Oliver 4685 User manual

4685 Horizontal Band Resaw
Owner’s Manual
Oliver Machinery M-468510/2013
Seattle, WA  Copyright 2013-2017
[e-mail] www.olivermachinery.net

Warranty
Oliver makes every effort possible to assure that its equipment meets the highest possible standards of
quality and durability. All products sold by Oliver are warranted to the original customer to be free from
defects for a period of 2 (two) years on all parts, excluding electronics and motors, which are warranted for
1 year. Oliver’s obligation under this warranty shall be exclusively limited to repairing or replacing (at Ol-
iver’s option) products which are determined by Oliver to be defective upon delivery F.O.B. (return freight
paid by customer) to Oliver, and on inspection by Oliver. This warranty does not apply to defects due,
directly or indirectly, to misuse, abuse, negligence, accidents, unauthorized repairs, alterations, lack of
maintenance, acts of nature, or items that would normally be consumed or require replacement due to
normal wear. In no event shall Oliver be liable for death, personal or property injury, or damages arising
from the use of its products.
Warning
Read this manual thoroughly before operating the machine. Oliver Machinery disclaims any liability for
machines that have been altered or abused. Oliver Machinery reserves the right to effect at any time,
without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem
necessary for any reason whatsoever.
For More Information
Oliver Machinery is always adding new Industrial Woodworking products to the line. For complete,
up-to-date product information, check with your local Oliver Machinery distributor, or visit
www.olivermachinery.net

HP-400P HORIZONTAL BAND RESAW -1-
WARNING
Some dust created by power sanding, sawing, and grinding,
drilling, and other construction activities contains
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm.
Some examples of these chemicals are：
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other masonry
products.
• Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending on how
often you do this type of work. To reduce your exposure to
these chemicals：works in a well ventilated area, and work
with approved safety equipment, such as those dust masks
that are specially designed to filter out microscopic
particles.

HP-400P HORIZONTAL BAND RESAW -2-
Specifications
Model HP-400P
HORIZONTAL RE-SAW BAND SAW
Max. Workpiece Size
250mm(W) x 250mm(H)（10"x10"）
400mm(W) x 250mm(H)（12"x10"）
Conveyor Belt Size
235mm(W)x 5480mm(L)
385mm(W)x 5480mm(L)
Saw Wheel Diameter
28"
Saw Wheel Width
1"
Saw Blade Size
180" (L) x 1"(W)
Dust Hood Diameter
4" x 2
Main Specifications：Digital Readout Type
A11
In-feed Speed
4~25 M/m
Max. cutting Length
50mm
Min. cutting Thickness
3mm
Controlling Blade Tension
Hand press pump
Main Motor：Horsepower
25HP
Voltage / Phase / Cycle
Hydraulic Motor：In-feed Speed
OMP250
Out-feed Speed
OMP160
Elevation Motor：Horsepower
1/4HP x 6P
Construction：Base Construction
Steel
Saw Wheel
Steel
Conveyor Table
Steel
Conveyor Belt
Rubber
Saw Blade Guide
Ceramic
Machine Dimensions
2780mm(L) x 2150mm(W) x 1880mm(T)
Machine Weight
1350kgs
Packing Type
Pallet
Packing Dimensions
2870mm(L) x 2260mm(W) x 2050mm(T)
Packing Weight
1600kgs
Country of Origin
Taiwan
Warranty
1 year

HP-400P HORIZONTAL BAND RESAW -3-
Table Of Contents
SECTION 1：SAFETY
4~7
SECTION 2：CIRCUIT REQUIREMENTS
8
SECTION 3：GENERAL INFORMATION
9
SECTION 4：MACHINE FEATURES
10~29
SECTION 5：SET UP
30~37
SECTION 6：OPERATIONS
38~41
SECTION 7：MAINTENANCE
42~47
SECTION 8：SERVICE ADJUSTMENTS
48~53
SECTION 9：OPTIONAL
54
SECTION 10：REFERENCE INFO
55~58

