Omcan FR-CN-0667 User manual

Revised - 08/09/2022
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Ice Cream Display Freezers
Models FR-CN-0667, 1016, 1245
Items 31455, 31456, 27941
Instruction Manual

2
Page
-------------------------------------------------------------------------------------------- 3
--------------------------------------------------------------------------- 4 - 5
--------------------------------------------------------------------------- 5 - 6
-------------------------------------------------------------------------- 6
-------------------------------------------------------------------------------------------- 7
--------------------------------------------------------------------------------------------- 7
----------------------------------------------------------------------------------------- 8
-------------------------------------------------------------------------------- 8 - 9
---------------------------------------------------------------------------- 10 - 12
---------------------------------------------------------------------------- 13
------------------------------------------------------------------------------------------------ 14
---------------------------------------------------------------------------- 15
Table of Contents
Section
Disclaimer
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Troubleshooting
Parts Breakdown
Electrical Schematics
Notes
Warranty Registration
Model FR-CN-0667 / Model FR-CN-1016 / Model FR-CN-1245

3
Disclaimer
OMCAN IS NOT RESPONSIBLE FOR ANY
DAMAGES DUE TO WATER LEAKS. WARRANTY
FOR WATER LEAKS IS VOID IF THE AMBIENT
ROOM TEMPERATURE EXCEEDS 75°F AND 55%
RELATIVE HUMIDITY, AND THE APPLIANCE
DRAIN IS NOT CONNECTED DIRECTLY TO A
FLOOR DRAIN.

4
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

5
General Information
Safety and Warranty
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.
RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure
or other damages resulting from installation in non-commercial or residential applications. The right
is reserved to deny shipment for residential usage; if this occurs, you will be notied as soon as
possible.
1 YEAR PARTS AND LABOUR WARRANTY

6
Technical Specications
Safety and Warranty
Model FR-CN-0667 FR-CN-1016 FR-CN-1245
Power 345 W 460 W
Freezer Capacity 160 L / 5.6 cu.ft. 260 L / 9.2 cu.ft. 360 L / 12.8 cu.ft.
Number of Doors 2
Number of Baskets 2 3
Temperature Range -26°C to 6°C / -15°F to 43°F
Max Ambient Temp
Rating 24°C / 75°F
Refrigerant R290
Electrical 110V / 60Hz / 1
Weight 101.5 lbs. / 46 kgs. 114.75 lbs. / 52 kgs. 152 lbs. / 69 kgs.
Packaging Weight 123.5 lbs. / 56 kgs. 136.75 lbs. / 62 kgs. 180.75 lbs. / 82 kgs.
Dimensions 26.3” x 27.8” x 34.5”
667 x 705 x 876mm
39” x 27.8” x 34.5”
990 x 705 x 876mm
49.6” x 27.8” x 34.4”
1260 x 705 x 875mm
Packaging Dimensions 29” x 30” x 37.5”
737 x 762 x 953mm
41.8” x 30” x 37.5”
1060 x 762 x 953mm
53” x 30” x 38”
1346 x 762 x 965mm
Item Number 31455 31456 27941
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized
service technician to repair the equipment locally.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see https://omcan.com/disclaimer for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

7
Operation
POWER SOURCE AND TEST-RUNNING
• Specied capacity of the wire is 6A. Section squares of the wire is 0.75mm. Single line or compound lines
are all allowed. The fuse of 2.5A specied electric current should be installed. (Power cord should be
replaced with the same of 6A and 0.75mm, when it is damaged).
• Single-phase power supply, 60Hz, voltage 110V. If the voltage is unstable, please install a voltage stabilizer
with capacity above 1000W.
• Avoid turning on and off the power too frequently. If the power is turned off, wait an interval of 5 minutes
before turning it on again.
• When the freezer will be out of use for a long time, disconnect the power rst, then clean it. Please
examine the circuit whether it is excellent before reuse.
OPERATION OF THE TEMPERATURE CONTROL KNOB
• The temperature in the cabinet can be controlled with the temperature control knob.
• The knob should be kept upright normally to adjust the temperature. FREEZING MAX is the strongest
cooling position and is suitable for fast freezing. Do not keep the knob at this point for long.
FOOD STORAGE
• There must be space between the foods stored in the cabinet, between the foods and the inner surface
of the cabinet, so as to keep good ventilation of cold air and freeze evenly. Do not put in any bottled or
canned beverage with freezing point above the temperature in the cabinet when it is below zero.
• For foods that should be moisture-free or lose water easily, wrap them up with hermetic food bags or fresh
lms before putting in the cabinet for the sake of avoiding smell-mixing and reducing frosting.
• Storage of volatile and combustible gases, liquids such as strong alkalies, strong acids, petrol, etc. is
forbidden.
Installation
TRANSPORTATION AND PLACEMENT
• When transporting the chest freezer from one place to another, the inclination of the cabinet should not
exceed 45 degrees, for prevention against compressor or system damage.
• Before use, remove all the packing material. The back side of the cabinet should be more than 20cm /
7.87” away from the wall, both ank sides more than 20cm / 7.87”.
• The freezer should be put in well-ventilated, dry place. Don’t use it under direct sunshine. The freezer
should be kept away from water sink, heat source and any volatile, corrosive material.

