Omega Ss-002 User manual

MQS5823/1022

SS-002 (-NA)

Layer N Wireless TC and RTD Smart

Sensor with Cloud Connectivity

Contains FCC ID: WR3SS001XNA

FCC Statement

Industry Canada Statement

This device complies with Industry

Canada license-exempt RSS

standard(s). Operaon is subject

to the following two condions:

(1) this device may not cause

interference, and (2) this device

must accept any interference,

including interference that may

cause undesired operaon of the

device.

Le présent appareil est conforme

aux CNR d’Industrie Canada

applicables aux appareils

radio exempts de licence.

L’exploitaon est autorisée aux

deux condions suivantes : (1)

l’appareil ne doit pas produire

de brouillage, et (2) l’ulisateur

de l’appareil doit accepter

tout brouillage radioélectrique

subi, même si le brouillage est

suscepble d’en compromere le

fonconnement.

Contains IC ID: 8205A-SS001XNA

External probe

sold separately.

This device complies with Part 15 of the FCC Rules. Operaon is

subject to the following two condions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operaon.

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide

reasonable protecon against harmful interference in a

residenal installaon. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instrucons, may cause harmful

interference to radio communicaons. However, there is

no guarantee that interference will not occur in a parcular

installaon. If this equipment does cause harmful interference

to radio or television recepon, which can be determined

by turning the equipment o and on, the user is encouraged

to try to correct the interference by one of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separaon between the equipment

and receiver.

• Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV

technician for help.

FCC Cauon: Any changes or modicaons not expressly

approved by the party responsible for compliance could void

the user’s authority to operate this equipment.

This transmier must not be co-located or operang in

conjuncon with any other antenna or transmier.

FOR MOBILE DEVICE USAGE (>20cm/low power)

Radiaon Exposure Statement:

This equipment complies with FCC radiaon exposure limits

set forth for an uncontrolled environment. This equipment

should be installed and operated with minimum distance 20 cm

between the radiator & your body.

The SS-002-1 oers a congurable mix of any

three of the four internal sensors: Temperature,

Humidity, Barometric Pressure, Ambient Light, AND

one external sensor opon:

Thermocouple, RTD, or DIN (contact closure).

Seng Alarms

To congure the alarms in your SS-002 using SYNC,

follow these steps:

Step 1: Click the icon next to the input

you wish to set an alarm for.

Step 2: Set the parameters for your alarm and click

Save.

SYNC - Device Sengs

Users can perform funcons such as rmware

updates and factory resets of the SS-002 by

navigang to the Device Sengs tab of SYNC

conguraon soware.

Range Boost Mode

When the SS-002 (-NA) device is powered directly

by a micro USB 2.0, the Smart Sensor will also

enter a Range Boost mode which will enhance the

wireless range or coverage of the Smart Sensor up

to 3.2 km*.

*Clear line of sight. Actual range may vary depending on

environment.

SS-002 USB Powered Range Boost

WARRANTY/DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects

in materials and workmanship for a period of 13 months from

date of purchase. OMEGA’s WARRANTY adds an additional one (1)

month grace period to the normal one (1) year product warranty

to cover handling and shipping time. This ensures that OMEGA’s

customers receive maximum coverage on each product.

If the unit malfunctions, it must be returned to the factory for evalua-

tion. OMEGA’s Customer Service Department will issue an Authorized

Return (AR) number immediately upon phone or written request.

Upon examination by OMEGA, if the unit is found to be defective,

it will be repaired or replaced at no charge. OMEGA’s WARRANTY

does not apply to defects resulting from any action of the purchaser,

including but not limited to mishandling, improper interfacing, opera-

tion outside of design limits, improper repair, or unauthorized modifi-

cation. This WARRANTY is VOID if the unit shows evidence of having

been tampered with or shows evidence of having been damaged as a

result of excessive corrosion; or current, heat, moisture or vibration;

improper specification; misapplication; misuse or other operating

conditions outside of OMEGA’s control. Components in which wear

is not warranted, include but are not limited to contact points, fuses,

and triacs.