HP-400P HORIZONTAL BAND RESAW -4-
SECTION 1：SAFETY
---------------------------------------------------------------------------------------
WARNING：
For Your Own Safety, Read Instruction Manual before Operating this Equipment
The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses
a series of symbols and signal words which are intended to convey the level of importance of the safety
messages. The progression of symbols is described below. Remember that safety messages by themselves do
not eliminate danger and are not a substitute for proper accident prevention measures.
DANGER：
Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.
WARNING：
Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.
CAUTION：
Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury. It
may also be used to alert against unsafe practices.
NOTICE：
This symbol is used to alert the user to useful information about proper operation of the equipment.
WARNING：
Safety Instructions for Power Tools
1. Keep guards in place and in working order.
2. Remove adjusting keys and wrenches. Form habit of checking to see that keys and adjusting wrenches are
removed from tool before turning on.
3. Keep work area clean. Cluttered areas and benches invite accidents.
4. Do not use in dangerous environment. Do not use power tools in damp or wet locations, or where any
flammable or noxious fumes may exist. Keep work area well lighted.
5. Keep children and visitors away. All children and visitors should be kept at a safe distance from work area.
6. Make workshop child proof with padlocks, master switches, or by removing starter keys.

HP-400P HORIZONTAL BAND RESAW -5-
7. Do not force tool. It will do the job better and safer at the rate for which it was designed.
8. Use right tool. Do not force tool or attachment to do a job for which it was not designed.
9. Use proper extension cord. Make sure your extension cord is in good condition. Conductor size should be
in accordance with the chart below. The amperage rating should be listed on the motor or tool nameplate.
An undersized cord will cause a drop in line voltage resulting in loss of power and overheating. Your
extension cord must also contain a ground wire and plug pin. Always repair or replace extension cords if
they become damaged.
Minimum gauge for extension cords
AMP RATING
LENGTH
25ft
50ft
100ft
0-6
16
16
14
7-10
16
16
14
11-12
16
16
14
13-16
14
12
12
17-20
12
12
10
21-30
10
10
No
10. Wear proper apparel. Do not wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry
which may get caught in moving parts. Non-slip footwear is recommended. Wear protective hair
covering to contain long hair.
11. Always use safety glasses. Also use face or dust mask if cutting operation is dusty. Everyday eyeglasses
only have impact resistant lenses, they are not safety glasses.
12. Secure work. Use clamps or a vise to hold work when practical. It is safer than using your hand and frees
both hands to operate tool.
13. Do not overreach. Keep proper footing and balance at all times.
14. Maintain tools with care. Keep tools sharp and clean for best and safest performance. Follow instructions
for lubricating and changing accessories.
15. Use recommended accessories. Consult the instruction manual for recommended accessories. The use of
improper accessories may cause risk of injury.
16. Reduce the risk of unintentional starting. On machines with magnetic contact starting switches there is a
risk of starting if the machine is bumped or jarred. Always disconnect from power source before
adjusting or servicing. Make sure switch is in off position before reconnecting.
17. Many woodworking tools can “kickback” the workpiece toward the operator if not handled properly.
Know what conditions can create “kickback” and know how to avoid them. Read the manual
accompanying the machine thoroughly.
18. Check damaged parts. Before further use of the tool, a guard or other part that is damaged should be
carefully checked to determine that it will operate properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other
conditions that may affect its operation. A guard or other part that is damaged should be properly repaired
or replaced.
19. Never leave tool running unattended. Turn power off. Do not leave tool until it comes to a complete stop.
20. Never operate a machine when tired, or under the influence of drugs or alcohol. Full mental alertness is
required at all times when running a machine.
21. Never allow unsupervised or untrained personnel to operate the machine. Make sure any instructions you
give in regards to the operation of the machine are approved, correct, safe, and clearly understood.

HP-400P HORIZONTAL BAND RESAW -6-
WARNING：
Additional Safety Instructions for Bandsaw
1. Do not operate with dull or badly worn blades. Dull blades require more demand on the motor and are less
likely to cut precisely. Inspect blades before each use.
2. Never position fingers or thumbs in line with the cut. Serious personal injury could occur.
3. Do not operate this bandsaw without wheel guards, pulley guards, and blade guards in place.
4. When replacing blades, make sure the teeth face toward the front of the saw.
5. Cuts should always be fully supported against the side of the conveyor table and by the pressure rollers.
6. Do not back workpiece away from the blade while the saw is running. If you need to back the work out,
stop the bandsaw and wait for the blade to stop. Do not twist or put excessive stress on blade while
backing work away.
7. Blade should be running at full speed before beginning a cut.
8. Always feed stock evenly and smoothly. Do not change conveyor speeds during a cut.
9. This machine is not designed to cut metal or other material except wood.
10. Do not manually stop or slow blade after turning the saw off. Allow it to come to a complete stop before
you leave it unattended.
11. All inspections, adjustments, and maintenance must be done with the power off and the circuit breaker
shut off. Wait for all moving parts to come to a complete stop.
12. Habits – good and bad – are hard to break. Develop good habits in your shop and safety will become
second- nature to you.
13. If at any time you are experiencing difficulties performing the intended operation, stop using the bandsaw.
Then contact our service department or ask a qualified expert how the operation should be performed.
14. Make sure blade is properly tensioned before operating machine.
15. Keep loose clothing and long hair away from moving conveyors!
WARNING：
Like all power tools, there is danger associated with the Model HP-400P. Accidents are frequently caused by
lack of familiarity or failure to pay attention. Use this tool with respect and caution to lessen the possibility of
operator injury. If normal safety precautions are overlooked or ignored, serious personal injury may occur.
CAUTION：
No list of safety guidelines can be complete. Every shop environment is different. Always consider safety
first, as it applies to your individual working conditions. Use this and other machinery with caution and
respect. Failure to do so could result in serious personal injury, damage to equipment, or poor work results.

