Omega Speedmaster Skywalker X-33 User manual

OPERATING INSTRUCTIONS

1
English
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Special recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
OMEGA International Warranty (valid for U.S.A. only). . . . . . . . . . . . . . . . . . . . . . . . . 4
OMEGA International Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
UTC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TIME ZONES T1 AND T2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
ALARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
PET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
CHRONOGRAPH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
CHIMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
SPECIAL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
EXAMPLE 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
EXAMPLE 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
PICTOGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

2
INTRODUCTION
Special recommendationS
What must I do to ensure that my OMEGA watch provides me with excellent service for many years?
Magnetic elds : avoid placing your watch on computers, loudspeakers or refrigerators, since they
generate powerful magnetic elds.
Swimming in the sea : always rinse your watch with fresh water afterwards.
Shocks : whether physical, thermal or other, avoid them.
Crown : push it back against the case into the wearing position to prevent moisture from entering the
case.
Cleaning : for metal bracelets, rubber straps and water-resistant cases, use a toothbrush and soapy
water for cleaning and dry with a soft cloth.
Chemical products : avoid direct contact with solvents, detergents, perfumes, cosmetics etc., since
they may damage the bracelet, case or gaskets.
Temperature : avoid exposure to extreme temperatures (greater than 60°C, or 140°F, less than 0°C, or
32°F) or extreme temperature changes.
Water-resistance : a watch’s water-resistance cannot be permanently guaranteed. It may notably be
affected by the ageing of gaskets or by an accidental shock to the crown. As stipulated in our service
instructions, we recommend you have the water resistance of your watch checked once a year by an
authorised OMEGA Service Centre.
Chronograph push-pieces : do not operate chronograph pushers under water in order to prevent water
entering the mechanism.

3
English
What are the service intervals ?
Like any precision instrument, a watch needs regular servicing to ensure that it functions perfectly. We
cannot indicate the frequency of such work, since it depends entirely on the model, the climate and the
owner's individual care of the watch. As a general rule, a watch should be serviced every 4 to 5 years,
depending on the conditions in which it is used.
Who should I contact for a maintenance service or battery replacement ?
We recommend that you contact an approved OMEGA service centre or authorised OMEGA retailer.
They are equipped with the tools and apparatus required to carry out the work and the necessary
checks in a professional manner. Furthermore, these entities can guarantee that their work is carried out
in accordance with OMEGA's strict quality standards.
A worn-out battery should be replaced immediately in order to reduce the risk of leakage and
consequent damage to the movement. The type of battery is dened on the guarantee card enclosed
with your watch.
environmental protection
Collection and treatment of end of life Quartz watches* This symbol indicates that this product
should not be disposed with household waste. It has to be returned to a local authorised
collection system. By following this procedure you will contribute to the protection of the
environment and human health. The recycling of the materials will help to conserve natural resources.
* valid in EU member states and in any countries with corresponding legislation.

4
omeGa international Warranty (valid for U.S.a. only)
introdUction
Your OMEGA®watch is warranted by OMEGA SA* FOR A PERIOD OF TWENTY-FOUR (24) MONTHS,
FROM THE DATE OF PURCHASE under the terms and conditions of this warranty. The international
OMEGA warranty covers material and manufacturing defects existing at the time of delivery of the
purchased OMEGA watch (“defects”). The warranty only comes into force if the warranty certicate
is dated, fully and correctly completed and stamped by an ofcial OMEGA** dealer (“valid warranty
certicate”). During the warranty period and by presenting the valid warranty certicate, you will have
the right to have any defect repaired free of charge. In the event that repairs are unable to restore
the normal conditions of use of your OMEGA watch, OMEGA SA guarantees its replacement by an
OMEGA watch of identical or similar charateristics. The warranty for the replacement watch ends
twenty-four (24) months, after the date of purchase of the replaced watch.
thiS manUfactUrer’SWarranty doeS not cover :
• the life of the battery.
• normal wear and tear and ageing (for example scratched crystal; alteration of the colour and/or
material of non metallic straps and chains, such as leather, textile, rubber).
• any damage on any part of the watch resulting from abnormal/abusive use, lack of care, negligence,
accidents (knocks, dents, crushing, broken crystal, etc.), incorrect use of the watch and non-
observance of the operating instructions provided by OMEGA SA.
• the OMEGA watch handled by non-authorized persons (for example for battery replacement,
service or repair) or which has been altered in its original condition beyond OMEGA SA’s control.