OMEGA is pleased to offer suggestions on the use of its vari-

ous products. However, OMEGA neither assumes responsibil-

ity for any omissions or errors nor assumes liability for any

damages that result from the use if its products in accordance

with information provided by OMEGA, either verbal or writ-

ten. OMEGA warrants only that the parts manufactured by

the company will be as specified and free of defects. OMEGA

MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF

ANY KIND WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT

THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING

ANY WARRANTY OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED.

LIMITATION OF LIABILITY: The remedies of purchaser set

forth herein are exclusive, and the total liability of OMEGA

with respect to this order, whether based on contract, warran-

ty, negligence, indemnification, strict liability or otherwise,

shall not exceed the purchase price of the component upon

which liability is based. In no event shall OMEGA be liable for

consequential, incidental or special damages.

CONDITIONS: Equipment sold by OMEGA is not intended to be used,

nor shall it be used: (1) as a “Basic Component” under 10 CFR 21 (NRC),

used in or with any nuclear installation or activity; or (2) in medical appli-

cations or used on humans. Should any Product(s) be used in or with

any nuclear installation or activity, medical application, used on humans,

or misused in any way, OMEGA assumes no responsibility as set forth

in our basic WARRANTY/DISCLAIMER language, and, additionally,

purchaser will indemnify OMEGA and hold OMEGA harmless from any

liability or damage whatsoever arising out of the use of the Product(s)

in such a manner.

RETURN REQUESTS/INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA

Customer Service Department. BEFORE RETURNING ANY

PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN

AUTHORIZED RETURN (AR) NUMBER FROM OMEGA’S CUSTOMER

SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING

DELAYS). The assigned AR number should then be marked on the

outside of the return package and on any correspondence.

FOR WARRANTY RETURNS,

please have the following

information available BEFORE

contacting OMEGA:

1. Purchase Order number

under which the product

was PURCHASED,

2. Model and serial number of the

product under warranty, and

3. Repair instructions and/or

specific problems relative

to the product.

FOR NON-WARRANTY REPAIRS,

consult OMEGA for current repair

charges. Have the following

information available BEFORE

contacting OMEGA:

1. Purchase Order number to cover

the COST of the repair or

calibration,

2. Model and serial number of the

product, and

3. Repair instructions and/or specific

problems relative to the product.

OMEGA’s policy is to make running changes, not model changes,

whenever an improvement is possible. This affords our customers

the latest in technology and engineering.

OMEGA is a trademark of OMEGA ENGINEERING, INC.

This document may not be copied, photocopied, reproduced,

translated, or reduced to any electronic medium or machine-readable

form, in whole or in part, without the prior written consent of OMEGA

ENGINEERING, INC.

omega.com [email protected]

The information contained in this document is believed to be correct,

but OMEGA accepts no liability for any errors it contains, and reserves

the right to alter specifications without notice.

Omega Engineering, Inc:

800 Connecticut Ave. Suite 5N01, Norwalk, CT 06854, USA

Toll-Free: 1-800-826-6342 (USA & Canada only)

Customer Service: 1-800-622-2378 (USA & Canada only)

Engineering Service: 1-800-872-9436 (USA & Canada only)

Tel: (203) 359-1660 Fax: (203) 359-7700

e-mail: [email protected]

For Other Locations Visit omega.com/worldwide

Omega Engineering,

GmbH:

Daimlerstrasse 26 75392

Deckenpfronn, Germany

Omega Engineering,

Limited:

1 Omega Drive, Northbank, Irlam

Manchester M44 5BD

United Kingdom

234

START HERE

Layer N SS-002 Overview

Important: The baery polarity is marked

inside the compartment. Promptly remove

dead baeries to prevent loss of data and

potenal damage due to leaking baeries.

External Sensor Pin 1 Pin 2 Pin 3

Thermocouple TC1 + TC1 - Not Used

RTD

2-Wire Color 1 Color 2 Short Pin 1

& Pin 3

3-Wire Color 1 Color 2 Color 1

4-Wire Color 1 Color 2 Color 1

Dry Contact Switch Not Used Common

Note: For RTD connecons, Pin 3 is the

excitaon constant current source.

