UserManual
Version1.03
Safety Rules
Symbols used in this manual
Thefollowingsymbolsareusedtoidentifyimportantsafetyinformation
WARNING!Laseremissionispossible.Assurelasersafetyprecautions.
CAUTION:Specialattentiontothispointisnecessarytomeethealthregulations
andtoavoiddamage.
Animportantnotetoensureanunproblematicoperation.
Important safety information
BeforeoperatingtheLightHUB®ULTRAlasersystem,readthemanualcarefullytoprevent
damagestohumanpersonsoranimals,integrateddevicesandconnecteddevices.
AlwaysfollowthelocalorIEC‐safetyrules(IEC60825‐1)duringtheoperationofthesystem.
WARNING:Thelasersystememitsvisibleorinvisiblecontinuouslaser
radiation.Thesystemisvariablyequippedwithdifferentlaserdiodesand
differentoutputpower.
Thelaserproductclassificationsare:
WARNING!
Read the safety precautions in this section
before installing, powering, operating or
servicing this product.

UserManual
Version1.0
4
CLASS3Blaserproduct,forupto100/500mWoutput‐power
CLASS4laserproduct,forupto1Woutput‐power
Theclassificationsareevaluatedandtestedunderworstcaseconditions.Laserdiode
basedlasersareabletooutput10xhigheroutput‐powerunderworstcaseconditions,
comparingtothenormaloperatingcondition.Avoidexposureofthelaserbeamorstray
laserlighttotheeyesandtheskin!
Beawareofthelasersafetyrulesandpayattentiontothefollowingpoints:
Donotlookatanylaserlightdirectlyorthroughopticallenses.
Installationofaspecialworkingareaforthelaserisrecommended,whichonly
givesaccesstospecialtrainedandasfaraslasersafetygoes,instructedpersons.
Warninglabelshavetobeperceptiblyplacedatallentriesoftheareathelaseris
installedandrunning.
Whereveritispossible,thebeamshouldbesheathedbyatube,topreventdirect
accesstothelaserbeam.
Theworkingareaofthelasershouldbeshieldedtopreventuncontrolledescape
ofthelaserbeam.Afterpassingtheexperimental/workingareathebeammust
beblockedbyanappropriatetarget,whichabsorbsthelaserlight.
Thelaserbeamshouldnotrunateyelevel.
Wearappropriatesafetyglassestopreventlightfromenteringtheeye,even
reflectionsfromanysurfaces.
NotesfortheLightHUB®ULTRAlasersystemaboutdifferentlaserdiodesandwavelengths:
TheLightHUB®ULTRAlasersystemisavailableindifferentwavelengthsand
powerlevels.Thelaserclasshastobere‐classifiedafteranymodificationand
changestothesystem.DonotmakeanyothermodificationtotheLightHUB®
ULTRAlasersystemthanspecifiedinhere.
Bewareofthedifferentsafetyrulesregardingthedifferentsafetyclasses.
Notesabouttheelectricalsafety:
TheLightHUB®ULTRAlasersystemcomeswiththebuildinpowersupply.The
electricalunitsshouldnotbeoperatedinhazardousenvironment.
Alwayscheckforloosenconnectorsorwires.
Donottouchanynotisolated(duetodamage)electricalparts,bewareof
electricalshock.
Alwayscheckfixedcableconnections.

UserManual
Version1.05
CAUTIONforOEM‐usage:
TheLightHUB®ULTRAlasersystemisalsoavailableasanOEM‐product.Thenitis
onlyforusageinsystemssuchascustomerdesigns.Thenthecustomerhasto
includethelasersysteminthesafety‐interlockchainandmainkey‐controland
laser‐emissionindication.TheOEM‐customerisresponsibleforasafeoperation
oftheLightHUB®ULTRAlaserCLASS3BorCLASS4product.InanykindofOEM
usage,theInterlockandsafetyshuttercircuitsmustbeevaluatedandtestedin
theend‐useapplication.Wewillbegladtogivedetailedassistancetoour
customer,ifthereareanyquestionsinsafesystemintegration.
Laser warning and explanatory labels
TheLightHUB®ULTRAlasersystemisdesignedasalaserclass3Borclass4product.It
complieswiththerulesoftheIEC60825‐1andwithFDAperformancestandardsforlaser
productsexceptfordeviationspursuanttoLaserNoticeNo50,datedJune24,2007.
ATTENTION:Donotlookintothebeamorintoreflectionsofthe
beamfromsurfaces!
Whenoperatingthelaserunderopenenvironmentinstallation,itmayemitstray‐light,
whichisahealthhazardfortheeyesandskin.Alwayswearprotectiveeye‐goggles
accordingtotheusedlaserwavelength.Avoidexposureoflaserlighttotheskinandeye.
CAUTION:Useofcontrolsoradjustmentsorperformanceofprocedures
otherthanthosespecifiedhereinmayresultinhazardousradiation
exposure!
ThefollowingpictureshowsanexampleforaLightHUB®ULTRAsystem.
Figure1:LightHUB®ULTRAlasersystemrearview

