Oliver 4016 User manual

4016 10” Professional Tablesaw
Owner’s Manual
Oliver Machinery M-4016 04/2008
Seattle, WA  Copyright 2003
info@oliverma hinery.net www.oliverma hinery.net

Warranty
Oliver makes every effort possible to assure that its equipment meets the highest possible standards of
quality and durability. All produ ts sold by Oliver are warranted to the original ustomer to be free from
defe ts for a period of 2 (two) years on all parts, ex luding ele troni s and motors, whi h are warranted
for 1 year. Oliver’s obligation under this warranty shall be ex lusively limited to repairing or repla ing (at
Oliver’s option) produ ts whi h are determined by Oliver to be defe tive upon delivery F.O.B. (return
freight paid by ustomer) to Oliver, and on inspe tion by Oliver. This warranty does not apply to defe ts
due, dire tly or indire tly, to misuse, abuse, negligen e, a idents, unauthorized repairs, alterations, la k
of maintenan e, a ts of nature, or items that would normally be onsumed or require repla ement due to
normal wear. In no event shall Oliver be liable for death, personal or property injury, or damages arising
from the use of its produ ts.
Warnin
Read this manual thoroughly before operating the ma hine. Oliver Ma hinery dis laims any liability for
ma hines that have been altered or abused. Oliver Ma hinery reserves the right to effe t at any time,
without prior noti e, those alterations to parts, fittings, and a essory equipment whi h they may deem
ne essary for any reason whatsoever.
For More Information
Oliver Ma hinery is always adding new Industrial Woodworking produ ts to the line. For omplete, up-to-
date produ t information, he k with your lo al Oliver Ma hinery distributor, or visit
www.oliverma hinery.net
2

WARNING
Read this manual ompletely and observe all warning labels on the ma hine. Oliver Ma hinery has made
every attempt to provide a safe, reliable, easy-to-use pie e of ma hinery. Safety, however, is ultimately
the responsibility of the individual ma hine operator. As with any pie e of ma hinery, the operator must
exer ise aution, patien e, and ommon sense to safely run the ma hine. Before operating this produ t,
be ome familiar with the safety rules in the following se tions.
•Always keep uards in place and in proper operatin condition.
•Use blade uard for every applicable operation includin all throu h cuts. If uard is removed
for special non-throu h cuts such as dado and rabbet cuts, replace before further use of the
saw.
•Keep hands out of line with the saw blade.
•Use a push stick.
•Do not perform any operation freehand.
•Never reach around or over the saw blade.
1. If you are not properly trained in the use of a tablesaw do not use until the proper training has been
obtained.
2. Read, understand and follow the safety instru tions found in this manual. Know the limitations and
hazards asso iated with this ma hine.
3. Electrical roundin : Make ertain that the ma hine frame is ele tri ally grounded and that a
ground lead is in luded in the in oming ele tri al servi e. In ases where a ord and plug are used,
make ertain that the grounding plug onne ts to a suitable ground. Follow the grounding pro edure
indi ated in the National Ele tri al Code.
4. Eye safety: Wear an approved safety shield, goggles, or glasses to prote t eyes. Common
eyeglasses are only impa t-resistant, they are not safety glasses.
5. Personal protection: Before operating the ma hine, remove tie, rings, wat h and other jewelry and
roll up sleeves above the elbows. Remove all loose outer lothing and onfine long hair. Prote tive
type footwear should be used. Where the noise ex eeds the level of exposure allowed in Se tion
1910.95 of the OSHA Regulations, use hearing prote tive devi es. Do not wear gloves.
6. Guards: Keep the ma hine guards in pla e for every operation for whi h they an be used. If any
guards are removed for maintenan e, DO NOT OPERATE the ma hine until the guards are
reinstalled.
7. Work area: Keep the floor around the ma hine lean and free of s rap material, saw dust, oil and
other liquids to minimize the danger of tripping or slipping. Be sure the table is free of all s rap,
foreign material and tools before starting to use the ma hine. Make ertain the work area is well
lighted and that a proper exhaust system is used to minimize dust. Use anti-skid floor strips on the
floor area where the operator normally stands and mark off ma hine work area. Provide adequate
work spa e around the ma hine.
8. Material condition: Do not attempt to saw boards with loose knots or with nails or other foreign
material. Do not attempt to saw twisted, warped, bowed sto k.
9. Operator position: Maintain a balan ed stan e and keep your body under ontrol at all times.
10. Before startin : Before turning on ma hine, remove all extra equipment su h as keys, wren hes,
s raps, and leaning rags away from the ma hine.
3