For 2-Wire RTD connecons, a short copper

wire is needed form Pin 1 to Pin 3.

For 4-Wire RTD connecon, only connect one

“Color 2” wire at Pin 2. The second “Color 2”

wire needs to be cut.

Introducon

Use this Quick Start Guide to set up your Layer N

SS-002 TC and RTD Smart Sensor.

Materials

Included with your SS-002

• Layer N SS-002 unit

• Quick start guide

• 2x AA alkaline baeries

• Sub GHz Antenna

• Terminal block connector

Addional Materials Needed

• A Windows 7,8, 9, 10, or 11 OS PC or laptop with

Omega’s free SYNC conguraon soware

• A compable Layer N Gateway

• A Layer N Cloud account or a qualifying Omega

Enterprise Gateway license er (Pro, Business, or

Business Pro)

Oponal Materials

• External TC, RD, or Contact Closure

• Micro USB 2.0 (for SYNC conguraon)

• SYNC Conguraon soware

-Downloadable on the OMEGA website

Important: Do not power on the Layer N

Gateway or Smart Sensor before Gateway

registraon is complete.

SS-002 Hardware Setup

Step 1: Install the antenna to the side of the

connector on the SS-002 unit.

Step 2: Insert the 2x AA baeries into the baery

compartment located on the underside of

the SS-002 unit.

Before you Begin

Before you begin seng up your SS-002, ensure

you have created a Layer N Cloud or Omega

Enterprise Gateway account and registered the

Layer N Gateway that will be paired with the SS-002

device.

During the gateway setup process, the gateway will

automacally download the latest rmware and

re-boot. Once the gateway is registered and the

pairing buon LED is green you may connue with

the SS-002 installaon.

The Pairing Buon of the Smart Sensor will power up

to a solid orange LED light in the center of the pairing

buon indicang that the device has been successfully

powered on. Refer to the LED Status indicator table

below:

LED Color Status

Amber/Orange

(solid)

SS-002 is powered on; not connected

to a Gateway

Green (blinking

repeatedly) SS-002 is in Pairing Mode

Amber/Orange

(blinking

repeatedly)

SS-002 is reconnecng to a paired

Gateway

Green (ash

periodically) SS-002 is communicang to a Gateway

Green (solid) SS-002 is performing a radio rmware

update

Red (solid) The reset buon has been held for a

radio factory reset

Red and Green

(blinking) A password error has occurred

No Light The SS-002 is asleep or the baery is

drained

Pairing to your Layer N Gateway

Once the Pairing Buon displays a solid orange LED light

in the center of the pairing buon, your Smart Sensor is

ready to be connected to a Layer N Gateway. Pairing your

SS-002 with a Layer N Gateway is made easy with a one-

buon pairing system between the two devices.

Step 1: Push the pairing buon once on your

SS-002 unit. The LED status indicator will blink

green indicang the device is in Pairing Mode.

When the Smart Sensor has been successfully paired to

your Layer N Gateway, the green LEDs on both devices

will stop ashing within 2 minutes.

The Smart Sensor LED will periodically ash green each

me data is transmied to the gateway.

As measurements are transmied, you will begin to see

data appearing on the Layer N Cloud or OEG interface.

The transmission interval can be adjusted from the Layer

N Cloud Interface or from the OEG interface, depending

on which plaorm the Gateway is connected to.

Step 2: Quickly push the pairing buon on the Layer

N Gateway. The LED on the gateway will blink

green indicang the gateway is in Pairing Mode.

Once your SS-002 has successfully paired to your

registered Layer N Gateway, the SS-002 will appear

on the Layer N Cloud interface or the OEG interface

and begin transming data.

View Readings on Layer N Cloud or OEG

For addional informaon on the customizable

features made available through the micro USB

connector, connue to the secons tled Advanced

Conguraon with SYNC and Smart Sensor USB

Connector.