UserManual
Version1.0
6
Thefollowinglabelsarefixedatthelasersystemnexttothefibreoutput:
1. Laser‐warningsign(common):
2. Laser‐warningandlaserrayexplanatorylabel:
Class3B:
Fortheinvisible‐range(UV):Wavelength/outputpower:
375[nm]/20[mW] 375[nm]/70[mW]395[nm]/120[mW]
Forthevisible‐range(VIS):Wavelength/outputpower:
405[nm]/20[mW]405[nm]/60[mW]405[nm]/120[mW]
405[nm]/300[mW]415[nm]/120[mW]425[nm]/120[mW]
445[nm]/50[mW]445[nm]/100[mW]457[nm]/100[mW]
460[nm]/100[mW]473[nm]/20[mW]473[nm]/80[mW]
473[nm]/100[mW]488[nm]/25[mW]488[nm]/60[mW]
Size: 52x26mm
Colour: yellow/black
Location:topcover,frontside
Size: 15x15mm
Colour: yellow/black
Location:frontside,leftsideaperture
Size: 52x26mm
Colour: yellow/black
Location:topcover,frontside

UserManual
Version1.07
Size: 52x26mm
Colour: yellow/black
Location:topcover,frontside
488[nm]/80[mW]488[nm]/100[mW]488[nm]/150[mW]
488[nm]/200[mW]505[nm]/80[mW]515[nm]/20[mW]
515[nm]/25[mW]515[nm]/80[mW]515[nm]/100[mW]
515[nm]/150[mW]532[nm]/20[mW]532[nm]/50[mW]
532[nm]/80[mW]532[nm]/100[mW]532[nm]/150[mW]
552[nm]/20[mW]552[nm]/60[mW]552[nm]/80[mW]
552[nm]/100[mW]552[nm]/150[mW]561[nm]/20[mW]
561[nm]/50[mW]561[nm]/80[mW]561[nm]/100[mW]
561[nm]/150[mW]594[nm]/20[mW]594[nm]/60[mW]
594[nm]/100[mW]633[nm]/100[mW]638[nm]/40[mW]
638[nm]/100[mW]638[nm]/150[mW]638[nm]/200[mW]
642[nm]/140[mW]647[nm]/140[mW]660[nm]/130[mW]
685[nm]/50[mW]
Fortheinvisible‐range(IR):Wavelength/outputpower:
705[nm]/40[mW]730[nm]/40[mW]785[nm]/120[mW]
785[nm]/200[mW]808[nm]/140[mW]830[nm]/140[mW]
Class4:
Forthevisible‐range(VIS):Wavelength/outputpower:higherthan500mW
Size: 52x26mm
Colour: yellow/black
Location:topcover,frontside

UserManual
Version1.0
8
Size: 52x26mm
Colour: yellow/black
Location:topcover,frontside
63110 Rodgau, Germany
Model: LightHUB ULTRA
S/N: xxxxxxx
Manufactured: mm/
yyyy
Size: 46x26mm
Colour: silver/black
Location:backside
Fortheinvisible‐range(IR):Wavelength/outputpower:higherthan500mW
3. Identificationofmanufacturerexplanatorylabel:
4. FDAcertificationlabel:
Size: 46x26mm
Colour: silver/black
Location:onthetopcoveratthe
front
ComplieswithFDAperformance
standardsforlaser
productsexceptfordeviations
pursuanttoLaserNoticeNo50,
datedJune24,2007.

UserManual
Version1.09