8
Troubleshooting
Maintenance
Symptom Cause Solution
The indicator is not on or the
compressor does not start.
The plug isn’t connected to the
socket.
Re-connect it.
No power. Connect to a socket with power.
The indicator is on, but the
compressor doesn’t work and
buzzes only.
The power voltage is <110V. Attach a power-regulator with more
than 1000W power.
The compressor stops a minute
after start, and restart after a few
minutes, and so repeatedly.
The power voltage is >110V.
• The freezer should be cleaned regularly. When cleaning, turn off the power, take out the foods in the
cabinet, clean the inside using water or a little neutral detergent.
• Do not use boiling water, acid, chemical diluters, petrol and oil, or dirt-removing powder.
• Dry it after cleaning.
• Use light soap water when cleaning the door seal, apply a little of talcum powder on it after natural drying to
extend its service life.
• Use soft cloth with water or a little detergent to clean the out surface.
Note, keeping the power supply and lower part of connect wires away from water to avoid
electricity leakage.
• Except common breakdowns, those who are not service technician should not take apart and repair the
freezer on their own so as to avoid worsening the trouble. Unauthorized repair of electrical part such as
compressor, temperature controller is forbidden.
DEFROSTING
• Defrost for better freezing efciency when the frost lm in the cabinet is 4-5mm thick.
• When defrosting, turn off the power, take out the frozen foods, open the door for warming and melting. Use
soft cloth to absorb water and clean it up.
• Do not use sharp metal tools such as steel brush to clean the frost lm when defrosting so as to avoid
evaporator damage.

9
Troubleshooting
The compressor works normally,
but the temperature in the cabinet
cools too slowly.
The door is being opened too
frequently.
Reduce open times.
The is too much food in the
cabinet, and it is placed improperly.
Place food properly, keep space
between them for ventilation of
cold air.
The frost lm is too thick. Take out food and defrost.
The surface of the condenser is
too dirty.
Stop and clean the condenser.
The door doesn’t seal. Adjust the door seal.
The noise is too loud. The freezer is placed in a unstable
location.
Place it in a stable location.
The xing of the freezer is loose. Tighten the xing.
There’s contact between pipes. Separate the pipes.
THE FOLLOWING ARE WITHIN NORMAL OPERATING PARAMETERS:
• When the freezer is working or after is stops for a while, the refrigerant in the pipes is cycling and gives out
“running water” sounds.
• The surface temperature of the compressor may be up 70°C ~ 80°C / 158°F ~ 176°F when it is working.
• The back side of step freezer gives out heat.
• In rainy season, the outer surface of the cabinet may have dew, which makes no defects on normal use.
Just dry it with a piece of cloth.
For service call 1-800-465-0234.

