adjustment Mode (05) Codes ....................................................................... 11-4
Setting Mode (08) Codes ............................................................................ 11-76

45584901TH Rev.1 1-1 /
Oki Data CONFIDENTIAL
1. SPECIFICATIONS/SYSTEM LIST
1.1 Specifications
1.1.1 General
Memory
(RAM)
Main memory 2 GB (including page memory)
Page Memory Included in main memory
HDD 160 GB
Account Codes 10000 codes
Department Codes 1000 codes
Machine version ODA:US,Canada,LA
OEL:Europe
AOS:Asia,Australia
JP: Japan

45584901TH Rev.1 1-2 /
Oki Data CONFIDENTIAL
1.1.2 HDD Memory Map
Category Item Unit HDD
HDD HDD GB 160
Copy Memory copy GB 30
Box e-Filing GB 80 (Shared with e-filing/Strage file)
Public box Box 1
User box Box 200
Folders per box Folder 100
Documents per box Document 400
Pages per document Page 200
Number of maximum jobs Job 899
Scan Scan to File GB 80
Pages per job Page 1000
Number of maximum jobs Job 899(ExceptPrint/FAX/interrupt)
FAX FAXTransmission GB 1 (Shared with Rx and Tx)
FAXReception GB 1 (Shared with Rx and Tx)
Print Printer Data Spool GB 25
Pages per job Job Storage full
Number of maximum jobs Job 1000
Job area GB 80 (Shared with e-filing/Strage file)
Pages per job Job Storage full
Number of maximum jobs Job 1000

45584901TH Rev.1 1-3 /
Oki Data CONFIDENTIAL
1.2 System List
Inner Finisher
45372301
(MJ-1038)
Spacer
45479101/OEL, AOS
45479102/ODA
Option-Tray
45466501/ODA
45466502/OEL, AOS
(N31440A)
Large Capacity
Feeder (LCF)
45393301/ODA
45393302/OEL, AOS
(N31450A)
Caster Stand
45466601/ODA
45466602/OEL, AOS
FAX Unit
45036921/NA
45036922/EU
45036923/AU
45036925/BR
(
GD-1340NA/EU/AU/BR
)
Antenna
45518001
(GN-3010)
IC Card Reader(F)
45535901
(KP-2006)
Wireless
LAN module
45517901
(GN-1060)
IP Sec Enabler
45518401
(GP-1080)
Meta Scan Enabler
45518201
(GS-1010)
External Interface
Enabler
45518301
(GS-1020)
Unicode Font
Enabler
45534801
(GS-1007)
Data overwrite
Enabler
45518101
(GP-1070)
IC Card Reader(H)
45518501
(KP-2004)
IC Card Reader(M)
45518601
(KP-2005)
Staple Cartridge
42937601/ODA
42937603/OEL
42937604/AOS
Staple Cartridge
45513301
Offline Stapler
45477401/ODA
45477402/OEL
45477403/AOS
Fig. 1-1
Notes:
• Theantenna(GN-3010)isnecessarytoenablethewirelessLANmodule.

45584901TH Rev.1 2-1 /
Oki Data CONFIDENTIAL
2. DISASSEMBLY AND REPLACEMENT
2.1 Removal and Installation of Options
Important:
• Before installing or removing options, turn the main power switch off and disconnect the
power cable from the outlet.
2.1.1 Inner Finisher (MJ-1038)
(1) Press the [Power] button on the control panel to shut it down.
(2) Turnthemainpowerswitchoftheequipmentoff.
(3) Disconnect the power cable.
(4) Open the scanner.
Fig. 2-1
(5) Remove 2 screws and take off the stacker tray.
Fig. 2-2

45584901TH Rev.1 2-2 /
Oki Data CONFIDENTIAL
(6) Take off the connector cover.
Fig. 2-3
(7) Disconnect the connector.
Fig. 2-4
(8) Remove 2 screws and take off the finisher.
Fig. 2-5
Other manuals for MC770 series
2
This manual suits for next models
4
Table of contents
Other Oki All In One Printer manuals