HP-400P HORIZONTAL BAND RESAW -7-
WARNING：
Additional Safety Instructions for Hydraulics
1. Be familiar with the hazards of hydraulic injection injuries. Leaking hydraulic fluid may have enough
pressure to penetrate skin. Never use your hands to check for suspected hydraulic leaks.
Hydraulic fluid that is injected into skin is a medical emergency that may cause infection, disability,
amputation or death.
The average injection injury may be a small wound that has barely broken the skin. Do not be fooled by
this type of injury. Immediately get to an emergency medical facility!
Minimizing the time between the injury and when the injected material is removed is critical to
minimizing the seriousness of the injury.
2. Use a piece of cardboard to check for suspected hydraulic leaks. Pressurized hydraulic fluid may cause
injection injuries and can be extremely hot. Never use your hands to check for suspected hydraulic leaks.
3. Protect your eyes around hydraulic systems. Safety glasses may not always protect your eyes from hot,
pressurized fluid. The best way to protect yourself is to stay away from leaks until you can depressurize
the system.
4. Stop the machine if you notice a hydraulic leak. Allowing the machine to continue running with a leak
may increase the hazard of the situation.
5. Depressurize the hydraulic system before attempting to adjust any hydraulic lines or fittings. Stop the
resaw, open the conveyor speed valves, and make sure the pressure gauge reads 0 psi.
6. Depressurize the hydraulic system before attempting any maintenance or service. Stop the resaw, open the
conveyor speed valves, and make sure the pressure gauge reads 0 psi.
7. Regularly inspect and perform the proper maintenance on the hydraulic system. A well-maintained
hydraulic system will have much few problems and hazards than a neglected system.
8. Make sure any hydraulic system maintenance is performed in a clean and dust-free work area. Remove any
sawdust, grime or water from hydraulic system openings or components before maintenance. Always use
lint-free rags when wiping components.
9. Only use high pressure hydraulic hose and steel hydraulic fittings when replacing components in the
hydraulic system. Do not use brass or aluminum.

HP-400P HORIZONTAL BAND RESAW -8-
SECTION 2：CIRCUIT REQUIREMENTS
---------------------------------------------------------------------------------------
WARNING：
Serious personal injury could occur if you connect your machine to the power source before you have
completed the setup process. Do not connect the machine to the power source until instructed to do so.
The Model HP-400P is rewiring for 3-phase operation.
The Model HP-400P has three 25 HP main motor and three 1/4 HP elevation motor.
Circuit Breaker Requirements
Install your bandsaw on a dedicated circuit to reduce the possibility of overloading the circuit and tripping
the circuit breaker. However, if an unusual load does not exist, and the circuit breaker still trips, have the
circuit inspected by a qualified electrician. Never use a larger circuit breaker than stated below, or you will
increase the risk of fire.
Connection Type
Because of the high amperage draw from this machine, we recommend that you hardwire it directly to your
circuit breaker and install a locking shut-off lever near the machine as a way to quickly disconnect the power.
Your factory Circuit Capacity
Always check to see if the wires in your circuit are capable of handling the amperage draw from your
machine, as well as any other machines that could be operating on the same circuit. If you are unsure, consult
a qualified electrician.
If the circuit breaker trips or the fuse blows regularly, your machine may be operating on a circuit that is
close to its amperage draw capacity. However, if an unusual amperage draw does not exist and a power
failure still occurs, refer to the troubleshooting section in this manual or contact a qualified electrician or our
service department.
CAUTION：
Be sure that your particular electrical configuration complies with local and state codes. The best way to
ensure compliance is to check with your local municipality or a licensed electrician.