11. Careless acts: Give the work you are doing your undivided attention. Looking around, arrying on a
onversation, and “horseplay” are areless a ts that an result in serious injury.
12. Disconnect all power sources: Before performing any servi e, maintenan e, adjustments or when
hanging blades. A ma hine under repair should be RED TAGGED to show it should not be used
until the maintenan e is omplete.
13. Job completion: If the operator leaves the ma hine area for any reason, the tablesaw should be
turned "off" and the blade should ome to a omplete stop before their departure. The key should be
pla ed in the “off” position, removed and given to a supervisor to prevent any unauthorized use of the
tablesaw.
14. Replacement parts: Use only genuine Oliver Ma hinery fa tory authorized repla ement parts and
a essories; otherwise the warranty and guarantee is null and void.
15. Misuse: Do not use this Oliver tablesaw for other than its intended use. If used for other purposes,
Oliver dis laims any real or implied warranty and holds itself harmless for any injury or damage whi h
may result from that use.
16. Dru s, alcohol and medication: Do not operate this ma hine while under the influen e of drugs,
al ohol, or any medi ation.
17. This machine is dei ned for utting wood produ ts only. Do not use to ut any kind of metal or
substan e other then wood.
18. Never start the saw while a work pie e is in onta t with the blade.
19. Raise or lower the blade only when the ma hine has been turned “off” and the blade has ome to a
omplete stop.
20. Miter Gau e and Rip Fence: Never use the miter gauge and rip fence at the same time.
21. Dama ed Saw Blade: Never use a damaged saw blade or one that has been dropped. Che k the
saw blade for ra ks or missing teeth. Do not use a ra ked or dull blade or one with missing teeth.
Make sure the blade is se urely lo ked on the arbor.
22. Make sure the blade is running in the proper dire tion. Refer to the arrow on the blade. The teeth
should be pointing down when viewing from the front of the saw.
23. Ali nment: Che k the alignment of the splitter to the blade. Also, he k the alignment of the fen e
to the miter slot.
24. Health hazards: Some dust reated by power sanding, sawing, grinding, drilling and other
onstru tion a tivities ontains hemi als known to ause an er, birth defe ts or other reprodu tive
harm. Some examples of these hemi als are:
•Lead from lead-based paint.
•Crystalline sili a from bri ks and ement and other masonry produ ts.
•Arseni and hromium from hemi ally-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To redu e
your exposure to these hemi als, work in a well-ventilated area, and work with approved safety
equipment, su h as those dust masks that are spe ifi ally designed to filter out mi ros opi parti les.
Familiarize yourself with the following safety noti es used in this manual:
CAUTION: (This means that if pre autions are not heeded, it may result in minor or moderate injury
and/or possible ma hine damage)
WARNING: (This means that if pre autions are not heeded, it ould result in serious injury or possibly
even death).
4

Table of Contents Pa e Number
Warranty......................................................................................................................................................2
Warnings..................................................................................................................................................3-4
Table of Contents........................................................................................................................................5
Spe ifi ations...............................................................................................................................................5
Contents of the Shipping Containers...........................................................................................................6
Ma hine Preparation and Setup..................................................................................................................7
Extension Wing Assembly...........................................................................................................................7
Handwheel Assembly..................................................................................................................................7
Rail Assembly..............................................................................................................................................8
Fen e Assembly and Adjustment................................................................................................................9
Adjusting the S ale Reader.........................................................................................................................9
Calibrating the Digital Angle Readout........................................................................................................10
Leveling Table Insert..................................................................................................................................11
Splitter and Blade Guard Assembly...........................................................................................................11
Miter Gauge...............................................................................................................................................12
Controls.....................................................................................................................................................12
Dust Colle tion...........................................................................................................................................12
Ele tri al Conne tions...............................................................................................................................13
Repla ing the Blade...................................................................................................................................13
Maintenan e..............................................................................................................................................14
Troubleshooting....................................................................................................................................15-16
Specifications
Model Number.......................................................................................................................................4016
Blade Diameter (In)....................................................................................................................................10
Arbor Diameter (In)................................................................................................................................5/8"
Maximum Depth of Cut at 90 Degrees (In).................................................................................................3"
Maximum Depth of Cut at 45 Degrees (In)...........................................................................................2-1/4"
Maximum Cut to the Right of Blade..........................................................................................................36”
Maximum Cut to the Left of Blade.............................................................................................................12”
Dust Port Diameter (In)................................................................................................................................4
Table Dimensions w/Extensions (LxW).....................................................................................27” x 45-1/4"
Table Height (In).......................................................................................................................................36”
Blade Tilt..................................................................................................................................................Left
Arbor Speed RPM.................................................................................................................................3,450
Gross Weight (with 36” rails and fen e)...................................................................................................639
5