Sensor Mix Conguraon

To congure the sensor mix in your SS-002,

connect a micro USB 2.0 cable from your Smart

Sensor device to your PC or laptop running SYNC

conguraon soware.

Step 1: Once your device has been auto-detected

by SYNC, click the Type dropdown in the

Inputs interface.

Advanced Conguraon with SYNC

The SS-002 can be congured using SYNC

conguraon soware by connecng through the

micro USB 2.0 port. SYNC can be used to congure

alarms in the sensor, set device passwords, and

update rmware.

Note: SYNC conguraon soware is

downloadable on the OMEGA website.

The SS-002-0 oers a congurable choice of one

external thermocouple, RTD, or DIN (contact

closure).

234

START HERE

Layer N SS-002 Overview

Important: The baery polarity is marked

inside the compartment. Promptly remove

dead baeries to prevent loss of data and

potenal damage due to leaking baeries.

External Sensor Pin 1 Pin 2 Pin 3

Thermocouple TC1 + TC1 - Not Used

RTD

2-Wire Color 1 Color 2 Short Pin 1

& Pin 3

3-Wire Color 1 Color 2 Color 1

4-Wire Color 1 Color 2 Color 1

Dry Contact Switch Not Used Common

Note: For RTD connecons, Pin 3 is the

excitaon constant current source.

For 2-Wire RTD connecons, a short copper

wire is needed form Pin 1 to Pin 3.

For 4-Wire RTD connecon, only connect one

“Color 2” wire at Pin 2. The second “Color 2”

wire needs to be cut.

Introducon

Use this Quick Start Guide to set up your Layer N

SS-002 TC and RTD Smart Sensor.

Materials

Included with your SS-002

• Layer N SS-002 unit

• Quick start guide

• 2x AA alkaline baeries

• Sub GHz Antenna

• Terminal block connector

Addional Materials Needed

• A Windows 7,8, 9, 10, or 11 OS PC or laptop with

Omega’s free SYNC conguraon soware

• A compable Layer N Gateway

• A Layer N Cloud account or a qualifying Omega

Enterprise Gateway license er (Pro, Business, or

Business Pro)

Oponal Materials

• External TC, RD, or Contact Closure

• Micro USB 2.0 (for SYNC conguraon)

• SYNC Conguraon soware

-Downloadable on the OMEGA website

Important: Do not power on the Layer N

Gateway or Smart Sensor before Gateway

registraon is complete.

SS-002 Hardware Setup

Step 1: Install the antenna to the side of the

connector on the SS-002 unit.

Step 2: Insert the 2x AA baeries into the baery

compartment located on the underside of

the SS-002 unit.

Before you Begin

Before you begin seng up your SS-002, ensure

you have created a Layer N Cloud or Omega

Enterprise Gateway account and registered the

Layer N Gateway that will be paired with the SS-002

device.

During the gateway setup process, the gateway will

automacally download the latest rmware and

re-boot. Once the gateway is registered and the

pairing buon LED is green you may connue with

the SS-002 installaon.

The Pairing Buon of the Smart Sensor will power up

to a solid orange LED light in the center of the pairing

buon indicang that the device has been successfully

powered on. Refer to the LED Status indicator table

below:

LED Color Status

Amber/Orange

(solid)

SS-002 is powered on; not connected

to a Gateway

Green (blinking

repeatedly) SS-002 is in Pairing Mode

Amber/Orange

(blinking

repeatedly)

SS-002 is reconnecng to a paired

Gateway

Green (ash

periodically) SS-002 is communicang to a Gateway

Green (solid) SS-002 is performing a radio rmware

update

Red (solid) The reset buon has been held for a

radio factory reset

Red and Green

(blinking) A password error has occurred

No Light The SS-002 is asleep or the baery is

drained

Pairing to your Layer N Gateway

Once the Pairing Buon displays a solid orange LED light

in the center of the pairing buon, your Smart Sensor is

ready to be connected to a Layer N Gateway. Pairing your

SS-002 with a Layer N Gateway is made easy with a one-

buon pairing system between the two devices.