10
Parts Breakdown
Model FR-CN-0667 31455

11
Parts Breakdown
Model FR-CN-1016 31456
Model FR-CN-1245 27941

12
Parts Breakdown
Model FR-CN-0667 31455
Item No. Description Position Item No. Description Position Item No. Description Position
37875 Glass Door without Key Hole for 31455 1 78718 Castor Channel Iron A for 31455 10 64768 Fan Motor Support for 31455 18
41162 Key/Lock for 31455 2 78719 Castor Channel Iron B for 31455 10 28446 Castor without Lock for 31455 19
28442 Glass Door with Key Hole for 31455 3 64765 Thermometer for 31455 11 78720 Compressor Support for 31455 20
31440 Basket for 31455 4 28449 Thermostat Series (no Knob) for 31455 12 28447 Shutter for 31455 22
64763 Thermostat Cover for 31455 5 64766 Thermostat Support for 31455 13 28448 Plug Series for 31455 23
64764 Thermometer Cover for 31455 6 39587 Indicator Lamp for 31455 14 63504 Compressor (R290) for 31455 25
64769 Cabinet Plastic Frame for 31455 7 39586 Filter for 31455 15 43413 Basket Divider for 31455
28453 Condenser for 31455 8 64441 Filter Support for 31455 16
28445 Caster with Lock for 31455 9 64767 Condenser Fan Motor for 31455 17
Item No. Description Position Item No. Description Position Item No. Description Position
28443 Left Glass Door without Key Hole for
31456 1 78718 Castor Channel Iron A for 31456 10 64768 Fan Motor Support for 31456 18
41162 Key/Lock for 31456 2 78719 Castor Channel Iron B for 31456 10 28446 Castor without Lock for 31456 19
39817 Right Glass Door with Key Hole for
31456 3 64765 Thermometer for 31456 11 78720 Compressor Support for 31456 20
31440 Basket for 31456 4 28449 Thermostat Series (no Knob) for 31456 12 28447 Shutter for 31456 22
64763 Thermostat Cover for 31456 5 64766 Thermostat Support for 31456 13 28448 Plug Series for 31456 23
64764 Thermometer Cover for 31456 6 39587 Indicator Lamp for 31456 14 63506 Compressor (R290) for 31456 25
64770 Cabinet Plastic Frame for 31456 7 39586 Filter for 31456 15 43413 Basket Divider for 31456
37874 Condenser for 31456 8 64441 Filter Support for 31456 16
28445 Caster with Lock for 31456 9 64771 Fan Motor for 31456 17
Item No. Description Position Item No. Description Position Item No. Description Position
28444 Left Glass Door without Key Holes for
27941 1 78718 Castor Channel Iron A for 27941 10 64768 Fan Motor Support for 27941 18
41162 Key/Lock for 27941 2 78719 Castor Channel Iron B for 27941 10 28446 Castor without Lock for 27941 19
39777 Right Glass Door with Key Hole for
27941 3 64765 Thermometer for 27941 11 78720 Compressor Support for 27941 20
31440 Basket for 27941 4 28449 Thermostat Series (no Knob) for 27941 12 28447 Shutter for 27941 22
64763 Thermostat Cover for 27941 5 64766 Thermostat Support for 27941 13 28448 Plug Series for 27941 23
64764 Thermometer Cover for 27941 6 39587 Indicator Lamp for 27941 14 63503 Compressor (R290) for 27941 25
64772 Cabinet Plastic Frame for 27941 7 39586 Filter for 27941 15 43413 Basket Divider for 27941
37874 Condenser for 27941 8 64441 Filter Support for 27941 16
28445 Caster with Lock for 27941 9 28454 Cooling Fan Motor for 27941 17
Model FR-CN-1016 31456
Model FR-CN-1245 27941

13
Electrical Schematics
Model FR-CN-0667 31455
Model FR-CN-1016 31456
Model FR-CN-1245 27941

14
Notes
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________

15
Warranty Registration
Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,
cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:
Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la
carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:
Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at
the perforation and then send to the address specied below. You can also register online by visiting:
OMCAN
PRODUCT WARRANTY REGISTRATION
3115 Pepper Mill Court,
Mississauga, Ontario
Canada, L5L 4X5
https://omcan.com/warranty-registration/
or email to: [email protected]
Purchaser’s Information
Name: Company Name:
Address:
Telephone:
City: Province or State: Postal or Zip: Email Address:
Country: Type of Company:
Restaurant Bakery Deli
Dealer from which Purchased: Butcher Supermarket Caterer
Dealer City: Dealer Province or State: Institution (specify):
Invoice: Other (specify):
Model Name: Model Number: Serial Number:
Machine Description:
Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):
Would you like to extend the warranty? Yes No

Por correo en Canadá
Pour postale au Canada
For mailing in Canada
Por correo en los EE.UU.
Pour diffusion aux États-Unis
For mailing in the US
OMCAN
PRODUCT WARRANTY REGISTRATION
4450 Witmer Industrial Estates, Unit 4,
Niagara Falls, New York
USA, 14305
Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North
American food service industry. Our success over these many years can be attributed to our commitment
to strengthen and develop new and existing relationships with our valued customers and manufacturers.
Today with partners in North America, Europe, Asia and South America, we continually work to improve
and grow the company. We strive to offer customers exceptional value through our qualied local sales
and service representatives who provide convenient access to over 6,500 globally sourced products.
Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et
matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces
nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles
et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en
Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et
développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à
nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 6500
produits provenant du monde entier.
Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros
de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir
a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos
clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan
continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor
excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un
fácil acceso a más de 6,500 productos con origen a nivel mundial.