Oliver 4016, 10”Tablesaw
Contents of the Shippin Containers
Saw
On e the top is removed the saw will be as
shown with the left extension wing already
atta hed. Inspe t for freight damage and
all the freight arrier if any.
Contents
Blade guard
3. Arbor wren hes
4. Wheel handle
5. A essory holders
6. Tools
7. Hardware pa ket, 5/8 & 1” arbor
8. Extension wing hardware
9. Miter gage
10. Extension wing
Fence and Rail Assembly
Fen e
Lo k handle
Front guide
Front guide support bra ket
Rear guide
Saw
Contents
Fen e and Rail Assembly
6

Machine Preparation and Setup
WARNING!
The equipment used to lift this machine must
have a rated capacity at, or above the wei ht
of the tablesaw. Failure to comply may
cause serious injury!
The tablesaw must be positioned on a smooth,
level surfa e. The area must be well lit and
have plenty of room to maneuver with large
pie es of wood.
Level the saw front to ba k and side to side
using a level pla ed on the table. Use shims
under the orners, if ne essary, but make sure
the saw is stable before being pla ed into
servi e.
Clean all rust prote ted surfa es with a
ommer ial solvent. Do not use a etone,
gasoline, la quer thinner or any type of
flammable solvent, or a leaner that may
damage paint. Cover leaned surfa es with
WD-40 or a 20W ma hine oil.
Pay parti ular attention to leaning in the miter
slot and the fa es of table and extension wing.
Extension Win Assembly
1. Atta h extension wing (A, Figure 1) to table
with four hex head bolts, and four lo k
washers (B, Figure 1). Snug but do not
tighten. Note: Start with one of the enter
holes (C, Figure 1) to hold the wing in pla e.
2. Slide extension wing toward the front edge
of the saw table until two edges are flush.
3. Using a straight edge (D, Figure. 2), align
extension wing to saw table and tighten hex
ap bolts. Repeat for opposite wing.
Handwheel Assembly
1. Pla e handwheel (F, Figure 3) onto the saw
shaft. Use an allen key to lo k the wheel
onto the shaft with the set s rew (G, Figure
3). Insert and s rew the lo king handle (H,
Figure 3) and the wheel handle (I, Figure 3)
into their respe tive holes. Repeat for other.
Figure 1
Figure 2
Figure 3
7

Rail Assembly
1. Rest the front guide support bra ket on the
swit h box as shown in Figure 4 and se ure
into pla e using the hamfered bolts, nuts
and washers provided in hardware pa ket 7.
Note that the two outside holes require a nut
and washer as well as a bolt while the four
inside holes require the bolts only.
2. Set the front guide on the support bra ket as
shown in Figure 5 and se ure into pla e with
the short bolts provided in hardware pa ket
7.
3. Install the rear guide as shown in Figure 6
using the supplied hardware. Note that the
two outside holes require a nut and washer
as well as a bolt while the four inside holes
require the bolts and washers only.
Figure 4
Figure 5
Figure 6
8

Fence Assembly and Adjustment
1. Pla e the fen e on the guides as shown in
Figure 7. Look for the rubber nib on the
underside of the fen e as shown and make
sure it lines up with the ba k support rail.
2. Align the fen e with the miter guage slot as
shown in Figure 7 and he k to see if the
fen e is parallel to the slot.
3. If the fen e is not parallel to the miter guage
slot, lift the fen e off the guides and pla e it
on the table as shown in Figure 8. Turn the
appropriate s rew, A to ompensate for the
differen e. Pla e the fen e ba k on the
guides and he k again for alignment to the
miter guage. If it is still mis-aligned, repeat
the pro edure.
Adjustin the Scale Reader
1. Raise the blade to its maximum height.
2. Pla e the fen e
on the guides on the right side of blade and
then slide the fen e toward the blade.
Continue until the fen e just tou hes the
saw teeth. Do not push too hard or the
blade will defle t.
3. Looking at the
right side s ale reader, the red pointer
should mat h up with the zero mark. If not,
loosen the two s rews, B, Figure 9 and slide
the viewer to align the mark with zero.
Tighten the s rews.
4. Move the fen e
to the left side of the blade and repeat the
pro edure for the left side viewer.
Figure 7
Figure 8
Figure 9
9