Step 1: Push the pairing buon once on your

SS-002 unit. The LED status indicator will blink

green indicang the device is in Pairing Mode.

When the Smart Sensor has been successfully paired to

your Layer N Gateway, the green LEDs on both devices

will stop ashing within 2 minutes.

The Smart Sensor LED will periodically ash green each

me data is transmied to the gateway.

As measurements are transmied, you will begin to see

data appearing on the Layer N Cloud or OEG interface.

The transmission interval can be adjusted from the Layer

N Cloud Interface or from the OEG interface, depending

on which plaorm the Gateway is connected to.

Step 2: Quickly push the pairing buon on the Layer

N Gateway. The LED on the gateway will blink

green indicang the gateway is in Pairing Mode.

Once your SS-002 has successfully paired to your

registered Layer N Gateway, the SS-002 will appear

on the Layer N Cloud interface or the OEG interface

and begin transming data.

View Readings on Layer N Cloud or OEG

For addional informaon on the customizable

features made available through the micro USB

connector, connue to the secons tled Advanced

Conguraon with SYNC and Smart Sensor USB

Connector.

Sensor Mix Conguraon

To congure the sensor mix in your SS-002,

connect a micro USB 2.0 cable from your Smart

Sensor device to your PC or laptop running SYNC

conguraon soware.

Step 1: Once your device has been auto-detected

by SYNC, click the Type dropdown in the

Inputs interface.

Advanced Conguraon with SYNC

The SS-002 can be congured using SYNC

conguraon soware by connecng through the

micro USB 2.0 port. SYNC can be used to congure

alarms in the sensor, set device passwords, and

update rmware.

Note: SYNC conguraon soware is

downloadable on the OMEGA website.

The SS-002-0 oers a congurable choice of one

external thermocouple, RTD, or DIN (contact

closure).

234

START HERE

Layer N SS-002 Overview

Important: The baery polarity is marked

inside the compartment. Promptly remove

dead baeries to prevent loss of data and

potenal damage due to leaking baeries.

External Sensor Pin 1 Pin 2 Pin 3

Thermocouple TC1 + TC1 - Not Used

RTD

2-Wire Color 1 Color 2 Short Pin 1

& Pin 3

3-Wire Color 1 Color 2 Color 1

4-Wire Color 1 Color 2 Color 1

Dry Contact Switch Not Used Common

Note: For RTD connecons, Pin 3 is the

excitaon constant current source.

For 2-Wire RTD connecons, a short copper

wire is needed form Pin 1 to Pin 3.

For 4-Wire RTD connecon, only connect one

“Color 2” wire at Pin 2. The second “Color 2”

wire needs to be cut.

Introducon

Use this Quick Start Guide to set up your Layer N

SS-002 TC and RTD Smart Sensor.

Materials

Included with your SS-002

• Layer N SS-002 unit

• Quick start guide

• 2x AA alkaline baeries

• Sub GHz Antenna

• Terminal block connector

Addional Materials Needed

• A Windows 7,8, 9, 10, or 11 OS PC or laptop with

Omega’s free SYNC conguraon soware

• A compable Layer N Gateway

• A Layer N Cloud account or a qualifying Omega

Enterprise Gateway license er (Pro, Business, or

Business Pro)

Oponal Materials

• External TC, RD, or Contact Closure

• Micro USB 2.0 (for SYNC conguraon)

• SYNC Conguraon soware

-Downloadable on the OMEGA website

Important: Do not power on the Layer N

Gateway or Smart Sensor before Gateway

registraon is complete.

SS-002 Hardware Setup

Step 1: Install the antenna to the side of the

connector on the SS-002 unit.

Step 2: Insert the 2x AA baeries into the baery

compartment located on the underside of

the SS-002 unit.

Before you Begin

Before you begin seng up your SS-002, ensure

you have created a Layer N Cloud or Omega

Enterprise Gateway account and registered the

Layer N Gateway that will be paired with the SS-002

device.

During the gateway setup process, the gateway will

automacally download the latest rmware and

re-boot. Once the gateway is registered and the

pairing buon LED is green you may connue with

the SS-002 installaon.