5
English
ALL APPLICABLE IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE GIVEN TO YOU BY LAW ARE
HEREBYLIMITEDINDURATIONTOTHEDURATIONOFTHISWARRANTY.UNDERNOCIRCUMSTANCES
WILL OMEGA SA BE LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND.
Some states do not allow limitations on how long implied warranties last, or exclusions or limitations of
incidental or consequential damages, so exclusions or limitations mentioned may not apply to you. This
warranty gives you specic legal rights and you may also have other rights which may vary from state
to state.
OMEGASA’sOBLIGATIONISSTRICTLYLIMITEDTOREPAIRORREPLACEMENTASEXPRESSLYSTATED
IN THIS LIMITED WARRANTY. YOUR OFFICIAL OMEGA DEALER CARRIES SOLE RESPONSIBILITY
FOR ANY OTHER GUARANTEES.
The OMEGA customer service ensures the perfect working order of your OMEGA watch. If your watch
needs maintenance, rely on an ofcial OMEGA dealer or an authorized OMEGA Service Center. They
can guarantee service according to OMEGA SA’s standards.
* OMEGA SA
Rue Stämpi 96, CH-2500 Bienne 4
** OMEGA SA Specialist Dealer in EU Countries
OMEGA®and ®are registered trademarks

6
omeGa international Warranty
introdUction
Your OMEGA®watch is warranted by OMEGA SA* for a period of twenty-four (24) months, from the
date of purchase under the terms and conditions of this warranty. The international OMEGA warranty
covers material and manufacturing defects existing at the time of delivery of the purchased OMEGA
watch (“defects”). The warranty only comes into force if the warranty certicate is dated, fully and
correctly completed and stamped by an ofcial OMEGA** dealer (“valid warranty certicate”).
During the warranty period and by presenting the valid warranty certicate, you will have the right
to have any defect repaired free of charge. In the event that repairs are unable to restore the normal
conditions of use of your OMEGA watch, OMEGA SA guarantees its replacement by an OMEGA watch
of identical or similar characteristics. The warranty for the replacement watch ends twenty-four (24)
months, after the date of purchase of the replaced watch.
the above manUfactUrer’SWarranty :
• is independent of any warranty that may be provided by the seller, for which he carries sole
responsibility;
• does not affect the purchaser’s rights against the seller nor any other mandatory statutory rights the
purchaser may have against the seller.
The OMEGA customer service ensures the perfect maintenance of your OMEGA watch. If your watch
needs attention, rely on an ofcial OMEGA dealer or an authorised OMEGA Service Centre. They can
guarantee service according to OMEGA SA’s standards.

7
English
thiS manUfactUrer’SWarranty doeS not cover :
• the life of the battery.
• normal wear and tear and ageing (for example scratched crystal; alteration of the colour and/or
material of non metallic straps and chains, such as leather, textile, rubber).
• any damage on any part of the watch resulting from abnormal/abusive use, lack of care, negligence,
accidents (knocks, dents, crushing, broken crystal, etc.), incorrect use of the watch and non-
observance of the operating instructions provided by OMEGA SA.
• any consequential or indirect damage resulting from the use, failure to operate, defects or lack of
precision of the OMEGA watch.
• the OMEGA watch handled by non-authorised persons (for example for battery replacement,
service or repair) or which has been altered in its original condition beyond OMEGA SA’s control.
Any further claim against OMEGA SA, for example for damages additional to the above described
warranty is expressly excluded, except mandatory statutory rights the purchaser may have against the
manufacturer.
* OMEGA SA
Rue Stämpi 96, CH-2500 Bienne 4
** OMEGA SA Specialist Dealer in EU Countries
OMEGA®and ®are registered trademarks

8
DESCRIPTION diSplayS
The information contained in this document is for the standard use of the SPEEDMASTER
SKYWALKER X-33 model. For further information, consult the Internet site
(www.omegawatches.com/skywalker).
The SPEEDMASTER SKYWALKER X-33 watch was designed in collaboration with the European Space
Agency (ESA) to enable astronauts to manage the various stages of their missions.
In addition to the usual watch functions, the SPEEDMASTER SKYWALKER X-33 has special functions for
programming the various phases of a mission or a project.
+/- indicator
- : Future event
+ : Past event
Day indicator
Function indicator
See pages 12 to 2412 to 24to 2424
Hour indicator
Month indicator
Year indicator
Or hundredths for the chronograph
function
Seconds indicator
Minute indicator

9
English
DESCRIPTION pUSherS and croWn
Favourite function
See page 2727
Display
Backlighting
Clear the hands
Stop chime
Programming
Access / exit programming
Chrono / timer functions
Start / stop
Programming
Increase the setting value
Display and programming
See inset below
Chrono / timer functions
Reset to zero, split, reset to initial value
Programming
Decrease the setting value
Press once
Press twice
Press and hold
(~ 3 seconds)
Display
Access the next function
Programming
Access the next setting
Display
Access the function groups
Display
Access the second page of the
selected function
Programming
Activate energy saving mode
(see page 26)26))
General information Using the crown

10
USE General information
naviGatinG betWeen GroUpS and paGeS
The functions are separated into two groups (see illustration opposite).
Pressing once on the crown brings up the next function.
Pressing and holding brings up the second group of functions.
Certain functions are displayed over two pages. Pressing twice on the crown brings up page 2 if it is
available (see illustration opposite (1/2)).
The display returns to page 1 after 10 seconds, or by pressing once on the crown.
proGramminG mode
In programming mode, the hands move so as to clear the displays.
Programming exited automatically after 20 seconds without activity.
When a chime sounds, the display ashes and brings up the function concerned.
For programmable functions, when the selection is used, the function is deactivated and the
programming is erased.
To better understand the watch functionalities (see the examples described on pages 28 and 30).28 and 30).and 30).30).).