Calibratin the Di ital An le Readout
1. Pla e a square on the table as shown in
Figure 11 then turn the saw tilt wheel until the
blade omes to 90 degree.
2. Push and hold the 0° set button as shown in
Figure 14 until the display stops blinking. The 0°
is now set.
3. Tilt the blade to 45 degrees as shown in
Figure 12. Push and hold the 45° set button
as shown in Figure 15 until the display stops
blinking. At this point the angle display is
alibrated.
Figure 12
Figure 14
Figure 15
10

Levelin Table Insert
Adjust the table insert flush with the table by
turning the four leveling s rews (C, Figure 16).
Pla e a straight edge a ross the table and
insert. Raise the insert until it just tou hes the
straight edge. Che k both the front and rear
se tion of the insert.
Splitter and Blade Guard Assembly
The table saw omes equipped with both a riving
knife and blade guard (see Figure 17). It is
always re ommended to use the blade guard
whenever possible. However, when doing
narrow uts when the guard would interfere with
the fen e or any other uts in whi h the blade
guard would pose a problem, repla e the guard
with the riving knife. Installation is the same for
both. For ease of installation, the blade guard
an be disassembled by loosening the lo k knob
and separating the splitter from the guard as
shown in Figure 18. It may be ne essary to
loosen the two s rews as indi ated in the
pi ture.
1. Disconnect saw from power source.
2. Remove table insert by loosening the s rew
at the front of insert.
3. Loosen the lo k nut then insert the fork of
the riving knife between the nut head and
ba king plate as shown in Figure 19. Lo k
into pla e.
4. Re-install the table insert.
Figure 16
Figure 17
Figure 18
Figure 19
11

Miter Gau e
1. Slide the miter gauge bar into the miter
gauge slot in table. Loosen the handle (A,
Figure 23) and pull out indexing rod (B,
Figure 23) to pivot the miter gauge body.
2. Push the indexing rod in to engage the
preset stops (C, Figure 23).
3. Adjust stops by loosening the hex nut (D,
Figure 23) and adjusting s rew (E, Figure
23).
Note: Always make test uts. The s ale is for
referen e. There are two holes in the miter
gauge fen e used to atta h a wooden fen e.
Controls (see Fi ures 24 & 25)
A. Emer ency Stop Button: Stops all
fun tions of ma hine.
B. Start: Starts saw blade rotation. Will not
work if the “Emergen y Stop” swit h is
engaged, or the key is in the “OFF” position.
C. Handwheel Lock: There is a handwheel
lo k on both handwheels. Loosen lo k to
turn handwheel and tighten when blade is in
desired lo ation.
D. Raisin and Lowerin Hand wheel:
Loosen hand wheel lo k. Turn handle
lo kwise to raise the blade. The blade
should be 1/8”-1/4” above the top of work
pie e, or 3-5 blade teeth above the top of
work pie e.
E. Tiltin Hand wheel: Loosen hand wheel
lo k. Turn handle ounter- lo kwise to tilt
blade to the left.
Dust Collection
There is a 4” dust port (G, Figure 25) lo ated on
the side of saw abinet. Make sure dust
olle tion system has suffi ient apa ity and
su tion for your tablesaw. Always turn on dust
olle tion system before starting the tablesaw.
Figure 23
Figure 24
Figure 25
12

