Omega Speedmaster X-33 Marstimer User manual

Fabricant / Manufacturer / Hersteller
OMEGA SA
Rue Jakob-Stämpi 96
CH-2502 Bienne
Switzerland

1
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Special recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Environmental protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OMEGA INTERNATIONAL WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PRESENTATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Pushers and crown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Navigation and programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Navigation in the functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
FUNCTIONS
UTC - Universal Time Coordinated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
T1 & T2 - Time zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
MTC - Martian Time Coordinated. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
M1 & M2 - Martian time zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
MET - Mission Elapsed Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
PET (PE1, PE2 & PE3) - Phase Elapsed Time . . . . . . . . . . . . . . . . . . . . . . . . . 29
AL1, AL2 & AL3 - Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
CHR - Chronograph . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
TMR - Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
STE / STM - True Solar Time on Earth and Mars . . . . . . . . . . . . . . . . . . . . . . . 39
Special functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

2
English
CHIMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
MISSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
PICTOGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

3
The Speedmaster X-33 Marstimer was specially designed in collaboration with the European Space
Agency (ESA) for managing and following missions to Mars.
The various functions will enable you to follow the stages of such a mission, from take-off to landing on
Mars, and tell you the local time at the rover's location on Mars, as well as the number of sols(1) elapsed
since landing. With the Speedmaster X-33 Marstimer, you can also use the functions in everyday life to
manage the stages of a project or trip, for example.
The Speedmaster X-33 Marstimer is manufactured under licence from the European Space Agency
(ESA), and is protected by the patent below:
• Title ELECTRONIC WATCH FOR SPACE AND/OR SURFACE EXPLORATION
• Application no. PCT/EP2020/061140
• Publicationno.  WO2021/213640A1
The European Space Agency (ESA) is an intergovernmental organisation, and as such, is not
involved in the manufacture and/or marketing of the Speedmaster X-33 Marstimer.
(1) A sol is a Martian day, which lasts 24 hours, 39 minutes and 35.244 seconds.

4
English
INTRODUCTION SPECIAL RECOMMENDATIONS
What do I need to do to make sure that my OMEGA watch will work perfectly for many years to come?
Magneticelds:avoid placing your watch on a magnet, speaker, refrigerator or electronic
tablet case, since they can generate powerful magnetic elds that can disrupt your
timepiece.
Bathing in the sea: always rinse your watch in fresh water afterwards.
Impacts: avoid exposing your watch to mechanical or any other impacts, as well as thermal
shocks.
Crown: push the crown back into the neutral position to prevent water from penetrating the
mechanism.
Cleaning: for metal bracelets, rubber straps and water-resistant cases, use a toothbrush
and soapy water for cleaning, and a soft cloth for drying.
Chemicals: avoid direct contact with solvents, detergents, perfumes, cosmetics, mosquito
repellents, etc., since they can damage the wristlet, case or gaskets.

5
Temperatures: avoid exposing your watch to extreme temperatures (higher than 60°C or
140°F and lower than 0°C or 32°F), or to extreme variations.
Water resistance: the absolute water resistance of a watch cannot be guaranteed forever.
In particular, it can be affected by ageing of the gaskets, or by an accidental impact on the
crown. As stipulated in our service instructions, we recommend having your watch's water
resistance tested once a year by an approved OMEGA service centre.
Pushers: do not operate the pushers underwater, to prevent water from penetrating the
mechanism.
Different strap sizes: For leather, rubber and fabric straps, there are various sizes available
from your OMEGA point of sale, other approved points of sale, or from omegawatches.com.
Bracelet length adjustment: you can visit an OMEGA point of sale or approved service
centre to have the bracelet length adjusted to your wrist. The specialists will measure your
wrist circumference, and provide guidance to optimise the wearing comfort of your watch.
What are the intervals between services?
Like any precision instrument, a watch requires regular servicing to ensure it operates
perfectly. We cannot specify the frequency of this operation, since it is entirely dependent
on the model, climate and care that each owner takes with their watch. As a general rule,
a watch should be serviced every 5 to 8 years, according to the conditions under which it
is used.