11
English
1212
12
12
12
12
12
12
12
12
USE naviGatinG betWeen fUnctionS
Universal Time Coordinated
International reference time
See page 1212
Time T1
Time defined by the user
See page 1414
Time T2
Time defined by the user
See page 1414
Mission Elapsed Time
Mission reference time
See page 1818
Chronograph
Chronograph function
See page 2424
TIMER
Countdown function
See page 2222
Phase Elapsed Time 1
First milestone reference
See page 2020
Phase Elapsed Time 2
Second milestone reference
See page 2020
Phase Elapsed Time 3
Third milestone reference
See page 2020
Alarm 1
First alarm
See page 1616
Alarm 2
Second alarm
See page 1616
Alarm 3
Third alarm
See page 1616

12
UTC diSplay
Universal time display (Universal Time Coordinated).
This time was previously known as GMT, and this name is still used in certain elds.
The and functions (see page 14) are set in relation to14) are set in relation to) are set in relation to .
Page 1 Page 2
UTC day number
As per standard ISO 8601 Current date
Perpetual calendar
Selected function
Current time
(24h mode)
Alternating between:
- day of the week and
- week number
Current time
(24h mode)

13
English
UTC proGramminG
Select function
+ increment
- increment
Enter programming
Conrm and move to the
next setting(1)
Exit programming
Because is the time base used for
all the other watch functions, it must be
programmed first.
(1) Follow the same procedure for the settings
below:
• year, month, day;
• hour, minute, second.

14
TIME ZONES T1 AND T2 diSplay
is used for local time. The hands continuously display time.
is used for the second time zone. is not displayed with the hands.
To set and , only the time difference from needs to be programmed. So the
time must be set before programming and .
Page 1 Page 2
Current date
Perpetual calendar
Number of day of the year
As per standard ISO 8601
Selected function
or
Current time
(24h mode)
Alternating between:
- day of the week and
- week number
Current time
(24h mode)

15
English
TIME ZONES T1 AND T2 proGramminG
Select function or
+ increment (2)
- increment (2)
Enter programming
Exit programming
Conrm and move to
the next setting(1)
(1) Follow the same procedure for the settings
below:
• hour, minute.
(2) It is possible to programme the hour in 1-hour
intervals, and the minute in 15-minute intervals.
The programming consists of dening the
time difference between the desired time
and .
During programming, the " " or " " sign
above the display indicates that the time
difference from is positive or negative.

16
ALARM diSplay
Three alarms are available: , and . They all work the same way.
(1) The reference time may be , or .
(2) The alarm sounds for each possible occurrence. For example, if you only set the chime time, without
incorporating the date or day, the alarm will sound every day at the set time.
For information about the chimes see page 25.25..
Page 2Page 1
Alarm status:
: activated
: deactivated
Next alarm activation date(2)
Selected function
, ,
Programmed alarm
time
Alternating between:
- day of next activation(2) and
- reference time(1)
Programmed alarm time

17
English
ALARM proGramminG
Select function
or or Select function
or or
+ increment
- increment
Conrm and move to
the next setting(1)
Enter programming
Exit programming
Activating the alarm
Activate/deactivate the
alarm
(1) Follow the same procedure for the settings
below:
• reference time , , ;
• year, month, day;
• hour, minute, second;
• day of the week.

18
MET diSplay
"Mission Elapsed Time"
This function displays the remaining time ( ) or elapsed time ( ) since the start of the mission
(see pages 26 and 30 for examples).26 and 30 for examples).and 30 for examples).30 for examples).for examples).
(1) If the mission start time has passed, the sign at the top of the display turns to " " and the time
continues to be counted from the mission time.
(2) The reference time may be , or .
For information about the chimes see page 2525.
Page 2Page 1 Mission date
Mission situation indicator
in time(1):
- : Future event
+ : Past event
Reference time(2)
Selected function
Mission time
Remaining/elapsed
time
Until/since the programmed
deadline
Number of days
Until/since the programmed
deadline

19
English
MET proGramminG
Select function
+ increment
- increment
Conrm and move to
the next setting(1)
Enter programming
Exit programming
(1) Follow the same procedure for the settings
below:
• reference time , , ;
• year, month, day;
• hour, minute, second.
The function can be
programmed up to a countdown
of 999 days, 23 hours, 59 minutes,
and 59 seconds.
The " " sign indicates that the event is in
the future. The " " sign indicates that the
event is in the past.