The Pairing Buon of the Smart Sensor will power up

to a solid orange LED light in the center of the pairing

buon indicang that the device has been successfully

powered on. Refer to the LED Status indicator table

below:

LED Color Status

Amber/Orange

(solid)

SS-002 is powered on; not connected

to a Gateway

Green (blinking

repeatedly) SS-002 is in Pairing Mode

Amber/Orange

(blinking

repeatedly)

SS-002 is reconnecng to a paired

Gateway

Green (ash

periodically) SS-002 is communicang to a Gateway

Green (solid) SS-002 is performing a radio rmware

update

Red (solid) The reset buon has been held for a

radio factory reset

Red and Green

(blinking) A password error has occurred

No Light The SS-002 is asleep or the baery is

drained

Pairing to your Layer N Gateway

Once the Pairing Buon displays a solid orange LED light

in the center of the pairing buon, your Smart Sensor is

ready to be connected to a Layer N Gateway. Pairing your

SS-002 with a Layer N Gateway is made easy with a one-

buon pairing system between the two devices.

Step 1: Push the pairing buon once on your

SS-002 unit. The LED status indicator will blink

green indicang the device is in Pairing Mode.

When the Smart Sensor has been successfully paired to

your Layer N Gateway, the green LEDs on both devices

will stop ashing within 2 minutes.

The Smart Sensor LED will periodically ash green each

me data is transmied to the gateway.

As measurements are transmied, you will begin to see

data appearing on the Layer N Cloud or OEG interface.

The transmission interval can be adjusted from the Layer

N Cloud Interface or from the OEG interface, depending

on which plaorm the Gateway is connected to.

Step 2: Quickly push the pairing buon on the Layer

N Gateway. The LED on the gateway will blink

green indicang the gateway is in Pairing Mode.

Once your SS-002 has successfully paired to your

registered Layer N Gateway, the SS-002 will appear

on the Layer N Cloud interface or the OEG interface

and begin transming data.

View Readings on Layer N Cloud or OEG

For addional informaon on the customizable

features made available through the micro USB

connector, connue to the secons tled Advanced

Conguraon with SYNC and Smart Sensor USB

Connector.

Sensor Mix Conguraon

To congure the sensor mix in your SS-002,

connect a micro USB 2.0 cable from your Smart

Sensor device to your PC or laptop running SYNC

conguraon soware.

Step 1: Once your device has been auto-detected

by SYNC, click the Type dropdown in the

Inputs interface.

Advanced Conguraon with SYNC

The SS-002 can be congured using SYNC

conguraon soware by connecng through the

micro USB 2.0 port. SYNC can be used to congure

alarms in the sensor, set device passwords, and

update rmware.

Note: SYNC conguraon soware is

downloadable on the OMEGA website.

The SS-002-0 oers a congurable choice of one

external thermocouple, RTD, or DIN (contact

closure).

234

START HERE

Layer N SS-002 Overview

Important: The baery polarity is marked

inside the compartment. Promptly remove

dead baeries to prevent loss of data and

potenal damage due to leaking baeries.

External Sensor Pin 1 Pin 2 Pin 3

Thermocouple TC1 + TC1 - Not Used

RTD

2-Wire Color 1 Color 2 Short Pin 1

& Pin 3

3-Wire Color 1 Color 2 Color 1

4-Wire Color 1 Color 2 Color 1

Dry Contact Switch Not Used Common

Note: For RTD connecons, Pin 3 is the

excitaon constant current source.

For 2-Wire RTD connecons, a short copper

wire is needed form Pin 1 to Pin 3.

For 4-Wire RTD connecon, only connect one

“Color 2” wire at Pin 2. The second “Color 2”

wire needs to be cut.

Introducon

Use this Quick Start Guide to set up your Layer N

SS-002 TC and RTD Smart Sensor.