6
English
Who should I contact for any battery service or replacement operation?
We recommend contacting an approved OMEGA service centre or an authorised OMEGA
dealer. They will have the tools and equipment required to undertake this work, and perform
the necessary checks in a professional manner. In addition, these specialists can guarantee
that their work will comply with the strict quality standards applied and stipulated by
OMEGA.
A drained battery must be replaced as quickly as possible, to prevent the risk of leakages,
which can damage the movement. The battery type is stated on the warranty card
accompanying your watch.
Important information about lithium button batteries:
WARNING
KEEP THE BATTERY OUT OF REACH OF CHILDREN
Swallowing can lead to chemical burns, perforation of soft tissue and death. Severe burns can occur
within two hours of ingestion. If swallowed, seek medical attention immediately.

7
EnvironmEntal protEction
Collection and processing of quartz watches at their end of life*
This symbol indicates that this product must not be disposed of in household waste. It must
be taken to an approved collection point. By applying this procedure, you will contribute
to protecting the environment and human health. Recycling of materials will help conserve
natural resources.
* applicable in European Community Members States, and in countries with comparable
legislation.

8
English
OMEGA INTERNATIONAL WARRANTY
(Valid for U.S.A. only)
OMEGA SA* GUARANTEES YOUR WATCH FOR SIXTY (60) MONTHS UNDER THE TERMS AND
CONDITIONS OF THIS WARRANTY, STARTING FROM THE DATE OF PURCHASE, FOR ALL OMEGA*
WATCHES PURCHASED AS OF 1 JULY 2018.
The international OMEGA warranty covers material and manufacturing defects existing at the time
of the purchase of the OMEGA watch ("defects"). The warranty only comes into force if the warranty
certicate is dated, fully and correctly completed and stamped by an ofcial OMEGA dealer ("valid
warranty certicate").
During the warranty period and by presenting the valid warranty certicate, you will have the right to
have any defect repaired free of charge. In the event that repairs are improper to restore the normal
conditions of use of your OMEGA watch, OMEGA SA guarantees its replacement by an OMEGAwatch
of identical or similar characteristics. For all watches purchased as of 1 July 2018, the warranty for the
replacement watch ends sixty (60) months after the date of purchase of the replaced watch.
this manufacturEr’swarranty doEs not covEr:
• The life of the battery.
• Normal wear and tear and ageing (for example scratched crystal; alteration of the colour and/or
material of non metallic straps and chains, such as leather, textile, rubber).
• Any damage on any part of the watch resulting from abnormal/ abusive use, lack of care,
negligence, accidents (knocks, dents, crushing, broken crystal, etc.), incorrect use of the watch and
nonobservance of the operating instructions provided by OMEGA SA.
• The OMEGA watch handled by non-authorized persons (for example for battery replacement,
service or repair) or which has been altered in its original condition beyond OMEGA SA’s control.

9
ALL APPLICABLE IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE GIVEN TO YOU BY LAW ARE
HEREBYLIMITEDINDURATIONTO THEDURATIONOFTHISWARRANTY.UNDERNOCIRCUMSTANCES
WILL OMEGA SA BE LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND.
Some states do not allow limitations on how long implied warranties last, or exclusions or limitations of
incidental or consequential damages, so exclusions or limitations mentioned may not apply to you. This
warranty gives you specic legal rights and you may also have other rights which may vary from state
to state.
OMEGA SA’s OBLIGATION IS STRICTLY LIMITED TO REPAIR OR REPLACEMENT AS EXPRESSLY
STATED IN THIS LIMITED WARRANTY. YOUR AUTHORISED OMEGA RETAILER CARRIES SOLE
RESPONSIBILITY FOR ANY OTHER GUARANTEES.
The OMEGA customer service ensures the perfect working order of your OMEGA watch. If your watch
needs maintenance, rely on an authorised OMEGA retailer or an authorized OMEGA Service Center
as set forth on the OMEGA website: they can guarantee service according to OMEGA SA’s standards.
* OMEGA SA
Rue Jakob-Stämpi 96
CH-2502 Bienne
OMEGA®and ®are registered trademarks