HP-400P HORIZONTAL BAND RESAW -9-
SECTION 3：GENERAL INFORMATION
---------------------------------------------------------------------------------------
WARNING：
If you do not read this entire manual before operating the machine, you will greatly increase your chances of
serious personal injury. To protect yourself, read and understand this entire manual.
Commentary
BLUE STEEL MACHINERY CO. is proud to offer the Model HP-400P Horizontal Band resaw. This band
resaw is part of BLUE STEEL’s growing family of fine woodworking machinery. When used according to
the guidelines stated in this manual, you can expect years of trouble-free, enjoyable operation, and proof of
BLUE STEEL’s commitment to customer satisfaction.
We are also pleased to provide this manual for the Model HP-400P. It was written to guide you through
assembly, review safety considerations, and cover general operating procedures. It represents our latest effort
to produce the best documentation possible.
If you have any comments or criticisms that you feel we should address in our next printing, please write to
us at：
Blue Steel Machinery Company
86-10, Shen Ching Road, Ching Shui, Taiwan 436
Tel：[phone]
Fax：[phone]
E-mail：[email protected]
Website：www.highpointtools.com

HP-400P HORIZONTAL BAND RESAW -10-
SECTION 4：MACHINE FEATURES
---------------------------------------------------------------------------------------
Main Features
1. Infeed Pressure Rollers：Maintain downward pressure on the board to keep it sturdy whiles the blade cuts
through it.
2. Blade Tensional：Provides a mechanical means for properly tightening the blade.

HP-400P HORIZONTAL BAND RESAW -11-
3. Head Elevation Motor：Responsible for moving the head (the part of the saw that contains the wheels and
blade) up or down as needed.
4. Electrical Control Box：Main area for wiring, rewiring, and changing the fuses. Should never be opened
when the machine is connected to the power source!
5. Infeed Conveyor：Moves the board through the bandsaw blade during cutting.
6. 4" Dust Port：Allows the resaw to be connected to a dust collection system.

HP-400P HORIZONTAL BAND RESAW -12-
7. Infeed Conveyor Speed Dial：Controls the speed that the infeed conveyor belt moves.
8. Infeed Conveyor Engagement Lever：Allows the operator to stop and start the infeed conveyor while the
blade is moving.
9. Control Panel：The part of the resaw where the operator can control the starting and stopping of the motor,
the various height changes, and the calibration of the blade height to the conveyor. The control panel also
houses a load meter that allows the operator to monitor the load being placed on the resaw during
operation.
10. Main Motor：Powers the saw wheels for blade movement and drives the hydraulic pump for conveyor

HP-400P HORIZONTAL BAND RESAW -13-
movement.
11. Hydraulic Pump：Creates hydraulic oil flow which drives the conveyor motors.
12. Hydraulic Tank：Holds the hydraulic fluid for the hydraulic system.
13. Blade Tension Gauge：Shows the current blade tension.

HP-400P HORIZONTAL BAND RESAW -14-
Function Description on Control Pane
2. AMP.METER
1. MEMORY
8. 4 digits preset display
3. MM/INCH indicator light
4. Running indicator light
5. Number 0-9
6. Button of down dim.
9. 4 digits gauge display
7. Button of up dim.
15. POWER ON
16. MOTOR START
17. MOTOR STOP
20. DOWN
19. UP
18. EMG STOP
13. Stop button
12. Setting gauge button
11. Setting preset button
10. Start button
14. Saving Dimension

HP-400P HORIZONTAL BAND RESAW -15-
MEMERY
This button is used for constant thickness setting. It provides
convenient repetitive thickness setting without need to set the
sizes again.
AMP.METER
This meter indicates the load condition of the saw wheel drive
motor.
Once overload occurs, the thermal relay pin on the magnetic
switch will
trip, Iocated in the control box.
POWER ON SWITCH
Turning this switch for power on and the indication lamp lights
on.
MOTOR START
Used for starting saw wheels running and the indication lamp
lights on.
MEMORY
This button is used for constant thickness setting. It provides
convenient repetitive thickness setting without need to set the
sizes again.
EMERGENCY STOPSWITCH
During operation, in case any abnormal motion occurs, press
this switch then all machine motions stop, except the LED
display IS still power on.
UP KEY
Press this switch for raising saw wheels.
Down KEY
Press this switch for lowering saw wheels