Electrical Connections
WARNING!
Electrical connections and wirin must be
done by a qualified electrician. The machine
must be properly rounded. Failure to
comply may cause serious injury!
This saw is available in both 1-Phase and 3-
Phase versions.
Electrical Connections for a 3-Phase Unit
This saw is 3-Phase, 220V/440V pre-wired
220V. If you need to swit h the tablesaw from
220V to 440V have a qualified ele tri ian make
the hanges. Oliver Ma hinery re ommends
using a dedi ated ir uit.
Make sure the voltage of your power supply
mat hes the spe ifi ations on the motor plate of
the ma hine.
With 3-Phase power verify the blade is turning in
the proper dire tion. Turn the saw on and make
sure the dire tion of the blade spins toward the
user when standing in front of the saw. If it does
not, dis onne t the power sour e and reverse
any two power leads.
Electrical Connections for a 1-Phase Unit
This saw is 1-Phase, 220V only. Oliver
Ma hinery re ommends using a dedi ated
ir uit.
Make sure the voltage of your power supply
mat hes the spe ifi ations on the motor plate of
the ma hine.
Replacin the Blade
The blade guard has been removed for photos,
but it is possible to hange the blade without
removing the blade guard.
1. Disconnect saw from power source.
2. Remove the table insert and raise the blade
ompletely.
3. Use the two provided arbor wren hes to
loosen the arbor nut, as shown in Figure 25.
Pla e one wren h on the arbor nut and one
on the flats lo ated on the arbor. Remove
the nut, flange and blade.
4. Repla e the blade followed by the flange
and arbor nut. Tighten the arbor nut while
holding the arbor in pla e.
Note: Make sure the blade and arbor are lean
before installing a new blade. The blade teeth
should point down when viewing from the front
of saw.
Figure 25
13

Maintenance
WARNING!
Disconnect the machine from power source
before proceedin with any maintenance, or
troubleshootin ! Failure to comply may
cause serious injury!
Periodi ally lean the inside of the ma hine for
dust ontrol. Use an air hose to blow out dust
from motor fan and motor over.
Use a wire brush to lean trunnions and worm
gears. Apply white lithium grease or powdered
graphite to lubri ate worm gears, and trunnions.
Keep pulleys and belts free from dirt, dust, oil
and grease.
Repla e worn v-belts as needed.
Remove rust from the tabletop with WD-40 and
a S ot h-Brite™ Hand Pad. Keep a light oat of
WD-40 on the table top when not in use
Accessory Holders
See Figure 27 for the orre t pla ement of
the a essory holders.
Figure 27
14

.
Troubleshootin
Description of Symptoms Possible Cause Corrective Action
Ma hine will not start
1. Fuse blown or ir uit breaker
tripped
2. Cord Damaged
3. Faulty swit h
4. Not onne ted to power
sour e
5. Conne ted to wrong voltage
6. Key in the “OFF” position
7. Emergen y stop button
pressed
1. Repla e fuse or reset ir uit
breaker
2. Have ord repla ed
3. Repla e swit h
4. Che k onne tion
5. Che k voltage
6. Insert key and turn to “ON”
position
7. Rotate emergen y stop button
lo kwise until it pops out
Blade does not ome up to speed
1. Cable too light or too long
2. Low urrent
3. Motor not wired for orre t
voltage
1. Repla e with adequate size
able
2. Conta t lo al ele tri
ompany
3. Refer to motor nameplate for
orre t voltage
Does not make a urate 45° or
90° uts
1. Stops not adjusted orre tly
2. Angle pointer not set
a urately
3. Miter gauge out of adjustment
1. Che k blade with ombination
square and adjust stops
2. Che k blade with ombination
square and adjust pointer
3. Adjust miter gauge
Saw makes unsatisfa tory uts
1. Dull blade
2. Blade mounted ba kwards
3. Gum or pit h on blade
4. In orre t blade for ut
1. Sharpen or repla e blade
2. Turn blade around
3. Remove blade and lean
4. Change blade to orre t type
Material binds blade when ripping
1. Fen e not aligned with blade
2. Warped wood
3. Ex essive feed rate
4. Splitter not aligned with blade
1. Che k and adjust fen e
2. Sele t another pie e of wood
3. Redu e feed rate
4. Align splitter with blade
15

Saw vibrates ex essively
1. Stand on uneven floor
2. Damaged saw blade
3. Bad V-belts
4. Bent pulley
5. Improper motor mounting
6. Loose hardware
1. Reposition on flat, level
surfa e
2. Repla e saw blade
3. Repla e V-belts
4. Repla e pulley
5. Che k and adjust motor
6. Tighten hardware
Material ki ked ba k from blade
1. Rip fen e out of alignment
2. Splitter not aligned with blade
3. Feeding sto k without rip
fen e
4. Splitter not in pla e
5. Dull blade
6. Letting go of material before it
is past blade
7. Anti-ki k ba k paws dull
1. Align rip fen e with miter slot
2. Align splitter with blade
3. Install and use rip fen e
4. Install and use splitter (with
guard)
5. Repla e blade
6. Push material all the way past
blade before releasing work
7. Repla e or sharpen anti-ki k
ba k paws
Blade does not raise or tilt freely Sawdust and debris in raising
and tilting me hanisms Clean and regrease
16

