Omega Spacemaster Z-33 User manual

OPERATING INSTRUCTIONS

1
English
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . 2
Special recommendations . . . . . . . . . . . . . . . . . . . . . . . .2
Environmental protection . . . . . . . . . . . . . . . . . . . . . . . . .3
OMEGA international warranty (valid for U.S.A. only) . . . . . . . . .4
OMEGA international warranty . . . . . . . . . . . . . . . . . . . . .6
DESCRIPTION AND USE . . . . . . . . . . . . . . . . . . . . 8
Watch components . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SPECIAL FUNCTIONS . . . . . . . . . . . . . . . . . . . . 10
First use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Display lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Favourite functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Energy saving mode . . . . . . . . . . . . . . . . . . . . . . . . . . 11
FUNCTIONS AND SETTINGS . . . . . . . . . . . . . . . . 12
Synchronising hands and setting display modes
(neutral display) . . . . . . . . . . . . . . . . . . . . 12
Local time (TIME 1) . . . . . . . . . . . . . . . . . . 14
Second time zone (TIME 2) . . . . . . . . . . . . . . 16
United Time Coordinated / time difference . . . . . 17
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Calendar . . . . . . . . . . . . . . . . . . . . . . . . 20
Calendar week. . . . . . . . . . . . . . . . . . . . . 21
Chronograph . . . . . . . . . . . . . . . . . . . . . . 22
Flight log . . . . . . . . . . . . . . . . . . . . . . . . 24
TIMER. . . . . . . . . . . . . . . . . . . . . . . . . . 27
GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . 29
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . 29
PICTOGRAMS . . . . . . . . . . . . . . . . . . . . . . . . 30
CONTENTS

2
INTRODUCTION
Special recommendations
What must I do to ensure that my OMEGA watch provides me with excel-
lent service for many years?
Magnetic fields: avoid placing your watch on loudspeakers or refrigera-
tors since they generate powerful magnetic fields which may damage it.
Swimming in the sea: always rinse your watch with fresh water after-
wards.
Shocks: whether they are thermal or other, avoid them.
Crown: push back the crown to its neutral position to prevent water from
penetrating into the mechanism.
Cleaning: for metal bracelets, rubber straps and water-resistant cases,
use a toothbrush and soapy water for cleaning and dry with a soft cloth.
Chemical products: avoid direct contact with solvents, detergents, per-
fumes, cosmetics, etc., since they may damage the bracelet, case or
gaskets.
Temperature: avoid exposing your watch to extreme temperatures
(greater than 60°C or 140°F and less than 0°C or 32°F) or extreme tem-
perature changes.
Water-resistance: a watch's absolute water-resistance cannot be per-
manently guaranteed. It may notably be affected by the ageing of gas-
kets or by an accidental shock to the crown. As stipulated in our service
instructions, we recommend you have the water resistance of your watch
checked once a year by an authorised OMEGA Service Centre.
Chronograph pushers: do not operate chronograph pushers under water
in order to prevent water entering the mechanism.

3
English
What are the service intervals?
Like any precision instrument, a watch needs regular servicing to ensure
that it functions perfectly. We cannot indicate the frequency of such
work, since it depends entirely on the model, the climate and the owner's
individual care of the watch. As a general rule, a watch should be ser-
viced every 4 to 5 years, depending on the conditions in which it is used.
Who should I contact for a maintenance service or battery replace-
ment?
We recommend that you contact an approved OMEGA service centre or
authorised OMEGA retailer. They are equipped with the tools and ap-
paratus required to carry out the work and the necessary checks in a pro-
fessional manner. Furthermore, these specialists can guarantee that their
work is carried out in accordance with OMEGA's strict quality standards.
A worn-out battery should be replaced as quickly as possible in order
to avoid the risk of leakage and consequent damage to the movement.
The type of battery is defined on the guarantee card enclosed with your
watch.
Environmental protection
Collection and treatment of end of life Quartz watches*. This
symbol indicates that this product must not be disposed of with
household waste. It has to be returned to an authorised collection
point. By following this procedure, you will contribute to the protection of
the environment and human health. The recycling of the materials will
help to conserve natural resources.
* Valid in EU member states and in any countries with corresponding leg-
islation.

4
OMEGA international warranty (valid for U.S.A. only)
Introduction
Your OMEGA®watch is warranted by OMEGA SA* for a period of
twenty-four (24) months from the date of purchase under the terms and
conditions of this warranty. The international OMEGA warranty covers
material and manufacturing defects existing at the time of delivery of
the purchased OMEGA watch ("defects"). The warranty only comes into
force if the warranty certificate is dated, fully and correctly completed
and stamped by an official OMEGA dealer ** ("valid warranty certifi-
cate"). During the warranty period and by presenting the valid warranty
certificate, you will have the right to have any defect repaired free of
charge. In the event that repairs are unable to restore the normal condi-
tions of use of your OMEGA watch, OMEGA SA guarantees its repla-
cement by an OMEGA watch of identical or similar characteristics. The
warranty for the replacement watch ends twenty-four (24) months after
the date of purchase of the replaced watch.
This warranty does not cover:
• the life of the battery.
• normal wear and tear and ageing (for example scratched crystal;
alteration of the colour and/or material of non-metallic straps and
chains, such as leather, textile and rubber).
• any damage on any part of the watch resulting from abnormal/abu-
sive use, lack of care, negligence, accidents (knocks, dents, crushing,
broken crystal, etc.), incorrect use of the watch and non-observance
of the operating instructions provided by OMEGA SA.
• the OMEGA watch handled by non-authorised persons (for example
for battery replacement, service or repair) or which has been altered
in its original condition beyond OMEGA's control.

