olympia electronics BS-475/B User manual

Page 1 of 4
BS-475 BS-475/B
Autonomous wireless siren with beacon for
the BS-468 / A burglar alarm system
921475000_09_009
Solar panels 12V / 1.4W
ABS/PC, PC (red)
USAGE
BATTERY TYPE
Outdoors
6V/1.3Ah Pb (lead)
IP20
105 dB / 1m
-10 60 C
o
to
Up to 90%
2 years (6 months for the battery )
1605 gr.
188x120x360 mm.
EN 50130-4, EN 55022, EN 60950-1
TECHNICAL SPECIFICATIONS
RELATIVE HUMIDITY
CONSTRUCTION MATERIAL
TYPICAL WEIGHT
EXTERNAL DIMENSIONS
GUARANTEE
POWER SUPPLY
SOUND LEVEL
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
DEGREES OF COVER PROTECTION
COMPLY WITH
COMMUNICATION FREQUENCY
COMMUNICATION RANGE
868 MHz
About 300m (in open area)
ETSI EN 300220, EN 50130-4, EN 55022, EN 60950-1 ERC REC 70-03
INSTALLATION
INSTALLATION
BEACON
BEACON
ALARM
ALARM
GENERAL
The BS-475 (white) or BS-475/B (carbon) alarm siren is used exclusively with the BS-
468/A panel. When the siren is activated, a red flashing light and a sound of 105dB
which range is 1 meter distance, are produced. Inside the device there is a tamper that
activates the siren if someone tries to remove its cover or pull the device off the wall.
The device is placed externally on a flat wall, at a height of more than 2.5 meters
and away from places or objects that can prevent the transmission of its sound. It is
recommended that the photovoltaic panel to be placed at a point where it has the
best possible visual contact with the sunlight.
ATTENTION!!! All four retaining screws must be installed.
The siren board has a LED (FLASH) jumper which can be set either in (ON) or in
(OFF) position. If the jumper is set to the (ON) position, the beacon makes a short
blink every 8 seconds in normal mode. Otherwise (jumper in OFF position) it is
turned off until an alarm is triggered. In any case it will be constantly on in sound
mode, regardless the jumper position. Also,upon arming procedure, the siren will
"flash" 3 times when the system is armed, but it will "flash" once when the system is
disarmed. This feature can be disabled from the control panel menu settings.
Flash mode from jumper and Arm-Disarm indication function are two independent
functions. Activating one of those settings will not activate the other and vice versa.
The siren sounds alarm when the BS-468/A control panel sends the
corresponding command. The beacon remains ON, as long as the sound lasts.
Thank you for your trust in our products
Olympia Electronics - European manufacturer

Page 2 of 4
RANGE TEST
RANGE TEST
SETUP
SETUP
Installation should only be carried out by quilified technicians.
To install, follow the procedure below:
1. Remove the retaining screws from the front cover of the device (Photo 1).
2. Remove the retaining screws from the inner cover of the device (Photo 2).
3. Drill with a 6mm diameter drill bit on the wall and place the mounting materials at
the 4 indicating points (Photo 3) so as to fasten the device.
4. Connect the battery (ATTENTION!!! The red wire to the positive pole (+)), re-install the
inner protective cover and fasten it with the retaining screws that you removed in
step 2.
5. Re-install the front cover and fasten it with the retaining screws that you removed
in step 1.
6. The device is ready to operate.
ATTENTION!! When the BS-468/A panel is in wireless installation mode and we want to insert the
BS-475 or BS-475/B siren into the network, one of the 2 photovoltaic panel's cables in the KL1 terminal
must be removed before we install the device in the network. When the device enters the network, the
cable must be re-installed to the KL1 terminal.
ALARM DURATION
ALARM DURATION
The siren is in alarm mode as long as there is an alarm signal. At the BS-468/A there is a user's setting,
to select 1 or 2 minutes. There is an absolute security limit of 5 minutes, above which it stops sounding
irrespective of the command it is selected from the control panel. Also, if the battery voltage is low (lower
than 5.5V), the siren will not sound irrespective of the command it takes from the control panel.
Once the device is connected to the panel's network, remove the battery and wait for 10 seconds.
Then press the tamper and reinstall the battery. Wait until the beacon lights up. Once you release the
tamper, the beacon will go out. In this case, the range TEST will start. During range test beacon
blinks every second. The duration of range test is 60-95 seconds. When it is finished the beacon
goes off and after 2 seconds the test result is displayed as follows:
Single blink: Strong signal. The device can be safely installed at this point.
Two blinks: Normal signal. The device can be safely installed at this point.
Three blinks: Weak signal. It is recommended not to install the device at this point.
There will be communication bettween the device and
the control panel but there will be communication
packets losses.
Four blinks: Out of range. The device is forbidden to be placed in this point.
Note: As soon as the test procedure is started, it is suggested that the device cover will be placed
directly in order to simulate the actual communication conditions. The environment must be also
adapted to the worst possible conditions (e.g. closed doors). Finally, in case of home improvements
or renovation, it is suggested to perform a range test again.
921475000_09_009

Page 3 of 4
Photo 1
Front cover of the siren
Photo 2
Internal protective cover
of the siren
1. Place mounting accessories
2. Retaining screws of the inner
protective cover
3. Loudspeaker
4. Terminal block
5. Battery 6V/1.3 Ah
6. Base self-protection tamper
7. Beacon
8. JUMPER FLASH
9. Front cover self-protection tamper
Photo 3
The main parts of the siren
SIREN SOUND SELECTION
SIREN SOUND SELECTION
The device has 8 different sounds. The selection is done by slider switches 1, 2 and 3 of
the DS1 dip switch (Photo 4). Slide switch 4 is inactive. By default only the slide switch 2
is ON.
7
5
4
6
3
2
11
1
1
2
8
9
921475000_09_009

Page 4 of 4
The siren checks its battery voltage and transmits the information to the panel. If the
panel displays a low battery indicator for extended periods of days with high
sunshine, consult your installer, as the battery may need to be replaced. This must
be done by a qualified technician with the control panel in service mode.
t i
in battery recycling points. Do not incinerate.
I s not allowed to discard batteries in to common trash bins, they must
be discarded only
BATTERY REPLACEMENT
BATTERY REPLACEMENT
WARRANTY
WARRANTY
ATTENTION!!! Do not remove or move the jumpers located at positions CΝ6
and CΝ2.
Olympia Electronics guarantees the quality, condition and operation of the goods.
The period of warranty is specified in the official catalogue of Olympia Electronics
and also in the technical leaflet, which accompanies each product. This warranty
ceases to exist if the buyer does not follow the technical instructions included in
official documents given by Olympia Electronics or if the buyer modifies the goods
provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged
can be returned to the premises of our company for repair or replacement, as long
as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and
to or not charge the buyer depending on the reason of defection. Olympia
Electronics reserves the right to charge or not the buyer the transportation cost.
HEAD OFFICE
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
www.olympia-electronics.gr
[email protected]
CN6
CN2
CN4
(JUMPER FLASH)
DS1
Photo 4. Main board of the siren.