Index Part Number Descriptions Spec. QTY Old P/N
0850429-000 Bagged Hardware 1
116 230114-906 Handle 2 PJ010018
117 040203-000 Open Wrench 11*13 1 HQ020800
118 040205-000 Open Wrench 14*17 1 HQ021100
119 040207-000 Open Wrench 22*24 1 HQ021400
120 040004-000 Hex. Wrench 4mm 1 HQ010500
121 040005-000 Hex. Wrench 5mm 1 HQ010600
122 040006-000 Hex. Wrench 6mm 1 HQ010700
123 040401-000 Screwdriver 1*75 1 HQ070100
124 041305-003 Poly Bag 275*185*0.05t 1 HR043800
142 380205-901 Nut TW5/8"-12(/in) 1 TH010011
0 850340-000 Bagged Hardware for Miter Gauge Resting Rack 1
16 049201-102 Hex. Screw w/Flat Washer M8*1.25P*12/(13B*6.5H) 2
97 170541-904 Fence Seat Resting Rack 2 TH020024
125 041103-001 Poly Bag 120*100*0.1t 1 HR040200
0850389-000 Bagged Hardware for Cast Iron Base 1
146 000006-105 Adjusting Screw M16*2.0P*60 4 RTJ040006
147 008011-100 Hex. Nut M16*2.0P(24B*13H) 4 HC011600
148 172277-902 Base Packing Block 4 RTJ040005
149 041201-002 Poly Bag 190*130*0.05t 1 HR023000
0 850483-000 Bagged Hardware for Adjusting Plate 1
32 172330-000 Adjusting Plate 3 TH250069
150 041401-002 Bubble Bag 100*70 1
1 922230-000 Spreader Guard Ass'y 1
.1 250180-627 Blade Guard 1 TH010033
.2 000002-309 Hex. Screw M6*1.0P*50 1
.3 008304-200 Nylock Nut M6*1.0P(10B*7H) 1 HW040600
.4 000302-101 Round Head Screw M4*0.7P*6 2 HA040402
.5 172335-904 Rod 1 TH250025
.6 130234-903 Connecting Rod Fixing Support 1 TH250044
.7 360865-901 Spreader Fixing Shaft 2 TH250047
.8 280160-901 Spring 2 TH250048
.9 010204-000 E-Ring ETW-7 2 HF031600
.11 010301-000 SPN Ring SPN-4 1 HF060200
.12 172336-904 Anti-Kick Pawl Left 1 TH250042
.13 280162-901 Spreader Spring (Right) 1 TH250049
.14 090149-910 Anti-Kick Fixing Bracket 1 TH250046
.15 360864-000 Pin 1 TH250051
.16 172337-904 Spreader 1 TH250017
.17 280163-901 Spreader Spring (Left) 1 TH250050
.18 172338-904 Anti-Kick Pawl (Right) 1 TH250043
.19 380495-901 Anti-Kick Paw Fixing Rod 1
.20 011002-110 Spring Pin 4*16 1 HG010909
.21 572736-000 Warning Label (Right) 1 RTJ040007
.22 572737-000 Warning Label (Left) 1 RTJ040008
4016 Part's List
1

