Omega FTB300 Series User manual

FTB300 Series Page 3
Wiring Diagram
Foot Strainer
Strainer Adapter
Strainer Body
Screen Strainer
Suction Tubing
Part Number
FPUSV-V Exploded View
Your FTB300 flow verification sensor package includes a Foot Strainer (see diagram below). This strainer will prevent any
small particles from entering and clogging the Sensor Body. Diaphragm pumps will require a strainer and a check valve.
The part number for the strainer that includes a check valve is FPUSV-V.
Sensor
+
_
Red 0v dc
(True digital Square-wave output)
+5v dc
Bare
Black (Ground)
Sensor connections:
Input voltage (vdc) 8 to 28 vdc
Output voltage (v) “high state” 4 80 v dc min (5 vdc normal)
Output voltage (v) “low state” 0 2v dc max
+ 5 Vdc (signal output)
8 to 28 Vdc (Positive)
K-Factors (pulses per fluid volume)
30-3001
100-10002
200-20003
300-30004
500-50005
700-70006
181,336
81,509
42,051
25,153
15,737
9,375
Flow Range
(ml/min)
Body
Size
Pulses per
Gallon
21,535
13,752
6,646
4,157
2,477
Pulses per
Liter
47,909 Useful formulas
60 / K = rate scale factor
rate scale factor x Hz = flow rate in volume per minute
1 / K = total scale factor
total scale factor x n pulses = total volume

FTB300 Series Page 3
Wiring Diagram
Foot Strainer
Strainer Adapter
Strainer Body
Screen Strainer
Suction Tubing
Part Number
FPUSV-V Exploded View
Your FTB300 flow verification sensor package includes a Foot Strainer (see diagram below). This strainer will prevent any
small particles from entering and clogging the Sensor Body. Diaphragm pumps will require a strainer and a check valve.
The part number for the strainer that includes a check valve is FPUSV-V.
Sensor
+
_
Red 0v dc
(True digital Square-wave output)
+5v dc
Bare
Black (Ground)
Sensor connections:
Input voltage (vdc) 8 to 28 vdc
Output voltage (v) “high state” 4 80 v dc min (5 vdc normal)
Output voltage (v) “low state” 0 2v dc max
+ 5 Vdc (signal output)
8 to 28 Vdc (Positive)
K-Factors (pulses per fluid volume)
30-3001
100-10002
200-20003
300-30004
500-50005
700-70006
181,336
81,509
42,051
25,153
15,737
9,375
Flow Range
(ml/min)
Body
Size
Pulses per
Gallon
21,535
13,752
6,646
4,157
2,477
Pulses per
Liter
47,909 Useful formulas
60 / K = rate scale factor
rate scale factor x Hz = flow rate in volume per minute
1 / K = total scale factor
total scale factor x n pulses = total volume

Page 4 FTB300 Series
Temperature vs. Pressure
Pressure and Temperature
PSIg / BAR
Temperature
130°F / 54.4°C
120°F / 48.9°C
110°F / 43.3°C
100°F / 37.8°C
90°F / 32.2°C
140°F / 60°C
150°F / 65.6°C
160°F / 71.1°C
170°F / 76.7°C
180°F / 82.2°C
190°F / 87.8°C
200°F / 93.3°C
80°F / 26.7°C
70°F / 21.1°C
0 / 0 50 / 3.4 75 / 5.2
25 / 1.7 100 / 6.9 130 / 9 150 / 10.3
Pressure and temperature limits are inversely proportional. At the maximum suggested pressure the tempera-
ture should approach 70°F / 21.1°C. At the maximum suggested temperature the pressure should approach
zero psi. We cannot guarantee our flowmeters will not be damaged either at or below the suggested limits
simply because of many factors which influence meter integrity; stress resulting from meter misalignment,
damage due to excessive vibration and/or deterioration caused by contact with certain chemicals as well as
direct sunlight. These situations and others tend to reduce the strength of the materials from which the meters
are manufactured.
Although meters may be suitable for other chemicals, we cannot guarantee their suitability. It is the
responsibility of the user to determine the suitability of the flowmeter in their application.
Application Note
PVC
PVDF
FTB300 Series Page 5
5
Exploded View and Parts List
NOTE: The “Exploded View” drawing illustrates assembly of the FTB300 Flow Verification Sensor. If
your sensor needs to be cleaned refer to this drawing when reassembling the unit.
Item Description Catalog number Quantity
1. FTB300 Body .031 30-300ml/min 76001-300 1
.062 100-1000ml/min 76001-301
.093 200-2000ml/min 76001-302
.125 300-3000ml/min 76001-303
.156 500-5000ml/min 76001-304
.187 700-7000ml/min 76001-305
2. Tubing, PVC 76001-299 2
3. O-Ring, Viton 90003-012 2
4. Adapter .250” F/NPT, PVC 76000-137 2
Adapter .125” F/NPT, PVC 76000-456
Adapter .375” Tubing Connection, PVDF 90002-038
Adapter .250” Tubing Connection, PVDF 90002-042
Adapter .500” ID Hose Barb, PVC 76001-360
Adapter .500” F/NPT, PVC 76001-359
Adapter .500” M/NPT, PVC 76001-358
5. Tube Nut 90002-305 2
6. Sensor Assembly 71010-182 1
7. Screws, SS 90011-113 2
8. Screws, SS 90011-190 4
9. Lens Cap, PVC (Optional PVDF) 90002-227 1
10. Axel, PVDF 90007-592 1
11. Paddle, PVDF 90002-229 1
12. O-Rng, Viton 90003-143 1
13. Screws, #4x.50 Phil Blk 90011-178 2
1
2
3
4
6
67
8
9
10
11
12
13