5
English
ALL APPLICABLE IMPLIED WARRANTIES, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY AND OF FITNESS FOR A PAR-
TICULAR PURPOSE GIVEN TO YOU BY LAW ARE HEREBY LIMITED IN
DURATION TO THE DURATION OF THIS WARRANTY. UNDER NO CIR-
CUMSTANCES WILL OMEGA SA BE LIABLE FOR ANY INDIRECT OR
CONSEQUENTIAL DAMAGES OF ANY KIND.
Some states do not allow limitations on how long implied warranties last,
or exclusions or limitations of incidental or consequential damages, so
exclusions or limitations mentioned may not apply to you. This warranty
gives you specific legal rights and you may also have other rights which
may vary from state to state.
OMEGA SA’s OBLIGATION IS STRICTLY LIMITED TO REPAIR OR REPLA-
CEMENT AS EXPRESSLY STATED IN THIS LIMITED WARRANTY. YOUR
OFFICIAL OMEGA DEALER CARRIES SOLE RESPONSIBILITY FOR ANY
OTHER GUARANTEES.
The OMEGA customer service ensures the perfect working order of your
OMEGA watch. If your watch needs maintenance, rely on an official
OMEGA dealer or an authorized OMEGA Service Center as set forth in
the enclosed list: they can guarantee service according to OMEGA SA’s
standards.
* OMEGA SA
Rue Stämpfli 96, CH-2500 Bienne 4
** OMEGA SA Specialist Dealer in EU countries
OMEGA®and ®are registered trademarks

6
OMEGA international warranty
Introduction
Your OMEGA®watch is warranted by OMEGA SA* for a period of
twenty-four (24) months from the date of purchase under the terms and
conditions of this warranty. The international OMEGA warranty covers
material and manufacturing defects existing at the time of delivery of
the purchased OMEGA watch ("defects"). The warranty only comes into
force if the warranty certificate is dated, fully and correctly completed
and stamped by an official OMEGA dealer ** ("valid warranty certifi-
cate"). During the warranty period and by presenting the valid warranty
certificate, you will have the right to have any defect repaired free of
charge. In the event that repairs are unable to restore the normal condi-
tions of use of your OMEGA watch, OMEGA SA guarantees its replace-
ment by an OMEGA watch of identical or similar characteristics. The
warranty for the replacement watch ends twenty-four (24) months after
the date of purchase of the replaced watch.
* OMEGA SA
Rue Stämpfli 96, CH-2500 Bienne 4
** OMEGA SA Specialist Dealer in EU countries
OMEGA®and ®are registered trademarks

7
English
This warranty does not cover:
• the life of the battery.
• normal wear and tear and ageing (for example scratched crystal;
alteration of the colour and/or material of non-metallic straps and
chains, such as leather, textile and rubber).
• any damage on any part of the watch resulting from abnormal/abu-
sive use, lack of care, negligence, accidents (knocks, dents, crushing,
broken crystal, etc.), incorrect use of the watch and non-observance
of the operating instructions provided by OMEGA SA.
• any consequential or indirect damage resulting from the use, failure to
operate, defects or lack of precision of the OMEGA watch.
• the OMEGA watch handled by non-authorised persons (for example
for battery replacement, service or repair) or which has been altered
in its original condition beyond OMEGA's control.
Any other claims against OMEGA SA, for example for damages other
than those defined in this warranty, are expressly excluded, except for
mandatory statutory rights the purchaser may have against the manu-
facturer.
This manufacturer's warranty:
• is independent of any warranty that may be provided by the retailer
and for which the retailer carries sole responsibility.
• does not affect the purchaser's rights with respect to the retailer nor
any other mandatory statutory rights the purchaser may have against
the retailer.
The OMEGA SA customer service ensures the perfect maintenance of
your OMEGA watch. If your watch needs attention, use an official OME-
GA dealer or an authorised OMEGA Service Centre. They can guaran-
tee a service which corresponds to OMEGA SA's standards.