.23 041303-019 Poly Bag 700*280*0.05t 1 HR025600
.24 520001-554 Spreader Cardboard Box 480*60*216mm 1
*2 TH27-42 Fence Ass'y
3 921782-000 Miter Guage Ass'y 1 RTJ0405
.1 003303-105 Round Head Screw 3/16"-24NC*3/8" 3 HB040905
.2 250193-620 Indicator 1 TH010304
.3 130053-901 Packing 1 TH010305
.4 360381-901 Fixing Shaft 1 TH120606
.5 043311-000 O-Ring (P type) P5 1 HM080300
.6 571151-000 Miter Guage Label 1 TH010303
.7 003305-106 Round Head Screw 5/32"-32NC*5/8" 3 HB040807
.8 009001-100 Hex. Nut 5/32"-32NC(8B*3.8H) 3 HD010200
.9 250146-000 Handle 1 TH030301
.10 006002-051 Flat Washer 8.5*18*3t 1 HY013700
.11 090067-008 Miter Guage 1 TH010302
.12 290017-901 Shoulder Screw 1 TH010308
.13 230222-901 Positioning Pin 3 TH120602
.14 380614-904 Positioning Bar 1 RTJ030041
.15 380069-901 Round Guide Piece 1 TH030303
.16 000403-105 Flat Head Screw M6*1.0P*6 1 HA050402
.17 041303-019 Poly Bag 700*280*0.05t 1 HR025600
.18 041102-003 Poly Bag 165*80*0.05t 1 HR020400
*4 TH27-83 Extension Wing Ass'y
5 050963-008 Extension Wing 1
6 000003-105 Hex. Screw M8*1.25P*25 (13B*5.5H) 6 HA010513
7 006305-100 Spring Washer 8.2*15.4 17 HE021100
8 002101-101 Pan Head Lock Screw M5*0.8P*20 1 HA350310
9 250703-615 Blade Insert 1 TH270013
10 420009-000 Wearing Plate 2-sided Tape (Left) 1 TH270023
11 420010-000 Wearing Plate 2-sided Tape (Right) 1 TH270024
12 270048-902 Wearing Plate (Left) 1 TH270006
13 270049-902 Wearing Plate (Right) 1 TH270007
14 001902-105 Set Lock Screw M6*1.0P*12 9
15 000104-111 CAP Screw M8*1.25P*35 4 HA020519
16 049201-102 Hex. Screw w/Flat Washer M8*1.25P*12/(13B*6.5H) 3
17 172331-904 Riving Knife 1 TH250005
19 050940-008 Table 1 TH270019
20 021306-000 Strain Relief PGA16-14B 2 HP042600
*21 TH27-01 Motor Ass'y TJ0A
22 008007-100 Hex. Nut M10*1.5P(17B*8H) 7 HC011000
23 006307-100 Spring Washer 10.2*18.5 13 HE021300
24 006001-069 Flat Washer 10*20*3.0t 13 HA040705
25 360761-901 Bolt 3 RTJ030021
26 012003-010 Key 5*5*30 1 HH010417
27 014314-000 Belt 180J-9 1
28 001902-102 Set Lock Screw M6*1.0P*8 4 HA320403
29 380384-902 Blade Pulley 1 RTH160013
30 030214-000 Ball Bearing 6004-2NSE 2 HJ030900
2

31 110066-000 Riving Knife Bracket 1 TH250018
32 172330-000 Adjust Plate 3 TH250069
33 000104-104 CAP Screw M8*1.25P*16 3 HA020508
34 380778-902 Lock Bolt 1
35 660145-000 Air Pressure Rod 1 TH270026
36 160076-000 Bushing 1 TH270020
37 012003-006 Key 5*5*18 5 HH010410
38 380858-901 Arbor 1 TH270003
39 390017-000 Blade 10''*40T 1
40 170518-901 Blade Washer 1 TH010012
41 380052-901 Blade Nut (5/8") 1 TJ010075
42 000105-103 CAP Screw M10*1.5P*30 4 HA020616
43 050585-008 Trunnion Bracket 2 OE320004
44 050937-000 Trunnion 1 TH270001
45 172517-901 Dust Guide 1
46 250704-615 Blade Side Cover 1 TH270017
47 000303-207 Round Head Screw M5*0.8P*20 5 HS040610
48 380383-902 Motor Pulley 1 RTH160008
49 050938-000 Up/Down Lift Bracket 1 TH270002
50 000003-102 Hex. Screw M8*1.25P*16 4 HA010508
51 006001-040 Flat Washer 8*30*3.0t 1 HE018300
52 360871-901 Up/Down Rod 1 TH270022
53 160073-000 Up/Down Rod Bushing 1 TH250062
54 660144-000 Ring 1 TH270010
55 031005-000 Ball Bearing 51102 2 HJ130300
56 130237-903 Rod Fixing Bracket 1 TH270029
57 001901-101 Set Lock Screw M5*0.8P*5 6 HA320301
58 380767-000 Bevel Gear 1
59 006001-078 Flat Washer 10.5*19*1.5t 1 HE015800
60 008307-100 Nylock Nut M10*1.25P(17B*12H) 1 HC040900
61 360825-000 Column 1 TH270011
62 008006-100 Hex. Nut M8*1.25P(13B*6.5H) 7 HC010800
63 000304-103 Round Head Screw M6*1.0P*12 1 HA040705
64 171697-156 Indicator 1 TJ020014
65 006503-100 Lock Washer 6.4*11(BW-6) 1 HE040900
66 130061-000 Key 2 TJ010041
67 000104-108 CAP Screw M8*1.25P*25 5 HA020515
68 050939-000 Gear Rotary Plate 1 TH270004
69 920662-000 Lock Bolt Ass'y 2 TJ0103
360036-000 Lock Bolt 1 TJ010301
250433-615 Lock Handle 1 TJ010302
70 240066-000 Handle Wheel 2 TH270027
71 130228-903 Fixing Ring 1
72 006006-106 Flat Washer 19.1*25.4*1.6 4 TH120081
73 360867-901 Elevation Control Shaft 1 TH270018
74 360355-901 Pin 2 PJ010044
75 000003-107 Hex. Screw M8*1.25P*35 1 HA010519
76 380768-000 Bevel Gear 1 130131-000
3