Materials

Included with your SS-002

• Layer N SS-002 unit

• Quick start guide

• 2x AA alkaline baeries

• Sub GHz Antenna

• Terminal block connector

Addional Materials Needed

• A Windows 7,8, 9, 10, or 11 OS PC or laptop with

Omega’s free SYNC conguraon soware

• A compable Layer N Gateway

• A Layer N Cloud account or a qualifying Omega

Enterprise Gateway license er (Pro, Business, or

Business Pro)

Oponal Materials

• External TC, RD, or Contact Closure

• Micro USB 2.0 (for SYNC conguraon)

• SYNC Conguraon soware

-Downloadable on the OMEGA website

Important: Do not power on the Layer N

Gateway or Smart Sensor before Gateway

registraon is complete.

SS-002 Hardware Setup

Step 1: Install the antenna to the side of the

connector on the SS-002 unit.

Step 2: Insert the 2x AA baeries into the baery

compartment located on the underside of

the SS-002 unit.

Before you Begin

Before you begin seng up your SS-002, ensure

you have created a Layer N Cloud or Omega

Enterprise Gateway account and registered the

Layer N Gateway that will be paired with the SS-002

device.

During the gateway setup process, the gateway will

automacally download the latest rmware and

re-boot. Once the gateway is registered and the

pairing buon LED is green you may connue with

the SS-002 installaon.

The Pairing Buon of the Smart Sensor will power up

to a solid orange LED light in the center of the pairing

buon indicang that the device has been successfully

powered on. Refer to the LED Status indicator table

below:

LED Color Status

Amber/Orange

(solid)

SS-002 is powered on; not connected

to a Gateway

Green (blinking

repeatedly) SS-002 is in Pairing Mode

Amber/Orange

(blinking

repeatedly)

SS-002 is reconnecng to a paired

Gateway

Green (ash

periodically) SS-002 is communicang to a Gateway

Green (solid) SS-002 is performing a radio rmware

update

Red (solid) The reset buon has been held for a

radio factory reset

Red and Green

(blinking) A password error has occurred

No Light The SS-002 is asleep or the baery is

drained

Pairing to your Layer N Gateway

Once the Pairing Buon displays a solid orange LED light

in the center of the pairing buon, your Smart Sensor is

ready to be connected to a Layer N Gateway. Pairing your

SS-002 with a Layer N Gateway is made easy with a one-

buon pairing system between the two devices.

Step 1: Push the pairing buon once on your

SS-002 unit. The LED status indicator will blink

green indicang the device is in Pairing Mode.

When the Smart Sensor has been successfully paired to

your Layer N Gateway, the green LEDs on both devices

will stop ashing within 2 minutes.

The Smart Sensor LED will periodically ash green each

me data is transmied to the gateway.

As measurements are transmied, you will begin to see

data appearing on the Layer N Cloud or OEG interface.

The transmission interval can be adjusted from the Layer

N Cloud Interface or from the OEG interface, depending

on which plaorm the Gateway is connected to.

Step 2: Quickly push the pairing buon on the Layer

N Gateway. The LED on the gateway will blink

green indicang the gateway is in Pairing Mode.

Once your SS-002 has successfully paired to your

registered Layer N Gateway, the SS-002 will appear

on the Layer N Cloud interface or the OEG interface

and begin transming data.

View Readings on Layer N Cloud or OEG

For addional informaon on the customizable

features made available through the micro USB

connector, connue to the secons tled Advanced

Conguraon with SYNC and Smart Sensor USB

Connector.

Sensor Mix Conguraon

To congure the sensor mix in your SS-002,

connect a micro USB 2.0 cable from your Smart

Sensor device to your PC or laptop running SYNC

conguraon soware.

Step 1: Once your device has been auto-detected

by SYNC, click the Type dropdown in the

Inputs interface.

Advanced Conguraon with SYNC

The SS-002 can be congured using SYNC

conguraon soware by connecng through the

micro USB 2.0 port. SYNC can be used to congure

alarms in the sensor, set device passwords, and

update rmware.

Note: SYNC conguraon soware is

downloadable on the OMEGA website.

The SS-002-0 oers a congurable choice of one

external thermocouple, RTD, or DIN (contact

closure).