10
English
OMEGA INTERNATIONAL WARRANTY
OMEGA SA* guarantees your watch for sixty (60) months under the terms and conditions of this
warranty, starting from the date of purchase, for all OMEGA* watches purchased as of 1 July 2018.
The international OMEGA warranty covers material and manufacturing defects existing at the time
of the purchase of the OMEGA watch ("defects"). The warranty only comes into force if the warranty
certicate is dated, fully and correctly completed and stamped by an ofcial OMEGA dealer ("valid
warranty certicate").
During the warranty period and by presenting the valid warranty certicate, you will have the right to
have any defect repaired free of charge. In the event that repairs are improper to restore the normal
conditions of use of your OMEGA watch, OMEGA SA guarantees its replacement by an OMEGAwatch
of identical or similar characteristics. For all watches purchased as of 1 July 2018, the warranty for the
replacement watch ends sixty (60) months after the date of purchase of the replaced watch.
this manufacturEr’swarranty doEs not covEr:
• The life of the battery.
• Normal wear and tear and ageing (for example scratched crystal; alteration of the colour and/or
material of non-metallic straps and chains, such as leather, textile, rubber).
• Any damage on any part of the watch resulting from abnormal/abusive use, lack of care, negligence,
accidents (knocks, dents, crushing, broken crystal, etc.), incorrect use of the watch and non-
observance of the operating instructions provided by OMEGA SA.
• Any consequential or indirect damage resulting from the use, failure to operate, defects or lack of
precision of the OMEGA watch.
• The OMEGA watch handled by non-authorised persons (for example for battery replacement,
service or repair) or which has been altered in its original condition beyond OMEGA SA’s control.

11
Any further claim against OMEGA SA, for example for damages additional to the above described
warranty is expressly excluded, except mandatory statutory rights the purchaser may have against the
manufacturer.
The above manufacturer’s warranty:
• is independent of any warranty that may be provided by the seller, for which he carries sole
responsibility;
• does not affect the purchaser’s rights against the seller nor any other mandatory statutory rights the
purchaser may have against the seller.
The OMEGA customer service ensures the perfect maintenance of your OMEGA watch. If your watch
needs attention, rely on an authorised OMEGA retailer or an authorised OMEGA Service Centre as set
forth in the enclosed list: they can guarantee service according to OMEGA SA’s standards.
* OMEGA SA
Rue Jakob-Stämpi 96
CH-2502 Bienne
OMEGA®and ®are registered trademarks

12
English
OMEGA INTERNATIONAL WARRANTY
NOTE: If you purchased your OMEGA®watch in Australia or New Zealand, the International
OMEGA* Warranty contained in the booklet provided with this watch and on the OMEGA website
(www.omegawatches.com) does NOT apply to you, and is replaced by this Australian / New Zealand
Warranty (referred to below as the "Warranty").
important noticE rEGardinG your consumEr riGhts
The benets given to you under this Warranty are additional to, and do not detract from, other rights
and remedies that you may have in relation to your OMEGA watch and its purchase under Australian
or New Zealand laws, including consumer protection laws.
In Australia, OMEGA watches come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have your OMEGA
watch repaired or replaced if it fails to be of acceptable quality and the failure does not amount to
a major failure.
In New Zealand, OMEGA watches also come with guarantees that cannot be excluded under the
New Zealand Consumer Guarantees Act.

13
this warranty:
• Is not intended to change or exclude any statutory or consumer rights that cannot be lawfully
changed or excluded;
• Is independent of any warranty that may be provided by the seller, for which he carries sole
responsibility; and
• Does not affect your rights against the seller, including any mandatory statutory rights you may have
against the seller under local consumer laws.
our warranty to you
This Warranty is provided by OMEGA SA of Rue Jakob-Stämpi 96, CH-2502 Bienne, Switzerland.
Telephone [phone].
All OMEGA watches purchased as of 1 July 2018 are guaranteed for 5 years from the date of purchase
under the terms and conditions of this warranty.
This Warranty covers material and manufacturing defects existing at the time of delivery of the
purchased OMEGA watch (“defects”). Where such defects become apparent during the warranty
period and provided you present a valid warranty certicate, OMEGA SA will:
• Repair your watch free of charge; or
• In the event that repairs are unable to restore the normal conditions of use of your OMEGA watch,
replace your watch with an OMEGA watch of identical or similar characteristics. Such replacement
watch will have the benet of this Warranty for the remainder of the Warranty Period applicable to
the original (replaced) watch.