HP-400P HORIZONTAL BAND RESAW -16-
1.SPECIFICATIONS： PLEASE OBEY THIS REGULATION!
1. Power Input：AC (380V) 5OHZ +20%
2. Signal Input：Standard Encoder A,B Phase Signal (DC12V).
3. Signal Output：Relay Panel point output .
Down / Back movement ==>R 1 Up / Forward movement ==>R2
4. The with Standing Pressure of The Output Panel of the Relay：AC (250v - 1A).
5. Unit of measurement：MM / INCH.
6. Route distance：MM 000.1 to 999.9 INCH 000.0 to 99.99
7. Inertia teaching：After 3-5 times start running,
The controller will automatically adjust to the best operation conditions.
8. Safety Limit Switch：When using this controller, the stroke safety limit switch must be adopted. Please use
NC, C , in the electromagnetism on-off return circuit to protect automatically. (Serious Warning) To make
sure the safety of people and machinery operation, the safety limit switch must be equipped.
9. Please be sure to add fuse on AC input (Fuse don't surpass 3A in AC load, please calculate fit amperage by
yourself.) To avoid motor or contactor out of order.
10. For reducing controller interference. Please separate signal wire and power wire.
11. Please add Varistor on AC load for reducing interference.
12. Don't connect the shielded cable of the Induction unit to circuit 0 volt or GND.
13. The programmable controller is intended of use in Zone B typical industrial environment.
14. All interfacing cables are less than 3M.
WARNING：
The electricians and operators have to pay their attention not to make any change personally on the above
mentioned 14 points. Otherwise, the controller is possible to be ensure the safety of people, please caution.
2.CHARACTERISTICS：
1. The Micro-Computer single chip is adopted in this controller.
The stability and safety can be assured under long time running.
2. Even though the power voltage is different or the drive construction
is worn out day by day and the change of return circuit can effect
completely the function of dimension clamping.
3. lf any error in motor drive of gyration no signal, automatic safety
monitoring system circuit will stop the machine to protection
electric circuit.
4. The memory is a limitless use.
5. Easy operation and learning.
6. RAM 1280 bytes.
Diagram 1：

HP-400P HORIZONTAL BAND RESAW -17-
3. PANEL DISPLAY AND DESCRIPTION OF BUTTON FUNCTIONS
Diagram 2：
1.
4 Digits display of Preset.
2.
4 Digits display of Gauge.
3.
After set dimension. It’s an auto running button.
4.
Button for input preset digits.
5.
Button for input gauge digits.
6.
Button for stop running and operating.
7.
MM/INCH indicator light.
8.
Running indicator light.
9.
Figure buttons for input dimension size.
10.
Manual operation, button for decrase.
11.
Manual operation, button for increase.
12.
：Saving input Dimension.
1. 4 Digits Preset display
5. Setting Gauge Button
6. Stop Button
4. Setting Press Button
3. Start Button
2. 4 Digits Gauge display
7. MM/INCHl Indicator light
8. Running indlcator Light
9. Number 0-9
10. Button of Down dim
12. Saving Dimenision
11. Button of
down dim.

HP-400P HORIZONTAL BAND RESAW -18-
4. OPERATING INSTRUCTION FOR CORRECTING CURRENT DIMENSION：
1. Using vernier gages or surveying instruments to measure the thickness of workpiece after sanding,
e,g.18.5mm.
2. Press button
3. GAUGE Digital flash .
4. Press Number button
5. Press button
6. 18.5mm is appear on the screen.
7. Completing size input.
PS：When correcting existing data, the button if the current figure show on the 28.8 and
correction in 18.5, the step to operate are as the following diagrams demonstrated.
Diagram 3
PS：Press button prior to press , the display will stop flashing .
WARNING：
In order not to cause any danger by the wrong dimension of machinery operation, except electricians, it's
prohibited to operate or make any change.
STEP 1：
Press button
000.0 is shown on
the GAUGE
display, and start
flash.
STEP 2：
Press button
000.1 is shown on
the display and
continue flash.
STEP 3：
Press button
001.8 is shown on
the display and
continue flash.
STEP 4：
Press button
018.5 is shown on
the display and
continue flash.
STEP 5：
Press button
and keep on pressing
until display is stop
flash. (2-3sec)
STEP 6：
After display is stop
flash, release button
the gauge data change
to 18.5mm.