77 000103-108 CAP Screw M6*1.0P*25 3 HA020413
78 006303-100 Spring Washer 6.1*12.3 3 HE020900
79 730063-004 Wire Protector ASW-16-B(16*20/300mm) 1
*80 TH27-02 Switch Ass'y TJ0B
81 003303-101 Round Head Screw 3/16"-24NC*1/2" 2HB040906
82 000303-202 Round Head Screw M5*0.8P*8 6
83 250547-615 Sensor Box 1
84 000301-206 Round Head Screw M3*0.5P*8 4
85 006002-139 Flat Washer 3*8*1.0t 4
86 950348-000 Sensor Ass'y 220~460V(450mm) 1
.1 490498-000 Sensor Plate 220~460V 1
.2 490434-000 Sensor Connecting Wire 450mm 1
.3 250665-615 Elevation Sensor Box 1
.4 001106-601 Round Head Self-Tapping Screw M2*0.63P*6L 3
87 250632-615 Dust Guard Cover 1 RTJ030046
88 050941-000 Cast Iron Base 1 TH270021
89 000004-102 Hex. Screw M10*1.5P*25 6 HA010613
90 230131-000 Fix Nob Screw 1 SS011277
91 340007-615 Packing-Up Block 2 PG010046
92 230196-908 Clamp Screw 2 RTJ030029
93 172369-000 Cover 1 TH270014
94 006001-041 Flat Washer 8.2*22*3.0t 3 HE018400
95 021315-000 Strain Relief MG25A-16B 1 HP042900
96 000302-101 Round Head Screw M4*0.7P*6 4 HA040402
98 006001-001 Flat Washer 4.3*10*1.0t 2 HE010600
99 000401-104 Flat Head Screw M4*0.7P*10 2 HA050204
100 172332-000 Body 1 TH270009
101 021507-000 Wire Protector 1
102 230297-615 Fixed Chain 2 TH100081
103 001102-604 Round Head Self-Tapping Screw M4*1.59P*12 2 HS180305
104 172266-000 Right Cover 1
105 000403-104 Flat Head Screw M6*1.0P*20 4 HA050410
106 170542-904 Miter Gauge Resting Rack 2 TH020025
107 170965-904 Fixin Support 1 TJ010090
108 172033-904 Wrench 2 RTJ030037
109 172110-000 Sensor Piece 1 TH240005
110 006001-009 Flat Washer 5.2*10*1.0t 2 HE011100
111 001101-205 Round Head Self-Tapping Screw M3*1.06P*6 2
112 170262-000 L-Shape Board 1
113 050582-008 Worm Shaft Support 1 OE320003
114 360807-901 Worm Shaft 1
115 130031-000 Fixing Ring 1 RTJ030047
126 042608-000 Dust Hose Clamp Ø60-80mm 2
127 042601-000 Dust Hose 2.5”*1000mm 1
128 001903-107 Set Lock Screw M8*1.25P*50 4 HA030528
129 002701-103 Round Head Hex Screw w/Flat Washer M6*1.0P*16/6.3*12*1.0t 2 HA380300
130 320381-000 Worm Shaft 1 TJ020011
131 001903-104 Set Lock Screw M8*1.25P*10 2 HA320504
132 011003-106 Spring Pin 5*28 1 HG011016
4