14
English
plEasE bE awarE that:
• Goods presented for repair may be replaced by refurbished goods of the same type rather than
being repaired. Refurbished parts may be used to repair the goods;
• Any data you store in your watch may be lost in the course of a repair. It is your responsibility to back
up any data that may be stored in your watch before presenting it for warranty service; and
• The Warranty is only valid if the warranty certicate enclosed with your OMEGA watch upon purchase
is dated, fully and correctly completed and stamped and signed by authorised OMEGA retailer.
EXclusions and limitations
this warranty doEs not covEr:
• The lifetime of the battery;
• Normal wear and tear and aging (e.g. scratched crystal; alteration of the colour and/or material of
non-metallic straps and chains, such as leather, textile, rubber; peeling of the plating);
• Any damage on any part of the watch resulting from abnormal/abusive use, lack of care, negligence,
accidents (knocks, dents, crushing, broken crystal, etc.), incorrect use of the watch and non-
observance of the use directions provided by OMEGA SA;
• Indirect or consequential damages of any kind resulting from e.g. the use, the non-functioning, the
defects or the inaccuracy of the OMEGA watch; or
• Defects caused by the OMEGA watch being handled by nonauthorized persons (e.g. for battery
replacement, services or repairs) or altered in its original condition beyond OMEGA SA’s control.

15
how to maKE a claim undEr this warranty
To make a claim under this Warranty, we recommend that you wrap your OMEGA watch carefully so as
to avoid any damage and send it by registered mail or drop it off in person to your nearest authorised
OMEGA retailer or an ofcial OMEGA Service Centre. To nd current contact information for your
nearest authorized OMEGA retailer or ofcial OMEGA Service Centre, please telephone [phone]
3300, email [e-mail] or go to www.omegawatches.com.
You will be responsible for paying the expenses associated with making a claim under this Warranty,
including postal or delivery expenses and any relevant taxes.
othEr conditions
No authorised OMEGA retailer or ofcial OMEGA Service Centre is authorised to make any
modication, extension or addition to this Warranty. OMEGA SA provides no warranty against defects
beyond the rights and remedies given under this Warranty and which are available under the Australian
Consumer Law and the New Zealand Consumer Guarantees Act 1993.
* OMEGA SA
Rue Jakob-Stämpi 96
CH-2502 Bienne
OMEGA®and ®are registered trademarks

16
English
PRESENTATION DISPLAYS
The digital display indicators vary according to the function used.
- : Future event
+ : Past event
: Martian function
indicator
Digital display 2
Seconds hand
Digital display 1
Minute hand
Digital display 3
Hour hand
: Earth function indicator

17
PRESENTATION PUSHERS AND CROWN
The indicators for the pusher and crown functions vary according to the function used.
Favourite function
page 44
Display
Back-lighting
Hands clearance
In programming mode
Enter / exit
In navigation mode
Previous function
In function mode
Specicactionaccordingto
the function
In programming mode
Increment
In navigation mode
Switch between groups
In function mode
Enter and programming
In programming mode
Conrmandproceedtonext
setting
In navigation mode
Next function
In function mode
Specicactionaccordingto
function
In programming mode
Decrease
Press once Press twice Press and hold
(~ 3 seconds)

18
English
PRESENTATION NAVIGATION AND PROGRAMMING
The functions of the Speedmaster X-33 Marstimer are separated into 2 groups. You can navigate
between functions using the pushers P1 and P2. Simply pressing the crown will, according to the
selected function, enter, exit or display more information on it. Pressing and holding the crown will
toggle between 2 groups of functions.
In programming mode, the hands move so as to clear the displays.
Programming mode exited automatically after 20 seconds without activity.
When a chime sounds, the displayashes and brings up the function concerned.
To reset a programmable function, enter programming mode for the function, and then select to
erase the programming.
To use the functions on your Speedmaster X-33 Marstimer, there are two examples of missions
available pages 46 and 48.