8
DESCRIPTION AND USE
The information contained in this document is for stand-
ard use of this model .
For more information, consult the Internet site
(www.omegawatches.com/spacemaster-z33).
Watch components
Displays
am/pm display
(AM or PM)
When the 12h mode is
selected (page 12)
Function display
According to mode
selected
Flight log
Flight being recorded
(page 24)
Display
Hours and values

9
English
Pushers and crown
Chrono/Timer
Start/stop
(page 22 and page 27)
Setting mode
Validation of the setting
and access to
the next setting
Alarm
On/Off (page 18)
Selection of the
functions
Access to the
setting mode
Modification of
the values
Return to
Normal mode
Press once
Press twice
Press and hold
Favourite functions
(page 11)
General
Press once = to light up and
clear the hands
(page 11)
Press twice = to record a flight
sequence
(page 24)
Chrono/Timer
Reset to initial value/
split/reset to zero.
(page 22 and page 27)
Flight log
Deletion of 1 or
all the flights (page 26)
Time 2
Return to local time
(Setting mode) (page 16)
or

10
SPECIAL FUNCTIONS
First use
Before using the flight log for the first time, you must:
• choose the flight log operating mode, page 12;
• set the time (TIME 1), page 14;
• set the UTC time difference, page 17;
• set the calendar, page 20.
Display lighting
This function:
• clears the hands to improve the visibility of the display;
• increases the brightness of the display if the ambient lighting is not
sufficient.
Use
1
To clear the hands (at 3
o'clock or 9 o'clock) and
increase the brightness of the
display.
After 5 seconds the hands return to their position and the bright-
ness of the display returns to its previous setting.

11
English
Favourite functions
This allows you to quickly access two favourite functions.
Use
1Display the desired function.
2Press for 3 seconds to record
the function.
3Press to move between the
two favourite functions.
Energy saving mode
This allows you to save the battery by blocking the hands and deactivat-
ing the display.
Use
1Simultaneously press for 5
seconds.
2Press the crown to exit the
mode.
In the energy saving mode, the time, date and recorded flights are
not lost. However, all the measurements in progress (chronograph,
flight time and timer measurements) are stopped.
or

12
FUNCTIONS AND SETTINGS
Synchronising hands and setting display modes (neutral
display)
This function allows you to:
• control and set the synchronization of the hands;
• set the time display mode (24h or 12h);
• set the day and month display mode
(day/month or month/day);
• select the flight log operating mode (page 24).
Display
1Neutral mode (no display)
Setting
1To start the synchronization
of the hands with the digital
display.
2To move the hour hand.
In 1 hour intervals.
3To validate the hours.
To access the set minutes
function.
or

13
English
4To move the minute hand.
In half-minute intervals.
5To validate the minutes.
To access the set seconds
function.
6To move the second hand.
In 1 second intervals in the
clockwise direction only.
7To validate the synchroniza-
tion and access the set time
display mode.
8To select the time display
mode.
9To validate the setting and
access the set day/month
display mode.
10 To select the day/month or
month/day display mode.
11 To validate the setting and
access the select flight log
operating mode.
Go to next page.

14
12 To select the flight log operat-
ing mode:
BLOCK UTC = "BLOCK TO BLOCK" with UTC time;
BLOCK LOCAL = "BLOCK TO BLOCK" with local time;
FLT UTC = "Flight time" with UTC time;
FLT LOCAL = "Flight time" with local time.
The flights are shown with the following indications: BO (BLOCK
to BLOCK time) and F0 (Flight time).
13 To validate the settings and
return to the neutral display.
Local time (TIME 1)
Displaying and setting the local time.
This setting is not possible when a flight sequence is being record-
ed ( ).
The TIME 2 and UTC settings are based on TIME 1. It is therefore
essential to carry out this setting first.
Display
1To display the local time.
or

15
English
Setting
1To access the setting mode.
2To set the hours.
3To validate the hours.
To access the set minutes
function.
4To set the minutes.
5To validate the minutes.
To access the set seconds
function.
6To set the seconds.
7To validate the settings.
You are asked if you want to
set the UTC time difference.
Displayed for 5 seconds.
8You have 5 seconds to start the
procedure for setting the UTC
time difference (page 17).
9
If you have not started the
procedure within 5 seconds,
the Setting mode is exited and
the local time is displayed.

16
Second time zone (TIME 2)
Displaying and setting the second time zone.
Display
1To display the second time
zone.
Setting
1To access the setting mode.
2To set the time of the second
time zone.
In 30 minute intervals.
Return to the local time (TIME 1).
3To validate the settings.
To display the time of the
second time zone.
or

17
English
United Time Coordinated / time difference
Displaying the United Time Coordinated (UTC).
Display
1To display the UTC.
Setting
The setting corresponds to the difference between the local time
and the UTC. The value may be negative if the UTC is behind the
local time.
This setting is not possible when a flight sequence is being record-
ed ( ).
1To access the setting mode.
2To set the difference between
the local time and the UTC.
In 30 minute intervals.
3To validate the settings.
To display the UTC.
or

18
Alarm
Displaying, activating and setting the alarm.
Display
1To display the alarm time.
Activation
1Press to switch the alarm ON
or OFF.
Activation = beep!
Setting
1To access the setting mode.
2To set the alarm hour.
3To validate the hour.
To access the set minutes
function.
4To set the minutes.
5To validate the minutes.
To access the set days func-
tion.
or
